Planet CAM-AHD325 User manual
– 5 – – 6–
5. Specications
Product
Model CAM-AHD325 CAM-AHD425
Camera
Sensor SONY 1/2.8” 2MP CMOS
Effective Picture
Elements 1920(H) x 1080(V) @ 30fps
Lens Furnished Board Lens 3.6mm/F1.2
Minimum
Illumination
0.01 lux @ F1.2 (AGC ON), 0 lux
with built-in IR LED
LED
IR LED
36 units of
850nm High
Power IR LED
24 units of
850nm High
Power IR LED
IR Project Distance 30 meters 20 meters
Video & Audio
S/N Ratio More than 58 dB
White Balance Automatically (1800K ~ 10500K)
Gamma
Characteristic 0.45
Gain Control Automatically
Auto Electronic
Shutter 1/50(1/60)s~1/100,000s
Noise Reduction 2D/3D
Synchronous
System Internal
Transmission
Distance
Coaxial transmission common 75-3
cable up to 300-500 meters
Environment
Operating
Temperature -20 to 50 degrees C
Video Output 1 Vp-p Composite Video/75 ohms
Power Supply 12V DC, 1A
Water Resistance IP66 IP65
Dimensions
(W x D x H)
83 x 192 x 77
mm
98 x 110 x 77
mm
Further Information
If you have any other question, please contact the dealer
where you purchased this product or you can contact
PLANET directly at the following email address: support_
ica@planet.com.tw
– 1 – – 2 –
– 3 – – 4 –
1. Packet Contents
VERIFY THE CONTENTS INSIDE THE PACKAGE BOX
The package should contain the items plus CAM-AHD325/
CAM-AHD425. If any item is missing or damaged, please
contact the seller immediately.
Quick installation guide x 1 Hex wrench x 1
(CAM-AHD325 only)
CAM-AHD325 CAM-AHD425
Screw packet x 1
2. Physical Introduction
CAM-AHD325 CAM-AHD425
IR LED IR LED Sunshield
Video Output
Power Input
OSD Control Button
Connector Description
Power Input Connect to a 12V DC power adapter.
Video Output BNC connector for analog video output.
3. Hardware Installation
1. Place the camera in a suitable location and attach with
screws.
2. Adjust the camera to the correct direction.
3. Connect video output connector to your AHD DVR.
4. Connect a 12V DC power adapter to the Power Input
connector.
Note
Before connecting the power adapter to the
camera, please make sure the power output
voltage is 12V DC (max. ±10%). If you are
not sure of this part, we suggest you use
a 12V DC switching power adapter. It can
provide stable power output.
4. OSD Function
Setting Steps
1. Exposure
2. Digital Noise Reduction
3. Special Functions
4. Adjust
– 1 – – 2 –
– 3 – – 4 –
1. Packet Contents
VERIFY THE CONTENTS INSIDE THE PACKAGE BOX
The package should contain the items plus CAM-AHD325/
CAM-AHD425. If any item is missing or damaged, please
contact the seller immediately.
Quick installation guide x 1 Hex wrench x 1
(CAM-AHD325 only)
CAM-AHD325 CAM-AHD425
Screw packet x 1
2. Physical Introduction
CAM-AHD325 CAM-AHD425
IR LED IR LED Sunshield
Video Output
Power Input
OSD Control Button
Connector Description
Power Input Connect to a 12V DC power adapter.
Video Output BNC connector for analog video output.
3. Hardware Installation
1. Place the camera in a suitable location and attach with
screws.
2. Adjust the camera to the correct direction.
3. Connect video output connector to your AHD DVR.
4. Connect a 12V DC power adapter to the Power Input
connector.
Note
Before connecting the power adapter to the
camera, please make sure the power output
voltage is 12V DC (max. ±10%). If you are
not sure of this part, we suggest you use
a 12V DC switching power adapter. It can
provide stable power output.
4. OSD Function
Setting Steps
1. Exposure
2. Digital Noise Reduction
3. Special Functions
4. Adjust
– 1 – – 2 –
– 3 – – 4 –
1. Packet Contents
VERIFY THE CONTENTS INSIDE THE PACKAGE BOX
The package should contain the items plus CAM-AHD325/
CAM-AHD425. If any item is missing or damaged, please
contact the seller immediately.
Quick installation guide x 1 Hex wrench x 1
(CAM-AHD325 only)
CAM-AHD325 CAM-AHD425
Screw packet x 1
2. Physical Introduction
CAM-AHD325 CAM-AHD425
IR LED IR LED Sunshield
Video Output
Power Input
OSD Control Button
Connector Description
Power Input Connect to a 12V DC power adapter.
Video Output BNC connector for analog video output.
3. Hardware Installation
1. Place the camera in a suitable location and attach with
screws.
2. Adjust the camera to the correct direction.
3. Connect video output connector to your AHD DVR.
4. Connect a 12V DC power adapter to the Power Input
connector.
Note
Before connecting the power adapter to the
camera, please make sure the power output
voltage is 12V DC (max. ±10%). If you are
not sure of this part, we suggest you use
a 12V DC switching power adapter. It can
provide stable power output.
4. OSD Function
Setting Steps
1. Exposure
2. Digital Noise Reduction
3. Special Functions
4. Adjust
– 1 – – 2 –
– 3 – – 4 –
1. Packet Contents
VERIFY THE CONTENTS INSIDE THE PACKAGE BOX
The package should contain the items plus CAM-AHD325/
CAM-AHD425. If any item is missing or damaged, please
contact the seller immediately.
