Pluribus Networks F9532-C User manual

–1–
1. Unpack the Switch and Check Contents
F9532-C or F9532B-C
Rack Mounting Kit—2 front-post brackets, 2 rear-post
brackets, 20 screws, and 2 ear-locking screws
Power Cord (included with AC PSUs only)
Console Cable—RJ-45 to DB-9
Documentation——End-UserLicenseAgreement,Quick
Start Guide (this document) andSafety and Regulatory
Information
Caution: The switch includes plug-in power supply (PSU)
and fan tray modules that are installed into its chassis. All
installed modules must have a matching airow direction.
That is, if the installed power modules have a front-to-back
(F2B) airow direction, all the installed fan tray modules
must also have a F2B airow direction.
Note: The switch drawings in this document are for
illustration only and may not match your particular switch
model.
2. Attach the Brackets
Attach each of the front- and rear-post brackets to the
switch using four of the included bracket screws.
Use an additional two screws to secure each of the rear-post
brackets at the mid-point on the sides of the switch.
Use the screws and cage nuts supplied with the rack to
secure the switch in the rack.
Caution: Installing the switch in a rack requires two
people. One person should position the switch in the rack,
while the other secures it using the rack screws.
装置の吸排気に必要な領域をマニ ュ アル上に規定し て
い る。
3
1
1
2
1
2
3
3. Adjust Rear-Post Bracket Ears
Lock the position of the rear-post bracket ears using the
included position-locking screws.
You can also adjust the rear-post bracket ears to t dierent
rack depths from 56 cm to 75 cm.
4. Connect Power
Connect an external AC power source to the modules.
5. Verify Switch Operation
Verify basic switch operation by checking the system LEDs.
When operating normally, the PSU1/PSU2, Diag, and Fan
LEDs should all be on green.
6. Conguring the switch
To congure your switch please refer to the Pluribus Networks
Quick Start Guide available at this location:
http://www.pluribusnetworks.com/get-started/
1
1
1
1
1
1
19-0019
32-Port 100G Fiber Ethernet Switch
Quick Start Guide
F9532-C | F9532B-C
www.pluribusnetworks.com

– 2 –
Hardware Specifications
Switch Chassis
Size (WxDxH) 438.4 x 515 x 43.5 mm (17.26 x 20.28 x 1.71 inch)
Weight 10.87 kg (23.96 lb), with two installed PSUs
Temperature Operating (F2B): 0° C to 45° C (32° F to 113° F)
Operating (B2F): 0° C to 40° C (32° F to 104° F)
Storage: -40° C to 70° C (-40° F to 158° F)
Humidity Operating: 5% to 95% (non-condensing)
Power
Consumption 550 Watts maximum
AC PSU
Power Rating 100–240 VAC, 50-60 Hz, 650 Watts
AC Input 100–240 VAC, 50-60 Hz, 6 A max.
DC Output 5VSB , 3-4A ; 12V , 54-52.9A
Regulatory Compliances
Emissions EN 55032:2012+AC:2013, Class A
EN 55032:2015+AC:2016, Class A
EN 61000-3-2:2014, Class A
EN 61000-3-3:2013
FCC Class A
VCCI Class A
CE Mark
KC Certification
Immunity EN 55024:2010+A1:2015
IEC 61000-4-2/3/4/5/6/8/11
Safety UL (CSA 22.2 No 60950-1 & UL60950-1)
CB (IEC/EN60950-1)
Quick Start Guide
E052017-AP-R01
150200001740A
