POFUNG BF9500 User manual

BF9500 车载台使用说明书
■
Thank you for choosing this Pofung mobile radios.
POFUNG always provide customers with high performance, high stability of the real radio communications products, this
mobile radios are no exception. In the process of you learn to use this mobile radios can feel the POFUNG friendly design of the
user interface.
Although the user friendly interface design, this mobile radios technically still is very complex, and some function is also new
for you.This manual can be regarded as the designer to provide users with individual tutorial, please follow the manual step by
step to complete the learning process, and retain for future reference.
When programming the mobile radio, read the factory initial date firstly, then rewrite the frequency and signaling
etc.,otherwise errors may occur because of different frequency band etc..
■FEATURES AND FUNCTIONS:
BF-9500 Mobile Radio has nice housing, stoutness & stability, advanced and reliable functions, perfect & valuable. More
functions as follows:
Display on a large LCD with adjustable brightness，convenient information access.
Distribute buttons reasonably, convenient for operation.
Adopt superior quality material, better technology and high quality radiator to ensure stable and durable operation.
200 programmable memorized channels.
Using 5Tone to send Message, Emergency alarm, Call all, ANI, Remotely kill, Remotely Waken, etc.
Programming different CTCSS, DCS, 2Tone, 5Tone in per channel, rejecting extra calling from other radios.
High/medium/low power, can meet the needs of long distance communication, more energy saving province electricity.
Automatic calling identification function by DTMA—ANI or 5Tone—ANI.
Theft alarm provides extra safety.
Compander function for decrease the background noise and enhance audio clarity. (Optional)
Scramble function (Optional)
■Precautions
Please observe the following precautions to prevent other accident damage mobile radio:

BF9500 车载台使用说明书
Do not attempt to configure your mobile radio while driving,it is dangerous.
Use mobile radio, shall comply with the local laws and regulations.
Don't launch with high output power for a long time;This may lead to mobile radio is
Overheating.
Don't try to refit the mobile radio.
Do not expose the transceiver to long periods of direct sunlight nor place it close to
heating appliances.
Do not place the transceiver in excessively dusty, humid or wet areas, nor unstable surfaces.
If an abnormal odor or smoke is detected coming from the transceiver, turn OFF the power immediately. Contact an POFUNG
service station or your dealer.
This transceiver is designed for a 13.8V DC power supply. Don't use a 24V battery to power on the transceiver.
■Supplied Accessories
After carefully unpacking the transceiver, identify the items listed in the table below. We suggest you keep the box and
packaging.

BF9500 车载台使用说明书
■Mobile installation
To install the transceiver, select a safe, convenient location inside your vehicle that minimizes danger to your passengers and
yourself while the vehicle is in motion. Consider installing the unit at an appropriate position so that knees or legs will not strike it
during sudden braking of your vehicle. Try to pick a well ventilated location that is shielded from direct sunlight.
1. Install the mounting bracket in the vehicle using the supplied self-tapping screws(4pcs) and flat washers(4pcs).
2. Position the transceiver, then insert and tighten the supplied hexagon SEMS screws(4pcs) and flat washer(4pcs).
·Double check that all screws are tightened to prevent vehicle vibration from loosening the bracket or transceiver.
·Determine the appropriate angle of the transceiver, using the 3 screw hole positions on the side of the mounting bracket.
■DC Power Cable Connection
1. Mobile Radio Operation
The vehicle battery must have a nominal rating of 12V. Never connect the mobile radio to a 24V battery. Be sure to use a 12V
vehicle battery that has sufficient current capacity. If the current to the mobile radio is insufficient, the display may darken during
transmission, or transmitting output power may drop excessively.

BF9500 车载台使用说明书
1) Route the DC power cable supplied with the transceiver directly to the vehicle's battery terminals using the shortest path
from the transceiver.
·We recommend you do not use the cigarette lighter socket as some cigarette lighter sockets introduce an unacceptable voltage
drop.
·The entire length of the cable must be dressed so it is isolated from heat, moisture, and the engine secondary (high voltage)
ignition system/ cables.
2) After installing cable, in order to avoid the risk of damp, please use heat-resistant tap to tie together with fuse box. Don't
forget to reinforce whole cable.
3) In order to avoid the risk of short circuit, please cut down connection with negative of battery, then connect with radio.
4) Confirm the correct polarity of the connections, then attach the power cable to the battery terminals; red connects to the
positive terminal and black connects to the negative terminal.
·Use the full length of the cable without cutting off excess even if the cable is longer than required. In particular, never r emove
the fuse holders from the cable.
5) Reconnect any wiring removed from the negative terminal.
6) Connect the DC power cable to the transceiver's power supplym connector.
·Press the connectors firmly together until the locking tab clicks.
2. Fixed Station Operation

