Pioneer DV-563A-S User manual

ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2003
DV-563A-S
RRV2740
DVD PLAYER
DV-563A-S
DV-50A
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Region No.
Serial No.
Confirm 3rd & 4th
alphabetical letters.
DV-563A-S KUXU/CA AC120V 1 &&PG######$$
DV-50A KUXU/CA AC120V 1 &&PG######$$
¶DV-50A is a system(s) component.
Component System Service Manual Remarks
EX-500 RRV2798
VSX-50 RRV2797
DVD RECEIVER
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
DV-50A RRV2740 This service manualDVD PLAYER
For details, refer to "Important symbols for good services".
T-ZZE JUNE 2003 printed in Japan
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

DV-563A-S
2
1234
1234
C
D
F
A
B
E
SAFETY INFORMATION
This service manual is intended for qualified service technicians; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
cause cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 – Proposition 65
NOTICE
(FOR CANADIAN MODEL ONLY)
Fuse symbols (fast operating fuse) and/or (slow operating fuse) on PCB indicate that replacement
parts must be of identical designation.
REMARQUE
(POUR MODÈLE CANADIEN SEULEMENT)
Les symboles de fusible (fusible de type rapide) et/ou (fusible de type lent) sur CCI indiquent que
les pièces de remplacement doivent avoir la même désignation.
ANY MEASUREMENTS NOT WITHIN THE
LIMITS OUTLINED ABOVE ARE INDICATIVE
OF A POTENTIAL SHOCK HAZARD AND
MUST BE CORRECTED BEFORE RETURN-
ING THE APPLIANCE TO THE CUSTOMER.
2. PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in the appliance
have special safety related characteristics. These are
often not evident from visual inspection nor the
protection afforded by them necessarily can be obtained
by using replacement components rated for voltage,
wattage, etc. Replacement parts which have these
special safety characteristics are identified in this
Service Manual.
Electrical components having such features are
identified by marking with a on the schematics and
on the parts list in this Service Manual.
The use of a substitute replacement component which
does not have the same safety characteristics as the
PIONEER recommended replacement one, shown in the
parts list in this Service Manual, may create shock, fire,
or other hazards.
Product Safety is continuously under review and new
instructions are issued from time to time. For the latest
information, always consult the current PIONEER
Service Manual. A subscription to, or additional copies
of, PIONEER Service Manual may be obtained at a
nominal charge from PIONEER.
(FOR USA MODEL ONLY)
1. SAFETY PRECAUTIONS
The following check should be performed for the
continued protection of the customer and service
technician.
LEAKAGE CURRENT CHECK
Measure leakage current to a known earth ground
(water pipe, conduit, etc.) by connecting a leakage
current tester such as Simpson Model 229-2 or
equivalent between the earth ground and all exposed
metal parts of the appliance (input/output terminals,
screwheads, metal overlays, control shaft, etc.). Plug
the AC line cord of the appliance directly into a 120V
AC 60 Hz outlet and turn the AC power switch on. Any
current measured must not exceed 0.5 mA.
Device
under
test
Leakage
current
tester
Earth
ground
Reading should
not be above
0.5 mA
Also test with
plug reversed
(Using AC adapter
plug as required)
Test all
exposed metal
surfaces
AC Leakage Test
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

DV-563A-S 3
5678
5678
C
D
F
A
B
E
[ Important symbols for good services ]
In this manual, the symbols shown-below indicate that adjustments, settings or cleaning should be made securely.
When you find the procedures bearing any of the symbols, be sure to fulfill them:
2. Adjustments
To keep the original performances of the product, optimum adjustments or specification confirmation is indispensable.
In accordance with the procedures or instructions described in this manual, adjustments should be performed.
3. Cleaning
For optical pickups, tape-deck heads, lenses and mirrors used in projection monitors, and other parts requiring cleaning,
proper cleaning should be performed to restore their performances.
5. Lubricants, glues, and replacement parts
Appropriately applying grease or glue can maintain the product performances. But improper lubrication or applying
glue may lead to failures or troubles in the product. By following the instructions in this manual, be sure to apply the
prescribed grease or glue to proper portions by the appropriate amount.For replacement parts or tools, the prescribed
ones should be used.
4. Shipping mode and shipping screws
To protect the product from damages or failures that may be caused during transit, the shipping mode should be set or
the shipping screws should be installed before shipping out in accordance with this manual, if necessary.
1. Product safety
You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and
should keep the safety during servicing by following the safety instructions described in this manual.
• Manufactured under license from Dolby
Laboratories. “Dolby” and the double-D symbol
are trademarks of Dolby Laboratories.
• “DTS” and “DTS Digital Out” are registered
trademarks of Digital Theater Systems, Inc.
• TruSurround and the symbol are
trademarks of SRS Labs, Inc. TruSurround tech-
nology is incorporated under license from SRS
Labs, Inc.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

