Pioneer Super Tuner IIID DEH-P5800MP User manual

Operation Manual
Mode demploi
Multi-CD control High power CD/MP3/WMA player
with FM/AM tuner
Syntoniseur FM/AM et lecteur de CD/MP3/WMA,
Puissance éle ée, a ec contrôleur pour lecteur de
CD à chargeur
DEH-P5800MP
English Français

Thank you for buying this Pioneer product.
Please read through these operating instructions so you will know how to operate
your model properly. After you have finished reading the instructions, keep this man-
ual in a safe place for future reference.
Before You Start
Information to User 5
For Canadian model 5
About this unit 5
About this manual 5
After-sales service for Pioneer products 6
Product registration 6
Features 6
About W A 7
About the SAT RADIO READY mark 7
Protecting your unit from theft 7
Removing the front panel 7
Attaching the front panel 8
About the demo mode 8
Reverse mode 8
Feature demo mode 8
Use and care of the remote control 9
Installing the battery 9
Using the remote control 9
Whats What
Head unit 10
Remote control 11
Basic Operations
Turning the unit on 12
Selecting a source 12
Loading a disc 12
Adjusting the volume 13
Turning the unit off 13
Tuner
Listening to the radio 14
Introduction of advanced tuner
operation 15
Storing and recalling broadcast
frequencies 15
Tuning in strong signals 15
Storing the strongest broadcast
frequencies 16
Built-in D Player
Playing a CD 17
Introduction of advanced built-in CD player
operation 17
Repeating play 17
Playing tracks in random order 18
Scanning tracks of a CD 18
Pausing CD playback 18
Using compression and B X 18
Selecting the search method 19
Searching every 10 tracks in the current
disc 19
Using disc title functions 19
Entering disc titles 19
Displaying disc titles 20
Using CD TEXT functions 20
Displaying text information on CD
TEXT discs 20
Scrolling text information in the
display 21
MP3/WMA/WAV Player
Playing P3/W A/WAV 22
Introduction of advanced built-in CD player
( P3/W A/WAV) operation 23
Repeating play 23
Playing tracks in random order 23
Scanning folders and tracks 23
Pausing P3/W A/WAV playback 24
Selecting folders from the folder title list 24
Using compression and B X 24
Selecting the search method 24
Searching every 10 tracks in the current
folder 25
Displaying text information on P3/W A/
WAV disc 25
Contents
En
2

When playing back an P3/W A
disc 25
When playing back a WAV disc 25
Scrolling text information in the display 26
Multi- D Player
Playing a CD 27
50-disc multi-CD player 27
Introduction of advanced multi-CD player
operation 28
Repeating play 28
Playing tracks in random order 28
Scanning CDs and tracks 29
Pausing CD playback 29
Using ITS playlists 29
Creating a playlist with ITS
programming 29
Playback from your ITS playlist 30
Erasing a track from your ITS
playlist 30
Erasing a CD from your ITS
playlist 30
Using disc title functions 31
Entering disc titles 31
Displaying disc titles 32
Selecting discs from the disc title
list 32
Using CD TEXT functions 32
Displaying text information on CD
TEXT discs 32
Scrolling text information in the
display 32
Using compression and bass emphasis 33
Audio Adjustments
Introduction of audio adjustments 34
Compensating for equalizer curves (EQ-
EX) 34
Using balance adjustment 34
Using the equalizer 35
Recalling equalizer curves 35
Adjusting equalizer curves 35
Fine-adjusting equalizer curve 36
Adjusting bass and treble 36
Adjusting bass and treble level 36
Selecting bass frequency 37
Selecting treble frequency 37
Adjusting loudness 37
Using subwoofer output 37
Adjusting subwoofer settings 38
Using nonfading output 38
Adjusting nonfading output level 38
Using the high pass filter 38
Adjusting source levels 39
Initial Settings
Adjusting initial settings 40
Setting the clock 40
Switching the warning tone 40
Switching the auxiliary setting 41
Switching the dimmer setting 41
Adjusting the brightness 41
Setting the rear output and subwoofer
controller 41
Switching the sound muting/attenuation 42
Switching the Ever Scroll 42
Other Functions
Turning the clock display on or off 43
Using the AUX source 43
Selecting AUX as the source 43
Setting the AUX title 43
Using different entertainment displays 44
Introduction of X operation 44
X operation 44
Swiching the X channel select
setting 45
Introduction of DVD operation 45
En 3
English
Contents

