pleasant hearth PH35PS Series User manual

[email protected] 7077-171I • December 08, 2016 1
Questions, problems, missing parts? Before returning to your retailer,
call our customer service department at 877-447-4768 8:30 a.m – 4:30 p.m. CST,
Monday – Friday or email us at [email protected].
Owner’s Manual
Installation and Operation
Models:
PH35PS Series - Medium Pellet Stove with Pedestal
PH50PS Series - Large Pellet Stove with Pedestal and Base Pan
PH50CABPS Series - Cabinet Pellet Stove
High Efciency Pellet Stove
SAFETY NOTICE: PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF
THIS PELLET FUEL-BURNING ROOM HEATER. FAILURE TO FOLLOW THESE INSTRUCTIONS
COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH. CONTACT LOCAL
BUILDING OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIRE-
MENTS IN YOUR AREA.
SAVE THESE INSTRUCTIONS
6440 W. Howard St.
Niles, IL 60714
877-447-4768
This heater meets the U.S. Environmental Protection Agency’s
emission limits for wood heaters sold after July 1, 1990.
PH35PS PH50PS PH50CABPS

7077-171I • December 08, 2016 (877) 447- 47682
Lighting Instructions • December 06, 2016
Lighting Instruction Guide
CAUTION
All material needs to be removed from the door glass and  rebox before operation.
Follow all instructions and warnings for safe startup of stove. Failure to follow instructions could result in
injury or damage.
During startup and normal operation your appliance’s front door must be closed.
Odors and vapors are released during initial startup after purchase. Burning your appliance on HI for 30 minutes will
allow the paint to cure. Open windows or doors for air circulation until burn-off is complete.
3.75
2.81
2
1
4
3
56
7
8
9
10
LO
OFF HI
0
-
1
-
2
-
3
-
4
+
1
+
2
+
3
+
4
O
N
A
U
T
O
A
L
A
R
M
www.pelprostoves.com
Weekly / Hebdomandair / Semanalmente
Comfort Level Mode *
Nivel de confort
Niveau de confort
Priming Fuel
carburant d'amorçage
cebado de combustible
LO / HI **
bajo / alto
lo / salut
Starting
1. Turn dial control to OFF position.
2. Fill hopper with pellets.
3. Turn dial control to desired setting.
Stopping
1. Turn dial control to OFF position.
2. Allow unit to cool before performing any
maintenance.
Départ
1. Tourner le cadran de commande en position OFF.
2. Remplir la trémie avec des granulés.
3. Tourner le cadran de commande au réglage désiré.
Arrêt
1. Tourner le cadran de commande en position OFF.
2
1
4
3
56
7
8
9
10
LO
OFF HI
1.
Turn Dial Control to OFF and ensure appliance is
completely shut down, Figure 2.1.
3.
Openfrontdoorandensureallbafesare
installed properly, Figure 2.2 (also see Clean
the Exhaust Path, Baf es, and Drop Tube in
the General Maintenance section of Owner’s
Manual under Maintaining and Servicing the
Appliance).
*Onceveried,closedoor.*
2.
Ensure appliance is completely cooled and clean
repot(see Cleaning Fire pot in the General
Maintenance section of Owner’s Manual under
Maintaining and Servicing the Appliance).
NOTE: If the appliance fails to ignite, the LED light will
blink red 4 times continuously indicating a missed
ignition alarm; repeat lighting steps 1 through 5.
NOTE: It may take up to 20 minutes for a missed
ignition alarm.
Figure 2.1
Figure 2.2
33
1122
4.
Inspect hopper and ensure there is pellet fuel in
the hopper. If there is fuel in the hopper, close lid
and proceed to step 5, Figure 2.3.
NOTE: If the hopper is completely empty, the
appliance will need to have pellet fuel added to the
hopper and may need to be primed (see Priming
The Feed Tube in the General Operating Infor-
mation section of Owner’s Manual).
5.
Turn dial control to desired setting.
-Green light will start blinking rapidly to indicate
startup sequence.
Push Bottom of Latch
Inward to Release
Figure 2.3

[email protected] 7077-171I • December 08, 2016 3
TABLE OF CONTENTS
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the appliance or to property.
Section 1: Listing and Code Approvals
 A. ApplianceCertication ...............................5
B. Mobile Home Approved .............................5
 C. GlassSpecications...................................5
D. Electrical Rating.........................................5
 E. BTU&EfciencySpecications.................5
Section 2: User Guide: General Information
A. Fire Safety .................................................6
B. Combustible/Non-Combustible
Materials....................................................6
C. Fuel Material & Fuel Storage.....................6
D. Before Your First Fire ................................6
Section 3: User Guide: General Operating Information
A. User Dial Control........................................7
B. Filling the Hopper.......................................7
C. Priming the Feed Tube ..............................8
D. Firepot Purge Cycle ...................................8
E. Shutdown...................................................8
F. Starting Your First Fire...............................9
G. Fire Characteristics....................................9
H. Your Pellet Appliance.................................10
I. LED Color Coding Chart & Explanation.....11
J. Ignition Cycles............................................12
K. Running in Minimum or Maximum .............12
L. Running in the Automatic Mode.................12
M. Clear Space ...............................................12
N. Trim Adjustments.......................................12
Section 4: Maintaining & Servicing Your Appliance
A. Proper Shutdown Procedure......................13
B. Quick Reference Maintenance Chart.........13
C. General Maintenance.................................13
D. High Ash Fuel Content Maintenance..........17
E. Frequently Asked Questions .....................18
Section 5: Replacement Parts
A. Convection Blower Replacement...............19
B. Exhaust Blower Replacement....................19
C. Snap Disc Replacement ............................20
D. Igniter Replacement...................................20
 E. BafeRemoval&Replacement.................20
F. Glass Replacement....................................21
G. Control Board Replacement.......................21
H. Fuse Replacement.....................................21
I. Feed Motor Replacement ..........................21
J. Feed Spring Replacement .........................21
Section 6: Getting Started
A. Design, Installation & Location
Considerations...........................................22
B. Draft...........................................................22
C. Negative Pressure.....................................22
D. Locating Your Appliance & Chimney.........23
E. Inspect Appliance & Components .............23
F. Tools & Supplies Needed..........................23
Section 7: Dimensions and Clearances
A. Appliance Dimension: PH35PS.................24
B. Appliance Dimension: PH50PS.................24
C. Appliance Dimension: PH50CAB ..............25
D. Clearances to Combustibles (UL & ULC)..25
E. Hearth Pad Requirements (UL & ULC) .....26
Section 8: Vent Information
A. Chimney & Exhaust Connection ................27
B. Venting Termination Requirements ...........27
C. Pellet Venting Charts .................................28
Section 9: Venting Systems
A. Vertical- Interior- Typical Installation..........29
B. Through the Wall & Vertical .......................29
C. Vertical into Existing Class A Chimney......29
D. Masonry .....................................................30
E. Alternate Masonry......................................30
F. Through the Wall........................................31
Section 10: Mobile Home.....................................32
Section 11: Appliance Set-Up..............................33
Section 12: Troubleshooting...............................34
Section 13: Reference Materials
A. Component Functions ...............................37
B. Wiring Harness..........................................38
C. Replacement Parts....................................39
D. Service & Maintenance Log.......................40
E. 5 Year Warranty ........................................43
Contact Information ...................................44
French Manual.....................................................45
Spanish Manual...................................................86

