Planet Networking & Communication IKVM-210 M Series User manual

8-/16-port Combo LCD KVM Switch
IKVM/KVM-210 M Series
- 1-
8-/16-port Combo LCD KVM
8-/16-port Combo IP LCD KVM
IKVM/KVM-210 M Series

8-/16-port Combo LCD KVM Switch
IKVM/KVM-210 M Series
- 2-
Copyright
Copyright 2017 by PLANET Technology Corp. All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or
computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical,
manual or otherwise, without the prior written permission of PLANET.
PLANET makes no representations or warranties, either expressed or implied, with respect to the
contents hereof and specifically disclaims any warranties, merchantability or fitness for any particular
purpose. Any software described in this manual is sold or licensed "as is". Should the programs prove
defective following their purchase, the buyer (and not PLANET, its distributor, or its dealer) assumes the
entire cost of all necessary servicing, repair, and any incidental or consequential damages resulting
from any defect in the software. Further, PLANET reserves the right to revise this publication and to
make changes from time to time in the contents hereof without obligation to notify any person of such
revision or changes.
All brand and product names mentioned in this manual are trademarks and/or registered trademarks of
their respective holders.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio technician for help.
FCC Caution
To assure continued compliance, use only shielded interface cables when connecting to computer or
peripheral devices. Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

8-/16-port Combo LCD KVM Switch
IKVM/KVM-210 M Series
- 3-
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Federal Communication Commission (FCC) Radiation Exposure Statement
This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In
order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to
the antenna shall not be less than 20 cm (8 inches) during normal operation.
Safety
This equipment is designed with the utmost care for the safety of those who install and use it. However,
special attention must be paid to the dangers of electric shock and static electricity when working with
electrical equipment. All guidelines of this and of the computer manufacture must therefore be allowed
at all times to ensure the safe use of the equipment.
CE Mark Warning
This is a Class B product. In a domestic environment, this product may cause radio interference, in
which case the user may be required to take adequate measures.
WEEE Regulation
To avoid the potential effects on the environment and human health as a result of the
presence of hazardous substances in electrical and electronic equipment, end users of
electrical and electronic equipment should understand the meaning of the crossed-out
wheeled bin symbol. Do not dispose of WEEE as unsorted municipal waste and have to collect such
WEEE separately.
Revision
User’s Manual of PLANET 8-/16-port Combo LCD KVM
Model: KVM-210-08M / KVM-210-16M / IKVM-210-08M / IKVM-210-16M
Rev: 1.00 (January, 2017)
Part No. EM-KVM_IKVM-210 M Series_v1.0.doc

8-/16-port Combo LCD KVM Switch
IKVM/KVM-210 M Series
- 4-
Table of Contents
Chapter 1. Product Introduction.......................................................................................................5
1.1 Package Contents....................................................................................................................5
1.2 Overview ..................................................................................................................................6
1.3 Features.................................................................................................................................10
1.4 Specifications .........................................................................................................................11
Chapter 2. Hardware Interface ........................................................................................................15
2.1 Physical Descriptions.............................................................................................................15
2.2 Hardware Installation .............................................................................................................18
Chapter 3. Operations......................................................................................................................21
3.1 Manual Key............................................................................................................................21
3.2 Switch Hotkey ........................................................................................................................21
3.3 OSD (On Screen Display)......................................................................................................21
3.3.1 GOTO ..................................................................................................................23
3.3.2 SCAN...................................................................................................................23
3.3.3 LIST .....................................................................................................................24
3.3.4 QV (Quick View) ..................................................................................................25
3.3.5 EDIT.....................................................................................................................25
3.3.6 SET......................................................................................................................26
Chapter 4. IPKVM Software (For IKVM Series)..............................................................................28
4.1 System Requirements............................................................................................................28
4.2 IPKVM Software Installation...................................................................................................28
Chapter 5. Web-based Management (For IKVM Series) ...............................................................31
5.1 Mouse Settings ......................................................................................................................31
5.2 Network Connection...............................................................................................................35
5.3 Web Managenent...................................................................................................................36
5.3.1 Console................................................................................................................36
5.3.2 User .....................................................................................................................38
5.3.3 Log.......................................................................................................................39
5.3.4 Network................................................................................................................39
5.3.5 System.................................................................................................................41
Appendix A: Frequently Asked Questions........................................................................................42

