Pioneer DEH-9350SD User manual

Português (B)
EspañolEnglish
Owner’s Manual
Manual de instrucciones
Manual do proprietário
DEH-9350SD
CD RECEIVER
RADIO CD
CD PLAYER
Downloaded from Caradio-Manual.com Manuals

Before You Start
About this unit 2
In case of trouble 2
Demo mode 2
Reverse mode 3
About this manual 3
Operating this unit
Head unit 3
Remote control 3
Basic Operations 4
Use and care of the remote control 4
Menu operations identical for function
settings/audio adjustments/initial
settings/lists 4
Tuner 5
CD/CD-R/CD-RW and external storage
devices (USB, SD) 5
iPod 7
Audio Adjustments 8
Initial Settings 9
Other Functions 10
Installation
Connections 11
Installation 12
Additional Information
Troubleshooting 14
Error messages 14
Handling guidelines 15
Compressed audio compatibility (disc, USB,
SD) 16
iPod compatibility 17
Sequence of audio files 17
Copyright and trademark 17
Specifications 18
Thank you for purchasing this PIONEER
product.
To ensure proper use, please read through this
manual before using this product. It is especially
important that you read and observe WARN-
INGs and CAUTIONs in this manual. Please
keep the manual in a safe and accessible place for
future reference.
About this unit
CAUTION
!Do not allow this unit to come into contact
with liquids. Electrical shock could result.
Also, damage to this unit, smoke, and over-
heating could result from contact with
liquids.
!Always keep the volume low enough to hear
outside sounds.
!Avoid exposure to moisture.
!If the battery is disconnected or discharged,
any preset memory will be erased.
CAUTION
This product is a class 1 laser product classi-
fied under the Safety of laser products, IEC
60825-1:2007, and contains a class 1M laser
module. To ensure continued safety, do not re-
move any covers or attempt to gain access to
the inside of the product. Refer all servicing to
qualified personnel.
CAUTION—CLASS 1M INVISIBLE LASER
RADIATION WHEN OPEN, DO NOT VIEW
DIRECTLY WITH OPTICAL INSTRUMENTS.
CAUTION:
USE OF CONTROL OR ADJUSTMENT OR
PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION
EXPOSURE.
CAUTION:
THE USE OF OPTICAL INSTRUMENTS
WITH THIS PRODUCT WILL INCREASE
EYE HAZARD.
In case of trouble
Should this unit fail to operate properly, please
contact your dealer or nearest authorized
PIONEER Service Station.
Demo mode
Important
!Failure to connect the red lead (ACC) of this
unit to a terminal coupled with ignition
switch on/off operations may lead to battery
drain.
!Remember that if the feature demo contin-
ues operating when the car engine is turned
off, it may drain battery power.
The demo automatically starts when the ignition
switch is set to ACC or ON while the unit is
turned off. Turning off the unit does not cancel
demo mode. To cancel the demo mode, press
DISP//SCRL. Press DISP/ /SCRL again to
start. Operating the demo while the ignition
switch is set to ACC may drain battery power.
Contents
01
2
Section
Before You Start
En
Downloaded from Caradio-Manual.com Manuals

