Pioneer AVH-P7600D User manual

Operation Manual
7 inch Wide Fully Motorized LCD Color Display with 5-
Channel High-Power DVD/VCD/CD eceiver
AVH-P7600DVD
English

Thank you for buying this Pioneer product.
Please read through these operating instructions so you will know how to operate
your model properly. After you have finished reading the instructions, keep this man-
ual in a safe place for future reference.
Be sure to read this
!Playable discs 8
!DVD video disc region numbers 9
!When an operation is prohibited 13
Precautions
IMPORTANT SAFE UARDS 6
To ensure safe driving 6
To avoid battery exhaustion 7
Before You Start
Information to User 8
For Canadian model 8
About this unit 8
About this manual 10
After sales service for Pioneer products 10
Product registration 10
Features 10
To protect the LCD screen 12
For viewing LCD comfortably 12
Condition memory 12
What the marks on DVDs indicate 12
Resetting the microprocessor 13
Use and care of the remote control 13
About the SAT RADIO READY mark 14
Feature demo 14
Whats What
Head unit 15
Remote control 17
Basic Operations
Turning the unit on and selecting a
source 20
Loading a disc 21
Adjusting the volume 21
Turning the unit off 21
Using the rear display 21
Displaying the navigation image 22
Touch panel key basic operation 22
Opening and closing the LCD panel 23
Changing the wide screen mode 24
Adjusting the picture adjustment 25
Protecting your unit from theft 26
Tuner
Listening to the radio 28
Introduction of advanced tuner
operation 29
Storing and recalling broadcast
frequencies 29
Tuning in strong signals 29
Storing the strongest broadcast
frequencies 30
P aying DVD audio discs
Listening to a DVD audio 31
Operating the DVD menu 32
Skipping back or forward to another
group 32
Stopping playback 32
Introduction of advanced DVD audio
operation 33
Repeating play 33
Playing tracks in a random order 33
Scanning tracks 33
Pausing DVD audio playback 34
Browsing still pictures 34
Frame by frame playback 34
Slow motion playback 35
Searching for a desired track or group 35
Changing audio language during playback
(Multi audio) 36
Changing the subtitle language during
playback (Multi subtitle) 36
Contents
En
2

Changing the viewing angle during playback
(Multi angle) 36
Using the dynamic range control 37
P aying DVD video discs
Watching a DVD video 38
Operating the DVD menu 39
Skipping back or forward to another title 39
Stopping playback 39
Introduction of advanced DVD video
operation 40
Repeating play 40
Pausing DVD video playback 40
Frame by frame playback 40
Slow motion playback 41
Searching for a desired scene, starting
playback from a specified time 41
Changing audio language during playback
(Multi audio) 42
Changing the subtitle language during
playback (Multi subtitle) 42
Changing the viewing angle during playback
(Multi angle) 43
Using the dynamic range control 43
P aying Video CDs
Watching a Video CD 44
Operating the menu 45
Stopping playback 45
Introduction of advanced Video CD
operation 46
Repeating play 46
Pausing Video CD playback 46
Frame by frame playback 47
Slow motion playback 47
Searching for a desired scene, starting
playback from a specified time 47
Selecting audio output 48
P aying CDs
Listening to a CD 49
Stopping playback 49
Introduction of advanced CD operation 50
Repeating play 50
Playing tracks in a random order 50
Scanning tracks of a CD 50
Pausing CD playback 51
Entering disc titles 51
Using CD TEXT functions 52
P aying MP3
Listening to MP3 53
Stopping playback 54
Introduction of advanced MP3 operation 54
Repeating play 55
Playing tracks in a random order 55
Scanning folders and tracks 55
Pausing MP3 playback 55
Displaying text information on MP3
discs 56
Scrolling text information in the display 56
Selecting tracks from the file name list 56
Mu ti-CD P ayer
Listening to a CD 57
50 disc multi CD player 57
Introduction of advanced multi CD player
operation 58
Repeating play 58
Playing tracks in a random order 58
Scanning CDs and tracks 59
Pausing CD playback 59
Using ITS playlists 59
Using disc title functions 61
Using CD TEXT functions 62
Using compression and bass emphasis 62
En 3
Contents

