Plaid Systems ENGRAVER User manual

USER GUIDE
INSTRUCTIONS
CAUTION:
This is a high speed tool. Negligence may cause injury if
not handled properly.
This tool is not a toy and is not intended for use by
children 14 years or younger without adult supervision.
Do not allow tool to come in contact with any liquid or
immerse in water as it may cause damage.
To avoid overheating, do not operate continuously for
more than 2 minutes at a time.
Keep hair, lose clothing, jewelry away from tool tip as it
may become entangled and cause injury.
Use eye protection and a dust mask while sanding,
engraving or grinding.
Do not insert any objects into the tool other than the tool
bits included.
After completing use of tool, turn to off position and keep
out of reach of children.
WARNING: CHOKING HAZARD – Small parts. Not for
children under 14 years or younger without adult
supervision.
Maximum operating speed is 15,000 rpm.
©2019 PLAID ENTERPRISES, INC. • 09/19
P.O. BOX 7600 •NORCROSS,GA30091-7600
[phone] • MADE IN CHINA
34670E
1. Rotate the battery cover at the end of tool to open.
2. Insert two 1.5V AA batteries into tool being sure to follow
the placement guide shown on tool.
3. Rotate the end battery cover to the “I” mark to ensure the
tool is in “On” mode.
4. To insert tip, first press Shaft Lock Button and rotate the
collet nut by hand until the lock engages the shaft,
preventing rotation, then insert desired tip. While hold-
ing the Shaft Lock Button, reverse rotate the collet nut
into secure position.
5. Press the work button to start using tool. Release the
work button to stop tool.
6. When changing tool tips always rotate the end battery
cover to the left to just past the “0” mark to ensure tool is
in OFF mode.
7. After use, remove the battery cover and remove batteries
before storing away, out of reach of children.
SAFETY PRECAUTIONS
MAINTENANCE
1. For best results use alkaline batteries. Do not mix old and
new batteries.
2. Do not mix alkaline, standard or rechargeable batteries.
3. Do not use tool continuously for more than 2 minutes at a
time as longer use may result in overheating tool motor
and shorten tool’s lifespan.
4. Tool can operate for approx. 30 cycles (2-minute continuous
use with 1 min break) using new batteries.
5. When tool is not in use, remove batteries and store away
from small children.