Reverse mode
If you do not perform an operation within about
30 seconds, screen indications start to reverse,
and then continue reversing every 10 seconds.
Pressing button BAND/ESC when power to this
unit is turned off while the ignition switch is set
to ACC or ON cancels the reverse mode. Press
button BAND/ESC again to start the reverse
mode.
About this manual
In the following instructions, USB memories,
USB portable audio players, and SD memory
cards are collectively referred to as “external
storage devices (USB, SD).”If only USB memo-
ries and USB portable audio players are indi-
cated, they are collectively referred to as “USB
storage devices.”
In this manual, iPod and iPhone will be referred
to as “iPod”.
Head unit
1
1
1
1
4
4
4
4
5
5
5
5
6
6
7
7
7
7
a
a
a
a
c
c
c
c
d
d
d
d
2
2
2
2
3
3
3
3
8
8
8
8
9
9
9
9
b
b
b
b
g
e
f
Part Part
1SRC/OFF 9/LOC
2(list) aS.Rtrv
3/iPod bMULTI-CONTROL
(M.C.)
4Open button cDISP//SCRL
5
AUX input jack
(3.5 mm stereo
jack)
dBAND/ESC
6USB port eDisc loading slot
7/DISP OFF fh(eject)
8/BASS g
SD memory card
slot
Remove the front
panel to access
the SD memory
card slot.
CAUTION
Use an optional Pioneer USB cable (CD-U50E)
to connect the USB audio player/USB memory
as any device connected directly to the unit will
protrude out from the unit and may be danger-
ous.
Do not use unauthorized products.
Remote control
h
h
h
o
o
o
m
m
1
1
1
d
o
d
d
i
l
k
n
n
n
j
j
Part Operation
hVOLUME Press to increase or decrease
volume.
iMUTE Press to mute. Press again to
unmute.
ja/b/c/d
Press to perform manual seek
tuning, fast forward, reverse
and track search controls.
Also used for controlling
functions.
kAUDIO Press to select an audio func-
tion.
lDISP/SCRL
Press to select different dis-
plays.
Press and hold to scroll
through the text information.
English
Before You Start 02
3
Section
Operating this unit
En
Downloaded from Caradio-Manual.com Manuals

Part Operation
mePress to pause or resume
playback.
nFUNCTION
Press to select functions.
Press and hold to recall the
initial setting menu when the
sources are off.
oLIST/ENTER
Press to display the disc title,
track title, folder, or file list de-
pending on the source.
While in the operating menu,
press to control functions.
Basic Operations
Important
!Handle gently when removing or attaching
the front panel.
!Avoid subjecting the front panel to excessive
shock.
!Keep the front panel out of direct sunlight
and high temperatures.
!To avoid damaging the device or vehicle inte-
rior, remove any cables and devices attached
to the front panel before detaching it.
Removing the front panel to protect your unit from
theft
1Press the open button to open the front panel.
2Grip the left side of the front panel and pull it
gently outward.
3Always keep the detached front panel in a pro-
tection device such as a protection case.
Re-attaching the front panel
1Reattach the front panel by holding it upright
to the unit and clipping it securely into the
mounting hooks.
Turning the unit on
1Press SRC/OFF to turn the unit on.
Turning the unit off
1Press and hold SRC/OFF until the unit turns
off.
Selecting a source
1Press SRC/OFF to cycle between:
TUNER (tuner)—CD (built-in CD player)—USB
(USB)/IPOD (iPod)—SD (SD memory card)—
AUX (AUX)
Adjusting the volume
1Turn M.C. to adjust the volume.
Note
When this unit’s blue/white lead is connected to
the vehicle’s auto-antenna relay control termi-
nal, the vehicle’s antenna extends when this
unit’s source is turned on. To retract the anten-
na, turn the source off.
Use and care of the remote
control
Using the remote control
1Point the remote control in the direction of the
front panel to operate.
When using for the first time, pull out the film
protruding from the tray.
Replacing the battery
1Slide the tray out on the back of the remote
control.
2Insert the battery with the plus (+) and minus
(–) poles aligned properly.
WARNING
!Keep the battery out of the reach of children.
Should the battery be swallowed, consult a
doctor immediately.
!Batteries (battery pack or batteries installed)
must not be exposed to excessive heat such
as sunshine, fire or the like.
CAUTION
!Use one CR2025 (3 V) lithium battery.
!Remove the battery if the remote control is
not used for a month or longer.
!There is a danger of explosion if the battery is
incorrectly replaced. Replace only with the
same or equivalent type.
!Do not handle the battery with metallic tools.
!Do not store the battery with metallic ob-
jects.
!If the battery leaks, wipe the remote control
completely clean and install a new battery.
!When disposing of used batteries, comply
with governmental regulations or environ-
mental public institutions’rules that apply in
your country/area.
Important
!Do not store the remote control in high tem-
peratures or direct sunlight.
!The remote control may not function properly
in direct sunlight.
!Do not let the remote control fall onto the
floor, where it may become jammed under
the brake or accelerator pedal.
Menu operations identical
for function settings/audio
adjustments/initial settings/
lists
Returning to the previous display
Returning to the previous list/category (the folder/
category one level higher.)
1Press DISP//SCRL.
Returning to the main menu
Returning to the top tier of the list/category.
1Press and hold DISP//SCRL.
Returning to the ordinary display
Canceling the initial setting menu
1Press BAND/ESC.
Returning to the ordinary display from the list/cat-
egory
1Press BAND/ESC.
Operating this unit
02
4
Section
Operating this unit
En
Downloaded from Caradio-Manual.com Manuals

