Pluggit Apff User manual

Operating and installation instructions

Manuel d‘utilisation et d‘installation

www.pluggit.com

for / pour Pluggit Avent AP190 / AP310 / AP460

VOCs air quality monitor APRF and humidity sensor APFF

Capteur VOC pour le contrôle de la qualité de l‘air ambiant

APRF et capteur d‘humiditéumidità APFF

The technology makes the difference.

Pluggit's value-added innovations for man and the environment.

Appetite for fresh air? You can get more information on the company,

the intelligent technology of Pluggit comfort ventilation systems,

references and regional contacts at

www.pluggit.com or as an on-line dialogue at www.lueftungsblog.de

The air conduct being installed invisibly in the floor and an ideal

positioning of the air outlets make for perfectly aligned transverse

ventilation. Displacement ventilation means that the fresh air is

supplied to the room almost without causing any draughts and

disturbing noise, without pressure and preheated during the

cold months.

Fresh air and heat supply in one - quicker, more flexible and more

energy saving than common heating systems.

allfloor – in ceilings, walls, above or under concrete and screed -

the Pluggit system design offers maximum flexibility with regard to

the installation of the ventilation ducts and thus is ideal for the use

in new buildings as well as for the refurbishment of

existing buildings.

This innovative technology allows for the supply of exactly the

required or desired amount of fresh air thanks to a highly sensitive

sensor system and control. Cost and time saving, the unit adapts to

the system characteristics at the touch of a button after the

installation and automatically calibrates itself consistently at

regular intervals.

Energy efficiency - a high heat supply rate alone makes a ventilation

system seem effective and energy efficient only at first glance.

The decisive factor for an assessment is rather the ratio of the

energy spent to the attained heat recovery rate - the so-called

electrical energy efficiency. Due to a high tightness, a consumption-

optimised device design and the latest heat exchanger technology,

our ventilation systems attain excellent ratings in terms of heat

recovery and energy efficiency.

The CleanSafe principle guarantees a very low pollution potential of

our distribution system due to smooth surfaces and a trouble-free

cleaning concept, the convincing results of which have been

confirmed by an independent testing institute.

Appetite for fresh air in your building?

The unique comfort ventilation system for the energetic

refurbishment of existing buildings.

allfloor

ServoFlow

CleanSafe

II VOC and humidity sensor for Avent P190/P310/P460

1. General safety information ................................................................................................. 2

2. General notes ...................................................................................................................... 2

2.1. Intended use ........................................................................................................................ 2

2.2. Unintended use .................................................................................................................... 2

2.3. Warranty .............................................................................................................................. 2

3. Installation .......................................................................................................................... 2

4. Technical data ..................................................................................................................... 4

5. Decommisioning/disposal ................................................................................................... 4

5.1. Decommissioning in case of dismantling ........................................................................... 4

5.2. Packaging ............................................................................................................................ 4

5.3. Old appliance ....................................................................................................................... 4

1. Consignes générales de sécurité ........................................................................................ 6

2. Consignes Générales ........................................................................................................... 6

2.1. Utilisation conforme ............................................................................................................ 6

2.2. Utilisation non Conforme .................................................................................................... 6

2.3. Garantie ............................................................................................................................... 6

3. Installation .......................................................................................................................... 6

4. Données techniques ............................................................................................................ 8

5. Mise hors service/élimination ............................................................................................. 8

5.1. Mise hors service lors du démontage ................................................................................. 8

5.2. Conditionnement ................................................................................................................. 8

5.3. Appareil usagé ..................................................................................................................... 8

TABLE OF CONTENTS

SOMMAIRE

2II VOC and humidity sensor for Avent P190/P310/P460

2.1. INTENDED USE

The VOC and humidity sensor continuously monitors the

quality of the exhaust air. The rotational speed of the venti-

lator levels is adjusted according to the measured quality.

The sensors are intended to be installed in the room venti-

lation units Avent P190/P310/P460.