XM tuner
Listening to the XM 64
Introduction of advanced XM tuner
operation 65
Switching the XM display 65
Storing and recalling broadcast stations 65
Swiching the XM channel select setting 65
Selecting the XM channel directly 66
Display the ID code 66
TV tuner
Watching the television 67
Introduction of advanced TV tuner
operation 68
Storing and recalling broadcast stations 68
Storing the strongest broadcast stations
sequentially 68
Confirming current channel and other
settings 69
DVD P ayer
Playing a disc 70
Turning the DVD player on or off 71
Selecting a disc 71
Introduction of advanced DVD player
operation 71
Repeating play 71
Pausing disc playback 72
Playing tracks in a random order 72
Scanning tracks of a CD 72
Using ITS playlists 72
Using disc title functions 72
Audio Adjustments
Introduction of audio adjustments 73
Using the equalizer 74
Using the auto equalizer 75
Using the position selector 76
Using balance adjustment 76
Adjusting source levels 76
Using the direct control 77
Using the Dolby Pro Logic II 77
Setting the speaker setting 78
Selecting a cut off frequency 79
Adjusting the speaker output levels 79
Adjusting the speaker output levels using a
test tone 79
Using the time alignment 80
Auto TA and EQ (auto time alignment and
auto equalizing) 81
Setting up the DVD p ayer
Introduction of DVD setup adjustments 84
Setting the subtitle language 84
Setting the audio language 85
Setting the menu language 85
Setting assist subtitles on or off 85
Setting angle icon display 86
Setting the aspect ratio 86
Setting the parental lock 86
To play back bonus groups 87
Setting remote control code type 87
Initia Settings
Adjusting initial settings 89
Switching the warning tone 89
Switching the auxiliary setting 89
Correcting distorted sound 89
Switching the sound muting/attenuation 90
Switching the automatic disc playback 90
Switching the dimmer setting for sub
display 90
Resetting the audio functions 90
Mixing navigation voice/beep and audio
sound 91
Other Functions
Introduction of setup adjustments 92
Contents
En
4

Setting the video input 92
Setting for rear view camera 92
Setting the clock 93
Setting the automatic open function 93
Adjusting the LCD panel slide position 94
Setting the video of rear display 94
Displaying the navigation image on rear
display 94
Using the AUX source 94
Switching the background display 95
Using the P M button 96
Additiona Information
Troubleshooting 97
Error messages 99
Understanding auto TA and EQ error
messages 100
DVD player and care 101
DVD discs 101
CD R/CD RW discs 101
MP3 files 102
Using the display correctly 103
Language code chart for DVD 105
Terms 106
Specifications 109
Index 111
En 5
Contents

