CORRECTION OF SERVICE MANUAL
Date: July 5, 2005 No.: SCH05014( 1/3 )
MODEL No. S/M No. PG MODEL No. S/M No. PG
DV-588A-S/KUXTL/CA RRV3139 48
Please correct your service manual
PIONEER SERVICE NETWORK CORPORATION
Memo: SMC06H002 NM,62
K.NOHARA ,MANAGER
HE
Technical Support Group
Service Support Division
Please replace the following 4 pages of the service manual
(RRV3139) with the attached new 2 pages.
Model No. S/M No.pages
DV-588A-S/KUXTL/CA RRV3139 48-51
*Page 50 and 51 would be unused number.

DV-588A-S
48
1234
1234
C
D
F
A
B
E
5. PCB PARTS LIST
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560 Ω
47k Ω
0.5 Ω
1 Ω
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x10
1
47 x10
3
R50
1R0
561
473
5.62k Ω RN1/4PC F562 x10
1
5621
Mark No. Description Part No.
LIST OF ASSEMBLIES
1..DVD MT PCB ASSY A2G601A130
1..OPERATION PCB ASSY A2G601A270
1..OPERATION 2 PCB ASSY A2G501A280
1..OPERATION 3 PCB ASSY A2G501ADF0
1..POWER PCB ASSSY A2G601A240
1..DVD MECHA ASSY A2G512A650
2..LOADING PCB ASSY A2F101A610
2..SW PCB ASSY A2F101A640
Mark No. Description Part No.
A
DVD MT PCB ASSY
SEMICONDUCTORS
IC4002 (MT1389EE/B2-L) MT1389EE/B2-L-K
IC4001 (BR24L16FJ-WE2) I57F04L160
IC2301 (LA6565-TE) I03F065650
IC4003 (BD5229G-TR) I97F052290
IC4004 (S29AL016D70TF1020) S2G601AF02
IC4005 (K4S641632H-UC75) IFLJ0632H7
>
IC4006 (SIP1117L-ADJ-TP) I1HF9117L0
IC7301 (MM1623BFBE) MM1623BF-TBB
IC8003-IC8005 (PMC1742KEG/2K) PCM1742KE-TBB
IC8006-IC8008 (BA4560F-E2) I07F045600
IC8001 (TC7SHU04FU) I55F004FU0
Q2301,Q8005,Q8011,Q8012(KTC3875S) TCAA3875SY
Q8008(KTC3875S) TCAA3875SY
Q2302-Q2305,Q8010 (KTA1504S) TAAA1504SY
Q8013,Q8014 (KTA1504S) TAAA1504SY
Q2306,Q2307 (2SK3018T106) T27T030180
Q8002-Q8004,Q8006 (DTC114YUA) TN7J407001
Q8007,Q8009 (DTC114YUA) TN7J407001
Q8015- Q8018 (2SD2114K) T97A021140
Q8020- Q8023 (2SD2114K) T97A021140
D8003 (UDZS6.8B) DE7RB6R82B
D8004-D8006 (1SS355) DD7R0S3550
B4001, B4002, B4008 (CHIP BEADS ) 0246C51024
(CHIP BEADS : MMZ1608R102CT)
B8001, B7304- B7305 (CHIP BEADS ) 0246C51024
(CHIP BEADS : MMZ1608R102CT)
NR4001, NR4002 (R, NETWORK) 110P43330M4
OTHERS
CP2301 CONNECTOR PCB SIDE 069GYOT119
CP2302 CONNECTOR PCB SIDE 069EV53030
CP2303 CONNECTOR PCB SIDE 069EV63030
CP4002 CONNECTOR PCB SIDE 069EVB3030
CP4003 CONNECTOR PCB SIDE 069S2E0629
CP8001 CONNECTOR PCB SIDE 069S220629
J7302 RCA JACK 060J451008
J7301 JACK 063D700008
J8001 RCA JACK 060J411039
J8002 RCA JACK 060J451007
X4001 CRYSTAL (27MHz) 100BT02701
Mark No. Description Part No.
B
OPERATION PCB ASSY
SEMICONDUCTORS
IC651 IC PT6315 PT6315
D651 1SS133T-77 D1VT001330
D652 1SS133T-77 D1VT001330
D654 1SS133T-77 D1VT001330
D655 1SS133T-77 D1VT001330
D656 1SS133T-77 D1VT001330
D657 1SS133T-77 D1VT001330
D658 1SS133T-77 D1VT001330
D659 1SS133T-77 D1VT001330
D667 1SS133T-77 D1VT001330
SWITCHES AND RELAYS
SW652 SWITCH TACT 0504R01T38
SW653 SWITCH TACT 0504R01T38
SW654 SWITCH TACT 0504R01T38
SW655 SWITCH TACT 0504R01T38
SW656 SWITCH TACT 0504R01T38
SW657 SWITCH TACT 0504R01T38
SW658 SWITCH TACT 0504R01T38
SW659 SWITCH TACT 0504R01T38
SW661 SWITCH TACT 0504R01T38
SW666 SWITCH TACT 0504R01T38
OTHERS
V651 TUBE FLUORESCENT VAW1077
CP601 CONNECTOR PCB SIDE 069EVB3050
CP602 CONNECTOR PCB SIDE 069EV93050
Mark No. Description Part No.

DV-588A-S 49
5678
5678
C
D
F
A
B
E
C
OPERATION 2 PCB ASSY
SWITCHES AND RELAYS
SW660 SWITCH TACT 0504R01T38
SW662 SWITCH TACT 0504R01T38
SW664 SWITCH TACT 0504R01T38
SW665 SWITCH TACT 0504R01T38
SW663 SWITCH TACT 0504R01T38
OTHERS
CP605 CONNECTOR PCB SIDE 069EV53050
F
POWER PCB ASSY
RESISTORS
>
R511 R,FUSE 68 OHM 1/4W R65584680J
OTHERS
>
CP501 AC CONNECTOR 06C32E3504
CP8102 CORD CONNECTOR 06C3223003
J8102 RCA JACK 060Q401115
OS8101 OPTICAL DEVICE 07AQ000009
G
OPERATION 3 PCB ASSY
SWITCHES AND RELAYS
OS651 REMOTE RECEIVER 077A040001
SW667 SWITCH TACT 0504R01T38
CAPACITORS
C674 KA 47 UF 6.3V E02LU0470M
C651 CC 0.1 UF 25V B CS0PB0315K
RESISTORS
R666 RC 2.2K OHM 1/4W R002T4222J
OTHERS
CP603 CONNECTOR PCB SIDE 069EV93050
CP604 CONNECTOR PCB SIDE 069EV53050
PCB280 PCB DEE038A 13DEE038AW
D
SW PCB ASSY
There is no Service Parts
E
LOADING MOTOR PCB ASSY
There is no Service Parts
