Pixel Vertax D11 User manual

使用说明书
1
3
4
5
6
7
10
11
9
12
15
14
13
电池盒兼手柄 Vertax D11
1接口盖
2相机接口盖支架
3电源/信号接点
4AE-L/AF-L按钮
5主指令拨盘
6多重选择器
7锁定螺旋钮
8电池座电源连接器盖
9电池仓锁把手
10 定位销
11 固定螺丝
12 快门释放按钮
13 控制锁
14 副指令拨盘
19 电源终端
20 Vertax D11
(用于AA电池)
电池座
15 三脚架插孔
16 电源终端
17 电源终端
18 Vertax D11EN电池座
(用于EN-EL15电池)
16
17
部件名称
2
85
6
7
8
1
3
4
A
B
18
19
20
9
10
1Contact cap
2
3
4
5
6
7
8Holder power connector cover
9Battery magazine release handle
10 Guide pin
11 Mounting screw
12
13 Control lock
14 Sub-command dial
19
20 Vertax D11 magazine for AA batteries
15 Tripod socket
16 Power terminals
17
18 Vertax D11EN magazine
for EN-EL15 batteries
Holder for camera contact cover
Power/signal contacts
AE-L/AF-L button
Main command dial
Multi selector Attachment wheel
Attachment wheel
Power terminals
Power terminals
Shutter-release button
A已锁定
Locked B未锁定
Unlocked
( )Name of each part
Instruction Manual
2

Vertax D11
柄具备一个交替式快门释放按钮，AE-L/AF-L按键，多重选择器及用於在纵向拍摄照片的主副指令
拨盘。
在使用本产品之前，请务必仔细阅读本使用说明书。
请务必妥善保管好本书，以便日后能随时查阅。
请在充分理解内容的基础上，正确使用。
是一个可以装一个电池EN-EL15或6个AA/LR6尺寸电池的电池盒兼手柄。本电池手
使用说明书使用说明书
感谢你购买品色产品。
Vertax D11
电池盒兼手柄 电池盒兼手柄
注意事项
PSM83 V10.02
1、
2、为了防止因金属物质接触电源终端而引起的短路，不使用Vertax D11时，请盖上接口盖。
3、当从Vertax D11取下电池座时，为防止因接触其它金属物体而引起短路，请取出电池或将电池座
或电池舱盖放入电池座盒中保存。
4、安装或从相机取出Vertax D11时,存储卡存取指示灯可能点亮,但这不是故障。
5、安装电池时极性切勿弄反，否则电池可能渗漏腐蚀性液体、发热或爆炸。
6、请勿置于高温中，如阳光直射下的封闭汽车内、控制面板等高温地方。
7、请保持干燥，勿用湿手接触产品，亦不可将产品浸入水中或暴露雨中，否则可能引起无法正常使
用。
8、请勿在易燃气体中使用，违反此警告可能引起爆炸或火灾。
9、本产品涉及电池，关于电池的使用请严格按照相应的操作规范，否则可能引起 爆炸、火灾或人身
伤害。
Vertax D11只能用于与其兼容的相机。
安装相机
1、从Vertax D11上取下接口盖(图2)。
2、从相机底部取下接口盖，安装到Vertax D11相机接口盖支架上(图3)。
3、定位Vertax D11，使Vertax D11固定螺丝（图4-B）与相机三脚架插孔（图4-A）对齐(图4)。
4、按照LOCK的箭头所示方向旋紧锁定螺旋钮(图5)。
安装相机前，请确认Vertax D11的控制锁处于锁定状态（图1-A）
这些控制按钮以竖直（人像）方向拍摄照片前，请按照（图1-B）所示解除锁定。
控制锁不是电源开关。请使用相机电源开关开启或关闭相机。
，以防止无意间被使用。使用
卸下电池匣
本说明书中的信息更新至2012年04月01日，如果要与此日期之后发布的产品组合使用，
有关信息请向品色经销商咨询。
现在，你可以体验无与伦比的品色产品。如有任何疑问可以向当地经销商咨询，或登陆
http://www.pixelhk.com.cn查询
当你要卸下Vertax D11，请关闭相机并将Vertax D11上的控制锁拨动到L位置。然后旋松锁定螺
旋钮，即可卸下Vertax D11。
不使用电池匣时，请务必重新盖上相机和Vertax D11上各自的接口盖。
可与1块EN-EL15锂离子可充电电池或6节AA电池一起使用。在插入电池前，
请确保相机电源处于关闭状态，并且Vertax D11控制锁处于L位置。
1、将电池仓锁把手向上拨(图6)，旋转电池仓锁把手至[ ](图7)，取出电池仓(图8)。
2、安装方法：
Vertax D11
EN-EL15: Vertax D11EN
电池座电源终端的方向插入电池。轻按电池，将其按照箭头所示方向滑入，直到电源终端卡
到正确位置发出咔嗒声(图9)。
AA电池：将6节AA电池装入Vertax D11电池座，同时请确保电池的装入方向正确(图10)。
将电池的凹槽对准 电池座上的突起部分，然后以电池上的箭头（▲）朝
向下