7077-171I • December 08, 2016 (877) 447- 47684
CAUTION
After reading these instructions, if you have any doubt
about your ability to complete your installation in a pro-
fessional manner you should obtain the services of an
installer versed in all aspects as to the correct and safe
installation. Do not use temporary makeshift compro-
mises during installation.
BEFORE INSTALLATION OF YOUR APPLIANCE
1.Checkwiththebuildinginspector’sofcefor
compliance with local codes; a permit may be
required.
2. Use 3” or 4” (76-102mm) diameter type “L” or
“PL” venting system. It can be vented vertically or
horizontally. Approved adaptors can be used to
connect the “L” or” PL” to approved wood stove
venting such as single wall or double wall venting
previously used to vent a wood burning appliance.
INSTALL VENT AT CLEARANCES SPECIFIED BY
THE VENT MANUFACTURE.
3. Always connect this unit to an approved chimney
system and NEVER vent to another room or inside
a building.
4. DO NOT INSTALL A FLUE DAMPER IN THE
EXHAUST VENTING SYSTEM OF THIS UNIT.
5. DO NOT CONNECT THIS UNIT TO A CHIMNEY
FLUE SERVING ANOTHER APPLIANCE.
6. The connector pipe and chimney should be
inspected periodically and cleaned if necessary.
Review additional information located in the mainte-
nance section of this Owner’s Manual.
7. Remember the clearance distances when you
place furniture or other objects within the area.
This includes heat sensitive materials such as
candles, seasonal decorations or draperies. DO
NOT STORE WOOD, FLAMMABLE LIQUIDS OR
OTHER COMBUSTIBLE MATERIALS TOO CLOSE
TO THE UNIT.
8. Be aware of the required clearances when locat-
ing the unit. Refer to the label on the rear of the
unit for required clearances.
9.Contactyourlocalmunicipalorprovincialre
authority for information of how to handle a chim-
neyre.Haveaclearunderstoodplantohandlea
chimneyre.Intheeventofachimneyre,CALL
THE FIRE DEPARTMENT.
10.Priortoburningtheunitforthersttimemake
sure the hardware kit has been removed from the
rebox.
IMPORTANT
It is highly recommended that the pellet heater
andchimneybeinstalledbyaqualiedinstaller.A
qualiedinstallerisapersonorentitywhoregularly
installs solid burning fuel products and chimneys in
the course of their ordinary business.
If the information in these
instructions is not followed
exactly, a re may result causing
property damage, personal injury,
or death.
• Donotstoreorusegasolineorotheram-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Donotoverre-Ifheaterorchimneycon-
nectorglows,youareoverring.Overring
will void your warranty.
• Comply with all minimum clearances to
combustiblesasspecied.Failureto
complymaycausehousere.
WARNING
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
replace.
• Alert children and adults to hazards of high
temperatures.
High temperatures may ignite clothing or other
ammable materials.
• Keepclothing,furniture,draperiesandotherammable
materials away.
HOT SURFACES!
Glass and other surfaces are hot
during operation AND cool down.
WARNING
Fire Risk.
Tested and approved for wood
pellets. Burning of any over type
of fuel will void your warranty.
WARNING