IMPORTANT SAFEGUARDS
Please read all of these instructions regarding
your display and retain them for future refer
ence.
1Read this manua fu y and carefu y be-
fore operating your disp ay.
2Keep this manua handy as a reference for
operating procedures and safety informa-
tion.
3Pay c ose attention to a warnings in this
manua and fo ow the instructions care-
fu y.
4Do not a ow other persons to use this sys-
tem unti they have read and understood
the operating instructions.
5Do not insta the disp ay where it may (i)
obstruct the drivers vision, (ii) impair the
performance of any of the vehic es oper-
ating systems or safety features, inc ud-
ing air bags, hazard amp buttons or (iii)
impair the drivers abi ity to safe y oper-
ate the vehic e.
6As with any accessory in your vehic es in-
terior, the disp ay shou d not divert your
attention from the safe operation of your
vehic e. If you experience difficu ty in op-
erating the system or reading the disp ay,
p ease park safe y before making adjust-
ments.
7Do not attempt to insta or service your
disp ay by yourse f. Insta ation or servi-
cing of the disp ay by persons without
training and experience in e ectronic
equipment and automotive accessories
may be dangerous and cou d expose you
to the risk of e ectric shock or other ha-
zards and can cause damage to the sys-
tem that is not covered by warranty.
8P ease remember to wear your seat be t at
a times whi e operating your vehic e. If
you are ever in an accident, your injuries
can be considerab y more severe if your
seat be t is not proper y buck ed.
To ensure safe driving
WARNING
!LIGHT GREEN LEAD AT POWER CON-
NECTOR IS DESIGNED TO DETECT
PARKED STATUS AND MUST BE CON-
NECTED TO THE POWER SUPPLY SIDE
OF THE PARKING BRAKE SWITCH. IM-
PROPER CONNECTION OR USE OF
THIS LEAD MAY VIOLATE APPLICABLE
LAW AND MAY RESULT IN SERIOUS IN-
JURY OR DAMAGE.
!To avoid the risk of accident and the potential
violation of applicable laws, the front DVD or
TV (sold separately) feature should never be
used while the vehicle is being driven. Also,
rear displays should not be in a location
where it is a visible distraction to the driver.
!In some countries or states the viewing of
images on a display inside a vehicle even by
persons other than the driver may be illegal.
Where such regulations apply, they must be
obeyed.
This unit detects whether your vehicles park
ing brake is engaged or not, and prevents you
from watching a DVD or TV on the front dis
play while driving. When you attempt to watch
a DVD or TV, the warning VIDEO VIEWING IS
NOT AVAILABLE WHILE DRIVING will appear
on the front display.
Parking brake interlo k
Certain functions offered by this unit could be
dangerous and/or unlawful if used while driv
ing. To prevent such functions from being
used while the vehicle is in motion, there is an
interlock with the vehicles parking brake. If
you attempt to use these functions while driv
ing, they may be inoperable.
Pre autions
En
6
Section
01

To watch a video source such as DVD or TV on
the front seat display, park your vehicle in a
safe place, apply the parking brake, release
the parking brake, and then apply the parking
brake again. When performing the above se
quence with the parking brake (apply release
apply), keep the brake pedal pushed down be
fore releasing the parking brake if the vehicle
is parked on a hill or otherwise might move
when releasing the parking brake.
WARNING
!When applying, releasing and applying the
parking brake in order to view video source or
to enable other functions offered by this unit,
park your vehicle in a safe place, and keep the
brake pedal pushed down before releasing the
parking brake if the vehicle is parked on a hill
or otherwise might move when releasing the
parking brake.
When using a display
onne ted to REAR OUT
This unitsREAR OUT is for connection of a
display to enable passengers in the rear seats
to watch the DVD or TV.
WARNING
NEVER install the rear display in a location that
enables the driver to watch the DVD or TV while
driving.
To avoid battery exhaustion
Be sure to run the vehicle engine while using
this unit. Using this unit without running the
engine can result in battery drainage.
WARNING
Do not use with vehicles that do not feature an
ACC position.
Pre autions
En 7
Section
01
Pre autions

Information to User
Alteration or modifications carried out without
appropriate authorization may invalidate the
users right to operate the equipment.
For Canadian model
This Class B digital apparatus complies with
Canadian ICES 003.
About this unit
The tuner frequencies on this unit are allo
cated for use in North America. Use in other
areas may result in poor reception.
WARNING:
Handling the cord on this product or cords asso
ciated with accessories sold with the product
may expose you to chemicals listed on proposi
tion 65 known to the State of California and other
governmental entities to cause cancer and birth
defects or other reproductive harm. Wash hands
after handling.
This product contains mercury. Disposal of this
material may be regulated due to environmental
considerations. For disposal or recycling informa
tion, please contact your local authorities or the
Electronics Industries Alliance: www.eiae.org.
CAUTION:
USE OF CONT OL O ADJUSTMENT O
PE FO MANCE OF P OCEDU ES
OTHE THAN THOSE SPECIFIED HE EIN
MAY ESULT IN HAZA DOUS ADIATION
EXPOSU E.
CAUTION:
THE USE OF OPTICAL INST UMENTS
WITH THIS P ODUCT WILL INC EASE
EYE HAZA D.
CAUTION
!Do not allow this unit to come into contact
with liquids. Electrical shock could result.
Also, this unit damage, smoke, and overheat
could result from contact with liquids.
!Keep this manual handy as a reference for op
erating procedures and precautions.
!Always keep the volume low enough so that
you can hear sounds from outside the vehicle.
!Protect this unit from moisture.
!If the battery is disconnected or discharged,
the preset memory will be erased and must be
reprogrammed.
Important (Seria number)
The serial number is located on the bottom of
this unit. For your own security and convenience,
be sure to record this number on the enclosed
warranty card.
Playable dis s
DVD, Video CD and CD discs that display the
logos shown below can be played back on this
player.
Before You Start
En
8
Section
02