Operation 45
Function menu switching 45
Using ITS playlist and disc title
functions 45
Additional Information
Understanding built-in CD player error
messages 46
CD player and care 46
CD-R/CD-RW discs 47
P3, W A and WAV files 47
P3 additional information 48
W A additional information 48
WAV additional information 48
About folders and P3/W A/WAV files 49
Terms 50
Specifications 52
Contents
En
4

Information to User
Alteration or modifications carried out without
appropriate authorization may invalidate the
users right to operate the equipment.
For Canadian model
This Class B digital apparatus complies with
Canadian ICES-003.
About this unit
The tuner frequencies on this unit are allo-
cated for use in North America. Use in other
areas may result in poor reception.
WARNING:
Handling the cord on this product or cords asso-
ciated with accessories sold with the product
may expose you to chemicals listed on proposi-
tion 65 known to the State of California and other
governmental entities to cause cancer and birth
defects or other reproductive harm. Wash hands
after handling.
CAUT ON:
USE OF CONTROL OR ADJUSTMENT OR
PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPEC F ED HERE N
MAY RESULT N HAZARDOUS RAD AT ON
EXPOSURE.
CAUT ON:
THE USE OF OPT CAL NSTRUMENTS
W TH TH S PRODUCT W LL NCREASE
EYE HAZARD.
AUTION
!Do not allow this unit to come into contact
with liquids. Electrical shock could result.
Also, this unit damage, smoke, and overheat
could result from contact with liquids.
!Keep this manual handy as a reference for op-
erating procedures and precautions.
!Always keep the volume low enough so that
you can hear sounds from outside the vehicle.
!Protect this unit from moisture.
!If the battery is disconnected or discharged,
the preset memory will be erased and must be
reprogrammed.
Important (Serial number)
The serial number is located on the bottom of
this unit. For your own security and convenience,
be sure to record this number on the enclosed
warranty card.
About this manual
This unit features a number of sophisticated
functions ensuring superior reception and op-
eration. All the functions have been designed
for the easiest possible use, but many are not
self-explanatory. This operation manual will
help you benefit fully from this units potential
and to maximize your listening enjoyment.
We recommend that you familiarize yourself
with the functions and their operation by read-
ing through the manual before you begin
using this unit. It is especially important that
you read and observe WARNINGs and AU-
TIONs in this manual.
Before You Start
En 5
English
Section
01

After-sales service for
Pioneer products
Please contact the dealer or distributor from
where you purchased this unit for after-sales
service (including warranty conditions) or any
other information. In case the necessary infor-
mation is not available, please contact the
companies listed below:
Please do not ship your unit to the companies
at the addresses listed below for repair without
advance contact.
U.S.A.
Pioneer Electronics (USA) Inc.
CUSTO ER SUPPORT DIVISION
P.O. Box 1760
Long Beach, CA 90801-1760
800-421-1404
ANADA
Pioneer Electronics of Canada, Inc.
CUSTO ER SATISFACTION DEPART ENT
300 Allstate Parkway
arkham, Ontario L3R OP2
1-877-283-5901
For warranty information please see the Lim-
ited Warranty sheet included with this unit.
Product registration
Visit us at the following site:
1 Register your product. We will keep the details
of your purchase on file to help you refer to
this information in the event of an insurance
claim such as loss or theft.
2 Receive updates on the latest products and
technologies.
3 Download owners manuals, order product
catalogues, research new products, and
much more.
Features
CD playbac
usic CD/CD-R/CD-RW playback is possible.
MP3 file playbac
You can play back P3 files recorded on CD-
RO /CD-R/CD-RW (ISO9660 Level 1/Level 2
standard recordings).
!Supply of this product only conveys a li-
cense for private, non-commercial use and
does not convey a license nor imply any
right to use this product in any commercial
(i.e. revenue-generating) real time broad-
casting (terrestrial, satellite, cable and/or
any other media), broadcasting/streaming
via internet, intranets and/or other net-
works or in other electronic content distri-
bution systems, such as pay-audio or
audio-on-demand applications. An inde-
pendent license for such use is required.
For details, please visit
http://www.mp3licensing.com.
WMA file playbac
You can play back W A files recorded on CD-
RO /CD-R/CD-RW (ISO9660 Level 1/Level 2
standard recordings).
WAV file playbac
You can play back WAV files recorded on CD-
RO /CD-R/CD-RW (Linear PC (LPC )/ S
ADPC recordings).
Before You Start
En
6
Section
01

