Pixelfly PF-MS82T User manual

4K@60 8x2 Presentation Switcher w/ HDBaseT & KVM
PF-MS82T
USER MANUAL

1
Important Safety Information
1. Read, follow, and keep these instructions.
2. Heed all warnings.
3. Do not use this product near water. Keep away from wet places, such as: spas, pools,
sinks, laundries, wet basements, etc.
4. When cleaning, unplug the unit and wipe with a dry cloth. Do not use damp cloths,
cleaning fluids, or aerosols which may result in electric shock, fire, or unit damage.
5. Operate this product using only the included power supply and/or power cable. Use of an
unapproved power implement may impair performance, damage the product, or cause
fires.
6. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
7. Do not install or place this product near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that produce heat.
8. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the product.
9. Only use attachments/accessories specified by Pixelfly s to avoid fire, shock, or other
hazards.
10. To reduce the risk of electric shock and/or damage to this product, never handle or touch
this unit or power cord if your hands are wet or damp. Do not expose this product to rain
or moisture.
11. Unplug this product during lightning storms or when unused for long periods of time.
12. Never open, remove unit panels, or make any adjustments not described in this manual.
Attempting to do so could result in electric shock, damage to the unit, or other hazards.

2
Contents
Important Safety Information............................................................................1
Introduction ...................................................................................................... 3
Features ...................................................................................................3
Package Contents .................................................................................... 4
Panel Description.............................................................................................5
Front Panel ...............................................................................................5
Rear Panel................................................................................................5
Specifications...................................................................................................8
Pinout Information.......................................................................................... 10
MIC/48V/LINE IN .................................................................................... 10
Installation and Wiring.................................................................................... 10
Installation............................................................................................... 10
Wiring ..................................................................................................... 11
Front Panel Control........................................................................................ 14
RS232 Control ............................................................................................... 15
Telnet Control................................................................................................. 16
Web UI Control .............................................................................................. 18
Get Access to the Web UI....................................................................... 18
Web UI Introduction ................................................................................ 19
Video Control................................................................................... 19
Audio Control................................................................................... 20
Config .............................................................................................. 23
Setting ............................................................................................. 27

3
Introduction
PF-MS82T is a presentation matrix switcher with 4K@60Hz 4:4:4 scaling
outputs. It has eight inputs and two outputs including three HDMI inputs, one
DisplayPort input, two VGA inputs with embedded stereo audio, two
HDBaseT inputs, one HDMI output and one HDBaseT output. The HDBaseT
inputs and output features IR pass-through, RS232 pass-through and PoE
(PSE). Any of the eight inputs can be routed to any of the two outputs
separately. HDMI output and HDBaseT output both have a built-in scaler
which can support up to 4K@60Hz 4:4:4 8bit, therefore PF-MS82T can
output image to any display equipment with the optimal resolution.
For audio, PF-MS82T has two MIC/LINE optional inputs which can be
configured individually by two DIP switches. PF-MS82T also features two
balanced stereo audio outputs which work as de-embedded outputs as
factory default, one for HDMI output and another for HDBaseT output. HDMI
OUT and HDBaseT OUT, AUDIO OUT1 and AUDIO OUT2 can be set
independently to output any mixed result of MIC/LINE IN 1&2 and
de-embedded Audio of HDMI OUT and HDBaseT through API commands
and Web UI.
For KVM, PF-MS82T has two USB-HOST ports on rear panel for HDMI input
1 and 2 as factory default. The two USB-HOST ports on rear panel can be
reconfigured to bind with other inputs (Except for HDBT in) through API
commands and Web GUI. There are two USB-DEVICE ports for HDMI output,
PF-MS82T can be controlled by Front panel buttons, Web GUI and API.
Features
8x2 4K Scaling Presentation Matrix Switcher
Support HDCP 2.2

4
HDMI output and HDBT output built-in scalers support up to 4K@60Hz
4:4:4 8bit
Supports seamless switching
HDBT inputs/output:
•Transmits 4K@60Hz 4:2:0 8bit signal up to 90m/300ft,
1080P@60Hz 4:4:4 8bit signal up to 100m/330ft via Cat 5e cable
•Transmits 4K@60Hz 4:2:0 8bit signal up to 100m/330ft,
1080P@60Hz 4:4:4 8bit signal up to 100m/330ft via Cat 6/6a/7
cable
Each HDBT port can supply power to remote TX/RX via PoE (IEEE
802.3af™ compliant PSE, 44~57V)
HDBT inputs and output support bi-directional IR pass-through, RS232
pass-through.
Supports Auto CEC control, set through API commands or Web UI
Supports USB 2.0
Supports de-embedded audio of HDMI OUT and HDBT OUT, AUDIO
OUT1 and AUDIO OUT2 set independently through API and Web UI to
output any mixed result
Supports ethernet pass through to HDBT inputs and output
Supports Front Panel control, RS232 control, LAN control through Telnet
API and Web UI
Package Contents
1 x PF-MS82T Switcher
1 x AC Power Cord with US, UK, EU, AU Pins
3 x IR Emitter
3 x IR Receiver
2 x Phoenix Male Connectors (3.5mm, 5 Pins)
6 x Phoenix Male Connectors (3.5mm, 3 Pins)
2 x Mounting Brackets (with Screws)

