PL Project PL2000 User manual

Main Page
Work Table with adjustable Height
PL2000
Instruction for Use PL2000
ORIGINAL’S
TRANSLATION
2182&DC_UserManual_PL2000_Release_5_EN_220228.docx 1/30
Work Table with adjustable Height PL2000
User Manual

History
Work Table with adjustable Height
PL2000
Instruction for UsePL2000
ORIGINAL’S
TRANSLATION
2182&DC_UserManual_PL2000_Release_5_EN_220228.docx 2/30
History
Date
Name
Description
30.11.2021
BoL
Creating the document
06.02.2022
RoM
Update Package contents
27.02.2022
RoM
Change first page image, add Figure 2 with description for it. Correct
power consumption. Replace Electrical circuit diagram and needed
Assembly and Installation of the Table figures.
28.02.2022
BoL
Some figures added, Maintenance chapter extended with residual
current breaker description.
Subject to technical modifications to improve the quality and safety of the manufactured
equipment.

Table of contents
Work Table with adjustable Height
PL2000
Instruction for Use PL2000
ORIGINAL’S
TRANSLATION
2182&DC_UserManual_PL2000_Release_5_EN_220228.docx 3/30
Table of contents:
....................
1GENERAL .............................................................................................................................5
2PACKAGE CONTENTS .......................................................................................................... 6
3SAFETY PRECAUTIONS........................................................................................................ 9
3.1 Subject of application .........................................................................................................................................9
3.2 Common risks of non-compliance with safety instructions ....................................................................................9
3.3 Residual hazards .............................................................................................................................................. 10
3.4 Transformation and modifications..................................................................................................................... 11
3.5 Qualified personnel .......................................................................................................................................... 11
3.6 Accident prevention ......................................................................................................................................... 11
3.7 Electromagnetic hazards .................................................................................................................................. 11
4INTENDED USE OF THE EQUIPMENT...................................................................................12
4.1 Purpose of all main modules ............................................................................................................................. 12
5TECHNICAL SPECIFICATIONS..............................................................................................14
6EQUIPMENT INSTALLATION...............................................................................................15
6.1 Stability during use, installation and maintenance ............................................................................................. 15
6.2 Environmental installation requirements ........................................................................................................... 15
6.3 Measurements for installation in order to reduce the noise and vibration level of the equipment .......................... 15
6.4 Assembly and Installation of the Table .............................................................................................................. 15
7EQUIPMENT OPERATION ...................................................................................................22
8MACHINE MAINTENANCE ...................................................................................................23
8.1 Spare parts list. ................................................................................................................................................ 23
8.2 Troubleshooting. Blocking and unblocking of the equipment.............................................................................. 24

Table of contents
Work Table with adjustable Height
PL2000
Instruction for Use PL2000
ORIGINAL’S
TRANSLATION
2182&DC_UserManual_PL2000_Release_5_EN_220228.docx 4/30
8.2.1 Changing fuse of the machine ............................................................................................................................... 24
8.2.2 Reactivating the differential (residual) current protection after a trip..................................................................... 25
9ELECTRICAL CIRCUIT DIAGRAM ..........................................................................................26
10 DECLARATION OF CONFORMITY.....................................................................................29
11 ADDRESS........................................................................................................................30
FIGURES:
FIGURE 1 MACHINE DESCRIPTION FRONT............................................................................................................................. 12
FIGURE 2 MACHINE DESCRIPTION BACK ................................................................................................................................13
FIGURE 3 MOUNTING THE BACK SUPPORT TO THE FLOOR BASE ........................................................................................ 16
FIGURE 4 ALIGNING THE MOTORIZED COLUMN................................................................................................................... 16
FIGURE 5 FASTENING THE MOTORIZED COLUMN ................................................................................................................ 16
FIGURE 6 GROUND WIRES OF THE STATIC PART ...................................................................................................................17
FIGURE 7 MOUNTING OF THE TABLE TOP ..............................................................................................................................17
FIGURE 8 FASTENING THE TABLE TOP .................................................................................................................................. 18
FIGURE 9 MOUNTING THE STAND TO THE TABLE TOP......................................................................................................... 18
FIGURE 10 FASTEN THE STAND ............................................................................................................................................. 19
FIGURE 11 CONNECTING THE GROUND WIRES ON THE MOVING PART............................................................................... 19
FIGURE 12 CONNECTING THE MOTOR CABLE ....................................................................................................................... 20
FIGURE 13 POWER SUPPLY CABLE......................................................................................................................................... 20
FIGURE 14 SUPPLYING A MACHINE THROUGH THE TABLE .................................................................................................. 21
FIGURE 15 CONTROL DEVICES OF PL2000 ............................................................................................................................. 22
FIGURE 16 REMOVING FUSE................................................................................................................................................... 24
FIGURE 17 VIEW OF THE FUSE-HOLDER................................................................................................................................. 25
FIGURE 18 REACTIVATING OF THE RESIDUAL CURRENT PROTECTION................................................................................ 25
TABLES:
TABLE 1 PACKAGE CONTENTS.................................................................................................................................................8
TABLE 2 SPARE PARTS AND ACCESSORIES........................................................................................................................... 24