DV-563A-S
4
1234
1234
C
D
F
A
B
E
CONTENTS
SAFETY INFORMATION..................................................................................................................................... 2
1. SPECIFICATIONS ............................................................................................................................................ 5
2. EXPLODED VIEWS AND PARTS LIST ............................................................................................................ 6
2.1 PACKING ................................................................................................................................................... 6
2.2 EXTERIOR SECTION................................................................................................................................ 8
2.3 FRONT PANEL SECTION ....................................................................................................................... 10
2.4 LOADING MECHA ASSY ........................................................................................................................ 12
2.5 TRAVERSE MECHA ASSY-S .................................................................................................................. 14
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM..........................................................................................16
3.1 BLOCK DIAGRAM ................................................................................................................................... 16
3.2 LOAB ASSY and OVERALL WIRING DIAGRAM..................................................................................... 18
3.3 DVDM ASSY 1/3 [FRONT END BLOCK]................................................................................................. 20
3.4 DVDM ASSY 2/3 [BACK END BLOCK].................................................................................................... 22
3.5 DVDM ASSY 3/3 [SACD and POWER SUPPLY BLOCK]........................................................................ 24
3.6 JCKB ASSY 1/2 [AUDIO BLOCK]............................................................................................................ 26
3.7 JCKB ASSY 2/2 [VIDEO BLOCK]............................................................................................................ 28
3.8 FLKY and PWSB ASSYS ........................................................................................................................ 30
3.9 POWER SUPPLY UNIT............................................................................................................................ 32
3.10 WAVEFORMS ........................................................................................................................................ 33
4. PCB CONNECTION DIAGRAM ..................................................................................................................... 35
4.1 LOAB ASSY............................................................................................................................................. 35
4.2 DVDM ASSY ............................................................................................................................................ 36
4.3 JCKB ASSY ............................................................................................................................................. 38
4.4 FLKY and PWSB ASSYS ........................................................................................................................ 40
4.5 POWER SUPPLY UNIT............................................................................................................................ 42
5. PCB PARTS LIST ........................................................................................................................................... 43
6. ADJUSTMENT ............................................................................................................................................... 46
6.1 ADJUSTMENT ITEMS AND LOCATION ................................................................................................. 46
6.2 JIGS AND MEASURING INSTRUMENTS............................................................................................... 46
6.3 NECESSARY ADJUSTMENT POINTS ................................................................................................... 47
6.4 TEST MODE ............................................................................................................................................ 48
6.5 MECHANISM ADJUSTMENT.................................................................................................................. 49
7. GENERAL INFORMATION............................................................................................................................. 51
7.1 DIAGNOSIS ............................................................................................................................................. 51
7.1.1 TEST MODE ......................................................................................................................................... 51
7.1.2 DISPLAY SPECIFICATION OF THE TEST MODE ............................................................................... 53
7.1.3 FUNCTIONAL SPECIFICATION OF THE SHORTCUT KEY................................................................ 54
7.1.4 SPECIFICATION OF MODEL INFORMATION DISPLAY...................................................................... 55
7.1.5 FUNCTIONAL SPECIFICATION OF THE SERVICE MODE................................................................. 56
7.1.6 MECHANICAL ERROR HISTORY........................................................................................................ 57
7.1.7 ID NUMBER AND ID DATA SETTING................................................................................................... 60
7.1.8 TROUBLE SHOOTING ......................................................................................................................... 63
7.1.9 SEQUENCE AFTER POWER ON ........................................................................................................ 65
7.1.10 DISASSEMBLY ................................................................................................................................... 66
7.2 IC ............................................................................................................................................................. 74
7.3 DISC / CONTENT FORMAT PLAYBACK COMPATIBILITY ..................................................................... 90
7.4 CLEANING............................................................................................................................................... 92
8. PANEL FACILITIES ........................................................................................................................................ 93
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