5
Panel Description
Front Panel
1 2 3 4
No.
Name
Description
1 POWER LED •On: The device is powered on.
•
Off: The device is powered off.
2
INPUT
SOURCE
Selection
Button
s and
LEDs
•Input Selection button: Press to manually
select a source as the current source input.
The button function can be enabled through
command control or Web UI.
•LED:
LED is located on the top of the
selection button. When the button function is
enabled, press an input selection button, the
LED will blink, press the output button in 3s
to select the input to output, detail
information, see “Front Panel Control”
section.
3&4
OUTPUT
Selection
Buttons and
LEDs
•Output Selection Buttons:
Press to
manually select a display
as the current
output.
•LEDs:
LED is located on the top of the
selection button. When the button function is
enabled, the LED is lighted.
Rear Panel
1 2 8910 11 12
1314151623
2526
456 73
24 171819202122
272829
No.
Name
Description
1 AC 100-240V
50/60Hz
Connect the power cord provided. Accepts AC
power of 100-240V 50/60Hz.

6
No.
Name
Description
2
HDMI 1-3
Connect to HDMI sources.
3
DP
Connect to a DP source.
4&6
VGA 1&2
Connect to VGA sources.
5&7 AUDIO 1&2 Connect to audio devi
ces for audio input,
embedded with the VGA sources.
8 HDBT 1&2 Connect to HDBT transmitters via Cat 5e/6/7
cables.
9
HDMI
Connect to an HDMI display.
10 HDBTConnect to an HDBT receiver via a Cat 5e/6/7
cable.
11 UPDATE
•FW: Micro-USB A Connector. For general
firmware upgrade.
•SCALER: USB Type-
A Connector. For
scaler upgrade.
•HDMI&HDBT DIP Switch: Select upgrade
HDMI OUT scaler or HDBT OUT scaler.
12 RESET
Use a pointed stylus to hold down the RESET
button for three or more seconds, and then
release it, reset the device.
13 A
UDIO OUT
1&2
Connect to audio devices such as amplifier.
Working as de-embedded
outputs as factory
default, 1 for HDMI output and 2 for HDBT
output.
14 IR OUT Connect to an IR emitter. For IR pass-through
with a receiver connected to HDBT OUT.
15 IR IN Connect to an IR receiver. For IR pass-through
with a receiver connected to HDBT OUT.
16 RS232
Connect to a RS232 enabled device for
bi-directional RS232 serial communication. with
a RS232 device in a remote HDBT receiver.
17&20 IR OUT Connect to an IR emitter. For IR pass-through
with a transmitter connected to HDBT IN 1/2.
18&21 IR IN Connect to an IR receiver. For IR pass-through
with a transmitter connected to HDBT IN 1/2.
19&22 RS232
Connect to a RS232 device for bi-directional
RS232 communication with a RS232 device in a
remote HDBT transmitter connected to HDBT IN
1/2.
23 USB HUB
Connect to USB devices such as keyboard,
Mouse, USB Camera. For HDMI Output.
24
USB HOST 1&2
Connect to USB HOST devices such as PC.

7
No.
Name
Description
Bind with HDMI IN 1-2 by default. They can be
reconfigured to bind with other inputs (Except
for HDBT in) through API commands and Web
UI.
25&26 MIC/48V/LINE
IN
MIC/48V/LINE IN POWER Selector switch for
audio input.
•MIC: MIC in
•48V: MIC in with phantom power
•LINE IN: Line in
*Warning*: Before the selector switch is set to
position “48V”, ensure any Line in device
connected to “MIC/LINE IN” port h
as been
removed; otherwise, device damage may occur.
MIC/48V/LINE IN Ports:
Connect to Audio
devices based on the settings of MIC/LINE IN
Selector Switch.
27
RS232
Connect to a RS232 device for RS232 control.
28 ETHERNET
Connect to an active IP network or PC to share
network access with the Ethernet equipped
devices at the HDBT end.
29 LAN Connect to an ethernet device for telnet control
or web UI control.