[email protected] 7077-171I • December 08, 2016 5
A. Appliance Certication
This appliance is equipped with 5mm ceramic glass.
Replace glass only with 5mm ceramic glass. Please contact
GHP for replacement glass.
C. Mobile Home Approved
NOTE: This installation must conform with local codes.
In the absence of local codes you must comply with the
ASTM E1509-04, ULC S627-00, (UM) 84-HUD,
Series: PH35PS, PH50PS, PH50CABPS
Laboratory: Intertek
Report No. 10072262PRT-001
Type: Solid Fuel Room Heater/Pellet
Fuel Burning Type
Standard: ASTM E1509-04 and ULC S627-
00, Room Heater Pellet Fuel
Burning type and (UM) 84-HUD,
Mobile Home Approved.
• This appliance is approved for mobile home
installations when not installed in a sleeping room and
when an outside combustion air inlet is provided.
• The structural integrity of the mobile home oor,
ceiling, and walls must be maintained.
• The appliance must be properly grounded to the frame
of the mobile home with #8 copper ground wire, and
use only listed double-wall connector pipe.
• Outside Air Kit provided with each unit must be
installed in a mobile home installation.
WARNING! Risk of Fire! GHP disclaims any responsibility
for, and the warranty and agency listing will be voided by the
below actions.
DO NOT:
• Install or operate damaged appliance
• Modify appliance
• Install other than as instructed by the manufacturer.
• Operate the appliance without fully assembling all
components
 • Overre
• Install any component not approved by the
manufacturer
• Install parts or components not Listed or approved
• Disable safety switches
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
Forassistanceoradditionalinformation,consultaqualied
installer, service agency or your dealer.
PH35PS Series: 115 VAC, 60 Hz, Start 2.6 Amps,
Run 0.9 Amps
PH50PS Series: 115 VAC, 60 Hz, Start 2.6 Amps,
Run 0.9 Amps
PH50CABPS Series: 115 VAC, 60 Hz, Start 2.6 Amps,
Run 0.9 Amps
D. Glass Specications
E. Electrical Rating (On High)
The Quadra-Fire Pleasant Hearth Pellet Heater meets the
U.S. Environmental Protection Agency’s emission limits for
pellet heaters sold after May 15, 2015.
This pellet heater needs periodic inspection and repair for
proper operation. It is against federal regulations to operate
this pellet heater in a manner inconsistent with operating
instructions in this manual.
PH35 PH50
PH50CAB
EPACertication#: 907 904
EPACertiedEmissions: 0.3 0.7 grams/hour
*LHVTestedEfciency: N/A N/A %
**HHVTestedEfciency: 83.8 84.4 %
***EPA BTU Output: 9,600
to
25,000
9,300 to
32,400
per hr.
****BTU Input: 12,900
to
34,400
12,500 to
43,900
per hr.
Vent Size: 3 or 4 inches, “L” or “PL”
Hopper Capacity: 40 80/120 lbs.
Fuel Wood Pellets
*WeightedaverageLHVefciencyusingdatacollectedduring
EPA emissions test.
**WeightedaverageHHVefciencyusingdatacollectedduring
EPA emissions test.
***ArangeofBTUoutputsbasedonEPADefaultEfciencyand
the burn rates from the low and high EPA tests.
****Based on the maximum feed rate per hour multiplied by
approximately 8600 BTU’s which is the average BTU’s from a
pound of pellets.
B. BTU & Efciency Specications
1Listing and Code Approvals

7077-171I • December 08, 2016 (877) 447- 476822
A . Design, Installation & Location Considerations
NOTICE: Check building codes prior to installation.
• Installation MUST comply with local, regional, state and
national codes and regulations.
• Consult insurance carrier, local building inspector, re
ofcialsorauthoritieshavingjurisdictionoverrestrictions,
installation inspection and permits.
Since pellet exhaust can contain ash, soot or sparks, you
must consider the location of:
• Windows
• Air Intakes
• Air Conditioner
• Overhang,softs,porchroofs,adjacentwalls
• Landscaping, vegetation
When locating vent and venting termination, vent above
roof line when possible.
NOTICE: Locating the appliance in a location of
considerable air movement can cause intermittent smoke
spillage from appliance. Do not locate appliance near:
• Frequently open doors
• Central heat outlets or returns
B. Draft
Draft is the pressure difference needed to vent appliances
successfully. When an appliance is drafting successfully,
all combustion by products are exiting the home through
the chimney.
Considerations for successful draft include:
• Preventing negative pressure
• Location of appliance and chimney
To measure the draft or negative pressure on your appliance
use a magnehelic or a digital pressure gauge capable of
reading 0 - .25 inches of water column (W.C.).
The appliance should be running on high for at least 15
minutes for the test.
With the stove running on high you should have a negative
pressure equal to or greater than the number given in the
chart.  If you have a lower reading than you nd on the
chart, your stove does not have adequate draft to burn the
fuel properly.
C. Negative Pressure
WARNING! Risk of Asphyxiation! Negative pressure can
cause spillage of combustion fumes and soot.
Negative pressure results from the imbalance of air avail-
able for the appliance to operate properly. It can be stron-
gest in lower levels of the house.
Causes include:
• Exhaust fans (kitchen, bath, etc.)
• Range hoods
• Combustion air requirements for furnaces, water heaters
and other combustion appliances
• Clothes dryers
• Location of return-air vents to furnace or air conditioning
• Imbalances of the HVAC air handling system
• Upper level air leaks such as:
- Recessed lighting
- Attic hatch or open windows
- Duct leaks
To minimize the effects of negative air pressure:
• Install the outside air kit with the intake facing prevailing
winds during the heating season
• Ensure adequate outdoor air for all combustion appliances
and exhaust equipment
• Ensure furnace and air conditioning return vents are not
located in the immediate vicinity of the appliance
• Avoid installing the appliance near doors, walkways or
small isolated spaces
• Recessed lighting should be a “sealed can” design
• Attic hatches weather stripped or sealed
• Attic mounted duct work and air handler joints and seams
taped or sealed
NOTICE: GHP assumes no responsibility for the
improper performance of the chimney system caused by:
• Inadequate draft due to environmental conditions
• Downdrafts
• Tight sealing construction of the structure
• Mechanical exhausting devices
MODEL Minimum Vacuum
Requirements
PH35PS 0.17 inches W.C.
PH50PS 0.17 inches W.C.
PH50CAB 0.17 inches W.C.
B. Draft (Cont’d)
Correct low draft or low vacuum problems by doing one of
the following:
• Thoroughly clean the exhaust path and venting. See
Maintenance Section.
• Inspect for worn or broken gaskets. Repair any gaskets
suspected of leaking, or adjust the trim.
6Getting Started

