Planet KVM-210 Series User manual

8-/16-port Combo KVM Switch
IKVM/KVM-210 Series
- 1-
8-/16-port Combo KVM
8-/16-port Combo IP KVM
IKVM/KVM-210 Series

8-/16-port Combo KVM Switch
IKVM/KVM-210 Series
- 2-
Copyright
Copyright 2017 by PLANET Technology Corp. All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or
computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical,
manual or otherwise, without the prior written permission of PLANET.
PLANET makes no representations or warranties, either expressed or implied, with respect to the
contents hereof and specifically disclaims any warranties, merchantability or fitness for any particular
purpose. Any software described in this manual is sold or licensed "as is". Should the programs prove
defective following their purchase, the buyer (and not PLANET, its distributor, or its dealer) assumes the
entire cost of all necessary servicing, repair, and any incidental or consequential damages resulting
from any defect in the software. Further, PLANET reserves the right to revise this publication and to
make changes from time to time in the contents hereof without obligation to notify any person of such
revision or changes.
All brand and product names mentioned in this manual are trademarks and/or registered trademarks of
their respective holders.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio technician for help.
FCC Caution
To assure continued compliance, use only shielded interface cables when connecting to computer or
peripheral devices. Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

8-/16-port Combo KVM Switch
IKVM/KVM-210 Series
- 3-
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Federal Communication Commission (FCC) Radiation Exposure Statement
This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In
order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to
the antenna shall not be less than 20 cm (8 inches) during normal operation.
Safety
This equipment is designed with the utmost care for the safety of those who install and use it. However,
special attention must be paid to the dangers of electric shock and static electricity when working with
electrical equipment. All guidelines of this and of the computer manufacture must therefore be allowed
at all times to ensure the safe use of the equipment.
CE Mark Warning
This is a Class B product. In a domestic environment, this product may cause radio interference, in
which case the user may be required to take adequate measures.
WEEE Regulation
To avoid the potential effects on the environment and human health as a result of the
presence of hazardous substances in electrical and electronic equipment, end users of
electrical and electronic equipment should understand the meaning of the crossed-out
wheeled bin symbol. Do not dispose of WEEE as unsorted municipal waste and have to collect such
WEEE separately.
Revision
User’s Manual of PLANET 8-/16-port Combo KVM
Model: KVM-210-08 / KVM-210-16 / IKVM-210-08 / IKVM-210-16
Rev: 1.00 (January, 2017)
Part No. EM-KVM_IKVM-210 Series_v1.0.doc

8-/16-port Combo KVM Switch
IKVM/KVM-210 Series
- 4-
Table of Contents
Chapter 1. Product Introduction.......................................................................................................5
1.1 Package Contents....................................................................................................................5
1.2 Overview ..................................................................................................................................6
1.3 Features...................................................................................................................................9
1.4 Specifications .........................................................................................................................10
Chapter 2. Hardware Interface ........................................................................................................12
2.1 Physical Descriptions.............................................................................................................12
2.2 Hardware Installation .............................................................................................................14
Chapter 3. Operations......................................................................................................................17
3.1 Manual Key............................................................................................................................17
3.2 Switch Hotkey ........................................................................................................................17
3.3 OSD (On Screen Display)......................................................................................................18
3.3.1 GOTO ..................................................................................................................19
3.3.2 SCAN...................................................................................................................19
3.3.3 LIST .....................................................................................................................20
3.3.4 QV (Quick View) ..................................................................................................21
3.3.5 EDIT.....................................................................................................................21
3.3.6 SET......................................................................................................................22
Chapter 4. IPKVM Software (For IKVM Series) ..............................................................................24
4.1 System Requirements............................................................................................................24
4.2 IPKVM Software Installation...................................................................................................24
Chapter 5. Web-based Management (For IKVM Series) ...............................................................27
5.1 Mouse settings.......................................................................................................................27
5.2 Network connection................................................................................................................31
5.3 Web Managenent...................................................................................................................32
5.3.1 Console................................................................................................................32
5.3.2 User .....................................................................................................................34
5.3.3 Log.......................................................................................................................35
5.3.4 Network................................................................................................................35
5.3.5 System.................................................................................................................37
Appendix A: Frequently Asked Questions........................................................................................38

8-/16-port Combo KVM Switch
IKVM/KVM-210 Series
- 5-
Chapter 1. Product Introduction
1.1 Package Contents
The package should contain the following:
Combo KVM Switch x 1
Quick Guide x 1
IP installation Guide x 1 (For IKVM Series)
KVM Cable x 1
Rack-mounting Kit x 1
Power Adapter x 1
If any of the above items are missing, please contact your seller immediately.