Tuner
Basic Operations
6
1 2 54
3
1Band indicator
25(stereo) indicator
3LOC indicator
Appears when local seek tuning is on.
4Preset number indicator
5Signal level indicator
6Frequency indicator
Selecting a band
1Press BAND/ESC until the desired band (FM-
1,FM-2,FM-3 for FM or AM) is displayed.
Manual tuning (step by step)
1Push M.C. left or right.
Seeking
1Push and hold M.C. left or right.
You can cancel seek tuning by pushing M.C.
left or right.
While pushing and holding M.C. left or right,
you can skip stations. Seek tuning starts as
soon as you release M.C.
Storing and recalling stations
for each band
1 Press (list).
The preset screen is displayed.
2 Use M.C. to store the selected frequency
in the memory.
Turn to change the preset number. Press and
hold to store.
3 Use M.C. to select the desired station.
Turn to change the station. Press to select.
#All stations stored for FM bands can be recalled
from each independent FM band.
#You can also change the station by pushing M.C.
up or down.
#To return to the ordinary display, press BAND/
ESC or (list).
Advanced operations using
special buttons
Local seek tuning
1Press /LOC repeatedly to select the desired
setting.
FM: Level 1—Level 2—Level 3—Level 4
AM: Level 1—Level 2
The highest level setting allows reception of
only the strongest stations, while lower levels
allow the reception of weaker stations.
Function settings
1 Press M.C. to display the main menu.
2 Turn M.C. to change the menu option
and press to select FUNCTION.
3 Turn M.C. to select the function.
After selecting, perform the following proce-
dures to set the function.
BSM (best stations memory)
BSM (best stations memory) automatically stores
the six strongest stations in the order of their sig-
nal strength.
1Press M.C. to turn BSM on.
!To cancel, press M.C. again.
Local (local seek tuning)
Local seek tuning lets you tune in to only those
radio stations with sufficiently strong signals for
good reception.
1Press M.C. to turn local on.
!To cancel, press M.C. again.
2Push M.C. left or right to select the desired set-
ting.
For details, refer to Local seek tuning on this
page.
CD/CD-R/CD-RW and external
storage devices (USB, SD)
Basic Operations
32
1
75 64
1Bit rate/sampling frequency indicator
Shows the bit rate or sampling frequency of
the current track (file) when the compressed
audio is playing.
!When playing back VBR (variable bit
rate)-recorded AAC files, the average bit
rate value is displayed. However, depend-
ing on the software used to decode AAC
files, VBR may be displayed.
2Folder number indicator
Shows the folder number currently playing
when the compressed audio is playing.
3Track number indicator
4PLAY/PAUSE indicator
5S.Rtrv indicator
Appears when Sound Retriever function is
on.
6Song time (progress bar)
7Play time indicator
Playing a CD/CD-R/CD-RW
1Press the open button to open the front panel.
2Insert the disc into the disc loading slot with
the label side up.
Ejecting a CD/CD-R/CD-RW
1Press the open button to open the front panel.
2Press h(eject).
Playing songs on a USB storage device
1Open the USB connector cover.
2Plug in the USB storage device using a USB
cable.
Stopping playback of files on a USB storage de-
vice
1You may disconnect the USB storage device at
any time.
Playing songs on an SD memory card
1Press the open button to open the front panel.
2Remove the front panel.
3Insert an SD memory card into the SD card
slot.
Insert it with the contact surface facing down,
and press on the card until it clicks and com-
pletely locks into place.
4Re-attach the front panel.
5Press SRC/OFF to select SD as the source.
Playback will start.
English
Operating this unit 02
5
Section
Operating this unit
En
Downloaded from Caradio-Manual.com Manuals