[email protected] 7077-171I • December 08, 2016 23
Location of the appliance and chimney will affect
performance.
• Install through the warm airspace enclosed by the building
envelope. This helps to produce more draft, especially
duringlightinganddie-downofthere.
• Penetrate the highest part of the roof. This minimizes the
affects of wind loading.
• Locate termination cap away from trees, adjacent
structures, uneven roof lines and other obstructions.
• Minimize the use of chimney offsets.
• Considertheappliancelocationrelativetooorandceiling
and attic joists.
• Take into consideration the termination requirements.
D. Locating Your Appliance & Chimney
Marginal Location:
• Below peak
Location NOT recommended:
• Not the highest point of the roof
• Wind loading possible
Multi-level Roofs
Windward
Leeward
Recommended:
Outside Air Intake
on windward side
NOT recommended:
Outside Air Intake
on leeward side
Recommended Location:
• Above peak
Recommended:
• Insulated exterior chase
in cooler climates
Recommended Location:
• Above peak
• Inside heated space
Location NOT recommended:
• Too close to tree
• Below adjacent structure
• Lower roof line
• Avoid outside wall
Marginal Location:
• Wind loading possible
E. Inspect Appliance & Components
• Remove appliance and components from packaging
and inspect for damage.
• Report to your dealer any parts damaged in shipment.
• Read all the instructions before starting the instal-
lation. Follow these instructions carefully during
the installation to ensure maximum safety and
benet.
Reciprocating Saw
Channel Locks
Hammer
Phillips Screwdriver
Tape Measure
Plumb Line
Level
Framing Material
Non-combustible Sealant
Material
Gloves
Safety Glasses
Framing Square
Electric Drill & Bits (1/4”)
1/4” Self-Tapping Screws
May also need:
Vent Support Straps
Venting Paint
Tools and building supplies normally required
for installation, unless installing into an existing
masonry replace:
F. Tools And Supplies Needed
Inspect appliance and components for
damage. Damaged parts may impair safe
operation.
WARNING
• Do NOT install damaged components.
• Do NOT install incomplete components.
• Do NOT install substitute components.
Report damaged parts to dealer.
6Getting Started

7077-171I • December 08, 2016 (877) 447- 476824
A. Appliance Dimensions
3-1/2
[89]
21-3/4 [552]
21-15/16
[558]
MODEL: PH35PS
30
[762]
12
[305]
26-13/16
[681]
4-1/8
[105]
19-7/8 [505]
MODEL: PH50PS
B. Appliance Dimensions
4
[102]
23-3/4 [603]
24-5/16
[617]
34
[864]
13
[330]
30-13/16
[783]
4-1/8
[104]
24-3/8 [620]
7Dimensions and Clearances

[email protected] 7077-171I • December 08, 2016 25
MODEL: PH50CAB
C. Appliance Dimensions
4-1/2
[114]
23-3/4 [603]
23-3/16
[590]
35-1/2
[902]
D. Clearances to Combustibles (UL and ULC)
CAUTION
• DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE
SERVICING ANOTHER APPLIANCE.
• DO NOT CONNECT TO ANY AIR DISTRIBUTION DUCT
OR SYSTEM.
WARNING
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
replace.
• Alert children and adults to hazards of high
temperatures.
High temperatures may ignite clothing or other
ammable materials.
• Keepclothing,furniture,draperiesandotherammable
materials away.
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
9-1/2
[241]
32-5/16
[821]
4-1/16
[103]
22-11/16 [576]
D
D
A B
C
Turn to pages 26, 27 and 28 for side views and more detailed
images of clearances and installation types.
* Follow pipe manufacture listed clearance
Vertical Installations (Interior Flue)
Straight Back Against Wall Inches Millimeters
ABack Wall to Appliance 2 51
BBack Wall to Flue Pipe 3 76
CSide Wall to Appliance 13 330
Corner Installation Inches Millimeters
DWalls to Appliance 3 76
Horizontal Flue Installations
Straight Back Against Wall Inches Millimeters
ABack Wall to Appliance 2 51
BBack Wall to Flue Pipe 3 76
CSide Wall to Appliance 13 330
7Dimensions and Clearances

7077-171I • December 08, 2016 (877) 447- 476826
*E: Exception for Horizontal Installations:
CANADA INSTALLATIONS:Anoncombustibleoorpro-
tectionsextendingbeneaththeuepipeisrequired with
horizontal venting or under the top vent adapter with verti-
cal installation.
USA INSTALLATIONS:Anon-combustibleoorprotection
extendingbeneaththeuepipeisrecommendedwithhori-
zontal venting or under the top vent adapter with vertical
installation.
A non combustible oor protector is required.
E. Hearth Pad Requirements (UL and ULC)
Useanon-combustibleoorprotector,extendingbeneath
appliance and to the front, sides and rear as indicated.
Measure front distance “M” from the surface of the glass
door.
Hearth Pad Requirements Inches
KSides 2
L* Back 2
MFront 6
Hearth Pad Requirements Millimeters
KSides 203
L* Back 51
MFront 152
USA Hearth Pad Requirements
Canada Hearth Pad Requirements
WARNING
If the information in these instruc-
tions is not followed exactly, a
re may result causing property
damage, personal injury, or death.
• Donotstoreorusegasolineorotheram-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Donotoverre-Ifheaterorchimney
connectorglows,youareoverring.Over
ringwillvoidyourwarranty.
• Comply with all minimum clearances to
combustiblesasspecied.Failureto
complymaycausehousere.
Must extend 2 inches (51mm) beyond each
side of pipe (shaded area)
L*
K
M
K
7Dimensions and Clearances

