Plow & Hearth 53563 Quick reference guide

Item #: 53563 Name: Solar Flower Spinner
USE AND CARE INSTRUCTIONS
Please read these instructions and keep them for future reference
Setup time approximately 20 minutes
© 201 Made in China exclusively for Plow & Hearth, Madison, VA 22727 plowandhearth.com 800-494-7544
7
Step 1:Slide one Spinner(B) onto end of the
T-bar(A), with the solar panel facing out.
Add Tubular Spacer(D) and thread on Nut(E),
Then tighten Nut with Wrench(L). Add Flat
Spacer(F) and Lock Washer (N),thread on Cap
Nut(G),and tighten with Wrench.
Slide second Spinner(C) onto other the end of
the T-bar(A), with the solar panel facing out.
Add Tubular Spacer(D), thread on Nut(E),
tighten with Wrench, add Flat Spacer(F)
and Lock Washer(N),thread on Cap Nut(G),
and tighten with Wrench.
Step 2:To assemble the
pole, slide Double Prong(I)
onto the Ground
Stake(H) and thread
on Extension(J).Align
holes on Extension and
Ground Stake and
install 2 Screws(M).
Next, thread on Spinner
Mount(K) onto Extension(J).
Align holes on Extension and
Spinner Mount and install
2 Screw(M).
Tool required
for pole
assembly:
Phillips Head
Screwdriver
Step 3:Choose appropriate place for your spinner.Push assembled
pole and ground Stake in ground,keeping pole straight.Place
assembled spinner from Step 1 onto Spinner Mount and enjoy.
NOTE: If you are expecting unusually
strong, sustained winds, take down
the spinner head to prevent damage
Before use, remove the solar panel'sprotective clear plastic film.

Page 2
©2017 Made in China exclusively for Plow & Hearth, Madison, VA 22727 plowandhearth.com 800-494-7544
Item #: 53563 Name: Solar Flower Spinner
Place your solar spinner where it will receive the most direct sunlight during the day and where it will not be aected by
arcial lights at night. Ensure that the switch on the back side of each spinner solar panel is in the “ON” poson, and
allow charging for a full day. With a full charge, the non-replaceable LED lights may remain illuminated for up to 6 hours,
depending on environmental condons.
To install your spinner, push the ground stake and extra prongs into the ground, keeping the pole straight. If needed,
son the ground to make it easier to install. Do not over-saturate.
The rechargeable ba may need to be replaced aa year of use. To replace the baery:
1. Remove the spinner blades from the T-bar.
2. Find and remove 3 inset screws on backside of solar panel. See diagram.
Do NOT remove screws holding metal blades to plasc compartment.
A. Remove this screw
B. Do not remove
C. Remove this screw
D. Do not remove
E. Remove this screw
F. Do not remove
3. Remove cover on the front of solar panel. Take out old bary and replace
with a new Ni-MH AAA 300 (or greater) mAh 1.2V rechargeable bay. Be sure to align
polarity markings on the bay with those in bay housing.
4. Replace cover aligning the screw holes with the posts and secure it with
screws.
5. Follow the instruons on page 1 to re-assemble the spinner.
Install only new baes of the same type. Failure to insert baes in the correct polarity may shorten bay life or
cause leakage. Do not dispose of baes in re. Recycle or dispose of baies as per state or local guidelines.
Switch to the “OFF” poson and remove baes when storing for extended periods
of me.
This device complies with Part 15 of the FCC Rules. Operaon is subject to the following two condions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operaon.
Warning: Changes or modions to this unit not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
Notes: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protecon against harmful interference in a residenal installaon. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instrucons,
may cause harmful interference to radio communicaons. However, there is no guarantee that interference will not occur in a
parcular installaon. If this equipment does cause harmful interference to radio or television recepon, which can be determined by
turning the equipment oand on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna. Increase the separaon between the equipment and receiver. Connect the equipment
into an outlet on a circuit dierent from that to which the receiver is connected. Consult the dealer or an experienced radio/TV
technician for help.