BF9500 车载台使用说明书
In order to use this transceiver for fixed station operation,you will need a separate 13.8V DC power supply
(not included), The recommended current capacity of your power supply is 15A.
1) Connect the DC power cable to the regulated DC power supply and ensure that the polarities are correct. (Red: positive,
Black:negative).
·Do not directly connect the transceiver to an AC outlet.
·Use the supplied DC power cable to connect the transceiver to a regulated power supply.
·Do not substitute a cable with smaller gauge wires.
2) Connect the transceiver's DC power connector to the connector on the DC power cable.
·press the connectors firmly together until the locking tab clicks.
◆Before connecting the DC power to the transceiver, be sure to switch the transceiver and the DC power supply OFF.
◆Do not plug the DC power supply into an AC outlet until you make all connections.
■REPLACING FUSES
If the fuse blows, determine the cause, then correct the problem. After the problem is resolved, replace the fuse. If newly
installed fuses continue to blow, disconnect the power cable and contact your authorized POFUNG dealer or an authorized
POFUNG service center for assistance.
Fuse Location
Fuse Current Rating

BF9500 车载台使用说明书
Transceiver
15A
Supplied Accessory DC power cable
20A
◆If you use the transceiver for a long period when the vehicle battery is not fully charged, or when the engine is OFF, the battery
may become discharged, and will not have sufficient reserves to start the vehicle. Avoid using the transceiver in these
conditions.
◆Only use fuses of the specified type and rating, otherwise the transceiver could be damaged.
■Antenna Connection
Before operating, install an efficient, well-tuned antenna. The success of your installation will depend largely on the type of
antenna and its correct installation. The transceiver can give excellent results if the antenna system and its installation are given
careful attention.
Use a 50Ωimpedance antenna and low-loss coaxial feed-line that has a characteristic impedance of 50Ω, to match the
transceiver input impedance. Coupling the antenna to the transceiver via feed-line having an impedance other
than 50Ωreduces the efficiency of the antenna system and can cause interference to nearby broadcast television
receivers, radio receivers, and other electronic equipment.
Transmitting without first connecting an antenna or other matched load may damage the transceiver. Always connect the
antenna to the transceiver before transmitting. All fixed stations should be equipped with a lightning arrester to reduce the risk of
fire, electric shock, and transceiver damage.
■Accessories Connections
1. External Speaker
If you plan to use an external speaker, choose a speaker with an impedance of 4Ω. The extemal speaker jack accepts a
3.5mm(1/8’’)mono (2-conductor) plug.

BF9500 车载台使用说明书
The speaker can not connect with the ground, otherwise the speaker will be fault.
2. DTMF Microphone
For voice communications, connect a microphone equipped with an 8-pin modular plug into the modular socket on the front
of the main unit. Press firmly on the plug until the locking tab clicks. Attach the supplied microphone hanger in an appropriate
location using the screws included in the screw set.
麦克风连接头：Microphone connector
3. PC Connecting
To utilize the Programming software(BF-9500) , you must first connect the transceiver to your PC then using an optional
programming cable PC (via USB socket).
Programming software acquisition can contact your dealer or visit the official website :www.baofengradio.com. Ask your
dealer about purchasing a Programming Cable USB-PC-95.
■Getting Acquainted
1. Front panel