[email protected] 7077-171I • December 08, 2016 27
Do not terminate vent in any enclosed or semi-enclosed
area such as a carport, garage, attic, crawl space, under a
sun deck or porch, narrow walkway or closely fenced area,
or any location that can build up a concentration of fumes
such as a stairwell, covered breezeway, etc.
CAUTION
A. Chimney and Exhaust Connection
1. Chimney & Connector:Use 3 or 4 inch (76-102mm)
diameter type "L" or "PL" venting system. It can be vented
vertically or horizontally.
2. Mobile Home: Approved for all Listed pellet vent. If using
the 3 inch (76mm) vertical Top Vent Adapter Kit or the 3
to 6 inch (76-152mm) Top Vent Offset Adapter, use Listed
doublewallueconnector.AnauthorizedOutsideAirKit
must be used with manufactured home installations.
3. Residential: The 3 inch (76mm) vertical Top Vent Adapter
Kit and the 3 to 6 inch (76-152mm) Top Vent OffsetAdapter
aretestedtouse24gaugesinglewallueconnectoror
ListeddoublewallueconnectortoClassAListedmetal
chimneys, or masonry chimneys meeting International
ConferenceofBuildingOfcials(ICBO)standardsforsolid
fuel appliances.
4. INSTALL VENT AT CLEARANCES SPECIFIED BY THE
VENT MANUFACTURER.
5. Secure exhaust venting system to the appliance with
at least 3 screws or rivets per the pipe manufacturer’s
instructions. Also secure all connector pipe joints with at
least 3 screws through each joint.
6. DO NOT INSTALL A FLUE DAMPER IN THE EXHAUST
VENTING SYSTEM OF THIS UNIT.
7. DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE
SERVING ANOTHER APPLIANCE.
NOTE: All pipe must be welded seam pipe whenever pos-
sible. Seal pipe joints with high temperature silicone (500°F
[260°C] minimum rated only). Do not put silicone inside
of pipe.
B. Venting Termination Requirements
1. Termination must exhaust above air inlet elevation. It is
strongly recommended that at least 60 inches (1.5m)
of vertical pipe be installed when appliance is vented
directly through a wall. This will create a natural draft,
which will help prevent the possibility of smoke or odor
venting into the home during a power outage. It will
also keep exhaust from causing a nuisance or hazard
by exposing people or shrubs to high temperatures. The
safest and preferred venting method is to extend the vent
vertically through the roof.
2. Distance from doors and opening windows, or gravity or
ventilation air inlets into building:
a. Not less than 48 inches (1.2m) below;
b. Not less than 48 inches (1.2m) horizontally from;
c. Not less than 12 inches (305mm) above.
3. Distance from permanently closed windows;
a. Not less than 12 inches (305mm) below; horizontally
from or above.
4. Distance between bottom of termination and grade should
be 12 inches (305mm) minimum. This is conditional
upon plants in the area, and nature of grade surface.
The grade surface must be a non-combustible material
(i.e., rock, dirt). The grade surface must not be lawn.
Distance between bottom of termination and public
walkway should be 7 feet (2.13m) minimum.
5. Distance to combustible materials must be 24 inches
(610mm) minimum. This includes adjacent buildings,
fences, protruding parts of the structure, roof overhang,
plants and shrubs, etc.
6. Termination Cap Location (Home Electrical Service)
• Side-to-side clearance is to be the same as minimum
clearance to vinyl inside corners.
• Clearance of a termination cap below electrical service
shall be the same as minimum clearance to vinyl sof-
ts.
• Clearance of a termination cap above electrical service
will be 12 inches (305mm) minimum.
• Location of the vent termination must not obstruct or
interfere with access to the electrical service.
Vent surfaces get HOT, can cause burns if
touched. Non-combustible shielding or guards
may be required.
WARNING
WARNING
ONLY use connector:
• Within the room, between appliance and ceiling or wall.
Connector shall NOT pass through:
• Attic or roof space
• Closet or similar concealed space
• Floor or ceiling
Maintain minimum clearances to combustibles
Fire Risk.
Follow Chimney Connector Manufacturer’s
Instructions for Proper Installation.
8Vent Information

7077-171I • December 08, 2016 (877) 447- 476828
C. Pellet Venting Charts
Fire Risk.
• Only LISTED venting components may be
used.
• NO OTHER vent components may be used.
Substitute or damaged vent components may
impair safe operation.
WARNING
The maximum horizontal venting allowed with no vertical vent-
ing attached is 48 inches (1219mm) including one 90° elbow
or two 45° elbows. This is our recommended horizontal vent-
ing installation. Addition of any horizontal venting beyond 48
inches (1219mm) requires a minimum 60 inches (1524mm) of
additional vertical vent. Horizontal sections of vent pipe should
have a 1/4 inch (6.35mm) rise per foot.
GHP recommends any installation requiring more than two 90°
elbows, or more than 15 feet (4.5m) of venting to use 4 inch
(102mm) vent.
NOTICE: These are guidelines for successful venting of your pellet appliance. The more vertical rise you can obtain in
your system, the better it will perform. Horizontal vent runs can accumulate ash and will need to be cleaned more often.
Try to keep them as short as possible.
45° elbow is equivalent to 1 foot
of straight pipe
90° elbow is equivalent to 3 feet
of straight pipe
Minimum Vertical Vent for One Elbow
0
5
10
15
20
0 5 10 15 20
Horizontal Run, (ft)
Minimum Vertical Rise
(ft)
Horizontal Run (FT)
Minimum Vertical Vent for One Elbow
Minimum Vertical Vent for Three Elbows
0
5
10
15
20
25
0 2 4 6 8 10 12
Length of Horizontal Sections (ft)
Minimum Vertical Rise
(ft)
Minimum Vertical Vent for Three Elbows
Length of Horizontal Sections (FT)
Minimum Vertical Vent for Two Elbows
0
5
10
15
20
0 5 10 15
Length of Horizontal Sections, (ft)
Minimum Vertical
Rise, (ft)
Minimum Vertical Vent for Two Elbows
Length of Horizontal Sections (FT)
ONE 90° ELBOW
Total
Horizontal
Minimum
Vertical
Vent
Diameter
403
553
663
773
884
994
10 10 4
11 11 4
12 12 4
13 13 4
14 14 4
15 15 4
16 16 4
17 17 4
18 18 4
19 19 4
TWO 90° ELBOWS
Total
Horizontal
Minimum
Vertical
Vent
Diameter
253
363
473
583
693
7 10 4
811 4
9 12 4
10 13 4
11 14 4
12 15 4
13 16 4
14 17 4
15 18 4
THREE 90° ELBOWS
Total
Horizontal
Minimum
Vertical
Vent
Diameter
211 4
3 12 4
4 13 4
5 14 4
6 15 4
7 16 4
8 17 4
9 18 4
10 19 4
11 20 4
8Vent Information