2.2. UNINTENDED USE

Any use of the sensors other than that described in "In-

tended use" shall not be permissible.

2.3. WARRANTY

In order to preserve your full statutory warranty claim, the

technical guidelines in these installation instructions must

be observed. 1. Remove designer cover (1).

2. Unscrew screws (2) and remove front cover (3).

1. GENERAL SAFETY INFORMATION

Warning:

The following safety instructions must be observed,

since damage and injury may otherwise result:

zPlease read these installation instructions care-

fully before starting to install the sensors.

zThe installation and all electrical work must only

be carried out by qualified expert personnel.

zWhen installing and commissioning the sensors,

observe all necessary legal and national re-

quirements (accident prevention regulations and

generally accepted codes of practice) and comply

with them.

zDamages resulting from inappropriate storage

of the product, improper installation or unin-

tended use are excluded from any liability

zTechnical changes reserved.

2. GENERAL NOTES

3. INSTALLATION

Note:

All following descriptions refer to the A version of the

room ventilation unit. The B version of the room ventila-

tion unit is to be installed analogously.

For further information, please refer to the operating

and installation instructions of the room ventilation unit.

Risk of injury:

Before installing the sensors, disconnect all poles

of the room ventilation unit from the power supply

system, since injury may otherwise result.

M+P-26A-0925

II VOC and humidity sensor for Avent P190/P310/P460

English

3. Unscrew the screws (4).

4. Fold the cover (5) upwards in service position.

5. Carefully extract rubber block (6).

6. Place humidity sensor (7) or VOC sensor (8) at a distance

of approx. 50 mm (A) in the rubber block (6).

7. Install rubber block (6) in the room ventilation unit and

lay cable of the sensor or the sensors to the main board.

8. Connect humidity sensor to J23 and VOC sensor to J5 of

the main board (9).

9. Fold down cover (5) and tighten with screws (4).

10. Tighten front cover (3) at the room ventilation unit.

M+P-26A-0890

M+P-26A-0905

M+P-26A-0920

USB

J5 J23 J18 J17 J16

M+P-26A-0921

4II VOC and humidity sensor for Avent P190/P310/P460

11. Start laptop.

12. Plug the USB cable with port type A in the laptop and

port type B in USB interface (10).

13. Start Pluggit iFlow.

14. Open installer section using the password.

The password is available after successful registration.

15. If the room ventilation unit is not automatically detected,

enter serial number and save it, see operating and in-

stallation instructions of the room ventilation unit.

16. Follow the instructions of the Pluggit iFlow activate VOC

and humidity sensor.

IAQ-2000 Technical data

• VCC = 5V +/-0,25V

• Maximum 20mV ripple admissible

• Current consumption: 30-45mA

• Dimensions: 22 x 8mm

• Weight: 10g

• Temperature range: 0-50°C

• Air humidity range: 5-95% relative humidity non-con-

densing

Exhaust air humidity sensor

• VCC = 5V +/-0,25V

• Current consumption: 30-45mA

• Dimensions: 20 x 10mm

• Weight: 12g

• Temperature range: 0-50°C

5.1. DECOMMISSIONING IN CASE OF DISMANTLING

Decommissioning must only be carried out by qualified per-

sonnel.

• Disconnect the unit from power supply.

• Disconnect all poles of the unit from the power supply

system.

5.2. PACKAGING

The transport and protective packaging are usually manu-

factured from reusable materials.

All packaging material must be disposed of according to

local laws and regulations.

5.3. OLD APPLIANCE

The sensors contain valuable materials and substances

which should be kept separate from residual waste.

The old appliance can be delivered to the local recycling

company for recycling.

Note:

The Pluggit iFlow can be downloaded free of charge at

www.pluggit.com and installed on the laptop. For this

purpose, you need to register as user/specialised com-

pany.

M+P-26A-0922

4. TECHNICAL DATA

5. DECOMMISIONING/DISPOSAL

Manuel d’installation du capteur d’humidité et COV pour Avent P190/P310/P460

Français