BF9500 车载台使用说明书
﹒Basic Functions
No.
KEY
FUNCTION
1
Main Dial
Change frequency, memory channel and scan direction etc
2
LCD
Display the menu, sfrequency, channel information etc..
3
TONE and CALL Function keys
Switches between 2TONE,5TONE and DTMF.
4
POWER and MHz Function keys
High/medium/low power switch；frequency regulation(MHz)
5
SQL and MONI Function keys
Set noise level and monitor function
6
DTMF Mic.connector
Microphone connection port；PC programming port，
7
Theft Alarm Port
Theft alarm functions
8
VOL
Adjust Volume Key
9
Power Light
Power lights
10
（Power Key）
Power On/Off
11
Reverse Frequency；Long press 2 seconds lock the keyboard；Amateur/Professional mode
switch；Channel deleted
12
Frequency and channel switch；Long press for 2 seconds to switch frequency and channel
scan;Channel deleted
13
Function of open；Long press for 2 seconds to enter the menu mode
14
TX
TX light,
2. Display
No.
Icon
FUNCTION
1
Compander
2
Priority Channel
3
Narrow band
4
Reverse Frequency
5
Offset frequency direction
6
Auto power off
7
Set DCS function
8
CTCSS code
9
CTCSS decode
10
Low power
11
Middle Power
12
Set DTMF、2TONE、5TONE function
13
Indicates the frequency or memory name
14
Pressing 【F】key

BF9500 车载台使用说明书
15
Signal is being received or monitor
16
Signal strength of receiving and transmitting.
17
Keypad lock
18
Current channel number has been stored
19
Channel scan skip this channel
20
Indicates the channel number in channel mode

BF9500 车载台使用说明书
3. Rear Panel 后面板
No.
Port
FUNCTION
1
Antenna Connector
Connection for 50Ωcoaxial cable and antenna.
2
Ext.Speaker Terminal
Terminal for optional external speaker SP01
3
Adjustable measuring port
Production of set parameters when special port
4. DTMF Microphone DTMF 手咪
1) Basic Functions
No.
Key
FUNCTION
1
UP
Increase frequency ,channel number or setting value
2
DOWN
Decrease frequency, channel number or setting value
3
PTT
Press the PTT (Push-TO-Talk) key to transmit
4
PF1/A
Custom key 1.( Default: CALL）.Press the [PTT]then press the [PF1/A] transmit A.
5
PF2/B
Custom key 2. (Default:V/M). Press the【PTT] then press the [PF2/B] transmit B.
6
PF3/ C
Custom key 3. (Default:FM_RADIO). Press the [PTT] then press the [PF3/ C] transmit C.
7
PF4/ D
Custom key 4.( Default:BATTERY)。Press the [PTT] then press the [PF4/ D] transmit D.
8
Number Key
Input VFO frequency or DTMF dial out etc..
9
LOCK Switch
Locks out the UP/Down/Numerical keys and Function keys
10
D T M F O N /OFF
Switches between DTMF dialing or function operating
11
MIC
Speak here during transmission
2) 【PF1～PF4】Function List：
REV
Reverse Frequency
CALL
Optional signaling call
MONI
Monitor
MHZ
In Frequency mode, Adjust the high MHZ
SHIFT
Offset Direction
V/M
Frequency/Channel
CT/DT
OFF/CTCSS Code/CTCSS CODEC/DCS CODEC

BF9500 车载台使用说明书
SQL
Set noise level
POWER
High/medium/low power switch
SCAN
frequency、channel、CTCSS/DCS Scan
PRI
Priority Channel switch
BATT
Battery voltage detection
RADIO
FM Radio switch
DTMF
DTMF edit
M-V
Storage of channel parameters
TONE
Optional signaling switch
LOCK
key lock(Except the PTT Key)
3）FM Radio mode：
①Press Microphones [UP] button UP the search；
②Press Microphones [DOWN] button Down the search；
FM Radio mode, when there is a signal or press [PTT] launch, withdrew from the state of
the radio automatically, over 5 seconds automatically return into the radio mode.
4）Microphones keys function：
·DTMF launch: press and hold 【PTT】+ Mic key（The microphone on DTMF function effectively）
·press and hold 【PTT】, then press 【DOWN】key: launch 1750 HZ, loose【DOWN】key to cancel the launch1750
·press and hold 【PTT】,Short press 【UP】key ：launch the set of optional signaling(DTMF/2TONE/5TONE)
5) Keypad Lockout
Pull down the slide switch to lock position, the lamp is turned off and all of keypads is not work except PTT switch.
6) Transmitting DTMF by microphone keypad
Slide DTMF key to DTMF position, press and hold the [PTT] key, transmitting the desired DTMF signaling by the numeric key
directly. ( Note: Slide DTMF key to DTMF position, the keyboard is invalid in standby)
■Professional Transceiver Mode 专业机模式
According to practical application, you can set the radio works as Professional Transceiver mode.
1. Sets the display mode 显示模式设定
1）By manual setup:：Prees the and keys boot, amateur or professional machine display mode switch
2）By programming software: In PC software's "General Setting"menu ,choose "Display Mode" to select Amateur
Transceiver mode or Professional Transceiver mode.
2. Amateur Transceiver Mode 业余机模式
Except setting as "CH" mode, others considered as Amateur transceiver mode. Under this mode,press key to switch
between Channel mode and VFO mode .