[email protected] 7077-171I • December 08, 2016 29
We strongly recommend a minimum of 60
inches (1.5m) vertical, however above the
eave is preferred.
Both installations are approved for mobile home
installations. Must use 3 or 4 inch (76 to 102mm)
“L” or “PL” Listed pellet venting or Listed double
wall pipe and authorized Outside Air Kit in mobile
homes. Single wall pipe is approved for residential
installations only.
Air Clearance to Pipe:
This appliance was tested with standard 3 inch
(76mm) Listed pellet vent.
Pellet pipe manufacturers Listed reduced clear-
ance pipe may be use for reduce clearance from
3 inch (76mm) air clearance to no less than 1 inch
(25mm) air clearance to combustibles for approved
Listed pellet pipe.
Follow pipe manufactures listed air clearances
to combustibles and installation instructions
for all reduced air clearances installations.
C. Vertical into Existing Class A Chimney
B. Through The Wall & Vertical - External -
Horizontal
A. Vertical - Interior - Typical Installation
PREFERRED METHOD #1 PREFERRED METHOD #2
Firestop
Flashing
Rain Cap
6 in.
(152mm)
Min.
Non-combustible Hearth Pad
10 in. (254mm) Min.
12 in.
(305mm)
Minimum
Clean-out T
Non-combustible Hearth Pad
Clean-out Cover
Tee
Wall Thimble
Support
Bracket
Every 60 in.
(1.5 m)
12 in.
(305mm)
Minimum
Rain Cap
Flashing
2 in. (5.08 mm) Minimum
6 in. (152 mm)
Minimum
Firestop
Flashing
Rain Cap
Non-combustible Hearth Pad
Follow vent manufacturer’s
clearances for reduced clearances
12 in. (305mm) Minimum
Ceiling Support
6 in. (152mm) Flue
Connector
6 in. (152mm) Class A
Chimney Connector
Adapter
6 in.
(152mm)
Min. 10 in. (254mm) Min.
Clean-out T
9Venting Systems

7077-171I • December 08, 2016 (877) 447- 476830
Fire Risk
Inspection of Chimney:
• Masonry chimney must be in good condition.
• Meets minimum standard of NFPA 211
• Factory-built chimney must be minimum 6 inch
(152mm) UL103 HT.
WARNING
E. Alternate Masonry
D. Masonry
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage. Refer
to the owner’s information manual provided with this appli-
ance. For assistance or additional information consult a
qualiedinstaller,serviceagencyoryourdealer.
WARNING
Non-combustible
Hearth Pad
Airtight Clean-out Door
Sheathing
2 in. (5.08mm) Minimum
Flashing
1 in. (25mm) Clearance
1 in. (25mm)
Clearance with Firestop
6 in.
(152mm)
Minimum
Fireclay Flue Liner
with Airspace
Concrete Cap
Non-combustible Hearth Pad
Airtight
Clean-Out Door
Clean-Out
Sheathing
3 in. (76mm) Minimum
1 in. (25mm) Clearance
Flashing
Fireclay flue
Liner with Airspace
Concrete Cap
1 in. (25mm) Clearance
with Firestop
6 in. (152mm)
Minimum
9Venting Systems

[email protected] 7077-171I • December 08, 2016 31
F. Through The Wall
Horizontal termination cap must be a minimum of 6 inches.
(152mm) from the wall. Approved for mobile home instal-
lations. Must use 3 or 4 inch (76-102mm) “L” or “PL” listed
pellet venting or Listed double wall pipe and an authorized
Outside Air Kit in mobile homes.
In Canada, where passage through a wall or parti-
tion of combustible construction is desired, the
installation shall conform to CAN/CSA-B365
NOTICE:
Please note that while the minimum clearance for the
termination cap is 6 inches (152mm) there is the pos-
sibly of soot build-up around the termination area. If this
occurs we suggest to move the termination further away
from the house to prevent it. The suggested minimum is
12 inches.
Straight Out
45 Degree
DO NOT DOWNWARD VENT.
The following will occur:
• The appliance will not vent properly
• Smoke spillage in the house
• Excessive sooting
CAUTION
Wall
Thimble
Illustration shows venting going in both directions.
Choose which one is best for your installation.
3 in. (76mm)
Minimum
3 in.
(76mm)
Minimum
6 in (152mm) Minimum
6 in (152mm)
Minimum
6 in.
(152mm)
Minimum
Non-combustible Hearth Pad
Wall
Thimble
Horizontal
Termination
Cap
10 in.
(254mm)
Minimum
6 in.
(152mm)
Minimum
From Glass
9Venting Systems

