point 5 Series User manual

POIH5060I4B
User Manual
Induction Hob

GB
operating instructions will help you use it properly and safely. We
recommend that you spend some time reading this instruction manual in
all the safety instructions carefully before use and keep this instruction
manual for future reference.
NO
Takk for at du kjøpte din nye POINT Induksjonstopp . Denne
bruksanvisningen hjelper deg med å bruke den ordentlig og sikkert.
Vi anbefaler at du tar deg tid til å lese gjennom hele bruksanvisningen for
å bli fortrolig med alle funksjonene den har. Les alle sikkerhetsanvisningene
nøye før bruk, og oppbevar bruksanvisningen for fremtidig referanse.
FI
Kiitos, että ostit uuden POINT-Induktiolieden. Tämä käyttöopas opastaa
sinua käyttämään laitetta oikein ja turvallisesti. Suosittelemme, että vietät
hetken tämän käyttöoppaan parissa, jotta ymmärtäisit täysin kaikki
laitteen tarjoamat toiminnalliset ominaisuudet. Lue kaikki
turvallisuusohjeet huolellisesti ennen laitteen käyttöä ja säilytä käyttöopas
myöhempää käyttöä varten.
DK
Tak for købet af din nye Induktionskogeplade fra POINT. Disse
brugsanvisninger hjælper dig med at bruge den korrekt og sikkert. Vi
anbefaler, at du læser denne brugsanvisning, så du får en fuld forståelse af,
hvordan alle funktionerne virker. Læs alle sikkerhedsinstruktioner nøje før
brug, og behold denne brugsanvisning til senere reference.
SE
Tack för ditt köp av din nya POINT-Induktionshäll. Denna bruksanvisning
hjälper dig att använda den säkert och på rätt sätt. Vi rekommenderar
att du tar dig tid att läsa denna bruksanvisning så att du förstår alla
driftsfunktioner den erbjuder. Läs alla säkerhetsanvisningar noga före
användning och förvara bruksanvisningen för framtida referens.
2
Thank you for purchasing your new POINT induction hob. These
order that you fully understand all the operational features it offers. Read

GB
DKSE
Instruction manual - English ...................... page
Användarmanua - Svenska ......................... sida
Brugsanvisning - Dansk ............................... side
Bruksanvisning - Norsk ............................... side
Käyttöohjeet - Suomi .................................. sivu
NOFI
4 - 38
3
39 - 73
74 - 108
109 - 143
144 - 178

FOREWORD
SAFETY WARNINGS
Your safety is important to us. Please read this information
before using your cooktop.
INSTALLATION
Electrical Shock Hazard
- Disconnect the appliance from the mains electricity
supply before carrying out any work or maintenance on it.
- Connection to a good earth wiring system is essential and
mandatory.
- Alterations to the domestic wiring system must only be
made by a qualified electrician.
- Failure to follow this advice may result in electrical shock
or death.
Cut Hazard
- Take care - panel edges are sharp.
- Failure to use caution could result in injuries or cuts.
Important safety instructions
- Read these instructions carefully before installing or
using this appliance.
- No combustible material or products should be placed on
this appliance at any time.
- Please make this information available to the person
responsible for installing the appliance as it could reduce
your installation costs.
4

GB
- In order to avoid a hazard, this appliance must be installed
according to these instructions for installation.
- This appliance is to be properly installed and earthed only
by a suitably qualified person.
- This appliance should be connected to a circuit which
incorporates an isolating switch providing full
disconnection from the power supply.
- Failure to install the appliance correctly could invalidate
any warranty or liability claims.
- This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved.
- Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children without
supervision.
- If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
- Warning: If the surface is cracked, switch o the
appliance to avoid the possibility of electric shock, for hob
surfaces of glass-ceramic or similar material which
- Metallic objects such as knives, forks, spoons and lids
should not be placed on the hob surface since they can
- A steam cleaner is not to be used.
- Do not use a steam cleaner to clean your cooktop.
5
protect live parts.
get hot.

