MULTI-CD CONTROL HIGH POWER CASSETTE PLAYER WITH RDS TUNER
KEH-P5010R X1M/EW
Service
Manual
CONTENTS
1. SAFETY INFORMATION ............................................2
2. EXPLODED VIEWS AND PARTS LIST.......................2
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ...12
4. PCB CONNECTION DIAGRAM ................................38
5. ELECTRICAL PARTS LIST ........................................46
6. ADJUSTMENT..........................................................53
7. GENERAL INFORMATION .......................................54
7.1 DIAGNOSIS ........................................................54
7.1.1 DISASSEMBLY .........................................54
7.1.2 CONNECTOR FUNCTION DESCRIPTION55
7.2 PARTS .................................................................56
7.2.1 IC................................................................56
7.2.2 DISPLAY....................................................63
7.3 OPERATIONAL FLOW CHART...........................65
8. OPERATIONS AND SPECIFICATIONS.....................66
KEH-P5010R/X1M/EW
-This service manual should be used together with the following manual(s):
Model No. Order No. Mech. Module Remarks
CX-1011 CRT2406 3L Cassette Mech. Module:Mech.Description, Disassembly, Adjustment
-This service manual does not describe the CD test mode.
For the operations in the CD test mode, refer to the CD player's Service manual.
MULTI-CD CONTROL HIGH POWER CASSETTE PLAYER WITH FM/MW/LW TUNER
KEH-P5011 X1M/EE
HIGH POWER CASSETTE PLAYER WITH FM/MW/LW TUNER
KEH-4011 X1M/EE

2
KEH-P5010R,P5011,4011
1. SAFETY INFORMATION
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
and refer the repair to a qualified service technician.
2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING
10
1
13
7
11
9
8
12
2
5
4
6
3
14

3
KEH-P5010R,P5011,4011
1 Cord Assy See Contrast table(2)
2 Accessory Assy CEA1917
3 Screw CBA1304
4 Handle CNC5395
5 Bush CNV3930
* 6 Polyethylene Bag E36-615
7 Polyethylene Bag CEG-162
8 Carton See Contrast table(2)
9 Contain Box See Contrast table(2)
10 Protector CHP2346
11 Protector CHP2347
12-1 Owner’s Manual See Contrast table(2)
12-2 Owner’s Manual See Contrast table(2)
12-3 Installation Manual See Contrast table(2)
* 12-4 Passport See Contrast table(2)
* 12-5 Warranty Card CRY1157
* 12-6 Caution Card CRP1238
13 Case Assy CXB3520
14 Inner Box See Contrast table(2)
Mark No. Description Part No. Mark No. Description Part No.
(1) PACKING SECTION PARTS LIST
NOTE:
-Parts marked by “*” are generally unavailable because they are not in our Master Spare Parts List.
-Screws adjacent to ∇mark on the product are used for disassembly.
-Owner's Manual, Installation Manual
Model Part No. Language
KEH-P5010R/X1M/EW CRD3286 English, Spanish, German
CRD3287 French, Italian, Dutch
CRD3293 English, Spanish, German,
French, Italian, Dutch
KEH-P5011/X1M/EE CRD3358 English, Russian
CRD3359 English, Russian
KEH-4011/X1M/EE CRD3292 English, Russian
CRD3296 English, Russian
Part No.
Mark No. Symbol and Description KEH-P5010R/X1M/EW KEH-P5011/X1M/EE KEH-4011/X1M/EE
1 Cord Assy CDE6514 CDE6222 CDE6548
8 Carton CHG4179 CHG4276 CHG4181
9 Contain Box CHL4179 CHL4276 CHL4181
12-1 Owner's Manual CRD3286 CRD3358 CRD3292
12-2 Owner's Manual CRD3287 Not used Not used
12-3 Installation Manual CRD3293 CRD3359 CRD3296
* 12-4 Passport CRY1013 Not used Not used
14 Inner Box CHW1754 Not used Not used
(2) CONTRAST TABLE
KEH-P5010R/X1M/EW, KEH-P5011/X1M/EE and KEH-4011/X1M/EE are constructed the same except for
the following:

