1. Packet Contents
VERIFY THE CONTENTS INSIDE THE PACKAGE BOX
The package should contain the items plus CAM-AHD325/
CAM-AHD425. If any item is missing or damaged, please
contact the seller immediately.
Quick installation guide x 1 Hex wrench x 1
(CAM-AHD325 only)
CAM-AHD325 CAM-AHD425
Screw packet for each model x 1
2. Physical Introduction
CAM-AHD425 CAM-AHD325
IR LED IR LED Sunshield
Power Input
Video Output
OSD Control Button
Connector Description
Power Input Connect to a 12V DC power adapter.
Video Output BNC connector for analog video output.
OSD Control
Button Description
H AHD Mode
T TVI Mode
C CVI Mode
A CVBS Mode
Press &
Direction Control OSD Configuration
3. Hardware Installation
1. Place the camera in a suitable location and attach with
screws.
2. Adjust the camera to the correct direction.
3. Connect a 12V DC power adapter to the power input
connector.
4. Connect to the DVR and select your channel. Next, select
required mode via the OSD control button and hold the
button for about 5 seconds to take effect. After that, the
image of camera will be shown on the channel.
5. Press the OSD control button to enter the main menu of
OSD function for conguration.
Note
Before connecting the power adapter to the
camera, please make sure the power output
voltage is 12V DC (max. ±5%). If you are not
sure of this part, we suggest you use a 12V
DC switching power adapter. It can provide
stable power output.
3.1 OSD Function
3.2 Setting Steps
1. Exposure
2. White Balance
3. Day & Night
4. Adjustment

– 5 – – 6–
4. Specications
Product
Model CAM-AHD325 CAM-AHD425
Camera
Sensor SONY 1/2.8” 2MP CMOS
Effective Picture
Elements 1920(H) x 1080(V) @ 30fps
Lens Furnished Fixed Lens 3.6mm/F1.2
Minimum
Illumination
0.01 lux @ F1.2, 0 lux with built-in
IR LED
LED
IR LED 36pcs Φ5 LED 24pcs Φ5 LED
IR Project Distance 30 meters 25 meters
Video & Audio
Hybrid Signal Output AHD/TVI/CVI/CVBS mode
S/N Ratio More than 52 dB
Day & Night Auto/Color/B/W/EXT
D-WDR ON/OFF
White Balance ATW/MWB
Gamma
Characteristics 0.45
Exposure Mode Globe/Center/BLC/FLC
Shutter Speed 1/25s~1/45,000s
Digital Noise
Reduction 2D DNR
Defog Auto/ON/OFF
AGC Auto/Manual
Transmission
Distance
Coaxial transmission over common
75-3 cable up to 300-500 meters
Environment
Cold Boot
Temperature -20 to 50 degrees C
Operating
Temperature -30 to 50 degrees C
Humidity ≤85%RH
Power Supply 12V DC, 1A
Water Resistance IP66 IP66
Dimensions
(W x D x H)
83 x 192 x 77
mm
67 x 160 x 66
mm
Further Information
If you have any other question, please contact the dealer
where you purchased this product or you can contact
PLANET directly at the following email address: support_
[email protected]