- The appliance is not intended to be operated by means of
an external timer or separate remote-control system.
- WARNING: Danger of fire: do not store items on the
cooking surfaces.
- The cooking process has to be supervised. A short term
cooking process has to be supervised continuously.
- WARNING: Unattended cooking on a hob with fat or oil
can be dangerous and may result in fire. NEVER try to
extinguish a fire with water, but switch o the appliance
and then cover flame e.g. with a lid or a fire blanket.
OPERATION AND MAINTENANCE
Electrical Shock Hazard
- Do not cook on a broken or cracked cooktop. If the cooktop
immediately at the mains power supply (wall switch) and
contact a qualified technician.
- Switch the cooktop o at the wall before cleaning or
maintenance.
- Failure to follow this advice may result in electrical shock
or death.
Health Hazard
- This appliance complies with electromagnetic safety
standards.
- However, persons with cardiac pacemakers or other
electrical implants (such as insulin pumps) must consult
with their doctor or implant manufacturer before using
this appliance to make sure that their implants will not
6
surface is broken or crack, switch the appliance o

GB
be aected by the electromagnetic field.
- Failure to follow this advice may result in death.
Hot Surface Hazard
- During use, accessible parts of this appliance will become
hot enough to cause burns.
- Do not let your body, clothing or any item other than
suitable cookware contact the Induction glass until the
surface is cool.
- Keep children away.
- Handles of saucepans may be hot to touch. Check
saucepan handles do not overhang other cooking zones
that are on. Keep handles out of reach of children.
- Failure to follow this advice could result in burns and
scalds.
Cut Hazard
- The razor-sharp blade of a cooktop scraper is exposed
when the safety cover is retracted. Use with extreme care
and always store safely and out of reach of children.
- Failure to use caution could result in injuries or cuts.
Important safety instructions
- Never leave the appliance unattended when in use.
Boilover causes smoking and greasy spillovers may ignite.
- Never use your appliance as a work or storage surface.
- Never leave any objects or utensils on the appliance.
7

- Do not place or leave any magnetisable objects (e.g. credit
cards, memory cards) or electronic devices (e.g. computers,
MP3 players) near the appliance, as they may be aected
by its electromagnetic field.
- Never use your appliance for warming or heating the room.
- After use, always turn o the cooking zones and the
cooktop as described in this manual (i.e. by using the
touch controls). Do not rely on the pan detection feature
to turn o the cooking zones when you remove the pans.
- Do not allow children to play with the appliance or sit,
stand, or climb on it.
- Do not store items of interest to children in cabinets
above the appliance. Children climbing on the cooktop
could be seriously injured.
- Do not leave children alone or unattended in the area
where the appliance is in use.
- Children or persons with a disability which limits their
ability to use the appliance should have a responsible and
competent person to instruct them in its use. The
instructor should be satisfied that they can use the
appliance without danger to themselves or their
surroundings.
- Do not repair or replace any part of the appliance unless
specifically recommended in the manual. All other
- Do not place or drop heavy objects on your cooktop.
- Do not stand on your cooktop.
- Do not use pans with jagged edges or drag pans across
the Induction glass surface as this can scratch the glass.
8
services should be done by a qualified technician.

GB
- Do not use scourers or any other harsh abrasive cleaning
agents to clean your cooktop, as these can scratch the
Induction glass.
- This appliance is intended to be used in household and
similar applications such as:
- sta kitchen areas in shops, oces and other working
environments;
- farm houses;
- by clients in hotels, motels and other residential type
environments;
- bed and breakfast type environments.
- WARNING: The appliance and its accessible parts become
hot during use.
- Care should be taken to avoid touching heating
elements.
- Children less than 8 years of age shall be kept away
unless continuously supervised.
- After use, switch o the hob element by its control and
do not rely on the pan detector.
9

TOP VIEW
PRODUCT INTRODUCTION
1. Max. 2200/3300 W zone
3. Max. 2200/3300 W zone
5. Free induction zone.
3300/3700 W
7. Glass plate
2. Max. 2200/3300 W zone
4. Max. 2200/3300 W zone
6. Free induction zone.
3300/3700 W
8. Control panel
CONTROL PANEL
1. ON/OFF control
3. Pause control
5. Flex control
7. Keylock control
2. Time control
4. Boost control
23
4
7
8
1
6 1 75 3 5
42
56
42 42 42
10
6. Power slider touch control
6 6 6