4
KEH-P5010R,P5011,4011
2.2 EXTERIOR(KEH-P5010R/X1M/EW)
A
B

5
KEH-P5010R,P5011,4011
1 Screw BSZ26P050FMC
2 Screw BSZ30P050FMC
3 Screw BSZ30P200FMC
4 Cord Assy CDE6514
5 Fuse(10A) CEK1136
6 Case CNB2350
7 Holder CNC5704
8 Cushion CNM5210
9 Insulator CNM7083
10 Tuner Amp Unit CWM7327
11 Screw BPZ26P080FMC
12 Screw BSZ26P080FMC
13 Screw BSZ26P160FMC
14 Cord CDE6450
15 FM/AM Tuner Unit CWE1562
16 Holder CNC8815
17 Pin Jack(CN301) CKB1035
18 Terminal(CN403) CKF1059
19 Plug(CN952) CKM1270
20 Connector(CN751) CKS3408
21 Connector(CN602) CKS3568
22 Connector(CN601) CKS3581
23 Antenna Jack(CN401) CKX1056
24 Panel CNB2341
25 Holder CNC6845
26 Holder CNC7996
27 Heat Sink CNR1505
28 Detach Grille Assy CXB6154
29 Screw BPZ20P100FZK
30 Button(DETACH) CAC5789
31 Button(1–6) CAC6822
32 Button(A,B) CAC6823
33 Button(EJECT, BSM) CAC6824
34 Button(CROSS) CAC6825
35 Button(+,-) CAC6834
36 Button(SOURCE) CAC6851
37 Spring CBH2210
38 Cover CNS6171
39 Keyboard Unit CWM7339
40 LCD(LCD1902) CAW1616
41 Connector(CN1901) CKS3580
42 Holder CNC9091
43 Spacer CNM5043
44 Sheet CNM7059
45 Rubber CNV6480
46 Lighting Conductor CNV6495
47 Lighting Conductor CNV6496
48 Connector CNV6497
49 Grille Unit CXB6332
50 Chassis Unit CXB6659
51 Holder Unit CXB6681
52 Button CAC4836
53 Spring CBH1834
54 Spring CBH1835
55 Spring CBH2182
56 Bracket CNC6135
57 Bracket CNC6791
58 Arm CNV4692
59 Arm CNV4693
60 Arm CNV4728
61 Panel Unit CXB6715
62 Door CAT2109
63 Spring CBH1838
64 Screw IMS20P030FZK
65 Cassette Mechanism Module EXK4170
66 Screw ISS26P055FUC
67 IC(IC301) PAL006A
68 Transistor(Q951) 2SD2396
69 IC(IC1902) SBX8035-H
70 Terminal Cover CKX-003
-EXTERIOR SECTION PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.

6
KEH-P5010R,P5011,4011
2.3 EXTERIOR(KEH-P5011/X1M/EE)
A
B

7
KEH-P5010R,P5011,4011
1 Screw BSZ26P050FMC
2 Screw BSZ30P050FMC
3 Screw BSZ30P200FMC
4 Cord Assy CDE6222
5 Fuse(10A) CEK1136
6 Case CNB2350
7 Holder CNC5704
8 Cushion CNM5210
9 Insulator CNM7083
10 Tuner Amp Unit CWM7647
11 Screw BPZ26P080FMC
12 Screw BSZ26P080FMC
13 Screw BSZ26P160FMC
14 Cord CDE6450
15 FM/AM Tuner Unit CWE1566
16 Holder CNC8815
17 Pin Jack(CN301) CKB1035
18 Terminal(CN403) CKF1059
19 Plug(CN952) CKM1270
20 Connector(CN751) CKS3408
21 Connector(CN602) CKS3568
22 Connector(CN601) CKS3581
23 Antenna Jack(CN401) CKX1056
24 Panel CNB2341
25 Holder CNC6845
26 Holder CNC7996
27 Heat Sink CNR1505
28 Detach Grille Assy CXB6909
29 Screw BPZ20P100FZK
30 Button(DETACH) CAC5789
31 Button(1–6) CAC6822
32 Button(A,B) CAC6823
33 Button(EJECT, BSM) CAC6824
34 Button(CROSS) CAC6825
35 Button(+,-) CAC6821
36 Button(SOURCE) CAC6851
37 Spring CBH2210
38 Cover CNS6171
39 Keyboard Unit CWM7648
40 LCD(LCD1902) CAW1635
41 Connector(CN1901) CKS3580
42 Holder CNC9091
43 •••••
44 Sheet CNM7059
45 Rubber CNV6480
46 Lighting Conductor CNV6495
47 Lighting Conductor CNV6496
48 Connector CNV6497
49 Grille Unit CXB6948
50 Chassis Unit CXB6660
51 Holder Unit CXB6681
52 Button CAC4836
53 Spring CBH1834
54 Spring CBH1835
55 Spring CBH2182
56 Bracket CNC6135
57 Bracket CNC6791
58 Arm CNV4692
59 Arm CNV4693
60 Arm CNV4728
61 Panel Unit CXB6715
62 Door CAT2109
63 Spring CBH1838
64 Screw IMS20P030FZK
65 Cassette Mechanism Module EXK4150
66 Screw ISS26P055FUC
67 IC(IC301) TA8277H
68 Transistor(Q951) 2SD2396
-EXTERIOR SECTION PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.