8
Specifications
Technical
Input/Output Port
2 x VGA IN with analog AUDIO IN embedded; 3 x HDMI IN; 1 x DP IN;
1 x HDMI OUT; 2 x HDBT IN;1 x HDBT OUT; 2 x Analog AUDIO OUT;
2 x IR IN; 2 x IR OUT; 3 x RS232; 2 x USB HUB; 2 x USB HOST;
1 x ETHERNET; 1 x LAN; 1 x FW (Micro USB Type A);
1 x Scaler (Female USB Type-A); 2 x LINE IN/MIC IN; 1 x AC IN
Input/Output Signal
Type
•Input: HDMI with 4K@60Hz YUV 4:4:4, HDCP 2.2; VGA with
1920x1200, DP with 4K@60Hz YUV 4:4:4, HDBT with 4K@60Hz YUV
4:2:0
•Output: HDMI with built-in 4K@60Hz 4:4:4 Scaler, HDCP 2.2, HDBT
with built-in 4K@30Hz 4:4:4 Scaler
Input Resolution
Supported
HDMI & DP IN:
VESA:
800 x 6008, 1024 x 7688, 1280 x 7688, 1280 x 8008, 1280 x 9608,
1280 x 10248, 1360 x 7688, 1366 x 7688,1440 x 9008, 1600 x 9008,
1600 x 12008, 1680 x 10508, 1920 x 12008, 2048 x 11528
SMPTE:
1280 x 720P6,7,8, 1920 x 1080P6,7,8, 3840 x 21602,3,5,8, 4096 x 21602,3,5,8
HDBT IN:
VESA:
800 x 6008, 1024 x 7688, 1280 x 7688, 1280 x 8008, 1280 x 9608,
1280 x 10248, 1360 x 7688, 1366 x 7688, 1440 x 9008, 1600 x 9008,
1600 x 12008, 1680 x 10508, 1920 x 12008, 2048 x 11528
SMPTE:
1280 x 720P6,7,8, 1920 x 1080P6,7,8, 3840 x 21602,3,5,8*, 4096 x 21602,3,5,8*
VGA IN:
VESA:
800x6008, 1024x7688,1280x7208, 1280x7688, 1280x8008, 1280x9608,
1280x10248, 1360x7688, 1366x7688, 1440x9008, 1600x9008, 1600x12008,
1680x10508, 1920x12008
2 = at 24 Hz, 3 = at 25 Hz, 5 = at 30 Hz, 6 = at 50 Hz, 7 = at 59.94 Hz, 8 =
at 60 Hz
Note:
4:4:4/4:2:2/4:2:0 color sampling except “*”, “*” means only 4:2:0 color
sampling.
HDBT inputs only support up to 4K@60Hz 4:2:0 and 4K@30Hz
4:4:4.
Output Resolution
Supported
HDMI OUT:
VESA:
800x6008, 1024x7688, 1280x7688, 1280x8008, 1280x9608, 1280x10248,
1360x7688, 1366x7688, 1440x9008, 1600x9008, 1600x12008, 1600x10508,
1920x12008
SMPTE:
1280x720P6,8, 1920x1080P6,8, 3840x21602,3,5,6,8, 4096x21602,3,5,8

9
Technical
HDBT OUT:
VESA:
800x6008, 1024x7688, 1280x7688, 1280x8008, 1280x9608, 1280x10248,
1360x7688, 1366x7688, 1440x9008, 1600x9008, 1600x12008, 1600x10508,
1920x12008, 3840x21602,3,5, 4096x21602,3,5
SMPTE:
1280x720P6,8, 1920x1080P6,8
2 = at 24 Hz, 3 = at 25 Hz, 5 = at 30 Hz, 6 = at 50 Hz, 8 = at 60 Hz
Note: HDBT output support up to 4K@30Hz 4:4:4
Audio Input Port 2 x 3-pin Phoenix Connector MIC/LINE IN,
2 x embedded stereo Audio IN followed VGA ports
Audio Output Port 2 x 5-pin Phoenix Connector AUDIO OUT
Audio Format
Supported
PCM 2.0
Maximum Data
Rate
HDMI & DP IN: up to18 Gbps
HDBT IN: up to 10.2 Gbps
HDMI OUT: up to 18 Gbps
HDBT OUT: up to 10.2 Gbps
Maximum Pixel
Clock
HDMI IN/OUT & DP IN: 600MHz

