TR Telecom RAPID M200 Installation and operating instructions

M2000 MOBILE RAPID RADIO
Security Information:
Please read the instructions in this guide carefully to ensure proper use of the mobile radio and avoid potential hazards.
Electronic Equipment
• Do not use the radio in an area that prohibits the use of wireless devices in case of interfering with other electronic equipment.
Flammable and Explosive Areas
• Do not use the radio in areas that contain potentially ammable or explosive materials (e.g. petrol station).
Operating Environment
• Do not use the radio in dusty, humid, or heavily polluted environments, or expose the radio to magnetic elds, as it may cause
internal circuit faults.
• Do not use the equipment during a thunderstorm. This may cause equipment failure or electric shock.
• Do not expose the radio to direct sunlight for extended periods
• Do not expose the radio to water/moisture as it may lead to re or electric shock.
• Do not place the radio near ames or other heat sources such as heaters, microwaves, candles, or ovens.
Accessories Requirements
• Do not use unapproved or incompatible power sources, chargers, or batteries as this may cause re or explosions.
• Only use manufacturer approved accessories. Use of unapproved accessories may cause damage to the radio and will void the warranty.
Maintenance Service:
• Ensure the radio has been switched off and power has been disconnected before cleaning or performing maintenance of the equipment.
• When the radio is not in use, cover all sockets.
• When cleaning dust off the exterior of the equipment do not use corrosive chemicals – use neutral detergents.
• Keep the radio and accessories dry – do not attempt to dry the equipment with a hairdryer, oven, or microwave.
User Manual & Installation Guide
TS0322
Instructions before use:
• Do not use the mobile radio or charge the battery in potentially explosive environments (e.g. where gas, dust, or steam etc. is present).
• Turn off the radio when refuelling your vehicle or when parked at any refuelling station.
• Do not expose the radio to direct sunlight for extended periods. Do not place the radio near heating appliances.
• Do not expose the radio to extremely dusty conditions or water/moisture. Do not place on an uneven surface.
• Do not disassemble the radio. Maintenance should only be carried out by a qualied technician.
1300 797 897 [email protected] www.trtelecom.com.au

Machine Chart:
Installation:
SIM Inserting Slot
1. Remove SIM card cover, insert SIM card,
place cover back on and screw to tighten.
2. Rotate xed bracket screws clockwise
until the xed bracket is tightened.
3. Connect with the power supply.
DC power input
4. Insert GPS antenna/external main antenna.
GPS antenna interface
5. Plug in the microphone.
Hand microphone interface
12 3 4 5
6
7
8
9101112
13
14
191817
16
15
20 21
Machine Chart Legend
1. Volume Knob
Turn left (-V), Turn right (+V) & Press to set 8. Return 15. Fixed Bracket Screw
2. Indicator 9. Customised Button 16. Fixed Bracket
3. LampLCD 10. Customised Button 17. GPS Antenna Interface
4. SOS 11. 2G/3G Switch Key 18. External Main Antenna Interface
5. Logo 12. SIM Switch Key 19. DC Power Interface
6. Previous Page 13. Mic Interface 20. Headset/USB Interface
7. Next Page 14. On/Off 21. SIM Inserting Slot
Device/Installation Kit Components
1x M2000 PTToC Device 1x Fist Microphone metal bracket
1x Fist Microphone 3x Fist Microphone metal bracket mounting screws
1x Mounting Bracket - Metal 1x GPS Antenna
2x Mounting Bracket pivot screws 1x 4G LTE Patch Antenna 698-2700 MHz (Glass Mount)
2x Mounting Bracket xing screws 2x DC Power cables (1 x black 1 x red)
