Water Level Meter
Instruction Manual

Pizzi Instruments S.r.l.
Via del Fornaccio, 46 –50012 Bagno a Ripoli (FI) Italy
Tel.[phone] –Fax [phone] –
email: [e-mail] - web: www.pizzi-instruments.it 2
Pizzi Instruments S.r.l. reserves the right to change the information contained in this document without
notice.
No part of this document may be reproduced without the prior written consent of Pizzi Instruments S.r.l.
The instruments supplied by Pizzi Instruments S.r.l. are designed and optimized to be used and installed
with simplicity.
However, since they are performed at a high technical level, they must be installed and used by a trained
and qualified technical staff.
Before the installation of the supplied instrumentation, it is advisable to carefully read this manual and any
other related documents.
All rights reserved.
Pizzi Instruments S.r.l.
Warranty
Pizzi Instruments S.r.l. warrants its product against defects in materials for twelve (12) months from the date
of shipment unless otherwise specified on the relevant contract or purchase order.
Products considered to be defective should be returned to Pizzi Instruments factory properly identified,
complete with serial number, Returned Materials Authorization (RMA) and freight prepaid.
Pizzi Instruments’ obligation under this warranty is limited to repairing or replacing (at Pizzi Instruments’
discretion) defective products, which shall be the sole and exclusive solution under this warranty.
The Customer shall assume all costs of removing and shipping defective products to Pizzi Instruments and
the costs of reinstalling the repaired/substituted instruments.
The foregoing warranty shall not apply to any Pizzi Instruments products which have been subjected to
modification, misuse, misapplication, neglect, improper service or maintenance, improper installation.
Pizzi Instruments S.r.l. is not liable for any damage or loss caused to other equipment or person, whether
direct, indirect, incidental, special or consequential which the buyer may experience as a result of the
installation or use of the product.
The amount of any claim is limited to the net invoice value of the item in question.
In no case Pizzi Instruments S.r.l. will recognize and reimburse the costs incurred by the customer for
installations, maintenance, management, as well as for the uninstallation and reinstallation of the instruments
to be repaired or replaced under warranty.
While the information contained in the manual is assumed to be accurate, Pizzi Instruments neither assumes
responsibility for any omission or error that may appear or assumes liability for any damage or loss that
result from the use of products in accordance with the information contained in the manual.
Pizzi Instruments S.r.l.
Document Revision
Date
Revision
Issued
Checked
Authorized
10/01/2013
001
ANP
MPZ
FPZ
08/04/2018
002
ANP
MPZ
FPZ

Pizzi Instruments S.r.l.
Via del Fornaccio, 46 –50012 Bagno a Ripoli (FI) Italy
Tel.[phone] –Fax [phone] –
email: [e-mail] - web: www.pizzi-instruments.it 3
Table of contents
Symbols and abbreviations ............................................................................................................................... 5
1. Introduction.................................................................................................................................................... 5
2. Initial Inspection............................................................................................................................................. 5
2.1 Damage during shipment ............................................................................................................................ 6
3. Storage .......................................................................................................................................................... 6
4. Description..................................................................................................................................................... 6
4.1 Instrument Components........................................................................................................................... 6
5. Preliminary requirements............................................................................................................................... 7
6.1 Preliminary Operations ............................................................................................................................ 7
7. Taking Measure............................................................................................................................................. 7
8. Technical Assistance..................................................................................................................................... 7

Pizzi Instruments S.r.l.
Via del Fornaccio, 46 –50012 Bagno a Ripoli (FI) Italy
Tel.[phone] –Fax [phone] –
email: [e-mail] - web: www.pizzi-instruments.it 4
Use of this manual
This manual must be considered for the installation and use of Water Level Meter .
Dangers and safety
Warning for the unpacking of the material:
Be careful when handling the packaging to avoid damage to property and / or people.
Handle with care every package before you open it.
Be sure to open every package without risking damage its contents.
Separate carefully each component of the package.
Warning for the installer:
Be careful in handling the heavy metal parts
Be careful when handling bulky packaging
Caution: Handle with care the bars of stainless steel and the bottom elements
Caution: Always use appropriate Personal Protective Equipment (PPE)
Be careful not to apply any shock to the instrument
Warnings for the disposal of the material
All material must be disposed in accordance with local regulations of the country where the
equipment will be installed and where it will be removed.

