Planmeca Ethernet Interface User manual

Planmeca Ethernet
Interface
INSTALLATION MANUAL
Publication part number 10007439
Version 6
Published 2005-06
En

PLANMECA OY Asentajankatu 6, 00880 Helsinki, Finland, tel. [phone]
fax [phone], e-mail: [email protected], www.planmeca.com

Table of Contents
TOC 1 Installation manual
1 INTRODUCTION ....................................................................................................................................1
1.1 Symbols ....................................................................................................................................... 1
1.2 Planmeca Ethernet interface kit ................................................................................................... 1
2 INSTALLATION OF THE PLANMECA ETHERNET INTERFACE BOX TO THE DIXI3 DIGITAL INTRA
X-RAY SYSTEM ......................................................................................................................................2
2.1 Overview of the installation .......................................................................................................... 2
2.2 Installing Planmeca Ethernet Interface ........................................................................................ 3
3 INSTALLATION OF THE PLANMECA ETHERNET INTERFACE BOX TO THE PLANMECA PROLINE XC
X-RAY SYSTEM ......................................................................................................................................8
3.1 Overview of the installation .......................................................................................................... 8
3.2 Installing Planmeca Ethernet Interface ........................................................................................ 9
4 RESTORING THE FACTORY DEFAULT SETTINGS ..................................................................................13
5 INDICATOR LIGHTS OF THE PLANMECA ETHERNET INTERFACE BOX ................................................14
6 CLEANING ..........................................................................................................................................15
7 UPGRADING ETHERNET INTERFACE SOFTWARE ................................................................................16
8 TECHNICAL SPECIFICATIONS ............................................................................................................21

Table of Contents
Installation manual TOC 2
Planmeca pursues a policy of continual product development. Although every
effort is made to produce up-to-date product documentation this publication
should not be regarded as an infallible guide to current specifications. We re-
serve the right to make changes without prior notice.
COPYRIGHT PLANMECA 2005-06
PUBLICATION PART NUMBER 10007439 revision 6
The manufacturer, assembler, and importer are responsible for the safety, re-
liability and performance of the unit only if:
- installation, calibration, modification and repairs are carried out by qualified
authorized personnel
- electrical installations are carried out according to the appropriate require-
ments such as IEC364
- equipment is used according to the operating instructions

Planmeca Ethernet interface 1
INTRODUCTION
Installation manual
1 INTRODUCTION
The Planmeca Ethernet Interface is for use with the Planmeca Dixi3 digital intra X-ray system
or with the Planmeca Proline XC X-ray with Dimax3 system and Planmeca Dimaxis Pro and
Dimaxis Classic imaging softwares. This manual describes how to install and use the system.
Please read this manual carefully before installing and using the system. Refer also to the
Planmeca Intra and Planmeca Dixi3 digital intra X-ray unit’s and / or Planmeca Proline XC X-
ray with Dimax3 user’s and installation manual.
NOTE The Planmeca Intra X-ray or Prostyle Intra X-ray and Planmeca Proline XC as
well as Dimaxis software have separate manuals, which should be used in con-
junction with this manual.
NOTE The Planmeca Ethernet Interface must be located outside the patient area.
1.1 Symbols
Type BF equipment (Standard IEC 878).
1.2 Planmeca Ethernet interface kit
- Planmeca Ethernet Interface Box
- Power supply: Mascot type 9920
- RJ45 Cat. 5 UTP cable
- Cross connected Cat. 5 UTP cable
NOTE The Planmeca Ethernet Interface kit does not include any power cable to the
power supply.

INSTALLATION OF THE PLANMECA ETHERNET INTERFACE BOX TO THE DIXI3 DIGITAL INTRA X-RAY SYS-
2 Planmeca Ethernet interface Installation manual
2 INSTALLATION OF THE PLANMECA ETHERNET INTERFACE BOX
TO THE DIXI3 DIGITAL INTRA X-RAY SYSTEM
2.1 Overview of the installation
NOTE You can install either two Planmeca Dixi3 digital intra X-ray systems, two Plan-
meca Proline XC systems, or Planmeca Dixi3 digital intra X-ray system and
Planmeca Proline XC X-ray system to the Ethernet Interface.
et_conn_sync.eps
OK
SET
STATUS
TX/RX
LINK
PLANMECAETHERNET INTERFACE
10/100 Base-T PLANET PORT 2
PWR
PORT 1 13,2VDC IN
max. 1A
PORT1 PORT2
Planmeca Ethernet
Interface
server
Hub / Switch
to Hub / Switch
Cross connected CAT 5 UTP cable
Power Supply:
Mascot type 9920
or
to PC
RJ45
RJ45
CAT 5 UTP RJ45 15m
Intra sync cable
CAT 5 UTP RJ45 15m
PC / Thin client
10/100 Base-T
10/100 Base-T CAT 5 UTP