7077-171I • December 08, 2016 (877) 447- 476832
1. An outside air inlet must be provided for the combustion
air and must remain clear of leaves, debris, ice and/or
snow. It must be unrestricted while the appliance is
in use to prevent room air starvation which causes
smoke spillage. Smoke spillage can also set off smoke
alarms.
2. The combustion air duct system must be made of
metal. It must permit zero clearance to combustible
construction and prevent material from dropping into
the inlet or into the area beneath the dwelling and
contain a rodent screen.
3. The appliance must be secured to the mobile home
structure by bolting it to the oor (using lag bolts)
with two attachment points. Use the same holes that
secured the appliance to the shipping pallet.
4. The appliance must be grounded with #8 solid copper
grounding wire or equivalent, terminated at each end
with an NEC approved grounding device.
5. RefertoClearances toCombustibles andoorpro-
tection requirements for listings to combustibles and
appropriate chimney systems.
6. Use silicone to create an effective vapor barrier at
the location where the chimney or other component
penetrates to the exterior of the structure.
7. Follow the chimney manufacturer’s instructions when
installing the vent system for use in a mobile home.
8. Installation shall be in accordance with the Manufactur-
ers Home & Safety Standard (HUD) CFR 3280, Part
24.
Installation must comply with Manufactured Home and
Safety Standard (HUD), CFR 3280, Part 24.
WARNING
You must use an authorized Outside Air Kit
for installation in a mobile home.
A. Mobile Home Installation
Spark Arrestor Cap
Roof Flashing
Storm Collar
Joist Shield/Firestop Approved Class “L”
or “PL” Pellet Vent
CAUTION
Never draw outside combustion air from:
• Wall,oororceilingcavity
• Enclosed space such as an attic, garage or
crawl space.
CAUTION
THE STRUCTURAL INTEGRITY OF THE MOBILE HOME
FLOOR, WALL AND CEILING/ROOF MUST BE MAIN-
TAINED
Do NOT cut through:
• Floor joist, wall, studs or ceiling trusses.
• Any supporting material that would affect the structural
integrity.
NEVER INSTALL IN A SLEEPING ROOM.
Consumes oxygen in the room.
WARNING
Asphyxiation Risk.
10Mobile Home

[email protected] 7077-171I • December 08, 2016 33
A. Outside Air Kit Instructions
CAUTION
Never draw outside combustion air from:
• Wall,oororceilingcavity
• “Enclosed space such as an attic, garage or
crawl space.
An outside air kit has been provide standard with the appli-
ance. It is highly recommended to use the outside air kit for
maximum performance and to reduce effects from negative
pressure in the home.
For attachment to this platform, knock out the rectangular
plate in the rear of the unit and slide the tube in the rear of
theunit.Usingthehoseclamp,attachtheexpipetothe2”
tubeweldedtotherearofthereboxasshowninthephoto.
Shock hazard.
• Do NOT remove grounding prong from plug.
• Plug directly into properly grounded 3 prong
receptacle.
• Route cord away from appliance.
• Do NOT route cord under or in front of appli-
ance.
CAUTION
B. Power up the Unit
Plug the unit into 120VAC power.
WARNING
DISCONNECT SUPPLY
BEFORE SERVICING.
11Appliance Set-Up

7077-171I • January 03, 2017 877 - 477 - 476845
Modèles :
PH35PS Série – Poêle à granules sur socle
PH50PS Série – Poêle à granules sur socle et base
PH50CAB Série – Poêle cabinet à granules
PH35PS PH50PS PH50CABPS
Poêle à granules de haute efcacité
Manuel du propriétaire
Installation et réparation
AVIS DE SÉCURITÉ: VEUILLEZ S’IL VOUS PLAÎT LIRE AU COMPLET CE MANUEL AVANT
L’INSTALLATION ET L’UTILISATION DE CET APPAREIL DE CHAUFFAGE À GRANULES. IL FAUT
SUIVRE LES INSTRUCTIONS POUR EMPÊCHER DES DOMMAGES MATÉRIELS, DES BLESSURES
CORPORELLES OU LA MORT. CONTACTEZ LE DIRECTEUR DE LA CONSTRUCTION DE VOTRE
RÉGION POUR VOUS INFORMER AU SUJET DES RESTRICTIONS ET DE L’INSPECTION DE
L’INSTALLATION.
GARDEZ CES INSTRUCTIONS
6440 W. Howard St.
Niles, IL 60714
877-447-4768
Ce système de chauffage respecte les limites
d’émission de l’Agence pour la protection
environnementale concernant les chauffages au bois
vendus après le 1er juillet 1990.
Questions, problèmes, pièces manquantes? Avant de retourner à votre détaillant,
appelez notre service à la clientèle au 877-447-4768 de 8 h 30 - 16 h 30 HNC, du lundi
au vendredi ou envoyez un courriel au [email protected].