BF9500 车载台使用说明书
1）Frequency+Channel mode：When set display as"FR",it enters into Frequency+Channel mode, new setting of channel
operation and shortcut operation can be temporarily used by user. Once the radio is turned off or switched to another channel,
the temporary setting will be erased and back to initial settings.
2）Channel+Name Tag Mode：When set display as "NM",it enters into Channel +Name Tag mode. At this mode, it will display
corresponding channel name when the current channel is edited with name. Otherwise, it will display frequency + channel. Its operations
are the same as frequency + channel mode.
3）VFO Mode（Frequency mode）：This mode shows only frequency on the display. Shortcut operation and Channel setting will be
changed & stored as the latest value permanently.Once the radio is turned off or changed to new VFO frequency, the latest set ting is
remained until next change.
3. Professional Transceiver Mode 专业机模式
When set display mode as "CH",it enters into Professional Transceiver mode.At this mode,except scan,other shortcut operation
can't operate.And from No.1-15 menu in function setting will be auto-hidden,They should be set by PC software.If there is
corresponding name for current channel,the LCD will display current channel name Otherwise,it shows current channel number.
■Basic Operations 基本操作
1. Switching The Power On/Off 车载台开启与关闭
1）Press the key to open the radio power.( Light is light orange)
2）Press the key for 1s to turn off.
2. Adjusting The Volume 调节音量
1）Turn the VOL knob clockwise to increase the audio level.
2）counterclockwise to decrease the audio level.
3. Transmitting （发射）
1）Please hold the Microphone, Then press and hold [PTT] key to speak into microphone.
·Please hold the microphone approximately 5.0cm from your lips, and then speak into the microphone in your normal
speaking voice to get best timbre.
·Press and hold [PTT] key, TX light and a red glow.
·If use outside launch coverage area, walkie-talkie fault of a loud sound.
2.）Loosen the microphones [PTT] to receive。
4. Receiving 进行接收

BF9500 车载台使用说明书
When the channel you are operating is called, the screen shows BUSY, in this way, you can hear the calling from transmitting
party.
If the transceiver has set at higher squelch level, it may fail to hear the calling.
When the channel you are operating is called,the screen shows BUSY ,you can't hear the calling from transmitting party,it means
current channel receives a matching carrier but not match signaling(Refer to CTCSS/DCS encode and decode or Optional Signaling
setup).
5. Squelch Function 监听功能
In standby mode, short press the key open squelch, mute circuit to shut down, you will hear the background noise a
hint sound ;Again a short press close squelch, can’t hear background noise (two consecutive hint sound).
If you need to check whether there is the channel interference, please press this button, and then turn the volume control
knob, you can hear the background noise or interference.
6. HIGH/MID/LOW Power switch 选择输出功率
Press key until LCD display icon,then press key to switch between high/Mid/low power. The LCD appears:
·L:Transmit in low power
·M: Transmit in middle power
·None: Transmit in high power.
·Don't use high output power for a long time to call, this may result in interphone overheating and can't work normally.
·Continuous use can lead to overheating radiator, this case, be careful not to touch the radiator.
·Mobile Radio overheat protection circuit may will interphone switch to low emission power output.
7. Switch between VFO and Channel mode 工作模式切换
In standby mode, press key or Microphone [UP][DOWN]key until appear Channel number. this indicates current
channel in channel mode. Repeat above operation to switch between Frequency mode (VFO) and Channel mode.
8. Selection Frequency 选择频率
1）VFO Mode (Frequency Mode )
In standby mode, press the key, switch to VFO mode, main knob clockwise control higher frequency, rotate
counterclockwise to reduce the frequency, or use the microphone key raise or lower frequencies.
2）MHz Mode