HDBT IN/OUT: 340MHz
Control Method Front panel buttons, LAN, RS232
General
Operating Temperature 0°C to 45°C (32°F to 113°F)
Storage Temperature
-20°C to 70°C (-4°F to 158°F)
Humidity 10% to 90%, non-condensing
ESD Protection
Human-body Model:
±8kV (Air-gap discharge)/
±4kV (Contact discharge)
Power Supply AC 100-240V 50/60Hz
Power Consumption
92.52W (Max)
Device Dimension
(W x H x D)
440mm x 43.5mm x 330mm (17.32" x 1.71" x 13.00") (mounting
brackets not included)
Net Weight
4.2kg/9.26lb
Rack Space Required 1U
Transmission Distance
Note: Straight-through category cable of T568B standard is recommended.
Cable Type Range Supported Video
Cat 5e 100m/330ft 1080P@60Hz 24bpp
90m/300ft 1080P@60Hz 48bpp
1080P@60Hz 3D
4K@30Hz 4:4:4 24bpp
4K@60Hz 4:2:0 24bpp
Cat 6/6a/7 100m/330ft

10
Pinout Information
MIC/48V/LINE IN
G -+
MIC/48V IN:
“+” Connects to positive of audio output
“G” Connects to ground
“-” Connects to negative of audio output
LINE IN:
“+” Connects to left channel
“G” Connects to ground
“-“ Connects to right channel
Installation and Wiring
Installation
CAUTION:Before installation, please ensure the device is disconnected from
the power source.
The switcher can be placed on a solid and stable surface or installed on a
standard equipment rack.
Steps to install the device on an equipment rack:
1. Attach the installation bracket to the enclosure using the screws provided
in the package separately.
2. The bracket is attached to the enclosure as shown.

11
3. Repeat steps 1-2 for the other side of the unit.
4. Install the unit in the mounting rack using the screws (provided by
others).
Wiring
WARNING: Before wiring, ensure all units are DISCONNECTED from power.
Otherwise, circuitry damage or physical injury may be caused.
Steps for device wiring:
1. Connect video source
Connect the VGA, DP and HDMI sources (such as PC, Blu-ray player,
Apple TV, 4K media player, etc) to the VGA IN, DP IN and HDMI IN ports.
2. Connect HDBT Transmitter
Connect HDBT transmitters to the HDBT (1&2) ports of the device with
Cat 5e/6/7 cables.
3. Connect MIC/48V/LINE IN
Slide the DIP switch to MIC/48V/LINE IN position, connect the
corresponding audio input device to the LINE IN ports.
*Warning*: Before the selector switch is set to position “48V”, ensure any
Line in device connected to “MIC/LINE IN” port has been removed;
otherwise, device damage may occur.
4. Connect HDMI OUT
Connect an HDMI display device (such as TV, projector, LED/LCD
display) to the HDMI OUT.

12
5. Connect HDBT Receiver
Connect HDBT OUT of the device to HDBT IN of an HDBT receiver
(such as PF-UHK100H-RX) with a Cat 5e/6/7 cable.
6. Connect AUDIO OUT
Connect an audio receiver (e.g. an amplifier) to the AUDIO OUT (1&2).
7. Connect for additional control options:
•LAN control (Telnet/Web UI): Connect a Local Area Network to the
LAN port.
•ETHERNET pass through: Connect an active Area Network/PC to the
ETHERNET port, connect a PC/Local Area Network to the Ethernet
port of HDBT transmitter or receiver connected with the switcher, the
PC can be connected to the Area Network.
•USB control: Connect USB host devices to the USB HOST 1 or 2 port,
Connect USB devices to USB DEVICE ports, by default, when HDMI
OUT port select HDMI IN 1 or 2 as the source input, the USB devices
can be connected to corresponding USB host devices.
Note: The two USB HOST ports can be configured to bind with other
inputs (Except for HDBT IN) through API commands and Web UI.
•RS232 Control: Connect a control PC to RS232 control port of the
device.
•RS232 pass-through: Connect a RS232 enabled device to RS232
port of the device for HDBT IN (1&2) or HDBT OUT, and connect a
RS232 enabled device to the connected transmitter or receiver for
bi-directional RS232 pass-through.
•IR pass-through: Connect an IR Emitter to IR OUT port of the device/
connected HDBT transmitter/connected HDBT receiver. Connect an
IR Receiver to IR IN port of the connected HDBT
transmitter/connected HDBT receiver/the device for bi-directional IR
pass-through.
8. Connect the AC power cord provided to the switcher.

