DEC 3000 –Portable Datarecorder
Instruction Manual

Instruments and System for Geotechnical and Structural Monitoring
User manual / DEC 3000
REV. 01 01 2020 2/29
Pizzi Instruments S.r.l. reserves the right to change the information contained in this document without
notice.
No part of this document may be reproduced without the prior written consent of Pizzi Instruments S.r.l.
The instruments supplied by Pizzi Instruments S.r.l. are designed and optimized to be used and installed
with simplicity.
However, since they are performed at a high technical level, they must be installed and used by a trained
and qualified technical staff.
Before the installation of the supplied instrumentation, it is advisable to carefully read this manual and any
other related documents.
All rights reserved.
Pizzi Instruments S.r.l.
Warranty
Pizzi Instruments S.r.l. warrants its product against defects in materials for twelve (12) months from the date
of shipment unless otherwise specified on the relevant contract or purchase order.
Products considered to be defective should be returned to Pizzi Instruments factory properly identified,
complete with serial number, Returned Materials Authorization (RMA) and freight prepaid.
Pizzi Instruments’ obligation under this warranty is limited to repairing or replacing (at Pizzi Instruments’
discretion) defective products, which shall be the sole and exclusive solution under this warranty.
The Customer shall assume all costs of removing and shipping defective products to Pizzi Instruments and
the costs of reinstalling the repaired/substituted instruments.
The foregoing warranty shall not apply to any Pizzi Instruments products which have been subjected to
modification, misuse, misapplication, neglect, improper service or maintenance, improper installation.
Pizzi Instruments S.r.l. is not liable for any damage or loss caused to other equipment or person, whether
direct, indirect, incidental, special or consequential which the buyer may experience as a result of the
installation or use of the product.
The amount of any claim is limited to the net invoice value of the item in question.
In no case Pizzi Instruments S.r.l. will recognize and reimburse the costs incurred by the customer for
installations, maintenance, management, as well as for the uninstallation and reinstallation of the instruments
to be repaired or replaced under warranty.
While the information contained in the manual is assumed to be accurate, Pizzi Instruments neither assumes
responsibility for any omission or error that may appear or assumes liability for any damage or loss that
result from the use of products in accordance with the information contained in the manual.
Pizzi Instruments S.r.l.
Document Revision
Date of
issuance
Revision
Prepared
Checked
Released
10/01/2012
001
ANP
MPZ
FPZ
01/04/2018
002
ANP
MPZ
FPZ

Instruments and System for Geotechnical and Structural Monitoring
User manual / DEC 3000
REV. 01 01 2020 3/29
Table of contents
Notes
Electrical Symbol Explanation
General Instructions
Instructions and general considerations on safety
1. General Information
1.1 Introduction
1.2 Instrument Articles
1.3 Technical Characteristics
2. Installation
2.1 Packing / Unpacking
2.2 Preparation for the use
2.3 Battery Charger
2.4 Environmental conditions
3. External Aspect of the Unit
4. User instruction
4.1 Switching of the system
4.2 Description of operative functions from keyboard
4.3 Menu of DEC3000
5. Configuration
5.1 Automatic Acquisition
5.2 Alarm Table
5.3 Manual Measurement
5.4 Memory State
5.5 Measure displaying
5.6 Period Cycle
5.7 Instrument Group
5.8 Measure Starting
5.9 Transfer of measurements
5.10 Clock
5.11 Configure System

Instruments and System for Geotechnical and Structural Monitoring
User manual / DEC 3000
REV. 01 01 2020 4/29
NOTES
This device and its documentation should be carefully examined to familiarize yourself with
the safety instructions before starting the operating procedures.
To ensure a correct and safe use, the operator of this unit must follow all the information
and warnings contained in this document.
This equipment has been designed in accordance with safety requirements EN61010 and
is marked with the CE mark that guarantees compliance with European directives.
ELECTRICAL SYMBOL EXPLANATION
Do not remove the cap to avoid the risk of electric shock. Inside
the Instrument there are no areas on which the operator could
intervene in case of failure. Any possible reparation can be
performed only by qualified personnel .
Read the operating manual and instructions, see the symbols
relating to security
This symbol indicates that the product at the end of its useful life
must be collected separately from other waste. The operator must
therefore send the equipment to the appropriate centers for
collection of electronic and electrotechnical waste
NOTE: the symbol note highlights important information
GENERAL INSTRUCTIONS
The Caution Symbol highlights the presence of a potential danger.
CAUTION: of instrument damage. All conditions specified in the associated
text must be fully known and understood before proceeding
This symbol indicates the presence of dangerous voltage
inside the instrument that can cause electrical shock and
possible serious health consequences