8
KEH-P5010R,P5011,4011
2.4 EXTERIOR(KEH-4011/X1M/EE)
A
B

9
KEH-P5010R,P5011,4011
1 Screw BSZ26P050FMC
2 Screw BSZ30P050FMC
3 Screw BSZ30P200FMC
4 Cord Assy CDE6548
5 Fuse(10A) CEK1136
6 Case CNB2350
7 Holder CNC5704
8 Cushion CNM5210
9 Insulator CNM7083
10 Tuner Amp Unit CWM7493
11 •••••
12 Screw BSZ26P080FMC
13 Screw BSZ26P160FMC
14 Cord CDE6450
15 FM/AM Tuner Unit CWE1566
16 Holder CNC8815
17 •••••
18 Terminal(CN403) CKF1059
19 Plug(CN952) CKM1270
20 •••••
21 Connector(CN602) CKS3568
22 Connector(CN601) CKS3581
23 Antenna Jack(CN401) CKX1056
24 Panel CNB2631
25 Holder CNC6845
26 Holder CNC7996
27 Heat Sink CNR1505
28 Detach Grille Assy CXB6645
29 Screw BPZ20P100FZK
30 Button(DETACH) CAC5789
31 Button(1–6) CAC6822
32 Button(A,B) CAC6823
33 Button(EJECT, BSM) CAC6824
34 Button(CROSS) CAC6825
35 Button(+,-) CAC6821
36 Button(SOURCE) CAC6851
37 Spring CBH2210
38 Cover CNS6171
39 Keyboard Unit CWM7495
40 LCD(LCD1902) CAW1635
41 Connector(CN1901) CKS3580
42 Holder CNC9091
43 •••••
44 Sheet CNM7059
45 Rubber CNV6480
46 Lighting Conductor CNV6495
47 Lighting Conductor CNV6496
48 Connector CNV6497
49 Grille Unit CXB6709
50 Chassis Unit CXB6660
51 Holder Unit CXB6681
52 Button CAC4836
53 Spring CBH1834
54 Spring CBH1835
55 Spring CBH2182
56 Bracket CNC6135
57 Bracket CNC6791
58 Arm CNV4692
59 Arm CNV4693
60 Arm CNV4728
61 Panel Unit CXB6715
62 Door CAT2109
63 Spring CBH1838
64 Screw IMS20P030FZK
65 Cassette Mechanism Module EXK4150
66 Screw ISS26P055FUC
67 IC(IC301) TA8277H
68 Transistor(Q951) 2SD2396
-EXTERIOR SECTION PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.

