Secure Fit CCD Spacer Installation
CCD Adapter (for STL Camera) CCD Spacer
Secure fit CCD Spacer 3.8" and
2.1" (Spacers for CDK12.5 not
shown)
Secure Fit CCD Spacer Installation rev031108Page 1

CCD Adapter
O
p
tical
p
ath=.25"
CCD Spacer
Lengths
=
2
.
1
"
and
STL Camera
with mounting
block
BF=1.5"
AO-L
Optical
path =
1.49"
NOTE:
Back focus from racked in focuser is 5.81"
Focuser travel =1.0"
Diagram for SBIG's STL Camera Mounting with CDK20
Secure Fit CCD Spacer Installation rev031108Page 2 Secure Fit CCD Spacer Installation rev031108Page 2
Hedrick
CDK 20
Backplate
pp
Lengths
2
.
1
and
3.8"
STL Camera
without
mounting block
BF=1.23"

STL Camera
with mounting
block
BF=1.5"
Diagram for SBIG's STL Camera Mounting with CDK12.5
Secure Fit CCD Spacer Installation rev031108Page 3 Secure Fit CCD Spacer Installation rev031108Page 3
10.455"
CCD Adapter
Optical path=.25"
CCD Spacer
Lengths = 3.5" and
5.25"
2.75"
CDK 12.5
Backplate
Camera with
mounting
block ,
BF=1.5"

Mounting block for
STL camera body
1 - Place STL camera on its
back and expose the STL
mounting block. If the 2"
adapter is attached, remove it.
(See Figure 3).
2 - Take the CCD adapter
shown in Figure 4 and place it
on the camera mounting block
as shown in figure 5. Figure 3
Secure Fit CCD Spacer Installation rev031108Page 4 Secure Fit CCD Spacer Installation rev031108Page 4
CCD adapter for
STL camera
Figure 4 Figure 5

Figure 6
3 - Mount the CCD adapter on
the CCD mounting block using
the 4x 6-32 flat head screws,
shown in figure 6. (the picture
shows socket head screws
which we do not use anymore)
4 - Mount the CCD secure fit
spacer on the CCD adapter.
Use the 4x 10-32 socket head
cap screws to secure the
Secure Fit CCD Spacer Installation rev031108Page 5 Secure Fit CCD Spacer Installation rev031108Page 5
Figure 7
components together, shown in
figure 7.

5 - Prepare the focuser by
removing four bolts from the
end of the focuser flange as
shown in figure 8.
6 - Mount the CCD spacer and
camera to the focuser flange
using the 4x 1/4-20 socket
head cap screws provided for
the CDK
20
or using the
4
x
10
-
Focuser flange
Remove four
screws from the
focuser flange
Secure Fit CCD Spacer Installation rev031108Page 6 Secure Fit CCD Spacer Installation rev031108Page 6
the
CDK
20
or
using
the
4
x
10
24 socket head cap screws
provided for the CDK12.5.
Figure 8