General
Work Table with adjustable Height
PL2000
Instruction for Use PL2000
ORIGINAL’S
TRANSLATION
2182&DC_UserManual_PL2000_Release_5_EN_220228.docx 5/30
1 General
PL2000 is a stable and versatile single leg working table, which is intended to enable a reliable
support of small machinery in different light industries.
The illustrations in this document are for
informational purposes only and may not be
accurate. Differences between revisions of the
various components may not be reflected in the
illustrations where this is not decisive for the
principle of operation of the system.
Note

Package contents
Work Table with adjustable Height
PL2000
Instruction for Use PL2000
ORIGINAL’S
TRANSLATION
2182&DC_UserManual_PL2000_Release_5_EN_220228.docx 6/30
2 Package contents
The presence of the following parts is to be checked immediately after unboxing the package:
Pos.
Nr
Qty.
Designation
1
1
Table Top
2
1
Back Support
3
1
Floor Base with
mounted Wheels
4
1
Stand
5
1
Pressing Plate
6
1
Motorized
Column
7
5
Toothed lock
washers
DIN 6797 A 4,3

Package contents
Work Table with adjustable Height
PL2000
Instruction for Use PL2000
ORIGINAL’S
TRANSLATION
2182&DC_UserManual_PL2000_Release_5_EN_220228.docx 7/30
8
5
Screw
DIN 7045 H
M4 x 6
9
4
Metal Washer
DIN-9021
Size 6.4
10
10
Metal Washer
DIN-125-1 A-A
Size 6.4
11
8
Screw
ISO 7380-1
Size M6 x 12
12
2
Screw
ISO 7380-1
Size M6 x 16
13
4
Screw
ISO 7380-1
Size M6 x 60
14
1
Floor base
YE/GN
grounding wire
(single side
mounted)
15
1
Back support’s
YE/GN
grounding wire
(single side
mounted)
16
1
Stand’s YE/GN
grounding wire
(single side
mounted)
17
1
YE/GN Wire for
grounding of the
motorized
column (single
side mounted)
18
1
Hex Key 4 mm
19
1
Hex Key 2.5 mm

Package contents
Work Table with adjustable Height
PL2000
Instruction for Use PL2000
ORIGINAL’S
TRANSLATION
2182&DC_UserManual_PL2000_Release_5_EN_220228.docx 8/30
20
1
Table to
Machine
Cable IEC
C13-C14
21
1
Power
Supply
Cable IEC
C13 2)
22
1
Wrench 10mm 1)
Table 1 Package contents
1) Dependent on the table’s revision the Wrench 10mm could not be included
2) The mains plug of the cable depends on the target country

Safety precautions
Work Table with adjustable Height
PL2000
Instruction for Use PL2000
ORIGINAL’S
TRANSLATION
2182&DC_UserManual_PL2000_Release_5_EN_220228.docx 9/30
3 Safety precautions
3.1 Subject of application
Electrically adjustable in height work table PL2000, for short referred as "table", is
intended to support different types of small machines in the industry.
It is unacceptable to use the table for other purposes or outside of measured parameters.
For safety purposes, the table has to be used and maintained according to the following manual
only.
In order to ensure safe and trouble-free operation, the device should be transported, placed,
mounted and leveled correctly in a right environmental condition. Also exploitation has to be with
care and regularly maintained.
3.2 Common risks of non-compliance with safety instructions
This table is safe and reliable. There is a risk of harm if it is not mounted properly or used by not
trained personnel. Anyone involved in the relocation, mounting, maintenance and operation with
the table must be familiar with the operating and installation instructions.