8-/16-port Combo KVM Switch
IKVM/KVM-210 Series
- 6-
1.2 Overview
Easily Control Servers with Flexibility
PLANET offers an ideal enterprise 8-/16-port KVM switch solution for company server room or testing
facilities. The KVM-210-08/16 features the patented design of the availability of USB and PS/2 interface
connection, user-friendly OSD utility and daisy-chain function. The KVM switch solution frees up more
table and rack space for users in addition to saving the cost of multiple keyboards, mice and monitors.
Remotely Access your Servers from Anywhere (For IKVM Series)
PLANET offers an ideal enterprise 8-/16-port KVM switch solution for company server room or testing
facilities. With the innovative IP-based technology, PLANET has turned the traditional KVM switches
into true networking devices. The IKVM-210-08/16 captures, digitizes and compresses video signal,
and then transmits it with keyboard and mouse signals through IP network. Multiple remote sites can
monitor the same PC server simultaneously.

8-/16-port Combo KVM Switch
IKVM/KVM-210 Series
- 7-
Remote Key Combination (For IKVM Series)
You could set the multiple key combinations at IKVM Series. When you open IKVM software at remote
client, you could use these key combinations to control these local PCs with a different OS via the
internet.
Computer Switching
There are three convenient methods to access any computer connected to the installation:
Port select button
Hotkeys on keyboard
OSD (on screen display) at local client and remote client
Perceptive LED Display
You could check the computer status on the front LED of the IKVM/KVM-210 Series. "Red" indicates
that a computer is connected to the corresponding port and "Green" indicates that the computer
connected to the corresponding port has focus.

8-/16-port Combo KVM Switch
IKVM/KVM-210 Series
- 8-
Security Protection
Two level password security only authorizes up to one user and an administrator with a separate profile
for each user.
Powerful Mouse/Keyboard Support
In the present computer applications, a mouse has become an indispensable device. The
IKVM/KVM-210 Series fully supports all models of PS/2 mice on the market. The KVM also supports
the PS/2 keyboard port of code set 1/2/3 and further allows you to use the KVM for all kinds of servers,
computers or their combination.

8-/16-port Combo KVM Switch
IKVM/KVM-210 Series
- 9-
1.3 Features
Hardware
■1U rack-mount size and desktop design
■Standalone machine controls up to 8 sets of computers
■Up to 2 levels can be cascaded and up to 64 computers can be controlled
■Front panel status LEDs give a clear indication of the active computers
Security
■Two-layer password security protection
■DES, AES and 3DES for data encryption (For IKVM Series)
Management
■Auto scan mode for monitoring computers
■Requires no additional software or hardware
■Computer selection via Port Select Button, Hotkey and On Screen Display (OSD)
■Hot pluggable: Add or remove computers without having to power down the switch
■QVS (Quick View Setting): Quickly select your computer by naming or SN number
Remote Access (For IKVM Series)
■Remotely control PC via TCP/IP and a built-in 10/100/1000Mbps Ethernet port
■High Video Quality: Resolution up to 2048 x 1536 (local side) or 1920 x 1080 (remote side)
■Sends the key combinations to a remote computer
■Administrator and multiple users with password protection
■Use of the absolute synchronistical technology of mouse to ensure the accuracy of the
Windows operating system
■Expedient bandwidth control
Compatibility
■Multiplatform support -- Windows, Linux and Sun
■Multibrowser support (IE, Chrome, Firefox) (For IKVM Series)
■Supports Microsoft Intellimouse, Logitech Net Mouse and other third-party’s PS/2 mice

8-/16-port Combo KVM Switch
IKVM/KVM-210 Series
- 10 -
1.4 Specifications
KVM-210 Series Specifications
Product KVM-210-08 KVM-210-16
Hardware
Number of Ports 8 D-sub ports (15-pin) 16 D-sub ports (15-pin)
Maximum 64 by 2-tier star-type cascading
(KVM-210-08 x 8)
256 by 2-tier star-type cascading
(KVM-210-16 x 16)
PC Ports
Keyboard PS/2 female + USB Type A female
Mouse PS/2 female + USB Type A female
Video 8 D-sub ports (15 female) 16 D-sub ports (15 female)
Console Ports
Keyboard PS/2 female + USB Type A female
Mouse PS/2 female + USB Type A female
Video 1 D-sub port (15 female)
LED On Line 8 (Red) 16 (Red)
Selected 8 (Green) 16 (Green)
Button 1 reset button
8 select button
1 reset button
16 select button
Video Resolution 2048 x 1536
Housing Metal
Dimensions (W x D x H) 432 x 155 x 44 mm
Weight 2.22kg
Power Requirement 9V DC, 1A
Installation 1U rack-mountable, desktop
Management
PC Selection
Port select button
Hotkeys on keyboard
OSD (on screen display)
Scan Interval 5~60 seconds
Security User password andsuper password
Environment & Certification
Operating Temperature -10 ~ 50 degrees C
Operating Humidity 0 ~ 90%
Regulatory CE, FCC

