Pioneer DXT-736BT User manual

ORDER NO.
PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2011
CRT4771
COMPLETE CAR AUDIO PACKAGE CD RDS RECEIVER
DXT-736BT /XSUS
This service manual should be used together with the following manual(s) listed below.
For the parts numbers, adjustments, etc. which are not shown in this manual,
refer to the following manual(s).
Model No. Order No. Mech. Module Remarks
DEH-7300BT/XSUC CRT4659
CX-3269 CRT4488 S11.1STD-DOUT CD Mech. Module : Circuit Descriptions, Mech. Descriptions, Disassembly
K-ZZZ AUG. 2011 Printed in Japan
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc.
and any use of such marks by Pioneer Corporation is under license.
Other trademarks and trade names are those of their respective owners.

DXT-736BT/XSUS
2
1234
1234
C
D
F
A
B
E
SAFETY INFORMATION
WARNING
This product may contain a chemical known to the State of California to cause cancer, or birth defects or
other reproductive harm.
Health & Safety Code Section 25249.6 - Proposition 65
EXPLODED VIEWS AND PARTS LIST
PACKING(Page 40)
PACKING SECTION PARTS LIST * : Non spare part
Owner's Manual
EXTERIOR(Page 44)
EXTERIOR SECTION PARTS LIST
Mark No. Description DEH-7300BT/XSUC DXT-736BT/XSUS
5 Remote Control Unit CXE3669 Not used
18 Unit Box YHG5573 YHG5652
19 Contain Box YHL5573 YHL5652
22-1 Owner's Manual YRD5324 YRD5366
* 22-4 Warranty Card CRY1276 QRY3001
* Speaker Set Not used TS-165P/XIES
* Speaker Not used 16-1624CA/XI
Sub Unit Box Not used YHG5671
Part No. Language
YRD5366 English, Spanish(Espanol)
Mark No. Description DEH-7300BT/XSUC DXT-736BT/XSUS
7 Remote Control Unit CXE3669 Not used
8 Cover CNS7068 Not used
29 Detach Grille Assy YXA5728 YXA5861(Grille Assy)
40 Keyboard Assy YWM5492 *YWM5578(Keyboard Unit)
42 Holder QNC3027 QNC3018
46 Grille Unit YXA5732 YXA5860
ELECTRICAL PARTS LIST(Page 71)
KEYBOARD UNIT
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual.
Circuit Symbol and No. Part Name DEH-7300BT/XSUC DXT-736BT/XSUS
IC1802 Remote IC GP1UXC14RK Not used
R1801 Not used RS1/10SR473J
R1804 RS1/10SR101J Not used
C1801 CCG1192 Not used