Safety precautions
Work Table with adjustable Height
PL2000
Instruction for Use PL2000
ORIGINAL’S
TRANSLATION
2182&DC_UserManual_PL2000_Release_5_EN_220228.docx 10/30
WARNING
CAUTION
3.3 Residual hazards
The hazards that were impossible to remove by technological means during the design and
manufacturing of the equipment are listed in this instruction. The following symbols are used to
warn of residual risks:
Symbol: Meaning: Dangerous situation
A warning of a potentially dangerous situation in
which non-compliance with safety measures can
result in death or serious physical injury.
Symbol: Meaning: Potentially dangerous situation
Warns of a potentially dangerous situation in
which non-compliance with safety measures could
lead to the destruction of property or some kind of
physical damage.
Symbol: Meaning: Important note
Useful information about the equipment or its
maintenance
Symbol: The national environmental and recycling legislation requires any waste equipment
and used consumables to be disposed separately from the household waste.
More information can be obtained from the respective public authorities or the
vendor of the product to be disposed.
Note

Safety precautions
Work Table with adjustable Height
PL2000
Instruction for Use PL2000
ORIGINAL’S
TRANSLATION
2182&DC_UserManual_PL2000_Release_5_EN_220228.docx 11/30
3.4 Transformation and modifications
The table PL2000 must not be modified in terms of its design or safety measures without express
written consent by the manufacturer - PL Project Ltd. Any modification excludes any
responsibility by the manufacturer for any damage or injury resulting from the modification.
3.5 Qualified personnel
The equipment must be installed, set up and placed for operation by associates familiar with the
equipment and by following the safety instructions and measures described below. Qualified
personnel are person or group of people that are trained for installation, relocation and
maintenance of the equipment.
3.6 Accident prevention
The table has a board controller and the motor speed is software preset in order to prevent any
danger to the operator, also motor electrical current is limited to prevent any damage to the
equipment.
The general rules and instructions for accident prevention must be followed.
3.7 Electromagnetic hazards
The PL2000 table complies with EN 55011 cl. 62.2 –Limits of electromagnetic disturbances for
class B group 1. The tests and measurements designate the system as safe for use even in
domestic and light industrial areas.

Intended use of the equipment
Work Table with adjustable Height
PL2000
Instruction for Use PL2000
ORIGINAL’S
TRANSLATION
2182&DC_UserManual_PL2000_Release_5_EN_220228.docx 12/30
4 Intended use of the equipment
The PL2000 is a single leg work table with electrical adjustment of height, which is intended to
carry small and relatively light machinery in different industry areas.
4.1 Purpose of all main modules
The basic components and controls of the table are shown on Figure 1 and Figure 2.
Figure 1 Machine description front
2
5
1
6
7
3
4
9
8

Intended use of the equipment
Work Table with adjustable Height
PL2000
Instruction for Use PL2000
ORIGINAL’S
TRANSLATION
2182&DC_UserManual_PL2000_Release_5_EN_220228.docx 13/30
CAUTION
Figure 2 Machine description back
1. Table’s top with the working surface;
2. Table’s back support;
3. Tables floor base with mounted wheels;
4. Stand for different tools, materials and accessories;
5. Trigger button –pressing this button starts the movement of the table’s top together with
the stand (4);
6. Height adjustment dial –using this one the desired height is chosen;
7. Power on switch;
8. Stand’s front board;
9. Motorized lifting column;
10. Differential current protection;
11. Power Supply Socket for Cable IEC C13 with switch and fuse;
12. Power Supply Socket for cable IEC C13-C14;
Any operation of the equipment outside its intended use may
result in damage to the equipment and injury to the operating
personnel
10
11
12

Technical specifications
Work Table with adjustable Height
PL2000
Instruction for UsePL2000
ORIGINAL’S
TRANSLATION
2182&DC_UserManual_PL2000_Release_5_EN_220228.docx 14/30
5 Technical specifications
Outer dimensions of the package: –
width ........... 530 mm;
length.......... 680 mm;
height.......... 150 mm;
Gross weight 23 kg;
Power supply 100-240V/50-60 Hz;
Power consumption –50 W;
Height range ~78-120 cm
Maximal linear velocity 10 mm/s
Noise level.. <70dB (А);
Net weight .. 21 kg;
Max permissible load 50 kg;
Working temperature 10÷38°C
Storing and transporting temperature -20÷+60°C
Average humidity without condensation 10÷90%
Environment: additional measures may become necessary when working in a dusty or
aggressive environment or exposed to strong electromagnetic interference.

