Pioneer AVIC-S2 User manual

AVIC-S2
System User Manual
AVIC-S2 / PIONEER

R00
Trademarks
The Bluetooth word mark and logo are owned by the Bluetooth SIG, Inc. All
other brand and product names are trademarks or registered trademarks of their
respective companies.
Note
The information in this document is subject to change without notice.

i
Table of Contents
Notice .................................................................................................iii
1Getting Started .............................................................................1
1.1 Understanding Hardware Features ...................................................1
Front Components.............................................................................1
Back Components .............................................................................2
Right-Side Components ....................................................................3
Top Components...............................................................................4
Bottom Components..........................................................................4
1.2 Connecting to AC Power and Charging the Battery..........................5
1.3 Performing the Initial Startup.............................................................6
1.4 Turning Your Device On and Off.......................................................7
1.5 Main Menu.........................................................................................7
1.6 Navigating on the Screen ..................................................................8
1.7 Using a SD Card................................................................................9
2Bluetooth HF Phone...................................................................11
2.1 About Bluetooth HF Phone..............................................................11
2.2 Connecting a Bluetooth Mobile Phone............................................11
2.3 Starting Bluetooth Mobile Phone.....................................................12
2.4 Placing a Call...................................................................................12
Keypad.............................................................................................13
Contacts...........................................................................................13
Call History ......................................................................................14
Redial...............................................................................................15
2.5 Operations During a Call .................................................................16
2.6 Receiving a Call...............................................................................17
2.7 Connecting to a Paired Phone.........................................................18
2.8 Initiating Pair Mode..........................................................................19
2.9 Closing Bluetooth HF Phone ...........................................................19
2.10 Ending the Bluetooth Connection....................................................19

ii
3Troubleshooting and Maintenance ...........................................20
3.1 Resetting Your System....................................................................20
3.2 Troubleshooting...............................................................................21
Power Problems ..............................................................................21
Screen Problems.............................................................................21
Connection Problems ......................................................................22
GPS Problems.................................................................................22
3.3 Maintaining Your Device..................................................................23

iii
Notice
 Before using this product, read “Important Information for the User” (a
separate manual) which contains warnings, cautions, and other important
information that you have to follow.
 This manual provides system and Bluetooth® information. For information
on the GPS navigation software, see the “Operation Manual.”
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one of the
following measures:
 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and receiver.
 Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
 Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.

iv
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate this
equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. End users must follow the specific operating
instructions for satisfying RF exposure compliance.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
IC statement
Operation is subject to the following two conditions:
1) This device may not cause interference and
2) This device must accept any interference, including interference that may
cause undesired operation of the device.
IMPORTANT NOTE:
IC Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an
uncontrolled environment. End users must follow the specific operating
instructions for satisfying RF exposure compliance.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance20cmbetween the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
This equipment complies with IC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cmbetween the radiator & your body.

1
1 Getting Started
1.1 Understandin Hardware Features
Front Components
Ref Component Description

Touch Screen Displays the output of your device. Touch the screen with
your fingertip to select menu commands or enter
information.

Bluetooth
Indicator Flashes in blue to indicate that Bluetooth is on. The Bluetooth is always on when your device is turned on.

Map Button Opens the Map screen.

2
In Phone Menu:
Scrolls through the Bluetooth menu buttons by rotating the
wheel.
Selects the highlighted item by pressing in the wheel.

Scroll Wheel
In the MP3 screen:
Adjusts the volume by rotating the wheel.

Menu Button Opens the Main Menu by pressing briefly.
Back Components
Ref Component Description

Speaker For voice prompts, system operation tone, and hands free
dial voice.

External GPS
Antenna This connector (under rubber dust cover) allows use of an external GPS antenna (not available through Pioneer),
which may be positioned on top of the car for better signal
reception in areas with poor reception. Contact Pioneer
Support for recommendations on available third party
products.

Reset Button Restarts your device (soft reset).

3

TMC Car Cradle
Connector Connects to the optional TMC Car Cradle for receiving TMC (Traffic Message Channel) information.

ON/OFF Switch The main power/battery cutoff switch.
Ri ht-Side Components
Ref Component Description

SD Slot Accepts an SD (Secure Digital) card for future map and
software upgrades.

Mini-USB
Connector Connects to the AC adapter or USB cable.

Headphone
Connector Connects to stereo headphones.

4
Top Components
Ref Component Description

Power Button Turns the device on and off by pressing for at least 2
seconds.
Glows bright amber to indicate that the battery is charging,
and turns green when the battery is fully charged.
Bottom Components
Ref Component Description

Microphone For Bluetooth hands-free calling.

