Pioneer DV-525K User manual

ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 1999
RRV2207
DVD PLAYER
DV-525K
T – ZZE SEPT. 1999 Printed in Japan
Model No. Order No. Remarks
DV-525/KU RRV2158
¶This service manual should be used together with the following manual(s):
Type Power Requirement
Model
DV-525K
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Region No.
RAMXQ ‡AC110-127/220-240V 6 Automatic select
The voltage can be converted by
the following method.
1. CONTRAST OF MISCELLANEOUS PARTS........ 2
2. SCHEMATIC DIAGRAM ....................................... 7
3. PCB CONNECTION DIAGRAM.......................... 14
CONTENTS

DV-525K
2
7CONTRAST TABLE
DV-525K/RAMXQ and DV-525/KU are constructed the same except for the following:
PCB ASSEMBLIES
P9 - 1 DVDM ASSY VWS1388 VWS1399
P9 - 2 AVJB ASSY VWV1693 VWV1695
NSP FLKB ASSY VWM1912 VWM1917
P7 - 1 FLKY ASSY VWG2050 VWG2054
P7 - 2 NSP PWSB ASSY VWG2103 VWG2058
P9 - 1 POWER SUPPLY ASSY VWR1311 VWR1313 ∗1
NSP EMIB ASSY Not used VWV1699 No. 1
PACKING
P5 - 1 Audio Cord VDE1033 VDE1054
P5 - 2 Video Cord VDE1034 VDE1055
P5 - 3 Remote Control Unit (CU-DV049) VXX2643 Not used
P5 - 3 Remote Control Unit (CU-DV046) Not used VXX2634
P5 - 4 NSP Dry Cell Battery (R6P, AA) VEM-013 VEM1010
P5 - 7 Packing Case VHG1800 VHG1832
P5 -10 NSP Warranty Card ARY7023 ARY7028
P5 -11 Operating Instructions (English) VRB1220 VRB1224
P5- 18 AC Power Cord Not used ADG7018
P5 -23 NSP Label VRW1629 Not used
Operating Instructions (Simp-Chinese) Not used VRC1092
SVCD Instruction Not used VRL1007
(English/Simp-Chinese)
Label (Packing Case) Not used VRW1814 for Packing Case
EXTERIOR SECTION
P6 - 1 Bonnet S VXX2651 VXX2652
P6 - 2 Tray Panel VNK4448 VNK4445
P6 - 6 Tray VNL1731 VNK4333
P6 -11 Screw BCZ40P060FZK BCZ40P060FNI
P6 -17 65 Label ARW7050 Not used
Nylon Rivet Not used AEC-525 No. 2
L Sheet Not used VEC2086 No. 3
Ref.
No. Remarks
DV-525/KU DV-525K/RAMXQ
Part No.
Mark Symbol and Description
1. CONTRAST OF MISCELLANEOUS PARTS
NOTES : ÷Parts marked by “ NSP ” are generally unavailable because they are not in our Master Spare Parts List.
÷The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
÷Reference Nos. indicate the pages and Nos. in the service manual for the base model.
÷When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex. 1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by
J = 5%, and K = 10%).
560 Ω=56 ×101 =561................................................... RD1/4PU 561J
47k Ω=47 ×10 3=473 .................................................. RD1/4PU 473J
0.5 Ω=R50 ...................................................................... RN2H Â50K
1 Ω=1R0 ......................................................................... RS1P 1Â0K
Ex. 2 When there are 3 effective digits (such as in high precision metal film resistors).
5.62k Ω=562 ×10 1=5621 ........................................... RN1/4PC 5621F

DV-525K
3
FRONT PANEL SECTION
P7 - 4 Flexible Cable (09P) VDA1725 VDA1732
P7 - 5 Front Panel VNK4444 VNK4439
P7 - 6 FL Lens VEC2095 VEC2063
P7 - 7 Name Plate PAM1776 PAM1779
P7 - 8 PW Botton (POWER) VNK4101 VNK4059
P7 - 9 Main Key VNK4447 VNK4446
Flexible Cable (05P) Not used VDA1733 No. 4
(EMIB CN201 ↔AVJB CN201)
Headphone Knob G Not used PAC1862 No. 5
Earth Plate Not used VBK1095 No. 6
BOTTOM VIEW SECTION
P9 - 8 AC Power Cord ADG7024 Not used
P9 -15 Cord Stopper CM-22C Not used
P9 -17 Rear Panel VNA2080 VNA2114
P9 -25 NSP Label VRW1629 Not used
NSP Housing Assy (2P) Not used VKP2189 for POWER SUPPLY ASSY
Label (Rear) Not used VRW1739 for Rear Panel
LOADING MECHANISM ASSY
P10 -22 Cushion VEB1312 Not used
Ref.
No. Remarks
DV-525/KU DV-525K/RAMXQ
Part No.
Mark Symbol and Description
∗1: This assembly is used for DV-525/WY. Refer to the service manual RRV2158.
¶The numbers in the remarks column correspond to the numbers on the “EXPLODED VIEWS”.
¶For PCB ASSEMBLIES, Refer to “CONTRAST OF PCB ASSEMBLIES”, “2. SCHEMATIC DIAGRAM” and “3. PCB CONNECTION DIAGRAM”.