10
KEH-P5010R,P5011,4011
2.5 CASSETTE MECHANISM MODULE
C
D

11
KEH-P5010R,P5011,4011
1 Screw BSZ20P040FMC
2 Washer CBF1037
3 Washer CBG1003
4 Screw EBA1028
5 Screw CBA1037
6 Spring EBH1531
7 Spring EBH1642
8 Spring EBH1641
9 Spring EBH1626
10 Spring EBH1627
11 Spring EBH1649
12 Cord EDD1024
13 Photo-reflector(EGN1) EGN1004
14 Arm ENC1526
15 Lever ENC1544
16 Lever ENC1543
17 Arm ENC1532
18 Frame ENC1533
19 Holder ENC1534
20 Gear ENC1535
21 Arm ENC1550
22 Roller ENR1040
23 Belt ENT1027
24 Collar ENV1508
25 Arm ENV1539
26 Arm ENV1540
27 Gear ENV1544
28 Gear ENV1547
29 Gear ENV1560
30 Worm Wheel ENV1566
31 Lever ENV1551
32 Flywheel ENV1554
33 Gathering PCB ENX1068
34 Switch(S1,S2) ESG1007
* 35 Deck Unit EWM1032
36 Plug(CN251) CKS3540
37 Gathering PCB ENX1067
38 Motor Unit(M1) EXA1491
39 Motor EXM1028
40 Head Assy(HD1) EXA1592
41 Motor Unit(M2) EXA1580
42 Screw BMZ20P022FMC
43 Bracket ENC1528
44 Chassis Unit EXA1615
45 Pinch Holder Unit EXA1608
46 Pinch Roller ENV1518
47 Pinch Holder Unit EXA1607
48 Pinch Roller ENV1518
49 Reel Unit EXA1585
50 Head Base Unit EXA1611
51 Lever Unit EXA1587
52 Gear Unit EXA1596
53 Motor Unit(Service) EXX1055
54 Washer HBF-179
55 Spring EBH1537
Mark No. Description Part No. Mark No. Description Part No.
-CASSETTE MECHANISM MODULE SECTION PARTS LIST

12
KEH-P5010R,P5011,4011
1234
1234
D
C
B
A
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM
3.1 BLOCK DIAGRAM(KEH-P5010R/X1M/EW)
TUNER Lch
Q702
Q472 Q703
LDET
TMUTE
B.U VDD
Q952
SYSPW
TMUTE
SYSPW
VDD
AVDD
61 27 74 68
SYSTEM
CONTROLLER
PE5197A
IC601(1/2)
TUN-L
TUN-L ELECTRONIC VOLUME
PML003AM
IC201 11
10
2
4
TAPE-L
RL
FL
POWER AMP
IC301
12
14
MUTE STBY
FL
RL
FL+
FL-
RL+
RL-
22 4
9
7
19
17
SYSPW B.U
B.U
SYSPW
Q302
Q951 Q959 Q301
Q953
Q601
Q602
MUTE
8.4V
REGULATOR
RESET
IC604
S-80834ANY
VCC
VDD
560
1
2
66 65
70
69
6
41
31
MUTE
RESET
BSENS
ASENS
SWVDD
DPDT
KYDT
DSENS
RIMUTE
STBY
LOADSW
X1
X2
TELIN
SYSTEM
CONTROLLER
IC601(2/2)
PE5197A
X601
Q954
BSENS
ASENS ACC
FUSE
10A
TEL MUTE
Q611
B.U
STBY
B.U
MUTE
LOAD 46
63 8919
Q650
SWVDD
VDD
SW5V
ILL
KYDT
DPDT
SW5V
VDD SWITCH
5
1
4
2
1
3
4
11
9
20
19
3
4
11
9
20
19
9
6
2
1
5
8
7
ATUNER AMP UNIT
CDECK UNIT
BKEYBOARD UNIT
734 5
734 5
LCD DRIVER
IC1901
PD6293A
DPDT
KYDT
VDD
VLCD
XO
XI
X901
18
20
56 10
22 23
IC251
HA12229F
IC351
PA2020A
EQ AMP
MECHANISM
DRIVER
CN251
CN252
CN254
CN255
CN253
6
15 TAPE+B
Lch
20
FWD
L-ch
REV
L-ch
39
32
33
18 19
17
315 6
8710
CN256 315 6
S1
LOAD
S2
MODE
EGN1
REEL
SENSE
M
M
M2
SUB
MOTOR
M1
MAIN
MOTOR
5
2
1
DREEL SENSE PCB
CN602
CN952
CN901
CN601
CN1901
VCK/VDT/VST
ACC
BACK UP
FL+
FL-
RL-
RL+
TEL MUTE
B.REMOTE
VCC
LOUT
RIMUTE
LDSW
STBY
KEY MATRIX
LCD
IC 3
EEPROM
ANTENNA
JACK 1
2
FM/AM TUNER UNIT
28
27
FM/AM 1ST IF 10.7MHz
T51 Q51 CF51 CF52 CF53
IC1
MIXER, IF AMP, DET.
6
21
18
LDET
COMP
22
25 10 14 12 15 16 8 13 2 3 4
CF202
VDD
LOCL
VCC
Q401
VCC VDD
DI/DO CE2 CK CE1 SDBW SL FMSD
PCE2
TUNPCK
TUNPCE
SDBW
SL
SD
PDIO
NL1 NL2
IC 2 FM MPX
NL1
LDET
15
RDS
DECODER
IC 701
PM4009A
20
11 12
24
X702
Q701
VDD
FM/AM FM/AM
55
78 NL1
SD
SL
SDBW
TUNPCE
TUNPCK
TUNPCE2
TUNPDO
LOCL
1
76
48
14
13
28
12
25 TUNPDI
11
PDIO
SWVDD
POWER SWITCH
1
6IC602
TPD1018F
8
8
DSENS
A
A
AMANT
FMANT
ATT
ATT
AMRF
FMRF
IMG ADJ
RF ADJ
X901
10.25MHz
ANTSW
LOCL
23 LOCH
AMDET
MPXREF 41kHz
AM 2ND IF
450kHz
19
CREQCURRQ
11
DGND
DGND
1
STIND
ST
L ch
ST
2
CURRQ
30
PAL006A
1
2
8
5
6
B.U
TX
RX
IPPW
ASENBO
IP-BUS DRIVER
IC751
HA12187FP
BUSL1
BUSL2
BUS2
BUS1
Q751
Q752
8
1
5
11
7
CN751
IP-BUS
BUSL1 5
BUSL2 61
2
CN301
Q346
Q205 MUTE
TX
RX
17
61
20 ASEMBO
IPPW
21
REMOTE CONTROL
SENSOR
IC1902
SBX8035-H
3
1
17
REM
RR
+
RR
-
FR
+
FR
-
FL
+
FL
-
RL
+
RL
-
ACC
GND
B.
REM
BACK
UP
LOCH
LOCH
26
CN401
REAR OUTPUT
L
5
R ch
924
NC FMLOCL
20177
NC NC WC
26 RFGND
NL2
79 NL2DT
NL2
9
PEE
45
PEE
B.REM
10
B.U
5