DV-563A-S 5
5678
5678
C
D
F
A
B
E
1. SPECIFICATIONS
General
System . . . . . . . . . . . . . . . . . . . . . . . . . DVD player
Power requirements
. . . . . . . . . . . . . . . . . . . AC 120 V, 60 Hz
Power consumption
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 W
Power consumption (standby)
. . . . . . . . . . . . . . . . . . . . . . . . . . . 0.12 W
Weight . . . . . . . . . . . . . . . . . . . . . 2.4 kg / 5 lb 3 oz
Dimensions . . . . 420 (W) x 55 (H) x 283 (D) mm
(16.5 (W) x 2.2 (H) x 11.1 (D) in.)
Operating temperature . . . . . . . . . . +5°C to +35°C
(+41°F to +95°F)
Operating humidity . . . . . . . . . . . . . . . . 5% to 85%
(no condensation)
Component video output
Y (luminance) - Output level . . . . . . . . 1 Vp-p (75 Ω)
PB(color) - Output level . . . . . . . . . 0.7 Vp-p (75 Ω)
PR(color) - Output level . . . . . . . . . 0.7 Vp-p (75 Ω)
Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA jacks
S-video output
Y (luminance) - Output level . . . . . . . . 1 Vp-p (75 Ω)
C (color) - Output level . . . . . . . . 286 mVp-p (75 Ω)
Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . S-video jack
Video output
Output level . . . . . . . . . . . . . . . . . . . . 1 Vp-p (75 Ω)
Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA jack
Audio output (1 stereo pair)
Output level . . . . . . . . . . . . . . . During audio output
200 mVrms (1 kHz, –20 dB)
Number of channels . . . . . . . . . . . . . . . . . . . . . . . 2
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA jack
Audio output (multi-channel / L, R, C,
SW, LS, RS)
Output level . . . . . . . . . . . . . . . During audio output
200 mVrms (1 kHz, –20 dB)
Number of channels . . . . . . . . . . . . . . . . . . . . . . . 6
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA jack
Digital audio characteristics
Frequency response
. . . . . . . . . . . . . . . 4 Hz to 44 kHz (DVD fs: 96 kHz)
. . . . . . . . . 4 Hz to 88 kHz (DVD-Audio fs: 192 kHz)
S/N ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118 dB
. . . . . . . . . . . . . . . . . . . . . . . 108 dB
Total harmonic distortion . . . . . . . . . . . . . 0.0014 %
Wow and flutter. . . . . . . . . . Limit of measurement
(±0.001% W. PEAK) or lower
Digital output
Optical digital output . . . . . . . . . Optical digital jack
Coaxial digital output . . . . . . . . . . . . . . . . RCA jack
Other terminals
Control in . . . . . . . . . . . . . . . . . . . . Minijack (3.5 ø)
Control out . . . . . . . . . . . . . . . . . . . Minijack (3.5 ø)
Accessories
Audio/video cable (DV-563A-S only).. . . . . . . . . 1
Power cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Remote control (DV-563A-S only).. . . . . . . . . . . 1
AA/R6P dry cell batteries (DV-563A-S only). . . . . 2
Operating Instructions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Warranty card (DV-563A-S only)
• The specifications and design of this
product are subject to change without
notice, due to improvement.
. . . . . . . . . . . . . 1
Dynamic range
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

DV-563A-S
6
1234
1234
C
D
F
A
B
E
2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
NOTES:
12
10
13
8
3
4
8
5
DV-563A-S
Only
DV-563A-S
Only
DV-563A-S
Only
6
7
9
11
2
1
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

DV-563A-S 7
5678
5678
C
D
F
A
B
E
PACKING parts List
(2) CONTRAST TABLE
DV-563A-S/KUXU/CA and DV-50A/KUXU/CA are constructed the same except for the following :
Mark No. Description Part No.
> 1Power Cable ADG7021
2Audio / Video Cable See Contrast table (2)
3 Remote Control Unit See Contrast table (2)
4 Battery Cover See Contrast table (2)
NSP 5 Dry Cell Battery (R6P, AA) See Contrast table (2)
6 Operating Instructions See Contrast table (2)
(English)
NSP 7 Warranty Card See Contrast table (2)
8Polyethylene Bag VHL1051
9Pad L VHA1319
10 Pad R VHA1320
11 Paper Board VHC1100
12 Packing Case See Contrast table (2)
13 Sheet (750 x 600 x 0.5) Z23-007
Mark No. Description Part No.
Mark No. Symbol and Description DV-563A-S/
KUXU/CA
DV-50A/KUXU/
CA
2Audio / Video Cable VDE1077 Not used
3 Remote Control Unit VXX2865 Not used
4 Battery Cover VNK4997 Not used
NSP 5 Dry Cell Battery (R6P, AA) VEM1030 Not used
6 Operating Instructions (English) VRB1311 VRB1313
NSP 7 Warranty Card ARY7045 Not used
12 Packing Case VHG2336 VHG2380
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