DVD audio
DVD video
Video CD
CD
Notes
!is a trademark of DVD Format/Logo Li
censing Corporation.
!This player can only play back discs bearing
the marks shown above.
DVD video dis region numbers
DVD video discs that have incompatible region
numbers cannot be played on this player. The
region number of the player can be found on
the bottom of this unit.
The illustration below shows the regions and
corresponding region numbers.
When ombined with a Pioneer
navigation unit
When you use this unit with the Pioneer DVD
navigation unit, make sure that you use the
map disc CNDV 21 or later. This manual ex
plains the operations with the combined use
of them.
If you do not use the map disc CNDV 21 but
use an older version with the navigation unit,
this unit may have some failures or inconve
niences as follows:
!ENTERTAINMENT button and WIDE button
cannot function as NAVI MENU button
and NAVI button.
!NAVI (navigation unit), such as DVD video
from the combined Pioneer navigation unit
with DVD video playback, cannot be se
lected as a source.
!In NAVI MIXING, the settings other than
ALL cannot be selected.
!Voice recognition control system of the
combined Pioneer navigation unit cannot
function properly. The voice operation for
navigation can be used, but the voice op
eration related to AV equipment cannot be
used.
Before You Start
En 9
Section
02
Before You Start

!Route guidance of the combined Pioneer
navigation unit cannot function properly
when some other source images are dis
played. uidance by voice can be obtained,
but on guidance by display (e.g. switching
to an enlarged map of an intersection) can
not be obtained.
!NAVI BG PICT (navigation unit wallpaper)
cannot be selected as a background dis
play.
About this manual
This unit features a number of sophisticated
functions ensuring superior reception and op
eration. All the functions have been designed
for the easiest possible use, but many are not
self explanatory. This operation manual will
help you benefit fully from this units potential
and to maximize your listening enjoyment.
We recommend that you familiarize yourself
with the functions and their operation by read
ing through the manual before you begin
using this unit. It is especially important that
you read and observe WARNINGs and CAU-
TIONs in this manual.
After-sales servi e for
Pioneer produ ts
Please contact the dealer or distributor from
where you purchased this unit for after sales
service (including warranty conditions) or any
other information. In case the necessary infor
mation is not available, please contact the
companies listed below:
Please do not ship your unit to the companies
at the addresses listed below for repair without
advance contact.
U.S.A.
Pioneer Electronics (USA) Inc.
CUSTOMER SUPPORT DIVISION
P.O. Box 1760
Long Beach, CA 90801 1760
800 421 1404
CANADA
Pioneer Electronics of Canada, Inc.
CUSTOMER SATISFACTION DEPARTMENT
300 Allstate Parkway
Markham, Ontario L3R OP2
1 877 283 5901
For warranty information please see the Lim
ited Warranty sheet included with this unit.
Produ t registration
Visit us at the following site:
1 Register your product. We will keep the details
of your purchase on file to help you refer to
this information in the event of an insurance
claim such as loss or theft.
2 Receive updates on the latest products and
technologies.
3 Download owners manuals, order product
catalogues, research new products, and
much more.
Features
Tou h panel key operation
It is possible to operate this unit by using
touch panel key.
Before You Start
En
10
Section
02