About WMA
The Windows edia"logo printed on the box
indicates that this unit can play back W A
data.
W A is short for Windows edia Audio and
refers to an audio compression technology
that is developed by icrosoft Corporation.
W A data can be encoded by using Windows
edia Player version 7 or later.
Windows edia and the Windows logo are tra-
demarks or registered trademarks of icrosoft
Corporation in the United States and/or other
countries.
Notes
!This unit may not operate correctly depending
on the application used to encode W A files.
!Depending on the version of Windows edia
Player used to encode W A files, album
names and other text information may not be
correctly displayed.
About the SAT RADIO
READY mar
The SAT RADIO READY mark printed on the
front panel indicates that the Satellite Radio
Tuner for Pioneer (i.e., X tuner and Sirius sa-
tellite tuner which are sold separately) can be
controlled by this unit. Please inquire to your
dealer or nearest authorized Pioneer service
station regarding the satellite radio tuner that
can be connected to this unit. For satellite
radio tuner operation, please refer to the satel-
lite radio tuner owners manual.
Notes
!The system will use direct satellite-to-receiver
broadcasting technology to provide listeners
i n their cars and at home with crystal-clear
sound seamlessly from coast to coast. Satel-
lite radio will create and package over 100
channels of digital-quality music, news,
sports, talk and childrens programming.
!SAT Radio, the SAT Radio logo and all re-
lated marks are trademarks of Sirius Satellite
Radio inc., and X Satellite Radio Inc.
Protecting your unit from
theft
The front panel can be detached from the
head unit to discourage theft.
!If the front panel is not detached from the
head unit within five seconds of turning off
the ignition, a warning tone will sound.
!You can turn off the warning tone. See
Switching the warning tone on page 40.
Important
!Never use force or grip the display and the
buttons too tightly when removing or attach-
ing.
!Avoid subjecting the front panel to excessive
shocks.
!Keep the front panel out of direct sunlight and
high temperatures.
Removing the front panel
1 Press OPEN to open the front panel.
Before You Start
En 7
English
Section
01

2 Grip the left side of the front panel and
pull it gently outward.
Take care not to grip it too tightly or to drop
the front panel and protect it from contact
with water or other fluids to prevent perma-
nent damage.
Attaching the front panel
%Replace the front panel by holding it
upright to the unit and clipping it securely
into the mounting hooks.
About the demo mode
This unit features two demonstration modes.
One is the reverse mode, the other is the fea-
ture demo mode.
!You cannot cancel a demo mode when the
front panel is open.
Important
The red lead (ACC) of this unit should be con-
nected to a terminal coupled with ignition switch
on/off operations. If this is not done, the vehicle
battery may be drained.
Reverse mode
If you do not perform an operation within
about 30 seconds, screen indications start to
reverse, and then continue reversing every 10
seconds. Pressing button 5when power to
this unit is turned off while the ignition switch
is set to ACC or ON cancels the reverse mode.
Press button 5again to start the reverse
mode.
Feature demo mode
The feature demo automatically starts when
power to this unit is turned off while the igni-
tion switch is set to ACC or ON. Pressing but-
ton during feature demo operation cancels
the feature demo mode. Press button again
to start the feature mode. Remember that if
the feature demo continues operating when
the car engine is turned off, it may drain bat-
tery power.
Before You Start
En
8
Section
01