8-/16-port Combo LCD KVM Switch
IKVM/KVM-210 M Series
- 5-
Chapter 1. Product Introduction
1.1 Package Contents
The package should contain the following:
Combo LCD KVM Switch x 1
Quick Guide x 1
IP installation Guide x 1 (For IKVM Series)
KVM Cable x 1
Rack-mounting Kit x 1
Power Adapter x 1
Power Cord x 1
Stand Kit x 1
M6 Screw x 12
If any of the above items are missing, please contact your seller immediately.

8-/16-port Combo LCD KVM Switch
IKVM/KVM-210 M Series
- 6-
1.2 Overview
Easy Switching, Efficient Management
PLANET KVM-210-08M/16M Combo VGA LCD KVM Switch features an integrated 17" LED-backlit
LCD panel allowing access to and control up to 8/16 computers from a single console (keyboard,
mouse and monitor). Simply use the supplied Combo VGA cable set to link the KVM-210-08M/16M to
the console ports of your KVM Switch, regardless of the connected port interface -- USB or PS/2.
Control All Your PCs via IP-based KVM (For IKVM Series)
PLANET IKVM-210-08M/16M Combo VGA LCD IP KVM Switch comes with a rack-mountable
keyboard, 17" LCD and touchpad in a single console that occupies only 1U of rack space. From across
the room, down the street or halfway around the globe, the IKVM-210-08M/16M can be accessed from
any computer on the LAN, WAN or Internet. Easy to install and use, it’s the optimal solution for
controlling up to 8/16 computers/servers.
Easy to Install
With the uniquely separate rail design, it helps to install the KVM console easily. Moreover, when there
is a need to maintain the console, the administrator can easily uninstall the device without affecting the
server above or below.

8-/16-port Combo LCD KVM Switch
IKVM/KVM-210 M Series
- 7-
Multiple Operating Systems Supported (For IKVM Series)
The IKVM-210-08M/16M is the most cost-effective and simple solution for controlling a group of PCs in
the network. Multiple computers can be managed via only one single set of monitor, keyboard and
mouse directly. No software drivers or system configuration are required. iMac, Power Mac and Sun
systems are also supported.
Remote Key Combination (For IKVM Series)
You could set the multiple key combinations at IKVM Series. When you open IKVM software at remote

8-/16-port Combo LCD KVM Switch
IKVM/KVM-210 M Series
- 8-
client, you could use these key combinations to control these local PCs with a different OS via the
internet.
Computer Switching
There are three convenient methods to access any computer connected to the installation:
Port select button
Hotkeys on keyboard
OSD (on screen display) at local client and remote client
Security Protection
Two level password security only authorizes up to one user and an administrator with a separate profile
for each user. Data encryption options include AES, DES and 3DES, and they can be selected for
keyboard, mouse and video signals.

8-/16-port Combo LCD KVM Switch
IKVM/KVM-210 M Series
- 9-
Powerful Mouse/Keyboard Support
In the present computer applications, a mouse has become an indispensable device. The
IKVM/KVM-210 Series fully supports all models of PS/2 mice on the market. The KVM also supports
the PS/2 keyboard port of code set 1/2/3 and further allows you to use the KVM for all kinds of servers,
computers or their combination.