Planmeca Ethernet interface 3
INSTALLATION OF THE PLANMECA ETHERNET INTERFACE BOX TO THE DIXI3 DIGITAL INTRA X-RAY
Installation manual
2.2 Installing Planmeca Ethernet Interface
To install the Planmeca Ethernet Interface first attach the Ethernet interface box to the power
supply and plug the power supply to the mains. Check that the
OK indicator light on the Plan-
meca Ethernet Interface box comes on (see picture below).
Attach the RJ45 Cat. 5 UTP cable from 10/100 Base-T directly to the hub or the cross-con-
nected Cat. 5 UTP cable to the computer. The
Link light comes on on the Planmeca Ethernet
Interface.
Attach the 15m interconnection cable from Dixi3 either to Port 1 or Port 2 (or to both of them
in case you use two Dixi2 systems). Check also that the
PWR (power) light comes on.
OK indicator light
Power supply
cable
OK
SET
STATUS
TX/RX
LINK
PLANMECA ETHERNET INTERFACE
10/100 Base-T PLANET PORT 2
PWR
PORT 1 13,2VDC IN
max. 1A
et_box2.eps
OK
SET
STATUS
TX/RX
LINK
PLANMECA ETHERNET INTERFACE
10/100 Base-T PLANET PORT 2
PWR
PORT 1 13,2VDC IN
max. 1A
et_box3.eps
Link
PWR
3-metre RJ45 cable

INSTALLATION OF THE PLANMECA ETHERNET INTERFACE BOX TO THE DIXI3 DIGITAL INTRA X-RAY SYS-
4 Planmeca Ethernet interface Installation manual
Installing the Intra sync cable
The sync cable synchronizes the exposure and receiving the image, i.e. detects the start of
the exposure. The sync cable is required when you want to store the exposure parameters
with the image.
It is also required when you want to use the Planmeca Intra control panel in the Dimaxis 4.0
software
Intraoral Exposure window. The exposure parameters can be set in this window if
you are using the Planmeca Intra with updated software 3.0.3. The control panel logic is iden-
tical to that of the Planmeca Intra remote control.
If you are NOT connecting any other equipment to the Ethernet interface, use the Planet
grabber cable with one connector. In this case connect the interconnection cable from Dixi3 to
Port 1.
If you are using the Planet grabber cable with two connectors, note that the connectors are
numbered. If you connected the interconnection cable to port 1connector, you must connect
the 10m/male/female cable to the Planet connector number 1, and if you connected the inter-
connection cable to port 2connector, you must connect the 10m/male/female cable to the
Planet connector number 2.
Connect the 10m/male/female cable between the Planet connector on the generator box and
Planet grabber cable.
Installing the Dimaxis software
Install the Dimaxis Pro or Dimaxis Classic software to your computer in case it is not yet
installed (refer to Dimaxis Pro Installation manual, publication number 10006119, or Dimaxis
Classic Installation manual, publication number 10006182).
Planet grabber cable and
sync cable

Planmeca Ethernet interface 5
INSTALLATION OF THE PLANMECA ETHERNET INTERFACE BOX TO THE DIXI3 DIGITAL INTRA X-RAY
Installation manual
Open then the Internet Explorer, insert the Planmeca Ethernet Interface default IP address
192.168.0.135. Without this default IP Address you can not configurate your Ethernet Inter-
face.
In the appearing Ethernet Interface window select
Configurations on your left-hand side. The
following window enables you to change the factory default IP Address and TCP Port. Con-
sult the local network administrator about the IP address settings you can use. After saving
your configuration return to the Ethernet Interface window to check your configuration.

INSTALLATION OF THE PLANMECA ETHERNET INTERFACE BOX TO THE DIXI3 DIGITAL INTRA X-RAY SYS-
6 Planmeca Ethernet interface Installation manual
Select Programs/Planmeca/Didapi Configuration from your Start menu. From the appearing
window select
Ethernet Interface .
In the
Ethernet Interface window the Dixi Ethernet Interface, the ProMax Ethernet Interface
and the Proline Ethernet Interface can be configured.
Common:
Select the directory where the configuration and calibration files are located by using the
Browse button. This directory is selected automatically when Dimaxis is installed in the
default directory.
Configuring the Dixi Ethernet Interface:
There are two possibilities to perform the configuration:
1) Enter the IP Address, the IP Port and the Dixi Port in the correct fields and click
Apply .
Alternatively you can leave the
IP Address field empty and enter the Network name in the
Network name field. It is not necessary to enter the IP address as well as the network name;
by entering the IP address you will get the network name, and vice versa. All IP addresses do
not necessarily have a network name.
2) Click
Open DixiEthernetConfig.txt and enter the information. By pressing the Refresh
button the performed modifications will be updated in the address fields. Wait until the
download is completed.