3 将电池座插入 并锁住电池舱盖。锁住前，请确认电池座已完全插好。
4 、开启相机并在控制面板或取景器中检查电池电量级别。若相机未开启，请确认电池已正确插入。
、Vertax D11 在
EN-EL15 电池
当温度低于约10°C时，EN-EL15电池的性能会减弱。请务必将电池充满电，并准备好一个暖和的
备用电池以便需要时进行更换。电池回暖后，其电量将会有所恢复。
AA 电池
由于AA LR6碱性电池的容量有限，请仅在没有其它电池可供选择时使用。
A 电池的容量随制作工艺和储存环境的不同而变化，有时容量可能极其低；在某些情况下，AA电池
可能会在使用寿命未到之前停止工作。请注意AA电池的容量在周围环境温度低于20°C时可能会降
低。不建议在低温环境中使用。
Vertax D11EN电池座(用于EN-EL15电池) 1个
说明书 1份
规格
电源 (1)一个电池EN-EL15
(2)６个AA/LR6尺寸碱性电池
工作温度范围 0℃-+40℃
尺寸 约132.6x x ｍｍ53.2 84.7
重量 约191.8克(不含电池和电池夹的重量)
制造商：品色（香港）企业有限公司
地 址：香港九龙荔枝角青山道704号合兴工业大厦4楼
电 话：(852) 2384-1188
产品规格及外观如有变化，恕不另行通知。
安装电池
A
随附物品
1 、 （d14组）
个选项改变电池使用顺序(图A)。
2、当 时，( )图标将显示在
控制面板中。若( )图标闪烁，表示电池舱盖未锁好，
请关闭并锁上电池舱盖(图B)。
您可使用相机个人设定菜单 组中的一
相机由Vertax D11供电
电池设定
3 、为确保相机由AA电池供电时能正确显示电池电量，
请在相机个人设定菜单（d13组）的电池类型中选择合
适的选项。若未选择正确的选项，相机将可能无法正常
操作(图C)。
4、 (图D)。电池信息可从相机设定菜单中查看
Vertax D11电池盒兼手柄 1个
Vertax D11电池座(用于AA电池) 1个
Vertax D11 can be used 1pc EN-EL15 (rechargeable battery) or 6pcs AA/LR6 batteries and includes
an alternate shutter-release button; AE-L/AF-L button, multi selector, and main and sub-command dials.
Please read this manual carefully before use this product
Please keep this instruction manual carefully for the future access.
Please use this product correctly base on your understanding knowledge from this instruction manual.
Thank you for purchasing a PIXEL product.
Vertax D11
Battery Grip
1、Vertax D11
2、To prevent electrical shorts caused by metal objects touching the power terminals, replace the
contact cap when the Vertax D11 is not in use.
3、When a battery holder is removed from the Vertax D11, remove the batteries or place the holder or
cover in the holder case to prevent electrical shorts caused by contact with other metal objects.
4、The memory card access lamp may light up when the Vertax D11 is attached or removed from the
camera, but this is not malfunction.
5、The batteries should be installed correctly. Reverse polarity may cause batteries to leak corrosive
liquids, heat or explosion.
6、Do not store in a high temperature, such as an enclosed car under direct sunlight , the dashboard
and other high-temperature areas.
7、Keep dry, do not contact wet hands with the product. Do not immerse in water or exposed to rain as
this may lead to failure of the device.
8、Do not use near flammable gases. Failure to follow this warning may cause explosion or fire.