BF9500 车载台使用说明书
①In VFO mode, press the key, the frequency of the screen display area MHZ digital flicker.
②Turning the knob to select the required value MHz. Main knob clockwise control increases MHZ, rotate
counterclockwise to reduce MHZ. Rise and fall MHZ or use hand microphones F key values.
③Press any key to set the selected frequency and return to normal VFO mode .
3）Incoming Frequency
①In standby mode, press the key, switch to VFO mode.
·Must be in VFO mode to use.
②Press numeric keys ([0] to [9]) enter the required frequency (the three decimal point as the MHZ, three decimal places for
KHZ).
9. Channel memory 信道存储
1）Frequency to save channel：
①Under frequency mode (VFO), turn selector knob to select the desired frequency or input frequency by MIC's numeric keys；
④Press Key,LCD appears F, channel number icon flashing；
⑤Press key to enter CTCSS/DCS signaling setup, turn selector knob to select the desired signaling；
④Turn selector knob to select the desired channel number to store;
⑤Press key, , Ficon and channel number disappears and emit a prompt voice, thus the channel storage succeed.
2）Channel storage channel 信道存信道：
①Under channel mode，turn selector knob to select the desired channel；
②Press Key,LCD appears F, channel number icon flashing；
③Turn selector knob to select the desired channel number to store；
④Press key, , Ficon and channel number disappears and emit a prompt voice, thus the channel storage succeed.
10. Channel Delete 删除信道
1）Under channel mode, turn selector knob to select channel which you want to delete；
2）Short press the key, then press the key, the screen appears SURE?Short press again, current channel will be
deleted and emitted a prompt voice.
11. Transmitting Tone-Pulse 发射中转导频频率（即单音脉冲）
Press and hold [PTT] key, then press Microphone key to transmit 1750Hz tone-pulse signal；loosen the key to cancel
the transmit 1750Hz tone-pulse signal.

BF9500 车载台使用说明书
12. Transmitting OPTIONAL SIGNALING 发射可选信令
Press and hold the Microphone [PTT] key, then press key to transmit pre-stored and selected DTMF/2Tone/5Tone optional
signaling.
13.Transmitting DTMF 发射 DTMF
Slide DTMF key to DTMF position, press and hold the [PTT] key, transmitting the desired DTMF signaling by the numeric key
directly.
14. KEYPAD LOCKOUT 键盘锁定
Avoiding unintentional operation, this function will lock main keys, all keys except and [PTT] key are invalid.
1）Long press key until LCD displays icon, it indicates keypad lockout function is valid.
2）Repeat above operation, icon disappears, it indicates keypad lockout function is invalid.
15. Power supply voltage display function 电源电压显示功能
After the machine is connected to the power supply, long hands the microphone [PF4] key can confirm that the power supply
voltage, the display screen displays the machine power supply voltage. When the supply voltage changes, the display will
immediately change. When restart the power supply or repeat the above operation, the machine will return the user operation
mode.
Voltage range shown only from 7 v - 16 v dc voltage, as shown in the numerical value is for reference only, if you want to
have more accurate readings, please use the voltmeter.
Shortcut Operations 快捷功能操作
1. Squelch level Setup（+）
Setting the radio to a tight squelch level,you can avoid unwanted signals or noise,but you may not receive a weak signal.
Therefore,it will be better for you to select the normal squelch level.
1）While standby, press the key, the screen display icon, then press , screen display
。
·The display screen shows the current squelch level。
2）Turn selector knob or press Mic key to set desired squelch level, Press any key to exit and save the Settings.
2. Frequency/Channel Scan 频率及信道扫描
1）Frequency Scan 频率扫描

