Pioneer 2DM300 Operating and maintenance instructions

A
B
C
D
E
F
G
H
I
J
1
2
3
4
5
ITEM # DESCRIPTION
A X-1200006* DM Lever Handle
B X-4900007 Bonnet Nut
C X-4200021* Deck Plate
D X-3900002C,H Ceramic Stem-Cold,Hot
E X-4200022 Base Plate
F X-4900008 Mounting Kit
G X-4900004 Supply Nuts
H X-2200004* DM High Gooseneck Spout
I X-4200016 Diverter Piston (For 2DM301)
J X-4200018* Side Spray Assembly (For 2DM301)
1 X-4900002 3/32” Allen Screw
2 X-4200114* 1.5 GPM Aerator
3 X-4200020* Spout Bonnet Nut
4 X-4900013 Spout Snap Ring
5 X-4900012 Spout O-rings
For more care information or trouble shooting inquiries
about your Pioneer product, please call:
Pioneer Industries, Inc. [phone]
Monday-Friday 8AM to 8PM EST (5AM to 5PM PST)
www.pioneerind.com

A
B
C
D
E
F
G
1
2
3
4
H
ITEM # DESCRIPTION
A X-1200008C,H* Lever Handle-Cold,Hot
B X-3200004C,H Ceramic Stem-Cold,Hot
C X-4200063* Escutcheon and Gasket
D X-4900008 Mounting Kit
E X-4900004 Supply Nuts
F X-2200013* Americana Spout
G X-4200016 Diverter Piston (For 2AM501)
H X-4200059* Side Spray Assembly (For 2AM501)
1 X-4900042C,H* Handle Button-Cold, Hot
2 X-4900035 Handle Screw
3 X-4900091* 1.5 GPM Aerator
4 X-4900012 Spout O-Rings
For more care information or trouble shooting inquiries
about your Pioneer product, please call:
Pioneer Industries, Inc. [phone]
Monday-Friday 8AM to 8PM EST (5AM to 5PM PST)
www.pioneerind.com