13
One-way PoE enables the switcher to power the remote HDBT
transmitter/receiver along a single Cat X cable, and no additional power
adapter is required at the transmitter/receiver.
9. Power on all attached devices.
When all is set, check if all LED indicators on switcher are normal to ensure
installation is successful. For LED indication, please refer to Panel
Description section.
See below application diagram:
DC 1 2V HDBT OUT
TX RX G
HDMI IN EDI D HOST RS232
HDMI IN
Blu-rayPlayer
DP IN USB HOST VGAIN
Cat x Cat x
PC PC
DocumentCamera
MIC Wireless MIC
Receiver
Audio In
Audio In
USB
DEVICES
USB
DEVICES
Display
HDMI OUT
HDMI IN
USB HOST
RS232
RS232
HDMI OUT
Keyboard & Mouse
Amplifier
AUDIO OUT
Display
Ethernet Switch
RS232
Control System
PC PC
Switcher
Receiver
Transmitter
MIC Speaker
Camera
LAN

14
Front Panel Control
Basic switch of input sources to output displays can be achieved by using
front panel controls.
To select input source for output:
Power on PF-MS82T, now you can select input for each output.
Ta ke HDMI IN2 to HDMI OUT as an example
1. Press HDMI IN2 input selection button, the LED on the top of this
selection button will blink.
Press the input selection button,
the LED will blink
2. Press HDMI OUT selection button within 3s after pressing the input
button, the LED on the top of this button will be lit on, and the LED on
the input selection button will stop blink. Select HDMI IN2 source to
HDMI OUT successfully.
LED stops blinking Press the output selection button,
the LED will be lit on
Note:
•If you don’t press the output button within 3s after pressing the input button,
the input LED will stop blinking, and the selection is invalid.
•The operation selecting other inputs to any output is the same as above
steps.

15
RS232 Control
Advanced users may also choose to control the device through RS232 serial
communication. API command for RS232 control is available in the separate
document “API Command Set_ PF-MS82T”.
A professional RS232 serial interface software (e.g. Serial Assist) may be
needed as well.
Before executing the API command through RS232 serial connection, please
ensure RS232 interface of the device and the control PC are configured
correctly.
Parameters Value
Baud Rate 57600 bps
Data Bits 8 bits
Parity None
Stop Bits 1 bit
Flow Control None

16
Telnet Control
Advanced users may need to control the switcher through Telnet. The Telnet
connection can be started from the Windows taskbar (see below) or a
professional Telnet client software (e.g. NetAssist). By default, the Telnet port
(port 23) does not require login credentials.
To establish a connection via Telnet at the CMD prompt:
1. Connect the ETHERNET(LAN) port of the PF-MS82T to your PC using a
straight UTP cable. Set your PC to the same network segment as the
switcher.
2. From your computer’s Windows Taskbar, select Start > Run to open the
Run dialog box.
3. Type “cmd” in the Open field.
4. Click OK to open an instance of the Windows command interpreter
(cmd.exe).
5. At the prompt (>), type “telnet” followed by a space and the switcher’s IP
address.
Example:
>telnet 192.168.20.235
A Telnet session opens for the switcher.

17
At the prompt, type the Telnet command and press Enter.
Te l n et command is available in another separate document.
If you are using Windows 7 and receive an error message, you may need to
enable Telnet by completing the following: (1) go to Start/Control
Panel/Programs and Features, (2) on the left, select “Turn Windows features
on or off”, (3) select the check-boxes Telnet Client and Telnet Server, and (4)
click OK.

18
Web UI Control
The Web UI designed for the switcher is available for basic controls and
advanced settings of the device. The Web UI can be accessed through a
browser, e.g. Chrome, Firefox, Safari, Opera, IE, etc.
Get Access to the Web UI
1. Connect your PC and the LAN port of the switcher to the same local area
network.
2. Input the switcher’s IP address in your browser and press Enter. The
following window will display.
Enter the default password “admin” and click “Login”.
The main page displays as follows.

19
Web UI Introduction
The Web UI main page includes several tabs for basic and advanced settings
Video Control, Audio Control, Config, Setting.
Video Control
Video Switch
This section manages distribution of input video source to output displays.
Click the switch button (white to green) to select the input source for the
output display.
Signal Status: Show the status of input sources, active (green) or no
signal (grey).
CEC Control (ON/OFF): Click to power on or off the CEC-enabled
display device immediately.
By default, HDMI IN1 routes to HDMI OUT, HDMI IN2 routes to HDBT OUT.