DV-525K
4
Clamper Plate
Bridge
Clamper
BPZ26P080FZK
No. 2
No. 3
7EXPLODED VIEWS
÷EXTERIOR SECTION
Front Panel
Main Key(2/2)
FL Lens
FLKY Assy
BBZ30P080FMC
Flexible Cable(14P)
Flexible Cable(09P)
No. 1
No. 5
No. 6
Main Key(1/2)
Name Plate
PWSB Assy
No. 4
BBZ30P080FMC
÷FRONT PANEL SECTION

DV-525K
5
7CONTRAST OF PCB ASSEMBLIES
IC13 VWY1659 VYW1649
IC14 TC55V1001AF8 KM68V1000CLG-7L
R1 Not used RS1/16S333J ∗1
R602 Not used RS1/16S0R0J
Mark Symbol and Description Part No.
VWS1388 VWS1399 Remarks
DVDM ASSY
VWS1399 and VWS1388 are constructed the same except for the following:
∗1: This part is used for DV-525/WY. Refer to the service manual RRV2158.
F
E
IC206 NJM78L05A Not used
Q260, Q360 Not used 2SD2114K(VW)
Q261 Not used DTA124EK
Q361 Not used DTA124TK
L201 Not used LAU220J
L262 CHIP BEADS Not used VTL1096
S201 Not used VSH1009
S451 Not used VSH1020 ∗1
S452 VSH1009 Not used
C261, C361 Not used CEJA470M16
C262 Not used CKSQYF104Z25
C290 CKSQYF104Z25 Not used
C550, C552, C555 CEAT471M6R3 Not used
R221, R455 RS1/10S0R0J Not used
R260, R360 Not used RS1/10S223J
R261, R361, R453 Not used RS1/10S103J ∗1(R453)
R270, R271 Not used RS1/10S102J
R290, R291 RS1/10S220J Not used
R292 RS1/10S6R8J Not used
R450, R456 Not used RS1/10S0R0J ∗1
R452 Not used RS1/10S153J ∗1
R550, R554 RN1/10SE1100D Not used
R551, R555 RS1/10S4R7J Not used
R552, R556 RN1/10SE3300D Not used
R553, R557 RN1/10SE4700D Not used
R558 RN1/10SC62R0D Not used
CN201 CONNECTOR Not used 52045-0545
JA505 3P PIN JACK VKB1105 Not used
JA601 1P PIN JACK (NI, BLK) VKB1077 VKB1121
PC BOARD AVJB VNP1717 VNP1730
Mark Symbol and Description Part No.
VWV1693 VWV1695 Remarks
AVJB ASSY
VWV1695 and VWV1693 are constructed the same except for the following:
F
F
∗1: These parts are used for DV-525/WY. Refer to the service manual RRV2158.

DV-525K
6
R118–R120 RS1/10S390J RS1/10S150J
R129, R130, R153 RS1/10S0R0J Not used
R131, R132 Not used RS1/10S0R0J
R141 RS1/10S622J RS1/10S163J
R143 RS1/10S363J RS1/10S272J
R190–R192 Not used RS1/10S391J ∗1
FL HOLDER VNF1087 VNF1096
Mark Symbol and Description Part No.
VWG2050 VWG2054 Remarks
FLKY ASSY
VWG2054 and VWG2050 are constructed the same except for the following:
F
G
7PCB PARTS LIST
Mark No. Description Part No. Mark No. Description Part No.
PWSB ASSY
SWITCHES AND RELAYS
S301 ASG7013
CAPACITORS
C301 CKSQYF104Z25
RESISTORS
All Resistors RS1/10S&&&J
OTHERS
CN301 CONNECTOR 9P 52492-0920
CN302 CONNECTOR BTMK04S-1S
EMIB ASSY
SEMICONDUCTORS
IC841 M65855FP
IC811 NJM2068M
IC881 NJM2370R10
Q895 DTC124EK
D851 UDZS5.1B
COILS AND FILTERS
F9921 CHIP SOLID INDUCTOR VTF1096
CAPACITORS
C816 CCSQSL271J50
C811, C841, C859 CEAT101M10
C800, C813, C851, C881 CEAT2R2M50
C849, C883 CEAT470M16
C810, C819, C845, C855, C861 CKSQYB103K50
C865, C882 CKSQYB103K50
C871 CKSQYB104K25
C812 CKSQYB122K50
C852 CKSQYB123K50
C801, C891 CKSQYB152K50
C863 CKSQYB332K50
C862 CKSQYB333K25
C853 CKSQYB472K50
C842, C884, C885, C911 CKSQYF104Z25
C864 CKSQYF105Z16
RESISTORS
VR813, VR845 (10kΩ•B) VCS1040
Other Resistors RS1/10S&&&J
OTHERS
CN201 CONNECTOR 5P 52492-0520
CN301 CONNECTOR PLUG BTMK04P-1R
JA891 HEADPHONE JACK RKB1014
PCB BINDER VEF1040
SNAP PLATE VNE1102
JACK HOLDER VNE2199
PRINTED CIRCUIT BOARD VNP1731
F
H
∗1: This part is used for DV-525/WY. Refer to the service manual RRV2158.
F
M