Use and care of the remote
control
Installing the battery
Slide the tray out on the back of the remote
control and insert the battery with the plus (+)
and minus () poles pointing in the proper di-
rection.
WARNING
Keep the battery out of the reach of children.
Should the battery be swallowed, immediately
consult a doctor.
AUTION
!Use only one R2025 (3 V) lithium battery.
!Remove the battery if the remote control is not
used for a month or longer.
!Do not recharge, disassemble, heat or dispose
of the battery in fire.
!Do not handle the battery with metallic tools.
!Do not store the battery with metallic materi-
als.
!In the event of battery leakage, wipe the re-
mote control completely clean and install a
new battery.
!When disposing of used batteries, please
comply with governmental regulations or en-
vironmental public institutionsrules that
apply in your country/area.
Using the remote control
Point the remote control in the direction of the
front panel to operate.
!The remote control may not function prop-
erly in direct sunlight.
Important
!Do not store the remote control in high tem-
peratures or direct sunlight.
!Do not let the remote control fall onto the
floor, where it may become jammed under the
brake or accelerator pedal.
Before You Start
En 9
English
Section
01

Head unit
1AUDIO button
Press to select various sound quality con-
trols.
2FUNCTION button
Press to select functions.
3SW button
Press to directly select subwoofer setting
menu. See Using subwoofer output on page
37. Press and hold to select EQ-EX setting
menu. See Compensating for equalizer
curves EQ-EX) on page 34.
4SOURCE button, VOLUME
This unit is turned on by selecting a source.
Press to cycle through all the available
sources.
Rotate it to increase or decrease the vo-
lume.
5OPEN button
Press to open the front panel.
6ENTERTAINMENT button
Press to change to the entertainment dis-
play.
7PAUSE button
Press to turn pause on or off.
8CLOCK button
Press to change to the clock display. Press
and hold to change the channel select
mode when X tuner is selected as the
source.
91buttons
Press for preset tuning and disc number
search when using a multi-CD player.
aEQ button
Press to select various equalizer curves.
bBAND button
Press to select among three F bands and
one A band and to cancel the control
mode of functions.
cDISPLAY button
Press to select different displays.
da/b/c/dbuttons
Press to perform manual seek tuning, fast
forward, reverse and track search controls.
Also used for controlling functions.
12 3 4 5
6
7
89abc
d
Whats What
En
10
Section
02

Remote control
Operation is the same as when using the but-
tons on the head unit. See the explanation of
the head unit about the operation of each but-
ton with the exception of ATT, which is ex-
plained below.
eVOLUME buttons
Press to increase or decrease the volume.
fATT button
Press to quickly lower the volume level, by
about 90%. Press once more to return to the
original volume level.
gSOURCE button
This unit is turned on by selecting a source.
Press to cycle through all the available
sources.
f
1
g
2
7
c
b
e
d
Whats What
En 11
English
Section
02

Turning the unit on
%Press SOURCE to turn the unit on.
When you select a source, the unit is turned
on.
Selecting a source
You can select a source you want to listen to.
To switch to the built-in CD player, load a disc
in the unit (refer to page 17).
%Press SOURCE to select a source.
Press SOURCE repeatedly to switch between
the following sources:
XM tunerTunerTelevisionDVD
player/Multi-DVD playerBuilt-in D
playerMulti- D playerExternal unit 1
External unit 2AUX
Notes
!In the following cases, the sound source will
not change:
When there is no unit corresponding to the
selected source connected to this unit.
When there is no disc in the unit.
When there is no disc in the DVD player.
When there is no magazine in the multi-
CD player.
When there is no magazine in the multi-
DVD player.
When the AUX (auxiliary input) is set to off
(refer to page 41).
!External unit refers to a Pioneer product (such
as one available in the future) that, although
incompatible as a source, enables control of
basic functions by this unit. Two external units
can be controlled by this unit. When two exter-
nal units are connected, the allocation of
them to external unit 1 or external unit 2 is
automatically set by this unit.
!When this units blue/white lead is connected
to the vehicles auto-antenna relay control
terminal, the vehicles antenna extends when
this units source is turned on. To retract the
antenna, turn the source off.
Loading a disc
1 Press OPEN to open the front panel.
CD loading slot appears.
#After a CD has been inserted, press SOURCE
to select the built-in CD player.
2 Insert a CD into the CD loading slot.
Playback will automatically start.
CD loading slot
EJECT button
#You can eject a CD by pressing EJECT.
#To avoid a malfunction, make sure that no
metal object comes into contact with the term-
inals when the front panel is open.
Notes
!The built-in CD player plays one standard, 12-
cm or 8-cm CD at a time. Do not use an adap-
ter when playing 8-cm CDs.
!Do not insert anything other than a CD into
the CD loading slot.
!There is sometimes a delay between starting
up CD playback and the sound being issued.
When being read, Format Read is displayed.
!If you cannot insert a disc completely or if
after you insert a disc the disc does not play,
check that the label side of the disc is up.
Press EJECT to eject the disc, and check the
disc for damage before inserting it again.
Basic Operations
En
12
Section
03