DVD audio playba k
It is possible to play back DVD audio.
DVD video playba k
It is possible to play back DVD video, DVD R
(video mode) and DVD RW (video mode).
Video CDs featuring PBC ompatibility
It is possible to play back Video CDs featuring
PBC (playback control).
CD playba k
Music CD/CD R/CD RW playback is possible.
MP3 file playba k
You can play back MP3 files recorded on CD
ROM/CD R/CD RW (ISO9660 Level 1/Level 2
standard recordings).
!Supply of this product only conveys a li
cense for private, non commercial use and
does not convey a license nor imply any
right to use this product in any commercial
(i.e. revenue generating) real time broad
casting (terrestrial, satellite, cable and/or
any other media), broadcasting/streaming
via internet, intranets and/or other net
works or in other electronic content distri
bution systems, such as pay audio or
audio on demand applications. An inde
pendent license for such use is required.
For details, please visit
http://www.mp3licensing.com.
NTSC ompatibility
This unit is NTSC system compatible. When
connecting other components to this unit, be
sure components are compatible with the
same video system otherwise images will not
be correctly reproduced.
Dolby Digital/DTS ompatibility
You can enjoy the atmosphere and excitement
provided by DVD movie and music software
featuring 5.1 channel recordings.
!Manufactured under license from Dolby La
boratories. Dolby,Pro Logic, and the
double D symbol are trademarks of Dolby
Laboratories.
!DTSand DTS Digital Surroundare regis
tered trademarks of Digital Theater Sys
tems, Inc.
Multi-aspe t
Switching between wide screen, letterbox and
panscan display is possible.
Multi-audio
You can switch between multiple audio sys
tems recorded on a DVD as desired.
Multi-subtitle
You can switch between multiple subtitle lan
guages recorded on a DVD as desired.
Multi-angle
You can switch between multiple viewing an
gles of a scene recorded on a DVD as desired.
Before You Start
En 11
Section
02
Before You Start

Note
This product incorporates copyright protection
technology that is protected by method claims of
certain U.S. patents and other intellectual prop
erty rights owned by Macrovision Corporation
and other rights owners. Use of this copyright
protection technology must be authorized by
Macrovision Corporation, and is intended for
home and other limited viewing uses only unless
otherwise authorized by Macrovision Corporation.
Reverse engineering or disassembly is
prohibited.
To prote t the LCD s reen
!Do not allow direct sunlight to fall on the
display when this unit is not being used.
Extended exposure to direct sunlight can
result in LCD screen malfunction due to
the resulting high temperatures.
!When using a portable phone, keep the an
tenna of the portable phone away from the
display to prevent disruption of the video by
the appearance of spots, colored stripes,
etc.
For viewing LCD omfortably
Due to its construction, the view angle of the
LCD screen is limited. The viewing angle (verti
cal and horizontal) can be increased, however,
by using BRIGHT to adjust the black density of
the video. When using for the first time, adjust
the black density in accordance with the view
ing angle (vertical and horizontal) to adjust for
clear viewing. DIMMER can also be used to
adjust the brightness of the LCD screen itself
to suit your personal preference.
Condition memory
This function memorizes audio language, sub
title language, angle number and aspect ratio
made during disc playback for up to 30 discs.
Without any special operations, the final set
ting details during playback of a disc are mem
orized. The next time a disc is played, the
previous settings are automatically applied.
!With some discs, audio language and sub
title language are automatically specified,
in which case condition memory does not
function.
!When the number of discs exceeds 30, set
tings for the latest disc replace those for
the least recent disc.
What the marks on DVDs
indi ate
The marks below may be found on DVD disc
labels and packages. They indicate the type of
images and audio recorded on the disc, and
the functions you can use.
Mark Meaning
2Indicates the number of audio sys
tems.
2Indicates the number of subtitle lan
guages.
3Indicates the number of viewing an
gles.
16 : 9 LB Indicates the picture size (aspect ratio:
screen width to height ratio) type.
1
ALL
Indicates the number of the region
where playback is possible.
Before You Start
En
12
Section
02