8-/16-port Combo LCD KVM Switch
IKVM/KVM-210 M Series
- 10 -
1.3 Features
Hardware
■Integrated 17” LCD monitor and keyboard/touchpad module within 1U chassis
■Standalone machine controls up to 8/16 sets of computers
■Up to 2 levels can be cascaded and up to 64/256 computers can be controlled
■Port Select Panel status LEDs give a clear indication of the active computers
■Mouse touch board with two function buttons
■Full-size 100-key keyboard with integrated number pad
■Front panel with lock to prevent damage by accident
Security
■Two-layer password security protection
■DES, AES and 3DES for data encryption (For IKVM Series)
Management
■Auto scan mode for monitoring computers
■Requires no additional software or hardware
■Computer selection via Port Select Button, Hotkey and On Screen Display (OSD)
■Hot pluggable: Add or remove computers without having to power down the switch
■QVS (Quick View Setting): Quickly select your computer by naming or SN number
Remote Access (For IKVM Series)
■Remotely control PC via TCP/IP and a built-in 10/100/1000Mbps Ethernet port
■High Video Quality: Resolution up to 1280 x 1024 (local side) or 1920 x 1080 (remote side)
■Sends the key combinations to a remote computer
■Administrator and multiple users with password protection
■Use of the absolute synchronistical technology of mouse to ensure the accuracy of the
Windows operating system
■Expedient bandwidth control
Compatibility
■Multiplatform support -- Windows, Linux and Sun
■Multibrowser support (IE, Chrome, Firefox) (For IKVM Series)
■Supports Microsoft Intellimouse, Logitech Net Mouse and other third-party’s PS/2 mice

8-/16-port Combo LCD KVM Switch
IKVM/KVM-210 M Series
- 11 -
1.4 Specifications
KVM-210 M Series Specifications
Product KVM-210-08M KVM-210-16M
Hardware
Number of Ports 8 D-sub ports (15-pin) 16 D-sub ports (15-pin)
Maximum
64 by 2-tier star-type
cascading
(KVM-210-08 x 8)
256 by 2-tier star-type
cascading
(KVM-210-16 x 16)
PC Ports
Keyboard PS/2 female + USB Type A female
Mouse PS/2 female + USB Type A female
Video 8 D-sub ports (15 female) 16 D-sub ports (15 female)
Port Select
Panel
Number Key 10
Reset 1
Enter 1
LED 8 (Red) 16 (Red)
Segment Display 1
LCD Panel
Monitor 17” SXGA Color TFT-LCD
Video Resolution 1280 x 1024
Pixel Pitch 0.297 x 0.297 mm
Support Color 16.2 M / 262K colors
Contrast Ratio 1000:1
Backlight LED
LCD Button 6
Console USB Hub Ports 3 USB 2.0 Type A female
Keyboard 100
Touch Pad 1
Housing Metal
Dimensions (W x D x H) 611 x 555.5 x 44.5 mm
Weight 17.52kg
Power Requirement 12V DC, 4A
Installation 1U rack-mountable
Management
PC Selection Port select button

8-/16-port Combo LCD KVM Switch
IKVM/KVM-210 M Series
- 12 -
Hotkeys on keyboard
OSD (on screen display)
Scan Interval 5~60 seconds
Security User password and super password
Environment & Certification
Operating Temperature 0 ~ 50 degrees C
Operating Humidity 0 ~ 90%
Regulatory CE, FCC

8-/16-port Combo LCD KVM Switch
IKVM/KVM-210 M Series
- 13 -
IKVM-210 M Series Specifications
Product IKVM-210-08M IKVM-210-16M
Hardware
Number of Ports 8 D-sub ports (15-pin) 16 D-sub ports (15-pin)
Maximum
64 by 2-tier star-type
cascading
(KVM-210-08 x 8)
256 by 2-tier star-type
cascading
(KVM-210-16 x 16)
PC Ports
Keyboard PS/2 female + USB Type A female
Mouse PS/2 female + USB Type A female
Video 8 D-sub ports (15 female) 16 D-sub ports (15 female)
Port Select
Panel
Number Key 10
Reset 1
Enter 1
LED 8 (Red) 16 (Red)
Segment Display 1
LCD Panel
Monitor 17” SXGA Color TFT-LCD
Video Resolution 1280 x 1024
Pixel Pitch 0.297 x 0.297 mm
Support Color 16.2 M / 262K colors
Contrast Ratio 1000:1
Backlight LED
LCD Button 6
Console USB Hub Ports 3 USB 2.0 Type A female
Remote Console 1 RJ45 port for 10/100/1000BASE-T
Video Resolution Local side: 1280 x 1024 (max)
Remote side: 1920 x 1080 (max)
Keyboard 100
Touch Pad 1
Housing Metal
Dimensions (W x D x H) 611 x 555.5 x 44.5 mm
Weight 17.52kg
Power Requirement 12V DC, 4A
Installation 1U rack-mountable