13
KEH-P5010R,P5011,4011
1234
1234
D
C
B
A
3.2 BLOCK DIAGRAM(KEH-P5011/X1M/EE, KEH-4011/X1M/EE)
TUNER Lch
Q703
B.U VDD
Q952
SYSPW
SYSPW
VDD
AVDD
27 74 68
SYSTEM
CONTROLLER
PE5198A
IC601(1/2)
TUN-L
TUN-L ELECTRONIC VOLUME
PML003AM
IC201 11
10
2
4
TAPE-L
RL
FL
POWER AMP
IC301
12
14
MUTE STBY
FL
RL
FL+
FL-
RL+
RL-
22 4
9
7
19
17
SYSPW B.U
B.U
SYSPW
Q302
Q951 Q959 Q301
Q953
Q601
Q602
MUTE
8.4V
REGULATOR
RESET
IC604
S-80834ANY
VCC
VDD
560
1
2
66 65
70
69
6
41
31
MUTE
RESET
BSENS
ASENS
SWVDD
DPDT
KYDT
DSENS
RIMUTE
STBY
LOADSW
X1
X2
TELIN
SYSTEM
CONTROLLER
IC601(2/2)
PE5198A
X601
Q954
BSENS
ASENS ACC
FUSE
10A
TEL MUTE
Q611
B.U
STBY
B.U
MUTE
LOAD 46
63 8919
Q650
SWVDD
VDD
SW5V
ILL
KYDT
DPDT
SW5V
VDD SWITCH
5
1
4
2
1
3
4
11
9
20
19
3
4
11
9
20
19
9
6
2
1
5
8
7
ATUNER AMP UNIT
CDECK UNIT
BKEYBOARD UNIT
734 5
734 5
LCD DRIVER
IC1901
PD6293A
DPDT
KYDT
VDD
VLCD
XO
XI
X901
18
20
56 10
22 23
IC251
HA12229F
IC351
PA2020A
EQ AMP
MECHANISM
DRIVER
CN251
CN252
CN254
CN255
CN253
6
15 TAPE+B
Lch
20
FWD
L-ch
REV
L-ch
39
32
33
18 19
17
315 6
8710
CN256 315 6
S1
LOAD
S2
MODE
EGN1
REEL
SENSE
M
M
M2
SUB
MOTOR
M1
MAIN
MOTOR
5
2
1
DREEL SENSE PCB
CN602
CN952
CN901
CN601
CN1901
VCK/VDT/VST
ACC
BACK UP
FL+
RL-
TEL MUTE
B.REMOTE
VCC
LOUT
RIMUTE
LDSW
STBY
KEY MATRIX
LCD
IC 3
EEPROM
ANTENNA
JACK 1
2
FM/AM TUNER UNIT
28
27
FM/AM 1ST IF 10.7MHz
T51 Q51 CF51 CF52 CF53
IC1
MIXER, IF AMP, DET.
6
21
18
LDET
COMP
22
25 10 14 12 15 16 8 13 2 3 4
CF202
VDD
LOCL
VCC
Q401
VCC VDD
DI/DO CE2 CK CE1 SDBW SL FMSD
PCE2
TUNPCK
TUNPCE
SL
SD
PDIO
NL1 NL2
IC 2 FM MPX
NL1
78 NL1
SD
SL
TUNPCE
TUNPCK
TUNPCE2
TUNPDO
LOCL
1
76
14
13
28
12
25 TUNPDI
11
PDIO
POWER SWITCH
1
6IC602
TPD1018F
8
8
DSENS
A
A
AMANT
FMANT
ATT
ATT
AMRF
FMRF
IMG ADJ
RF ADJ
X901
10.25MHz
ANTSW
LOCL
23 LOCH
AMDET
MPXREF 41kHz
AM 2ND IF
450kHz
19
CREQ
11
DGND
DGND
1
STIND
ST
L ch
ST
2
TA8277H
1
2
8
5
6
B.U
TX
RX
IPPW
ASENBO
IP-BUS DRIVER
IC751
HA12187FP
BUSL1
BUSL2
BUS2
BUS1
Q751
Q752
8
1
5
11
7
CN751
IP-BUS
BUSL1 5
BUSL2 61
2
CN301
Q346
Q205 MUTE
TX
RX
17
61
20 ASEMBO
IPPW
21
LOCH
LOCH
26
CN401
REAR OUTPUT
L
5
R ch
924
NC FMLOCL
20177
NC NC WC
26 RFGND
NL2
FL-
RL+
KEH-P5011/X1M/EE
KEH-P5011/X1M/EE
KEH-P5011/X1M/EE
B.REM
10
B.U
5