Instruments and System for Geotechnical and Structural Monitoring
User manual / DEC 3000
REV. 01 01 2020 5/29
INSTRUCTIONS AND GENERAL CONSIDERATIONS ON SAFETY
The symbol ATTENTION highlights the presence of a potential danger
.ATTENTION: personal injuries. All the indication contained in this
manual must be fully acquired and understood before proceeding .
This instrument has been designed and constructed in Italy and fully
complies with security requirements required by law.
To maintain the unit in a safe state and to ensure risk-free operations,
the following instructions must be examined and fully understood
before beginning the procedure works:
Overload:
Do not overload wall outlet, Extension cords or adapters, as this could
cause fire or electric shock.
Liquids:
Keep liquids away from the instrument and do not place objects
containing liquids on or near to it.
Connections:
Always use the recommended connections in order to avoid danger or
damage.
Positioning:
On site installation :
a)Place the instrument in the appropriate sealed box to avoid that it
could be exposed to lightning, rain or sun light. If the box should be
selected metallic material, make sure that the connection has been
made for grounding of the metallic casing
b)Do not place the instrument near radiators or other heat sources
c)Make sure that the instrument is at least 200 cm from other
equipment sensitive to magnetic interference, like TV or VRC.
d)Do not place the instrument on trolleys, stands, tripod, bracket, or
unstable table, from which it could fall. A fall can cause injury or
substantial damage to the instrument
e)Do not place the instrument near other power lines; the connection
cables with sensors must be shielded and placed at a distance of not
less than 200 cm from other power cables.
External Bodies:
Do not introduce external objects through cracks and openings in the
instruments, as they may touch under voltage parts or damage
sensitive components

Instruments and System for Geotechnical and Structural Monitoring
User manual / DEC 3000
REV. 01 01 2020 6/29
Replacement of components:
a)In case of necessity, you have to ensure that the replacement
of components will be performed by authorized and trained
personnel which will used the original components or otherwise
having the same characteristics as the original. Unauthorized
use of not suitable parts may cause further damage.
b)All maintenance must be performed by qualified technical
personnel.
c)Before any installation, maintenance or intervention on the
instrument make sure that the switch is off. Some components
may be energized and an inadvertent contact with them could
damage the equipment in addition to causing serious damage
to the person.
d)Do not remove the cap, to avoid the risk of electric shock.
Inside the instrument not there are no areas on which the
operator could intervene in case of failure. A possible repair
can be performed by qualified personnel only .
Do not work if the instrument is switched on:
a) Risk of electric shock that can cause serious personal injury
and damage to the instrument.
b) Inside the feeder, during the usual operating conditions, there
are dangerous tension levels and components that store a
substantiall quantity of energy. These components are however
inaccessible. A hazardous intervention on the instruments could
provoke electrical shocks or permanent damages to the feeder.
Attention:
- Do not open the instrument, do not touch the internal parts or
components on the cards, because they might be in tension.
- Do not insert metal or flammable objects inside the
instrument.
- Do not touch the feeder with damp hands
- Keep the module away from heat sources
- Do not use the equipment in case of failure since the use of a
defective instrument can cause more damage. Contact us to
solve the problem.

Instruments and System for Geotechnical and Structural Monitoring
User manual / DEC 3000
REV. 01 01 2020 7/29
1 GENERAL INFORMATION
DEC3000 is a portable datalogger that allows to carry out the manual measurements
with almost all sensors for static structural and geo-technical controls, present today in the
market.
DEC 3000 is able to memorize the detected data, that could be download from serial port
by an external laptop and to show the same on display or during the acquisition phase or
upon request.
The portable unit DEC 3000 is able to carry out the manual reading of a single channel
and, consequently of a single instrument and also offers a lot of other opportunities; it is
possible to configure and memorize the classic parameters for every kind of sensor
(Offset, K, alarm thresholds), to assign to a specific instrument a determined channel; it is
also possible to configure some measuring group setting for each channel the specific
parameters of every sensor; in particular situation, when, for example, the unit is used as
an automatic acquisition unit, it is foreseen the possibility to set some temporization for the
channel interrogation or of the groups of the configured sensors.
1.1 Introduction
The DEC3000 is a portable datalogger complete with internal battery and battery charger.
These are the main functional and operating characteristics of the product:
-Possibility to configure the system and the single channels with the typical
parameters of every single sensor;
-Presentation of the measures detected on digital display and at the same time the
memorization on static memory;
-Availability of RS232 –RS485 communication ports or of other of standard type;
-Availability of self-test to the whole acquisition system and of control of some
sensors
1.2 The supply includes:
-DEC3000 - Portable Datalogger complete with internal battery and external battery
charger
-User Manual
-CE Certification