Planmeca Ethernet interface 7
INSTALLATION OF THE PLANMECA ETHERNET INTERFACE BOX TO THE DIXI3 DIGITAL INTRA X-RAY
Installation manual
The following window appears. Change your client name, Ethernet Interface IP address, Eth-
ernet Interface port and Dixi2 port number. Confirm your selection by clicking “
save ” on the
File pull-down menu.
If a password has been set, it must include only capital letters. Do not use space or special
characters.
The Planmeca Ethernet Interface is now installed and you can enter the Dimaxis Pro or
Dimaxis Classic program.
NOTE Before installing the device to the network contact your network administrator
if needed.
Client name
Computer name
“Localhost”
Ethernet Interface
IP Address
OR
Network Name
Ethernet Interface
IP Port
Dixi2 Port
PASSWD
Password

INSTALLATION OF THE PLANMECA ETHERNET INTERFACE BOX TO THE PLANMECA PROLINE XC X-RAY
8 Planmeca Ethernet interface Installation manual
3 INSTALLATION OF THE PLANMECA ETHERNET INTERFACE BOX
TO THE PLANMECA PROLINE XC X-RAY SYSTEM
3.1 Overview of the installation
NOTE You can install either two Planmeca Dixi3 digital intra X-ray systems, two Plan-
meca Proline XC systems, or Planmeca Dixi3 digital intra X-ray system and
Planmeca Proline XC X-ray system to the Ethernet Interface.
XC_ethernet_connections_hub.eps
OK
SET
STATUS
TX/RX
LINK
PLANMECA ETHERNET INTERFACE
10/100 Base-T PLANET PORT 2
PWR
PORT 1 13,2VDC IN
max. 1A
PORT1 PORT2
Planmeca Ethernet
Interface
Cross connected CAT 5 UTP cable
to PC to Hub/ Switch
RJ45
RJ45
PC Data cable CAT 5 UTP RJ45
Interconnection cable
server
Hub / Switch
PC / Thin client
Planet grabber
cable Power
Supply:
Mascot
type 9920
10/100 Base-T 10/100 Base-T
CAT 5 UTP

Planmeca Ethernet interface 9
INSTALLATION OF THE PLANMECA ETHERNET INTERFACE BOX TO THE PLANMECA PROLINE XC X-RAY
Installation manual
3.2 Installing Planmeca Ethernet Interface
1. To install the Planmeca Ethernet Interface first attach the Ethernet interface box to the
power supply and plug the power supply to the mains. Check that the
OK indicator light
on the Planmeca Ethernet Interface box comes on (see picture below).
2. Attach the RJ45 Cat. 5 UTP cable from 10/100 Base-T directly to the hub or the cross-
connected Cat. 5 UTP cable to the computer. The
Link light starts to flash on the
Planmeca Ethernet Interface.
3. Connect the Planet grabber cable to the Planer connector and connect the
interconnection cable to the Planet grabber cable.
If you are NOT connecting any other equipment to the PC, use the Planet grabber cable
with one connector. In this case connect the PC data cable to Port 1.
When using the Planet grabber cable with two connectors note, that the connectors of
the Planet grabber cable with two connectors are numbered. If you connect the
interconnection cable to connector number 1, you must connect the PC data cable to the
port 1, and if you connect the interconnection cable to connector number 2, you must
connect the PC data cable to the port 2.
4. Connect the PC data cable from Planmeca Proline XC keyboard processor PCB either to
Port 1or Port 2(or to both of them in case you use two systems). Check also that the
PWR (power) light comes on.
Install the Dimaxis Pro or Dimaxis Classic software to your computer in case it is not yet
installed (refer to Dimaxis Installation manual, publication number 10006119).
Power supply
cable
OK indicator light
RJ45 or
Link
PWR
1
2
4
3
PC data cable
Planet grabber cable and
interconnection cable
Cross-connected
cable

INSTALLATION OF THE PLANMECA ETHERNET INTERFACE BOX TO THE PLANMECA PROLINE XC X-RAY
10 Planmeca Ethernet interface Installation manual
Open then the Internet Explorer, insert the Planmeca Ethernet Interface default IP address
192.168.0.135. Without this default IP Address you can not configurate your Ethernet Inter-
face.
In the appearing Ethernet Interface window select
Configurations on your left-hand side. The
following window enables you to change the factory default IP Address and TCP Port. Con-
sult the local network administrator about the IP address settings you can use (in this exam-
ple 192.168.1.123). After saving your configuration return to the Ethernet Interface window to
check your configuration.