DV-563A-S
8
1234
1234
C
D
F
A
B
E
2.2 EXTERIOR SECTION
BCD
CONTACT SIDE
NON-CONTACT
SIDE
BCD
E
E
A
A
11
10
25
25
25
18
7
7
1
17
13
26
25
10
16
12
8
6
5
4
2
15
22
C
F
25
25
25 25
25
26
28
28
19
20 25
26
26
27
27
21
26
26
10 B
Refer to
"2.4 LOADING MECHA. ASSY".
Refer to
"2.3 FRONT PANEL SECTION".
25
25
28
14
26
26
28
30
23
24
DV-563A-S
Only
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

DV-563A-S 9
5678
5678
C
D
F
A
B
E
EXTERIOR SECTION parts List
(2) CONTRAST TABLE
DV-563A-S/KUXU/CA and DV-50A/KUXU/CA are constructed the same except for the following :
Mark No. Description Part No.
1DVDM Assy VWS1563
2 JCKB Assy VWV1942
3•• • • •
> 4POWER SUPPLY Unit VWR1365
NSP 5 Loading Mecha. Assy VWT1207
6 Connector Assy PG05KK-E37
7 Flexible Cable (33P) VDA1956
8 Connector Assy (13P) VKP2310
9•• • • •
10 Cord Clamper RNH-184
11 Rubber Foot VEB1349
12 PCB Support VEC2184
13 Cushion VEC2342
14 Rear Panel See Contrast table (2)
NSP 15 Base Chassis VNA2614
16 PCB Base VNE2278
17 PCB Base VNE2310
NSP 18 S Earth Plate VNF1128
19 Adapter 3L VNL1960
20 Adapter 3R VNL1961
21 Bonnet Case S VXX2874
22 Tray Panel VNK5280
23 Acryl Door See Contrast table (2)
24 KUC Label VRW1959
25 Screw BBZ30P060FMC
26 Screw BBZ30P080FZK
27 Screw BCZ40P060FNI
28 Screw PPZ30P080FMC
29 • • • • •
30 Hologram Sheet See Contrast table (2)
Mark No. Description Part No.
Mark No. Symbol and Description DV-563A-S/
KUXU/CA
DV-50A/KUXU/
CA
14 Rear Panel VNA2578 VNA2574
23 Acryl Door VEC2338 VEC2361
30 Hologram Sheet VEC2359 Not used
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

DV-563A-S
10
1234
1234
C
D
F
A
B
E
2.3 FRONT PANEL SECTION
D
E
CONTACT SIDE
NON-CONTACT
SIDE
10
11
6
5
12
12
12
12
12
2
9
1
4
12
7
3
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

DV-563A-S 11
5678
5678
C
D
F
A
B
E
FRONT PANEL SECTION parts List
(2) CONTRAST TABLE
DV-563A-S/KUXU/CA and DV-50A/KUXU/CA are constructed the same except for the following :
Mark No. Description Part No.
1 FLKY Assy See Contrast table (2)
NSP 2 PWSB Assy VWG2429
3 Connector Assy PF03PP-B07
4 Flexible Cable (21P) VDA1957
5 Rubber Foot VEB1349
6 FL Lens VEC2336
7 FL Filter VEC2339
8•• • • •
9 FP Angle VNE2300
10 Front Panel Assy See Contrast table (2)
11 Pioneer Name Plate See Contrast table (2)
12 Screw PPZ30P080FMC
Mark No. Description Part No.
Mark No. Symbol and Description DV-563A-S/
KUXU/CA
DV-50A/KUXU/
CA
1 FLKY Assy VWG2427 VWG2430
10 Front Panel Assy VXA2576 VXA2575
11 Pioneer Name Plate VAM1129 Not used
11 Pioneer Name Plate B Not used PAN1376
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