!If an error message such as ERROR-11 is dis-
played, refer to Understanding built-in CD
player error messages on page 46.
!When the CD loading or ejecting function
does not operate properly, you can eject the
CD by pressing and holding EJECT while
opening the front panel.
Adjusting the volume
%Use VOLUME to adjust the sound level.
With the head unit, rotate VOLUME to in-
crease or decrease the volume.
With the remote control, press VOLUME to in-
crease or decrease the volume.
Turning the unit off
%Press SOURCE and hold until the unit
turns off.
Basic Operations
En 13
English
Section
03

Listening to the radio
1
2
3
4
5
These are the basic steps necessary to operate
the radio. ore advanced tuner operation is
explained starting on the next page.
1Stereo (5) indicator
Shows when the selected frequency is
being broadcast in stereo.
2LOC indicator
Shows when local seek tuning is on.
3Preset number indicator
Shows which preset has been selected.
4Band indicator
Shows which band the radio is tuned to, A
or F .
5Frequency indicator
Shows the frequency to which the tuner is
tuned.
1 Press SOURCE to select the tuner.
Press SOURCE until you see Tuner displayed.
2 Press BAND to select a band.
Press BAND until the desired band (FM1,
FM2,FM3 for F or AM) is displayed.
3 To perform manual tuning, briefly press
cor d.
The frequencies move up or down step by
step.
4 To perform seek tuning, press and hold
cor dfor about one second and release.
The tuner will scan the frequencies until a
broadcast strong enough for good reception is
found.
#You can cancel seek tuning by briefly pressing
cor d.
#If you press and hold cor dyou can skip sta-
tions. Seek tuning starts as soon as you release
the button.
Tuner
En
14
Section
04

Introduction of advanced
tuner operation
1
1Function display
Shows the function status.
%Press FUNCTION to display the function
names.
Press FUNCTION repeatedly to switch be-
tween the following functions:
BSM (best stations memory)Local (local
seek tuning)
#To return to the frequency display, press
BAND.
Note
If you do not operate the function within about 30
seconds, the display is automatically returned to
the frequency display.
Storing and recalling
broadcast frequencies
If you press any of the preset tuning buttons
1you can easily store up to six broadcast
frequencies for later recall with the touch of a
button.
%When you find a frequency that you
want to store in memory, press one of pre-
set tuning buttons 1and hold until the
preset number stops flashing.
The number you have pressed will flash in the
preset number indicator and then remain lit.
The selected radio station frequency has been
stored in memory.
The next time you press the same preset tun-
ing button the radio station frequency is re-
called from memory.
Notes
!Up to 18 F stations, six for each of the three
F bands, and six A stations can be stored
in memory.
!You can also use aand bto recall radio sta-
tion frequencies assigned to preset tuning
buttons 1.
Tuning in strong signals
Local seek tuning lets you tune in only those
radio stations with sufficiently strong signals
for good reception.
1 Press FUNCTION to select Local.
Press FUNCTION until Local appears in the
display.
2 Press ato turn local seek tuning on.
Local seek sensitivity (e.g., Local 2) appears in
the display.
3 Press cor dto set the sensitivity.
There are four levels of sensitivity for F and
two levels for A :
F : Local 1Local 2Local 3Local 4
A : Local 1Local 2
The Local 4 setting allows reception of only
the strongest stations, while lower settings let
you receive progressively weaker stations.
4 When you want to return to normal
seek tuning, press bto turn local seek tun-
ing off.
Local :OFF appears in the display.
Tuner
En 15
English
Section
04