Instruments and System for Geotechnical and Structural Monitoring
User manual / DEC 3000
REV. 01 01 2020 8/29
 Technical Characteristics

Instruments and System for Geotechnical and Structural Monitoring
User manual / DEC 3000
REV. 01 01 2020 9/29
2. INSTALLATION
2.1 Packing/Unpacking
Check that the transport packing of the instrument is not damaged. If damaged, please
retain it until you have completely controlled the state of each accessory and functionality,
both mechanic and electronic of the instrument.
For a proper unpacking of the instrument, follow the instructions below:
Make transportation sustaining the inferior part
Open the external carton packing Remove the protective material
Remove the instrument and holding it in vertical position.
After unpacking the instrument, check the correspondence between checklist (see "Articles
of instrument") and the provided material, documentation included.
2.2 Preparation for the use
The portable acquisition unit DEC3000 is supplied with a not charged battery. It is
necessary to charge the battery for at least 24 hours. It is advisable to use the unit only
when there is a charge greater than the 30%.
Do not fully discharge the battery, by this way the battery could be
irremediably damaged.
2.3 Battery Charger
External 12Vdc
2.4 Environmental conditions
Val. min.
Val. max
Temperature
- 40 C°
+ 85 C°
Humidity
0
95% rel. Max
Altitude
0 mt
8000 mt

Instruments and System for Geotechnical and Structural Monitoring
User manual / DEC 3000
REV. 01 01 2020 10/29
3. EXTERNAL ASPECT OF THE UNIT
“A” Alphanumeric Display of visualization at 4 lines
“B” Keyboard 8 keys:
Selection Button: they allow to move from a voice to another of the
menu
Modification keys: they allow to manually set up every voice of the
menu according the different needs.
E
“Enter”: it allows to “enter” in the submenu of the different functions of
the main menu, to save the eventual modifications and to come back
to the superior leveles of the unit functions.
C
“Cancel”: allows to “exit” from every submenu; if the modifications are
not saved ( button “E”), pressing the button “C” they won't be
maintained .
“ON”
“OF”
ON : it is necessary to switch on the instrument
OFF : it is necessary to switch off the instrument
“C” Connector for external battery charger / communication port RS232
“D” Connector for connection cable between Acquisition Unit / Sensors
C
D
B
A

Instruments and System for Geotechnical and Structural Monitoring
User manual / DEC 3000
REV. 01 01 2020 11/29
4. USER INSTRUCTION
4.1 Switching of the system :
Once the battery is fully charged, the unit is ready to be used.
Pressing the key “ON” , on the display will appear the writing “WAITING” for a max of 20
sec.
This interval is necessary to give the Unit the time to configure all the setting in memory;
later on the display will appear the following window of “Wait /Acquisition”:
Where:
aa/bb/cc
Current Date (if set)
AA/BB/CC
Date of the next acquisition (if set)
hh:mm
Current hour (if set)
HH:MM
Hour of next acquisition ( if set)
xxxxxxxxxxx
Identificative name of the system (see par. 4.1.10) /when present,
signalization of channels with alarm
xxxxxxxxxxx
Follow identificative name of the system (see par. 4.1.10)/ when present
signalizatio of channels with alarm
4.2 Description of the operative functions from keyboard
From the window of “wait/acquisition”, pressing the key “E”, you enter in the Main Menu of
the DEC 3000; the following window at vertical sliding appears :
The alphanumeric display shows 4 lines of control, therefore, to see all the other functions
of the Main Menu will be necessary to move from item to item until the last screen pressing
↓. In the display, a small arrow on the left of each item, indicate how and where we are
moving.
aa/bb/cc hh:mm
xxxxxxxxxxxxxxxxxxxx
xxxxxxxxxxxxxxxxxxxx
AA/BB/CC HH:MM
ACQUISITION ←
MANUAL MEASURE
MEMORY STATE
MEASURES DISPLAYS