DV-563A-S
12
1234
1234
C
D
F
A
B
E
2.4 LOADING MECHA ASSY
LOADING MECHA ASSY parts List
A
A
To DVDM CN101 (Pickup Assy-S)
To DVDM CN104 (Stepping Motor)
To DVDM CN102 (Spindle Motor)
2
3
5
4
12
23 13
17
21
16
22
15
14
22
22
22
20
18
19
91
7
10
11
6
8
8
8
8
A
Refer to
"2.5 TRAVERSE MECHA. ASSY-S".
Lubricating Oil
GYA1001
Daifree
GEM1036
Refer to
" Application of Lubricant".
Note :
Lubricating Oil
GYA1001
Mark No. Description Part No.
NSP 1 LOAB Assy VWG2426
2Traverse Mecha. Assy-S VXX2871
3 Loading Motor Assy VXX2872
4 Motor Pulley PNW1634
5 Motor VXM1105
6 Flexible Cable (24P) VDA1945
7 Connector Assy 2P VKP2253
8 Floating Rubber VEB1351
9 Belt VEB1330
10 Stabilizer VNE2253
11 Loading Base VNL1917
12 Float Base DVD VNL1918
13 Drive Cam VNL1919
14 Gear Pulley VNL1921
15 Loading Gear VNL1922
16 Drive Gear VNL1923
17 SW Lever VNL1925
18 Clamper Plate VNE2251
19 Bridge VNE2252
20 Clamper VNL1924
21 Screw JGZ17P028FMC
22 Screw Z39-019
23 Tray VNL1920
Mark No. Description Part No.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

DV-563A-S 13
5678
5678
C
D
F
A
B
E
Application of Lubricant
Lubricating Oil
GYA1001
Around the shaft
No. 11
Loading Base
No. 23
Tray
No. 13
Drive Cam
No. 13
Drive Cam
No. 23
Tray
Front View Rear View
Daifree
GEM1036
Inner side of a ditch
Concave of unevenness
Top View Bottom View
Daifree
GEM1036
Daifree
GEM1036
Side of the rib
Lubricating Oil
GYA1001
Concave of unevenness
Daifree
GEM1036 Concave of unevenness
Daifree
GEM1036
Lubricating Oil
GYA1001
Lubricating Oil
GYA1001 Lubricating Oil GYA1001
Inner side of a ditch
Lubricating Oil
GYA1001 Inner side of a ditch
Lubricating Oil
GYA1001
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

DV-563A-S
14
1234
1234
C
D
F
A
B
E
2.5 TRAVERSE MECHA ASSY-S
To
DVDM CN104
(Stepping Motor)
To DVDM CN102
(Spindle Motor)
To
DVDM CN101
(Pickup Assy)
CONTACT SIDE
NON-CONTACT
SIDE
12
3
7
8
1
17
16
17
10
13
17
10
6
11
14
16
2
9
15 (Torque : 0.15 ±0.01 N•m)
15 (Torque : 0.15 ±0.01 N•m)
4 (Adjustment screw)
5
(Adjustment
spring)
Screw Tight
GYL1001
Silicone Adhesive
GEM1037
Silicone Adhesive
GEM1037
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

DV-563A-S 15
5678
5678
C
D
F
A
B
E
TRAVERSE MECHA ASSY-S parts List
Mark No. Description Part No.
1 Spindle Motor VXM1099
2 Stepping Motor VXM1101
3 Pickup Assy-S OXX8005
4Skew Screw VBA1080
5Skew Spring VBH1335
6 Guide Bar VLL1514
7 Sub Guide Bar VLL1515
8 Leaf Spring VNC1023
9 Joint Spring VNC1019
10 Support Spring VNC1020
NSP 11 Mecha.Chassis VNE2248
12 Damper Sheet VEB1335
13 Spacer VNL1913
14 Joint 03 VNL1949
15 Tapping Screw OBA8021
16 Screw BBZ20P050FZK
17 Screw PMA26P100FMC
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