GB
Working Theory
Induction cooking is a safe, advanced, ecient, and economical cooking
technology. It works by electromagnetic vibrations generating heat directly
in the pan, rather than indirectly through heating the glass surface.
The glass becomes hot only because the pan eventually warms it up.
Before using your New Induction Hob
• Read this guide, taking special note of the ‘Safety Warnings’ section.
• Remove any protective film that may still be on your Induction hob.
TOUCH CONTROLS
OPERATION OF PRODUCT
• The controls respond to touch, so you don’t need to apply any pressure.
• Use the ball of your finger, not its tip.
• You will hear a beep each time a touch is registered.
• Make sure the controls are always clean, dry, and that there is no object
(e.g. a utensil or a cloth) covering them. Even a thin film of water may
make the controls dicult to operate.
Iron pot
Magnetic circuit
Ceramic glass plate
Induction coil
Induced currents
11

CHOOSING
•Only use cookware with a base suitable for induction cooking.
Look for the induction symbol on the packaging or on the bottom
of the pan.
• You can check whether your cookware is
suitable by carrying out a magnet test.
Move a magnet towards the base of the pan.
If it is attracted, the pan is suitable for induction.
• If you do not have a magnet:
1. Put some water in the pan you want to check.
2. If does not flash in the display and the water is heating, the
pan is suitable.
• Cookware made from the following materials is not suitable: pure s
tainless steel, aluminum or copper without a magnetic base, glass,
wood, porcelain, ceramic, and earthenware.
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits flat against the glass,
and is the same size as the cooking zone. Use pans whose diameter is as
large as the graphic of the zone selected. Using a pot slightly wider will
make sure energy be used at its maximum effciency. If you use a smaller
pot, e
undetected by the hob. Always centre your pan on the cooking zone.
Always lift pans o the Induction hob – do not slide, or they may scratch
the glass.
12
ffciency could be less than expected. Pot less than 100mm could be

GB
Cooking zone The base diameter of induction cookware
PAN DIMENSION
The cooking zones are, up to a limit, automatically adapted to the
diameter of the pan. However the bottom of this pan must have a
minimum of diameter according to the corresponding cooking zone.
To obtain the best eciency of your hob, please place the pan in the
center of the cooking zone.
1,2,3,4
flex induction
Minimum (mm)
100
210
Maximum (mm)
220
220x380
Touch the ON/OFF control. After power
on, the buzzer beeps once, heating zone
indicating that the induction hob has
entered the state of standby mode.
Place a suitable pan on the cooking zone
that you wish to use.
• Make sure the bottom of the pan and
the surface of the cooking zone are
clean and dry.
HOW TO USE
Start cooking
13
selection controls show “ - ” ,

Each hob has its own independent slider,
boost, timing operation button, which
can independently operate the power
level/timing function.
Adjust heat setting by touching the
slider control.
• If you don’t choose a heat setting
automatically switch o. You will need
to start again at step 1.
• You can modify the heat setting at any
time during cooking.
Power down
Power up
Power down
If the display flashes alternately with the heat setting
This means that:
• you have not placed a pan on the correct cooking zone or,
• the pan you’re using is not suitable for induction cooking or,
• the pan is too small or not properly centered on the cooking zone.
No heating takes place unless there is a suitable pan on the cooking zone.
The display will automatically turn o after 1 minute if no suitable pan is
placed on it.
Touch the slider of the corresponding
burner to the far left, make sure the
display shows "0", after 3s the cooking
area is turned o, and the display
shows "-".
Finish cooking
14
within 20 sec, the Induction hob will

GB
Turn the whole cooktop o by touching
the ON/OFF control.
Beware of hot surfaces
H/h will show which cooking zone is hot
to touch. It will disappear when the
surface has cooled down to a safe
temperature. It can also be used as an
energy saving function if you want to
heat further pans, use the hotplate that
is still hot.
OR
Using the Boost Function
Touch the ON/OFF control. After power
on, the buzzer beeps once, heating zone
indicating that the induction hob has
entered the state of standby mode.
Activate the boost function
15
selection controls show “ - ” ,
zone indicator shows “Marquee” and the
power reaches Max.
Touching the boost control “B”, the