5
1.2 Connectin to AC Power and Char in the
Battery
You are recommended to fully charge your device before using it for the very
first time.
1. Connect the AC adapter cable to the mini-USB connector on your device.
2. Connect one end of the power cable to the AC adapter and the other end to a
wall outlet.
The power indicator glows amber when charging is in progress. Do not
disconnect your device from AC power until the battery is fully charged. The
power indicator will turn green. This will take a couple of hours.
CAUTION: For optimal performance of the lithium battery, take note of the followin :
 Do not char e the battery where the temperature is hi h (e. . in direct sunli ht).
 There is no need to fully dischar e the battery before char in . You can char e the
battery before it is dischar ed.
 If you will not use the product for a lon period of time, be sure to fully char e the
battery at least once every two weeks. Over dischar e of the battery can affect the
char in performance.

6
1.3 Performin the Initial Startup
1. Slide the ON/OFF switch to the ON position.
2. Your device turns on and prompts you to select the language. Select the
desired language and tap OK . Your device restarts and guides you through
the rest of the initial startup settings.
3. The Main Menu appears.

7
1.4 Turnin Your Device On and Off
Press and hold the power button for at least 2 seconds to turn on and off your
device.
When you press the power button to turn off the unit, your device actually enters
into a suspend stateand the systemstops operating. Once you turn on the system
again, it resumes from the same guidance or menu screen you left off at.
1.5 Main Menu
The Main Menu is your starting place for various tasks. Tap a button to start a
task or open another menu. (For information on the GPS navigation software,
see the “Operation Manual.”)
You can access the Main Menu at any time by pressing the MENU button on
your device.

8
Button Name Description For Detailed Information
Navigation Starts the navigation software. See the “Operation Manual”
supplied with the software.
Audio Player Plays MP3 music. Chapter 2
System Setting Customizes the system settings. Chapter 3
Bluetooth Serves as a hands-free (HF) device
for a Bluetooth mobile phone. Chapter 4
1.6 Navi atin on the Screen
To navigate and select objects on the screen, simply use your finger and touch
the screen. The following are possible via touch screen:
 Tap
Touch the screen once with your finger to
open items or select options.
 Drag
Hold your finger on the screen and drag
up/down/left/right or across the screen.
 Tap and hold
Tap and hold your finger until an action is
complete, or a result or menu is shown.

9
1.7 Usin a SD Card
NOTE: Make sure that no forei n objects enter the slot.
Your device has a SD slot where you can insert an Secure Digital storage card
for future software and application upgrades sold by Pioneer. To use a SD card,
insert it into the slot, with the connector pointing to the slot and its label facing
the front of the device.
To remove a card, first make sure that no application is accessing the card, and
then slightly push the top edge of the card to release it and then pull it out of the
slot.

11
2 Bluetooth HF Phone
2.1 About Bluetooth HF Phone
Your device can serve as a hands-free (HF) device for a Bluetooth mobile
phone. After establishing the Bluetooth connection, you can tap your device to
place and receive phone calls instead of picking up the mobile phone, and the
built-in speakers and microphone can also be used for your conversation.
2.2 Connectin a Bluetooth Mobile Phone
To connect with a Bluetooth mobile phone for the first time:
1. Initiate the Bluetooth searching process on your mobile phone. You should
see “Pioneer AVIC-S2” in the device list after searching is completed.
2. Select “Pioneer AVIC-S2” to create the connection. Use the 0000 default
passkey to connect.
3. Your AVIC-S2 can now serve as a hands-free device for your mobile
phone.

12
2.3 Startin Bluetooth Mobile Phone
1. Tap Bluetooth on the Main Menu.
2. The Bluetooth HF Phone main screen appears. The status bar at the bottom
shows the name of the mobile phone connected.
2.4 Placin a Call
After pairing with your mobile phone, you can place a call using any of the four
buttons ( Keypad , Contacts , Call History , and
Redial ) on the Bluetooth HF Phone main screen.

13
Keypad
By tapping the Keypad button on the Bluetooth HF Phone main screen,
you can enter the telephone number with the onscreen keypad. After entering
the telephone number, tap to place the call.
NOTE:
 To delete the last di it entered, tap the Backspace button.
 The other two buttons allow you to switch to Contacts and Call
History screens.
Contacts
You can transfer contact data of your Bluetooth devices via OPP (Object Push
Profile). As long as you have sent such information to your device, the
information is available in Bluetooth HP Phone.
To call a contact, tap the Contacts button on the Bluetooth HF Phone
main screen.
Backspace
Back
Contacts
Call History
Call

14
Tap the desired contact and the phone number list appears. Tap the phone
number to call and tap to call the selected phone number.
Call History
NOTE: Bluetooth HF hone cannot access the call history stored in a connected mobile
phone.
Tap the Call History button on the Bluetooth HF Phone main screen to
display the recent incoming, outgoing, or missed calls together with information
such as date, time, and duration of each call.
Index
Back
Call the selected
number.
Delete the selected
contact.