Storing the strongest
broadcast frequencies
BS (best stations memory) lets you automa-
tically store the six strongest broadcast fre-
quencies under preset tuning buttons 1.
Once stored you can tune in to those frequen-
cies with the touch of button.
1 Press FUNCTION to select BSM.
Press FUNCTION until BSM appears in the
display.
2 Press ato turn BSM on.
BSM begins to flash. While BSM is flashing
the six strongest broadcast frequencies will be
stored under preset tuning buttons 1in the
order of their signal strength. When finished,
BSM stops flashing.
#To cancel the storage process, press b.
Note
Storing broadcast frequencies with BS may re-
place broadcast frequencies you have saved
using buttons 1.
Tuner
En
16
Section
04

Playing a CD
1
2
These are the basic steps necessary to play a
CD with your built-in CD player. ore ad-
vanced CD operation is explained starting on
this page.
1Track number indicator
Shows the track currently playing.
2Play time indicator
Shows the elapsed playing time of the cur-
rent track.
1 Press SOURCE to select the built-in CD
player.
Press SOURCE until you see Compact Disc
displayed.
#If no disc is loaded in the unit, you cannot se-
lect Compact Disc (built-in CD player). Insert a
disc in the unit. (Refer to page 12.)
2 To perform fast forward or reverse,
press and hold cor d.
#If you select ROUGH SEARCH, pressing and
holding cor denables you to search every 10
tracks in the current disc. (Refer to Selecting the
search method on page 19.)
3 To skip back or forward to another
track, press cor d.
Pressing dskips to the start of the next track.
Pressing conce skips to the start of the cur-
rent track. Pressing again will skip to the pre-
vious track.
Introduction of advanced
built-in CD player operation
1
1Function display
Shows the function status.
%Press FUNCTION to display the function
names.
Press FUNCTION repeatedly to switch be-
tween the following functions:
Repeat (repeat play)Random (random play)
Scan (scan play)Pause (pause)
Comp./BMX (compression and B X)
FF/REV (search method)
#To return to the playback display, press BAND.
Note
If you do not operate the function within about 30
seconds, the display is automatically returned to
the playback display.
Repeating play
Repeat play lets you hear the same track over
again.
1 Press FUNCTION to select Repeat.
Press FUNCTION until Repeat appears in the
display.
2 Press cor dto select the repeat range.
Press cor duntil the desired repeat range ap-
pears in the display.
!DISC Repeat the current disc
Built-in CD Player
En 17
English
Section
05

!TRACK Repeat just the current track
Note
If you perform track search or fast forward/re-
verse during TRACK, the repeat play range
changes to DISC.
Playing trac s in random order
Random play lets you play back tracks on the
CD in a random order.
1 Press FUNCTION to select Random.
Press FUNCTION until Random appears in
the display.
2 Press ato turn random play on.
Random : ON appears in the display. Tracks
will play in a random order.
3 Press bto turn random play off.
Random :OFF appears in the display. Tracks
will continue to play in order.
Scanning trac s of a CD
Scan play lets you hear the first 10 seconds of
each track on the CD.
1 Press FUNCTION to select Scan.
Press FUNCTION until Scan appears in the
display.
2 Press ato turn scan play on.
Scan : ON appears in the display. The first 10
seconds of each track is played.
3 When you find the desired track press
bto turn scan play off.
Scan :OFF appears in the display. The track
will continue to play.
#If the display has automatically returned to
the playback display, select Scan again by press-
ing FUNCTION.
Note
After scanning of a CD is finished, normal play-
back of the tracks will begin again.
Pausing CD playbac
Pause lets you temporarily stop playback of
the CD.
1 Press FUNCTION to select Pause.
Press FUNCTION until Pause appears in the
display.
2 Press ato turn pause on.
Pause : ON appears in the display. Play of the
current track pauses.
3 Press bto turn pause off.
Pause :OFF appears in the display. Play will re-
sume at the same point that you turned pause
on.
Using compression and BMX
Using the CO P (compression) and B X
functions let you adjust the sound playback
quality of this player. Each of the functions has
a two-step adjustment. The CO P function
balances the output of louder and softer
sounds at higher volumes. B X controls
sound reverberations to give playback a fuller
sound. Listen to each of the effects as you se-
lect through them and use the one that best
enhances the playback of the track or CD that
you are listening to.
Built-in CD Player
En
18
Section
05