When an operation is prohibited
When you are watching a DVD and attempt to
perform an operation, it may not be performed
because of the programming on the disc.
When this happens, the icon appears on
the screen.
!The icon may not appear with certain
discs.
Resetting the mi ropro essor
Pressing RESET lets you reset the micropro
cessor to its initial settings without changing
the condition memory.
The microprocessor must be reset under the
following conditions:
!Prior to using this unit for the first time
after installation
!If the unit fails to operate properly
!When strange or incorrect messages ap
pear on the display
1 Turn the ignition s itch OFF.
2 Press RESET ith a pen tip or other
pointed instrument.
RESET button
Notes
!When using with a Pioneer navigation unit, if
you press RESET, be sure ACC OFF is se
lected. If ACC ON is selected, correct opera
tion may not be possible even if you press
RESET.
!After completing connections or when you
want to erase all memorized settings or return
the unit to its initial (factory) settings, switch
your engine ON or set the ignition switch to
ACC ON before pressing RESET.
Use and are of the remote
ontrol
Installing the battery
Slide the tray out on the back of the remote
control and insert the battery with the plus (+)
and minus () poles pointing in the proper di
rection.
!When using for the first time, pull out the
film protruding from the tray.
WARNING
Keep the battery out of the reach of children.
Should the battery be swallowed, immediately
consult a doctor.
CAUTION
!Use only one CR2025 (3 V) lithium battery.
!Remove the battery if the remote control is not
used for a month or longer.
!Do not recharge, disassemble, heat or dispose
of the battery in fire.
!Do not handle the battery with metallic tools.
!Do not store the battery with metallic materi
als.
Before You Start
En 13
Section
02
Before You Start

!In the event of battery leakage, wipe the re
mote control completely clean and install a
new battery.
!When disposing of used batteries, please
comply with governmental regulations or en
vironmental public institutionsrules that
apply in your country/area.
Using the remote ontrol
Point the remote control in the direction of the
front panel to operate.
!The remote control may not function prop
erly in direct sunlight.
Important
!Do not store the remote control in high tem
peratures or direct sunlight.
!Do not let the remote control fall onto the
floor, where it may become jammed under the
brake or accelerator pedal.
About the SAT RADIO
READY mark
The SAT RADIO READY mark printed on the
front panel indicates that the Satellite Radio
Tuner for Pioneer (aka, XM tuner and Sirius sa
tellite tuner which are sold separately) can be
controlled by this unit. Please inquire to your
dealer or nearest authorized Pioneer service
station regarding the satellite radio tuner that
can be connected to this unit. For satellite
radio tuner operation, please refer to the satel
lite radio tuner owners manual.
Notes
!The system will use direct satellite to receiver
broadcasting technology to provide listeners
in their cars and at home with crystal clear
sound seamlessly from coast to coast. Satel
lite radio will create and package over 100
channels of digital quality music, news,
sports, talk and childrens programming.
!SAT Radio, the SAT Radio logo and all re
lated marks are trademarks of Sirius Satellite
Radio inc., and XM Satellite Radio Inc.
Feature demo
Important
The red lead (ACC) of this unit should be con
nected to a terminal coupled with ignition switch
on/off operations. If this is not done, the vehicle
battery may be drained.
The feature demo automatically starts when
power to this unit is turned off while the igni
tion switch is set to ACC or ON. Pressing and
holding ATT during feature demo operation
cancels the feature demo mode. Press and
hold ATT again to start the feature demo
mode. Remember that if the feature demo
continues operating when the car engine is
turned off, it may drain battery power.
Before You Start
En
14
Section
02

Head unit
1DISPLAY button
Press to select different displays.
2PGM button
Press to operate the preprogrammed func
tions for each source. (Refer to Using the
PG button on page 96.)
3Ambient light sensor
Senses ambient light. This system automati
cally adjusts the brightness of the display to
compensate for ambient light.
4FLIP DOWN/CLOCK button
Press to turn the LCD panel horizontal tem
porarily from upright position.
Press to display the clock for eight seconds
when the LCD panel is closed.
5OPEN/CLOSE button
Press to open or close the LCD panel.
6ENTERTAINMENT button
Press to switch between the background
displays.
7WIDE button
Press to select a desired mode for enlarging
a 4:3 picture to a 16:9 one.
8MENU button
Press and hold to display the picture adjust
ment menu.
9RESET button
Press to return to the factory settings (initial
settings).
aDETACH button
Press to remove the front panel from the
head unit.
bEJECT button
Press to eject a disc from this unit.
1
2
4
5
3
6
7
a
c
d
e
f
g
h
i
l
k
9
j
8
b
Whats What
En 15
Section
03
Whats What