8-/16-port Combo LCD KVM Switch
IKVM/KVM-210 M Series
- 14 -
Management
Supported Protocol TCP, IP, HTTP
Client Software IPKVM Software
PC Selection
Port select button
Hotkeys on keyboard
OSD (on screen display)
Scan Interval 5~60 seconds
Security User password and super password
DES, AES and 3DES
Environment & Certification
Operating Temperature 0 ~ 50 degrees C
Operating Humidity 0 ~ 90%
Regulatory CE, FCC

8-/16-port Combo LCD KVM Switch
IKVM/KVM-210 M Series
- 15 -
Chapter 2. Hardware Interface
2.1 Physical Descriptions
Control Platform
No. Component Function Description
1 LCD 17" LCD screen
2 Port Select Panel Switch the Port Number and display the online port
3 Touchpad Mouse Operation
4 Keyboard Keyboard Operation
5 Slide Rail Single Slide Rail
6 8-/16-port KVM Modular KVM for 8/16 ports
7 LCD Panel OSD Buttons Controls Display Required Quality
KVM-210 M Series Rear Panels

8-/16-port Combo LCD KVM Switch
IKVM/KVM-210 M Series
- 16 -
IKVM-210 M Series Rear Panels
Interface Description
Power Jack
The input power is 12V DC.
Use the power adapter included in the package; otherwise, it may
damage the unit and result in danger.
USB Port Plug external USB keyboard and mouse into this port.
Computer Port Install the KVM cable connected to a PC here.
Port Select Panel
Interface Description
Online If a corresponding LED number is on, it means the port is online. Otherwise, the
port is off.
Select The selected port number will display here in segment display.
RST Detect the PS2/USB signal of port again.
ENT
User can select by pressing the number buttons and press “ENT” to confirm,
then it will switch to the corresponding port. If that port is offline or the wrong
number is pressed which is not included in display scope, there will be no
response, but just keep the present status.

8-/16-port Combo LCD KVM Switch
IKVM/KVM-210 M Series
- 17 -
IP Module
Interface Description
LAN Port One 10/100/1000BASE-T RJ45 auto-MDI/MDI-X port.
Reboot Press and release to restart the system.
Reset Press for 5 seconds to reset to default.

8-/16-port Combo LCD KVM Switch
IKVM/KVM-210 M Series
- 18 -
2.2 Hardware Installation
The LCD KVM provides a standard 19-inch rack for the installation of devices. Please use the rack
installation accessories attached with the product package. First install the accessories to the device
and then the device to the rack.
Step 1. Screw the front flange to the rack first. Slide the bars with the rear flange towards the rack until
the flanges make contact with the rack, then screw the rear flanges to the rack.
Step 2. Slide the switch onto the support flanges. Use the screws supplied with this package to loosely
attach the front of the switch to the front of the rack.
1) You must use the screws supplied with the mounting brackets. Damage caused to the
parts by using incorrect screws would invalidate your warranty.
2) Please make sure computer and switch KVM are turned off.

8-/16-port Combo LCD KVM Switch
IKVM/KVM-210 M Series
- 19 -
Step 3. Slide the rear attachment sliding brackets along the slide bars until they contact the rear of the
switch.
Step 4. Use the screws supplied with this package to attach the bars to the rear of the switch.
Step 5. Connect a PC to a computer port of the KVM, for example, port 1.

8-/16-port Combo LCD KVM Switch
IKVM/KVM-210 M Series
- 20 -
Step 6. Attach the power supply to the KVM unit and plug the other end into an electrical receptacle.
Now you will see the LED for Port 1 light up. Switch on your monitor from the Port Select button.