Instruments and System for Geotechnical and Structural Monitoring
User manual / DEC 3000
REV. 01 01 2020 12/29
Arrived on the last function of the window , continuing to press the directional button, the
other screen will be open from the Main Menu, with the other available functions :
Still pressing the button ↓ , you can display the last screen of functions of the main menu:
To enter each of these functions and to display the available submenu (Fig.1), you have
to move the "indicator arrow “ of the display over the desired item and to press the Key "
E ". Whenever you enter the menu or you want to return to it, after having set the various
items of interest, the cursor is always placed in correspondence of the function
"ACQUISITION". “"Pressing "E" you enter the function and the system activates the
acquisition in accordance with the previously defined program (instruments group and
their timing).
MEASURES DISPLAYS ←
PERIOD CYCLES
INSTRUMENTS GROUP
START MEASURES
START MEASURES ←
TRANSFER MEASURES
CLOCK
CONFIGURE SYSTEM

Instruments and System for Geotechnical and Structural Monitoring
User manual / DEC 3000
REV. 01 01 2020 13/29
4.3 Menu of DEC3000
PREVIOUS MENU
(DW) ↓ ↑ (UP)
INITIATE CFG
(DW) ↓ ↑ (UP)
DELET MEASURE
ACQUISITION
(DW) ↓ ↑ (UP)
MANUAL MEASURE
(DW) ↓ ↑ (UP)
MEMORY STATE
(DW) ↓ ↑ (UP)
DISPLAY MEASURE
(DW) ↓ ↑ (UP)
PERIOD CYCLES
(DW) ↓ ↑ (UP)
INSTRUMENT GROUPS
(DW) ↓ ↑ (UP)
MEASURE START
(DW) ↓ ↑ (UP)
MEASURE TRANSFER
(DW) ↓ ↑ (UP)
CLOCK
(DW) ↓ ↑ (UP)
CONFIGURE SYSTEM
(ENTER)
PREVIOUS MENU
(DW) ↓ ↑ (UP)
SINGLE MEASURE
(DW) ↓ ↑ (UP)
MEASURE GROUP
(DW) ↓ ↑ (UP)
TEST
(ENTER)
(ENTER)
(ENTER)
(ENTER)
(ENTER)
(ENTER)
PREVIOUS MENU
(DW) ↓ ↑ (UP)
INSTALLATION
(DW) ↓ ↑ (UP)
SERIAL PORT
(DW) ↓ ↑ (UP)
CONFIGURE PERIPH.
(DW) ↓ ↑ (UP)
CONFIGURE CHANNEL
(DW) ↓ ↑ (UP)
MEMORY MANAGEMENT
(ENTER)
(ENTER)
(ENTER)
(ENTER)
aa / bb / cc hh : mm
xxxxxxxxxxxxxxxxxxxxxxxxx
xxxxxxxxxxxxxxxxxxxxxxxxx
AA / BB / CC HH : MM
(ENTER)
Fig.1
(ENTER)

Instruments and System for Geotechnical and Structural Monitoring
User manual / DEC 3000
REV. 01 01 2020 14/29
5. CONFIGURATION
5.1 Automatic Acquisition (in case of the use of the read out unit in an automatic
acquisition system )
From the main menu, positioning the “indicator arrow” on ACQUISITION and pressing the
Key “E” on the display the following window appears:
With the meaning, known, of the various messages.
At the hour HH:MM of the day AA/BB/CC, the system executes the pre-set measure cycle.
During the temporized acquisition the following window appears:
In the first line there is the number that indicates the instrument group during the
acquisition phase and in the second line there is the number of channel correspondent to
the single instrument interrogated in this moment.
In the following lines there will be rapidly showed, for the different interrogated
instruments, both the measure value and the eventual detected alarms.
NOTE: the temporized acquisition will be executed only if we are in the
ACQUISITION; if the measure period falls in a moment in which we are
working on other functions, the acquisition won't be carried out.
Once achieved the acquisition, the following window will appear :
where XXX(YZ) that could be repeated more times with different values for XXX and also
for Y and Z (that however could remain the same) and it has the following meaning :
XXX = number of interested channel
Y = first alarm code
Z = second alarm code
in case of single alarm one of the two numbers will be the "zero".
aa/bb/cc hh:mm
AA/BB/CC HH:MM
ACQUISITION GR.nn
MEASURE CHANNEL N.mm
aa/bb/cc hh:mm
*XXX(YZ)*
AA/BB/CC HH:MM

