Pioneer DV-575A User manual

01
1
En
DVD Player
DV-575A
DV-578A
DV-676A-s
Operating Instructions
Register Your Product at
www.pioneerelectronics.com
DV-676A-S only
DV-676A-S only
DV575A KU_Mid.book 1 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals

The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
The lightning flash with arrowhead, within
an equilateral triangle, is intended to alert
the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
CAUTION:
TO PREVENT THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
D1-4-2-3_En
IMPORTANT NOTICE – THE SERIAL NUMBER FOR THIS EQUIPMENT IS LOCATED IN THE REAR.
PLEASE WRITE THIS SERIAL NUMBER ON YOUR ENCLOSED WARRANTY CARD AND
KEEP IN A SECURE AREA. THIS IS FOR YOUR SECURITY. D1-4-2-6-1_En
CAUTION : USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
CAUTION : THE USE OF OPTICAL INSTRUMENTS WITH THIS PRODUCT WILL INCREASE EYE HAZARD.
D6-8-2-1_En
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
D8-10-1-2_En
Information to User
Alteration or modifications carried out without appropriate authorization may invalidate the user’s right to operate
the equipment.
D8-10-2_En
WARNING: Handling the cord on this product or
cords associated with accessories sold with the
product will expose you to lead, a chemical known to
the State of California and other governmental
entities to cause cancer and birth defects or other
reproductive harm.
D36-P4_En
Wash hands after handling
T
his product contains mercury. Disposal of this
material may be regulated due to environmental
considerations. For disposal or recycling information,
please contact your local authorities or the Electronics
Industries Alliance : www.eiae.org.
K057_En
WARNING: The apparatus is not waterproofs, to
prevent fire or shocks hazard, do not expose this
apparatus to rain or moisture and do not put any
water source near this apparatus, such as vase,
flower pot, cosmetics container and medicine
bottle etc.
D3-4-2-1-3_En
[ For U.S. and P.X. model ]
CAUTION: This product satisfies FCC regulations when shielded cables and connectors are used to connect the
unit to other equipment. To prevent electromagnetic interference with electric appliances such as radios and
televisions, use shielded cables and connectors for connections.
D8-10-3a_En
[ For U.S. and P.X. model ]
DV575A KU_Mid.book 2 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals

READ INSTRUCTIONS — All the safety and
operating instructions should be read before the
product is operated.
RETAIN INSTRUCTIONS — The safety and
operating instructions should be retained for
future reference.
HEED WARNINGS — All warnings on the product
and in the operating instructions should be
adhered to.
FOLLOW INSTRUCTIONS — All operating and use
instructions should be followed.
CLEANING — The product should be cleaned only
with a polishing cloth or a soft dry cloth. Never
clean with furniture wax, benzine, insecticides
or other volatile liquids since they may corrode
the cabinet.
ATTACHMENTS — Do not use attachments not
recommended by the product manufacturer as
they may cause hazards.
WATER AND MOISTURE — Do not use this
product near water — for example, near a
bathtub, wash bowl, kitchen sink, or laundry
tub; in a wet basement; or near a swimming
pool; and the like.
ACCESSORIES — Do not place this product on an
unstable cart, stand, tripod, bracket, or table.
The product may fall, causing serious injury to a
child or adult, and serious damage to the
product. Use only with a cart, stand, tripod,
bracket, or table recommended by the
manufacturer, or sold with the product. Any
mounting of the product should follow the
manufacturer’s instructions, and should use a
mounting accessory recommended by the
manufacturer.
CART — A product and cart combination should be
moved with care. Quick stops, excessive force,
and uneven surfaces may cause the product
and cart combination to overturn.
VENTILATION — Slots and openings in the cabinet
are provided for ventilation and to ensure
reliable operation of the product and to protect
it from overheating, and these openings must
not be blocked or covered. The openings should
never be blocked by placing the product on a
bed, sofa, rug, or other similar surface. This
product should not be placed in a built-in
installation such as a bookcase or rack unless
proper ventilation is provided or the
manufacturer’s instructions have been adhered
to.
POWER SOURCES — This product should be
operated only from the type of power source
indicated on the marking label. If you are not
sure of the type of power supply to your home,
consult your product dealer or local power
company.
LOCATION – The appliance should be installed in a
stable location.
NONUSE PERIODS – The power cord of the
appliance should be unplugged from the outlet
when left un-used for a long period of time.
GROUNDING OR POLARIZATION
• If this product is equipped with a polarized
alternating current line plug (a plug having one
blade wider than the other), it will fit into the
outlet only one way. This is a safety feature. If
you are unable to insert the plug fully into the
outlet, try reversing the plug. If the plug should
still fail to fit, contact your electrician to replace
your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
• If this product is equipped with a three-wire
grounding type plug, a plug having a third
(grounding) pin, it will only fit into a grounding
type power outlet. This is a safety feature. If you
are unable to insert the plug into the outlet,
contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the
grounding type plug.
POWER-CORD PROTECTION — Power-supply
cords should be routed so that they are not likely
to be walked on or pinched by items placed
upon or against them, paying particular
attention to cords at plugs, convenience
receptacles, and the point where they exit from
the product.
OUTDOOR ANTENNA GROUNDING — If an
outside antenna or cable system is connected to
the product, be sure the antenna or cable
system is grounded so as to provide some
protection against voltage surges and built-up
static charges. Article 810 of the National
Electrical Code, ANSI/NFPA 70, provides
information with regard to proper grounding of
the mast and supporting structure, grounding of
the lead-in wire to an antenna discharge unit,
size of grounding conductors, location of
antenna-discharge unit, connection to
grounding electrodes, and requirements for the
grounding electrode. See Figure A.
LIGHTNING — For added protection for this
product during a lightning storm, or when it is
left unattended and unused for long periods of
time, unplug it from the wall outlet and
disconnect the antenna or cable system. This
will prevent damage to the product due to
lightning and power-line surges.
POWER LINES — An outside antenna system
should not be located in the vicinity of overhead
power lines or other electric light or power
circuits, or where it can fall into such power
lines or circuits. When installing an outside
antenna system, extreme care should be taken
to keep from touching such power lines or
circuits as contact with them might be fatal.
OVERLOADING — Do not overload wall outlets,
extension cords, or integral convenience
receptacles as this can result in a risk of fire or
electric shock.
OBJECT AND LIQUID ENTRY — Never push
objects of any kind into this product through
openings as they may touch dangerous voltage
points or short-out parts that could result in a
fire or electric shock. Never spill liquid of any
kind on the product.
SERVICING — Do not attempt to service this
product yourself as opening or removing covers
may expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service
personnel.
DAMAGE REQUIRING SERVICE — Unplug this
product from the wall outlet and refer servicing
to qualified service personnel under the
following conditions:
• When the power-supply cord or plug is
damaged.
• If liquid has been spilled, or objects have fallen
into the product.
• If the product has been exposed to rain or water.
• If the product does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions as an improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore the product to its normal operation.
• If the product has been dropped or damaged in
any way.
• When the product exhibits a distinct change in
performance — this indicates a need for service.
REPLACEMENT PARTS — When replacement parts
are required, be sure the service technician has
used replacement parts specified by the
manufacturer or have the same characteristics
as the original part. Unauthorized substitutions
may result in fire, electric shock, or other
hazards.
SAFETY CHECK — Upon completion of any service
or repairs to this product, ask the service
technician to perform safety checks to
determine that the product is in proper
operating condition.
WALL OR CEILING MOUNTING — The product
should not be mounted to a wall or ceiling.
HEAT — The product should be situated away from
heat sources such as radiators, heat registers,
stoves, or other products (including amplifiers)
that produce heat.
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
NEC — NATIONAL ELECTRICAL CODE
Fig. A
D1-4-2-2_En
[For Canadian model]
This Class B digital apparatus complies with Canadian ICES-003.
[Pour le modèle Canadien]
Cet appareil numérique de la Classe B est conforme à la norme NMB-003 du Canada. D8-10-1-3_EF
DV575A KU_Mid.book 3 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals

WARNING:
BEFORE PLUGGING IN THE UNIT FOR THE FIRST
TIME, READ THE FOLLOWING SECTION CAREFULLY.
The voltage of the available power supply differs
according to country or region. Be sure that the
power supply voltage of the area where this unit
will be used meets the required voltage (e.g., 230V
or 120V) written on the rear panel.
D3-4-2-1-4_En
WARNING: No naked flame sources, such as
lighted candle, should be placed on the apparatus.
If naked flame sources accidentally fall down, fire
spread over the apparatus then may cause fire.
D3-4-2-1-7a_En
WARNING: Slot and openings in the cabinet are
provided for ventilation and to ensure reliable
operation of the product and to protect it from
overheating, to prevent fire hazard, the openings
should never be blocked and covered with items,
such as newspapers, table-cloths, curtains, etc. Also
do not put the apparatus on the thick carpet, bed,
sofa, or fabric having a thick pile. D3-4-2-1-7b_En
Operating Environment
Operating environment temperature and humidity:
+5 ºC – +35 ºC (+41 ºF – +95 ºF); less than 85 %RH
(cooling vents not blocked)
Do not install in the following locations
• Location exposed to direct sunlight or strong artificial
light
• Location exposed to high humidity, or poorly
ventilated location D3-4-2-1-7c_En
CAUTION
This product contains a laser diode of higher class
than 1. To ensure continued safety, do not remove any
covers or attempt to gain access to the inside of the
product.
Refer all servicing to qualified personnel.
The following caution label appears on your unit.
Location : rear of the unit
CLASS 1
LASER PRODUCT
D3-4-2-1-8_En
The STANDBY/ON switch is secondary connected
and therefore, does not separate the unit from mains
power in STANDBY position. Therefore install the
unit suitable places easy to disconnect the MAINS
plug in case of the accident. The MAINS plug of unit
should be unplugged from the wall socket when left
unused for a long period of time. D3-4-2-2-2a_En
On the bonnet of the unit
[For Australia model]
[For Singapore and Taiwan model]
For Taiwan exclusively
T
aiwanese two pin flat-bladed plug
[ Except U.S. and P.X. model ]
DV575A KU_Mid.book 4 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals

This product incorporates copyright protection
technology that is protected by method claims
of certain U.S. patents and other intellectual
property rights owned by Macrovision
Corporation and other rights owners. Use of
this copyright protection technology must be
authorized by Macrovision Corporation, and is
intended for home and other limited viewing
uses only unless otherwise authorized by
Macrovision Corporation. Reverse engineering
or disassembly is prohibited.
This product is for general household purposes.
Any failure due to use for other than household
purposes (such as long-term use for business
purposes in a restaurant or use in a car or ship)
and which requires repair will be charged for
even during the warranty period. K041_En
Energy-saving design
DV-575A and DV-578A are designed to use 0.07W of electricity when
power is switched to standby.
DV-676A-S is designed to use 0.12W of electricity when power is
switched to standby.
For U.S. and Australia Model
C67-7-3_En
S001_En
Selecting fine audio equipment such as the unit
you’ve just purchased is only the start of your
musical enjoyment. Now it’s time to consider how
you can maximize the fun and excitement your
equipment offers. This manufacturer and the
Electronic Industries Association’s Consumer
Electronics Group want you to get the most out of
your equipment by playing it at a safe level. One that
lets the sound come through loud and clear without
annoying blaring or distortion-and, most importantly,
without affecting your sensitive hearing.
Sound can be deceiving. Over time your hearing
“comfort level” adapts to higher volumes of sound.
So what sounds “normal” can actually be loud and
harmful to your hearing. Guard against this by
setting your equipment at a safe level BEFORE your
hearing adapts.
To establish a safe level:
• Start your volume control at a low setting.
• Slowly increase the sound until you can hear it
comfortably and clearly, and without distortion.
Once you have established a comfortable sound
level:
• Set the dial and leave it there.
Taking a minute to do this now will help to prevent
hearing damage or loss in the future. After all, we
want you listening for a lifetime.
We Want You Listening For A Lifetime
Used wisely, your new sound equipment will
provide a lifetime of fun and enjoyment. Since
hearing damage from loud noise is often
undetectable until it is too late, this manufacturer
and the Electronic Industries Association’s
Consumer Electronics Group recommend you avoid
prolonged exposure to excessive noise. This list of
sound levels is included for your protection.
Decibel
Level Example
30 Quiet library, soft whispers
40
Living room, refrigerator, bedroom away from traffic
50 Light traffic, normal conversation, quiet office
60 Air conditioner at 20 feet, sewing machine
70 Vacuum cleaner, hair dryer, noisy restaurant
80
Average city traffic, garbage disposals, alarm clock
at two feet.
THE FOLLOWING NOISES CAN BE DANGEROUS
UNDER CONSTANT EXPOSURE
90
Subway, motorcycle, truck traffic, lawn mower
100 Garbage truck, chain saw, pneumatic drill
120 Rock band concert in front of speakers,
thunderclap
140 Gunshot blast, jet plane
180 Rocket launching pad
Information courtesy of the Deafness Research Foundation.
POWER-CORD CAUTION
Handle the power cord by the plug. Do not pull out the
plug by tugging the cord and never touch the power
cord when your hands are wet as this could cause a
short circuit or electric shock. Do not place the unit, a
piece of furniture, etc., on the power cord, or pinch the
cord. Never make a knot in the cord or tie it with other
cords. The power cords should be routed such that they
are not likely to be stepped on. A damaged power cord
can cause a fire or give you an electrical shock. Check
the power cord once in a while. When you find it
damaged, ask your nearest PIONEER authorized
service center or your dealer for a replacement.
S002_En
This product includes FontAvenue®fonts
licenced by NEC corporation. FontAvenue is
a registered trademark of NEC Corporation.
DV575A KU_Mid.book 5 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals

6
En
Contents
01 Before you start
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
What’s in the box . . . . . . . . . . . . . . . . . . . . 8
Hints on installation . . . . . . . . . . . . . . . . . . 8
Disc / content format playback compatibility
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
02 Connecting up
Easy connections . . . . . . . . . . . . . . . . . . . 11
Connecting using the S-video output . . . . 12
Connecting using the component video
output
. . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Connecting to an AV receiver . . . . . . . . . . 14
03 Controls and displays
Front panel . . . . . . . . . . . . . . . . . . . . . . . . 16
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Remote control . . . . . . . . . . . . . . . . . . . . 18
04 Getting started
Switching on . . . . . . . . . . . . . . . . . . . . . . 19
Using the on-screen displays . . . . . . . . . . 19
Setting up the player for your TV . . . . . . . . 20
Setting the language of this player’s
on-screen displays
. . . . . . . . . . . . . . . . . . 20
Playing discs . . . . . . . . . . . . . . . . . . . . . . 20
05 Playing discs
Scanning discs . . . . . . . . . . . . . . . . . . . . 25
Playing in slow motion . . . . . . . . . . . . . . . 25
Frame advance/frame reverse . . . . . . . . . 25
Viewing a JPEG slideshow . . . . . . . . . . . . 26
Browsing video content with the Disc
Navigator
. . . . . . . . . . . . . . . . . . . . . . . . . 26
Browsing WMA, MP3 and JPEG files with
the Disc Navigator
. . . . . . . . . . . . . . . . . . 27
Looping a section of a disc . . . . . . . . . . . . 28
Using repeat play . . . . . . . . . . . . . . . . . . . 28
Using random play . . . . . . . . . . . . . . . . . .29
Creating a program list . . . . . . . . . . . . . . .30
Searching a disc . . . . . . . . . . . . . . . . . . . .31
Switching subtitles . . . . . . . . . . . . . . . . . .31
Switching audio language/channels . . . . .32
Zooming the screen . . . . . . . . . . . . . . . . . .32
Switching camera angles . . . . . . . . . . . . .32
Displaying disc information . . . . . . . . . . . .32
06 Audio Settings and Video Adjust
menus
Audio Settings menu . . . . . . . . . . . . . . . . .33
Video Adjust menu . . . . . . . . . . . . . . . . . .34
07 Initial Settings menu
Using the Initial Settings menu . . . . . . . . .35
Digital Audio Out settings . . . . . . . . . . . . .35
Video Output settings . . . . . . . . . . . . . . . .36
Language settings . . . . . . . . . . . . . . . . . . .36
Display settings . . . . . . . . . . . . . . . . . . . . .37
Options settings . . . . . . . . . . . . . . . . . . . .37
Speakers settings . . . . . . . . . . . . . . . . . . .38
Parental Lock . . . . . . . . . . . . . . . . . . . . . .40
08 Additional information
Taking care of your player and discs . . . . .44
Screen sizes and disc formats. . . . . . . . . .45
Setting the TV system . . . . . . . . . . . . . . . .46
Resetting the player. . . . . . . . . . . . . . . . . .46
Power reset . . . . . . . . . . . . . . . . . . . . . . . . 46
DVD-Video regions . . . . . . . . . . . . . . . . . .47
Selecting languages using the language
code list. . . . . . . . . . . . . . . . . . . . . . . . . . .47
Language code list . . . . . . . . . . . . . . . . . .48
Country code list . . . . . . . . . . . . . . . . . . . .48
Troubleshooting . . . . . . . . . . . . . . . . . . . .49
Glossary. . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Specifications . . . . . . . . . . . . . . . . . . . . . .55
DV575A KU_Mid.book 6 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals

Before you start 01
7
En
Chapter 1
Before you start
Features
• DVD-Audio and SACD compatible
Experience the super high-quality audio perfor-
mance of DVD-Audio and Super Audio CD
(SACD).
• Super VCD compatible
*1
This player supports the IEC’s Super VCD stan-
dard. Compared to the Video CD standard,
Super VCD offers superior picture quality, and
allows two stereo soundtracks to be recorded.
Super VCD also supports the widescreen size.
• 24-bit/192kHz compatible DAC
The on-board 24-bit/192kHz DAC means that
this player is fully compatible with high
sampling-rate discs, capable of delivering
exceptional sound quality in terms of dynamic
range, low-level resolution and high-frequency
detail.
• Built-in Dolby
*2
Digital and DTS
*3
decoding with multichannel outputs
1
This player features multichannel analog
outputs for connection to an AV amplifier to
give you stunning surround sound from Dolby
Digital, DTS and multichannel DVD-Audio
discs.
• PureCinema Progressive Scan video
When connected to a progressive scan-
compatible TV or monitor using the
component video outputs, you can enjoy
extremely stable, flicker free images, with the
same frame refresh rate as the original movie.
• New Disc Navigator with moving
pictures
The new Disc Navigator enables you play the
first few seconds of each title or chapter in a
thumbnail image on screen.
• DSP effects for enhanced playback
See Audio Settings and Video Adjust menus on
page 33.
• Picture zoom
See Zooming the screen on page 32.
• MP3 and WMA compatibility
See Compressed audio compatibility on page 9.
• JPEG compatibility
See JPEG file compatibility on page 10.
• Energy saving design
An auto power-off function switches the player
into standby if not used for about 30 minutes.
*1
Model DV-676A-S only
*2
Manufactured under license from Dolby
Laboratories. “Dolby” and the double-D symbol
are trademarks of Dolby Laboratories.
*3
“DTS” and “DTS Digital Surround” are
registered trademarks of Digital Theater
Systems Inc.
DV575A KU_Mid.book 7 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
9
En
•Place on an unstable surface, or one that is
not large enough to support all four of the
unit’s feet.
Disc / content format playback
compatibility
This player is compatible with a wide range of
disc types (media) and formats. Playable discs
will generally feature one of the following logos
on the disc and/or disc packaging. Note
however that some disc types, such as
recordable CD and DVD, may be in an
unplayable format—see below for further
compatibility information.
Please also note that recordable discs cannot be
recorded using this player.
• is a trademark of Fuji Photo Film Co. Ltd.
• Also compatible with KODAK Picture CD
* DV-676A-S only
CD-R/RW compatibility
• Compatible formats: CD-Audio, Video CD/
Super VCD, ISO 9660 CD-ROM* containing
MP3, WMA or JPEG files
*
ISO 9660 Level 1 or 2 compliant. CD
physical format: Mode1, Mode2 XA Form1.
Romeo and Joliet file systems are both
compatible with this player.
• Multi-session playback: No
• Unfinalized disc playback: No
DVD-R/RW compatibility
• Compatible formats: DVD-Video, Video
Recording (VR)*
*
Edit points may not play exactly as edited;
screen may go momentarily blank at edited
points.
• Unfinalized playback: No
• WMA/MP3/JPEG file playback on DVD-R/
RW: No
Compressed audio compatibility
•Compatible formats: MPEG-1 Audio Layer 3
(MP3), Windows Media Audio (WMA)
• Sampling rates: 32, 44.1 or 48kHz
• Bit-rates: Any (128Kbps or higher
recommended)
• VBR (variable bit rate) MP3 playback: No
• VBR WMA playback: No
• WMA lossless encoding compatible: No
• DRM (Digital Rights Management)
compatible: Yes (DRM-protected audio
files will
not play in this player—see also
DRM in the Glossary on page 53)
•File extensions: .mp3, .wma (these must be
used for the player to recognize MP3 and
WMA files – do not use for other file types)
• File structure: Up to 299 folders; up to 648
folders and files combined
DVD-Video DVD-R DVD-RW
Video CDAudio CD CD-R CD-RW
DVD-Audio
Super VCD*Super Audio CD
Fujicolor CD
DV575A KU_Mid.book 9 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals

Before you start01
8
En
What’s in the box
Please confirm that the following accessories
are in the box when you open it.
• Remote control
• AA/R6P dry cell batteries x2
• Audio/video cable (red/white/yellow plugs)
• Power cable
• Operating instructions
• Warranty card (DV-575A and DV-578A
model only)
• Front panel button names sticker
(Singapore and Taiwan models only) —
Chinese language button names for the
front panel controls.
• Remote control overlay
(Singapore and
Taiwan models only)
— Place the overlay
on the remote control to be able to read the
buttons in Chinese.
Putting the batteries in the remote
• Open the battery compartment cover
and insert the batteries as shown.
Use two AA/R6P batteries and follow the
indications (
 ,  ) inside the compartment.
Close the cover when you’re finished.
Important
Incorrect use of batteries can result in hazards
such as leakage and bursting. Please observe
the following:
• Don’t mix new and old batteries together.
• Don’t use different kinds of battery
together—although they may look similar,
different batteries may have different
voltages.
•Make sure that the plus and minus ends of
each battery match the indications in the
battery compartment.
• Remove batteries from equipment that
isn’t going to be used for a month or more.
• When disposing of used batteries, please
comply with governmental regulations or
environmental public instruction’s rules
that apply in your country or area.
Hints on installation
We want you to enjoy using this product for
years to come, so please use the following
guidelines when choosing a suitable location:
Do...
• Use in a well-ventilated room.
•Place on a solid, flat, level surface, such as
a table, shelf or stereo rack.
Don’t...
• Use in a place exposed to high
temperatures or humidity, including near
radiators and other heat-generating
appliances.
•Place on a window sill or a place where the
player will be exposed to direct sunlight.
• Use in an excessively dusty or damp
environment.
• Place directly on top of an amplifier, or
other component in your stereo system
that becomes hot in use.
•Use near a television or monitor as you may
experience interference—especially if the
television uses an indoor antenna.
• Use in a kitchen or other room where the
player may be exposed to smoke or steam.
• Use on a thick rug or carpet, or cover with
cloth—this may prevent proper cooling of
the unit.
DV575A KU_Mid.book 8 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
10
En
About WMA
The Windows Media
®
logo printed on the box
indicates that this player can playback
Windows Media Audio content.
WMA is an acronym for Windows Media Audio
andrefers to an audiocompression technology
developed by Microsoft Corporation. WMA
content can be encoded by using Windows
Media
®
Player version 7, 7.1, Windows Media
®
Player for Windows
®
XP, or Windows Media
®
Player 9 Series.
Microsoft, Windows Media, and the Windows
logo are trademarks, or registered trademarks of
Microsoft Corporation in the United States and/
or other countries.
JPEG file compatibility
• Compatible formats: Baseline JPEG and
EXIF 2.2* still image files up to a resultion
of 3072 x 2048.
*
File format used by digital still cameras
• Progressive JPEG compatible: No
• File extensions: .jpg (must be used for the
player to recognize JPEG files – do not use
for other file types)
• File structure: Up to 299 folders; up to 648
folders and files combined
PC-created disc compatibility
Discs recorded using a personal computer
may not be playable in this unit due to the
setting of the application software used to
create the disc. In these particular instances,
check with the software publisher for more
detailed information.
Discs recorded in packet write mode (UDF
format) are not compatible with this player.
Check the DVD-R/RW or CD-R/RW software
disc boxes for additional compatibility
information.
DV575A KU_Mid.book 10 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals

Before you start 01
7
En
Chapter 1
Before you start
Features
Experience the super high-quality audio perfor-
mance of DVD-Audio and Super Audio CD
(SACD).
This player supports the IEC’s Super VCD stan-
dard. Compared to the Video CD standard,
Super VCD offers superior picture quality, and
allows two stereo soundtracks to be recorded.
Super VCD also supports the widescreen size.
The on-board 24-bit/192kHz DAC means that
this player is fully compatible with high
sampling-rate discs, capable of delivering
exceptional sound quality in terms of dynamic
range, low-level resolution and high-frequency
detail.
This player features multichannel analog
outputs for connection to an AV amplifier to
give you stunning surround sound from Dolby
Digital, DTS and multichannel DVD-Audio
discs.
When connected to a progressive scan-
compatible TV or monitor using the
component video outputs, you can enjoy
extremely stable, flicker free images, with the
same frame refresh rate as the original movie.
The new Disc Navigator enables you play the
first few seconds of each title or chapter in a
thumbnail image on screen.
See Audio Settings and Video Adjust menus on
page 33.
See Zooming the screen on page 32.
See Compressed audio compatibility on page 9.
See JPEG file compatibility on page 10.
An auto power-off function switches the player
into standby if not used for about 30 minutes.
*1
Model DV-676A-S only
*2
Manufactured under license from Dolby
Laboratories. “Dolby” and the double-D symbol
are trademarks of Dolby Laboratories.
*3
“DTS” and “DTS Digital Surround” are
registered trademarks of Digital Theater
Systems Inc.
DV575A KU_Mid.book 7 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
9
En
•Place on an unstable surface, or one that is
not large enough to support all four of the
unit’s feet.
Disc / content format playback
compatibility
This player is compatible with a wide range of
disc types (media) and formats. Playable discs
will generally feature one of the following logos
on the disc and/or disc packaging. Note
however that some disc types, such as
recordable CD and DVD, may be in an
unplayable format—see below for further
compatibility information.
Please also note that recordable discs cannot be
recorded using this player.
• is a trademark of Fuji Photo Film Co. Ltd.
• Also compatible with KODAK Picture CD
* DV-676A-S only
CD-R/RW compatibility
• Compatible formats: CD-Audio, Video CD/
Super VCD, ISO 9660 CD-ROM* containing
MP3, WMA or JPEG files
*
ISO 9660 Level 1 or 2 compliant. CD
physical format: Mode1, Mode2 XA Form1.
Romeo and Joliet file systems are both
compatible with this player.
• Multi-session playback: No
• Unfinalized disc playback: No
DVD-R/RW compatibility
• Compatible formats: DVD-Video, Video
Recording (VR)*
*
Edit points may not play exactly as edited;
screen may go momentarily blank at edited
points.
• Unfinalized playback: No
• WMA/MP3/JPEG file playback on DVD-R/
RW: No
Compressed audio compatibility
•Compatible formats: MPEG-1 Audio Layer 3
(MP3), Windows Media Audio (WMA)
• Sampling rates: 32, 44.1 or 48kHz
• Bit-rates: Any (128Kbps or higher
recommended)
• VBR (variable bit rate) MP3 playback: No
• VBR WMA playback: No
• WMA lossless encoding compatible: No
• DRM (Digital Rights Management)
compatible: Yes (DRM-protected audio
files will
not play in this player—see also
DRM in the Glossary on page 53)
•File extensions: .mp3, .wma (these must be
used for the player to recognize MP3 and
WMA files – do not use for other file types)
• File structure: Up to 299 folders; up to 648
folders and files combined
DVD-Video DVD-R DVD-RW
Video CDAudio CD CD-R CD-RW
DVD-Audio
Super VCD*Super Audio CD
Fujicolor CD
DV575A KU_Mid.book 9 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals

Before you start01
8
En
What’s in the box
Please confirm that the following accessories
are in the box when you open it.
• Remote control
• AA/R6P dry cell batteries x2
• Audio/video cable (red/white/yellow plugs)
• Power cable
• Operating instructions
• Warranty card (DV-575A and DV-578A
model only)
• Front panel button names sticker
(Singapore and Taiwan models only) —
Chinese language button names for the
front panel controls.
• Remote control overlay
(Singapore and
Taiwan models only)
— Place the overlay
on the remote control to be able to read the
buttons in Chinese.
Putting the batteries in the remote
Use two AA/R6P batteries and follow the
indications (
, ) inside the compartment.
Close the cover when you’re finished.
Important
Incorrect use of batteries can result in hazards
such as leakage and bursting. Please observe
the following:
• Don’t mix new and old batteries together.
• Don’t use different kinds of battery
together—although they may look similar,
different batteries may have different
voltages.
•Make sure that the plus and minus ends of
each battery match the indications in the
battery compartment.
• Remove batteries from equipment that
isn’t going to be used for a month or more.
• When disposing of used batteries, please
comply with governmental regulations or
environmental public instruction’s rules
that apply in your country or area.
Hints on installation
We want you to enjoy using this product for
years to come, so please use the following
guidelines when choosing a suitable location:
Do...
• Use in a well-ventilated room.
•Place on a solid, flat, level surface, such as
a table, shelf or stereo rack.
Don’t...
• Use in a place exposed to high
temperatures or humidity, including near
radiators and other heat-generating
appliances.
•Place on a window sill or a place where the
player will be exposed to direct sunlight.
• Use in an excessively dusty or damp
environment.
• Place directly on top of an amplifier, or
other component in your stereo system
that becomes hot in use.
•Use near a television or monitor as you may
experience interference—especially if the
television uses an indoor antenna.
• Use in a kitchen or other room where the
player may be exposed to smoke or steam.
• Use on a thick rug or carpet, or cover with
cloth—this may prevent proper cooling of
the unit.
DV575A KU_Mid.book 8 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
10
En
About WMA
The Windows Media
®
logo printed on the box
indicates that this player can playback
Windows Media Audio content.
WMA is an acronym for Windows Media Audio
andrefers to an audiocompression technology
developed by Microsoft Corporation. WMA
content can be encoded by using Windows
Media
®
Player version 7, 7.1, Windows Media
®
Player for Windows
®
XP, or Windows Media
®
Player 9 Series.
Microsoft, Windows Media, and the Windows
logo are trademarks, or registered trademarks of
Microsoft Corporation in the United States and/
or other countries.
JPEG file compatibility
• Compatible formats: Baseline JPEG and
EXIF 2.2* still image files up to a resultion
of 3072 x 2048.
*
File format used by digital still cameras
• Progressive JPEG compatible: No
• File extensions: .jpg (must be used for the
player to recognize JPEG files – do not use
for other file types)
• File structure: Up to 299 folders; up to 648
folders and files combined
PC-created disc compatibility
Discs recorded using a personal computer
may not be playable in this unit due to the
setting of the application software used to
create the disc. In these particular instances,
check with the software publisher for more
detailed information.
Discs recorded in packet write mode (UDF
format) are not compatible with this player.
Check the DVD-R/RW or CD-R/RW software
disc boxes for additional compatibility
information.
DV575A KU_Mid.book 10 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals

Connecting up 02
11
En
Chapter 2
Connecting up
Easy connections
The setup described here is a basic setup that allows you to play discs using just the cables
supplied with the player. In this setup, stereo audio is played through the speakers in your TV.
Important
•This player is equipped with copy protection technology. Do not connect this player to your TV
via a VCR using audio/video or S-video cables, as the picture from this player will not appear
properly on your TV. (This player may also not be compatible with some combination TV/VCRs
for the same reason; refer to the manufacturer for more information.)
• When connecting to your TV as shown above, do not set the
Component Out setting (see
Video Output settings on page 36) to Progressive .
S
VIDEO OUT
AUDIO OUT (5.1 ch )
CENTER
COMPONENT VIDEO OUT
AUDIO OUT ( 2 ch )
FRONT
SURROUND
SUB
WOOFER
COAXIAL
OPTICAL
DIGITAL AUDIO OUT
VIDEO
OUT
PR
PB
Y
LL
R
R
AC IN
L
R
Yellow
White
Red
TV
A/V IN
To power
outlet
DV575A KU_Mid.book 11 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
13
En
Watching progressive scan video
from the component video outputs
This player can output progressive scan video
from the component video output. Compared
to interlace video, progressive scan video
effectively doubles the scanning rate of the
picture, resulting in a very stable, flicker-free
image.
To set up the player for use with a progressive
scan TV, see
Video Output settings on page 36.
When the player is set to output progressive
scan video, the
PRGSVE indicator lights in the
front panel display.
Important
• If you connect a TV that is not compatible
with a progressive scan signal and switch
the player to progressive, you will not be
able to see any picture at all. In this case,
switch everything off and reconnect using
the supplied video cable (see
Easy
connections
on page 11), then switch back
to
Interlace (see below).
Switching the video output to interlace
using the front panel controls
Switch the player to standby then, using the
front panel controls, press
STANDBY/ON
while pressing
to switch the player back to
Interlace .
Compatibility of this player with
progressive-scan and high-definition TVs
This player is compatible with progressive
video Macro Vision System Copy Guard.
Consumers should note that not all high-
definition television sets are fully compatible
with this product and may cause artifacts to be
displayed in the picture. In case of 525
progressive scan picture problems, it is
recommended that the user switch the
connection to the ‘standard definition’ output
(Interlace). If there are questions regarding our
TV set compatibility with this model, please
contact our customer service center.
This player is compatible with the following
Pioneer displays and monitors:
Plasma display (DV-575A, DV-578A )
PDP-505HD, PDP-5030HD, PDP-4330HD,
PDP-5040HD, PDP-4340HD, Pro-1000HD, Pro-
800HD, Pro-1000HDI, Pro-800HDI, Pro-
1110HD, Pro-910HD, PDP-4300, PDP-5031
Projection monitor receiver (DV-575A, DV-578A )
SD-533HD5, SD-643HD5, Pro-710HD, Pro-
610HD, Pro-510HD, Pro-720HD, Pro-620HD,
Pro-520HD, Pro-730HD, Pro-630HD, Pro-
530HD, Pro-730HDI, Pro-530HDI
Plasma display (DV-676A-S)
PDP-502MX, PDP-503HDG, PDP-433HDG,
PDP-5040HD, PDP-4340HD
Projection monitor receiver (DV-676A-S)
SD-532HD5, SD-533HD5
FL DIMMER OPEN/CLOSE
STANDBY/ON
DV-575A / DV-676A-S
STANDBY/ON
DV575A KU_Mid.book 13 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
15
En
Connecting the digital output
This player has both optical and coaxial-type
digital audio outputs for connection to an AV
receiver. Connect whichever is convenient.
Depending on the capabilities of your AV
receiver, you might have to set up this player to
output only digital audio in a compatible
format. See
Digital Audio Out settings on
page 35 and refer to the operating instructions
that came with your AV receiver.
•Connect one of the DIGITAL AUDIO OUT
jacks on this player to a digital input on
your AV receiver.
For an optical connection, use an optical cable
(not supplied) to connect the
OPTICAL
DIGITAL AUDIO OUT
jack to an optical input
on your AV receiver.
For a coaxial connection, use a coaxial cable
(similar to the supplied video cable) to connect
the
COAXIAL DIGITAL AUDIO OUT jack to a
coaxial input on your AV receiver.
S
VIDEO OUT
AUDIO OUT (5.1 ch )
CENTER
COMPONENT VIDEO OUT
AUDIO OUT ( 2 ch )
FRONT
SURROUND
SUB
WOOFER
COAXIAL
OPTICAL
DIGITAL AUDIO OUT
VIDEO
OUT
P R
P B
Y
LL
R
R
AV receiver
DIGITAL IN
(OPTICAL)
DIGITAL IN
(COAXIAL)
DV575A KU_Mid.book 15 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Controls and displays
03
17
En
Display
1 V-PART
Lights when playing a video part of a DVD disc.
2 PRGSVE
Lights when the player is set to output progres-
sive scan video (see
Component Out on
page 36 ).
3 GRP
Indicates that the character display is showing
a DVD-Audio group number.
4 TITLE
Indicates that the character display is showing
a DVD title number.
5 TRK
Indicates that the character display is showing
a DVD-Audio, SACD, CD or Video CD/Super
VCD track number.
6 CHP
Indicates that the character display is showing
a DVD chapter number.
7 5.1CH
Lights when analog 5.1 channel output is
selected (see
Audio Output Mode on page 41).
8 D.MIX
During multichannel audio playback, indicates
that the output signal has been “downmixed”
from the original audio source. This is an auto-
matic function performed by the player in order
to present the most appropriate audio mix to
the speakers present in your system.
9
Lights in any of the repeat play modes.
10 REMAIN
Indicates that the character display is showing
the disc or title/chapter/track remain time.
11 Character display
12
Lights during multi-angle scenes on a DVD
disc.
13 and
Indicates whether a disc is playing or paused.
14 DTS
Lights when a DTS soundtrack is playing.
15 D
Lights when a Dolby Digital soundtrack is
playing.
1415 1113 12
2 43 5 5 6 7 8 9 10
1
DV575A KU_Mid.book 17 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Getting started
04
19
En
Chapter 4
Getting started
Switching on
After making sure that everything is connected
properly and that the player is plugged in,
press
STANDBY/ON on the front panel or
remote control to switch the player on.
Also, switch on your TV and make sure that it is
set to the input you connected the DVD player
to.
FAQ
• My DVD player switches on but there is
nothing displayed on my TV.
Make sure that the TV is set to the correct
video input (not a TV channel). For
example, if you connected this player to the
VIDEO 1 inputs on your TV, switch your TV
to
VIDEO 1 .
Note
•This player features a screen saver and an
auto power off function. If the player is
stopped and no button is pressed for
around five minutes, the screen saver
starts. If the disc tray is closed but no disc
is playing and no control is pressed for
about 30 minutes, the player automatically
goes into standby.
Using the on-screen displays
For ease of use, this player makes extensive
use of graphical on-screen displays (OSDs).
All the screens are navigated in basically the
same way, using the cursor buttons (
) to change the highlighted item and
pressing
ENTER to select it.
FL DIMMER
STANDBY/ON
DV-575A / DV-676A-S
STANDBY/ON
Button What it does
HOME
MENU
Display/exit the on-screen display.
Changes the highlighted menu
item.
ENTER
Selects the highlighted menu
item (both
ENTER buttons on the
remote work in exactly the same
way).
RETURN Returns to the main menu
without saving changes.
ENTER
GUIDE RETURN
ENTER
HOME
MENU
RETURN
OPEN/CLOSE
TOP MENU MENU
HOME
MENU RETURN
ENTER
DV-578A
DV575A KU_Mid.book 19 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Getting started
04
21
En
1 If the player isn’t already on, press
STANDBY/ON to switch it on.
If you’re playing a DVD or Video CD/Super VCD,
also turn on your TV and make sure that it is set
to the correct video input.
2 Press OPEN/CLOSE to open the disc
tray.
3 Load a disc.
Load a disc with the label side facing up, using
the disc tray guide to align the disc (if you’re
loading a double-sided DVD disc, load it with
the side you want to play face down).
4 Press (play) to start playback.
If you’re playing a DVD or Video CD/Super VCD,
an on-screen menu may appear. See
DVD disc
menus
on page 22 and Video CD/Super VCD
PBC menus
on page 23 for more on how to
navigate these.
•If you’re playing an MP3/WMA disc, it may
take a few seconds before playback starts.
Note
• You may find with some DVD discs that
some playback controls don’t work in
certain parts of the disc. This is not a
malfunction.
Basic playback controls
The table below shows the basic controls on
the remote for playing discs. The following
chapter covers other playback features in more
detail.
0
123
456
789
STANDBY/ON
OPEN/CLOSE
ENTER
ENTER
Button What it does
Starts playback.
If the display shows RESUME or
LAST MEM playback starts from
the resume or last memory point
(see also Resume and Last Memory
on page 22.)
Pauses a disc that’s playing, or
restarts a paused disc.
Stops playback.
See also Resume and Last Memory
on page 22.
(remote
only)
Press to start fast reverse scanning.
Press
(play) to resume normal
playback.
(remote
only)
Press to start fast forward scanning.
Press (play) to resume normal
playback.
DV575A KU_Mid.book 21 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Getting started
04
23
En
Video CD/Super VCD PBC menus
Some Video CD/Super VCDs have menus from
which you can choose what you want to watch.
These are called PBC (Playback control)
menus.
You can play a PBC Video CD/Super VCD
without having to navigate the PBC menu by
starting playback using a number button to
select a track, rather than the
(play) button.
Button What it does
TOP MENU Displays the ‘top menu’ of a DVD
disc—this varies with the disc.
MENU Displays a DVD disc menu—this
varies with the disc and may be
the same as the ‘top menu’.
Moves the cursor around the
screen.
ENTER Selects the current menu option.
RETURN Returns to the previously dis-
played menu screen. On some
DVD-Audio discs featuring
browsable pictures, press to dis-
play the browser screen.
Numbers
(remote
only)
Highlights a numbered menu
option (some discs only). Press
ENTER to select.
Button What it does
RETURN Displays the PBC menu.
Numbers
(remote
only)
Use to enter a numbered menu
option. Press
ENTER
to select.
Displays the previous menu page
(if there is one).
Displays the next menu page (if
there is one).
0
123
456
789
RETURN
ENTER
ENTER
DV575A KU_Mid.book 23 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Playing discs
05
25
En
Chapter 5
Playing discs
Note
• Many of the functions covered in this
chapter apply to DVD and SACD discs,
Video CDs/Super VCDs, CDs and WMA/
MP3 JPEG discs, although the exact
operation of some varies slightly with the
kind of disc loaded.
• Some DVDs restrict the use of some
functions (random or repeat, for example)
in some or all parts of the disc. This is not a
malfunction.
•When playing Video CD/Super VCDs, some
of the functions are not available during
PBC playback. If you want to use them,
start the disc playing using a number
button to select a track.
Scanning discs
You can fast-scan discs forward or backward at
four different speeds.
1 During playback, press or to
start scanning.
• There is no sound while scanning DVDs
(including DVD-Audio) and Video CD/
Super VCDs.
2 Press repeatedly to increase the
scanning speed.
• The scanning speed is shown on-screen.
3 To resume normal playback, press
(play).
• When scanning a Video CD/Super VCD
playing in PBC mode or a WMA/MP3 track,
playback automatically resumes at the end
or beginning of the track.
• Depending on the disc, normal playback
may automatically resume when a new
chapter is reached on a DVD disc.
Playing in slow motion
You can play DVD-Videos and DVD-R/RW at
four different slow motion speeds, forwards
and backwards. Video CD/Super VCDs can be
played at four different forward slow motion
speeds.
1 During playback, press (pause).
2 Press and hold
or until
slow motion playback starts.
• The slow motion speed is shown on-
screen.
• There is no sound during slow motion
playback.
3 Press repeatedly to change the slow
motion speed.
4 To resume normal playback, press
(play).
• Depending on the disc, normal playback
may automatically resume when a new
chapter is reached.
Frame advance/frame reverse
You can advance or back up DVD-Video and
DVD-R/RW discs frame-by-frame. With Video
CD/Super VCDs you can only use frame
advance.
DV575A KU_Mid.book 25 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Playing discs
05
27
En
• Title – Titles from a DVD-Video disc.
•
Chapter – Chapters from the current title
of a DVD-Video disc.
•
Track – Tracks from a Video CD/Super VCD
disc.
•
Time – Thumbnails from a Video CD/Super
VCD disc at 10 minute intervals.
•
Original: Title – Original titles from a VR
mode DVD-RW disc.
•
Playlist: Title – Playlist titles from a VR
mode DVD-RW disc.
•
Original: Time – Thumbnails from the
Original content at 10 minute intervals.
•
Playlist: Time – Thumbnails from the
Playlist at 10 minute intervals.
The screen shows up to six moving thumbnail
images displayed one after another. To display
the previous/next six thumbnails, press
/
(you don’t have to wait for all the
thumbnails to finish playing to display the
previous/next page).
3 Select the thumbnail image for what
you want to play.
You can use either the cursor buttons (
) and ENTER to select a thumbnail, or the
number buttons.
To select using the number buttons, enter a
two-digit number then press
ENTER .
Tip
•Another way to find a particular place on a
disc is to use one of the search modes. See
Searching a disc on page 31.
Browsing WMA, MP3 and JPEG
files with the Disc Navigator
Use the Disc Navigator to find a particular file
or folder by filename.
1 Press HOME MENU and select ‘Disc
Navigator’ from the on-screen menu.
2 Use the cursor buttons (
)
and ENTER to navigate.
Use the cursor up/down buttons ( ) to
move up and down the folder/file list.
Use the cursor left button (
) to return to the
parent folder.
Use
ENTER or cursor right ( ) to open a
highlighted folder.
•You can also return to the parent folder by
going to the top of the list to the ‘
.. ’ folder,
then pressing
ENTER .
01
04
02
05
03
06
Disc Navigator: Title
01- 49: --
00:00/ 00:00 0kbps
Folder1
Folder2
Folder3
Folder4
DV575A KU_Mid.book 27 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Playing discs
05
29
En
1During playback, press PLAY MODE and
select ‘Repeat’ from the list of functions on
the left.
2 Select a repeat play option.
If program play is active, select Program
Repeat
to repeat the program list, or Repeat
Off
to cancel.
The repeat options available depend on the
kind of disc loaded. For example, for DVD-
Video and DVD-RW discs, you can select
Title
Repeat
or Chapter Repeat (or Repeat Off ).
• For DVD-Audio discs, select
Group
Repeat
or Track Repeat (or Repeat Off ).
•For SACDs,CDs and Video CD/Super
VCDs, select
Disc Repeat or Track Repeat
(or
Repeat Off ).
Using random play
Use the random play function to play titles or
chapters (DVD-Video), Groups (DVD-Audio), or
tracks (DVD-Audio, SACD, CD, Video CD/
Super VCD) at random. (Note that the same
track/title/chapter may play more than once.)
You can set the random play option when a
disc is playing or stopped.
Important
• Random play remains in effect until you
select
Random Off from the random play
menu options.
•You can’t use random play with VR format
DVD-RW discs, Video CD/Super VCDs
playing in PBC mode, WMA/MP3 discs, or
while a DVD disc menu is being displayed.
• You can't use random play together with
program or repeat play.
1 Press PLAY MODE and select ‘Random’
from the list of functions on the left.
2 Select a random play option.
The random play options available depend on
the kind of disc loaded. For example, for DVD-
Video discs, you can select
Random Title or
Random Chapter , (or Random Off ).
• For DVD-Audio discs, select
Random
Group
or Random Track , (or Random
Off
).
•For CDs, SACDs and Video CD/Super
VCDs, select
On or Off to switch random
play on or off.
DV575A KU_Mid.book 29 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Playing discs
05
31
En
Tip
•Use the following controls during program
play:
Other functions available from the
program menu
There are a number of other options in the
program menu in addition to Create/Edit.
•
Playback Start – Starts playback of a
saved program list
•
Playback Stop – Turns off program play,
but does not erase the program list
•
Program Delete – Erases the program list
and turns off program play
Searching a disc
You can search DVD-Video discs by title or
chapter number, or by time; DVD-Audio discs
can be searched by group or track number;
SACDs by track number, CDs and Video CD/
Super VCDs by track number or time.
Important
• Search functions are not available with
Video CD/Super VCDs in PBC mode, or
with WMA/MP3 discs.
1 Press PLAY MODE and select ‘Search
Mode’ from the list of functions on the left.
2 Select a search mode.
The search options available depend on the
kind of disc loaded.
• The disc must be playing in order to use
time search.
3Use the number buttons to enter a title,
chapter or track number, or a time.
• For a time search, enter the number of
minutes and seconds into the currently
playing title (DVD) or track (CD/Video CD/
Super VCD) you want playback to resume
from. For example, press
4 , 5 , 0 , 0 to have
playback start from 45 minutes into the
disc. For 1 hour, 20 minutes and 30
seconds, press
8 , 0 , 3 , 0 .
• Some DVD-Audio discs feature pages of
browsable pictures. Enter the page
number you want.
4 Press ENTER to start playback.
Switching subtitles
Some DVD-Video discs have subtitles in one or
more languages; the disc box will usually tell
you which subtitle languages are available. You
can switch subtitle language during playback.
1 Press SUBTITLE repeatedly to select a
subtitle option.
Button What it does
PLAY
MODE
Save the program list and exit
the program edit screen without
starting playback ( HOME MENU
does the same).
Skip to the next step in the
program list.
DV575A KU_Mid.book 31 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Audio Settings and Video Adjust menus
06
33
En
Chapter 6
Audio Settings and Video
Adjust menus
Audio Settings menu
The Audio Settings menu offers features for
adjusting the way discs sound.
1 Press HOME MENU and select ‘Audio
Settings’ from the on-screen display.
2Select and change settings using the
(cursor) buttons, and ENTER.
Audio DRC
• Settings: High , Medium , Low , Off
(default)
When watching Dolby Digital DVDs at low
volume, it’s easy to lose the quieter sounds
completely—including some of the dialog.
Switching Audio DRC (Dynamic Range
Control) to on can help by bringing up the
quieter sounds, while controlling loud peaks.
How much of a difference you hear depends on
the material you’re listening to. If the material
doesn’t have wide variations in volume, you
may not notice much change.
Note
• Audio DRC is only effective with Dolby
Digital audio sources.
• Audio DRC is only effective through the
digital output when
Digital Out is set to
On , and Dolby Digital Out is set to Dolby
Digital > PCM
(see Digital Audio Out
settings
on page 35).
• The effect of Audio DRC also depends on
your speakers and AV receiver settings.
Virtual Surround
• Settings: On , Off (default)
Switch on Virtual Surround to enjoy realistic
surround sound effects from just two speakers.
Tip
• You can also use the SURROUND button
on the remote control to switch Virtual
Surround on.
Note
• 96kHz Linear PCM audio is automatically
downsampled to 48kHz if Virtual Surround
is switched on.
• The
Audio Output Mode (see page 41)
must be set to
2 Channel in order to be
able to use Virtual Surround.
DV575A KU_Mid.book 33 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
35
En
Chapter 7
Initial Settings menu
Using the Initial Settings menu
The Initial Settings menu provides audio and
video output settings, parental lock settings,
and display settings, among others.
If an option is grayed out it means that it
cannot be changed at the current time. This is
usually because a disc is playing. Stop the
disc, then change the setting.
1 Press HOME MENU and select ‘Initial
Settings’.
2 Use the cursor buttons and ENTER to
select the setting and option you want to
set.
All the settings and options are explained on
the following pages.
Note
• In the table below, the default setting is
shown in
bold : other settings are shown in
italics .
•The Digital Audio Out settings only need to
be set if you have connected the digital
output of this player to an AV receiver, or
other equipment.
• Check the operating instructions supplied
with your other equipment to see which
digital audio formats it’s compatible with.
•Some settings, such as
TV Screen , Audio
Language
and Subtitle Language may be
overridden by the DVD disc. Often these
settings can also be made from the DVD
disc menu.
Digital Audio Out settings
Setting Option What it means
Digital Out On
Digital audio is output from the digital outputs.
Note that there is no digital output when playing SACDs and
some DVD-Audio discs regardless of this setting.
Off
No digital audio output.
Dolby Digital Out Dolby Digital
Dolby Digital encoded digital audio is output when playing a
Dolby Digital DVD disc.
Dolby Digital > PCM
Dolby Digital audio is converted to PCM audio before being
output.
DTS Out DTS
DTS encoded digital audio is output when playing a DTS disc.
(Noise will be output if your amplifier/receiver is not compatible
with DTS audio.)
DTS > PCM
DTS audio is converted to PCM audio before being output.
DV575A KU_Mid.book 35 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
37
En
Display settings
Options settings
Subtitle Language English
If there is are English subtitles on the disc then they will be
displayed.
Languages as displayed
If there is the subtitle language selected on the disc, then it will
be displayed.
Other Language
Select to choose a language other than the ones displayed (see
page 47).
DVD Menu Lan-
guage
w/Subtitle Lang.
DVD disc menus will be displayed in the same language as
your selected subtitle language, if possible.
Languages as displayed
DVD disc menus will be displayed in the selected language, if
possible.
Other Language
Select to choose a language other than the ones displayed (see
page 47).
Subtitle Display On
Subtitles are displayed according to your selected subtitle
language (see above).
Off
Subtitles are always off by default when you play a DVD disc
(note that some discs override this setting).
Setting Option What it means
Setting Option What it means
OSD Language English
On-screen displays of the player are in English.
Languages as displayed
On-screen displays are shown in the language selected.
Angle Indicator On
A camera icon is displayed on-screen during multi-angle
scenes on a DVD disc.
Off
No multi-angle indication is shown.
Setting Option What it means
Parental Lock –
See Parental Lock on page 40.
DVD Playback
Mode
DVD-Audio
All material on a DVD-Audio disc is playable.
DVD-Video
Only the DVD-Video part of a DVD-Audio disc is playable.
DV575A KU_Mid.book 37 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
39
En
About the audio output settings
The table below shows how the audio settings you make in the Initial Settings menu (see page 35)
affect the output from the 2 channel and the 5.1 channel analog outputs, and from the digital
outputs with various types of disc.
*
1
When Audio Output Mode is set to 2 Channel , the AUDIO OUT (5.1ch) FRONT L / R jacks act as a second pair
of stereo audio outputs.
*
2
Dolby Digital > PCM , MPEG > PCM or DTS > PCM setting (pages 35–36)
*
3
Dolby Digital , MPEG or DTS setting (pages 35–36)
*
4
Discs that prohibit downmixing will be output as 5.1 channel even if 2 Channel is selected as the Audio Output
Mode setting (see page 41).
*
5
Discs that prohibit downmixing also mute the digital output.
*
6
When Audio Output Mode is set to 5.1 Channel , mono sources are heard from the center speaker only.
Disc audio format Player setting
Front L / R
–
–
–
–
–
–
–
–
–
–
–
––
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
–
Front L / R
Front L / R
Front L / R
Left / Right Left / Right
Left / Right Left / Right
Left / Right
*6
Left / Right
Left / Right
Left / Right
Left / Right
Left / Right
2ch downmix
2ch downmix
2ch downmix
*4
2ch downmix
2ch downmix
Front L / R
2ch downmix
Front L / R
2ch downmix
2 Ch
5.1 Ch
2 Ch
5.1 Ch
Front L/R
analog outputs
*1
Surround L/R
Center, LFE, outputs
*1
Digital outputs
PCM convert
*2
Bitstream
*3
Dolby Digital
Dolby Digital
karaoke
2 Ch / 5.1 Ch
2 Ch / 5.1 Ch
2 Ch / 5.1 Ch
2 Ch / 5.1 Ch
2 Ch / 5.1 Ch
Linear PCM
2 Ch
5.1 Ch
DTS
MPEG
2 Ch
5.1 Ch
DVD-Audio
2 Ch
5.1 Ch
Super Audio CD
2 Ch
5.1 Ch
DTS CD
CD
Video CD
DVD-RW
(VR mode)
DVD
Dolby Digital
–
2ch downmix
2ch downmix
*5
2ch downmix
*5
DTS
DTS
Dolby Digital
Left / Right
Left / Right Left / Right
Left / Right Left / Right
Dolby Digital
MPEG or PCM
MPEG
DV575A KU_Mid.book 39 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
41
En
The new Country code is set and you will return
to the Options menu screen. Note that the new
Country code doesn’t take effect until the next
disc is loaded (or the current disc is reloaded).
DTS Downmix
• Default setting: Stereo
If you’ve selected DTS > PCM in DTS Out on
page 35 or
2 Channel in Audio Output Mode on
page 41, you can choose the way the signal is
downmixed to PCM audio.
Stereo will
downmix the DTS signal to 2-channel stereo,
whereas
Lt/Rt will downmix to a 2-channel
signal compatible with Dolby surround matrix
decoders. (This allows you to hear surround
sound if your AV receiver or amplifier has Dolby
Pro Logic capability.)
Audio Output Mode
• Default setting: 2 Channel
If you connected this player to your amplifier
using the 5.1 channel analog outputs (front,
surround, center and subwoofer outs), set this
to
5.1 Channel ; if you connected only the
stereo outs, set to
2 Channel .
Note
•Even if you set Audio Output Mode to 5.1
Channel
, you’ll only get sound from all
speakers when playing a 5.1 channel multi-
channel disc.
• When set to
5.1 Channel , only the front
left/right channels are output from the
AUDIO OUT (2ch) jacks. Change to 2
Channel
if you want to listen to downmixed
stereo audio (for example, because you are
listening through the TV’s built-in
speakers).
•When set to
5.1 Channel there is no digital
output when playing DVD-Audio.
•If you set to
2 Channel , Dolby Digital, DTS
and MPEG audio is mixed down to two
channels so you still hear all the audio
recorded on the disc. With DTS encoded
audio, you can choose how the signal is
downmixed to PCM audio. See
DTS
Downmix
above to change the downmix
setting.
• Some DVD-Audio discs don’t allow down-
mixing of audio. These discs always output
multi-channel audio regardless of the
setting made here.
DV575A KU_Mid.book 41 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
43
En
1Use the (cursor up/down) to select
a speaker.
• The L and R speakers are paired; you can’t
set them differently.
2 Press (cursor right) to change the
speaker distance for the highlighted
speaker.
3 Use the
(cursor up/down) to
change the distance.
•When you change the distance settings of
the front left (
L ) or front right ( R ) speakers,
all the other speaker distances change
relative to it.
•Front left/right (
L / R ) speaker distances can
be set from 1 ft. (30 cm) to 30 ft. (9 m) in 1
ft. (30 cm ) increments.
• The center speaker (
C ) can be set from –7
ft. (2.1 m) to 0 ft. (0 m) relative to the front
left/right speakers.
• Surround left/right (
LS / RS ) speakers can
be set from –20 ft. (6.0 m) to 0 ft. (0 m) rela-
tive to the front left/right speakers.
•You can’t set the subwoofer (
SW ) distance.
4 Press (cursor left) to go back to the
speaker list if you want to modify another
speaker, or press ENTER to exit the Speaker
Distance screen.
Note
•During playback of SACD and MPEG-audio
DVD-Video discs, the effective
C , LS and RS
speaker distance settings are –3.0ft (–
0.9m) to 0.0ft (0.0m) relative to the front
left/right speakers.
DV-575A/DV-578A screen
DV-676A-S screen
DV575A KU_Mid.book 43 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
45
En
If you use a chemical-impregnated cleaning
cloth, read the instructions carefully before
use. These cloths may leave smear marks on
half-mirror finish surfaces; if this happens,
finish with a dry cloth.
Cleaning the pickup lens
The DVD player’s lens should not become dirty
in normal use, but if for some reason it should
malfunction due to dust or dirt, consult your
nearest Pioneer-authorized service center. We
do not recommend using commercially
available lens cleaners for CD players.
Condensation
Condensation may form inside the player if it is
brought into a warm room from outside, or if
the temperature of the room rises quickly.
Although the condensation won’t damage the
player, it may temporarily impair its
performance. Leave it to adjust to the warmer
temperature for about an hour before
switching on.
Moving the player
If you need to move the player, first press
STANDBY/ON on the front panel to turn the
player off. Wait for
-OFF- to disappear from the
display, then unplug the power cable. Never lift
or move the unit during playback—discs rotate
at a high speed and may be damaged.
Screen sizes and disc formats
DVD-Video discs come in several different
screen aspect ratios, ranging from TV
programs, which are generally 4:3, to
CinemaScope widescreen movies, with an
aspect ratio of up to about 7:3.
Televisions, too, come in different aspect
ratios; ‘standard’ 4:3 and widescreen 16:9.
Widescreen TV users
If you have a widescreen TV, the TV Screen
setting (page 36) of this player should be set to
16:9 (Wide) .
When you watch discs recorded in 4:3 format,
you can use the TV controls to select how the
picture is presented. Your TV may offer various
zoom and stretch options; see the instructions
that came with your TV for details.
Please note that some movie aspect ratios are
wider than 16:9, so even though you have a
widescreen TV, these discs will still play in a
‘letter box’ style with black bars at the top and
bottom of the screen.
Standard TV users
If you have a standard TV, the TV Screen
setting (page 36) of this player should be set to
4:3 (Letter Box) or 4:3 (Pan&Scan) ,
depending on which you prefer.
Set to
4:3 (Letter Box) , widescreen discs are
shown with black bars top and bottom.
Set to
4:3 (Pan&Scan) , widescreen discs are
shown with the left and right sides cropped.
Although the picture looks larger, you don’t
actually see the whole picture.
Please note that many widescreen discs
override the player’s settings so that the disc is
shown in letter box format regardless of the
setting.
DV575A KU_Mid.book 45 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
47
En
DVD-Video regions
All DVD-Video discs carry a region mark on the
case somewhere that indicates which
region(s) of the world the disc is compatible
with. Your DVD player also has a region mark,
which you can find on the rear panel. Discs
from incompatible regions will not play in this
player. Discs marked
ALL will play in any
player.
The diagram below shows the various DVD
regions of the world.
Selecting languages using the
language code list
Some of the language options (such as ‘DVD
Language’ in the Setup Navigator) allow you to
set your prefered language from any of the 136
languages listed in the language code list on
page 48.
1 Select ‘Other Language’.
2Use the
(cursor left/right) buttons
to select either a code letter or a code
number.
3Use the
(cursor up/down) buttons
to select a code letter or a code number.
See Language code list on page 48 for a
complete list of languages and codes.
1
2
2
5
5
6
3
21
4
4
DV575A KU_Mid.book 47 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
49
En
Troubleshooting
Incorrect operation is often mistaken for trouble or malfunction. If you think that there is
something wrong with this component, check the points below. Sometimes the trouble may lie in
another component. Inspect the other components and electrical appliances being used. If the
trouble cannot be rectified after checking the items below, ask your nearest Pioneer authorized
service center or your dealer to carry out repair work.
Problem Remedy
The disc won’t play or is
automatically ejected
after loading.
• Make sure the disc is free from dirt and dust and is not damaged
(page 44).
• Make sure the disc is loaded with the label side face-up and aligned
properly in the disc tray guide.
• Incompatible region number: If the region number on a DVD-Video
disc does not match the number on the player, the disc cannot be
used (page 47).
• Condensation inside the player: Allow time for condensation to
evaporate. Avoid using the player near an air-conditioning unit.
• Disc is loaded upside down: Reload the disc with the label side face
up.
• A Super VCD that does not conform with the IEC standards might
not play normally.
DVD-Audio playback
stops.
• The disc may have been illegally copied.
Picture playback stops
and the operation
buttons cannot be used.
• Press , then start playback again ( ).
• Press and hold the front panel STANDBY/ON button for about 10
seconds to switch the unit off, then press again to switch back on.
• Switch the power off once, unplug from the wall socket, then plug
back in and switch on again using the front panel STANDBY/ON
button.
New settings made in the
Setup screen menus while
a disc is playing are
ineffective.
• Some settings can be changed while a disc is playing, but are not
effective until the disc is stopped then restarted: Press , then start
playback again ( ).
Settings are canceled. • When the power is cut due to power failure or by unplugging the
power cord, settings will be canceled: Press STANDBY/ON on the
front panel to turn the player off. Wait for --OFF-- to disappear from
the display, then unplug the power cord.
The remote control
doesn't seem to work.
• The remote control is too far from the player, or the angle with the
remote sensor is too wide: Use the remote within its operating range
(page 18).
• The batteries are exhausted: Put in new ones (page 8).
DV575A KU_Mid.book 49 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
51
En
Cannot play multi-
channel audio
• Make sure that Audio Output Mode is set to 5.1 Channel
(page 41).
• Check that the Dolby Digital, DTS and MPEG Out settings
(pages 35–36) are suitable for your amplifier/receiver—check the
instruction manual that came with your amplifier/receiver.
• DVD-Audio and SACDs do not output multichannel digital audio.
Listen through the player’s analog outputs.
• Check that the settings in the Speaker Installation screen are
correct (page 42).
• Check the audio options available from the disc menu.
Cannot listen to high-
sampling rate audio
through the digital
output.
• Make sure that Linear PCM Out is set to Downsample Off
(page 35).
• As a copy-protection measure, some DVDs do not output 96kHz
audio. In this case, even if set to Downsample Off , the player
automatically outputs the audio at 48 kHz. This is not a malfunction.
Cannot output 192kHz or
176.4kHz digital audio.
• The player does not output digital audio at these sampling rates. The
digital output is automatically downsampled.
Cannot output 96kHz or
88.2kHz digital audio.
• Check that Linear PCM Out is set to Downsample Off (page 35).
• Some discs are digital copy protected and do not output high
sampling rate digital audio. In this case the output is automatically
downsampled.
No DTS audio output. • If this unit is connected to a non-DTS compatible amplifier or
decoder using a digital audio cable, set DTS Out to DTS
>
PCM
(page 35). If you do not do this, noise will be output when you play a
DTS disc.
• If this unit is connected to a DTS-compatible amplifier or decoder
using a digital audio cable, check the amplifier settings, and that the
cable is properly connected.
Audio mix does not
sound right or sounds
incomplete (for example,
inaudible dialog).
• Make sure that Audio Output Mode is set to 2 Channel if you've
connected to the stereo inputs on your amplifier or TV (page 41).
The audio recorded on a
Super VCD disc is not
output properly.
• If the audio is switched to [2] when playing a Super VCD that
contains only one stereo soundtrack, there may be no sound at all.
Press AUDIO to change the soundtrack.
Can’t hear effect of
Virtual Surround
• Virtual Surround does not work with SACD or DVD-Audio.
• The Virtual Surround effect is only output through the AUDIO OUT
(2ch) analog audio outputs.
• Make sure that Audio Output Mode is set to 2 Channel (page 41).
• The effectiveness of Virtual Surround varies with the disc.
Problem Remedy
DV575A KU_Mid.book 51 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
53
En
Glossary
Analog audio Direct representation of sound by an
electrical signal. See also Digital audio .
Aspect ratio The width of a TV screen relative to its
height. Conventional TVs are 4:3;
widescreen models are 16:9.
Bonus Group
(DVD-Audio
only)
An ‘extra’ group on some DVD-Audio
discs that requires a key number to
access.
Browsable
pictures
(DVD-Audio
only)
A feature of some DVD-Audio discs in
which the user can browse still pictures
recorded on the disc as the audio is
played. See also Slideshow .
Digital audio Indirect representation of sound using
numbers. See also Sampling frequency
and Analog audio .
Dolby
Digital
*1
A multi-channel audio encoding system
developed by Dolby Laboratories that
enables far more audio to be stored on a
disc than PCM encoding. See also PCM
(Pulse Code Modulation) .
DRM DRM (Digital Rights Management) copy
protection is a technology designed to
prevent unauthorized copying by
restricting playback, etc. of material on
devices other the PC (or other WMA
recording equipment) used to record it.
For detailed information, please see the
instruction manuals or help files that
came with your PC (or other WMA
recording equipment) and/or software.
DTS
*2
A multi-channel audio encoding system
developed by Digital Theater Systems
that enables far more audio to be stored
on a disc than PCM encoding. See also
PCM (Pulse Code Modulation) .
EXIF
(Exchangeabl
e Image File)
A file format developed by Fuji Photo
Film for digital still cameras. Digital
cameras from various manuafcturers
use this compressed file format which
carries date, time and thumbnail
information, as well as the picture data.
File
extension
A tag added to the end of a filename to
indicate the type of file. For example,
“.mp3” indicates an MP3 file.
ISO 9660
format
International standard for the volume
and file structure of CD-ROM discs.
JPEG A standard file format used for still
images. JPEG files are identified by the
file extension “.jpg”.
MP3 MP3 (MPEG1 audio layer 3) is a
compressed stereo audio file format.
Files are recognized by their file
extension “.mp3”.
MPEG audio An audio format used on Video CD/
Super VCDs and some DVD discs.
Packed PCM
(DVD-Audio
only)
A lossless compression system that
enables more PCM audio to be stored
on a DVD-Audio disc than would
otherwise be possible.
PBC
(PlayBack
Control)
A system of navigating a Video CD/
Super VCD through on-screen menus
recorded onto the disc.
PCM
(Pulse Code
Modulation)
Digital audio encoding system found on
CDs. Good quality, but requires a lot of
data compared to Dolby Digital, DTS
and MPEG encoded audio. See also
Digital audio .
Progressive
scan video
All the lines that make up a video
picture are updated in one pass
(compared to interlace which takes two
passes to update the whole picture).
Regions
(DVD-Video
only)
These associate DVD-Video discs and
players with particular areas of the
world. See DVD-Video regions on
page 47 for more information.
Sampling
frequency
The rate at which sound is measured to
be turned into digital audio data. The
higher the rate, the better the sound
quality. CD is 44.1 kHz; DVD can be up
to 96 kHz. See also Digital audio .
DV575A KU_Mid.book 53 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
55
En
Specifications
General
System . . . . . . . . . . . . . . . . . . . . . . . . DVD player
Power requirements
DV-575A / DV-578A . . . . . . . . . . .AC 120 V, 60 Hz
DV-676A-S
. . . . . . AC 110–127/220–240 V, 50/60 Hz
Power consumption
DV-575A / DV-578A . . . . . . . . . . . . . . . . . . . .11 W
DV-676A-S. . . . . . . . . . . . . . . . . . . . . . . . . . . .12 W
Power consumption (standby)
DV-575A / DV-578A . . . . . . . . . . . . . . . . . . 0.07 W
DV-676A-S. . . . . . . . . . . . . . . . . . . . . . . . . . 0.12 W
Weight . . . . . . . . . . . . . . . . . . . 2.1 kg / 4 lb 10 oz
Dimensions . .420 (W) x 55 (H) x 243 (D) mm
. . . . . . . . . . . . . . . (16.5 (W) x 2.2 (H) x 9.6 (D) in.)
Operating temperature . . . . . . . +5°C to +35°C
(+41°F to +95°F)
Operating humidity . . . . . . . . . . . . . . . 5% to 85%
(no condensation)
Component video output
Y (luminance) - Output level . . . . . . 1 Vp-p (75 )
P
B
(color) - Output level . . . . . . . 0.7 Vp-p (75 )
P
R
(color) - Output level . . . . . . . 0.7 Vp-p (75 )
Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA
S-video output
Y (luminance) - Output level . . . . . . 1 Vp-p (75 )
C (color) - Output level . . . . . . 286 mVp-p (75 )
Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .S-video
Video output
Output level . . . . . . . . . . . . . . . . . . . 1 Vp-p (75 )
Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA
Audio output (1 stereo pair)
Output level . . . . . . . . . . . . .During audio output
200 mVrms (1 kHz, –20 dB)
Number of channels . . . . . . . . . . . . . . . . . . . . . . 2
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA
Audio output (multi-channel / L, R, C, SW,
LS, RS)
Output level. . . . . . . . . . . . . During audio output
200 mVrms (1 kHz, –20 dB)
Number of channels . . . . . . . . . . . . . . . . . . . . . 6
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . .RCA jack
Digital audio characteristics
Frequency response . . . . . . . . . . 4 Hz to 44 kHz
(DVD fs: 96 kHz)
4 Hz to 88 kHz (DVD-Audio fs: 192 kHz)
S/N ratio . . . . . . . . . . . . . . . . . . . . . . . . . . .115 dB
Dynamic range . . . . . . . . . . . . . . . . . . . . . .101 dB
Total harmonic distortion. . . . . . . . . . . . 0.0020 %
Wow and flutter . . . . . . . .Limit of measurement
(±0.001% W. PEAK) or lower
Digital output
Coaxial digital output jack . . . . . . . . . . .RCAjack
Optical digital output . . . . . . .Optical digital jack
Accessories
Audio/video cable. . . . . . . . . . . . . . . . . . . . . . . . 1
Power cable
DV-676A-S (Singapore/Taiwan model) . . . . . . 2
Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . 1
AA/R6P dry cell batteries . . . . . . . . . . . . . . . . . 2
Operating Instructions
Warranty card (
U.S. model only
).. . . . . . . . . . 1
Front panel button names sticker
(Singapore/Taiwan models only)
. . . . . . . . . . 1
Remote control overlay
(Singapore/Taiwan models only)
. . . . . . . . . . 1
The specifications and design of this product are subject to
change without notice, due to improvement.
Published by Pioneer Corporation.
Copyright © 2004 Pioneer Corporation.
All rights reserved
DV575A KU_Mid.book 55 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals

Before you start01
8
En
What’s in the box
Please confirm that the following accessories
are in the box when you open it.
• Remote control
• AA/R6P dry cell batteries x2
• Audio/video cable (red/white/yellow plugs)
• Power cable
• Operating instructions
• Warranty card (DV-575A and DV-578A
model only)
• Front panel button names sticker
—
Chinese language button names for the
front panel controls.
• Remote control overlay
— Place the overlay
on the remote control to be able to read the
buttons in Chinese.
Putting the batteries in the remote
• Open the battery compartment cover
and insert the batteries as shown.
Use two AA/R6P batteries and follow the
indications (
 ,  ) inside the compartment.
Close the cover when you’re finished.
Important
Incorrect use of batteries can result in hazards
such as leakage and bursting. Please observe
the following:
• Don’t mix new and old batteries together.
• Don’t use different kinds of battery
together—although they may look similar,
different batteries may have different
voltages.
•Make sure that the plus and minus ends of
each battery match the indications in the
battery compartment.
• Remove batteries from equipment that
isn’t going to be used for a month or more.
• When disposing of used batteries, please
comply with governmental regulations or
environmental public instruction’s rules
that apply in your country or area.
Hints on installation
We want you to enjoy using this product for
years to come, so please use the following
guidelines when choosing a suitable location:
Do...
• Use in a well-ventilated room.
•Place on a solid, flat, level surface, such as
a table, shelf or stereo rack.
Don’t...
• Use in a place exposed to high
temperatures or humidity, including near
radiators and other heat-generating
appliances.
•Place on a window sill or a place where the
player will be exposed to direct sunlight.
• Use in an excessively dusty or damp
environment.
• Place directly on top of an amplifier, or
other component in your stereo system
that becomes hot in use.
•Use near a television or monitor as you may
experience interference—especially if the
television uses an indoor antenna.
• Use in a kitchen or other room where the
player may be exposed to smoke or steam.
• Use on a thick rug or carpet, or cover with
cloth—this may prevent proper cooling of
the unit.
DV575A KU_Mid.book 8 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
10
En
About WMA
The Windows Media
®
logo printed on the box
indicates that this player can playback
Windows Media Audio content.
WMA is an acronym for Windows Media Audio
andrefers to an audiocompression technology
developed by Microsoft Corporation. WMA
content can be encoded by using Windows
Media
®
Player version 7, 7.1, Windows Media
®
Player for Windows
®
XP, or Windows Media
®
Player 9 Series.
JPEG file compatibility
• Compatible formats: Baseline JPEG and
EXIF 2.2* still image files up to a resultion
of 3072 x 2048.
*
• Progressive JPEG compatible: No
• File extensions: .jpg (must be used for the
player to recognize JPEG files – do not use
for other file types)
• File structure: Up to 299 folders; up to 648
folders and files combined
PC-created disc compatibility
Discs recorded using a personal computer
may not be playable in this unit due to the
setting of the application software used to
create the disc. In these particular instances,
check with the software publisher for more
detailed information.
Discs recorded in packet write mode (UDF
format) are not compatible with this player.
Check the DVD-R/RW or CD-R/RW software
disc boxes for additional compatibility
information.
DV575A KU_Mid.book 10 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals

Connecting up 02
11
En
Chapter 2
Connecting up
Easy connections
The setup described here is a basic setup that allows you to play discs using just the cables
supplied with the player. In this setup, stereo audio is played through the speakers in your TV.
Important
•This player is equipped with copy protection technology. Do not connect this player to your TV
via a VCR using audio/video or S-video cables, as the picture from this player will not appear
properly on your TV. (This player may also not be compatible with some combination TV/VCRs
for the same reason; refer to the manufacturer for more information.)
• When connecting to your TV as shown above, do not set the
Component Out setting (see
Video Output settings on page 36) to Progressive .
Yellow
White
Red
TV
A/V IN
To power
outlet
DV575A KU_Mid.book 11 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
13
En
Watching progressive scan video
from the component video outputs
This player can output progressive scan video
from the component video output. Compared
to interlace video, progressive scan video
effectively doubles the scanning rate of the
picture, resulting in a very stable, flicker-free
image.
To set up the player for use with a progressive
scan TV, see
Video Output settings on page 36.
When the player is set to output progressive
scan video, the
PRGSVE indicator lights in the
front panel display.
Important
• If you connect a TV that is not compatible
with a progressive scan signal and switch
the player to progressive, you will not be
able to see any picture at all. In this case,
switch everything off and reconnect using
the supplied video cable (see
Easy
connections
on page 11), then switch back
to
Interlace (see below).
Switching the video output to interlace
using the front panel controls
Switch the player to standby then, using the
front panel controls, press
 STANDBY/ON
while pressing
 to switch the player back to
Interlace .
Compatibility of this player with
progressive-scan and high-definition TVs
This player is compatible with progressive
video Macro Vision System Copy Guard.
Consumers should note that not all high-
definition television sets are fully compatible
with this product and may cause artifacts to be
displayed in the picture. In case of 525
progressive scan picture problems, it is
recommended that the user switch the
connection to the ‘standard definition’ output
(Interlace). If there are questions regarding our
TV set compatibility with this model, please
contact our customer service center.
This player is compatible with the following
Pioneer displays and monitors:
Plasma display (DV-575A, DV-578A )
PDP-505HD, PDP-5030HD, PDP-4330HD,
PDP-5040HD, PDP-4340HD, Pro-1000HD, Pro-
800HD, Pro-1000HDI, Pro-800HDI, Pro-
1110HD, Pro-910HD, PDP-4300, PDP-5031
Projection monitor receiver (DV-575A, DV-578A )
SD-533HD5, SD-643HD5, Pro-710HD, Pro-
610HD, Pro-510HD, Pro-720HD, Pro-620HD,
Pro-520HD, Pro-730HD, Pro-630HD, Pro-
530HD, Pro-730HDI, Pro-530HDI
Plasma display (DV-676A-S)
PDP-502MX, PDP-503HDG, PDP-433HDG,
PDP-5040HD, PDP-4340HD
Projection monitor receiver (DV-676A-S)
SD-532HD5, SD-533HD5
FL DIMMER





 OPEN/CLOSE
STANDBY/ON
DV-575A / DV-676A-S
STANDBY/ON
DV575A KU_Mid.book 13 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
15
En
Connecting the digital output
This player has both optical and coaxial-type
digital audio outputs for connection to an AV
receiver. Connect whichever is convenient.
Depending on the capabilities of your AV
receiver, you might have to set up this player to
output only digital audio in a compatible
format. See
Digital Audio Out settings on
page 35 and refer to the operating instructions
that came with your AV receiver.
•Connect one of the DIGITAL AUDIO OUT
jacks on this player to a digital input on
your AV receiver.
For an optical connection, use an optical cable
(not supplied) to connect the
OPTICAL
DIGITAL AUDIO OUT
jack to an optical input
on your AV receiver.
For a coaxial connection, use a coaxial cable
(similar to the supplied video cable) to connect
the
COAXIAL DIGITAL AUDIO OUT jack to a
coaxial input on your AV receiver.
AV receiver
DIGITAL IN
(OPTICAL)
DIGITAL IN
(COAXIAL)
DV575A KU_Mid.book 15 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Controls and displays
03
17
En
Display
1 V-PART
Lights when playing a video part of a DVD disc.
2 PRGSVE
Lights when the player is set to output progres-
sive scan video (see
Component Out on
page 36 ).
3 GRP
Indicates that the character display is showing
a DVD-Audio group number.
4 TITLE
Indicates that the character display is showing
a DVD title number.
5 TRK
Indicates that the character display is showing
a DVD-Audio, SACD, CD or Video CD/Super
VCD track number.
6 CHP
Indicates that the character display is showing
a DVD chapter number.
7 5.1CH
Lights when analog 5.1 channel output is
selected (see
Audio Output Mode on page 41).
8 D.MIX
During multichannel audio playback, indicates
that the output signal has been “downmixed”
from the original audio source. This is an auto-
matic function performed by the player in order
to present the most appropriate audio mix to
the speakers present in your system.
9
Lights in any of the repeat play modes.
10 REMAIN
Indicates that the character display is showing
the disc or title/chapter/track remain time.
11 Character display
12
Lights during multi-angle scenes on a DVD
disc.
13  and 
Indicates whether a disc is playing or paused.
14 DTS
Lights when a DTS soundtrack is playing.
15 D
Lights when a Dolby Digital soundtrack is
playing.
1415 1113 12
2 43 5 5 6 7 8 9 10
1
DV575A KU_Mid.book 17 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Getting started
04
19
En
Chapter 4
Getting started
Switching on
After making sure that everything is connected
properly and that the player is plugged in,
press
 STANDBY/ON on the front panel or
remote control to switch the player on.
Also, switch on your TV and make sure that it is
set to the input you connected the DVD player
to.
FAQ
• My DVD player switches on but there is
nothing displayed on my TV.
Make sure that the TV is set to the correct
video input (not a TV channel). For
example, if you connected this player to the
VIDEO 1 inputs on your TV, switch your TV
to
VIDEO 1 .
Note
•This player features a screen saver and an
auto power off function. If the player is
stopped and no button is pressed for
around five minutes, the screen saver
starts. If the disc tray is closed but no disc
is playing and no control is pressed for
about 30 minutes, the player automatically
goes into standby.
Using the on-screen displays
For ease of use, this player makes extensive
use of graphical on-screen displays (OSDs).
All the screens are navigated in basically the
same way, using the cursor buttons (
) to change the highlighted item and
pressing
ENTER to select it.
FL DIMMER
STANDBY/ON
DV-575A / DV-676A-S
STANDBY/ON
Button What it does
HOME
MENU
Display/exit the on-screen display.
Changes the highlighted menu
item.
ENTER
Selects the highlighted menu
item (both
ENTER buttons on the
remote work in exactly the same
way).
RETURN Returns to the main menu
without saving changes.
 


DV-578A
DV575A KU_Mid.book 19 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Getting started
04
21
En
1 If the player isn’t already on, press
 STANDBY/ON to switch it on.
If you’re playing a DVD or Video CD/Super VCD,
also turn on your TV and make sure that it is set
to the correct video input.
2 Press  OPEN/CLOSE to open the disc
tray.
3 Load a disc.
Load a disc with the label side facing up, using
the disc tray guide to align the disc (if you’re
loading a double-sided DVD disc, load it with
the side you want to play face down).
4 Press  (play) to start playback.
If you’re playing a DVD or Video CD/Super VCD,
an on-screen menu may appear. See
DVD disc
menus
on page 22 and Video CD/Super VCD
PBC menus
on page 23 for more on how to
navigate these.
•If you’re playing an MP3/WMA disc, it may
take a few seconds before playback starts.
Note
• You may find with some DVD discs that
some playback controls don’t work in
certain parts of the disc. This is not a
malfunction.
Basic playback controls
The table below shows the basic controls on
the remote for playing discs. The following
chapter covers other playback features in more
detail.


/ /






Button What it does
 Starts playback.
If the display shows RESUME or
LAST MEM playback starts from
the resume or last memory point
(see also Resume and Last Memory
on page 22.)
 Pauses a disc that’s playing, or
restarts a paused disc.
 Stops playback.
See also Resume and Last Memory
on page 22.

(remote
only)
Press to start fast reverse scanning.
Press
 (play) to resume normal
playback.

(remote
only)
Press to start fast forward scanning.
Press  (play) to resume normal
playback.
DV575A KU_Mid.book 21 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Getting started
04
23
En
Video CD/Super VCD PBC menus
Some Video CD/Super VCDs have menus from
which you can choose what you want to watch.
These are called PBC (Playback control)
menus.
You can play a PBC Video CD/Super VCD
without having to navigate the PBC menu by
starting playback using a number button to
select a track, rather than the
 (play) button.
Button What it does
TOP MENU Displays the ‘top menu’ of a DVD
disc—this varies with the disc.
MENU Displays a DVD disc menu—this
varies with the disc and may be
the same as the ‘top menu’.
Moves the cursor around the
screen.
ENTER Selects the current menu option.
RETURN Returns to the previously dis-
played menu screen. On some
DVD-Audio discs featuring
browsable pictures, press to dis-
play the browser screen.
Numbers
(remote
only)
Highlights a numbered menu
option (some discs only). Press
ENTER to select.
Button What it does
RETURN Displays the PBC menu.
Numbers
(remote
only)
Use to enter a numbered menu
option. Press
ENTER
to select.
 Displays the previous menu page
(if there is one).
 Displays the next menu page (if
there is one).

DV575A KU_Mid.book 23 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Playing discs
05
25
En
Chapter 5
Playing discs
Note
• Many of the functions covered in this
chapter apply to DVD and SACD discs,
Video CDs/Super VCDs, CDs and WMA/
MP3 JPEG discs, although the exact
operation of some varies slightly with the
kind of disc loaded.
• Some DVDs restrict the use of some
functions (random or repeat, for example)
in some or all parts of the disc. This is not a
malfunction.
•When playing Video CD/Super VCDs, some
of the functions are not available during
PBC playback. If you want to use them,
start the disc playing using a number
button to select a track.
Scanning discs
You can fast-scan discs forward or backward at
four different speeds.
1 During playback, press  or  to
start scanning.
• There is no sound while scanning DVDs
(including DVD-Audio) and Video CD/
Super VCDs.
2 Press repeatedly to increase the
scanning speed.
• The scanning speed is shown on-screen.
3 To resume normal playback, press 
(play).
• When scanning a Video CD/Super VCD
playing in PBC mode or a WMA/MP3 track,
playback automatically resumes at the end
or beginning of the track.
• Depending on the disc, normal playback
may automatically resume when a new
chapter is reached on a DVD disc.
Playing in slow motion
You can play DVD-Videos and DVD-R/RW at
four different slow motion speeds, forwards
and backwards. Video CD/Super VCDs can be
played at four different forward slow motion
speeds.
1 During playback, press  (pause).
2 Press and hold
/ or / until
slow motion playback starts.
• The slow motion speed is shown on-
screen.
• There is no sound during slow motion
playback.
3 Press repeatedly to change the slow
motion speed.
4 To resume normal playback, press