7077-171I • January 03, 2017 877 - 477 - 476846
Lighting Instructions • January 03, 2017
Guide d’instructions d’éclairage
PRUDENCE
Tout le matériel doit être enlevé de la vitre de porte et de la chambre de combustion avant l’opération.
Suivez toutes les instructions et avertissements pour un démarrage sûr du poêle. Le non-respect des instruc-
tions peut entraîner des blessures ou des dommages.
Pendant le démarrage et le fonctionnement normal, la porte avant de votre appareil doit être fermée.
Les odeurs et les vapeurs sont libérés lors du démarrage initial après l’achat. Brûler votre appareil sur HI pendant 30
minutespermettraàlapeinturedeguérir.Ouvrezlesfenêtresoulesportespourlacirculationdel’airjusqu’àlandu
brûlage.
3.75
2.81
2
1
4
3
56
7
8
9
10
LO
OFF HI
0
-
1
-
2
-
3
-
4
+
1
+
2
+
3
+
4
O
N
A
U
T
O
A
L
A
R
M
www.pelprostoves.com
Weekly / Hebdomandair / Semanalmente
Comfort Level Mode *
Nivel de confort
Niveau de confort
Priming Fuel
carburant d'amorçage
cebado de combustible
LO / HI **
bajo / alto
lo / salut
Starting
1. Turn dial control to OFF position.
2. Fill hopper with pellets.
3. Turn dial control to desired setting.
Stopping
1. Turn dial control to OFF position.
2. Allow unit to cool before performing any
maintenance.
Départ
1. Tourner le cadran de commande en position OFF.
2. Remplir la trémie avec des granulés.
3. Tourner le cadran de commande au réglage désiré.
Arrêt
1. Tourner le cadran de commande en position OFF.
2
1
4
3
56
7
8
9
10
LO
OFF HI
1.
TournezlacommandedecadransurOFFetvériezquel
‘appareil est complètement arrêté., Figure 2.1.
3.
Ouvrez la porte avant et assurez-vous que tous les
déecteurssontcorrectementinstallés,Figure2.2(voiraussi
Nettoyerlechemind’évacuation,lesdéecteursetletube
d’échappement dans la section Entretien général du manuel
du propriétaire sous Maintenance et entretien de l’appareil).
*Unefoisvérié,fermezlaporte.*
2.
Assurez-vous que l’appareil est complètement refroidi et
nettoyez le poêle à feu (reportez-vous à la section Nettoyage
de la cuve à incendie dans la section Entretien général du
mode d’emploi sous Entretien et entretien de l’appareil).
REMARQUE: Si l’appareil ne s’allume pas, le voyant DEL
clignotera rouge 4 fois en permanence indiquant une
alarme d’allumage manquée; Répéter les étapes 1 à 5.
REMARQUE: L’alarme d’allumage manqué peut prendre
jusqu’à 20 minutes.
Figure 2.1
Figure 2.2
33
1122
4.
Inspectez la trémie et assurez-vous qu’il ya de la graisse dans
la trémie. S’il y a du carburant dans la trémie, fermez le cou-
vercle et passez à l’étape 5, Figure 2.3.
REMARQUE: Si la trémie est complètement vide, il faudra
ajouter de la pelletée à la trémie et l’amorcer (voir Apprêter le
tube d’alimentation dans la section Informations générales du
manuel d’utilisation).
5.
Tournez le sélecteur sur le réglage souhaité.
-Le voyant vert commence à clignoter rapidement pour
indiquer la séquence de démarrage.
Push Bottom of Latch
Inward to Release
Figure 2.3

[email protected] 7077-171I • January 03, 2017 47
1 Référencement et codes
d’approbation
A. Homologation de l’appareil ...............................................45
B. Approuvé pour les maisons mobiles..................................45
C. Caractéristiques de la vitre...............................................45
D. Charge électrique (température élevée)...........................45
E.BTU&Efcacité................................................................45
2 Information générale
A. Sécurité-incendie...............................................................46
B. Matériel Combustible/incombustible .................................46
C. Le combustible et son rangement ...................................46
D. Avant votre premier feu ....................................................46
3 Instructions générales d’exploitation
A. Bouton de réglage .............................................................47
B. Remplissage de la trémie .................................................47
C. Amorçage du tuyau d’alimentation ....................................48
D. La purge du foyer ..............................................................48
E. Éteindre .............................................................................48
F. Votre premier feu................................................................48
G. Le Feu ..............................................................................48
H. Instructions Générales pour votre appareil à granules .....49
I.GraphiqueCouleurLEDdecodicationetexplication.......50
J. Cycle d’allumage ...........................................................51
K. Mode Minimum ou Maximum............................................51
L. Mode de fonctionnement Automatique ...........................51
M. Espacement .....................................................................51
N. Réglage de compensation................................................51
4 L’entretien et la réparation de votre
appareil
A. Arrêt Convenable Procédure .............................................52
B. Guide éclair pour le nettoyage et l’inspection....................52
C. Entretien général ...............................................................52
D. Entretien (grande quantité de cendres).............................56
E. Foire aux questions ..........................................................57
5 Pièces de remplacement
A. Ventilateur à convection remplacement.............................58
B. Remplacement du ventilateur d’extraction.........................58
C. Remplacement de la rondelle à pression ...........................59
D. Remplacement de L’igniteur ...........................................59
E. Enlever et remplacer les chicanes ..................................59
F. Remplacement de la vitre..................................................60
G. Remplacement de la carte électronique............................60
H. Remplacement du fusible ................................................60
I. Remplacement du moteur d’alimentation...........................60
J. Remplacement du ressort d’alimentation..........................60
6 Guide de l’installateur
A. Design, installation et emplacement..................................61
B. Le Tirage............................................................................61
C. Pression négative..............................................................61
D. L’emplacement de l’appareil et de la cheminée.................62
E.Vériezl’appareiletlespièces ..........................................62
F. Outils et fournitures nécessaires.......................................62
7 Dimensions et espacement
A. Dimensions de l’appareil...................................................63
B. Espacement de l’appareil (UL and ULC) ..........................64
C. Exigences pour le protege plancher..................................65
8 Informations sur les évents
A. Raccordement de la cheminée et du conduit de sortie......66
B. Exigences pour le couronnement .....................................66
C. Ventilation pour granules...................................................67
9 Systèmes de ventilation
A. Vertical – Intérieur – Installation Typique ...........................68
C. Verticale dans une cheminée Catégorie A........................68
B. À travers le mur et verticale – Extérieur............................68
D. Maçonnerie.......................................................................69
E. Maçonnerie Autre..............................................................69
F. À travers le mur.................................................................70
10 Maison mobile
A. Installation maison mobile .................................................71
11 Préparation de l’appareil
A. Instructions kit air extérieur ..............................................72
B. Mettre l’appareil en marche .............................................72
12 Dépannage
13 Matériel de référence
A. Les pièces..........................................................................76
B. Schéma de câblage...........................................................77
C. Vue éclatée.......................................................................78
D. Garantie de 5 années........................................................79
Dénition des avertissements de sécurité :
• DANGER! Indique une situation dangereuse qui entraînera la mort ou des blessures graves si elle n’est pas évitée.
• AVERTISSEMENT! Indique une situation dangereuse pouvant entraîner la mort ou des blessures graves si elle n’est
pas évitée.
• ATTENTION! Indique une situation dangereuse pouvant provoquer des blessures mineures ou modérées si elle n’est
pas évitée.
• AVIS : Désigne des pratiques pouvant endommager l’appareil ou d’autres biens matériels.