Instruments and System for Geotechnical and Structural Monitoring
User manual / DEC 3000
REV. 01 01 2020 15/29
5.2 Alarm table
Alarm
Code
Alarm Cause
Measurement
carried out
yes / not
Elaboration
carried out
yes/not
Format of restitution and record of the
measurement of alarm code (first value “x”
second value “y”)
0
Valid Measurement
yes
yes
+XXXXXXX
1
Open Sensor Circuit
yes
not
???????? 1 0
2
Sensor Circuit in short circuit
yes
not
???????? 2 0
3
Electrical Noise
yes
not
???????? 3 0
4
-------------------------------
------
-----
-------------------
5
Measure in overflow
yes
not
???????? 0 5
6
Failure to relay pilot card or to
relay card (only if a Mux is
connected)
no
not
???????? 6 0
7
Overflow of the inferior threshold
value
yes
yes
+XXXXXXX 0 7
8
Overflow of the superior
threshold value
yes
yes
+XXXXXXX 0 8
9
No Vref ADC
not
not
???????? 9 0
A
Failure to power supply circuit
and measure card
not
not
??????? A 0
B
Time-out ADC
not
not
???????? B 0
C
Error in the selection of the ADC
switch
not
not
???????? C 0
D
Failure in the memory circuit
not
not
???????? D 0
E
Failure in the measure
peripheral
not
not
???????? E 0
5.3 Manual Measure
From the main menu, moving the “arrow indicator” on ↓ and on the command MANUAL
MEASURE and pressing the Key “E” , the following window appears :
The arrow indicator will be positioned on PREVIOUS MENU, so to return to the main
menu it will be sufficient to press again the Key “E”.
PREVIOUS MENU
SINGLE MEASURE
MEASURE GROUP
TEST

Instruments and System for Geotechnical and Structural Monitoring
User manual / DEC 3000
REV. 01 01 2020 16/29
To manually set the measurements on a single channel you must enter the submenu
SINGLE MEASURE, then pressing the key ↓ , the arrow indicator will move to the function
of interest, by pressing the "E" the following window will appear on the display :
Where:
X X X
Number of the selected channel
S Y Y . Y Y Y Y
Value of the measurement
Z Z Z Z Z Z
Unit of measurement
X
Circuit alarm code (1/2/3/4/5/6/7/8/9/A/B/C/D/E)
Y
Measure alarm code (5/7/8)
By the keys ←→ you will move on the single items and by the keys ↑↓ you set
parameters of interest .
Once the parameters are set to start the data acquisition, you have to press the key E to
return to the menu MANUAL MEASURE, hence, by pressing the confirmation command
on “PREVIOUS MENU”, you return to the main menu. There you can positioned the arrow
on the ACQUISITON command and start the acquisition cycle, timed according to the
parameters that you have set.
SINGLE MEASURE
CHANNEL : X X X
XXX Z Z Z Z Z Z S Y Y . Y Y Y Y
ALARM CODE : X Y

Instruments and System for Geotechnical and Structural Monitoring
User manual / DEC 3000
REV. 01 01 2020 17/29
Types of measurements: list and code
Binary Code
Type of measurement
Function of the measurement
0
N.C.
Measurement not configured (default)
1
CV-OG
( XX . XXXX) CV-OG
2
CVm_A
( XXXXX . X) CV-mode A
3
CVm_B
( XXXXX . X) CV-mode B
4
CVm_C
( XXXXX . X) CV-mode C
(to be implemented)
5
CVm_D
( XXXXX . X) CV-mode D
(to be implemented)
6
CVm_E
( XXXXX . X) CV-mode E (to be implemented )
7
CVm_F
( XXXXX . X) CV-mode F
8
CVOG1
( XX . XXXX) CV-OG1
9
-------
(not used at the moment )
10
-------
(not used at the moment )
11
-------
(not used at the moment )
12
-------
(not used at the moment )
13
POT.
( XXX . XXX) POTENZIOMETER
14
PT100
( XXXXX . X) TEMPERATURE PT-100
15
CU-30
( XXXXX . X) TEMPERATURE CU-30
16
420
( XXX . XXX) CURRENT 4 20 ma
17
5V/A
( XXXX . XX) TENSION 5Vdc / A
18
IMP/G
( XXXXXX . ) PULSES / DAY
(to be implemented)
19
5V/B
( XXXX . XX) TENSION 5Vdc / B
20
S.G.
( XX . XXXX) STRAIN-GAUGE
21
P.Res.
( XXX . XXX) POTENZIOMETER RESIST.
22
C/^C
( XXXXX . X) CARLSSON ^C
23
C/RAT
( XXXX . XX) CARLSSON RAT
24
C/ohm
( XXX . XXX) CARLSSON OHM
25
RES.
( XXX . XXX) RESISTANCE
26
NTC
( XXXXX . X) TEMPERATURE NTC (3KΩ)
27
CU-15
( XXXXX . X) TEMPERATURE CU-15
28
Vbatt
( XXXX . XX) Tension Power Supply DEC-3000 (Battery)