Planmeca Ethernet interface 11
INSTALLATION OF THE PLANMECA ETHERNET INTERFACE BOX TO THE PLANMECA PROLINE XC X-RAY
Installation manual
Select Programs/Planmeca/Didapi Configuration from your Start menu. From the appearing
window select
Ethernet Interface .
In the
Ethernet Interface window the Dixi Ethernet Interface, ProMax Ethernet Interface and
Proline Ethernet interface can be configured.
Common:
Select the directory where the configuration and calibration files are located by using the
Browse button. This directory is selected automatically when Dimaxis is installed in the
default directory.
Configuring the Proline Ethernet Interface:
There are two possibilities to perform the configuration:
1) Enter the IP Address, the IP Port and the Box Port (to which the Proline X-ray is attached)
in the correct fields and click
Apply . Alternatively you can leave the IP Address field empty
and enter the Network name in the
Network name field. It is not necessary to enter the IP
address as well as the network name; by entering the IP address you will get the network
name, and vice versa. All IP addresses do not necessarily have a network name.
2) Click
Open ProlineEthernetConfig.txt and enter the information. By pressing the Refresh
button the performed modifications will be updated in the address fields. Wait until the
download is completed.

INSTALLATION OF THE PLANMECA ETHERNET INTERFACE BOX TO THE PLANMECA PROLINE XC X-RAY
12 Planmeca Ethernet interface Installation manual
The following window appears. Change your client name, Ethernet Interface IP address, Eth-
ernet Interface port and Proline box port number. Confirm your selection by clicking “
save ” on
the
File pull-down menu.
If a password has been set, it must include only capital letters. Do not use space or special
characters.
The Planmeca Ethernet Interface is now installed and you can enter the Dimaxis Pro or
Dimaxis Classic program.
NOTE Before installing the device to the network contact your network administrator
if needed.
Client name
Computer name
“Localhost”
Ethernet Interface
IP Address
OR
Network Name
Ethernet Interface
IP Port
Proline Port
/PASSWD
Password

Planmeca Ethernet interface 13
RESTORING THE FACTORY DEFAULT SETTINGS
Installation manual
4 RESTORING THE FACTORY DEFAULT SETTINGS
In case you want to restore the factory default settings remove the power supply cable, press
and hold the
Set button (1) with a sharp pin and plug in the power supply cable (2) (see pic-
ture below).
OK
SET
STATUS
TX/RX
LINK
PLANMECA ETHERNET INTERFACE
10/100 Base-T PLANET PORT 2
PWR
PORT 1 13,2VDC IN
max. 1A
et_box4.eps
12

INDICATOR LIGHTS OF THE PLANMECA ETHERNET INTERFACE BOX
14 Planmeca Ethernet interface Installation manual
5 INDICATOR LIGHTS OF THE PLANMECA ETHERNET INTERFACE
BOX
Planmeca Ethernet interface box indicator lights
LED PLANMECA ETHERNET INTERFACE BOX
Link Planmeca Ethernet interface box is connected to the hub/switch or to
the computer when the Link light is on.
TX/RX Data is transferred/received when the light is flashing.
OK Planmeca Ethernet interface box is attached to the power supply and
works in normal mode when the OK light is on. The OK light blinks
slowly if the factory settings are selected. The OK
light blinks fast when
a problem has occurred in the system.
Status Exposure is being taken with the X-ray system when the Status light is
on.
PWR Planmeca Ethernet interface box is connected to Dixi / Planmeca Pro-
line XC when the PWR light comes on.
OK
SET
STATUS
TX/RX
LINK
PLANMECA ETHERNET INTERFACE
10/100 Base-T PLANET PORT 2
PWR
PORT 1 13,2VDC IN
max. 1A
et_box3.eps

Planmeca Ethernet interface 15
CLEANING
Installation manual
6CLEANING
The Planmeca Ethernet Interface can be cleaned with a soft cloth damped in a mild cleaning
solution.
NOTE Do not disinfect the unit.
CAUTION Switch off the unit before cleaning.

UPGRADING ETHERNET INTERFACE SOFTWARE
16 Planmeca Ethernet interface Installation manual
7 UPGRADING ETHERNET INTERFACE SOFTWARE
Required items:
- The file containing a new software version, for example dixibox1_4_2_0R.sr
- The loader software
- A cross connected Cat. 5 UTP cable to the computer or possibility to use 10.1.0.x IP
addresses in the local network
Upgrading the software
While the Set button is pressed and held with a sharp pin when the Planmeca Ethernet Box is
powered up, Ethernet Box will boot up using the 10.1.0.5 IP address and listen for a new soft-
ware on the network. To be able send data to that IP address on the local network, the Com-
puter IP address must be changed to 10.1.0.x, i.e. the computer must be in the same subnet
as the Ethernet box.
1. To change the computer’s IP address, select
Network Connections from the Control
panel. Then double-click the Local Area Connection. The Local area connection status
window appears. Click Properties.