DV-563A-S
16
1234
1234
C
D
F
A
B
E
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM
3.1 BLOCK DIAGRAM
CN105
(21P)
CN103
(3P)
CN104
(21P)
21
12
10
11
14
20
1
1
21
12
10
11
14
20
5
21
17
19
11
15
13
33
32
9
8
29
CN602
(33P) CN102 (33P)
13
17
15
23
19
12
4
2
6
8
26
25
30
29
18
16
8
6
9
10
3
4
21
22
23
24
IC601
STI5588CVB
Back End IC
IC603
VYW2087
16M Flash ROM
IC602
K4S281632D-TC75
128M SDRAM
IC702
K4S641632F-TC75
64M SDRAM
16 B_DATA
BDVDM ASSY
SPINDLE
MOTOR
LD(650)
PICKUP
ASSY-S
OEIC
7
LD(780)
9
A
17
C
19
B1
16
B2
15
B3
22
B4
21
TRKG DRV
4
TRKG RTN
3
FOCS DRV
2
FOCS RTN
1
X6401
27MHz
(3/3)(2/3)
IC604
TC7WU04FU
IC606
TC7WU04FU
120
PIXCLK
265 3
(1/3)
(1/3)
7
7
1
1
X301
20MHz
IC301
STM6316ATXXA
Front End IC
IC701
SAA7893HL/C2
SACD IC
89
21
90
20
6
864
87 86
Q201,
Q202
Q531
Q211,
Q212
LD1
LD2
E
14 C
12 D
F
A
BOUT_DATA
44
PC(6)
PC(0)
FG
55
PD(0)
FRE
IN FRE OUT
99
21
35
RF
SACD
SYS_CLK 41
PCM_CELF_IN
39
PCM_LERI_IN
40
PCM_LSRS_IN
DSD_PCM_0
DSD_PCM_1
DSD_PCM_2
DSD_PCM_3
DSD_PCM_4
DSD_PCM_5
AGCINP
70
PE(1)
38
PC(2)
IC101
M63018FP
FTS Driver
30
31
34
35
TO–
SPDL PDM LOAD DRV
26 40
SPIN
LOIN+
TO+
FO+
FE DATA
SACD_27MHz
SACD_RF
SACD_RF
A DATA2 A DATA1 A DATA0
DSD L/PCMDATA0
DSD R
DSD C/PCMDATA1
DSD LFE
DSD LS/PCMDATA2
DSD RS
FO–
ALOAB ASSY
XCLOSE
OPEN
XCLOSE
OPEN
LOADING
MOTOR
ASSY
36
FG
24
LOAD+
SW2
V+3D
LOAD–
+– M
S101
2 1
1 2
3
4
1
2
SW1
5 5
3
4
CN103CN601
LO–
CN602
6
5
7
8
9
4
3
2
1
CN102
(12P)
H1+
A1
A2
A3
H1–
H2+
H2–
H3+
H3–
STEPPING
MOTOR
ST2–
ST2+
ST1+
ST1–
M4
3
2
1
CN104
53
PCMDATA1
54
PCMDATA2
52
PCMDATA0
27
R_OUT
57
SPDIF
26
G_OUT
25
B_OUT
34
CV_OUT
33
C_OUT
32
Y_OUT
CN1013
(24P) CN101 (24P)
DSD_L/PCMDATA0
22
CN601
(33P) CN101 (33P)
HW–
HW+
HV–
HV+
HU–
HU+
16
17
18
19
20
21
U
14
V
13
W
12
6SL2–
5SL2+
9SL1+
10 SL1–
36 LO+
37
V+3_FED
108
109
110
111
113
114
AC IN
CN1
FPOWER
SUPPLY
UNITLIVE
NEUTRAL
1
2
CN401
(13P)
CN101
(13P)
13
12
11
8
7
5
4
2
13
12
11
8
7
5
4
2
-28V
FL DC+
FL DC-
EV+3.3V
VFDP
IR
SEL IR
KEY0
FL DC+
FL DC-
V+3E
SW+1.8V
EV+6V(A)
EV+6V(B)
SW+12V
V+3_333
V+6 V+1R8
V-28
V+1R8_BED
V+1R8_D
V+1R8_FED
V+12
IC403
PQ1L333M2SP
3V REG.
V+_3A
V+3_033
V+3E
V+6B
V+3_FEA
IC402
PQ033EZ01ZP
3V REG.
V+5
V+5D
IC401
MM1565AF
5V REG.
IC400
PST328
Reset
V+3DV+3_FED
V+1R8_FEA
DSD_C/PCMDATA1
30
DSD_LFE
32
DSD_LS/PCMDATA2
DSD_RS
28
V+3A
A_DOUT
R_CR
G_Y
B_CB
V
S_C
S_Y
IR
SEL_IR
V+6
V+6
V+3A
V+12
V+12
26
8
9
4
5
V+3A
V+12
V+6B
A DOUT
RC_OUT
G_OUT
B_OUT
CV_OUT
C_OUT
Y_OUT
Q541
Q551
Q6972
Q511
Q501
Q521
21
1
2
25
26
10
DSD_R
24
DFLKY ASSY
EPWSB ASSY
FL101
FL Tube
IR101
Remote Sensor Unit
IC101
PE5374A
FL Control
Microcomputer
-28V
KEY0 - KEY2
KEY0
POWER
SEL IR
V+3E
60
17
8 8
RESET RESET IN
6
20-22
X101
5MHz
3 4
X1 X2
CN102
(3P)
3 1
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