Pizzi Instruments S.r.l.
Via del Fornaccio, 46 –50012 Bagno a Ripoli (FI) Italy
Tel.[phone] –Fax [phone] –
email: [e-mail] - web: www.pizzi-instruments.it 5
Symbols and abbreviations
Highlights important information
The Caution Symbol highlights the presence of a potential danger.
CAUTION: of instrument damage. All conditions specified in the associated text must be
fully known and understood before proceeding
This symbol indicates that the product at the end of its useful life must be collected
separately from other waste. The operator must therefore send the equipment to the
appropriate centers for collection of electronic and electrotechnical waste
1. Introduction
This instrument is used for the measurement of water levels in wells or in piezometric pipes.
The instrument is easy to use and has a rugged and robust design.
The principle of measurement is simple; an electric cable with two conductors is lowered into a well or
borehole until it enters into contact with the water surface to be measured.
On the head is the probe which acts as a weighting body for the cable and the element that touches the
water.
Once contact has occurred, the water short circuits the two final pins of the probe.
This short circuit is detected by an acoustic device with suitable battery located at the other end of the cable,
housed in the cable reel.
The connection cable is inextensible and graduated in centimeters (or in millimeters for the model with flat
cable tape).
When the probe head enters into contact with the water, an acoustic signal warns the operator and at that
moment, it is possible to detect by direct reading of the cable, the depth at which contact occurred,
determining the depth of the water surface and thus its level.
2. Initial Inspection
All the instruments have been carefully inspected, both mechanically and electrically, before they leave the
factory.
Please check if all received items correspond with the packing list, your order confirmation and if the list of
components (chapter 4.1) corresponds to the material effectively present.
In case of discrepancy, please contact Pizzi Instruments or your local Representative.
NOTE: All instruments are thoroughly checked both electrically and mechanically before leaving the
factory.

Pizzi Instruments S.r.l.
Via del Fornaccio, 46 –50012 Bagno a Ripoli (FI) Italy
Tel.[phone] –Fax [phone] –
email: [e-mail] - web: www.pizzi-instruments.it 6
2.1 Damage during shipment
If requested at the moment of the order, all instruments can be insured prior to shipment. If you receive a
damaged shipment and shipping insurance was previously arranged you should:
Report the damage to your shipper immediately
Inform Pizzi Instruments or your local representative immediately
Keep all packaging and shipping documents
NOTE: All shipments must immediately opened upon delivery and the content must be
checked, in quality and quantity, on the base of the packing list sent together with the goods.
No claims for shortages, damages or errors will be considered valid if no writing form to our
office within 3 days of receipt of goods will be sent.
Attention: insurance claims may be void if the above procedure is not followed.
3. Storage
Keep the material in a proper site to avoid its deterioration before the installation and to protect it
from any possibility of shocks.
Do not place weights on top of the instrumentation
Do not store the equipment in places where it could cause damage to persons or property
Be careful during the storage not to bend or crush the steel parts
4. Description
4.1 Instrument Components
The system includes :
A probe provided with two contacts in conductive material insulated by a special drip edge.
An additional head for the weighting of the probe.
An inextensible cable with flat or round shape (flat with millimeter or centimeter graduation,
according to model).
The model with flat cable has a maximum external diameter of 12 mm and can be used together with all
piezometric pipes normally in use.
Smaller diameter head(10mm) can only be supplied with the circular cable model.

Pizzi Instruments S.r.l.
Via del Fornaccio, 46 –50012 Bagno a Ripoli (FI) Italy
Tel.[phone] –Fax [phone] –
email: [e-mail] - web: www.pizzi-instruments.it 7
5. Preliminary requirements
Before using the instrument, it is a good rule to check the suitable conditions in the area where the
instrument is used.
A very important procedure for the correct use and the following operation of the instrument is the elimination
of any deposits of any material both on the probe head and on the cable.
6.1 Preliminary Operations
Check the correct operation of the instrument by setting the switch on "ON" position and immerse the head in
a container with water, if everything properly works you will hear the "beep" and the "LED" will light up; failure
to operate may depend either on damage to the cable or on the exhaustion of the battery ("9V") housed on
the front panel.
7. Taking Measure
1. Lower the head into the hole where the measurement is to be made, on contact with the water the
instrument will emit a "beep" and the "LED" will light up.
2. Raise the probe until the sound stops and then re-trace it again to find the contact point for subsequent
approximations
3. Read the measurement directly on the cable and write it down on a previously prepared table
4. At the end of the measurements, clean the instrument and check it again.
8. Technical Assistance
Pizzi Instruments S.r.l. has a wide range of service as phone assistance, installation, training, calibration,
reparation and maintenance.
For any additional information you can directly contact our technicians at the following addresses:
[e-mail]
T: [phone]
F: [phone]