(play).
• Depending on the disc, normal playback
may automatically resume when a new
chapter is reached.
Frame advance/frame reverse
You can advance or back up DVD-Video and
DVD-R/RW discs frame-by-frame. With Video
CD/Super VCDs you can only use frame
advance.
DV575A KU_Mid.book 25 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Playing discs
05
27
En
• Title – Titles from a DVD-Video disc.
•
Chapter – Chapters from the current title
of a DVD-Video disc.
•
Track – Tracks from a Video CD/Super VCD
disc.
•
Time – Thumbnails from a Video CD/Super
VCD disc at 10 minute intervals.
•
Original: Title – Original titles from a VR
mode DVD-RW disc.
•
Playlist: Title – Playlist titles from a VR
mode DVD-RW disc.
•
Original: Time – Thumbnails from the
Original content at 10 minute intervals.
•
Playlist: Time – Thumbnails from the
Playlist at 10 minute intervals.
The screen shows up to six moving thumbnail
images displayed one after another. To display
the previous/next six thumbnails, press
 /
 (you don’t have to wait for all the
thumbnails to finish playing to display the
previous/next page).
3 Select the thumbnail image for what
you want to play.
You can use either the cursor buttons (
) and ENTER to select a thumbnail, or the
number buttons.
To select using the number buttons, enter a
two-digit number then press
ENTER .
Tip
•Another way to find a particular place on a
disc is to use one of the search modes. See
Searching a disc on page 31.
Browsing WMA, MP3 and JPEG
files with the Disc Navigator
Use the Disc Navigator to find a particular file
or folder by filename.
1 Press HOME MENU and select ‘Disc
Navigator’ from the on-screen menu.
2 Use the cursor buttons (
)
and ENTER to navigate.
Use the cursor up/down buttons ( ) to
move up and down the folder/file list.
Use the cursor left button (
) to return to the
parent folder.
Use
ENTER or cursor right ( ) to open a
highlighted folder.
•You can also return to the parent folder by
going to the top of the list to the ‘
.. ’ folder,
then pressing
ENTER .
01
04
02
05
03
06
Disc Navigator: Title
01- 49: --
00:00/ 00:00 0kbps
Folder1
Folder2
Folder3
Folder4
DV575A KU_Mid.book 27 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Playing discs
05
29
En
1During playback, press PLAY MODE and
select ‘Repeat’ from the list of functions on
the left.
2 Select a repeat play option.
If program play is active, select Program
Repeat
to repeat the program list, or Repeat
Off
to cancel.
The repeat options available depend on the
kind of disc loaded. For example, for DVD-
Video and DVD-RW discs, you can select
Title
Repeat
or Chapter Repeat (or Repeat Off ).
• For DVD-Audio discs, select
Group
Repeat
or Track Repeat (or Repeat Off ).
•For SACDs,CDs and Video CD/Super
VCDs, select
Disc Repeat or Track Repeat
(or
Repeat Off ).
Using random play
Use the random play function to play titles or
chapters (DVD-Video), Groups (DVD-Audio), or
tracks (DVD-Audio, SACD, CD, Video CD/
Super VCD) at random. (Note that the same
track/title/chapter may play more than once.)
You can set the random play option when a
disc is playing or stopped.
Important
• Random play remains in effect until you
select
Random Off from the random play
menu options.
•You can’t use random play with VR format
DVD-RW discs, Video CD/Super VCDs
playing in PBC mode, WMA/MP3 discs, or
while a DVD disc menu is being displayed.
• You can't use random play together with
program or repeat play.
1 Press PLAY MODE and select ‘Random’
from the list of functions on the left.
2 Select a random play option.
The random play options available depend on
the kind of disc loaded. For example, for DVD-
Video discs, you can select
Random Title or
Random Chapter , (or Random Off ).
• For DVD-Audio discs, select
Random
Group
or Random Track , (or Random
Off
).
•For CDs, SACDs and Video CD/Super
VCDs, select
On or Off to switch random
play on or off.
DV575A KU_Mid.book 29 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Playing discs
05
31
En
Tip
•Use the following controls during program
play:
Other functions available from the
program menu
There are a number of other options in the
program menu in addition to Create/Edit.
•
Playback Start – Starts playback of a
saved program list
•
Playback Stop – Turns off program play,
but does not erase the program list
•
Program Delete – Erases the program list
and turns off program play
Searching a disc
You can search DVD-Video discs by title or
chapter number, or by time; DVD-Audio discs
can be searched by group or track number;
SACDs by track number, CDs and Video CD/
Super VCDs by track number or time.
Important
• Search functions are not available with
Video CD/Super VCDs in PBC mode, or
with WMA/MP3 discs.
1 Press PLAY MODE and select ‘Search
Mode’ from the list of functions on the left.
2 Select a search mode.
The search options available depend on the
kind of disc loaded.
• The disc must be playing in order to use
time search.
3Use the number buttons to enter a title,
chapter or track number, or a time.
• For a time search, enter the number of
minutes and seconds into the currently
playing title (DVD) or track (CD/Video CD/
Super VCD) you want playback to resume
from. For example, press
4 , 5 , 0 , 0 to have
playback start from 45 minutes into the
disc. For 1 hour, 20 minutes and 30
seconds, press
8 , 0 , 3 , 0 .
• Some DVD-Audio discs feature pages of
browsable pictures. Enter the page
number you want.
4 Press ENTER to start playback.
Switching subtitles
Some DVD-Video discs have subtitles in one or
more languages; the disc box will usually tell
you which subtitle languages are available. You
can switch subtitle language during playback.
1 Press SUBTITLE repeatedly to select a
subtitle option.
Button What it does
PLAY
MODE
Save the program list and exit
the program edit screen without
starting playback ( HOME MENU
does the same).
 Skip to the next step in the
program list.
DV575A KU_Mid.book 31 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Audio Settings and Video Adjust menus
06
33
En
Chapter 6
Audio Settings and Video
Adjust menus
Audio Settings menu
The Audio Settings menu offers features for
adjusting the way discs sound.
1 Press HOME MENU and select ‘Audio
Settings’ from the on-screen display.
2Select and change settings using the
(cursor) buttons, and ENTER.
Audio DRC
• Settings: High , Medium , Low , Off
(default)
When watching Dolby Digital DVDs at low
volume, it’s easy to lose the quieter sounds
completely—including some of the dialog.
Switching Audio DRC (Dynamic Range
Control) to on can help by bringing up the
quieter sounds, while controlling loud peaks.
How much of a difference you hear depends on
the material you’re listening to. If the material
doesn’t have wide variations in volume, you
may not notice much change.
Note
• Audio DRC is only effective with Dolby
Digital audio sources.
• Audio DRC is only effective through the
digital output when
Digital Out is set to
On , and Dolby Digital Out is set to Dolby
Digital > PCM
(see Digital Audio Out
settings
on page 35).
• The effect of Audio DRC also depends on
your speakers and AV receiver settings.
Virtual Surround
• Settings: On , Off (default)
Switch on Virtual Surround to enjoy realistic
surround sound effects from just two speakers.
Tip
• You can also use the SURROUND button
on the remote control to switch Virtual
Surround on.
Note
• 96kHz Linear PCM audio is automatically
downsampled to 48kHz if Virtual Surround
is switched on.
• The
Audio Output Mode (see page 41)
must be set to
2 Channel in order to be
able to use Virtual Surround.
DV575A KU_Mid.book 33 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
35
En
Chapter 7
Initial Settings menu
Using the Initial Settings menu
The Initial Settings menu provides audio and
video output settings, parental lock settings,
and display settings, among others.
If an option is grayed out it means that it
cannot be changed at the current time. This is
usually because a disc is playing. Stop the
disc, then change the setting.
1 Press HOME MENU and select ‘Initial
Settings’.
2 Use the cursor buttons and ENTER to
select the setting and option you want to
set.
All the settings and options are explained on
the following pages.
Note
• In the table below, the default setting is
shown in
bold : other settings are shown in
italics .
•The Digital Audio Out settings only need to
be set if you have connected the digital
output of this player to an AV receiver, or
other equipment.
• Check the operating instructions supplied
with your other equipment to see which
digital audio formats it’s compatible with.
•Some settings, such as
TV Screen , Audio
Language
and Subtitle Language may be
overridden by the DVD disc. Often these
settings can also be made from the DVD
disc menu.
Digital Audio Out settings
Setting Option What it means
Digital Out On
Digital audio is output from the digital outputs.
Note that there is no digital output when playing SACDs and
some DVD-Audio discs regardless of this setting.
Off
No digital audio output.
Dolby Digital Out Dolby Digital
Dolby Digital encoded digital audio is output when playing a
Dolby Digital DVD disc.
Dolby Digital > PCM
Dolby Digital audio is converted to PCM audio before being
output.
DTS Out DTS
DTS encoded digital audio is output when playing a DTS disc.
(Noise will be output if your amplifier/receiver is not compatible
with DTS audio.)
DTS > PCM
DTS audio is converted to PCM audio before being output.
DV575A KU_Mid.book 35 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
37
En
Display settings
Options settings
Subtitle Language English
If there is are English subtitles on the disc then they will be
displayed.
Languages as displayed
If there is the subtitle language selected on the disc, then it will
be displayed.
Other Language
Select to choose a language other than the ones displayed (see
page 47).
DVD Menu Lan-
guage
w/Subtitle Lang.
DVD disc menus will be displayed in the same language as
your selected subtitle language, if possible.
Languages as displayed
DVD disc menus will be displayed in the selected language, if
possible.
Other Language
Select to choose a language other than the ones displayed (see
page 47).
Subtitle Display On
Subtitles are displayed according to your selected subtitle
language (see above).
Off
Subtitles are always off by default when you play a DVD disc
(note that some discs override this setting).
Setting Option What it means
Setting Option What it means
OSD Language English
On-screen displays of the player are in English.
Languages as displayed
On-screen displays are shown in the language selected.
Angle Indicator On
A camera icon is displayed on-screen during multi-angle
scenes on a DVD disc.
Off
No multi-angle indication is shown.
Setting Option What it means
Parental Lock –
See Parental Lock on page 40.
DVD Playback
Mode
DVD-Audio
All material on a DVD-Audio disc is playable.
DVD-Video
Only the DVD-Video part of a DVD-Audio disc is playable.
DV575A KU_Mid.book 37 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
39
En
About the audio output settings
The table below shows how the audio settings you make in the Initial Settings menu (see page 35)
affect the output from the 2 channel and the 5.1 channel analog outputs, and from the digital
outputs with various types of disc.
*
1
When Audio Output Mode is set to 2 Channel , the AUDIO OUT (5.1ch) FRONT L / R jacks act as a second pair
of stereo audio outputs.
*
2
Dolby Digital > PCM , MPEG > PCM or DTS > PCM setting (pages 35–36)
*
3
Dolby Digital , MPEG or DTS setting (pages 35–36)
*
4
Discs that prohibit downmixing will be output as 5.1 channel even if 2 Channel is selected as the Audio Output
Mode setting (see page 41).
*
5
Discs that prohibit downmixing also mute the digital output.
*
6
When Audio Output Mode is set to 5.1 Channel , mono sources are heard from the center speaker only.
Disc audio format Player setting
Front L / R
–
–
–
–
–
–
–
–
–
–
–
––
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
–
Front L / R
Front L / R
Front L / R
Left / Right Left / Right
Left / Right Left / Right
Left / Right
*6
Left / Right
Left / Right
Left / Right
Left / Right
Left / Right
2ch downmix
2ch downmix
2ch downmix
*4
2ch downmix
2ch downmix
Front L / R
2ch downmix
Front L / R
2ch downmix
2 Ch
5.1 Ch
2 Ch
5.1 Ch
Front L/R
analog outputs
*1
Surround L/R
Center, LFE, outputs
*1
Digital outputs
PCM convert
*2
Bitstream
*3
Dolby Digital
Dolby Digital
karaoke
2 Ch / 5.1 Ch
2 Ch / 5.1 Ch
2 Ch / 5.1 Ch
2 Ch / 5.1 Ch
2 Ch / 5.1 Ch
Linear PCM
2 Ch
5.1 Ch
DTS
MPEG
2 Ch
5.1 Ch
DVD-Audio
2 Ch
5.1 Ch
Super Audio CD
2 Ch
5.1 Ch
DTS CD
CD
Video CD
DVD-RW
(VR mode)
DVD
Dolby Digital
–
2ch downmix
2ch downmix
*5
2ch downmix
*5
DTS
DTS
Dolby Digital
Left / Right
Left / Right Left / Right
Left / Right Left / Right
Dolby Digital
MPEG or PCM
MPEG
DV575A KU_Mid.book 39 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
41
En
The new Country code is set and you will return
to the Options menu screen. Note that the new
Country code doesn’t take effect until the next
disc is loaded (or the current disc is reloaded).
DTS Downmix
• Default setting: Stereo
If you’ve selected DTS > PCM in DTS Out on
page 35 or
2 Channel in Audio Output Mode on
page 41, you can choose the way the signal is
downmixed to PCM audio.
Stereo will
downmix the DTS signal to 2-channel stereo,
whereas
Lt/Rt will downmix to a 2-channel
signal compatible with Dolby surround matrix
decoders. (This allows you to hear surround
sound if your AV receiver or amplifier has Dolby
Pro Logic capability.)
Audio Output Mode
• Default setting: 2 Channel
If you connected this player to your amplifier
using the 5.1 channel analog outputs (front,
surround, center and subwoofer outs), set this
to
5.1 Channel ; if you connected only the
stereo outs, set to
2 Channel .
Note
•Even if you set Audio Output Mode to 5.1
Channel
, you’ll only get sound from all
speakers when playing a 5.1 channel multi-
channel disc.
• When set to
5.1 Channel , only the front
left/right channels are output from the
AUDIO OUT (2ch) jacks. Change to 2
Channel
if you want to listen to downmixed
stereo audio (for example, because you are
listening through the TV’s built-in
speakers).
•When set to
5.1 Channel there is no digital
output when playing DVD-Audio.
•If you set to
2 Channel , Dolby Digital, DTS
and MPEG audio is mixed down to two
channels so you still hear all the audio
recorded on the disc. With DTS encoded
audio, you can choose how the signal is
downmixed to PCM audio. See
DTS
Downmix
above to change the downmix
setting.
• Some DVD-Audio discs don’t allow down-
mixing of audio. These discs always output
multi-channel audio regardless of the
setting made here.
DV575A KU_Mid.book 41 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
43
En
1Use the (cursor up/down) to select
a speaker.
• The L and R speakers are paired; you can’t
set them differently.
2 Press (cursor right) to change the
speaker distance for the highlighted
speaker.
3 Use the
(cursor up/down) to
change the distance.
•When you change the distance settings of
the front left (
L ) or front right ( R ) speakers,
all the other speaker distances change
relative to it.
•Front left/right (
L / R ) speaker distances can
be set from 1 ft. (30 cm) to 30 ft. (9 m) in 1
ft. (30 cm ) increments.
• The center speaker (
C ) can be set from –7
ft. (2.1 m) to 0 ft. (0 m) relative to the front
left/right speakers.
• Surround left/right (
LS / RS ) speakers can
be set from –20 ft. (6.0 m) to 0 ft. (0 m) rela-
tive to the front left/right speakers.
•You can’t set the subwoofer (
SW ) distance.
4 Press (cursor left) to go back to the
speaker list if you want to modify another
speaker, or press ENTER to exit the Speaker
Distance screen.
Note
•During playback of SACD and MPEG-audio
DVD-Video discs, the effective
C , LS and RS
speaker distance settings are –3.0ft (–
0.9m) to 0.0ft (0.0m) relative to the front
left/right speakers.
DV-575A/DV-578A screen
DV-676A-S screen
DV575A KU_Mid.book 43 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
45
En
If you use a chemical-impregnated cleaning
cloth, read the instructions carefully before
use. These cloths may leave smear marks on
half-mirror finish surfaces; if this happens,
finish with a dry cloth.
Cleaning the pickup lens
The DVD player’s lens should not become dirty
in normal use, but if for some reason it should
malfunction due to dust or dirt, consult your
nearest Pioneer-authorized service center. We
do not recommend using commercially
available lens cleaners for CD players.
Condensation
Condensation may form inside the player if it is
brought into a warm room from outside, or if
the temperature of the room rises quickly.
Although the condensation won’t damage the
player, it may temporarily impair its
performance. Leave it to adjust to the warmer
temperature for about an hour before
switching on.
Moving the player
If you need to move the player, first press
 STANDBY/ON on the front panel to turn the
player off. Wait for
-OFF- to disappear from the
display, then unplug the power cable. Never lift
or move the unit during playback—discs rotate
at a high speed and may be damaged.
Screen sizes and disc formats
DVD-Video discs come in several different
screen aspect ratios, ranging from TV
programs, which are generally 4:3, to
CinemaScope widescreen movies, with an
aspect ratio of up to about 7:3.
Televisions, too, come in different aspect
ratios; ‘standard’ 4:3 and widescreen 16:9.
Widescreen TV users
If you have a widescreen TV, the TV Screen
setting (page 36) of this player should be set to
16:9 (Wide) .
When you watch discs recorded in 4:3 format,
you can use the TV controls to select how the
picture is presented. Your TV may offer various
zoom and stretch options; see the instructions
that came with your TV for details.
Please note that some movie aspect ratios are
wider than 16:9, so even though you have a
widescreen TV, these discs will still play in a
‘letter box’ style with black bars at the top and
bottom of the screen.
Standard TV users
If you have a standard TV, the TV Screen
setting (page 36) of this player should be set to
4:3 (Letter Box) or 4:3 (Pan&Scan) ,
depending on which you prefer.
Set to
4:3 (Letter Box) , widescreen discs are
shown with black bars top and bottom.
Set to
4:3 (Pan&Scan) , widescreen discs are
shown with the left and right sides cropped.
Although the picture looks larger, you don’t
actually see the whole picture.
Please note that many widescreen discs
override the player’s settings so that the disc is
shown in letter box format regardless of the
setting.
DV575A KU_Mid.book 45 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
47
En
DVD-Video regions
All DVD-Video discs carry a region mark on the
case somewhere that indicates which
region(s) of the world the disc is compatible
with. Your DVD player also has a region mark,
which you can find on the rear panel. Discs
from incompatible regions will not play in this
player. Discs marked
ALL will play in any
player.
The diagram below shows the various DVD
regions of the world.
Selecting languages using the
language code list
Some of the language options (such as ‘DVD
Language’ in the Setup Navigator) allow you to
set your prefered language from any of the 136
languages listed in the language code list on
page 48.
1 Select ‘Other Language’.
2Use the
(cursor left/right) buttons
to select either a code letter or a code
number.
3Use the
(cursor up/down) buttons
to select a code letter or a code number.
See Language code list on page 48 for a
complete list of languages and codes.
1
2
2
5
5
6
3
21
4
4
DV575A KU_Mid.book 47 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
49
En
Troubleshooting
Incorrect operation is often mistaken for trouble or malfunction. If you think that there is
something wrong with this component, check the points below. Sometimes the trouble may lie in
another component. Inspect the other components and electrical appliances being used. If the
trouble cannot be rectified after checking the items below, ask your nearest Pioneer authorized
service center or your dealer to carry out repair work.
Problem Remedy
The disc won’t play or is
automatically ejected
after loading.
• Make sure the disc is free from dirt and dust and is not damaged
(page 44).
• Make sure the disc is loaded with the label side face-up and aligned
properly in the disc tray guide.
• Incompatible region number: If the region number on a DVD-Video
disc does not match the number on the player, the disc cannot be
used (page 47).
• Condensation inside the player: Allow time for condensation to
evaporate. Avoid using the player near an air-conditioning unit.
• Disc is loaded upside down: Reload the disc with the label side face
up.
• A Super VCD that does not conform with the IEC standards might
not play normally.
DVD-Audio playback
stops.
• The disc may have been illegally copied.
Picture playback stops
and the operation
buttons cannot be used.
• Press  , then start playback again (  ).
• Press and hold the front panel  STANDBY/ON button for about 10
seconds to switch the unit off, then press again to switch back on.
• Switch the power off once, unplug from the wall socket, then plug
back in and switch on again using the front panel  STANDBY/ON
button.
New settings made in the
Setup screen menus while
a disc is playing are
ineffective.
• Some settings can be changed while a disc is playing, but are not
effective until the disc is stopped then restarted: Press  , then start
playback again (  ).
Settings are canceled. • When the power is cut due to power failure or by unplugging the
power cord, settings will be canceled: Press  STANDBY/ON on the
front panel to turn the player off. Wait for --OFF-- to disappear from
the display, then unplug the power cord.
The remote control
doesn't seem to work.
• The remote control is too far from the player, or the angle with the
remote sensor is too wide: Use the remote within its operating range
(page 18).
• The batteries are exhausted: Put in new ones (page 8).
DV575A KU_Mid.book 49 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
51
En
Cannot play multi-
channel audio
• Make sure that Audio Output Mode is set to 5.1 Channel
(page 41).
• Check that the Dolby Digital, DTS and MPEG Out settings
(pages 35–36) are suitable for your amplifier/receiver—check the
instruction manual that came with your amplifier/receiver.
• DVD-Audio and SACDs do not output multichannel digital audio.
Listen through the player’s analog outputs.
• Check that the settings in the Speaker Installation screen are
correct (page 42).
• Check the audio options available from the disc menu.
Cannot listen to high-
sampling rate audio
through the digital
output.
• Make sure that Linear PCM Out is set to Downsample Off
(page 35).
• As a copy-protection measure, some DVDs do not output 96kHz
audio. In this case, even if set to Downsample Off , the player
automatically outputs the audio at 48 kHz. This is not a malfunction.
Cannot output 192kHz or
176.4kHz digital audio.
• The player does not output digital audio at these sampling rates. The
digital output is automatically downsampled.
Cannot output 96kHz or
88.2kHz digital audio.
• Check that Linear PCM Out is set to Downsample Off (page 35).
• Some discs are digital copy protected and do not output high
sampling rate digital audio. In this case the output is automatically
downsampled.
No DTS audio output. • If this unit is connected to a non-DTS compatible amplifier or
decoder using a digital audio cable, set DTS Out to DTS
>
PCM
(page 35). If you do not do this, noise will be output when you play a
DTS disc.
• If this unit is connected to a DTS-compatible amplifier or decoder
using a digital audio cable, check the amplifier settings, and that the
cable is properly connected.
Audio mix does not
sound right or sounds
incomplete (for example,
inaudible dialog).
• Make sure that Audio Output Mode is set to 2 Channel if you've
connected to the stereo inputs on your amplifier or TV (page 41).
The audio recorded on a
Super VCD disc is not
output properly.
• If the audio is switched to [2] when playing a Super VCD that
contains only one stereo soundtrack, there may be no sound at all.
Press AUDIO to change the soundtrack.
Can’t hear effect of
Virtual Surround
• Virtual Surround does not work with SACD or DVD-Audio.
• The Virtual Surround effect is only output through the AUDIO OUT
(2ch) analog audio outputs.
• Make sure that Audio Output Mode is set to 2 Channel (page 41).
• The effectiveness of Virtual Surround varies with the disc.
Problem Remedy
DV575A KU_Mid.book 51 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
53
En
Glossary
Analog audio Direct representation of sound by an
electrical signal. See also Digital audio .
Aspect ratio The width of a TV screen relative to its
height. Conventional TVs are 4:3;
widescreen models are 16:9.
Bonus Group
(DVD-Audio
only)
An ‘extra’ group on some DVD-Audio
discs that requires a key number to
access.
Browsable
pictures
(DVD-Audio
only)
A feature of some DVD-Audio discs in
which the user can browse still pictures
recorded on the disc as the audio is
played. See also Slideshow .
Digital audio Indirect representation of sound using
numbers. See also Sampling frequency
and Analog audio .
Dolby
Digital
*1
A multi-channel audio encoding system
developed by Dolby Laboratories that
enables far more audio to be stored on a
disc than PCM encoding. See also PCM
(Pulse Code Modulation) .
DRM DRM (Digital Rights Management) copy
protection is a technology designed to
prevent unauthorized copying by
restricting playback, etc. of material on
devices other the PC (or other WMA
recording equipment) used to record it.
For detailed information, please see the
instruction manuals or help files that
came with your PC (or other WMA
recording equipment) and/or software.
DTS
*2
A multi-channel audio encoding system
developed by Digital Theater Systems
that enables far more audio to be stored
on a disc than PCM encoding. See also
PCM (Pulse Code Modulation) .
EXIF
(Exchangeabl
e Image File)
A file format developed by Fuji Photo
Film for digital still cameras. Digital
cameras from various manuafcturers
use this compressed file format which
carries date, time and thumbnail
information, as well as the picture data.
File
extension
A tag added to the end of a filename to
indicate the type of file. For example,
“.mp3” indicates an MP3 file.
ISO 9660
format
International standard for the volume
and file structure of CD-ROM discs.
JPEG A standard file format used for still
images. JPEG files are identified by the
file extension “.jpg”.
MP3 MP3 (MPEG1 audio layer 3) is a
compressed stereo audio file format.
Files are recognized by their file
extension “.mp3”.
MPEG audio An audio format used on Video CD/
Super VCDs and some DVD discs.
Packed PCM
(DVD-Audio
only)
A lossless compression system that
enables more PCM audio to be stored
on a DVD-Audio disc than would
otherwise be possible.
PBC
(PlayBack
Control)
A system of navigating a Video CD/
Super VCD through on-screen menus
recorded onto the disc.
PCM
(Pulse Code
Modulation)
Digital audio encoding system found on
CDs. Good quality, but requires a lot of
data compared to Dolby Digital, DTS
and MPEG encoded audio. See also
Digital audio .
Progressive
scan video
All the lines that make up a video
picture are updated in one pass
(compared to interlace which takes two
passes to update the whole picture).
Regions
(DVD-Video
only)
These associate DVD-Video discs and
players with particular areas of the
world. See DVD-Video regions on
page 47 for more information.
Sampling
frequency
The rate at which sound is measured to
be turned into digital audio data. The
higher the rate, the better the sound
quality. CD is 44.1 kHz; DVD can be up
to 96 kHz. See also Digital audio .
DV575A KU_Mid.book 53 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
55
En
Specifications
General
System . . . . . . . . . . . . . . . . . . . . . . . . DVD player
Power requirements
DV-575A / DV-578A . . . . . . . . . . .AC 120 V, 60 Hz
DV-676A-S
. . . . . . AC 110–127/220–240 V, 50/60 Hz
Power consumption
DV-575A / DV-578A . . . . . . . . . . . . . . . . . . . .11 W
DV-676A-S. . . . . . . . . . . . . . . . . . . . . . . . . . . .12 W
Power consumption (standby)
DV-575A / DV-578A . . . . . . . . . . . . . . . . . . 0.07 W
DV-676A-S. . . . . . . . . . . . . . . . . . . . . . . . . . 0.12 W
Weight . . . . . . . . . . . . . . . . . . . 2.1 kg / 4 lb 10 oz
Dimensions . .420 (W) x 55 (H) x 243 (D) mm
. . . . . . . . . . . . . . . (16.5 (W) x 2.2 (H) x 9.6 (D) in.)
Operating temperature . . . . . . . +5°C to +35°C
(+41°F to +95°F)
Operating humidity . . . . . . . . . . . . . . . 5% to 85%
(no condensation)
Component video output
Y (luminance) - Output level . . . . . . 1 Vp-p (75 )
P
B
(color) - Output level . . . . . . . 0.7 Vp-p (75 )
P
R
(color) - Output level . . . . . . . 0.7 Vp-p (75 )
Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA
S-video output
Y (luminance) - Output level . . . . . . 1 Vp-p (75 )
C (color) - Output level . . . . . . 286 mVp-p (75 )
Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .S-video
Video output
Output level . . . . . . . . . . . . . . . . . . . 1 Vp-p (75 )
Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA
Audio output (1 stereo pair)
Output level . . . . . . . . . . . . .During audio output
200 mVrms (1 kHz, –20 dB)
Number of channels . . . . . . . . . . . . . . . . . . . . . . 2
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA
Audio output (multi-channel / L, R, C, SW,
LS, RS)
Output level. . . . . . . . . . . . . During audio output
200 mVrms (1 kHz, –20 dB)
Number of channels . . . . . . . . . . . . . . . . . . . . . 6
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . .RCA jack
Digital audio characteristics
Frequency response . . . . . . . . . . 4 Hz to 44 kHz
(DVD fs: 96 kHz)
4 Hz to 88 kHz (DVD-Audio fs: 192 kHz)
S/N ratio . . . . . . . . . . . . . . . . . . . . . . . . . . .115 dB
Dynamic range . . . . . . . . . . . . . . . . . . . . . .101 dB
Total harmonic distortion. . . . . . . . . . . . 0.0020 %
Wow and flutter . . . . . . . .Limit of measurement
(±0.001% W. PEAK) or lower
Digital output
Coaxial digital output jack . . . . . . . . . . .RCAjack
Optical digital output . . . . . . .Optical digital jack
Accessories
Audio/video cable. . . . . . . . . . . . . . . . . . . . . . . . 1
Power cable
DV-676A-S (Singapore/Taiwan model) . . . . . . 2
Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . 1
AA/R6P dry cell batteries . . . . . . . . . . . . . . . . . 2
Operating Instructions
Warranty card (
U.S. model only
).. . . . . . . . . . 1
Front panel button names sticker
(Singapore/Taiwan models only)
. . . . . . . . . . 1
Remote control overlay
(Singapore/Taiwan models only)
. . . . . . . . . . 1
The specifications and design of this product are subject to
change without notice, due to improvement.
Published by Pioneer Corporation.
Copyright © 2004 Pioneer Corporation.
All rights reserved
DV575A KU_Mid.book 55 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals

Before you start01
8
En
What’s in the box
Please confirm that the following accessories
are in the box when you open it.
• Remote control
• AA/R6P dry cell batteries x2
• Audio/video cable (red/white/yellow plugs)
• Power cable
• Operating instructions
• Warranty card (DV-575A and DV-578A
model only)
• Front panel button names sticker
(Singapore and Taiwan models only) —
Chinese language button names for the
front panel controls.
• Remote control overlay
(Singapore and
Taiwan models only)
— Place the overlay
on the remote control to be able to read the
buttons in Chinese.
Putting the batteries in the remote
• Open the battery compartment cover
and insert the batteries as shown.
Use two AA/R6P batteries and follow the
indications (
, ) inside the compartment.
Close the cover when you’re finished.
Important
Incorrect use of batteries can result in hazards
such as leakage and bursting. Please observe
the following:
• Don’t mix new and old batteries together.
• Don’t use different kinds of battery
together—although they may look similar,
different batteries may have different
voltages.
•Make sure that the plus and minus ends of
each battery match the indications in the
battery compartment.
• Remove batteries from equipment that
isn’t going to be used for a month or more.
• When disposing of used batteries, please
comply with governmental regulations or
environmental public instruction’s rules
that apply in your country or area.
Hints on installation
We want you to enjoy using this product for
years to come, so please use the following
guidelines when choosing a suitable location:
Do...
• Use in a well-ventilated room.
•Place on a solid, flat, level surface, such as
a table, shelf or stereo rack.
Don’t...
• Use in a place exposed to high
temperatures or humidity, including near
radiators and other heat-generating
appliances.
•Place on a window sill or a place where the
player will be exposed to direct sunlight.
• Use in an excessively dusty or damp
environment.
• Place directly on top of an amplifier, or
other component in your stereo system
that becomes hot in use.
•Use near a television or monitor as you may
experience interference—especially if the
television uses an indoor antenna.
• Use in a kitchen or other room where the
player may be exposed to smoke or steam.
• Use on a thick rug or carpet, or cover with
cloth—this may prevent proper cooling of
the unit.
DV575A KU_Mid.book 8 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
10
En
About WMA
The Windows Media
®
logo printed on the box
indicates that this player can playback
Windows Media Audio content.
WMA is an acronym for Windows Media Audio
andrefers to an audiocompression technology
developed by Microsoft Corporation. WMA
content can be encoded by using Windows
Media
®
Player version 7, 7.1, Windows Media
®
Player for Windows
®
XP, or Windows Media
®
Player 9 Series.
Microsoft, Windows Media, and the Windows
logo are trademarks, or registered trademarks of
Microsoft Corporation in the United States and/
or other countries.
JPEG file compatibility
• Compatible formats: Baseline JPEG and
EXIF 2.2* still image files up to a resultion
of 3072 x 2048.
*
File format used by digital still cameras
• Progressive JPEG compatible: No
• File extensions: .jpg (must be used for the
player to recognize JPEG files – do not use
for other file types)
• File structure: Up to 299 folders; up to 648
folders and files combined
PC-created disc compatibility
Discs recorded using a personal computer
may not be playable in this unit due to the
setting of the application software used to
create the disc. In these particular instances,
check with the software publisher for more
detailed information.
Discs recorded in packet write mode (UDF
format) are not compatible with this player.
Check the DVD-R/RW or CD-R/RW software
disc boxes for additional compatibility
information.
DV575A KU_Mid.book 10 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals

Connecting up 02
11
En
Chapter 2
Connecting up
Easy connections
The setup described here is a basic setup that allows you to play discs using just the cables
supplied with the player. In this setup, stereo audio is played through the speakers in your TV.
Important
•This player is equipped with copy protection technology. Do not connect this player to your TV
via a VCR using audio/video or S-video cables, as the picture from this player will not appear
properly on your TV. (This player may also not be compatible with some combination TV/VCRs
for the same reason; refer to the manufacturer for more information.)
• When connecting to your TV as shown above, do not set the
Component Out setting (see
Video Output settings on page 36) to Progressive .
S
VIDEO OUT
AUDIO OUT (5.1 ch )
CENTER
COMPONENT VIDEO OUT
AUDIO OUT ( 2 ch )
FRONT
SURROUND
SUB
WOOFER
COAXIAL
OPTICAL
DIGITAL AUDIO OUT
VIDEO
OUT
PR
PB
Y
LL
R
R
AC IN
L
R
Yellow
White
Red
TV
A/V IN
To power
outlet
DV575A KU_Mid.book 11 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
13
En
Watching progressive scan video
from the component video outputs
This player can output progressive scan video
from the component video output. Compared
to interlace video, progressive scan video
effectively doubles the scanning rate of the
picture, resulting in a very stable, flicker-free
image.
To set up the player for use with a progressive
scan TV, see
Video Output settings on page 36.
When the player is set to output progressive
scan video, the
PRGSVE indicator lights in the
front panel display.
Important
• If you connect a TV that is not compatible
with a progressive scan signal and switch
the player to progressive, you will not be
able to see any picture at all. In this case,
switch everything off and reconnect using
the supplied video cable (see
Easy
connections
on page 11), then switch back
to
Interlace (see below).
Switching the video output to interlace
using the front panel controls
Switch the player to standby then, using the
front panel controls, press
STANDBY/ON
while pressing
to switch the player back to
Interlace .
Compatibility of this player with
progressive-scan and high-definition TVs
This player is compatible with progressive
video Macro Vision System Copy Guard.
Consumers should note that not all high-
definition television sets are fully compatible
with this product and may cause artifacts to be
displayed in the picture. In case of 525
progressive scan picture problems, it is
recommended that the user switch the
connection to the ‘standard definition’ output
(Interlace). If there are questions regarding our
TV set compatibility with this model, please
contact our customer service center.
This player is compatible with the following
Pioneer displays and monitors:
Plasma display (DV-575A, DV-578A )
PDP-505HD, PDP-5030HD, PDP-4330HD,
PDP-5040HD, PDP-4340HD, Pro-1000HD, Pro-
800HD, Pro-1000HDI, Pro-800HDI, Pro-
1110HD, Pro-910HD, PDP-4300, PDP-5031
Projection monitor receiver (DV-575A, DV-578A )
SD-533HD5, SD-643HD5, Pro-710HD, Pro-
610HD, Pro-510HD, Pro-720HD, Pro-620HD,
Pro-520HD, Pro-730HD, Pro-630HD, Pro-
530HD, Pro-730HDI, Pro-530HDI
Plasma display (DV-676A-S)
PDP-502MX, PDP-503HDG, PDP-433HDG,
PDP-5040HD, PDP-4340HD
Projection monitor receiver (DV-676A-S)
SD-532HD5, SD-533HD5
FL DIMMER OPEN/CLOSE
STANDBY/ON
DV-575A / DV-676A-S
STANDBY/ON
DV575A KU_Mid.book 13 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
15
En
Connecting the digital output
This player has both optical and coaxial-type
digital audio outputs for connection to an AV
receiver. Connect whichever is convenient.
Depending on the capabilities of your AV
receiver, you might have to set up this player to
output only digital audio in a compatible
format. See
Digital Audio Out settings on
page 35 and refer to the operating instructions
that came with your AV receiver.
•Connect one of the DIGITAL AUDIO OUT
jacks on this player to a digital input on
your AV receiver.
For an optical connection, use an optical cable
(not supplied) to connect the
OPTICAL
DIGITAL AUDIO OUT
jack to an optical input
on your AV receiver.
For a coaxial connection, use a coaxial cable
(similar to the supplied video cable) to connect
the
COAXIAL DIGITAL AUDIO OUT jack to a
coaxial input on your AV receiver.
S
VIDEO OUT
AUDIO OUT (5.1 ch )
CENTER
COMPONENT VIDEO OUT
AUDIO OUT ( 2 ch )
FRONT
SURROUND
SUB
WOOFER
COAXIAL
OPTICAL
DIGITAL AUDIO OUT
VIDEO
OUT
P R
P B
Y
LL
R
R
AV receiver
DIGITAL IN
(OPTICAL)
DIGITAL IN
(COAXIAL)
DV575A KU_Mid.book 15 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Controls and displays
03
17
En
Display
1 V-PART
Lights when playing a video part of a DVD disc.
2 PRGSVE
Lights when the player is set to output progres-
sive scan video (see
Component Out on
page 36 ).
3 GRP
Indicates that the character display is showing
a DVD-Audio group number.
4 TITLE
Indicates that the character display is showing
a DVD title number.
5 TRK
Indicates that the character display is showing
a DVD-Audio, SACD, CD or Video CD/Super
VCD track number.
6 CHP
Indicates that the character display is showing
a DVD chapter number.
7 5.1CH
Lights when analog 5.1 channel output is
selected (see
Audio Output Mode on page 41).
8 D.MIX
During multichannel audio playback, indicates
that the output signal has been “downmixed”
from the original audio source. This is an auto-
matic function performed by the player in order
to present the most appropriate audio mix to
the speakers present in your system.
9
Lights in any of the repeat play modes.
10 REMAIN
Indicates that the character display is showing
the disc or title/chapter/track remain time.
11 Character display
12
Lights during multi-angle scenes on a DVD
disc.
13 and
Indicates whether a disc is playing or paused.
14 DTS
Lights when a DTS soundtrack is playing.
15 D
Lights when a Dolby Digital soundtrack is
playing.
1415 1113 12
2 43 5 5 6 7 8 9 10
1
DV575A KU_Mid.book 17 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Getting started
04
19
En
Chapter 4
Getting started
Switching on
After making sure that everything is connected
properly and that the player is plugged in,
press
STANDBY/ON on the front panel or
remote control to switch the player on.
Also, switch on your TV and make sure that it is
set to the input you connected the DVD player
to.
FAQ
• My DVD player switches on but there is
nothing displayed on my TV.
Make sure that the TV is set to the correct
video input (not a TV channel). For
example, if you connected this player to the
VIDEO 1 inputs on your TV, switch your TV
to
VIDEO 1 .
Note
•This player features a screen saver and an
auto power off function. If the player is
stopped and no button is pressed for
around five minutes, the screen saver
starts. If the disc tray is closed but no disc
is playing and no control is pressed for
about 30 minutes, the player automatically
goes into standby.
Using the on-screen displays
For ease of use, this player makes extensive
use of graphical on-screen displays (OSDs).
All the screens are navigated in basically the
same way, using the cursor buttons (
) to change the highlighted item and
pressing
ENTER to select it.
FL DIMMER
STANDBY/ON
DV-575A / DV-676A-S
STANDBY/ON
Button What it does
HOME
MENU
Display/exit the on-screen display.
Changes the highlighted menu
item.
ENTER
Selects the highlighted menu
item (both
ENTER buttons on the
remote work in exactly the same
way).
RETURN Returns to the main menu
without saving changes.
ENTER
GUIDE RETURN
ENTER
HOME
MENU
RETURN
OPEN/CLOSE
TOP MENU MENU
HOME
MENU RETURN
ENTER
DV-578A
DV575A KU_Mid.book 19 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Getting started
04
21
En
1 If the player isn’t already on, press
STANDBY/ON to switch it on.
If you’re playing a DVD or Video CD/Super VCD,
also turn on your TV and make sure that it is set
to the correct video input.
2 Press OPEN/CLOSE to open the disc
tray.
3 Load a disc.
Load a disc with the label side facing up, using
the disc tray guide to align the disc (if you’re
loading a double-sided DVD disc, load it with
the side you want to play face down).
4 Press (play) to start playback.
If you’re playing a DVD or Video CD/Super VCD,
an on-screen menu may appear. See
DVD disc
menus
on page 22 and Video CD/Super VCD
PBC menus
on page 23 for more on how to
navigate these.
•If you’re playing an MP3/WMA disc, it may
take a few seconds before playback starts.
Note
• You may find with some DVD discs that
some playback controls don’t work in
certain parts of the disc. This is not a
malfunction.
Basic playback controls
The table below shows the basic controls on
the remote for playing discs. The following
chapter covers other playback features in more
detail.
0
123
456
789
STANDBY/ON
OPEN/CLOSE
ENTER
ENTER
Button What it does
Starts playback.
If the display shows RESUME or
LAST MEM playback starts from
the resume or last memory point
(see also Resume and Last Memory
on page 22.)
Pauses a disc that’s playing, or
restarts a paused disc.
Stops playback.
See also Resume and Last Memory
on page 22.
(remote
only)
Press to start fast reverse scanning.
Press
(play) to resume normal
playback.
(remote
only)
Press to start fast forward scanning.
Press (play) to resume normal
playback.
DV575A KU_Mid.book 21 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Getting started
04
23
En
Video CD/Super VCD PBC menus
Some Video CD/Super VCDs have menus from
which you can choose what you want to watch.
These are called PBC (Playback control)
menus.
You can play a PBC Video CD/Super VCD
without having to navigate the PBC menu by
starting playback using a number button to
select a track, rather than the
(play) button.
Button What it does
TOP MENU Displays the ‘top menu’ of a DVD
disc—this varies with the disc.
MENU Displays a DVD disc menu—this
varies with the disc and may be
the same as the ‘top menu’.
Moves the cursor around the
screen.
ENTER Selects the current menu option.
RETURN Returns to the previously dis-
played menu screen. On some
DVD-Audio discs featuring
browsable pictures, press to dis-
play the browser screen.
Numbers
(remote
only)
Highlights a numbered menu
option (some discs only). Press
ENTER to select.
Button What it does
RETURN Displays the PBC menu.
Numbers
(remote
only)
Use to enter a numbered menu
option. Press
ENTER
to select.
Displays the previous menu page
(if there is one).
Displays the next menu page (if
there is one).
0
123
456
789
RETURN
ENTER
ENTER
DV575A KU_Mid.book 23 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Playing discs
05
25
En
Chapter 5
Playing discs
Note
• Many of the functions covered in this
chapter apply to DVD and SACD discs,
Video CDs/Super VCDs, CDs and WMA/
MP3 JPEG discs, although the exact
operation of some varies slightly with the
kind of disc loaded.
• Some DVDs restrict the use of some
functions (random or repeat, for example)
in some or all parts of the disc. This is not a
malfunction.
•When playing Video CD/Super VCDs, some
of the functions are not available during
PBC playback. If you want to use them,
start the disc playing using a number
button to select a track.
Scanning discs
You can fast-scan discs forward or backward at
four different speeds.
1 During playback, press or to
start scanning.
• There is no sound while scanning DVDs
(including DVD-Audio) and Video CD/
Super VCDs.
2 Press repeatedly to increase the
scanning speed.
• The scanning speed is shown on-screen.
3 To resume normal playback, press
(play).
• When scanning a Video CD/Super VCD
playing in PBC mode or a WMA/MP3 track,
playback automatically resumes at the end
or beginning of the track.
• Depending on the disc, normal playback
may automatically resume when a new
chapter is reached on a DVD disc.
Playing in slow motion
You can play DVD-Videos and DVD-R/RW at
four different slow motion speeds, forwards
and backwards. Video CD/Super VCDs can be
played at four different forward slow motion
speeds.
1 During playback, press (pause).
2 Press and hold
or until
slow motion playback starts.
• The slow motion speed is shown on-
screen.
• There is no sound during slow motion
playback.
3 Press repeatedly to change the slow
motion speed.
4 To resume normal playback, press
(play).
• Depending on the disc, normal playback
may automatically resume when a new
chapter is reached.
Frame advance/frame reverse
You can advance or back up DVD-Video and
DVD-R/RW discs frame-by-frame. With Video
CD/Super VCDs you can only use frame
advance.
DV575A KU_Mid.book 25 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Playing discs
05
27
En
• Title – Titles from a DVD-Video disc.
•
Chapter – Chapters from the current title
of a DVD-Video disc.
•
Track – Tracks from a Video CD/Super VCD
disc.
•
Time – Thumbnails from a Video CD/Super
VCD disc at 10 minute intervals.
•
Original: Title – Original titles from a VR
mode DVD-RW disc.
•
Playlist: Title – Playlist titles from a VR
mode DVD-RW disc.
•
Original: Time – Thumbnails from the
Original content at 10 minute intervals.
•
Playlist: Time – Thumbnails from the
Playlist at 10 minute intervals.
The screen shows up to six moving thumbnail
images displayed one after another. To display
the previous/next six thumbnails, press
/
(you don’t have to wait for all the
thumbnails to finish playing to display the
previous/next page).
3 Select the thumbnail image for what
you want to play.
You can use either the cursor buttons (
) and ENTER to select a thumbnail, or the
number buttons.
To select using the number buttons, enter a
two-digit number then press
ENTER .
Tip
•Another way to find a particular place on a
disc is to use one of the search modes. See
Searching a disc on page 31.
Browsing WMA, MP3 and JPEG
files with the Disc Navigator
Use the Disc Navigator to find a particular file
or folder by filename.
1 Press HOME MENU and select ‘Disc
Navigator’ from the on-screen menu.
2 Use the cursor buttons (
)
and ENTER to navigate.
Use the cursor up/down buttons ( ) to
move up and down the folder/file list.
Use the cursor left button (
) to return to the
parent folder.
Use
ENTER or cursor right ( ) to open a
highlighted folder.
•You can also return to the parent folder by
going to the top of the list to the ‘
.. ’ folder,
then pressing
ENTER .
01
04
02
05
03
06
Disc Navigator: Title
01- 49: --
00:00/ 00:00 0kbps
Folder1
Folder2
Folder3
Folder4
DV575A KU_Mid.book 27 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Playing discs
05
29
En
1During playback, press PLAY MODE and
select ‘Repeat’ from the list of functions on
the left.
2 Select a repeat play option.
If program play is active, select Program
Repeat
to repeat the program list, or Repeat
Off
to cancel.
The repeat options available depend on the
kind of disc loaded. For example, for DVD-
Video and DVD-RW discs, you can select
Title
Repeat
or Chapter Repeat (or Repeat Off ).
• For DVD-Audio discs, select
Group
Repeat
or Track Repeat (or Repeat Off ).
•For SACDs,CDs and Video CD/Super
VCDs, select
Disc Repeat or Track Repeat
(or
Repeat Off ).
Using random play
Use the random play function to play titles or
chapters (DVD-Video), Groups (DVD-Audio), or
tracks (DVD-Audio, SACD, CD, Video CD/
Super VCD) at random. (Note that the same
track/title/chapter may play more than once.)
You can set the random play option when a
disc is playing or stopped.
Important
• Random play remains in effect until you
select
Random Off from the random play
menu options.
•You can’t use random play with VR format
DVD-RW discs, Video CD/Super VCDs
playing in PBC mode, WMA/MP3 discs, or
while a DVD disc menu is being displayed.
• You can't use random play together with
program or repeat play.
1 Press PLAY MODE and select ‘Random’
from the list of functions on the left.
2 Select a random play option.
The random play options available depend on
the kind of disc loaded. For example, for DVD-
Video discs, you can select
Random Title or
Random Chapter , (or Random Off ).
• For DVD-Audio discs, select
Random
Group
or Random Track , (or Random
Off
).
•For CDs, SACDs and Video CD/Super
VCDs, select
On or Off to switch random
play on or off.
DV575A KU_Mid.book 29 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Playing discs
05
31
En
Tip
•Use the following controls during program
play:
Other functions available from the
program menu
There are a number of other options in the
program menu in addition to Create/Edit.
•
Playback Start – Starts playback of a
saved program list
•
Playback Stop – Turns off program play,
but does not erase the program list
•
Program Delete – Erases the program list
and turns off program play
Searching a disc
You can search DVD-Video discs by title or
chapter number, or by time; DVD-Audio discs
can be searched by group or track number;
SACDs by track number, CDs and Video CD/
Super VCDs by track number or time.
Important
• Search functions are not available with
Video CD/Super VCDs in PBC mode, or
with WMA/MP3 discs.
1 Press PLAY MODE and select ‘Search
Mode’ from the list of functions on the left.
2 Select a search mode.
The search options available depend on the
kind of disc loaded.
• The disc must be playing in order to use
time search.
3Use the number buttons to enter a title,
chapter or track number, or a time.
• For a time search, enter the number of
minutes and seconds into the currently
playing title (DVD) or track (CD/Video CD/
Super VCD) you want playback to resume
from. For example, press
4 , 5 , 0 , 0 to have
playback start from 45 minutes into the
disc. For 1 hour, 20 minutes and 30
seconds, press
8 , 0 , 3 , 0 .
• Some DVD-Audio discs feature pages of
browsable pictures. Enter the page
number you want.
4 Press ENTER to start playback.
Switching subtitles
Some DVD-Video discs have subtitles in one or
more languages; the disc box will usually tell
you which subtitle languages are available. You
can switch subtitle language during playback.
1 Press SUBTITLE repeatedly to select a
subtitle option.
Button What it does
PLAY
MODE
Save the program list and exit
the program edit screen without
starting playback ( HOME MENU
does the same).
Skip to the next step in the
program list.
DV575A KU_Mid.book 31 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Audio Settings and Video Adjust menus
06
33
En
Chapter 6
Audio Settings and Video
Adjust menus
Audio Settings menu
The Audio Settings menu offers features for
adjusting the way discs sound.
1 Press HOME MENU and select ‘Audio
Settings’ from the on-screen display.
2Select and change settings using the
(cursor) buttons, and ENTER.
Audio DRC
• Settings: High , Medium , Low , Off
(default)
When watching Dolby Digital DVDs at low
volume, it’s easy to lose the quieter sounds
completely—including some of the dialog.
Switching Audio DRC (Dynamic Range
Control) to on can help by bringing up the
quieter sounds, while controlling loud peaks.
How much of a difference you hear depends on
the material you’re listening to. If the material
doesn’t have wide variations in volume, you
may not notice much change.
Note
• Audio DRC is only effective with Dolby
Digital audio sources.
• Audio DRC is only effective through the
digital output when
Digital Out is set to
On , and Dolby Digital Out is set to Dolby
Digital > PCM
(see Digital Audio Out
settings
on page 35).
• The effect of Audio DRC also depends on
your speakers and AV receiver settings.
Virtual Surround
• Settings: On , Off (default)
Switch on Virtual Surround to enjoy realistic
surround sound effects from just two speakers.
Tip
• You can also use the SURROUND button
on the remote control to switch Virtual
Surround on.
Note
• 96kHz Linear PCM audio is automatically
downsampled to 48kHz if Virtual Surround
is switched on.
• The
Audio Output Mode (see page 41)
must be set to
2 Channel in order to be
able to use Virtual Surround.
DV575A KU_Mid.book 33 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
35
En
Chapter 7
Initial Settings menu
Using the Initial Settings menu
The Initial Settings menu provides audio and
video output settings, parental lock settings,
and display settings, among others.
If an option is grayed out it means that it
cannot be changed at the current time. This is
usually because a disc is playing. Stop the
disc, then change the setting.
1 Press HOME MENU and select ‘Initial
Settings’.
2 Use the cursor buttons and ENTER to
select the setting and option you want to
set.
All the settings and options are explained on
the following pages.
Note
• In the table below, the default setting is
shown in
bold : other settings are shown in
italics .
•The Digital Audio Out settings only need to
be set if you have connected the digital
output of this player to an AV receiver, or
other equipment.
• Check the operating instructions supplied
with your other equipment to see which
digital audio formats it’s compatible with.
•Some settings, such as
TV Screen , Audio
Language
and Subtitle Language may be
overridden by the DVD disc. Often these
settings can also be made from the DVD
disc menu.
Digital Audio Out settings
Setting Option What it means
Digital Out On
Digital audio is output from the digital outputs.
Note that there is no digital output when playing SACDs and
some DVD-Audio discs regardless of this setting.
Off
No digital audio output.
Dolby Digital Out Dolby Digital
Dolby Digital encoded digital audio is output when playing a
Dolby Digital DVD disc.
Dolby Digital > PCM
Dolby Digital audio is converted to PCM audio before being
output.
DTS Out DTS
DTS encoded digital audio is output when playing a DTS disc.
(Noise will be output if your amplifier/receiver is not compatible
with DTS audio.)
DTS > PCM
DTS audio is converted to PCM audio before being output.
DV575A KU_Mid.book 35 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
37
En
Display settings
Options settings
Subtitle Language English
If there is are English subtitles on the disc then they will be
displayed.
Languages as displayed
If there is the subtitle language selected on the disc, then it will
be displayed.
Other Language
Select to choose a language other than the ones displayed (see
page 47).
DVD Menu Lan-
guage
w/Subtitle Lang.
DVD disc menus will be displayed in the same language as
your selected subtitle language, if possible.
Languages as displayed
DVD disc menus will be displayed in the selected language, if
possible.
Other Language
Select to choose a language other than the ones displayed (see
page 47).
Subtitle Display On
Subtitles are displayed according to your selected subtitle
language (see above).
Off
Subtitles are always off by default when you play a DVD disc
(note that some discs override this setting).
Setting Option What it means
Setting Option What it means
OSD Language English
On-screen displays of the player are in English.
Languages as displayed
On-screen displays are shown in the language selected.
Angle Indicator On
A camera icon is displayed on-screen during multi-angle
scenes on a DVD disc.
Off
No multi-angle indication is shown.
Setting Option What it means
Parental Lock –
See Parental Lock on page 40.
DVD Playback
Mode
DVD-Audio
All material on a DVD-Audio disc is playable.
DVD-Video
Only the DVD-Video part of a DVD-Audio disc is playable.
DV575A KU_Mid.book 37 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
39
En
About the audio output settings
The table below shows how the audio settings you make in the Initial Settings menu (see page 35)
affect the output from the 2 channel and the 5.1 channel analog outputs, and from the digital
outputs with various types of disc.
*
1
When Audio Output Mode is set to 2 Channel , the AUDIO OUT (5.1ch) FRONT L / R jacks act as a second pair
of stereo audio outputs.
*
2
Dolby Digital > PCM , MPEG > PCM or DTS > PCM setting (pages 35–36)
*
3
Dolby Digital , MPEG or DTS setting (pages 35–36)
*
4
Discs that prohibit downmixing will be output as 5.1 channel even if 2 Channel is selected as the Audio Output
Mode setting (see page 41).
*
5
Discs that prohibit downmixing also mute the digital output.
*
6
When Audio Output Mode is set to 5.1 Channel , mono sources are heard from the center speaker only.
Disc audio format Player setting
Front L / R
–
–
–
–
–
–
–
–
–
–
–
––
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
–
Front L / R
Front L / R
Front L / R
Left / Right Left / Right
Left / Right Left / Right
Left / Right
*6
Left / Right
Left / Right
Left / Right
Left / Right
Left / Right
2ch downmix
2ch downmix
2ch downmix
*4
2ch downmix
2ch downmix
Front L / R
2ch downmix
Front L / R
2ch downmix
2 Ch
5.1 Ch
2 Ch
5.1 Ch
Front L/R
analog outputs
*1
Surround L/R
Center, LFE, outputs
*1
Digital outputs
PCM convert
*2
Bitstream
*3
Dolby Digital
Dolby Digital
karaoke
2 Ch / 5.1 Ch
2 Ch / 5.1 Ch
2 Ch / 5.1 Ch
2 Ch / 5.1 Ch
2 Ch / 5.1 Ch
Linear PCM
2 Ch
5.1 Ch
DTS
MPEG
2 Ch
5.1 Ch
DVD-Audio
2 Ch
5.1 Ch
Super Audio CD
2 Ch
5.1 Ch
DTS CD
CD
Video CD
DVD-RW
(VR mode)
DVD
Dolby Digital
–
2ch downmix
2ch downmix
*5
2ch downmix
*5
DTS
DTS
Dolby Digital
Left / Right
Left / Right Left / Right
Left / Right Left / Right
Dolby Digital
MPEG or PCM
MPEG
DV575A KU_Mid.book 39 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
41
En
The new Country code is set and you will return
to the Options menu screen. Note that the new
Country code doesn’t take effect until the next
disc is loaded (or the current disc is reloaded).
DTS Downmix
• Default setting: Stereo
If you’ve selected DTS > PCM in DTS Out on
page 35 or
2 Channel in Audio Output Mode on
page 41, you can choose the way the signal is
downmixed to PCM audio.
Stereo will
downmix the DTS signal to 2-channel stereo,
whereas
Lt/Rt will downmix to a 2-channel
signal compatible with Dolby surround matrix
decoders. (This allows you to hear surround
sound if your AV receiver or amplifier has Dolby
Pro Logic capability.)
Audio Output Mode
• Default setting: 2 Channel
If you connected this player to your amplifier
using the 5.1 channel analog outputs (front,
surround, center and subwoofer outs), set this
to
5.1 Channel ; if you connected only the
stereo outs, set to
2 Channel .
Note
•Even if you set Audio Output Mode to 5.1
Channel
, you’ll only get sound from all
speakers when playing a 5.1 channel multi-
channel disc.
• When set to
5.1 Channel , only the front
left/right channels are output from the
AUDIO OUT (2ch) jacks. Change to 2
Channel
if you want to listen to downmixed
stereo audio (for example, because you are
listening through the TV’s built-in
speakers).
•When set to
5.1 Channel there is no digital
output when playing DVD-Audio.
•If you set to
2 Channel , Dolby Digital, DTS
and MPEG audio is mixed down to two
channels so you still hear all the audio
recorded on the disc. With DTS encoded
audio, you can choose how the signal is
downmixed to PCM audio. See
DTS
Downmix
above to change the downmix
setting.
• Some DVD-Audio discs don’t allow down-
mixing of audio. These discs always output
multi-channel audio regardless of the
setting made here.
DV575A KU_Mid.book 41 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
43
En
1Use the (cursor up/down) to select
a speaker.
• The L and R speakers are paired; you can’t
set them differently.
2 Press (cursor right) to change the
speaker distance for the highlighted
speaker.
3 Use the
(cursor up/down) to
change the distance.
•When you change the distance settings of
the front left (
L ) or front right ( R ) speakers,
all the other speaker distances change
relative to it.
•Front left/right (
L / R ) speaker distances can
be set from 1 ft. (30 cm) to 30 ft. (9 m) in 1
ft. (30 cm ) increments.
• The center speaker (
C ) can be set from –7
ft. (2.1 m) to 0 ft. (0 m) relative to the front
left/right speakers.
• Surround left/right (
LS / RS ) speakers can
be set from –20 ft. (6.0 m) to 0 ft. (0 m) rela-
tive to the front left/right speakers.
•You can’t set the subwoofer (
SW ) distance.
4 Press (cursor left) to go back to the
speaker list if you want to modify another
speaker, or press ENTER to exit the Speaker
Distance screen.
Note
•During playback of SACD and MPEG-audio
DVD-Video discs, the effective
C , LS and RS
speaker distance settings are –3.0ft (–
0.9m) to 0.0ft (0.0m) relative to the front
left/right speakers.
DV-575A/DV-578A screen
DV-676A-S screen
DV575A KU_Mid.book 43 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
45
En
If you use a chemical-impregnated cleaning
cloth, read the instructions carefully before
use. These cloths may leave smear marks on
half-mirror finish surfaces; if this happens,
finish with a dry cloth.
Cleaning the pickup lens
The DVD player’s lens should not become dirty
in normal use, but if for some reason it should
malfunction due to dust or dirt, consult your
nearest Pioneer-authorized service center. We
do not recommend using commercially
available lens cleaners for CD players.
Condensation
Condensation may form inside the player if it is
brought into a warm room from outside, or if
the temperature of the room rises quickly.
Although the condensation won’t damage the
player, it may temporarily impair its
performance. Leave it to adjust to the warmer
temperature for about an hour before
switching on.
Moving the player
If you need to move the player, first press
STANDBY/ON on the front panel to turn the
player off. Wait for
-OFF- to disappear from the
display, then unplug the power cable. Never lift
or move the unit during playback—discs rotate
at a high speed and may be damaged.
Screen sizes and disc formats
DVD-Video discs come in several different
screen aspect ratios, ranging from TV
programs, which are generally 4:3, to
CinemaScope widescreen movies, with an
aspect ratio of up to about 7:3.
Televisions, too, come in different aspect
ratios; ‘standard’ 4:3 and widescreen 16:9.
Widescreen TV users
If you have a widescreen TV, the TV Screen
setting (page 36) of this player should be set to
16:9 (Wide) .
When you watch discs recorded in 4:3 format,
you can use the TV controls to select how the
picture is presented. Your TV may offer various
zoom and stretch options; see the instructions
that came with your TV for details.
Please note that some movie aspect ratios are
wider than 16:9, so even though you have a
widescreen TV, these discs will still play in a
‘letter box’ style with black bars at the top and
bottom of the screen.
Standard TV users
If you have a standard TV, the TV Screen
setting (page 36) of this player should be set to
4:3 (Letter Box) or 4:3 (Pan&Scan) ,
depending on which you prefer.
Set to
4:3 (Letter Box) , widescreen discs are
shown with black bars top and bottom.
Set to
4:3 (Pan&Scan) , widescreen discs are
shown with the left and right sides cropped.
Although the picture looks larger, you don’t
actually see the whole picture.
Please note that many widescreen discs
override the player’s settings so that the disc is
shown in letter box format regardless of the
setting.
DV575A KU_Mid.book 45 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
47
En
DVD-Video regions
All DVD-Video discs carry a region mark on the
case somewhere that indicates which
region(s) of the world the disc is compatible
with. Your DVD player also has a region mark,
which you can find on the rear panel. Discs
from incompatible regions will not play in this
player. Discs marked
ALL will play in any
player.
The diagram below shows the various DVD
regions of the world.
Selecting languages using the
language code list
Some of the language options (such as ‘DVD
Language’ in the Setup Navigator) allow you to
set your prefered language from any of the 136
languages listed in the language code list on
page 48.
1 Select ‘Other Language’.
2Use the
(cursor left/right) buttons
to select either a code letter or a code
number.
3Use the
(cursor up/down) buttons
to select a code letter or a code number.
See Language code list on page 48 for a
complete list of languages and codes.
1
2
2
5
5
6
3
21
4
4
DV575A KU_Mid.book 47 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
49
En
Troubleshooting
Incorrect operation is often mistaken for trouble or malfunction. If you think that there is
something wrong with this component, check the points below. Sometimes the trouble may lie in
another component. Inspect the other components and electrical appliances being used. If the
trouble cannot be rectified after checking the items below, ask your nearest Pioneer authorized
service center or your dealer to carry out repair work.
Problem Remedy
The disc won’t play or is
automatically ejected
after loading.
• Make sure the disc is free from dirt and dust and is not damaged
(page 44).
• Make sure the disc is loaded with the label side face-up and aligned
properly in the disc tray guide.
• Incompatible region number: If the region number on a DVD-Video
disc does not match the number on the player, the disc cannot be
used (page 47).
• Condensation inside the player: Allow time for condensation to
evaporate. Avoid using the player near an air-conditioning unit.
• Disc is loaded upside down: Reload the disc with the label side face
up.
• A Super VCD that does not conform with the IEC standards might
not play normally.
DVD-Audio playback
stops.
• The disc may have been illegally copied.
Picture playback stops
and the operation
buttons cannot be used.
• Press , then start playback again ( ).
• Press and hold the front panel STANDBY/ON button for about 10
seconds to switch the unit off, then press again to switch back on.
• Switch the power off once, unplug from the wall socket, then plug
back in and switch on again using the front panel STANDBY/ON
button.
New settings made in the
Setup screen menus while
a disc is playing are
ineffective.
• Some settings can be changed while a disc is playing, but are not
effective until the disc is stopped then restarted: Press , then start
playback again ( ).
Settings are canceled. • When the power is cut due to power failure or by unplugging the
power cord, settings will be canceled: Press STANDBY/ON on the
front panel to turn the player off. Wait for --OFF-- to disappear from
the display, then unplug the power cord.
The remote control
doesn't seem to work.
• The remote control is too far from the player, or the angle with the
remote sensor is too wide: Use the remote within its operating range
(page 18).
• The batteries are exhausted: Put in new ones (page 8).
DV575A KU_Mid.book 49 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
51
En
Cannot play multi-
channel audio
• Make sure that Audio Output Mode is set to 5.1 Channel
(page 41).
• Check that the Dolby Digital, DTS and MPEG Out settings
(pages 35–36) are suitable for your amplifier/receiver—check the
instruction manual that came with your amplifier/receiver.
• DVD-Audio and SACDs do not output multichannel digital audio.
Listen through the player’s analog outputs.
• Check that the settings in the Speaker Installation screen are
correct (page 42).
• Check the audio options available from the disc menu.
Cannot listen to high-
sampling rate audio
through the digital
output.
• Make sure that Linear PCM Out is set to Downsample Off
(page 35).
• As a copy-protection measure, some DVDs do not output 96kHz
audio. In this case, even if set to Downsample Off , the player
automatically outputs the audio at 48 kHz. This is not a malfunction.
Cannot output 192kHz or
176.4kHz digital audio.
• The player does not output digital audio at these sampling rates. The
digital output is automatically downsampled.
Cannot output 96kHz or
88.2kHz digital audio.
• Check that Linear PCM Out is set to Downsample Off (page 35).
• Some discs are digital copy protected and do not output high
sampling rate digital audio. In this case the output is automatically
downsampled.
No DTS audio output. • If this unit is connected to a non-DTS compatible amplifier or
decoder using a digital audio cable, set DTS Out to DTS
>
PCM
(page 35). If you do not do this, noise will be output when you play a
DTS disc.
• If this unit is connected to a DTS-compatible amplifier or decoder
using a digital audio cable, check the amplifier settings, and that the
cable is properly connected.
Audio mix does not
sound right or sounds
incomplete (for example,
inaudible dialog).
• Make sure that Audio Output Mode is set to 2 Channel if you've
connected to the stereo inputs on your amplifier or TV (page 41).
The audio recorded on a
Super VCD disc is not
output properly.
• If the audio is switched to [2] when playing a Super VCD that
contains only one stereo soundtrack, there may be no sound at all.
Press AUDIO to change the soundtrack.
Can’t hear effect of
Virtual Surround
• Virtual Surround does not work with SACD or DVD-Audio.
• The Virtual Surround effect is only output through the AUDIO OUT
(2ch) analog audio outputs.
• Make sure that Audio Output Mode is set to 2 Channel (page 41).
• The effectiveness of Virtual Surround varies with the disc.
Problem Remedy
DV575A KU_Mid.book 51 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
53
En
Glossary
Analog audio Direct representation of sound by an
electrical signal. See also Digital audio .
Aspect ratio The width of a TV screen relative to its
height. Conventional TVs are 4:3;
widescreen models are 16:9.
Bonus Group
(DVD-Audio
only)
An ‘extra’ group on some DVD-Audio
discs that requires a key number to
access.
Browsable
pictures
(DVD-Audio
only)
A feature of some DVD-Audio discs in
which the user can browse still pictures
recorded on the disc as the audio is
played. See also Slideshow .
Digital audio Indirect representation of sound using
numbers. See also Sampling frequency
and Analog audio .
Dolby
Digital
*1
A multi-channel audio encoding system
developed by Dolby Laboratories that
enables far more audio to be stored on a
disc than PCM encoding. See also PCM
(Pulse Code Modulation) .
DRM DRM (Digital Rights Management) copy
protection is a technology designed to
prevent unauthorized copying by
restricting playback, etc. of material on
devices other the PC (or other WMA
recording equipment) used to record it.
For detailed information, please see the
instruction manuals or help files that
came with your PC (or other WMA
recording equipment) and/or software.
DTS
*2
A multi-channel audio encoding system
developed by Digital Theater Systems
that enables far more audio to be stored
on a disc than PCM encoding. See also
PCM (Pulse Code Modulation) .
EXIF
(Exchangeabl
e Image File)
A file format developed by Fuji Photo
Film for digital still cameras. Digital
cameras from various manuafcturers
use this compressed file format which
carries date, time and thumbnail
information, as well as the picture data.
File
extension
A tag added to the end of a filename to
indicate the type of file. For example,
“.mp3” indicates an MP3 file.
ISO 9660
format
International standard for the volume
and file structure of CD-ROM discs.
JPEG A standard file format used for still
images. JPEG files are identified by the
file extension “.jpg”.
MP3 MP3 (MPEG1 audio layer 3) is a
compressed stereo audio file format.
Files are recognized by their file
extension “.mp3”.
MPEG audio An audio format used on Video CD/
Super VCDs and some DVD discs.
Packed PCM
(DVD-Audio
only)
A lossless compression system that
enables more PCM audio to be stored
on a DVD-Audio disc than would
otherwise be possible.
PBC
(PlayBack
Control)
A system of navigating a Video CD/
Super VCD through on-screen menus
recorded onto the disc.
PCM
(Pulse Code
Modulation)
Digital audio encoding system found on
CDs. Good quality, but requires a lot of
data compared to Dolby Digital, DTS
and MPEG encoded audio. See also
Digital audio .
Progressive
scan video
All the lines that make up a video
picture are updated in one pass
(compared to interlace which takes two
passes to update the whole picture).
Regions
(DVD-Video
only)
These associate DVD-Video discs and
players with particular areas of the
world. See DVD-Video regions on
page 47 for more information.
Sampling
frequency
The rate at which sound is measured to
be turned into digital audio data. The
higher the rate, the better the sound
quality. CD is 44.1 kHz; DVD can be up
to 96 kHz. See also Digital audio .
DV575A KU_Mid.book 53 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
55
En
Specifications
General
System . . . . . . . . . . . . . . . . . . . . . . . . DVD player
Power requirements
DV-575A / DV-578A . . . . . . . . . . .AC 120 V, 60 Hz
DV-676A-S
. . . . . . AC 110–127/220–240 V, 50/60 Hz
Power consumption
DV-575A / DV-578A . . . . . . . . . . . . . . . . . . . .11 W
DV-676A-S. . . . . . . . . . . . . . . . . . . . . . . . . . . .12 W
Power consumption (standby)
DV-575A / DV-578A . . . . . . . . . . . . . . . . . . 0.07 W
DV-676A-S. . . . . . . . . . . . . . . . . . . . . . . . . . 0.12 W
Weight . . . . . . . . . . . . . . . . . . . 2.1 kg / 4 lb 10 oz
Dimensions . .420 (W) x 55 (H) x 243 (D) mm
. . . . . . . . . . . . . . . (16.5 (W) x 2.2 (H) x 9.6 (D) in.)
Operating temperature . . . . . . . +5°C to +35°C
(+41°F to +95°F)
Operating humidity . . . . . . . . . . . . . . . 5% to 85%
(no condensation)
Component video output
Y (luminance) - Output level . . . . . . 1 Vp-p (75 )
P
B
(color) - Output level . . . . . . . 0.7 Vp-p (75 )
P
R
(color) - Output level . . . . . . . 0.7 Vp-p (75 )
Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA
S-video output
Y (luminance) - Output level . . . . . . 1 Vp-p (75 )
C (color) - Output level . . . . . . 286 mVp-p (75 )
Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .S-video
Video output
Output level . . . . . . . . . . . . . . . . . . . 1 Vp-p (75 )
Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA
Audio output (1 stereo pair)
Output level . . . . . . . . . . . . .During audio output
200 mVrms (1 kHz, –20 dB)
Number of channels . . . . . . . . . . . . . . . . . . . . . . 2
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA
Audio output (multi-channel / L, R, C, SW,
LS, RS)
Output level. . . . . . . . . . . . . During audio output
200 mVrms (1 kHz, –20 dB)
Number of channels . . . . . . . . . . . . . . . . . . . . . 6
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . .RCA jack
Digital audio characteristics
Frequency response . . . . . . . . . . 4 Hz to 44 kHz
(DVD fs: 96 kHz)
4 Hz to 88 kHz (DVD-Audio fs: 192 kHz)
S/N ratio . . . . . . . . . . . . . . . . . . . . . . . . . . .115 dB
Dynamic range . . . . . . . . . . . . . . . . . . . . . .101 dB
Total harmonic distortion. . . . . . . . . . . . 0.0020 %
Wow and flutter . . . . . . . .Limit of measurement
(±0.001% W. PEAK) or lower
Digital output
Coaxial digital output jack . . . . . . . . . . .RCAjack
Optical digital output . . . . . . .Optical digital jack
Accessories
Audio/video cable. . . . . . . . . . . . . . . . . . . . . . . . 1
Power cable
DV-676A-S (Singapore/Taiwan model) . . . . . . 2
Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . 1
AA/R6P dry cell batteries . . . . . . . . . . . . . . . . . 2
Operating Instructions
Warranty card (
U.S. model only
).. . . . . . . . . . 1
Front panel button names sticker
(Singapore/Taiwan models only)
. . . . . . . . . . 1
Remote control overlay
(Singapore/Taiwan models only)
. . . . . . . . . . 1
The specifications and design of this product are subject to
change without notice, due to improvement.
Published by Pioneer Corporation.
Copyright © 2004 Pioneer Corporation.
All rights reserved
DV575A KU_Mid.book 55 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals

Before you start01
8
En
What’s in the box
Please confirm that the following accessories
are in the box when you open it.
• Remote control
• AA/R6P dry cell batteries x2
• Audio/video cable (red/white/yellow plugs)
• Power cable
• Operating instructions
• Warranty card (DV-575A and DV-578A
model only)
• Front panel button names sticker
—
Chinese language button names for the
front panel controls.
• Remote control overlay
— Place the overlay
on the remote control to be able to read the
buttons in Chinese.
Putting the batteries in the remote
• Open the battery compartment cover
and insert the batteries as shown.
Use two AA/R6P batteries and follow the
indications (
 ,  ) inside the compartment.
Close the cover when you’re finished.
Important
Incorrect use of batteries can result in hazards
such as leakage and bursting. Please observe
the following:
• Don’t mix new and old batteries together.
• Don’t use different kinds of battery
together—although they may look similar,
different batteries may have different
voltages.
•Make sure that the plus and minus ends of
each battery match the indications in the
battery compartment.
• Remove batteries from equipment that
isn’t going to be used for a month or more.
• When disposing of used batteries, please
comply with governmental regulations or
environmental public instruction’s rules
that apply in your country or area.
Hints on installation
We want you to enjoy using this product for
years to come, so please use the following
guidelines when choosing a suitable location:
Do...
• Use in a well-ventilated room.
•Place on a solid, flat, level surface, such as
a table, shelf or stereo rack.
Don’t...
• Use in a place exposed to high
temperatures or humidity, including near
radiators and other heat-generating
appliances.
•Place on a window sill or a place where the
player will be exposed to direct sunlight.
• Use in an excessively dusty or damp
environment.
• Place directly on top of an amplifier, or
other component in your stereo system
that becomes hot in use.
•Use near a television or monitor as you may
experience interference—especially if the
television uses an indoor antenna.
• Use in a kitchen or other room where the
player may be exposed to smoke or steam.
• Use on a thick rug or carpet, or cover with
cloth—this may prevent proper cooling of
the unit.
DV575A KU_Mid.book 8 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
10
En
About WMA
The Windows Media
®
logo printed on the box
indicates that this player can playback
Windows Media Audio content.
WMA is an acronym for Windows Media Audio
andrefers to an audiocompression technology
developed by Microsoft Corporation. WMA
content can be encoded by using Windows
Media
®
Player version 7, 7.1, Windows Media
®
Player for Windows
®
XP, or Windows Media
®
Player 9 Series.
JPEG file compatibility
• Compatible formats: Baseline JPEG and
EXIF 2.2* still image files up to a resultion
of 3072 x 2048.
*
• Progressive JPEG compatible: No
• File extensions: .jpg (must be used for the
player to recognize JPEG files – do not use
for other file types)
• File structure: Up to 299 folders; up to 648
folders and files combined
PC-created disc compatibility
Discs recorded using a personal computer
may not be playable in this unit due to the
setting of the application software used to
create the disc. In these particular instances,
check with the software publisher for more
detailed information.
Discs recorded in packet write mode (UDF
format) are not compatible with this player.
Check the DVD-R/RW or CD-R/RW software
disc boxes for additional compatibility
information.
DV575A KU_Mid.book 10 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals

Connecting up 02
11
En
Chapter 2
Connecting up
Easy connections
The setup described here is a basic setup that allows you to play discs using just the cables
supplied with the player. In this setup, stereo audio is played through the speakers in your TV.
Important
•This player is equipped with copy protection technology. Do not connect this player to your TV
via a VCR using audio/video or S-video cables, as the picture from this player will not appear
properly on your TV. (This player may also not be compatible with some combination TV/VCRs
for the same reason; refer to the manufacturer for more information.)
• When connecting to your TV as shown above, do not set the
Component Out setting (see
Video Output settings on page 36) to Progressive .
Yellow
White
Red
TV
A/V IN
To power
outlet
DV575A KU_Mid.book 11 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
13
En
Watching progressive scan video
from the component video outputs
This player can output progressive scan video
from the component video output. Compared
to interlace video, progressive scan video
effectively doubles the scanning rate of the
picture, resulting in a very stable, flicker-free
image.
To set up the player for use with a progressive
scan TV, see
Video Output settings on page 36.
When the player is set to output progressive
scan video, the
PRGSVE indicator lights in the
front panel display.
Important
• If you connect a TV that is not compatible
with a progressive scan signal and switch
the player to progressive, you will not be
able to see any picture at all. In this case,
switch everything off and reconnect using
the supplied video cable (see
Easy
connections
on page 11), then switch back
to
Interlace (see below).
Switching the video output to interlace
using the front panel controls
Switch the player to standby then, using the
front panel controls, press
 STANDBY/ON
while pressing
 to switch the player back to
Interlace .
Compatibility of this player with
progressive-scan and high-definition TVs
This player is compatible with progressive
video Macro Vision System Copy Guard.
Consumers should note that not all high-
definition television sets are fully compatible
with this product and may cause artifacts to be
displayed in the picture. In case of 525
progressive scan picture problems, it is
recommended that the user switch the
connection to the ‘standard definition’ output
(Interlace). If there are questions regarding our
TV set compatibility with this model, please
contact our customer service center.
This player is compatible with the following
Pioneer displays and monitors:
Plasma display (DV-575A, DV-578A )
PDP-505HD, PDP-5030HD, PDP-4330HD,
PDP-5040HD, PDP-4340HD, Pro-1000HD, Pro-
800HD, Pro-1000HDI, Pro-800HDI, Pro-
1110HD, Pro-910HD, PDP-4300, PDP-5031
Projection monitor receiver (DV-575A, DV-578A )
SD-533HD5, SD-643HD5, Pro-710HD, Pro-
610HD, Pro-510HD, Pro-720HD, Pro-620HD,
Pro-520HD, Pro-730HD, Pro-630HD, Pro-
530HD, Pro-730HDI, Pro-530HDI
Plasma display (DV-676A-S)
PDP-502MX, PDP-503HDG, PDP-433HDG,
PDP-5040HD, PDP-4340HD
Projection monitor receiver (DV-676A-S)
SD-532HD5, SD-533HD5
FL DIMMER





 OPEN/CLOSE
STANDBY/ON
DV-575A / DV-676A-S
STANDBY/ON
DV575A KU_Mid.book 13 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
15
En
Connecting the digital output
This player has both optical and coaxial-type
digital audio outputs for connection to an AV
receiver. Connect whichever is convenient.
Depending on the capabilities of your AV
receiver, you might have to set up this player to
output only digital audio in a compatible
format. See
Digital Audio Out settings on
page 35 and refer to the operating instructions
that came with your AV receiver.
•Connect one of the DIGITAL AUDIO OUT
jacks on this player to a digital input on
your AV receiver.
For an optical connection, use an optical cable
(not supplied) to connect the
OPTICAL
DIGITAL AUDIO OUT
jack to an optical input
on your AV receiver.
For a coaxial connection, use a coaxial cable
(similar to the supplied video cable) to connect
the
COAXIAL DIGITAL AUDIO OUT jack to a
coaxial input on your AV receiver.
AV receiver
DIGITAL IN
(OPTICAL)
DIGITAL IN
(COAXIAL)
DV575A KU_Mid.book 15 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Controls and displays
03
17
En
Display
1 V-PART
Lights when playing a video part of a DVD disc.
2 PRGSVE
Lights when the player is set to output progres-
sive scan video (see
Component Out on
page 36 ).
3 GRP
Indicates that the character display is showing
a DVD-Audio group number.
4 TITLE
Indicates that the character display is showing
a DVD title number.
5 TRK
Indicates that the character display is showing
a DVD-Audio, SACD, CD or Video CD/Super
VCD track number.
6 CHP
Indicates that the character display is showing
a DVD chapter number.
7 5.1CH
Lights when analog 5.1 channel output is
selected (see
Audio Output Mode on page 41).
8 D.MIX
During multichannel audio playback, indicates
that the output signal has been “downmixed”
from the original audio source. This is an auto-
matic function performed by the player in order
to present the most appropriate audio mix to
the speakers present in your system.
9
Lights in any of the repeat play modes.
10 REMAIN
Indicates that the character display is showing
the disc or title/chapter/track remain time.
11 Character display
12
Lights during multi-angle scenes on a DVD
disc.
13  and 
Indicates whether a disc is playing or paused.
14 DTS
Lights when a DTS soundtrack is playing.
15 2 D
Lights when a Dolby Digital soundtrack is
playing.
1415 1113 12
2 43 5 5 6 7 8 9 10
1
DV575A KU_Mid.book 17 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Getting started
04
19
En
Chapter 4
Getting started
Switching on
After making sure that everything is connected
properly and that the player is plugged in,
press
 STANDBY/ON on the front panel or
remote control to switch the player on.
Also, switch on your TV and make sure that it is
set to the input you connected the DVD player
to.
FAQ
• My DVD player switches on but there is
nothing displayed on my TV.
Make sure that the TV is set to the correct
video input (not a TV channel). For
example, if you connected this player to the
VIDEO 1 inputs on your TV, switch your TV
to
VIDEO 1 .
Note
•This player features a screen saver and an
auto power off function. If the player is
stopped and no button is pressed for
around five minutes, the screen saver
starts. If the disc tray is closed but no disc
is playing and no control is pressed for
about 30 minutes, the player automatically
goes into standby.
Using the on-screen displays
For ease of use, this player makes extensive
use of graphical on-screen displays (OSDs).
All the screens are navigated in basically the
same way, using the cursor buttons (
) to change the highlighted item and
pressing
ENTER to select it.
FL DIMMER
STANDBY/ON
DV-575A / DV-676A-S
STANDBY/ON
Button What it does
HOME
MENU
Display/exit the on-screen display.
Changes the highlighted menu
item.
ENTER
Selects the highlighted menu
item (both
ENTER buttons on the
remote work in exactly the same
way).
RETURN Returns to the main menu
without saving changes.
 


DV-578A
DV575A KU_Mid.book 19 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Getting started
04
21
En
1 If the player isn’t already on, press
 STANDBY/ON to switch it on.
If you’re playing a DVD or Video CD/Super VCD,
also turn on your TV and make sure that it is set
to the correct video input.
2 Press  OPEN/CLOSE to open the disc
tray.
3 Load a disc.
Load a disc with the label side facing up, using
the disc tray guide to align the disc (if you’re
loading a double-sided DVD disc, load it with
the side you want to play face down).
4 Press  (play) to start playback.
If you’re playing a DVD or Video CD/Super VCD,
an on-screen menu may appear. See
DVD disc
menus
on page 22 and Video CD/Super VCD
PBC menus
on page 23 for more on how to
navigate these.
•If you’re playing an MP3/WMA disc, it may
take a few seconds before playback starts.
Note
• You may find with some DVD discs that
some playback controls don’t work in
certain parts of the disc. This is not a
malfunction.
Basic playback controls
The table below shows the basic controls on
the remote for playing discs. The following
chapter covers other playback features in more
detail.


/ /






Button What it does
 Starts playback.
If the display shows RESUME or
LAST MEM playback starts from
the resume or last memory point
(see also Resume and Last Memory
on page 22.)
 Pauses a disc that’s playing, or
restarts a paused disc.
 Stops playback.
See also Resume and Last Memory
on page 22.

(remote
only)
Press to start fast reverse scanning.
Press
 (play) to resume normal
playback.

(remote
only)
Press to start fast forward scanning.
Press  (play) to resume normal
playback.
DV575A KU_Mid.book 21 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Getting started
04
23
En
Video CD/Super VCD PBC menus
Some Video CD/Super VCDs have menus from
which you can choose what you want to watch.
These are called PBC (Playback control)
menus.
You can play a PBC Video CD/Super VCD
without having to navigate the PBC menu by
starting playback using a number button to
select a track, rather than the
 (play) button.
Button What it does
TOP MENU Displays the ‘top menu’ of a DVD
disc—this varies with the disc.
MENU Displays a DVD disc menu—this
varies with the disc and may be
the same as the ‘top menu’.
Moves the cursor around the
screen.
ENTER Selects the current menu option.
RETURN Returns to the previously dis-
played menu screen. On some
DVD-Audio discs featuring
browsable pictures, press to dis-
play the browser screen.
Numbers
(remote
only)
Highlights a numbered menu
option (some discs only). Press
ENTER to select.
Button What it does
RETURN Displays the PBC menu.
Numbers
(remote
only)
Use to enter a numbered menu
option. Press
ENTER
to select.
 Displays the previous menu page
(if there is one).
 Displays the next menu page (if
there is one).

DV575A KU_Mid.book 23 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Playing discs
05
25
En
Chapter 5
Playing discs
Note
• Many of the functions covered in this
chapter apply to DVD and SACD discs,
Video CDs/Super VCDs, CDs and WMA/
MP3 JPEG discs, although the exact
operation of some varies slightly with the
kind of disc loaded.
• Some DVDs restrict the use of some
functions (random or repeat, for example)
in some or all parts of the disc. This is not a
malfunction.
•When playing Video CD/Super VCDs, some
of the functions are not available during
PBC playback. If you want to use them,
start the disc playing using a number
button to select a track.
Scanning discs
You can fast-scan discs forward or backward at
four different speeds.
1 During playback, press  or  to
start scanning.
• There is no sound while scanning DVDs
(including DVD-Audio) and Video CD/
Super VCDs.
2 Press repeatedly to increase the
scanning speed.
• The scanning speed is shown on-screen.
3 To resume normal playback, press 
(play).
• When scanning a Video CD/Super VCD
playing in PBC mode or a WMA/MP3 track,
playback automatically resumes at the end
or beginning of the track.
• Depending on the disc, normal playback
may automatically resume when a new
chapter is reached on a DVD disc.
Playing in slow motion
You can play DVD-Videos and DVD-R/RW at
four different slow motion speeds, forwards
and backwards. Video CD/Super VCDs can be
played at four different forward slow motion
speeds.
1 During playback, press  (pause).
2 Press and hold
/ or / until
slow motion playback starts.
• The slow motion speed is shown on-
screen.
• There is no sound during slow motion
playback.
3 Press repeatedly to change the slow
motion speed.
4 To resume normal playback, press