cJoystick
Move to do manual seek tuning, fast for
ward, reverse and track search controls.
Also used for controlling functions.
dEQ button
Press to select various equalizer curves.
eBAND/ESC button
Press to select among three FM bands and
one AM band and to cancel the control
mode of functions.
fANGLE (+/) button
Press to change the LCD panel angle.
gATT button
Press to quickly lower the volume level, by
about 90%. Press once more to return to the
original volume level.
hBACK button
Press to return to the previous display.
iREAR ON button
Press to switch between the video sources
(such as DVD or AV) on rear display.
jDisc loading slot
Insert a disc to play.
kSOURCE button
This unit is turned on by selecting a source.
Press to cycle through all the available
sources.
lVOLUME
Rotate it to increase or decrease the
volume.
Whats What
En
16
Section
03

Remote ontrol
1Remote control selection s itch
Switch to change the setting of the remote
control. For details, refer to Setting remote
control code type on page 87.
2VOLUME button
Press to increase or decrease the volume.
3REAR.S button
Press to switch between the video sources
(such as DVD or AV) on rear display.
4SOURCE button
This unit is turned on by selecting a source.
Press to cycle through all the available
sources.
5Joystick
Move to do manual seek tuning, fast for
ward, reverse and track search controls.
Also used for controlling functions.
6DIRECT button
Press to do direct channel select when
using an XM tuner.
7Remote control operation mode s itch
Switch the operation mode between AVH,
DVD and TV modes. Normally, set to AVH.
!AVH For common operation of this
unit
!DVD Only for DVD player operation
!TV Only for TV tuner operation
For details, refer to Using the remote control
operation mode switch on the next page.
8PGM button
Press to operate the preprogrammed func
tions for each source. (Refer to Using the
PG button on page 96.)
9BACK button
Press to return to the previous display.
5
2
3
4
7
9
a
b
c
d
f
g
e
h
i
k
m
o
q
l
p
r
n
j
8
6
1
Whats What
En 17
Section
03
Whats What

aBAND/ESC button
Press to select among three FM bands and
one AM band and to cancel the control
mode of functions.
bENTERTAINMENT button
Press to switch between the background
displays.
cFORWARD (n) button
Press to perform fast forward.
dSTOP (g) button
Press to stop playback.
eNEXT (p) button
Press to go to the next track (chapter).
fCLEAR button
Press to cancel the input number when
010 are used.
g010 buttons
Press to directly select the desired track,
preset tuning or disc. Buttons 16can oper
ate the preset tuning for the tuner or disc
number search for the multi CD player.
hPREVIOUS (o) button
Press to return to the previous track (chap
ter).
iREVERSE (m) button
Press to perform fast reverse.
jPLAY/PAUSE (f) button
Press to switch sequentially between play
back and pause.
kANGLE button
Press to change the viewing angle during
DVD playback.
lSTEP (r/q) button
Press to move ahead one frame at a time
during DVD/VideoCD playback. Press and
hold for one second to activate slow play
back.
mSUBTITLE (SUB.T) button
Press to change the subtitle language dur
ing DVD playback.
nDISPLAY button
Press to select different displays.
oAUDIO button
Press to change the audio language during
DVD playback.
pRETURN button
Press to display the PBC (playback control)
menu during PBC playback.
qMENU button
Press to display the DVD menu during DVD
playback.
rTOP MENU (TOP.M) button
Press to return to the top menu during DVD
playback.
Using the remote ontrol
operation mode swit h
There are three remote control operation
modes on the remote control.
AVH mode operation
When operating this unit by remote control,
the mode is normally switched to AVH.
!The joystick on the remote control can per
form the same operations as the one on
the head unit. Furthermore, the joystick
can perform the same operations as the
touch panel keys a,b,cand d.
Whats What
En
18
Section
03

