Platinum CCTV CD-5260 User manual

Platinum CCTV Surveillance Solutions
CD-5260 Indoor/Outdoor
Day/Night Infrared Bullet Camera
Installation Manual
Outdoor Weatherproof Day/Night Infrared
Camera w/ 420 TVL Sony 1/3” CCD
http://Platinum-CCTV.com

Platinum CCTV Surveillance Solutions
Camera Installation
1. Camera Mounting:
Items Needed:
Screwdriver, Drill, Mounting Hardware (not
included), Pencil
a. Mark wall through Mounting Holes on
bracket
b. Drill Holes for mounting
c. Drill Hole for Cables (if needed)
d. Insert Drywall Anchors (Drywall
Mounting Only *Not Included)
e. Insert Screws holding bracket to wall
f. Attach Camera to bracket and tighten

Platinum CCTV Surveillance Solutions
Camera Installation
g. Connect Cables
Off White = Power Connection (Left)
Yellow = BNC Video Connection (Right)
h. Adjust camera angle to suit needs

Platinum CCTV Surveillance Solutions
CD-5260 IR CCD Bullet Camera
Image Sensor 1/3” Sony ExView CCD
Number of Pixels NTSC: 510 (H) x 492 (V)
Scanning System 15.7343Khz (H), 60 Hz (V)
Sync System Internal Synchronization
Resolution 420 TVL
Lens 3.6mm Wide angle Lens
Video Output 1.0Vp-p75Ω
S/N Ratio >48/dB (AGC off)
IR LEDs 24 pcs IR LEDs
Operation Temp. -10°C ~ +50°C
Storage Temp. -20°C ~ +60°C
Useable
Illumination
0.5 Lux (F:1.2), 0 Lux (IR On)
Power Source DC 12V ± 10%
Installation Notes
•For Indoor or Outdoor Use
•Disassembly of camera is not recommended
•Handle lens carefully with gloves to prevent damage
from oil on your hands
•Handle with care
•Never touch lens directly
•Clean the glass occasionally with a dry micro-fiber
cloth, or plastic cleaner only – Do not use abrasive-
type cleaners as they will scratch glass