(play).
• Depending on the disc, normal playback
may automatically resume when a new
chapter is reached.
Frame advance/frame reverse
You can advance or back up DVD-Video and
DVD-R/RW discs frame-by-frame. With Video
CD/Super VCDs you can only use frame
advance.
DV575A KU_Mid.book 25 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Playing discs
05
27
En
• Title – Titles from a DVD-Video disc.
•
Chapter – Chapters from the current title
of a DVD-Video disc.
•
Track – Tracks from a Video CD/Super VCD
disc.
•
Time – Thumbnails from a Video CD/Super
VCD disc at 10 minute intervals.
•
Original: Title – Original titles from a VR
mode DVD-RW disc.
•
Playlist: Title – Playlist titles from a VR
mode DVD-RW disc.
•
Original: Time – Thumbnails from the
Original content at 10 minute intervals.
•
Playlist: Time – Thumbnails from the
Playlist at 10 minute intervals.
The screen shows up to six moving thumbnail
images displayed one after another. To display
the previous/next six thumbnails, press
 /
 (you don’t have to wait for all the
thumbnails to finish playing to display the
previous/next page).
3 Select the thumbnail image for what
you want to play.
You can use either the cursor buttons (
) and ENTER to select a thumbnail, or the
number buttons.
To select using the number buttons, enter a
two-digit number then press
ENTER .
Tip
•Another way to find a particular place on a
disc is to use one of the search modes. See
Searching a disc on page 31.
Browsing WMA, MP3 and JPEG
files with the Disc Navigator
Use the Disc Navigator to find a particular file
or folder by filename.
1 Press HOME MENU and select ‘Disc
Navigator’ from the on-screen menu.
2 Use the cursor buttons (
)
and ENTER to navigate.
Use the cursor up/down buttons ( ) to
move up and down the folder/file list.
Use the cursor left button (
) to return to the
parent folder.
Use
ENTER or cursor right ( ) to open a
highlighted folder.
•You can also return to the parent folder by
going to the top of the list to the ‘
.. ’ folder,
then pressing
ENTER .
01
04
02
05
03
06
Disc Navigator: Title
01- 49: --
00:00/ 00:00 0kbps
Folder1
Folder2
Folder3
Folder4
DV575A KU_Mid.book 27 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Playing discs
05
29
En
1During playback, press PLAY MODE and
select ‘Repeat’ from the list of functions on
the left.
2 Select a repeat play option.
If program play is active, select Program
Repeat
to repeat the program list, or Repeat
Off
to cancel.
The repeat options available depend on the
kind of disc loaded. For example, for DVD-
Video and DVD-RW discs, you can select
Title
Repeat
or Chapter Repeat (or Repeat Off ).
• For DVD-Audio discs, select
Group
Repeat
or Track Repeat (or Repeat Off ).
•For SACDs,CDs and Video CD/Super
VCDs, select
Disc Repeat or Track Repeat
(or
Repeat Off ).
Using random play
Use the random play function to play titles or
chapters (DVD-Video), Groups (DVD-Audio), or
tracks (DVD-Audio, SACD, CD, Video CD/
Super VCD) at random. (Note that the same
track/title/chapter may play more than once.)
You can set the random play option when a
disc is playing or stopped.
Important
• Random play remains in effect until you
select
Random Off from the random play
menu options.
•You can’t use random play with VR format
DVD-RW discs, Video CD/Super VCDs
playing in PBC mode, WMA/MP3 discs, or
while a DVD disc menu is being displayed.
• You can't use random play together with
program or repeat play.
1 Press PLAY MODE and select ‘Random’
from the list of functions on the left.
2 Select a random play option.
The random play options available depend on
the kind of disc loaded. For example, for DVD-
Video discs, you can select
Random Title or
Random Chapter , (or Random Off ).
• For DVD-Audio discs, select
Random
Group
or Random Track , (or Random
Off
).
•For CDs, SACDs and Video CD/Super
VCDs, select
On or Off to switch random
play on or off.
DV575A KU_Mid.book 29 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Playing discs
05
31
En
Tip
•Use the following controls during program
play:
Other functions available from the
program menu
There are a number of other options in the
program menu in addition to Create/Edit.
•
Playback Start – Starts playback of a
saved program list
•
Playback Stop – Turns off program play,
but does not erase the program list
•
Program Delete – Erases the program list
and turns off program play
Searching a disc
You can search DVD-Video discs by title or
chapter number, or by time; DVD-Audio discs
can be searched by group or track number;
SACDs by track number, CDs and Video CD/
Super VCDs by track number or time.
Important
• Search functions are not available with
Video CD/Super VCDs in PBC mode, or
with WMA/MP3 discs.
1 Press PLAY MODE and select ‘Search
Mode’ from the list of functions on the left.
2 Select a search mode.
The search options available depend on the
kind of disc loaded.
• The disc must be playing in order to use
time search.
3Use the number buttons to enter a title,
chapter or track number, or a time.
• For a time search, enter the number of
minutes and seconds into the currently
playing title (DVD) or track (CD/Video CD/
Super VCD) you want playback to resume
from. For example, press
4 , 5 , 0 , 0 to have
playback start from 45 minutes into the
disc. For 1 hour, 20 minutes and 30
seconds, press
8 , 0 , 3 , 0 .
• Some DVD-Audio discs feature pages of
browsable pictures. Enter the page
number you want.
4 Press ENTER to start playback.
Switching subtitles
Some DVD-Video discs have subtitles in one or
more languages; the disc box will usually tell
you which subtitle languages are available. You
can switch subtitle language during playback.
1 Press SUBTITLE repeatedly to select a
subtitle option.
Button What it does
PLAY
MODE
Save the program list and exit
the program edit screen without
starting playback ( HOME MENU
does the same).
 Skip to the next step in the
program list.
DV575A KU_Mid.book 31 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Audio Settings and Video Adjust menus
06
33
En
Chapter 6
Audio Settings and Video
Adjust menus
Audio Settings menu
The Audio Settings menu offers features for
adjusting the way discs sound.
1 Press HOME MENU and select ‘Audio
Settings’ from the on-screen display.
2Select and change settings using the
(cursor) buttons, and ENTER.
Audio DRC
• Settings: High , Medium , Low , Off
(default)
When watching Dolby Digital DVDs at low
volume, it’s easy to lose the quieter sounds
completely—including some of the dialog.
Switching Audio DRC (Dynamic Range
Control) to on can help by bringing up the
quieter sounds, while controlling loud peaks.
How much of a difference you hear depends on
the material you’re listening to. If the material
doesn’t have wide variations in volume, you
may not notice much change.
Note
• Audio DRC is only effective with Dolby
Digital audio sources.
• Audio DRC is only effective through the
digital output when
Digital Out is set to
On , and Dolby Digital Out is set to Dolby
Digital > PCM
(see Digital Audio Out
settings
on page 35).
• The effect of Audio DRC also depends on
your speakers and AV receiver settings.
Virtual Surround
• Settings: On , Off (default)
Switch on Virtual Surround to enjoy realistic
surround sound effects from just two speakers.
Tip
• You can also use the SURROUND button
on the remote control to switch Virtual
Surround on.
Note
• 96kHz Linear PCM audio is automatically
downsampled to 48kHz if Virtual Surround
is switched on.
• The
Audio Output Mode (see page 41)
must be set to
2 Channel in order to be
able to use Virtual Surround.
DV575A KU_Mid.book 33 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
35
En
Chapter 7
Initial Settings menu
Using the Initial Settings menu
The Initial Settings menu provides audio and
video output settings, parental lock settings,
and display settings, among others.
If an option is grayed out it means that it
cannot be changed at the current time. This is
usually because a disc is playing. Stop the
disc, then change the setting.
1 Press HOME MENU and select ‘Initial
Settings’.
2 Use the cursor buttons and ENTER to
select the setting and option you want to
set.
All the settings and options are explained on
the following pages.
Note
• In the table below, the default setting is
shown in
bold : other settings are shown in
italics .
•The Digital Audio Out settings only need to
be set if you have connected the digital
output of this player to an AV receiver, or
other equipment.
• Check the operating instructions supplied
with your other equipment to see which
digital audio formats it’s compatible with.
•Some settings, such as
TV Screen , Audio
Language
and Subtitle Language may be
overridden by the DVD disc. Often these
settings can also be made from the DVD
disc menu.
Digital Audio Out settings
Setting Option What it means
Digital Out On
Digital audio is output from the digital outputs.
Note that there is no digital output when playing SACDs and
some DVD-Audio discs regardless of this setting.
Off
No digital audio output.
Dolby Digital Out Dolby Digital
Dolby Digital encoded digital audio is output when playing a
Dolby Digital DVD disc.
Dolby Digital > PCM
Dolby Digital audio is converted to PCM audio before being
output.
DTS Out DTS
DTS encoded digital audio is output when playing a DTS disc.
(Noise will be output if your amplifier/receiver is not compatible
with DTS audio.)
DTS > PCM
DTS audio is converted to PCM audio before being output.
DV575A KU_Mid.book 35 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
37
En
Display settings
Options settings
Subtitle Language English
If there is are English subtitles on the disc then they will be
displayed.
Languages as displayed
If there is the subtitle language selected on the disc, then it will
be displayed.
Other Language
Select to choose a language other than the ones displayed (see
page 47).
DVD Menu Lan-
guage
w/Subtitle Lang.
DVD disc menus will be displayed in the same language as
your selected subtitle language, if possible.
Languages as displayed
DVD disc menus will be displayed in the selected language, if
possible.
Other Language
Select to choose a language other than the ones displayed (see
page 47).
Subtitle Display On
Subtitles are displayed according to your selected subtitle
language (see above).
Off
Subtitles are always off by default when you play a DVD disc
(note that some discs override this setting).
Setting Option What it means
Setting Option What it means
OSD Language English
On-screen displays of the player are in English.
Languages as displayed
On-screen displays are shown in the language selected.
Angle Indicator On
A camera icon is displayed on-screen during multi-angle
scenes on a DVD disc.
Off
No multi-angle indication is shown.
Setting Option What it means
Parental Lock –
See Parental Lock on page 40.
DVD Playback
Mode
DVD-Audio
All material on a DVD-Audio disc is playable.
DVD-Video
Only the DVD-Video part of a DVD-Audio disc is playable.
DV575A KU_Mid.book 37 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
39
En
About the audio output settings
The table below shows how the audio settings you make in the Initial Settings menu (see page 35)
affect the output from the 2 channel and the 5.1 channel analog outputs, and from the digital
outputs with various types of disc.
*
1
When Audio Output Mode is set to 2 Channel , the AUDIO OUT (5.1ch) FRONT L / R jacks act as a second pair
of stereo audio outputs.
*
2
Dolby Digital > PCM , MPEG > PCM or DTS > PCM setting (pages 35–36)
*
3
Dolby Digital , MPEG or DTS setting (pages 35–36)
*
4
Discs that prohibit downmixing will be output as 5.1 channel even if 2 Channel is selected as the Audio Output
Mode setting (see page 41).
*
5
Discs that prohibit downmixing also mute the digital output.
*
6
When Audio Output Mode is set to 5.1 Channel , mono sources are heard from the center speaker only.
Disc audio format Player setting
Front L / R
–
–
–
–
–
–
–
–
–
–
–
––
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
–
Front L / R
Front L / R
Front L / R
Left / Right Left / Right
Left / Right Left / Right
Left / Right
*6
Left / Right
Left / Right
Left / Right
Left / Right
Left / Right
2ch downmix
2ch downmix
2ch downmix
*4
2ch downmix
2ch downmix
Front L / R
2ch downmix
Front L / R
2ch downmix
2 Ch
5.1 Ch
2 Ch
5.1 Ch
Front L/R
analog outputs
*1
Surround L/R
Center, LFE, outputs
*1
Digital outputs
PCM convert
*2
Bitstream
*3
Dolby Digital
Dolby Digital
karaoke
2 Ch / 5.1 Ch
2 Ch / 5.1 Ch
2 Ch / 5.1 Ch
2 Ch / 5.1 Ch
2 Ch / 5.1 Ch
Linear PCM
2 Ch
5.1 Ch
DTS
MPEG
2 Ch
5.1 Ch
DVD-Audio
2 Ch
5.1 Ch
Super Audio CD
2 Ch
5.1 Ch
DTS CD
CD
Video CD
DVD-RW
(VR mode)
DVD
Dolby Digital
–
2ch downmix
2ch downmix
*5
2ch downmix
*5
DTS
DTS
Dolby Digital
Left / Right
Left / Right Left / Right
Left / Right Left / Right
Dolby Digital
MPEG or PCM
MPEG
DV575A KU_Mid.book 39 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
41
En
The new Country code is set and you will return
to the Options menu screen. Note that the new
Country code doesn’t take effect until the next
disc is loaded (or the current disc is reloaded).
DTS Downmix
• Default setting: Stereo
If you’ve selected DTS > PCM in DTS Out on
page 35 or
2 Channel in Audio Output Mode on
page 41, you can choose the way the signal is
downmixed to PCM audio.
Stereo will
downmix the DTS signal to 2-channel stereo,
whereas
Lt/Rt will downmix to a 2-channel
signal compatible with Dolby surround matrix
decoders. (This allows you to hear surround
sound if your AV receiver or amplifier has Dolby
Pro Logic capability.)
Audio Output Mode
• Default setting: 2 Channel
If you connected this player to your amplifier
using the 5.1 channel analog outputs (front,
surround, center and subwoofer outs), set this
to
5.1 Channel ; if you connected only the
stereo outs, set to
2 Channel .
Note
•Even if you set Audio Output Mode to 5.1
Channel
, you’ll only get sound from all
speakers when playing a 5.1 channel multi-
channel disc.
• When set to
5.1 Channel , only the front
left/right channels are output from the
AUDIO OUT (2ch) jacks. Change to 2
Channel
if you want to listen to downmixed
stereo audio (for example, because you are
listening through the TV’s built-in
speakers).
•When set to
5.1 Channel there is no digital
output when playing DVD-Audio.
•If you set to
2 Channel , Dolby Digital, DTS
and MPEG audio is mixed down to two
channels so you still hear all the audio
recorded on the disc. With DTS encoded
audio, you can choose how the signal is
downmixed to PCM audio. See
DTS
Downmix
above to change the downmix
setting.
• Some DVD-Audio discs don’t allow down-
mixing of audio. These discs always output
multi-channel audio regardless of the
setting made here.
DV575A KU_Mid.book 41 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
43
En
1Use the (cursor up/down) to select
a speaker.
• The L and R speakers are paired; you can’t
set them differently.
2 Press (cursor right) to change the
speaker distance for the highlighted
speaker.
3 Use the
(cursor up/down) to
change the distance.
•When you change the distance settings of
the front left (
L ) or front right ( R ) speakers,
all the other speaker distances change
relative to it.
•Front left/right (
L / R ) speaker distances can
be set from 1 ft. (30 cm) to 30 ft. (9 m) in 1
ft. (30 cm ) increments.
• The center speaker (
C ) can be set from –7
ft. (2.1 m) to 0 ft. (0 m) relative to the front
left/right speakers.
• Surround left/right (
LS / RS ) speakers can
be set from –20 ft. (6.0 m) to 0 ft. (0 m) rela-
tive to the front left/right speakers.
•You can’t set the subwoofer (
SW ) distance.
4 Press (cursor left) to go back to the
speaker list if you want to modify another
speaker, or press ENTER to exit the Speaker
Distance screen.
Note
•During playback of SACD and MPEG-audio
DVD-Video discs, the effective
C , LS and RS
speaker distance settings are –3.0ft (–
0.9m) to 0.0ft (0.0m) relative to the front
left/right speakers.
DV-575A/DV-578A screen
DV-676A-S screen
DV575A KU_Mid.book 43 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
45
En
If you use a chemical-impregnated cleaning
cloth, read the instructions carefully before
use. These cloths may leave smear marks on
half-mirror finish surfaces; if this happens,
finish with a dry cloth.
Cleaning the pickup lens
The DVD player’s lens should not become dirty
in normal use, but if for some reason it should
malfunction due to dust or dirt, consult your
nearest Pioneer-authorized service center. We
do not recommend using commercially
available lens cleaners for CD players.
Condensation
Condensation may form inside the player if it is
brought into a warm room from outside, or if
the temperature of the room rises quickly.
Although the condensation won’t damage the
player, it may temporarily impair its
performance. Leave it to adjust to the warmer
temperature for about an hour before
switching on.
Moving the player
If you need to move the player, first press
 STANDBY/ON on the front panel to turn the
player off. Wait for
-OFF- to disappear from the
display, then unplug the power cable. Never lift
or move the unit during playback—discs rotate
at a high speed and may be damaged.
Screen sizes and disc formats
DVD-Video discs come in several different
screen aspect ratios, ranging from TV
programs, which are generally 4:3, to
CinemaScope widescreen movies, with an
aspect ratio of up to about 7:3.
Televisions, too, come in different aspect
ratios; ‘standard’ 4:3 and widescreen 16:9.
Widescreen TV users
If you have a widescreen TV, the TV Screen
setting (page 36) of this player should be set to
16:9 (Wide) .
When you watch discs recorded in 4:3 format,
you can use the TV controls to select how the
picture is presented. Your TV may offer various
zoom and stretch options; see the instructions
that came with your TV for details.
Please note that some movie aspect ratios are
wider than 16:9, so even though you have a
widescreen TV, these discs will still play in a
‘letter box’ style with black bars at the top and
bottom of the screen.
Standard TV users
If you have a standard TV, the TV Screen
setting (page 36) of this player should be set to
4:3 (Letter Box) or 4:3 (Pan&Scan) ,
depending on which you prefer.
Set to
4:3 (Letter Box) , widescreen discs are
shown with black bars top and bottom.
Set to
4:3 (Pan&Scan) , widescreen discs are
shown with the left and right sides cropped.
Although the picture looks larger, you don’t
actually see the whole picture.
Please note that many widescreen discs
override the player’s settings so that the disc is
shown in letter box format regardless of the
setting.
DV575A KU_Mid.book 45 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
47
En
DVD-Video regions
All DVD-Video discs carry a region mark on the
case somewhere that indicates which
region(s) of the world the disc is compatible
with. Your DVD player also has a region mark,
which you can find on the rear panel. Discs
from incompatible regions will not play in this
player. Discs marked
ALL will play in any
player.
The diagram below shows the various DVD
regions of the world.
Selecting languages using the
language code list
Some of the language options (such as ‘DVD
Language’ in the Setup Navigator) allow you to
set your prefered language from any of the 136
languages listed in the language code list on
page 48.
1 Select ‘Other Language’.
2Use the
(cursor left/right) buttons
to select either a code letter or a code
number.
3Use the
(cursor up/down) buttons
to select a code letter or a code number.
See Language code list on page 48 for a
complete list of languages and codes.
1
2
2
5
5
6
3
21
4
4
DV575A KU_Mid.book 47 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
49
En
Troubleshooting
Incorrect operation is often mistaken for trouble or malfunction. If you think that there is
something wrong with this component, check the points below. Sometimes the trouble may lie in
another component. Inspect the other components and electrical appliances being used. If the
trouble cannot be rectified after checking the items below, ask your nearest Pioneer authorized
service center or your dealer to carry out repair work.
Problem Remedy
The disc won’t play or is
automatically ejected
after loading.
• Make sure the disc is free from dirt and dust and is not damaged
(page 44).
• Make sure the disc is loaded with the label side face-up and aligned
properly in the disc tray guide.
• Incompatible region number: If the region number on a DVD-Video
disc does not match the number on the player, the disc cannot be
used (page 47).
• Condensation inside the player: Allow time for condensation to
evaporate. Avoid using the player near an air-conditioning unit.
• Disc is loaded upside down: Reload the disc with the label side face
up.
• A Super VCD that does not conform with the IEC standards might
not play normally.
DVD-Audio playback
stops.
• The disc may have been illegally copied.
Picture playback stops
and the operation
buttons cannot be used.
• Press  , then start playback again (  ).
• Press and hold the front panel  STANDBY/ON button for about 10
seconds to switch the unit off, then press again to switch back on.
• Switch the power off once, unplug from the wall socket, then plug
back in and switch on again using the front panel  STANDBY/ON
button.
New settings made in the
Setup screen menus while
a disc is playing are
ineffective.
• Some settings can be changed while a disc is playing, but are not
effective until the disc is stopped then restarted: Press  , then start
playback again (  ).
Settings are canceled. • When the power is cut due to power failure or by unplugging the
power cord, settings will be canceled: Press  STANDBY/ON on the
front panel to turn the player off. Wait for --OFF-- to disappear from
the display, then unplug the power cord.
The remote control
doesn't seem to work.
• The remote control is too far from the player, or the angle with the
remote sensor is too wide: Use the remote within its operating range
(page 18).
• The batteries are exhausted: Put in new ones (page 8).
DV575A KU_Mid.book 49 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
51
En
Cannot play multi-
channel audio
• Make sure that Audio Output Mode is set to 5.1 Channel
(page 41).
• Check that the Dolby Digital, DTS and MPEG Out settings
(pages 35–36) are suitable for your amplifier/receiver—check the
instruction manual that came with your amplifier/receiver.
• DVD-Audio and SACDs do not output multichannel digital audio.
Listen through the player’s analog outputs.
• Check that the settings in the Speaker Installation screen are
correct (page 42).
• Check the audio options available from the disc menu.
Cannot listen to high-
sampling rate audio
through the digital
output.
• Make sure that Linear PCM Out is set to Downsample Off
(page 35).
• As a copy-protection measure, some DVDs do not output 96kHz
audio. In this case, even if set to Downsample Off , the player
automatically outputs the audio at 48 kHz. This is not a malfunction.
Cannot output 192kHz or
176.4kHz digital audio.
• The player does not output digital audio at these sampling rates. The
digital output is automatically downsampled.
Cannot output 96kHz or
88.2kHz digital audio.
• Check that Linear PCM Out is set to Downsample Off (page 35).
• Some discs are digital copy protected and do not output high
sampling rate digital audio. In this case the output is automatically
downsampled.
No DTS audio output. • If this unit is connected to a non-DTS compatible amplifier or
decoder using a digital audio cable, set DTS Out to DTS
>
PCM
(page 35). If you do not do this, noise will be output when you play a
DTS disc.
• If this unit is connected to a DTS-compatible amplifier or decoder
using a digital audio cable, check the amplifier settings, and that the
cable is properly connected.
Audio mix does not
sound right or sounds
incomplete (for example,
inaudible dialog).
• Make sure that Audio Output Mode is set to 2 Channel if you've
connected to the stereo inputs on your amplifier or TV (page 41).
The audio recorded on a
Super VCD disc is not
output properly.
• If the audio is switched to [2] when playing a Super VCD that
contains only one stereo soundtrack, there may be no sound at all.
Press AUDIO to change the soundtrack.
Can’t hear effect of
Virtual Surround
• Virtual Surround does not work with SACD or DVD-Audio.
• The Virtual Surround effect is only output through the AUDIO OUT
(2ch) analog audio outputs.
• Make sure that Audio Output Mode is set to 2 Channel (page 41).
• The effectiveness of Virtual Surround varies with the disc.
Problem Remedy
DV575A KU_Mid.book 51 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
53
En
Glossary
Analog audio Direct representation of sound by an
electrical signal. See also Digital audio .
Aspect ratio The width of a TV screen relative to its
height. Conventional TVs are 4:3;
widescreen models are 16:9.
Bonus Group
(DVD-Audio
only)
An ‘extra’ group on some DVD-Audio
discs that requires a key number to
access.
Browsable
pictures
(DVD-Audio
only)
A feature of some DVD-Audio discs in
which the user can browse still pictures
recorded on the disc as the audio is
played. See also Slideshow .
Digital audio Indirect representation of sound using
numbers. See also Sampling frequency
and Analog audio .
Dolby
Digital
*1
1
A multi-channel audio encoding system
developed by Dolby Laboratories that
enables far more audio to be stored on a
disc than PCM encoding. See also PCM
(Pulse Code Modulation) .
DRM DRM (Digital Rights Management) copy
protection is a technology designed to
prevent unauthorized copying by
restricting playback, etc. of material on
devices other the PC (or other WMA
recording equipment) used to record it.
For detailed information, please see the
instruction manuals or help files that
came with your PC (or other WMA
recording equipment) and/or software.
DTS
*2
A multi-channel audio encoding system
developed by Digital Theater Systems
that enables far more audio to be stored
on a disc than PCM encoding. See also
PCM (Pulse Code Modulation) .
EXIF
(Exchangeabl
e Image File)
A file format developed by Fuji Photo
Film for digital still cameras. Digital
cameras from various manuafcturers
use this compressed file format which
carries date, time and thumbnail
information, as well as the picture data.
File
extension
A tag added to the end of a filename to
indicate the type of file. For example,
“.mp3” indicates an MP3 file.
ISO 9660
format
International standard for the volume
and file structure of CD-ROM discs.
JPEG A standard file format used for still
images. JPEG files are identified by the
file extension “.jpg”.
MP3 MP3 (MPEG1 audio layer 3) is a
compressed stereo audio file format.
Files are recognized by their file
extension “.mp3”.
MPEG audio An audio format used on Video CD/
Super VCDs and some DVD discs.
Packed PCM
(DVD-Audio
only)
A lossless compression system that
enables more PCM audio to be stored
on a DVD-Audio disc than would
otherwise be possible.
PBC
(PlayBack
Control)
A system of navigating a Video CD/
Super VCD through on-screen menus
recorded onto the disc.
PCM
(Pulse Code
Modulation)
Digital audio encoding system found on
CDs. Good quality, but requires a lot of
data compared to Dolby Digital, DTS
and MPEG encoded audio. See also
Digital audio .
Progressive
scan video
All the lines that make up a video
picture are updated in one pass
(compared to interlace which takes two
passes to update the whole picture).
Regions
(DVD-Video
only)
These associate DVD-Video discs and
players with particular areas of the
world. See DVD-Video regions on
page 47 for more information.
Sampling
frequency
The rate at which sound is measured to
be turned into digital audio data. The
higher the rate, the better the sound
quality. CD is 44.1 kHz; DVD can be up
to 96 kHz. See also Digital audio .
DV575A KU_Mid.book 53 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
55
En
Specifications
General
System . . . . . . . . . . . . . . . . . . . . . . . . DVD player
Power requirements
DV-575A / DV-578A . . . . . . . . . . .AC 120 V, 60 Hz
DV-676A-S
. . . . . . AC 110–127/220–240 V, 50/60 Hz
Power consumption
DV-575A / DV-578A . . . . . . . . . . . . . . . . . . . .11 W
DV-676A-S. . . . . . . . . . . . . . . . . . . . . . . . . . . .12 W
Power consumption (standby)
DV-575A / DV-578A . . . . . . . . . . . . . . . . . . 0.07 W
DV-676A-S. . . . . . . . . . . . . . . . . . . . . . . . . . 0.12 W
Weight . . . . . . . . . . . . . . . . . . . 2.1 kg / 4 lb 10 oz
Dimensions . .420 (W) x 55 (H) x 243 (D) mm
. . . . . . . . . . . . . . . (16.5 (W) x 2.2 (H) x 9.6 (D) in.)
Operating temperature . . . . . . . +5°C to +35°C
(+41°F to +95°F)
Operating humidity . . . . . . . . . . . . . . . 5% to 85%
(no condensation)
Component video output
Y (luminance) - Output level . . . . . . 1 Vp-p (75 )
P
B
(color) - Output level . . . . . . . 0.7 Vp-p (75 )
P
R
(color) - Output level . . . . . . . 0.7 Vp-p (75 )
Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA
S-video output
Y (luminance) - Output level . . . . . . 1 Vp-p (75 )
C (color) - Output level . . . . . . 286 mVp-p (75 )
Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .S-video
Video output
Output level . . . . . . . . . . . . . . . . . . . 1 Vp-p (75 )
Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA
Audio output (1 stereo pair)
Output level . . . . . . . . . . . . .During audio output
200 mVrms (1 kHz, –20 dB)
Number of channels . . . . . . . . . . . . . . . . . . . . . . 2
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA
Audio output (multi-channel / L, R, C, SW,
LS, RS)
Output level. . . . . . . . . . . . . During audio output
200 mVrms (1 kHz, –20 dB)
Number of channels . . . . . . . . . . . . . . . . . . . . . 6
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . .RCA jack
Digital audio characteristics
Frequency response . . . . . . . . . . 4 Hz to 44 kHz
(DVD fs: 96 kHz)
4 Hz to 88 kHz (DVD-Audio fs: 192 kHz)
S/N ratio . . . . . . . . . . . . . . . . . . . . . . . . . . .115 dB
Dynamic range . . . . . . . . . . . . . . . . . . . . . .101 dB
Total harmonic distortion. . . . . . . . . . . . 0.0020 %
Wow and flutter . . . . . . . .Limit of measurement
(±0.001% W. PEAK) or lower
Digital output
Coaxial digital output jack . . . . . . . . . . .RCAjack
Optical digital output . . . . . . .Optical digital jack
Accessories
Audio/video cable. . . . . . . . . . . . . . . . . . . . . . . . 1
Power cable
DV-676A-S (Singapore/Taiwan model) . . . . . . 2
Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . 1
AA/R6P dry cell batteries . . . . . . . . . . . . . . . . . 2
Operating Instructions
Warranty card (
U.S. model only
).. . . . . . . . . . 1
Front panel button names sticker
(Singapore/Taiwan models only)
. . . . . . . . . . 1
Remote control overlay
(Singapore/Taiwan models only)
. . . . . . . . . . 1
The specifications and design of this product are subject to
change without notice, due to improvement.
Published by Pioneer Corporation.
Copyright © 2004 Pioneer Corporation.
All rights reserved
DV575A KU_Mid.book 55 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals

Before you start01
8
En
What’s in the box
Please confirm that the following accessories
are in the box when you open it.
• Remote control
• AA/R6P dry cell batteries x2
• Audio/video cable (red/white/yellow plugs)
• Power cable
• Operating instructions
• Warranty card (DV-575A and DV-578A
model only)
• Front panel button names sticker
—
Chinese language button names for the
front panel controls.
• Remote control overlay
— Place the overlay
on the remote control to be able to read the
buttons in Chinese.
Putting the batteries in the remote
• Open the battery compartment cover
and insert the batteries as shown.
Use two AA/R6P batteries and follow the
indications (
 ,  ) inside the compartment.
Close the cover when you’re finished.
Important
Incorrect use of batteries can result in hazards
such as leakage and bursting. Please observe
the following:
• Don’t mix new and old batteries together.
• Don’t use different kinds of battery
together—although they may look similar,
different batteries may have different
voltages.
•Make sure that the plus and minus ends of
each battery match the indications in the
battery compartment.
• Remove batteries from equipment that
isn’t going to be used for a month or more.
• When disposing of used batteries, please
comply with governmental regulations or
environmental public instruction’s rules
that apply in your country or area.
Hints on installation
We want you to enjoy using this product for
years to come, so please use the following
guidelines when choosing a suitable location:
Do...
• Use in a well-ventilated room.
•Place on a solid, flat, level surface, such as
a table, shelf or stereo rack.
Don’t...
• Use in a place exposed to high
temperatures or humidity, including near
radiators and other heat-generating
appliances.
•Place on a window sill or a place where the
player will be exposed to direct sunlight.
• Use in an excessively dusty or damp
environment.
• Place directly on top of an amplifier, or
other component in your stereo system
that becomes hot in use.
•Use near a television or monitor as you may
experience interference—especially if the
television uses an indoor antenna.
• Use in a kitchen or other room where the
player may be exposed to smoke or steam.
• Use on a thick rug or carpet, or cover with
cloth—this may prevent proper cooling of
the unit.
DV575A KU_Mid.book 8 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
10
En
About WMA
The Windows Media
®
logo printed on the box
indicates that this player can playback
Windows Media Audio content.
WMA is an acronym for Windows Media Audio
andrefers to an audiocompression technology
developed by Microsoft Corporation. WMA
content can be encoded by using Windows
Media
®
Player version 7, 7.1, Windows Media
®
Player for Windows
®
XP, or Windows Media
®
Player 9 Series.
JPEG file compatibility
• Compatible formats: Baseline JPEG and
EXIF 2.2* still image files up to a resultion
of 3072 x 2048.
*
• Progressive JPEG compatible: No
• File extensions: .jpg (must be used for the
player to recognize JPEG files – do not use
for other file types)
• File structure: Up to 299 folders; up to 648
folders and files combined
PC-created disc compatibility
Discs recorded using a personal computer
may not be playable in this unit due to the
setting of the application software used to
create the disc. In these particular instances,
check with the software publisher for more
detailed information.
Discs recorded in packet write mode (UDF
format) are not compatible with this player.
Check the DVD-R/RW or CD-R/RW software
disc boxes for additional compatibility
information.
DV575A KU_Mid.book 10 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals

Connecting up 02
11
En
Chapter 2
Connecting up
Easy connections
The setup described here is a basic setup that allows you to play discs using just the cables
supplied with the player. In this setup, stereo audio is played through the speakers in your TV.
Important
•This player is equipped with copy protection technology. Do not connect this player to your TV
via a VCR using audio/video or S-video cables, as the picture from this player will not appear
properly on your TV. (This player may also not be compatible with some combination TV/VCRs
for the same reason; refer to the manufacturer for more information.)
• When connecting to your TV as shown above, do not set the
Component Out setting (see
Video Output settings on page 36) to Progressive .
S
VIDEO OUT
AUDIO OUT (5.1 ch )
CENTER
COMPONENT VIDEO OUT
AUDIO OUT ( 2 ch )
FRONT
SURROUND
SUB
WOOFER
COAXIAL
OPTICAL
DIGITAL AUDIO OUT
VIDEO
OUT
PR
PB
Y
LL
R
R
AC IN
L
R
Yellow
White
Red
TV
A/V IN
To power
outlet
DV575A KU_Mid.book 11 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
13
En
Watching progressive scan video
from the component video outputs
This player can output progressive scan video
from the component video output. Compared
to interlace video, progressive scan video
effectively doubles the scanning rate of the
picture, resulting in a very stable, flicker-free
image.
To set up the player for use with a progressive
scan TV, see
Video Output settings on page 36.
When the player is set to output progressive
scan video, the
PRGSVE indicator lights in the
front panel display.
Important
• If you connect a TV that is not compatible
with a progressive scan signal and switch
the player to progressive, you will not be
able to see any picture at all. In this case,
switch everything off and reconnect using
the supplied video cable (see
Easy
connections
on page 11), then switch back
to
Interlace (see below).
Switching the video output to interlace
using the front panel controls
Switch the player to standby then, using the
front panel controls, press
 STANDBY/ON
while pressing
 to switch the player back to
Interlace .
Compatibility of this player with
progressive-scan and high-definition TVs
This player is compatible with progressive
video Macro Vision System Copy Guard.
Consumers should note that not all high-
definition television sets are fully compatible
with this product and may cause artifacts to be
displayed in the picture. In case of 525
progressive scan picture problems, it is
recommended that the user switch the
connection to the ‘standard definition’ output
(Interlace). If there are questions regarding our
TV set compatibility with this model, please
contact our customer service center.
This player is compatible with the following
Pioneer displays and monitors:
Plasma display (DV-575A, DV-578A )
PDP-505HD, PDP-5030HD, PDP-4330HD,
PDP-5040HD, PDP-4340HD, Pro-1000HD, Pro-
800HD, Pro-1000HDI, Pro-800HDI, Pro-
1110HD, Pro-910HD, PDP-4300, PDP-5031
Projection monitor receiver (DV-575A, DV-578A )
SD-533HD5, SD-643HD5, Pro-710HD, Pro-
610HD, Pro-510HD, Pro-720HD, Pro-620HD,
Pro-520HD, Pro-730HD, Pro-630HD, Pro-
530HD, Pro-730HDI, Pro-530HDI
Plasma display (DV-676A-S)
PDP-502MX, PDP-503HDG, PDP-433HDG,
PDP-5040HD, PDP-4340HD
Projection monitor receiver (DV-676A-S)
SD-532HD5, SD-533HD5
FL DIMMER





 OPEN/CLOSE
STANDBY/ON
DV-575A / DV-676A-S
STANDBY/ON
DV575A KU_Mid.book 13 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
15
En
Connecting the digital output
This player has both optical and coaxial-type
digital audio outputs for connection to an AV
receiver. Connect whichever is convenient.
Depending on the capabilities of your AV
receiver, you might have to set up this player to
output only digital audio in a compatible
format. See
Digital Audio Out settings on
page 35 and refer to the operating instructions
that came with your AV receiver.
•Connect one of the DIGITAL AUDIO OUT
jacks on this player to a digital input on
your AV receiver.
For an optical connection, use an optical cable
(not supplied) to connect the
OPTICAL
DIGITAL AUDIO OUT
jack to an optical input
on your AV receiver.
For a coaxial connection, use a coaxial cable
(similar to the supplied video cable) to connect
the
COAXIAL DIGITAL AUDIO OUT jack to a
coaxial input on your AV receiver.
S
VIDEO OUT
AUDIO OUT (5.1 ch )
CENTER
COMPONENT VIDEO OUT
AUDIO OUT ( 2 ch )
FRONT
SURROUND
SUB
WOOFER
COAXIAL
OPTICAL
DIGITAL AUDIO OUT
VIDEO
OUT
P R
P B
Y
LL
R
R
AV receiver
DIGITAL IN
(OPTICAL)
DIGITAL IN
(COAXIAL)
DV575A KU_Mid.book 15 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Controls and displays
03
17
En
Display
1 V-PART
Lights when playing a video part of a DVD disc.
2 PRGSVE
Lights when the player is set to output progres-
sive scan video (see
Component Out on
page 36 ).
3 GRP
Indicates that the character display is showing
a DVD-Audio group number.
4 TITLE
Indicates that the character display is showing
a DVD title number.
5 TRK
Indicates that the character display is showing
a DVD-Audio, SACD, CD or Video CD/Super
VCD track number.
6 CHP
Indicates that the character display is showing
a DVD chapter number.
7 5.1CH
Lights when analog 5.1 channel output is
selected (see
Audio Output Mode on page 41).
8 D.MIX
During multichannel audio playback, indicates
that the output signal has been “downmixed”
from the original audio source. This is an auto-
matic function performed by the player in order
to present the most appropriate audio mix to
the speakers present in your system.
9
Lights in any of the repeat play modes.
10 REMAIN
Indicates that the character display is showing
the disc or title/chapter/track remain time.
11 Character display
12
Lights during multi-angle scenes on a DVD
disc.
13  and 
Indicates whether a disc is playing or paused.
14 DTS
Lights when a DTS soundtrack is playing.
15 D
Lights when a Dolby Digital soundtrack is
playing.
1415 1113 12
2 43 5 5 6 7 8 9 10
1
DV575A KU_Mid.book 17 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Getting started
04
19
En
Chapter 4
Getting started
Switching on
After making sure that everything is connected
properly and that the player is plugged in,
press
 STANDBY/ON on the front panel or
remote control to switch the player on.
Also, switch on your TV and make sure that it is
set to the input you connected the DVD player
to.
FAQ
• My DVD player switches on but there is
nothing displayed on my TV.
Make sure that the TV is set to the correct
video input (not a TV channel). For
example, if you connected this player to the
VIDEO 1 inputs on your TV, switch your TV
to
VIDEO 1 .
Note
•This player features a screen saver and an
auto power off function. If the player is
stopped and no button is pressed for
around five minutes, the screen saver
starts. If the disc tray is closed but no disc
is playing and no control is pressed for
about 30 minutes, the player automatically
goes into standby.
Using the on-screen displays
For ease of use, this player makes extensive
use of graphical on-screen displays (OSDs).
All the screens are navigated in basically the
same way, using the cursor buttons (
///

) to change the highlighted item and
pressing
ENTER to select it.
FL DIMMER
STANDBY/ON
DV-575A / DV-676A-S
STANDBY/ON
Button What it does
HOME
MENU
Display/exit the on-screen display.
/// Changes the highlighted menu
item.
ENTER
Selects the highlighted menu
item (both
ENTER buttons on the
remote work in exactly the same
way).
RETURN Returns to the main menu
without saving changes.
ENTER
GUIDE RETURN
ENTER
HOME
MENU
RETURN
 


OPEN/CLOSE
TOP MENU MENU
HOME
MENU RETURN
ENTER
DV-578A
DV575A KU_Mid.book 19 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Getting started
04
21
En
1 If the player isn’t already on, press
 STANDBY/ON to switch it on.
If you’re playing a DVD or Video CD/Super VCD,
also turn on your TV and make sure that it is set
to the correct video input.
2 Press  OPEN/CLOSE to open the disc
tray.
3 Load a disc.
Load a disc with the label side facing up, using
the disc tray guide to align the disc (if you’re
loading a double-sided DVD disc, load it with
the side you want to play face down).
4 Press  (play) to start playback.
If you’re playing a DVD or Video CD/Super VCD,
an on-screen menu may appear. See
DVD disc
menus
on page 22 and Video CD/Super VCD
PBC menus
on page 23 for more on how to
navigate these.
•If you’re playing an MP3/WMA disc, it may
take a few seconds before playback starts.
Note
• You may find with some DVD discs that
some playback controls don’t work in
certain parts of the disc. This is not a
malfunction.
Basic playback controls
The table below shows the basic controls on
the remote for playing discs. The following
chapter covers other playback features in more
detail.
0
123
456
789
STANDBY/ON
OPEN/CLOSE
ENTER
ENTER


/ /






Button What it does
 Starts playback.
If the display shows RESUME or
LAST MEM playback starts from
the resume or last memory point
(see also Resume and Last Memory
on page 22.)
 Pauses a disc that’s playing, or
restarts a paused disc.
 Stops playback.
See also Resume and Last Memory
on page 22.

(remote
only)
Press to start fast reverse scanning.
Press
 (play) to resume normal
playback.