Quick installation guide x 1 Hex wrench x 1
(CAM-AHD325 only)
CAM-AHD325 CAM-AHD425
Screw packet x 1
2. Physical Introduction
CAM-AHD325 CAM-AHD425
IR LED IR LED Sunshield
Video Output
Power Input
OSD Control Button
Connector Description
Power Input Connect to a 12V DC power adapter.
Video Output BNC connector for analog video output.
3. Hardware Installation
1. Place the camera in a suitable location and attach with
screws.
2. Adjust the camera to the correct direction.
3. Connect video output connector to your AHD DVR.
4. Connect a 12V DC power adapter to the Power Input
connector.
Note
Before connecting the power adapter to the
camera, please make sure the power output
voltage is 12V DC (max. ±10%). If you are
not sure of this part, we suggest you use
a 12V DC switching power adapter. It can
provide stable power output.
4. OSD Function
Setting Steps
1. Exposure
2. Digital Noise Reduction
3. Special Functions
4. Adjust
– 5 – – 6–
5. Specications
Product
Model CAM-AHD325 CAM-AHD425
Camera
Sensor SONY 1/2.8” 2MP CMOS
Effective Picture
Elements 1920(H) x 1080(V) @ 30fps
Lens Furnished Board Lens 3.6mm/F1.2
Minimum
Illumination
0.01 lux @ F1.2 (AGC ON), 0 lux
with built-in IR LED
LED
IR LED
36 units of
850nm High
Power IR LED
24 units of
850nm High
Power IR LED
IR Project Distance 30 meters 20 meters
Video & Audio
S/N Ratio More than 58 dB
White Balance Automatically (1800K ~ 10500K)
Gamma
Characteristic 0.45
Gain Control Automatically
Auto Electronic
Shutter 1/50(1/60)s~1/100,000s
Noise Reduction 2D/3D
Synchronous
System Internal
Transmission
Distance
Coaxial transmission common 75-3
cable up to 300-500 meters
Environment
Operating
Temperature -20 to 50 degrees C
Video Output 1 Vp-p Composite Video/75 ohms
Power Supply 12V DC, 1A
Water Resistance IP66 IP65
Dimensions
(W x D x H)
83 x 192 x 77
mm
98 x 110 x 77
mm
Further Information
If you have any other question, please contact the dealer
where you purchased this product or you can contact
PLANET directly at the following email address: support_
ica@planet.com.tw
– 5 – – 6–
5. Specications
Product
Model CAM-AHD325 CAM-AHD425
Camera
Sensor SONY 1/2.8” 2MP CMOS
Effective Picture
Elements 1920(H) x 1080(V) @ 30fps
Lens Furnished Board Lens 3.6mm/F1.2
Minimum
Illumination
0.01 lux @ F1.2 (AGC ON), 0 lux
with built-in IR LED
LED
IR LED
36 units of
850nm High
Power IR LED
24 units of
850nm High
Power IR LED
IR Project Distance 30 meters 20 meters
Video & Audio
S/N Ratio More than 58 dB
White Balance Automatically (1800K ~ 10500K)
Gamma
Characteristic 0.45
Gain Control Automatically
Auto Electronic
Shutter 1/50(1/60)s~1/100,000s
Noise Reduction 2D/3D
Synchronous
System Internal
Transmission
Distance
Coaxial transmission common 75-3
cable up to 300-500 meters
Environment
Operating
Temperature -20 to 50 degrees C
Video Output 1 Vp-p Composite Video/75 ohms
Power Supply 12V DC, 1A
Water Resistance IP66 IP65
Dimensions
(W x D x H)
83 x 192 x 77
mm
98 x 110 x 77
mm
Further Information
If you have any other question, please contact the dealer
where you purchased this product or you can contact
PLANET directly at the following email address: support_
– 5 – – 6–
5. Specications
Product
Model CAM-AHD325 CAM-AHD425
Camera
Sensor SONY 1/2.8” 2MP CMOS
Effective Picture
Elements 1920(H) x 1080(V) @ 30fps
Lens Furnished Board Lens 3.6mm/F1.2
Minimum
Illumination
0.01 lux @ F1.2 (AGC ON), 0 lux
with built-in IR LED
LED
IR LED
36 units of
850nm High
Power IR LED
24 units of
850nm High
Power IR LED
IR Project Distance 30 meters 20 meters
Video & Audio
S/N Ratio More than 58 dB
White Balance Automatically (1800K ~ 10500K)
Gamma
Characteristic 0.45
Gain Control Automatically
Auto Electronic
Shutter 1/50(1/60)s~1/100,000s
Noise Reduction 2D/3D
Synchronous
System Internal
Transmission
Distance
Coaxial transmission common 75-3
cable up to 300-500 meters
Environment
Operating
Temperature -20 to 50 degrees C
Video Output 1 Vp-p Composite Video/75 ohms
Power Supply 12V DC, 1A
Water Resistance IP66 IP65
Dimensions
(W x D x H)
83 x 192 x 77
mm
98 x 110 x 77
mm
Further Information
If you have any other question, please contact the dealer
where you purchased this product or you can contact
PLANET directly at the following email address: support_
ica@planet.com.tw