Equipment operation
Work Table with adjustable Height
PL2000
Instruction for Use PL2000
ORIGINAL’S
TRANSLATION
2182&DC_UserManual_PL2000_Release_5_EN_220228.docx 15/30
6 Equipment installation
6.1 Stability during use, installation and maintenance
Following the instructions in present Chapter 6 the operator, respectively the maintenance
personnel ensure the safety of the equipment and people during use, installation and
maintenance.
6.2 Environmental installation requirements
The table is designed for indoor use only.
Keep it away from moisture or rain, snow, ice, salt water and aggressive chemicals.
The presence of metallic dust or corrosive gases in the air can impair the functionality of the
machine.
Installing of the machine can be made by each user by keeping with the following requirements:
6.3 Measurements for installation in order to reduce the noise and vibration level of the
equipment
The table with electrical height adjustment PL2000 works with levels of the noise and vibrations
which are safe for the operators and the maintenance personnel.
There are not special measures foreseen in order to reduce these levels.
6.4 Assembly and Installation of the Table
Installation of the machine is easy and doesn’t require additional instruments unless the ones
that could be found in the packaging.
1. Unpack of the table. Take it out from the transportation packaging and released from all
sealing.
2. Assembly the table according the following diagrams:
a.. Mount the Back Support to the Floor Base: !

Equipment operation
Work Table with adjustable Height
PL2000
Instruction for Use PL2000
ORIGINAL’S
TRANSLATION
2182&DC_UserManual_PL2000_Release_5_EN_220228.docx 16/30
Figure 3 Mounting the back support to the floor base
b.. Align the Motorized Column and the Pressing Plate:
Figure 4 Aligning the Motorized Column
c.. Fastening the Motorized Column:
Figure 5 Fastening the Motorized Column

Equipment operation
Work Table with adjustable Height
PL2000
Instruction for Use PL2000
ORIGINAL’S
TRANSLATION
2182&DC_UserManual_PL2000_Release_5_EN_220228.docx 17/30
d.. Connecting the ground wires :
Figure 6 Ground wires of the static part
e.. Mount the Table Top:!
Figure 7 Mounting of the Table Top

Equipment operation
Work Table with adjustable Height
PL2000
Instruction for Use PL2000
ORIGINAL’S
TRANSLATION
2182&DC_UserManual_PL2000_Release_5_EN_220228.docx 18/30
f... Fasten the Table Top
Figure 8 Fastening the Table Top
g.. Mount the Stand to the Table Top:
Figure 9 Mounting the Stand to the Table Top

Equipment operation
Work Table with adjustable Height
PL2000
Instruction for Use PL2000
ORIGINAL’S
TRANSLATION
2182&DC_UserManual_PL2000_Release_5_EN_220228.docx 19/30
CAUTION
h.. Fasten the Stand to the Table Top
Figure 10 Fasten the Stand
i... Connecting the ground wires of the moving part
Figure 11 Connecting the ground wires on the moving part
DANGER. Incorrect connection or fastening of
grounding wires may cause danger for life and
health of the operating personnel!

Equipment operation
Work Table with adjustable Height
PL2000
Instruction for Use PL2000
ORIGINAL’S
TRANSLATION
2182&DC_UserManual_PL2000_Release_5_EN_220228.docx 20/30
j... Plug in the Motorized Column’s cable into the control module’s socket. Please see
Figure 12.
Figure 12 Connecting the motor cable
3. Place for installation:
The table should be placed on a flat, horizontal and stable floor with area equal or larger in
each dimension than 70cm.
4. Power supply
The machine is supplied by a standard IEC C13, 3-wire power supply cable. The cable is
included in the delivery.
The receptacle’s side of the cable should be plugged in the appropriate connector on the
bottom side of the PL2000 control box - Figure 13.
Figure 13 Power supply cable