BF9500 车载台使用说明书
①In VFO mode,long press to enterinto frequency scan；
②Turn selector knob or press Microphone key to change scan direction；
③Press any key except key to exit.
2）Channel Scan 信道扫描
①In channel mode,Press key to enter into channel scan；
②Turn selector knob or press Microphone key to change scan direction；
③Press any key except key to exit.
3）CTCSS/DCS SCAN 扫描
When CTCSS or DCS functions activation, walkie-talkie to stop on the busy frequency, and decoding the CTCSS or DCS
signaling.If CTCSS or match the DCS signaling, cancel the mute interphone.Otherwise, the intercom restore scanning.
①Standby mode, Short press key, the screen display icon,then shore press key, until the screen display "CTCSS"
or "DCS";
②Long press key, Begin CTCSS or DCS signaling scanning；
③When decoding to match the CTCSS or DCS signaling, automatic exit CTCSS/DCS scan mode, display the current signal value,
press any key to exit in the process of scanning scanning state;
④If you want to save the current data, short press the key, the channel number flashes, main knob choose channel
number, short press the key, save the current data to the specified channel.
4. CTCSS/DCS Encode and Decode setup CTCSS/DCS 编解码设置
1）Standby mode, Short press key, then shore press key,
·When LCD appears CT icon, it means current channel with CTCSS CODEC, turn selector knob or press Microphone's
key to select desired CTCSS CODEC.
·When LCD appears icon, it means current channel with CTCSS encode, turn selector knob or press Microphone's
key to select desired CTCSS encode.
·When LCD appears DCS icon, it means current channel with DCS encode, turn selector knob or press Microphone's
key to select desired DCS encode.
2）Repeat steps（1），Switch the CTCSS encode（ ）/ CTCSS CODEC (CT)/ DCS CODEC (DCS)/OFF。
3）Press any key except key to Standby mode.
Under channel mode,this operation can be temporarily used by user. Once the radio is turned off or switched to another

BF9500 车载台使用说明书
channel,the temporary setting will be erased.
5. Offset Direction and offset frequency setup 差频方向及差频频率设置
Repeater receives a signal(UP-LINK) on one frequency and retransmits on another frequency(DOWN-LINK). The difference
between these two frequencies is called the offset frequency. If the UP-LINK frequency higher than DOWN-LINK frequency, the
direction is positive, If it is lower, the shift direction is negative.
1）Standby mode,long press key, LCD displays offset direction and offset frequency；
2）Repeatedly press key to select positive offset and negative offset；
3）When LCD displays "+ " icon, it indicates positive offset, which means transmitting frequency higher than receiving frequency；
When LCD displays " " icon, it indicates negative offset, which means transmitting frequency lower than receiving frequency；
4）Turn selector knob or Mic's key to change offset frequency, offset frequency changed as per stepping；
5）Press any key except key to save and exit the Settings .（Channel mode, the temporary save ）
Under channel mode,this operation can be temporarily used by user. Once the radio is turned off or switched to another
channel,the temporary setting will be erased.
6.可选信令选择设置
DTMF/5Tone/2Tone signalling function as similarily as CTCSS/DCS. Without receiving correspondent tone signalling, the speaker
will remain mute. DTMF and 5Tone signalling can be applied for other advanced features such as ANI, PTT ID, group call, remotely
stun,remotely kill, waken,...etc.
1）Standby mode,long Press key, Optional signaling required to set the current channel.
2）Repeat the above operation can be set optional signal to DTMF, 2TONE and 5TONE.
LCD appears "DTMF" icon : enable DTMF CODEC
LCD appears "2TONE" icon :enable 2TONE CODEC；
LCD appears "5TONE" icon : enable 5TONE CODEC；
None: No signaling.
Under channel memory mode,this operation can be temporarily used by user. Once the radio is turned off or switched to
another channel,the temporary setting will be erased.
7. Transmitting OPTIONAL SIGNALING 可选信令发码
If the current channel are optional to choose the corresponding signaling, short press the key, send the optional
signaling；

BF9500 车载台使用说明书
1）Display the DTMF: sending DTMF code, sending categories for menu "5" category, specific content can be found in the menu
"21";
2）Display the"2TON" : sending 2TON code, sending categories for menu "3" category；
3）Display the "5TON" :sending 5TONE code,sending categories for menu"4" category；
4）No optional signaling is sending DTMF, with (1).
8. Reverse TX/RX 倒频功能设置
TX frequency turns to RX frequency & RX frequency changes to TX frequency. The signaling will also be reversed if CTCSS/DCS
signaling exited in this channel.
In standby mode, the repetition of short key, set the current channel switch the function. the function opens, the
screen Ricon.
■Menu Operation 菜单操作
■Menu access and operation(standby mode) 菜单访问与操作（待机模式下操作）
1）Long press the key for 2 seconds, enter the function menu Settings.
2）Turn selector knob or Mic's key, select the desired menu number.
·When change the menu number, display screen will be displayed on the brief explanation of each menu and the parameters.
3）Short press to confirm to the contents of the menu, the menu content flicker.
4）Turn selector knob or Mic's key, select the desired menu content；
5）Short press the key to confirm, after a prompt tone to save and return to the higher level menu;
6）Set up process short press or , cancel the save.
7）Press to other keys, cancel the save, send 3 the sound and return to the main interface.
■The edit menu content 菜单内容编辑：