Instruments and System for Geotechnical and Structural Monitoring
User manual / DEC 3000
REV. 01 01 2020 18/29
Binary Code
Type of measurement
Function of the measurement
29
CVohm
( XXXX . XX) Resistance line + Vibrating Wire Sensor
30
-------
(not used at the moment )
31
-------
(not used at the moment )
32
-------
(not used at the moment )
33
SER0
( XXXX . XX) MEAS. LEVEL (RS-232 transmission continuous)
(to be implemented )
34
SER1
( XXXX . XX) MEAS. LEVEL (RS232 on call)
(to be implemented )
35
SER2
( XXXXX . X) C.A asse X (RS-232 transmission continuous)
(to be implemented )
36
SER3
( XXXXX . X) C.A asse Y (RS-232 transmission continuous)
(to be implemented )
37
SER4
( XXXXX . X) C.A asse X (RS-232 on call)
(to be implemented )
38
SER5
( XXXXX . X) C.A asse Y (RS-232 on call )
(to be implemented )
39
SER6
( XXXXX . X) E.D. 2000 (RS-232 on call)
(to be implemented )
40
SER7
( XXXX . XX) MIS. LIVELLO DIGIQUARTZ (RS-232 on call)
(to be implemented )
41
SER8
( XXXXX . X) VIS/SC C.A asse X (RS-232 on call)
(to be implemented )
42
SER9
( XXXXX . X) VIS/SC C.A asse Y (RS-232 on call)
(to be implemented )
43
SER10
(not used at the moment )
44
SER11
(not used at the moment )
45
SER12
(not used at the moment )
46
SER13
(not used at the moment )
47
-------
(not used at the moment )

Instruments and System for Geotechnical and Structural Monitoring
User manual / DEC 3000
REV. 01 01 2020 19/29
In case we wouldn't save the preset parameters, in the sub-menu SINGLE MEASURE,
pressing the Key “C” and you will return to the menu MANUAL MEASURE; the following
window appears:
The third command of the menu is MEASUREMENT GROUP; it is necessary to manually
set the measure cycles for groups. Moving the “indicator arrow” on the item of interest,
pressing the Key “E”, on the display the following window appears :
The symbols and the procedure of data entering into individual items is the same of the
sub-menu SINGLE MEASURE.
Once the parameters have been set to start the data acquisition according to the
parameters you have set, you follow the same procedure indicated for the "single
measurement"; if you do not want to keep the configuration settings and exit from this
sub-menu, just press "C" to return to the initial window of the menu manual
measurement.
The forth item of the menu MANUAL MEASURE, TEST, is necessary to start a self-test
of the control unit .
Moving the indicator arrow on the item of interest press the Key "E" ; on the display the
following window will be visualized:
MEASURE GROUP: X X
MEASURE CHANNEL : X X X
X X X s Y Y . Y Y Y Y Z Z Z Z Z Z
ALARM CODE : X Y
TEST T/M xx xx xx
TEST RS232 xx
TEST AD xx
TEST CV xx
PREVIOUS MENU ←
SINGLE MEASURE
MEASURE GROUP
TEST

Instruments and System for Geotechnical and Structural Monitoring
User manual / DEC 3000
REV. 01 01 2020 20/29
while the system performs the functional test of its component units, on the display will
appear the following writings :
a) OK is for regular operation and (xx) number is for a malfunctioning alarm. The
malfunction alarm is referred to the following functions:
b) alarm indication (xx) in case of anomaly
Where:
xx = is the alarm code generated by the execution of the test relating respectively to
functions indicated in the second column, namely:
T/M/S
Real Time Clock, Eeprom Memory and Selector
RS-232
RS-232 Serial Port
AD
AD Converter
CV
Vibrating Wire Measure
The following table illustrates the typology of the different alarm codes and its relevant
meaning :
TYPOLOGY OF ALARM CODES
Alarm Code
Alarm Cause
Ok
No failure
4
Absence of signal
6
Failure on relay pilot card or on relay card
9
Failure on the conversion circuit of the relative measure card
A
Failure on the power supply circuit of the sensors on the relative
measure card
B
Missing of interconnection between the measure units or control units
or failure on the relative measure card
C
Fault in the selection of the ADC switch
D
Failure on the memory circuit on the relative card
