DVD RECORDER
DVR-310-S
CONTENTS
1. CONTRAST OF MISCELLANEOUS PARTS ........ 3
2. MODEL TYPE SETTING ...................................... 6
3. SCHEMATIC DIAGRAM ....................................... 8
4. IC ....................................................................... 13
¶For SPECIFICATIONS and PANEL FACILITIES, refer to the operating instructions.
This service manual should be used together with the following manual(s):
RemarksOrder No.
DVR-3100-S/WYXU
RRV2843
Model
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Serial No.
Model Type Power Requirement Region No. Piease confirm 3rd & 4th
alphabetical letters.
DVR-310-S RAXU AC110-127V/AC220-240VÓ6&&PG######$$