(remote
only)
Press to start fast forward scanning.
Press  (play) to resume normal
playback.
DV575A KU_Mid.book 21 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Getting started
04
23
En
Video CD/Super VCD PBC menus
Some Video CD/Super VCDs have menus from
which you can choose what you want to watch.
These are called PBC (Playback control)
menus.
You can play a PBC Video CD/Super VCD
without having to navigate the PBC menu by
starting playback using a number button to
select a track, rather than the
 (play) button.
Button What it does
TOP MENU Displays the ‘top menu’ of a DVD
disc—this varies with the disc.
MENU Displays a DVD disc menu—this
varies with the disc and may be
the same as the ‘top menu’.
/// Moves the cursor around the
screen.
ENTER Selects the current menu option.
RETURN Returns to the previously dis-
played menu screen. On some
DVD-Audio discs featuring
browsable pictures, press to dis-
play the browser screen.
Numbers
(remote
only)
Highlights a numbered menu
option (some discs only). Press
ENTER to select.
Button What it does
RETURN Displays the PBC menu.
Numbers
(remote
only)
Use to enter a numbered menu
option. Press
ENTER
to select.
 Displays the previous menu page
(if there is one).
 Displays the next menu page (if
there is one).
0
123
456
789
RETURN

ENTER
ENTER
DV575A KU_Mid.book 23 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Playing discs
05
25
En
Chapter 5
Playing discs
Note
• Many of the functions covered in this
chapter apply to DVD and SACD discs,
Video CDs/Super VCDs, CDs and WMA/
MP3 JPEG discs, although the exact
operation of some varies slightly with the
kind of disc loaded.
• Some DVDs restrict the use of some
functions (random or repeat, for example)
in some or all parts of the disc. This is not a
malfunction.
•When playing Video CD/Super VCDs, some
of the functions are not available during
PBC playback. If you want to use them,
start the disc playing using a number
button to select a track.
Scanning discs
You can fast-scan discs forward or backward at
four different speeds.
1 During playback, press  or  to
start scanning.
• There is no sound while scanning DVDs
(including DVD-Audio) and Video CD/
Super VCDs.
2 Press repeatedly to increase the
scanning speed.
• The scanning speed is shown on-screen.
3 To resume normal playback, press 
(play).
• When scanning a Video CD/Super VCD
playing in PBC mode or a WMA/MP3 track,
playback automatically resumes at the end
or beginning of the track.
• Depending on the disc, normal playback
may automatically resume when a new
chapter is reached on a DVD disc.
Playing in slow motion
You can play DVD-Videos and DVD-R/RW at
four different slow motion speeds, forwards
and backwards. Video CD/Super VCDs can be
played at four different forward slow motion
speeds.
1 During playback, press  (pause).
2 Press and hold
/ or / until
slow motion playback starts.
• The slow motion speed is shown on-
screen.
• There is no sound during slow motion
playback.
3 Press repeatedly to change the slow
motion speed.
4 To resume normal playback, press

(play).
• Depending on the disc, normal playback
may automatically resume when a new
chapter is reached.
Frame advance/frame reverse
You can advance or back up DVD-Video and
DVD-R/RW discs frame-by-frame. With Video
CD/Super VCDs you can only use frame
advance.
DV575A KU_Mid.book 25 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Playing discs
05
27
En
• Title – Titles from a DVD-Video disc.
•
Chapter – Chapters from the current title
of a DVD-Video disc.
•
Track – Tracks from a Video CD/Super VCD
disc.
•
Time – Thumbnails from a Video CD/Super
VCD disc at 10 minute intervals.
•
Original: Title – Original titles from a VR
mode DVD-RW disc.
•
Playlist: Title – Playlist titles from a VR
mode DVD-RW disc.
•
Original: Time – Thumbnails from the
Original content at 10 minute intervals.
•
Playlist: Time – Thumbnails from the
Playlist at 10 minute intervals.
The screen shows up to six moving thumbnail
images displayed one after another. To display
the previous/next six thumbnails, press
 /
 (you don’t have to wait for all the
thumbnails to finish playing to display the
previous/next page).
3 Select the thumbnail image for what
you want to play.
You can use either the cursor buttons ( //
/
) and ENTER to select a thumbnail, or the
number buttons.
To select using the number buttons, enter a
two-digit number then press
ENTER .
Tip
•Another way to find a particular place on a
disc is to use one of the search modes. See
Searching a disc on page 31.
Browsing WMA, MP3 and JPEG
files with the Disc Navigator
Use the Disc Navigator to find a particular file
or folder by filename.
1 Press HOME MENU and select ‘Disc
Navigator’ from the on-screen menu.
2 Use the cursor buttons (
/// )
and ENTER to navigate.
Use the cursor up/down buttons ( / ) to
move up and down the folder/file list.
Use the cursor left button (
 ) to return to the
parent folder.
Use
ENTER or cursor right (  ) to open a
highlighted folder.
•You can also return to the parent folder by
going to the top of the list to the ‘
.. ’ folder,
then pressing
ENTER .
01
04
02
05
03
06
Disc Navigator: Title
01- 49: --
00:00/ 00:00 0kbps
Folder1
Folder2
Folder3
Folder4
DV575A KU_Mid.book 27 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Playing discs
05
29
En
1During playback, press PLAY MODE and
select ‘Repeat’ from the list of functions on
the left.
2 Select a repeat play option.
If program play is active, select Program
Repeat
to repeat the program list, or Repeat
Off
to cancel.
The repeat options available depend on the
kind of disc loaded. For example, for DVD-
Video and DVD-RW discs, you can select
Title
Repeat
or Chapter Repeat (or Repeat Off ).
• For DVD-Audio discs, select
Group
Repeat
or Track Repeat (or Repeat Off ).
•For SACDs,CDs and Video CD/Super
VCDs, select
Disc Repeat or Track Repeat
(or
Repeat Off ).
Using random play
Use the random play function to play titles or
chapters (DVD-Video), Groups (DVD-Audio), or
tracks (DVD-Audio, SACD, CD, Video CD/
Super VCD) at random. (Note that the same
track/title/chapter may play more than once.)
You can set the random play option when a
disc is playing or stopped.
Important
• Random play remains in effect until you
select
Random Off from the random play
menu options.
•You can’t use random play with VR format
DVD-RW discs, Video CD/Super VCDs
playing in PBC mode, WMA/MP3 discs, or
while a DVD disc menu is being displayed.
• You can't use random play together with
program or repeat play.
1 Press PLAY MODE and select ‘Random’
from the list of functions on the left.
2 Select a random play option.
The random play options available depend on
the kind of disc loaded. For example, for DVD-
Video discs, you can select
Random Title or
Random Chapter , (or Random Off ).
• For DVD-Audio discs, select
Random
Group
or Random Track , (or Random
Off
).
•For CDs, SACDs and Video CD/Super
VCDs, select
On or Off to switch random
play on or off.
DV575A KU_Mid.book 29 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Playing discs
05
31
En
Tip
•Use the following controls during program
play:
Other functions available from the
program menu
There are a number of other options in the
program menu in addition to Create/Edit.
•
Playback Start – Starts playback of a
saved program list
•
Playback Stop – Turns off program play,
but does not erase the program list
•
Program Delete – Erases the program list
and turns off program play
Searching a disc
You can search DVD-Video discs by title or
chapter number, or by time; DVD-Audio discs
can be searched by group or track number;
SACDs by track number, CDs and Video CD/
Super VCDs by track number or time.
Important
• Search functions are not available with
Video CD/Super VCDs in PBC mode, or
with WMA/MP3 discs.
1 Press PLAY MODE and select ‘Search
Mode’ from the list of functions on the left.
2 Select a search mode.
The search options available depend on the
kind of disc loaded.
• The disc must be playing in order to use
time search.
3Use the number buttons to enter a title,
chapter or track number, or a time.
• For a time search, enter the number of
minutes and seconds into the currently
playing title (DVD) or track (CD/Video CD/
Super VCD) you want playback to resume
from. For example, press
4 , 5 , 0 , 0 to have
playback start from 45 minutes into the
disc. For 1 hour, 20 minutes and 30
seconds, press
8 , 0 , 3 , 0 .
• Some DVD-Audio discs feature pages of
browsable pictures. Enter the page
number you want.
4 Press ENTER to start playback.
Switching subtitles
Some DVD-Video discs have subtitles in one or
more languages; the disc box will usually tell
you which subtitle languages are available. You
can switch subtitle language during playback.
1 Press SUBTITLE repeatedly to select a
subtitle option.
Button What it does
PLAY
MODE
Save the program list and exit
the program edit screen without
starting playback ( HOME MENU
does the same).
 Skip to the next step in the
program list.
DV575A KU_Mid.book 31 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Audio Settings and Video Adjust menus
06
33
En
Chapter 6
Audio Settings and Video
Adjust menus
Audio Settings menu
The Audio Settings menu offers features for
adjusting the way discs sound.
1 Press HOME MENU and select ‘Audio
Settings’ from the on-screen display.
2Select and change settings using the
/
//
(cursor) buttons, and ENTER.
Audio DRC
• Settings: High , Medium , Low , Off
(default)
When watching Dolby Digital DVDs at low
volume, it’s easy to lose the quieter sounds
completely—including some of the dialog.
Switching Audio DRC (Dynamic Range
Control) to on can help by bringing up the
quieter sounds, while controlling loud peaks.
How much of a difference you hear depends on
the material you’re listening to. If the material
doesn’t have wide variations in volume, you
may not notice much change.
Note
• Audio DRC is only effective with Dolby
Digital audio sources.
• Audio DRC is only effective through the
digital output when
Digital Out is set to
On , and Dolby Digital Out is set to Dolby
Digital > PCM
(see Digital Audio Out
settings
on page 35).
• The effect of Audio DRC also depends on
your speakers and AV receiver settings.
Virtual Surround
• Settings: On , Off (default)
Switch on Virtual Surround to enjoy realistic
surround sound effects from just two speakers.
Tip
• You can also use the SURROUND button
on the remote control to switch Virtual
Surround on.
Note
• 96kHz Linear PCM audio is automatically
downsampled to 48kHz if Virtual Surround
is switched on.
• The
Audio Output Mode (see page 41)
must be set to
2 Channel in order to be
able to use Virtual Surround.
DV575A KU_Mid.book 33 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
35
En
Chapter 7
Initial Settings menu
Using the Initial Settings menu
The Initial Settings menu provides audio and
video output settings, parental lock settings,
and display settings, among others.
If an option is grayed out it means that it
cannot be changed at the current time. This is
usually because a disc is playing. Stop the
disc, then change the setting.
1 Press HOME MENU and select ‘Initial
Settings’.
2 Use the cursor buttons and ENTER to
select the setting and option you want to
set.
All the settings and options are explained on
the following pages.
Note
• In the table below, the default setting is
shown in
bold : other settings are shown in
italics .
•The Digital Audio Out settings only need to
be set if you have connected the digital
output of this player to an AV receiver, or
other equipment.
• Check the operating instructions supplied
with your other equipment to see which
digital audio formats it’s compatible with.
•Some settings, such as
TV Screen , Audio
Language
and Subtitle Language may be
overridden by the DVD disc. Often these
settings can also be made from the DVD
disc menu.
Digital Audio Out settings
Setting Option What it means
Digital Out On
Digital audio is output from the digital outputs.
Note that there is no digital output when playing SACDs and
some DVD-Audio discs regardless of this setting.
Off
No digital audio output.
Dolby Digital Out Dolby Digital
Dolby Digital encoded digital audio is output when playing a
Dolby Digital DVD disc.
Dolby Digital > PCM
Dolby Digital audio is converted to PCM audio before being
output.
DTS Out DTS
DTS encoded digital audio is output when playing a DTS disc.
(Noise will be output if your amplifier/receiver is not compatible
with DTS audio.)
DTS > PCM
DTS audio is converted to PCM audio before being output.
DV575A KU_Mid.book 35 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
37
En
Display settings
Options settings
Subtitle Language English
If there is are English subtitles on the disc then they will be
displayed.
Languages as displayed
If there is the subtitle language selected on the disc, then it will
be displayed.
Other Language
Select to choose a language other than the ones displayed (see
page 47).
DVD Menu Lan-
guage
w/Subtitle Lang.
DVD disc menus will be displayed in the same language as
your selected subtitle language, if possible.
Languages as displayed
DVD disc menus will be displayed in the selected language, if
possible.
Other Language
Select to choose a language other than the ones displayed (see
page 47).
Subtitle Display On
Subtitles are displayed according to your selected subtitle
language (see above).
Off
Subtitles are always off by default when you play a DVD disc
(note that some discs override this setting).
Setting Option What it means
Setting Option What it means
OSD Language English
On-screen displays of the player are in English.
Languages as displayed
On-screen displays are shown in the language selected.
Angle Indicator On
A camera icon is displayed on-screen during multi-angle
scenes on a DVD disc.
Off
No multi-angle indication is shown.
Setting Option What it means
Parental Lock –
See Parental Lock on page 40.
DVD Playback
Mode
DVD-Audio
All material on a DVD-Audio disc is playable.
DVD-Video
Only the DVD-Video part of a DVD-Audio disc is playable.
DV575A KU_Mid.book 37 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
39
En
About the audio output settings
The table below shows how the audio settings you make in the Initial Settings menu (see page 35)
affect the output from the 2 channel and the 5.1 channel analog outputs, and from the digital
outputs with various types of disc.
*
1
When Audio Output Mode is set to 2 Channel , the AUDIO OUT (5.1ch) FRONT L / R jacks act as a second pair
of stereo audio outputs.
*
2
Dolby Digital > PCM , MPEG > PCM or DTS > PCM setting (pages 35–36)
*
3
Dolby Digital , MPEG or DTS setting (pages 35–36)
*
4
Discs that prohibit downmixing will be output as 5.1 channel even if 2 Channel is selected as the Audio Output
Mode setting (see page 41).
*
5
Discs that prohibit downmixing also mute the digital output.
*
6
When Audio Output Mode is set to 5.1 Channel , mono sources are heard from the center speaker only.
Disc audio format Player setting
Front L / R
–
–
–
–
–
–
–
–
–
–
–
––
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
Surround L/R,
Center, LFE
–
Front L / R
Front L / R
Front L / R
Left / Right Left / Right
Left / Right Left / Right
Left / Right
*6
Left / Right
Left / Right
Left / Right
Left / Right
Left / Right
2ch downmix
2ch downmix
2ch downmix
*4
2ch downmix
2ch downmix
Front L / R
2ch downmix
Front L / R
2ch downmix
2 Ch
5.1 Ch
2 Ch
5.1 Ch
Front L/R
analog outputs
*1
Surround L/R
Center, LFE, outputs
*1
Digital outputs
PCM convert
*2
Bitstream
*3
Dolby Digital
Dolby Digital
karaoke
2 Ch / 5.1 Ch
2 Ch / 5.1 Ch
2 Ch / 5.1 Ch
2 Ch / 5.1 Ch
2 Ch / 5.1 Ch
Linear PCM
2 Ch
5.1 Ch
DTS
MPEG
2 Ch
5.1 Ch
DVD-Audio
2 Ch
5.1 Ch
Super Audio CD
2 Ch
5.1 Ch
DTS CD
CD
Video CD
DVD-RW
(VR mode)
DVD
Dolby Digital
–
2ch downmix
2ch downmix
*5
2ch downmix
*5
DTS
DTS
Dolby Digital
Left / Right
Left / Right Left / Right
Left / Right Left / Right
Dolby Digital
MPEG or PCM
MPEG
DV575A KU_Mid.book 39 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
41
En
The new Country code is set and you will return
to the Options menu screen. Note that the new
Country code doesn’t take effect until the next
disc is loaded (or the current disc is reloaded).
DTS Downmix
• Default setting: Stereo
If you’ve selected DTS > PCM in DTS Out on
page 35 or
2 Channel in Audio Output Mode on
page 41, you can choose the way the signal is
downmixed to PCM audio.
Stereo will
downmix the DTS signal to 2-channel stereo,
whereas
Lt/Rt will downmix to a 2-channel
signal compatible with Dolby surround matrix
decoders. (This allows you to hear surround
sound if your AV receiver or amplifier has Dolby
Pro Logic capability.)
Audio Output Mode
• Default setting: 2 Channel
If you connected this player to your amplifier
using the 5.1 channel analog outputs (front,
surround, center and subwoofer outs), set this
to
5.1 Channel ; if you connected only the
stereo outs, set to
2 Channel .
Note
•Even if you set Audio Output Mode to 5.1
Channel
, you’ll only get sound from all
speakers when playing a 5.1 channel multi-
channel disc.
• When set to
5.1 Channel , only the front
left/right channels are output from the
AUDIO OUT (2ch) jacks. Change to 2
Channel
if you want to listen to downmixed
stereo audio (for example, because you are
listening through the TV’s built-in
speakers).
•When set to
5.1 Channel there is no digital
output when playing DVD-Audio.
•If you set to
2 Channel , Dolby Digital, DTS
and MPEG audio is mixed down to two
channels so you still hear all the audio
recorded on the disc. With DTS encoded
audio, you can choose how the signal is
downmixed to PCM audio. See
DTS
Downmix
above to change the downmix
setting.
• Some DVD-Audio discs don’t allow down-
mixing of audio. These discs always output
multi-channel audio regardless of the
setting made here.
DV575A KU_Mid.book 41 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Initial Settings menu
07
43
En
1Use the / (cursor up/down) to select
a speaker.
• The L and R speakers are paired; you can’t
set them differently.
2 Press  (cursor right) to change the
speaker distance for the highlighted
speaker.
3 Use the
/ (cursor up/down) to
change the distance.
•When you change the distance settings of
the front left (
L ) or front right ( R ) speakers,
all the other speaker distances change
relative to it.
•Front left/right (
L / R ) speaker distances can
be set from 1 ft. (30 cm) to 30 ft. (9 m) in 1
ft. (30 cm ) increments.
• The center speaker (
C ) can be set from –7
ft. (2.1 m) to 0 ft. (0 m) relative to the front
left/right speakers.
• Surround left/right (
LS / RS ) speakers can
be set from –20 ft. (6.0 m) to 0 ft. (0 m) rela-
tive to the front left/right speakers.
•You can’t set the subwoofer (
SW ) distance.
4 Press  (cursor left) to go back to the
speaker list if you want to modify another
speaker, or press ENTER to exit the Speaker
Distance screen.
Note
•During playback of SACD and MPEG-audio
DVD-Video discs, the effective
C , LS and RS
speaker distance settings are –3.0ft (–
0.9m) to 0.0ft (0.0m) relative to the front
left/right speakers.
DV-575A/DV-578A screen
DV-676A-S screen
DV575A KU_Mid.book 43 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
45
En
If you use a chemical-impregnated cleaning
cloth, read the instructions carefully before
use. These cloths may leave smear marks on
half-mirror finish surfaces; if this happens,
finish with a dry cloth.
Cleaning the pickup lens
The DVD player’s lens should not become dirty
in normal use, but if for some reason it should
malfunction due to dust or dirt, consult your
nearest Pioneer-authorized service center. We
do not recommend using commercially
available lens cleaners for CD players.
Condensation
Condensation may form inside the player if it is
brought into a warm room from outside, or if
the temperature of the room rises quickly.
Although the condensation won’t damage the
player, it may temporarily impair its
performance. Leave it to adjust to the warmer
temperature for about an hour before
switching on.
Moving the player
If you need to move the player, first press
 STANDBY/ON on the front panel to turn the
player off. Wait for
-OFF- to disappear from the
display, then unplug the power cable. Never lift
or move the unit during playback—discs rotate
at a high speed and may be damaged.
Screen sizes and disc formats
DVD-Video discs come in several different
screen aspect ratios, ranging from TV
programs, which are generally 4:3, to
CinemaScope widescreen movies, with an
aspect ratio of up to about 7:3.
Televisions, too, come in different aspect
ratios; ‘standard’ 4:3 and widescreen 16:9.
Widescreen TV users
If you have a widescreen TV, the TV Screen
setting (page 36) of this player should be set to
16:9 (Wide) .
When you watch discs recorded in 4:3 format,
you can use the TV controls to select how the
picture is presented. Your TV may offer various
zoom and stretch options; see the instructions
that came with your TV for details.
Please note that some movie aspect ratios are
wider than 16:9, so even though you have a
widescreen TV, these discs will still play in a
‘letter box’ style with black bars at the top and
bottom of the screen.
Standard TV users
If you have a standard TV, the TV Screen
setting (page 36) of this player should be set to
4:3 (Letter Box) or 4:3 (Pan&Scan) ,
depending on which you prefer.
Set to
4:3 (Letter Box) , widescreen discs are
shown with black bars top and bottom.
Set to
4:3 (Pan&Scan) , widescreen discs are
shown with the left and right sides cropped.
Although the picture looks larger, you don’t
actually see the whole picture.
Please note that many widescreen discs
override the player’s settings so that the disc is
shown in letter box format regardless of the
setting.
DV575A KU_Mid.book 45 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
47
En
DVD-Video regions
All DVD-Video discs carry a region mark on the
case somewhere that indicates which
region(s) of the world the disc is compatible
with. Your DVD player also has a region mark,
which you can find on the rear panel. Discs
from incompatible regions will not play in this
player. Discs marked
ALL will play in any
player.
The diagram below shows the various DVD
regions of the world.
Selecting languages using the
language code list
Some of the language options (such as ‘DVD
Language’ in the Setup Navigator) allow you to
set your prefered language from any of the 136
languages listed in the language code list on
page 48.
1 Select ‘Other Language’.
2Use the
/ (cursor left/right) buttons
to select either a code letter or a code
number.
3Use the
/ (cursor up/down) buttons
to select a code letter or a code number.
See Language code list on page 48 for a
complete list of languages and codes.
1
2
2
5
5
6
3
21
4
4
DV575A KU_Mid.book 47 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
49
En
Troubleshooting
Incorrect operation is often mistaken for trouble or malfunction. If you think that there is
something wrong with this component, check the points below. Sometimes the trouble may lie in
another component. Inspect the other components and electrical appliances being used. If the
trouble cannot be rectified after checking the items below, ask your nearest Pioneer authorized
service center or your dealer to carry out repair work.
Problem Remedy
The disc won’t play or is
automatically ejected
after loading.
• Make sure the disc is free from dirt and dust and is not damaged
(page 44).
• Make sure the disc is loaded with the label side face-up and aligned
properly in the disc tray guide.
• Incompatible region number: If the region number on a DVD-Video
disc does not match the number on the player, the disc cannot be
used (page 47).
• Condensation inside the player: Allow time for condensation to
evaporate. Avoid using the player near an air-conditioning unit.
• Disc is loaded upside down: Reload the disc with the label side face
up.
• A Super VCD that does not conform with the IEC standards might
not play normally.
DVD-Audio playback
stops.
• The disc may have been illegally copied.
Picture playback stops
and the operation
buttons cannot be used.
• Press  , then start playback again (  ).
• Press and hold the front panel  STANDBY/ON button for about 10
seconds to switch the unit off, then press again to switch back on.
• Switch the power off once, unplug from the wall socket, then plug
back in and switch on again using the front panel  STANDBY/ON
button.
New settings made in the
Setup screen menus while
a disc is playing are
ineffective.
• Some settings can be changed while a disc is playing, but are not
effective until the disc is stopped then restarted: Press  , then start
playback again (  ).
Settings are canceled. • When the power is cut due to power failure or by unplugging the
power cord, settings will be canceled: Press  STANDBY/ON on the
front panel to turn the player off. Wait for --OFF-- to disappear from
the display, then unplug the power cord.
The remote control
doesn't seem to work.
• The remote control is too far from the player, or the angle with the
remote sensor is too wide: Use the remote within its operating range
(page 18).
• The batteries are exhausted: Put in new ones (page 8).
DV575A KU_Mid.book 49 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
51
En
Cannot play multi-
channel audio
• Make sure that Audio Output Mode is set to 5.1 Channel
(page 41).
• Check that the Dolby Digital, DTS and MPEG Out settings
(pages 35–36) are suitable for your amplifier/receiver—check the
instruction manual that came with your amplifier/receiver.
• DVD-Audio and SACDs do not output multichannel digital audio.
Listen through the player’s analog outputs.
• Check that the settings in the Speaker Installation screen are
correct (page 42).
• Check the audio options available from the disc menu.
Cannot listen to high-
sampling rate audio
through the digital
output.
• Make sure that Linear PCM Out is set to Downsample Off
(page 35).
• As a copy-protection measure, some DVDs do not output 96kHz
audio. In this case, even if set to Downsample Off , the player
automatically outputs the audio at 48 kHz. This is not a malfunction.
Cannot output 192kHz or
176.4kHz digital audio.
• The player does not output digital audio at these sampling rates. The
digital output is automatically downsampled.
Cannot output 96kHz or
88.2kHz digital audio.
• Check that Linear PCM Out is set to Downsample Off (page 35).
• Some discs are digital copy protected and do not output high
sampling rate digital audio. In this case the output is automatically
downsampled.
No DTS audio output. • If this unit is connected to a non-DTS compatible amplifier or
decoder using a digital audio cable, set DTS Out to DTS
>
PCM
(page 35). If you do not do this, noise will be output when you play a
DTS disc.
• If this unit is connected to a DTS-compatible amplifier or decoder
using a digital audio cable, check the amplifier settings, and that the
cable is properly connected.
Audio mix does not
sound right or sounds
incomplete (for example,
inaudible dialog).
• Make sure that Audio Output Mode is set to 2 Channel if you've
connected to the stereo inputs on your amplifier or TV (page 41).
The audio recorded on a
Super VCD disc is not
output properly.
• If the audio is switched to [2] when playing a Super VCD that
contains only one stereo soundtrack, there may be no sound at all.
Press AUDIO to change the soundtrack.
Can’t hear effect of
Virtual Surround
• Virtual Surround does not work with SACD or DVD-Audio.
• The Virtual Surround effect is only output through the AUDIO OUT
(2ch) analog audio outputs.
• Make sure that Audio Output Mode is set to 2 Channel (page 41).
• The effectiveness of Virtual Surround varies with the disc.
Problem Remedy
DV575A KU_Mid.book 51 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
53
En
Glossary
Analog audio Direct representation of sound by an
electrical signal. See also Digital audio .
Aspect ratio The width of a TV screen relative to its
height. Conventional TVs are 4:3;
widescreen models are 16:9.
Bonus Group
(DVD-Audio
only)
An ‘extra’ group on some DVD-Audio
discs that requires a key number to
access.
Browsable
pictures
(DVD-Audio
only)
A feature of some DVD-Audio discs in
which the user can browse still pictures
recorded on the disc as the audio is
played. See also Slideshow .
Digital audio Indirect representation of sound using
numbers. See also Sampling frequency
and Analog audio .
Dolby
Digital
*1
A multi-channel audio encoding system
developed by Dolby Laboratories that
enables far more audio to be stored on a
disc than PCM encoding. See also PCM
(Pulse Code Modulation) .
DRM DRM (Digital Rights Management) copy
protection is a technology designed to
prevent unauthorized copying by
restricting playback, etc. of material on
devices other the PC (or other WMA
recording equipment) used to record it.
For detailed information, please see the
instruction manuals or help files that
came with your PC (or other WMA
recording equipment) and/or software.
DTS
*2
A multi-channel audio encoding system
developed by Digital Theater Systems
that enables far more audio to be stored
on a disc than PCM encoding. See also
PCM (Pulse Code Modulation) .
EXIF
(Exchangeabl
e Image File)
A file format developed by Fuji Photo
Film for digital still cameras. Digital
cameras from various manuafcturers
use this compressed file format which
carries date, time and thumbnail
information, as well as the picture data.
File
extension
A tag added to the end of a filename to
indicate the type of file. For example,
“.mp3” indicates an MP3 file.
ISO 9660
format
International standard for the volume
and file structure of CD-ROM discs.
JPEG A standard file format used for still
images. JPEG files are identified by the
file extension “.jpg”.
MP3 MP3 (MPEG1 audio layer 3) is a
compressed stereo audio file format.
Files are recognized by their file
extension “.mp3”.
MPEG audio An audio format used on Video CD/
Super VCDs and some DVD discs.
Packed PCM
(DVD-Audio
only)
A lossless compression system that
enables more PCM audio to be stored
on a DVD-Audio disc than would
otherwise be possible.
PBC
(PlayBack
Control)
A system of navigating a Video CD/
Super VCD through on-screen menus
recorded onto the disc.
PCM
(Pulse Code
Modulation)
Digital audio encoding system found on
CDs. Good quality, but requires a lot of
data compared to Dolby Digital, DTS
and MPEG encoded audio. See also
Digital audio .
Progressive
scan video
All the lines that make up a video
picture are updated in one pass
(compared to interlace which takes two
passes to update the whole picture).
Regions
(DVD-Video
only)
These associate DVD-Video discs and
players with particular areas of the
world. See DVD-Video regions on
page 47 for more information.
Sampling
frequency
The rate at which sound is measured to
be turned into digital audio data. The
higher the rate, the better the sound
quality. CD is 44.1 kHz; DVD can be up
to 96 kHz. See also Digital audio .
DV575A KU_Mid.book 53 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
Additional information
08
55
En
Specifications
General
System . . . . . . . . . . . . . . . . . . . . . . . . DVD player
Power requirements
DV-575A / DV-578A . . . . . . . . . . .AC 120 V, 60 Hz
DV-676A-S
. . . . . . AC 110–127/220–240 V, 50/60 Hz
Power consumption
DV-575A / DV-578A . . . . . . . . . . . . . . . . . . . .11 W
DV-676A-S. . . . . . . . . . . . . . . . . . . . . . . . . . . .12 W
Power consumption (standby)
DV-575A / DV-578A . . . . . . . . . . . . . . . . . . 0.07 W
DV-676A-S. . . . . . . . . . . . . . . . . . . . . . . . . . 0.12 W
Weight . . . . . . . . . . . . . . . . . . . 2.1 kg / 4 lb 10 oz
Dimensions . .420 (W) x 55 (H) x 243 (D) mm
. . . . . . . . . . . . . . . (16.5 (W) x 2.2 (H) x 9.6 (D) in.)
Operating temperature . . . . . . . +5°C to +35°C
(+41°F to +95°F)
Operating humidity . . . . . . . . . . . . . . . 5% to 85%
(no condensation)
Component video output
Y (luminance) - Output level . . . . . . 1 Vp-p (75 )
P
B
(color) - Output level . . . . . . . 0.7 Vp-p (75 )
P
R
(color) - Output level . . . . . . . 0.7 Vp-p (75 )
Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA
S-video output
Y (luminance) - Output level . . . . . . 1 Vp-p (75 )
C (color) - Output level . . . . . . 286 mVp-p (75 )
Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .S-video
Video output
Output level . . . . . . . . . . . . . . . . . . . 1 Vp-p (75 )
Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA
Audio output (1 stereo pair)
Output level . . . . . . . . . . . . .During audio output
200 mVrms (1 kHz, –20 dB)
Number of channels . . . . . . . . . . . . . . . . . . . . . . 2
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . RCA
Audio output (multi-channel / L, R, C, SW,
LS, RS)
Output level. . . . . . . . . . . . . During audio output
200 mVrms (1 kHz, –20 dB)
Number of channels . . . . . . . . . . . . . . . . . . . . . 6
Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . .RCA jack
Digital audio characteristics
Frequency response . . . . . . . . . . 4 Hz to 44 kHz
(DVD fs: 96 kHz)
4 Hz to 88 kHz (DVD-Audio fs: 192 kHz)
S/N ratio . . . . . . . . . . . . . . . . . . . . . . . . . . .115 dB
Dynamic range . . . . . . . . . . . . . . . . . . . . . .101 dB
Total harmonic distortion. . . . . . . . . . . . 0.0020 %
Wow and flutter . . . . . . . .Limit of measurement
(±0.001% W. PEAK) or lower
Digital output
Coaxial digital output jack . . . . . . . . . . .RCAjack
Optical digital output . . . . . . .Optical digital jack
Accessories
Audio/video cable. . . . . . . . . . . . . . . . . . . . . . . . 1
Power cable
DV-676A-S (Singapore/Taiwan model) . . . . . . 2
Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . 1
AA/R6P dry cell batteries . . . . . . . . . . . . . . . . . 2
Operating Instructions
Warranty card (
U.S. model only
).. . . . . . . . . . 1
Front panel button names sticker
(Singapore/Taiwan models only)
. . . . . . . . . . 1
Remote control overlay
(Singapore/Taiwan models only)
. . . . . . . . . . 1
The specifications and design of this product are subject to
change without notice, due to improvement.
Published by Pioneer Corporation.
Copyright © 2004 Pioneer Corporation.
All rights reserved
DV575A KU_Mid.book 55 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals

Before you start01
8
En
What’s in the box
Please confirm that the following accessories
are in the box when you open it.
• Remote control
• AA/R6P dry cell batteries x2
• Audio/video cable (red/white/yellow plugs)
• Power cable
• Operating instructions
• Warranty card (DV-575A and DV-578A
model only)
• Front panel button names sticker
(Singapore and Taiwan models only) —
Chinese language button names for the
front panel controls.
• Remote control overlay
(Singapore and
Taiwan models only)
— Place the overlay
on the remote control to be able to read the
buttons in Chinese.
Putting the batteries in the remote
• Open the battery compartment cover
and insert the batteries as shown.
Use two AA/R6P batteries and follow the
indications (
, ) inside the compartment.
Close the cover when you’re finished.
Important
Incorrect use of batteries can result in hazards
such as leakage and bursting. Please observe
the following:
• Don’t mix new and old batteries together.
• Don’t use different kinds of battery
together—although they may look similar,
different batteries may have different
voltages.
•Make sure that the plus and minus ends of
each battery match the indications in the
battery compartment.
• Remove batteries from equipment that
isn’t going to be used for a month or more.
• When disposing of used batteries, please
comply with governmental regulations or
environmental public instruction’s rules
that apply in your country or area.
Hints on installation
We want you to enjoy using this product for
years to come, so please use the following
guidelines when choosing a suitable location:
Do...
• Use in a well-ventilated room.
•Place on a solid, flat, level surface, such as
a table, shelf or stereo rack.
Don’t...
• Use in a place exposed to high
temperatures or humidity, including near
radiators and other heat-generating
appliances.
•Place on a window sill or a place where the
player will be exposed to direct sunlight.
• Use in an excessively dusty or damp
environment.
• Place directly on top of an amplifier, or
other component in your stereo system
that becomes hot in use.
•Use near a television or monitor as you may
experience interference—especially if the
television uses an indoor antenna.
• Use in a kitchen or other room where the
player may be exposed to smoke or steam.
• Use on a thick rug or carpet, or cover with
cloth—this may prevent proper cooling of
the unit.
DV575A KU_Mid.book 8 ページ ２００４年２月６日 金曜日 午後２時３８分
Downloaded From Disc-Player.com Pioneer Manuals
10
En
About WMA
The Windows Media
®
logo printed on the box
indicates that this player can playback
Windows Media Audio content.
WMA is an acronym for Windows Media Audio
andrefers to an audiocompression technology
developed by Microsoft Corporation. WMA
content can be encoded by using Windows
Media
®
Player version 7, 7.1, Windows Media
®
Player for Windows
®
XP, or Windows Media
®
Player 9 Series.
Microsoft, Windows Media, and the Windows
logo are trademarks, or registered trademarks of
Microsoft Corporation in the United States and/
or other countries.
JPEG file compatibility
• Compatible formats: Baseline JPEG and
EXIF 2.2* still image files up to a resultion
of 3072 x 2048.
*
File format used by digital still cameras
• Progressive JPEG compatible: No
• File extensions: .jpg (must be used for the
player to recognize JPEG files – do not use
for other file types)
• File structure: Up to 299 folders; up to 648
folders and files combined
PC-created disc compatibility
Discs recorded using a personal computer
may not be playable in this unit due to the
setting of the application software used to
create the disc. In these particular instances,
check with the software publisher for more
detailed information.
Discs recorded in packet write mode (UDF
format) are not compatible with this player.
Check the DVD-R/RW or CD-R/RW software
disc boxes for additional compatibility
information.