8-/16-port Combo KVM Switch
IKVM/KVM-210 Series
- 11 -
IKVM-210 Series Specifications
Product
IKVM-210-08
IKVM-210-16
Hardware
Number of Ports
8 D-sub ports (15-pin)
16 D-sub ports (15-pin)
Maximum Control of PCs
64 by 2-tier star-type cascading
(KVM-210-08 x 8)
256 by 2-tier star-type cascading
(KVM-210-16 x 16)
PC Ports
Keyboard
PS/2 female + USB type A female
Mouse
PS/2 female + USB type A female
Video
8 D-sub ports (15 female)
16 D-sub ports (15 female)
Console Ports
Keyboard
PS/2 female + USB type A female
Mouse
PS/2 female + USB type A female
Video
1 D-sub port (15 female)
LED
On Line
8 (Red)
16 (Red)
Selected
8 (Green)
16 (Green)
Button
1 reset button
8 select buttons
1 reset button
16 select buttons
Remote Console
1 RJ45 port for 10/100/1000BASE-T
Video Resolution
Local side: 2048 x 1536 (max)
Remote side: 1920 x 1080 (max)
Housing
Metal
Dimensions (W x D x H)
432 x 155 x 44 mm
Weight
2.22kg
Power Requirement
9V DC, 1A
Installation
1U rack-mountable, desktop
Management
Supported Protocol
TCP, IP, HTTP
Client Software
IPKVM Software
PC Selection
Port select button
Hotkeys on keyboard
OSD (on screen display)
Scan Interval
5~60 seconds
Security
User password and super password
DES, AES and 3DES
Environment & Certification
Operating Temperature
-10 ~ 50 degrees C
Storage Temperature
-20 ~ 60 degrees C
Operating Humidity
0 ~ 90%
Regulatory
CE, FCC

8-/16-port Combo KVM Switch
IKVM/KVM-210 Series
- 12 -
Chapter 2. Hardware Interface
2.1 Physical Descriptions
IKVM/KVM-210 Series Front Panel
LED and button definitions
LED Color Function
On Line Red Lightsto indicate that the PC is operating.
Select Green Press this button to select a PC port.
Button Function
Reset This button is hidden in the pinhole. Please hold the reset button for about 5 seconds to
load default.
KVM-210 Series Rear Panels
IKVM-210 Series Rear Panels

8-/16-port Combo KVM Switch
IKVM/KVM-210 Series
- 13 -
Interface Description
Power Jack
The input power is 9V DC.
Use the power adapter included in the package; otherwise, it may
damage the unit and result in danger.
USB Port Plug USB keyboard and mouse in this port.
Computer Port Install the KVM cable connected to a PC here.
Console Ports In the Master KVM, connect the monitor, keyboard and mouse here.
In the Slave KVM, connect the cable from the Master computer port here.
IP Module
Interface Description
LAN Port One 10/100/1000BASE-T RJ45 auto-MDI/MDI-X port.
Reboot Press and release to restart the system.
Reset Press for 5 seconds to reset to default.

8-/16-port Combo KVM Switch
IKVM/KVM-210 Series
- 14 -
2.2 Hardware Installation
The Switch KVM provides a standard 19-inch rack for the installation of devices. Please use the rack
installation accessories attached with the product package. First install the accessories to the device
and then the device to the rack.
Step 1. Place your KVM Switch on a hard flat surface, with the front panel positioned towards your front
side.
Step 2. Attach a rack-mount bracket to each side of the KVM Switch with supplied screws attached to
the package.
1) You must use the screws supplied with the mounting brackets. Damage caused to the
parts by using incorrect screws would invalidate your warranty.
2) Please make sure computer and switch KVM are turned off.
Step 3. Secure the brackets tightly.
Step 4. Follow the same steps to attach the second bracket to the opposite side.
Step 5. After the brackets are attached to the Web Smart Switch, use suitable screws to securely
attach the brackets to the rack.