14
KEH-P5010R,P5011,4011
1234
1234
D
C
B
A
3.3 OVERALL CONNECTION DIAGRAM(GUIDE PAGE)(KEH-P5010R/X1M/EW)
Note: When ordering service parts, be sure to refer to “EXPLODED VIEWS AND PARTS LIST” or “ELECTRICAL PARTS
LIST”.
A-a A-b
A-aA-a A-bA-b
A-bA-b
A-aA-a
Large size
SCH diagram
Guide page
Detailed page
A
A-a
B
C
DSP-201M-S00B
X601:CSS1310
6.29MHz
0R0
162
162
272
272
123123
FM/AM TUNER UNIT
ANTENNA JACK A
CN1901
CN251
For resistors and capacitors in the circuit diagrams, their resistance values or
capacitance values are expressed in codes:
Ex. *Resistors
Code Practical value
123 12k ohms
103 10k ohms
*Capacitors
Code Practical value
103 0.01uF
101/10 100uF/10V
TUNER AMP UNIT
LOADSW
The >mark found on some component parts indicates
the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of
identical designation.
Symbol indicates a resistor.
No differentiation is made between chip resistors and
discrete resistors.
NOTE :
Symbol indicates a capacitor.
No differentiation is made between chip capacitors and
discrete capacitors.
SYSTEM CONTROLLER
SWD 5V
B
FM(100%) 400Hz
AM(30%) 400Hz
: -15.5dBs
: -26.0dBs
TAPE (0dB)315Hz : -9.9dBs
IP-BUS DRIV