!16can perform the same operations as
the preset tuning keys P1P6and the
disc selection keys 0106.
If you want to select a disc located at 7
to 12 by using buttons 16, press and
hold the corresponding numbers, such
as 1for disc 7, until the disc number ap
pears in the display.
DVD mode operation
If you switch the mode to DVD, the joystick
and 010 operations are changed for DVD
player.
%When you ant to operate the follo -
ing functions, s itch the mode to DVD:
!When browsing still pictures by using the
joystick. (Refer to Browsing still pictures on
page 34.)
!When operating the DVD menu by using
the joystick. (Refer to Operating the DVD
menu on page 39.)
!When operating the PBC menu by using
010. (Refer to Watching a Video CD on
page 44.)
!When specifying group, title or track by
using 010. (Refer to Specifying group on
page 35, Specifying title on page 42 and Spe-
cifying track on page 48.)
Note
When switching the mode to DVD, you cannot
use these buttons; BACK,ENTERTAINMENT,
DISPLAY,PGM and DIRECT.
TV mode operation
If you use the rear output on TV tuner, you can
watch the TV picture on the rear display inde
pendently. To operate the TV on the rear dis
play independently, switch the mode to TV.In
this case, the joystick operation is changed for
TV.
!For details concerning operation, refer to
the TV tuners operation manuals.
%When you ant to operate the follo -
ing functions only on the rear display,
s itch the mode to TV:
!When performing manual or seek tuning by
moving the joystick left or right.
!When recalling preset stations by moving
the joystick up or down.
!When confirming current channel and
other settings by pressing DIRECT. (Refer to
Confirming current channel and other set-
tings on page 69.)
Note
When switching the mode to TV, you cannot use
except the joystick, DIRECT,SOURCE and
VOLUME.
Whats What
En 19
Section
03
Whats What

Turning the unit on and
sele ting a sour e
1
1Source icon
Shows which source has been selected.
You can select a source you want to listen to. If
DVD AUTO PLAY is turned on, load a disc in
the unit to switch to DVD (refer to Switching
the automatic disc playback on page 90).
%When using the touch panel keys,
touch the source icon and then touch the
desired source name.
The source names are displayed and select
able ones are highlighted.
!DVD Built in DVD player
!S-DVD DVD player/multi DVD player
!M-CD Multi CD player
!TUNER Tuner
!TV Television
!AV Video input
!EXT1 External unit 1
!EXT2 External unit 2
!AUX AUX
!XM XM tuner
!NAVI Navigation unit
!OFF Turn the unit off
#When the source icon is not displayed, you
can display it by touching the screen.
#While operating the menu, you cannot select
a source by touching the source icon.
#To return to the playback display, touch ESC.
%When using the button, press SOURCE
to select a source.
Press SOURCE repeatedly to switch between
the following sources:
XM (XM tuner)TUNER (tuner)TV (televi
sion)AV (video input)DVD (built in DVD
player)S-DVD (DVD player/multi DVD
player)M-CD (multi CD player)EXT1 (ex
ternal unit 1)EXT2 (external unit 2)AUX
(AUX)NAVI (navigation unit)
Notes
!In the following cases, the sound source will
not change:
When there is no unit corresponding to the
selected source connected to this unit.
When there is no disc in the unit.
When there is no disc in the DVD player.
When there is no magazine in the multi
CD player.
When there is no magazine in the multi
DVD player.
When the AUX (auxiliary input) is set to off
(refer to page 89).
When the AV (video input) is not set to
VIDEO (refer to page 92).
!External unit refers to a Pioneer product (such
as one available in the future) that, although
incompatible as a source, enables control of
basic functions by this unit. Two external units
can be controlled by this unit. When two exter
nal units are connected, the allocation of
them to external unit 1 or external unit 2 is
automatically set by this unit.
!When this units blue lead is connected to the
cars auto antenna relay control terminal, the
cars antenna extends when this units se
lected source is the tuner. To retract the anten
na, switch to a source other than the tuner.
Basi Operations
En
20
Section
04