9、This product includes batteries; please strictly follow the instruction for proper operation. Failure to
follow this may cause explosions, fire or personal injury.
The is for use with compatible cameras only.
Attach to camera
1、Remove the contact cap (Figure 2) from the Vertax D11 battery grip.
2、Remove the contact cover, and replace it in the contact cover holder on the Vertax D11(Figure3)
3、Hold the Vertax D11; Vertax D11 mounting screw (Figure4-B) aligned with the camera tripod socket
(Figure4-A)
4、Follow the arrow direction to tight lock the battery grip on camera. (Figure 5)
Be sure the Vertax D11 control lock on the locked position (Figure1-A) before attach to camera.
Before using the camera as vertical side, please turn the control lack as unlocked (Figure1-B).
The control lock is not a power switch. Use the camera power switch to turn the camera on and off .
Removing the Battery Pack
To remove the Vertax D11, turn the camera off and set the control lock on the Vertax D11 to L, then
loosen the attachment wheel and remove the Vertax D11. Be sure to replace the contact cover on the
camera and the contact cap on the Vertax D11 when the battery pack is not in use.
batteries.Before inserting batteries, be sure that the camera is off and that the Vertax D11 control lock
is in the L position.
Flip the Vertax D11 battery magazine release handle to up (Figure6) and rotate it as 90degree [ ]
(Figure7), release the battery magazine(Figure8).
2、Installation Method:
The Vertax D11 can be used with one EN-EL15 rechargeable Li-ion battery, or with six AA
1、
EN-EL15: Matching the indentations on the battery to the projections on the Vertax D11EN magazine,
insert the battery with the arrow (▲) on the battery toward the battery holder power terminals . Press
the battery lightly downward and slide it in the direction of the arrow until the power terminals click into
place (Figure9).
AA battery: Place 6pcs AA battery in the Vertax D11 magazine for AA battery as shown in (Figue10),
make sure these batteries are in the correct position.
3 Insert the battery holder in the and latch the battery-chamber cover . Make sure the
holder is fully inserted before turning the latch.
4 、Turn the camera on and check the battery level in the control panel or viewfi nder. If the camera
does not turn on, check that the battery is correctly inserted
、Vertax D11
EN-EL15 Battery
The performance of EN-EL15 battery drops at temperatures below about 10 °C (50 °F). Be sure the
battery is fully charged and keep a warm spare battery on hand ready to exchange as necessary. Cold
batteries will recover some of their charge when warmed.
AA Batteries
Due to their limited capacity, AA LR6 alkaline batteries should be used only when no other alternative
is available.The capacity of AA batteries varies with make and storage conditions and may in some
instances be extremely low; in some cases, AA batteries may cease to function before their expiry date.
Note that the capacity of AA batteries may drop at temperatures below 20 °C (68 °F). Use is not
recommended at low temperatures.
Vertax D11EN magazine for EN-EL15 batteries 1PC
Instruction Manual 1PC
Specifications
Battery (1)One EN-EL15 battery (2)6pcs AA/LR 6 Alkaline Battery
Working temperature 0℃-+40℃
Dimensions Approx. 53.2 84.7132.6xxｍｍ
Weight
The product specifications and exterior are subjected to change without notice.
Inserting Battery
Included items
1 、
menu can be used to change the order in which
the batteries are used(Figure A).
2 、When the camera is drawing power from the Vertax D11,
a ( ) icon is displayed in the control panel. If the ( )
icon blinks, the battery-chamber cover is not locked. Close
and latch the battery-chamber cover(Figure B).
An option in Group d of the camera Custom Settings
(Group d14)
Battery Setting
Battery Grip Vertax D11 1PC
Vertax D11 magazine for AA batteries 1PC
Instruction Manual
Caution
3 、
level when AA batteries are used,choose the appropriate
option for battery type in the camera Custom Settings menu
(Group d13). If the correct option is not selected, the camera
may fail to function as expected(Figure C).
4 、Battery status can be checked in camera setting menu
(Figure D).
To ensure that the camera shows the correct battery
This manual information is updated at 1st Apr, 2012. If you wish to use this product combined with other
Pixel products published after this date; please consult with the PIXEL dealer for further information.
Now you can start to use incredible PIXEL product. If you have any question, please contact your local
dealer or visit to http://www.pixelhk.com
Approx.191.8 g(without batteries and battery magazine)