DV-525K
7
A
B
C
D
1234
1234
2. SCHEMATIC DIAGRAM
Note :When ordering service parts, be sure to refer to "EXPLODEDVIEWS and PARTS LIST" or "PCB PARTS LIST".
2.1 DVDM ASSY
VYW1649
1/3
E
3/3
E
3/3
E
MY_1
R602
0
2/3F
DVDM ASSY (VWS1399)
E
2/3F
E

DV-525K
8
A
B
C
D
1234
1234
1/2F
F
2.2 AVJB ASSY
F1/2F
AVJB ASSY (VWV1695)
CN101
VKN1567
JA601
VKB1077
JA602
GP1F32T
CN13
E3/3
AUDIO POWER SUPPLY
AUDIO POWER SUPPLY
2/2
F
2/2
F
PULSE TRANS.
(V/CB)
(Y)
(C)

DV-525K
9
A
B
C
D
5678
5678
1/2F
F
JA201
DKB1031
1/2
2/2
MIC L
MIC R
: AUDIO SIGNAL ROUTE
: V/CB SIGNAL ROUTE
: Y SIGNAL ROUTE
: C SIGNAL ROUTE
(V/CB)
(Y)
(C)
: The power supply is shown with the marked box.
CN201
S201
DTA124TK
L262
VTL1096
C262
0.1
VSH1009
MF

DV-525K
10
A
B
C
D
1234
1234
2.3 FLKY and PWSB ASSYS
F
G
62k 2.7k
47k 16k
S101-S106 :
ASG7013
R131 R132
F
FLKY ASSY (VWG2054)
G

DV-525K
11
A
B
C
D
5678
5678
CN102
52492-0920
CN101
VKN1274
CN1
E1/3
15
15
15
CN301
52492-0920
CN302
BTMK04S-1S
RED
F
PWSB ASSY (VWG2058)
H
: The power supply is shown with the marked box.
CN301
MF
F
GF
H

DV-525K
12
A
B
C
D
1234
1234
2.4 EMIB ASSY
EMIB ASSY (VWV1699)
Chassis
F
M
F
M

DV-525K
13
A
B
C
D
5678
5678
CN302
HF
CN201
FF
CN201
CN301
F
M

DV-525K
14
A
B
C
D
1234
1234
(VNP1728-A)
VC1
IC15
IC8
Q109
Q101
IC1
Q102
IC3
Q84
Q83
IC5
IC7
IC22
Q106
IC11
Q103
Q7
Q82
IC18
Q86
IC25
IC401
Q6
CN201
K
DVDM ASSY
CN101
PICKUP
ASSY
CN301
B
CN101
SIDE A
16M
F
E
FF
GF
3.1 DVDM ASSY • This PCB is a four-layered board.
3. PCB CONNECTION DIAGRAM
F
E

DV-525K
15
A
B
C
D
1234
1234
(VNP1728-A)
Q88 Q90 Q92
Q1
IC14
IC19
Q3
IC13
Q114
Q113
IC17 IC16
IC27
Q112
Q251
Q105
Q107
Q108
IC21 IC2
Q87
IC26
Q89 Q91
IC12
SIDE B
DVDM ASSY
F
E
• This PCB is a four-layered board.
F
E

DV-525K
16
A
B
C
D
1234
1234
Q120
Q260 IC205 IC305 IC201 IC701 IC202 IC501
IC203 Q361 Q720
Q257 Q357 Q201 Q202
IC206
AVJB ASSY
F
F
AVJB ASSY
F
F
CN201
MF
3.2 AVJB ASSY
F
F

DV-525K
17
A
B
C
D
5678
5678
Q504 Q503 Q151 IC602 IC601Q150
Q502 Q501
IC502 IC150
(VNP1730-C)
(VNP1730-C)
CN13
SIDE A
SIDE B
EF
F
F

DV-525K
18
A
B
C
D
1234
1234
(VNP1729-A)
(VNP1729-A)
FLKY
ASSY
FLKY
ASSY
PWSB ASSY
F
G
F
H
PWSB ASSY
F
H
F
G
CN301
MF
3.3 FLKY and PWSB ASSYS
F
GF
H

DV-525K
19
A
B
C
D
5678
5678
IC102
IC101
(VNP1729-A)
(VNP1729-A)
CN1
SIDE A
SIDE B
EF
F
G

DV-525K
20
A
B
C
D
1234
1234
CN302
HF
CN201
FF
EMIB ASSY
Q895 IC881 IC811 IC841
(VNP1731-B)
(VNP1731-B)
SIDE A
SIDE B
F
M
EMIB ASSY
F
M
3.4 EMIB ASSY
F
M
