Plumbworld PWLPRADC03 User manual

Issue 1 - 25/11/22
PWLPRADC03
PWLPRADC06
PWLPRADC09
Large Radiator Cover
with 3 Drawers

2
Serious or fatal crushing injuries can occur from furniture tipping over.
To help prevent this item of furniture tipping over:
WARNING!
IN ORDER TO PREVENT OVERTURNING THIS PRODUCT MUST BE
USED WITH THE WALL ATTACHMENT DEVICE PROVIDED
An attachment device is provided with your product, however you will need to source suitable
fixings for your wall type. If in doubt, please consult a qualified tradesperson.
Always ensure the wall to be drilled is free from hidden electrical wires, water and gas pipes.
• Use the wall attachment device provided.
• Do not let children climb or hang on drawers, doors or shelves.
• Place the heaviest items in the lower drawers or shelves.
• Do not place TV’s or other heavy objects on top of this product, unless it has been specifically
designed to support them.
• Never open more than one drawer at a time.

Fittings
NOTE: The quantities below are the correct amount to complete the assembly. In some cases
Cam Stud x 35
A
Cam Socket x 35
B
Dowel x 10
C
Drawer Stop x 6
D
50 x 40 x15mm
Wall Block x 3
E
Wall plug with Screw x 8
F
Handle x 3
G
12mm screw x 8
H
35mm screw x 12
I
Felt Strip x 6
J
Wall Strap x 2
K
Washer x 4
L

4
Panels
(150(w)cm x 19(d)cm)
Top panel x1
1
(94.5(h)cm x 18(d)cm)
Left side panel x1
2
(94.5(h)cm x 18(d)cm)
Right side panel x1
3
(18(d)cm x 12(h)cm)
Centre panel x2
4
(145.5(w)cm x 18(d)cm)
Middle panel x1
5
(145.5(w)cm x 75(h)cm)
Face panel x1
6
(46.8(w)cm x 13(h)cm)
Drawer front panel x3
7
(15(d)cm x 10.7(h)cm)
Drawer left side panel x3
8
(15(d)cm x 10.7(h)cm)
Drawer right side panel x3
9
(45.4(w)cm x 14.7(d)cm)
Drawer bottom panel x3
10
(44.4(w)cm x 10.7(h)cm)
Drawer back panel x3
11

5
2
3
1Cam Stud x 10
A
Cam Stud x 35
A
Cam Socket x 35
B
Dowel x 10
C
Drawer Stop x 6
D
50 x 40 x15mm
Wall Block x 3
E
Wall plug with Screw x 8
F
Handle x 3
G
12mm screw x 8
H
35mm screw x 12
I
Felt Strip x 6
J
Wall Strap x 2
K
Washer x 4
L
2Cam Stud x 6
A
Drawer Stop x 6
D
D
1
D
D
D
D
D

6
180°
55
3
4Cam Socket x 4
B
B
Dowel x 2
C
C
Cam Stud x 7
A
4
5
B
B
C
4
B
For how to use
camlocks watch
our video:
www.youtube.com/
watch?v=tBMdYxtpu88

7
5
6
Cam Socket x 3
B
Cam Socket x 10
B
Dowel x 2
C
5
6
3
2
C
C

8
1
7
8
Cam Socket x 6
B
Dowel x 6
C
C
C
C
C
C
B
C
B
B
B
B
B
E
F
F
F
F
wall
28mm
28mm 500mm
928mm
28mm
500mm
50 x 40 x15mm
Wall Block x 3
E
Wall plug with Screw x 6
F

9
9
10 12mm screw x 2
H
Wall Strap x 2
K
Washer x 2
L
H
K
L

10
180°
G
H
H
×3
×3
11
L
F
12 Cam Stud x 12
A
Handle x 3
G
12mm screw x 6
H
7
7
Washer x 2
L
Wall plug with Screw x 2
F

11
×3
×3
B
B
B
B
13 Cam Socket x 12
B
14
9
9
7
8
8
10

12
×3×3
J
J
I
I
I
I
180°
J
11
15
16
35mm screw x 12
I
Felt Strip x 6
J

13
Using camlocks
Step 1 Step 3
Step 2 Step 4
Connect the male
camlock as directed in
the assembly instructions
using a screwdriver.
Push the male camlock
into every hole.
Insert the female
camlock as shown in the
instructions.
Note: Ensure that the
arrow on the top of the
camlock points towards
the entry hole for the
male camlock.
Turn the female camlock
with a screwdriver.
You should feel a click
when the camlock is
locked in place.
The joint is now secure.
For how to use
camlocks watch
our video:
www.youtube.com/
watch?v=tBMdYxtpu88

14