15
KEH-P5010R,P5011,4011
5678
5678
D
C
B
A
A-b
A
600µH
332/16
>CEK1136
RR
+
RR
-
FR
+
FR
-
FL
+
FL
-
RL
+
RL
-
ACC
GND
B.
REM
BACK
UP
REAR OUTPUT
L
R
111098
765
4321
IP-BUS INPUT
SOURCE SELECTOR,
ELECTRONIC VOLUME MUTE
POWER AMP
8.4V REGULATOR
OFF MUTE
5V REGULATOR
POWER SWITCH
BACK UP SENSE
ACC SENSE
CELLULAR MUTE
SYSTEM MUTE
BACK LIGHT SWITCH
FM
AM
IP-BUS
TAPE
: 6.6dBs
: -2.9dBs
: 10.3dBs
: -3.8dBs
IP-BUS(0dB)1kHz : 2.2dBs
TAPE : -4.6dBs
TAPE : 22.2dBs
VER

16
KEH-P5010R,P5011,4011
1234
1234
D
C
B
A
DSP-201M-S00B
X601:CSS1310
6.29MHz
0R0
162
162
272
272
123123
FM/AM TUNER UNIT
ANTENNA JACK ATUNER AMP UNIT
SYSTEM CONTROLLER
FM(100%) 400Hz AM(30%) 400Hz
: -15.5dBs : -26.0dBs
A-a
A-a A-b
1
2
3
4

17
KEH-P5010R,P5011,4011
5678
5678
D
C
B
A
B
C
CN1901
CN251
For resistors and capacitors in the circuit diagrams, their resistance values or capacitance values are expressed in codes: Ex. *Resistors Code Practical value 123 12k ohms 103 10k ohms *Capacitors Code Practical value 103 0.01uF 101/10 100uF/10V
LOADSW
The >mark found on some component parts indicates
the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation.
Symbol indicates a resistor. No differentiation is made between chip resistors and discrete resistors.
NOTE :
Symbol indicates a capacitor. No differentiation is made between chip capacitors and discrete capacitors.
SYSTEM CONTROLLER
SWD 5V
BACK L
TAPE (0dB)315Hz : -9.9dBs
IP-BUS DRIVER
A-a
A-a A-b
4
5 6 7

18
1234
1234
D
C
B
A
600µH
332/16
>CEK1136
REAR OUTPUT
L
R
SOURCE SELECTOR,
ELECTRONIC VOLUME MUTE
POWER AMP
8.4V REGULATOR
OFF MUTE
5V REGULATOR
SYSTEM MUTE
FM AM IP-BUS TAPE
: 6.6dBs : -2.9dBs : 10.3dBs : -3.8dBs
TAPE : -4.6dBs
TAPE : 22.2dBs
A-a A-b
A-b
1
2
3
4
KEH-P5010R,P5011,4011

19
5678
5678
D
C
B
A
RR
+
RR
-
FR
+
FR
-
FL
+
FL
-
RL
+
RL
-
ACC
GND
B.
REM
BACK
UP
111098
765
4321
IP-BUS INPUT
5V REGULATOR
POWER SWITCH
BACK UP SENSE
ACC SENSE
CELLULAR MUTE
BACK LIGHT SWITCH
IP-BUS(0dB)1kHz : 2.2dBs
VER
A-b
A-a A-b
4
5 6
7
KEH-P5010R,P5011,4011

20
KEH-P5010R,P5011,4011
1234
1234
D
C
B
A
3.4 OVERALL CONNECTION DIAGRAM(GUIDE PAGE)(KEH-P5011/X1M/EE)
A
A-a
B
C
DSP-201M-S00B
333
473
X601:CSS1023
4.194304MHz
682
162
162
272
272
123123
FM/AM TUNER UNIT
ANTENNA JACK A
CN1901
CN251
For resistors and capacitors in the circuit diagrams, their resistance values or
capacitance values are expressed in codes:
Ex. *Resistors
Code Practical value
123 12k ohms
103 10k ohms
*Capacitors
Code Practical value
103 0.01uF
101/10 100uF/10V
TUNER AMP UNIT
LOADSW
The >mark found on some component parts indicates
the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of
identical designation.
Symbol indicates a resistor.
No differentiation is made between chip resistors and
discrete resistors.
NOTE :
Symbol indicates a capacitor.
No differentiation is made between chip capacitors and
discrete capacitors.
SYSTEM CONTROLLER
SWD 5V
B
FM(100%) 400Hz
AM(30%) 400Hz
: -15.5dBs
: -26.0dBs
TAPE (0dB)315Hz : -9.9dBs
IP-BUS DRIV