1 Press FUNCTION to select Comp./BMX.
Press FUNCTION until Comp./BMX appears
in the display.
2 Press aor bto select your favorite set-
ting.
Press aor brepeatedly to switch between the
following settings:
Comp./BMX OFFComp. 1Comp. 2
Comp./BMX OFFBMX 1BMX 2
Selecting the search method
You can switch the search method between
fast forward/reverse and searching every 10
tracks.
1 Press FUNCTION to select FF/REV.
Press FUNCTION until FF/REV appears in the
display.
#If the search method ROUGH SEARCH has
been previously selected, ROUGH SEARCH will
be displayed.
2 Press cor dto select the search meth-
od.
Press cor duntil the desired search method
appears in the display.
!FF/REV Fast forward and reverse
!ROUGH SEARCH Searching every 10
tracks
Searching every 10 trac s in
the current disc
If a disc contains over 10 tracks, you can
search every 10 tracks. When a disc contains
many tracks, you can roughly search for the
track you want to play.
1 Select the search method
ROUGH SEARCH.
2 Press and hold cor dto search every
10 tracks on a disc.
#If a disc contains less than 10 tracks, pressing
and holding drecalls the last track of the disc.
Also, if the remaining number of tracks after
searching every 10 tracks is less than 10, press-
ing and holding drecalls the last track of the
disc.
#If a disc contains less than 10 tracks, pressing
and holding crecalls the first track of the disc.
Also, if the remaining number of tracks after
searching every 10 tracks is less than 10, press-
ing and holding crecalls the first track of the
disc.
Using disc title functions
You can input CD titles and display the title.
The next time you insert a CD for which you
have entered a title, the title of that CD will be
displayed.
Entering disc titles
Use the disc title input feature to store up to
48 CD titles in the unit. Each title can be up to
10 characters long.
1 Play the CD that you want to enter a
title for.
2 Press FUNCTION and hold until TITLE
appears in the display.
#When playing a CD TEXT disc, you cannot
switch to TITLE. The disc title will have already
been recorded on a CD TEXT disc.
Built-in CD Player
En 19
English
Section
05

3 Press button 1 to select the desired
character type.
Press button 1repeatedly to switch between
the following character types:
Alphabet (upper case)Alphabet (lower case)
European letters, such as those with ac-
cents (e.g., á, à, ä, ç)
#You can select to input numbers and symbols
by pressing button 2.
4 Press aor bto select a letter of the al-
phabet.
Each press of awill display a letter of the al-
phabet in A B C ... X Y Z, numbers and sym-
bols in 1 2 3 ... @ # < order. Each press of b
will display a letter in the reverse order, such
as Z Y X ... C B A.
5 Press dto move the cursor to the next
character position.
When the letter you want is displayed, press d
to move the cursor to the next position and
then select the next letter. Press cto move
backwards in the display.
Move the cursor to the last position by
pressing dafter entering the title.
When you press done more time, the entered
title is stored in memory.
7 Press BAND to return to the playback
display.
Notes
!Titles remain in memory, even after the disc
has been removed from the unit, and are re-
called when the disc is reinserted.
!After data for 48 discs has been stored in
memory, data for a new disc will overwrite the
oldest one.
!If you connect a multi-CD player, you can
input disc titles for up to 100 discs.
Displaying disc titles
You can display the text information of any
disc that has had a disc title entered.
%Press DISPLAY.
Press DISPLAY repeatedly to switch between
the following settings:
Play timeDisc Title (disc title)
When you select Disc Title, the title of the cur-
rently playing disc is shown in the display.
#When a CD with a disc title is inserted, the
disc title automatically begins to scroll through
the display.
#If no title has been entered for the currently
playing disc, No Disc Title is displayed.
Using CD TEXT functions
Some discs have certain information encoded
on the disc during manufacture. These discs
may contain such information as the CD title,
track title, artists name and playback time
and are called CD TEXT discs. Only these spe-
cially encoded CD TEXT discs support the
functions listed below.
Displaying text information on
CD TEXT discs
%Press DISPLAY.
Press DISPLAY repeatedly to switch between
the following settings:
Built-in CD Player
En
20
Section
05