After the boost operation time reaches,
it will automatically exit the boost mode
and return to the level before entering
the boost mode . If the level before
entering the boost mode is 0, it will
In boost mode, the operation slider will
exit the boost mode, and the gear will
be displayed in the display area.
Cancel the Boost function
Note:
• The function can work in all cooking zones.
• The cooking zone returns to its original setting after 10 minutes.
• The flex cooking zone returns to its original setting after 5 minutes.
• As the boost function of 1st cooking zone is activated, start 2nd cooking
area, and the 1st cooking area will automatically change to level 9. Vice
versa.
• If the original heat setting equals 0, it will return to 9 after 10 minutes.
• This area can be used as a single zone or as two dierent zones,
• Flexible area is made of two independent inductors that can be controlled
separately. When working as a single zone, the part that is not covered
by cookware is automatically switched o after 8 seconds. Do not use
• To grant a correct pan detection and even heat distribution, the cookware
Flexible Area
16
become level 9 for operation.
according to the cooking needs anytime.
should be correctly placed.
unsuitable pot on the Flexible area centered.

GB
- In the front or rear side of the flexible zone when the cookware is smaller
than 22 cm
- Anywhere with bigger cookware.
Examples of good pot placement and bad pot placement.
To activate the flexible area as a single
big zone, simply press the dedicated
keys.
The power setting works as any other normal area.
As big zone
As two independent zones
If the pot is moved from the front to the rear part (or vice versa), the
flexible area detects automatically the new position, keeping the same
power.
To add a further pot, press again the dedicated keys, in order to detect
the cookware.
To use the flexible area as two dierent zones with dierent
power settings, press the dedicated keys.
17
Do not use unsuitable pot on the Flexible area centered.

When the hob is in the lock mode, all the controls are disabled
except the ON/OFF , you can always turn the induction hob o
with the ON/OFF control in an emergency, but you shall unlock
the hob first in the next operation.
Locking the Controls
accidentally turning the cooking zones on).
• When the controls are locked, all the controls except the ON/OFF control
are disabled.
Touch the lock control.
Touch and hold the lock control for a while.
To lock the controls
To unlock the controls
Timer control
The digital will show “ Lo ”.
• Each heat zone has independent time increase and decrease buttons.
• In flex mode, the time operation keys of the flex included hobs can
operate the time of the flex zone.
• In the flex zone mode, if the timing exists, turn off the flex zone function,
• Enter flex mode, and the timing setting is turned off by default.
• The maximum settable timing time is 8:00.
•The maximum setting time of the current gear is the default timing time
of the gear. For details, see the Default working times.
• After entering the timing, the display will only display the current timing
time.
18
and the time will remain on the LF/RF hob.
• Press the key for a short time to increase or decrease time by 1min, and
• You can lock the controls to prevent unintended use (for example, children
press the key for a long time to increase or increase by 10min.

GB
When the time is set to 0, it will exit the
level display mode at a fixed time
without operation for 3s.
short press are eective.
short press are eective.
1. When the cooking zones are running,
touch the "II" control, all the displays
control can be operated.
2. Touch " II " again, the displays show
the original setting, and the cooking
zones keep on heating.
Pause
At the same time, press the timing
plus or minus button for 1s to cancel
the timing.
will show " " and heating by level 2.
19
Time decrease button, long press and
Time increase button, long press and
At this moment, only " II" and " "

PAN TRANSFER
3. The pot transfer function is not enabled by default when bunner is in
transferred.
Start LR hob, LR burner running
at 9 level.
When the power is stable,
transfer the LR cooker to RF.
Blinking with sound.
20
1. LF digital tube displays On, it means open pan transfer function.
4. After the transfer is confirmed, the timing time and level will be
RF burner flashing and display the
power level of LR burner.
/
boost mode.
seconds long press LF timing reduction function key for 3s, close and
start the pan transfer function;
2. LF digital tube displays OF, it means close pan transfer function.
In the o state, long press the On Off key to start the cooktop, in 10