DV-563A-S 17
5678
5678
C
D
F
A
B
E
CJCKB ASSY
DAC L/D0
CR/R
Y/G
CB/B
V
C
Y
V+3D
Q801
DAC R
DAC C/D1
DAC LFE
DAC LS/D2
DAC RS
V+12A
V+6
18
17
12
13
VOUTL+
VOUTR+
VOUTL–
VOUTR–
IC201
DSD1791DBR
Audio DAC (L, R)
25
3
24
DSD_L
PDATA
DSD_R
JA101
L
RFRONT
L
RAUDIO OUT
L
CENTER
SUB WOOFER
RSURROUND
IC204
BA4560F
Audio LPF & Amp.
7
6
18
16
12
10
14
8
4
3
C
Y
5
6
1
2/2
1/2
3
2
9
10
VOUTR
VOUTL
IC301
DSD1702EG
Audio DAC (Ls, Rs)
1
4
2
DSD_L
PCMDATA
DSD_R
21
Cr_R_out
IC701
LA73054
Video Amp.
16 Cr_R_in
25
Y/G_out
11 Y/G_in
23
Cb_B_out
14 Cb_B_in
33
V_out
2V_in
31
C_out
6C_in
28
Y_out
8Y_in
9
10
VOUTR
VOUTL
1
2
DSD_L
DSD_R
IC302
BA4560F
Audio LPF & Amp.
1
3
2
4PCMDATA
7
2/2
1/2
6
5
1
3
2
7
2/2
1/2
6
5
IC401
DSD1702EG
Audio DAC (C, Lfe)
IC402
BA4560F
Audio LPF & Amp.
JA601
JA602
CONTROL
IN
OUT
SEL IR
IR
A_DOUT
VREF
Q101
REG.
V+12A V+5A
IC101
NJM78M05FA
5V REG.
V+6 V+5V
IC771
MM1565AF
5V REG.
JA801
JA102
(19P)
DIGITAL
AUDIO OUT
OPTICAL
DIGITAL
AUDIO OUT
COAXIAL
S VIDEO OUT
VIDEO OUT
Y (GREEN)
COMPONENT
VIDEO OUT
PB(BLUE)
PR(RED)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

DV-563A-S
18
1234
1234
C
D
F
A
B
E
3.2 LOAB ASSY and OVERALL WIRING DIAGRAM
JCKB ASSY
(VWV1942)
C
Note : When ordering service parts, be sure
to refer to "EXPLODED VIEWS and
PARTS LIST" or "PCB PARTS LIST".
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

DV-563A-S 19
5678
5678
C
D
F
A
B
E
A
LOAB ASSY
(VWG2426)
ALOADING
MOTOR ASSY
: VXX2872
STEPPING MOTOR
: VXM1101
SPINDLE
MOTOR
: VXM1099
PICKUP ASSY-S
(OXX8005)
DVDM ASSY
(VWS1563)
B
POWER SUPPLY UNIT
(VWR1365)
F
PWSB ASSY
(VWG2429)
E
FLKY ASSY
D
(DV-563A-S: VWG2427)
(DV-50A: VWG2430)
: FOCUS SERVO LOOP LINE
: TRACKING SERVO LOOP LINE
(F)
(T)
: STEPPING SERVO LOOP LINE
(S)
RF : RF SIGNAL ROUTE
FTTF
SSSS
RF RF
RF
RF
RF
RF
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

DV-563A-S
20
1234
1234
C
D
F
A
B
E
3.3 DVDM ASSY 1/3 [FRONT END BLOCK]
B1/3
B1/3
DVDM ASSY (VWS1563)
CN601
STEPPING
MOTOR
SPINDLE
MOTOR
PICKUP
ASSY-S
A
S
S
S
S
F
F
T
T
S S S S
RF
RF
RF
RF
RF
RF
5
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