BF9500 车载台使用说明书
1）According to the menu operation flow into the content editor interface(Menu No.10 and Menu No.21)；
2）Scintillation screen "_", rotate the knob switch or Mic's key, and select the desired content, short
press confirm to save the current character and into the next character editing, short press confirm the current
character (not save) and into the next character editing, short press move to the left a character editor, short
press button to delete the cursor and on the right side of the content.When the cursor is at the far left short
press automatic save and exit is set to the main interface, When the cursor at the far right position and the without
setting content and press the key does not automatically save and return to the higher level menu interface, When
the cursor at the far right position and the without setting content and press the key to save and return to the higher
level menu interface.
■Menu item list 菜单项列表
Menu
Display
Function
option
default
1
STP.
Frequency step
2.5、5、6.25、8.33、10、12.5、
20、25、50、100K
6.25K
2
SPK.
Horn open mode
SQ、CTC、TON、C*T、C/T
SQ
3
2TONE
2TONE signaling group
00～31
00
4
5TONE
5TONE signaling group
00～49
00
5
DTMF
DTMF signaling group
0～9
0
6
FMN.
Narrow-band switch
ON、OFF
OFF
7
TX.
Launch
ON、OFF
ON
8
BCL.
busy channel lockout
ON、OFF
OFF
9
TALK.
Talk Around
ON、OF
OF
10
M.NAME
Editing Channel Name
11
BS.
Beat Frequency
ON、OFF
OFF
12
L. OUT.
Scan skip
ON、OFF
OFF
13
COMP.
Voice Compander
ON、OF
OF
14
SCR.
Scrambler setup
ON、OFF
OFF
15
MDF.
Channel display mode
MN、FRQ
MN
16
D.
Radio's DTMF SELF ID
ENQUIRY
12345
17
F.
Radio's 5TONE SELF ID
ENQUIRY
12345
18
BP.
Voice Prompt
ON、OFF
OFF
19
TOT.
Time-out timer
OFF、1～30 分钟
3
20
APO.
Auto power off
OFF、0.5H、1H、1.5H、2H、4H
OFF

BF9500 车载台使用说明书
21
DTMF.MR
DTMF sending content editor
CH？0～9
22
SPD.
DTMF Transmitting Time
50、100、200、300、500 毫秒
50
23
SCAN.
Scan mode
TO、CO、SE
TO
24
LAMP.
Backlight luminance
1～8
8
25
COLOR
Backlight Color
CL-RX 1～3
1
CL-TX 1～3
2
CL-ST 1～3
3
26
PF1
PF1
See the microphone
programmable key definitions
CALL
27
PF2
PF2
See the microphone
programmable key definitions
V/M
28
PF3
PF3
See the microphone
programmable key definitions
RADIO
29
PF4
PF4
See the microphone
programmable key definitions
BATT
30
TB.
Pilot Frequency
1000、1450、1750、2100Hz
1750Hz
31
P.VFO
VFO Range
400～470MHz
400 ～
470MHz
32
RESET
Restore to default setting
VFO、FULL
VFO
This Mobile Radio is equipped with 2 levels operation menu.From No.1 to No.15 are channel function setup, From No.15 to
No. 29 are general setting setup.
■General Setting 菜单设置操作详细说明：
1. Frequency Channel Step Setup 步进频率设置
1）In frequency (VFO) mode, press and hold key to enter general setting menu；
2）Adjust the knob switch or Mic's key, and select 01 menu option, the screen display ;
3）Short press the key, enter the function menu, the screen flashing "625";
4）Adjust the knob switch or Mic's key, Select the desired, there are 2.5 K, 5 K, 6.25 K, 8.33 K, 10 K, 12.5 K, 20 K and
25 K, 50 K, 100 K;
5）Short press the key, save and exit the Settings；
6）Setup process short press , then cancel save , and switch to the on a menu or next a menu；
7）Press to other keys , cancel the save and return to main interface.
