Plaisio Turbox User manual

Desktop PC
USER MANUAL

2
Note
This user manual is only for reference and might differ from the actual
product.
Contents
•Overview 4
oParts 4
▪Front View 5
▪Top View 7
▪Rear View 9
•Installation 11
•Troubleshooting 12
•Regulatory Information 15
•Safety & Maintenance 16
•Service Manual
oMotherboard Replacement 18
oCPU Replacement 19
oPSU Replacement 19
oStorage Media Replacement 20

3

4
Desktop PC
•Overview
•Parts

5
Front View

6
1. Optical drive slot (CD/DVD)
2. Optical drive open/close button
Note:
If you want to insert an optical media (CD/DVD), press this
button once and the slot will open. Put the media in the right
position and press this button again. Avoid putting pressure
on the slot because it might get damaged.

7
Top View

8
1. Power button
2. HDD activity LED
3. Reset button
4. USB 3.0 Port
5. Speaker Jack
6. Microphone Jack

9
Rear View

10
1. Power Cable Socket
2. Keyboard/ Mouse Port
3. DVI/ VGA Display Port
4. HDMI Display Port
5. USB Ports
6. Ethernet Port
7. Speaker, Microphone and Headphone Jacks

11
•Installation
Power supply (electricity) is required in order to
install this Desktop PC.
✓Connect one end of the power cable to the
computer’s power cable socket (Rear view no2).
Connect the other end to a wall power socket of
your home.
✓Connect the display cable to the corresponding
port (VGA –DVI –HDMI), depending on your
monitor.
✓Connect your keyboard and mouse to the
corresponding ports (Rear view nο3, nο4).
✓You are now ready to boot your computer by
pressing the power button (Top view no1)

12
•Troubleshooting
•Monitor problem
✓Check the power supply of your monitor. Your
monitor needs separate power supply in order
to operate.
✓Check if your monitor is powered on.
✓Check the connection of the display cable
(VGA-DVI-HDMI).
✓If the problem persists, try connecting the
monitor using another type of display cable or
try another monitor.
✓If the problem persists, call 800 11 12345 for
help from our qualified personnel.

13
•Boot problem
If you are pressing the power button on your computer but it
doesn’t boot:
✓Check if it is properly connected to the power
socket.
✓Check if the PSU power switch is off (Rear view no1)
✓If you have connected your computer to a power
strip, remove it from the power strip and connect it
directly to the power socket on the wall and try
again. If the problem persists, try plugging it into
another power socket.
✓If the problem persists, call 800 11 12345 for help
from our qualified personnel.

14
•Software Reinstallation
Caution
This process will format the hard disk drive. After
formatting, you will need to reinstall the software.
Formatting will erase all data on the hard disk.
✓Back up all your data from your hard disk.
✓Insert Recovery Boot CD to your CD-ROM drive.
✓Reboot your PC and select the CD-ROM drive as first
boot device. Follow the on-screen instructions to
complete the procedure.
✓For any question, call 800 11 12345 for help from
our qualified personnel.

15
Regulatory Information
Declaration of conformity
This product complies to the requirements of the
following EU Directives: Low Voltage Directive, LVD
2014/35/EC, Electromagnetic Compatibility Directive,
EMC 2014/30/EC and Ecodesign Requirements
Directive, 2009/125/EC.
Full text of the EU Compliance Declaration is
available on the following website:
http://www.plaisio.gr/, at the company’s HQ:
Thesi Skliri, Magoula, Attica, 19018,
or by telephone: [phone]

16
Safety & Maintenance
This user manual contains important information about the
use and operation of your PC. Please read it thoroughly and
carefully before use, for optimal performance of your PC, as
well as to avoid any damage/injury to yourself and your PC.
Any change or modification not compliant to the contents of
this user manual may violate the warranty terms and cause
damage/injury to yourself and your PC.
Do not use the power cable if it is damaged.
•Do not try to connect the power cable to an unsuitable socket.
•Do not use multiple devices on the same power strip because there
is danger of overheating or fire.
•Do not touch the power cable with wet hands.
•Do not bend or pull the power cable forcefully.
•Do not place heavy objects on the power cable.
•Use only the provided power cable.
•Do not install the device near heat sources such as radiators, fan
heaters, stoves, ovens or other appliances (including amplifiers)
that may produce heat. Pay special attention to the power cable.
•First turn off the device and then disconnect the power cable from
the power socket.
•Do not block ventilation openings.

17
•Disconnect the device from the power socket during electrical
storms.
•Do not paint or try to disassemble or modify this product. Contact
the qualified personnel of Plaisio Computers to obtain service.
•It is not allowed to use substances such as gasoline, solvents or
alcohol to clean the product. Do not apply corrosive chemicals
(such as detergents) on your appliance. To clean it, only use a soft
cloth or compressed air.
•Do not leave your device exposed to the sun or in a very dusty
environment.
•Do not use the device in case it is damaged.
•In case of malfunction, do not try to repair the device by yourself.
Contact our qualified personnel.

18
Service Manual
Motherboard Replacement
1)
ATX_12V
9)
F_AUDIO
2)
ATX
10)
SPEAKER
3)
CPU_FAN
11)
F_USB30
4)
SYS_FAN1
12)
F_USB1/F_USB2
5)
SATA3 0/1/2/3
13)
TPM
6)
M2F_32G
14)
BAT
7)
SPDIF_O
15)
CI
8)
F_PANEL
16)
CLR_CMOS

19
CPU Replacement
Locate the triangular marking on the CPU socket. Match this triangular marking to the corresponding
triangular marking at the top of the CPU.
A Small Triangle
A Small Triangle
Marking Denotes
Pin
AM4 Socket
Marking Denotes
AM4
CPU
one of the
Socket
CPU Pin One
PSU Replacement
Pin Definition

20
Storage Media Replacement
Connect the cable of your new Storage Media to the below listed ports.