8-/16-port Combo KVM Switch
IKVM/KVM-210 Series
- 15 -
Step 6. Connect the monitor to the KVM Switch. Using the attached cable, or the one included with
your monitor, connect it to the HDB-15 female port on the back of the KVM unit labeled with the monitor
symbol at the CONSOLE port connector.
Step 7. Connect the keyboard to the KVM Switch, via PS/2 or USB interface.

8-/16-port Combo KVM Switch
IKVM/KVM-210 Series
- 16 -
The console section does not support hot plugging of PS/2 mouse and keyboard.
Step 8. Connect the mouse to the KVM Switch, via PS/2 or USB interface.
The console section does not support hot plugging of PS/2 mouse and keyboard.
Step 9. Install the Master KVM to the 3-in-1 cable (same as the cable for connecting the KVM to the PC)
in the middle of the Slave KVMs.
Step 10. Double-check all of the connections. You can check the color of keyboard and mouse
connector to make sure the keyboard and mouse cables go to the correct ports.
Step 11. Attach the power supply to the KVM unit and plug the other end into an electrical receptacle.
Now you will see the LED for Port 1 light up. Switch on your monitor.
It is not necessary to power down the whole system for installing a new PC or KVM
thereafter. All you need is to make sure that the new PC or KVM is OFF during the
installation. If the KVM powers down due to external Factors (such as power failure or
the power of the KVM is turned off), we recommend you to reinstall the whole system.

8-/16-port Combo KVM Switch
IKVM/KVM-210 Series
- 17 -
Chapter 3. Operations
There are three ways to switch PC. Please see the operation instructions below for more
understanding.
3.1 Manual Key
You just need to press the Port Select Button on the front panel of the KVM. The Selection LED
(Green)is on, indicating that you are switching to the corresponding port.
3.2 Switch Hotkey
You can use the numeric keys to enter the direct switch. For example, if you want to switch to PC port 2,
you could press Ctrl + Ctrl + 2 and switch to PC port 2.
Scroll + Scroll + Num (Default setting)
Ctrl + Ctrl + Num
Alt + Alt + Num
Shift + Shift + Num

8-/16-port Combo KVM Switch
IKVM/KVM-210 Series
- 18 -
3.3 OSD (On Screen Display)
Press the Ctrl on the keyboard twice to start the OSD. Use the key Up, Down and Enter keys on the
keyboard to switch or directly move the mouse to the target PC, and then double-click the left button.
Ctrl + Ctrl (Default setting)
Scroll + Scroll
Alt + Alt
Shift + Shift
Parameters Description
PN
This column lists the port numbers for all the CPU ports on the
installation. The simplest method to access a particular computer is
to move the highlight bar to it, and then press [Enter].
QV If a port has been selected for Quick View scanning, an arrowhead
symbol would display in this column to indicate so.
PC The computers that are powered on and are on-line have an
arrowhead symbol in this column to indicate so.
NAME If a port has been given a name, its name would appear in this
column.

8-/16-port Combo KVM Switch
IKVM/KVM-210 Series
- 19 -
3.3.1 GOTO
GOTO allows you to switch directly to a port either by keying in the port’s name or its port number.
NAME:Move highlight bar to “NAME”, press [Enter], input name of a port, and then press [Enter] to
confirm.
PN:Move highlight bar to “PN”, press [Enter], input port number, and then press [Enter] to switch. If
the port number is invalid, it will remind the user to input again.
3.3.2 SCAN
The SCAN function can automatically scan from the currently selected port; the scan interval can be set
by users. When scanning, a small window on the screen indicates the current port number. Press
[Space] to stop scanning, and the KVM switches to the port last scanned.

8-/16-port Combo KVM Switch
IKVM/KVM-210 Series
- 20 -
3.3.3 LIST
The LIST function lets you broaden or narrow the scope of which port the OSD displays on the main
screen.
Parameters Description
ALL Lists all of the ports on the installation.
QVIEW Lists only the ports that have been selected as Quick View Ports.
POWERED ON Lists only the ports that have their attached computers powered on.
POWERED ON +
QVIEW
Lists only the ports that have their attached computers powered on
and have been selected as Quick View Ports.
QVIEW + NAME Lists only the ports that have been selected as Quick View Ports and
have name.
NAME Lists only the ports that have names.
