Polanik PP-173 User manual

TECHNICAL SPECIFICATION
INSTRUCTION MANUAL
Competition aluminium collapsible hur le
PP-173
PP-173/6a
File: 2014-07-16
PRODUCT SUPPORT
Paweł Ciechanowski
p ciechanowski@polanik com

Tech specification and instruction manual PP-173 PP-173/6a 2 / 10
Contents
Chapter Page
I General description and use 2
II Technical specification 3
III Packing and transport 4
IV Parts list (part sets) 4
V Assembly 5
VI Operation and maintenance 6
VII IAAF Certificates 9
I. General escription an use
PP-173 (PP-173/6a 6b 6c) is a resistant to weather, inexpensive in transport and high quality competition hurdle,
which is designed for national and international competitions Main features:
•very durable aluminium construction – anodized telescope tubes together with feet and frame, highly
durable plastic top board made of ribbed profile
•collapsible construction economical in transport
•spring-loaded button systems of height adjustment and counterweight selection
•special cut-outs for mounting top boards
•it meets the international quality standards
•IAAF certificates
PP-173 © 2014 Polanik
The pro ucer reserves the right to intro uce without warning changes in pro uct constructions an colours.

Tech specification and instruction manual PP-173 PP-173/6a 3 / 10
II. Technical specification
*There may be differences in hue between the telescope tubes and the hurdle feet
Co e PP-173 PP-173/6a
Hur le type competition collapsible certified competition collapsible certified
(A)
Top boar plastic, with inside ribbing plastic, with inside ribbing
(B) Telescope tube aluminium anodized*, spring-loaded button
system of height adjustment
aluminium anodized*, spring-loaded button
system of height adjustment
(C)
Frame aluminium anodized aluminium anodized
(D)
Feet
aluminium anodized*, spring-loaded button
system of counterweight selection,
counterweights installed on stainless steel
balls
aluminium anodized*, spring-loaded button
system of counterweight selection,
counterweights installed on stainless steel
balls
- 686
762 762
840 840
914 914
990 990
Heights [mm]
1067 1067
Weight [kg] 12 12
A
B
C
D

Tech specification and instruction manual PP-173 PP-173/6a 4 / 10
III. Packing an transport
The hurdles are put on pallets in parts (frames, feet and foot screws separately) and wrapped with foil The packed
pallet (to be foiled) is presented below:
IV. Parts list (part sets)
Item Part/set description Q-ty pcs Sketch
1 Hurdle frame 1
Package type foiled pallet
contents 25 pcs
length 120
width 80
Dim
[cm]
height 100
Volume m
3
] 0,96
Gross weight [kg] 325
box with
hurdle feet
box with foot
screws
frames with telescope tubes and
top boards mounted

Tech specification and instruction manual PP-173 PP-173/6a 5 / 10
Item Part/set description Q-ty pcs Sketch
2 Hurdle foot 2
3 Washer 2
4 Foot screw 2
V. Assembly
A wrench 17 is needed to perform the assembly Although one person can prepare the hurdle for use, a convenient
and fast assembly process requires two persons
To assemble the hurdle please do the following:
a) slide carefully one hurdle foot (item 2) into one frame socket (item 1),
b) make sure the foot (item 2) is properly placed in the socket, if it is not straight, please correct its position,
c) screw the foot (item 2) to the hurdle frame (item 1) by means of the foot screw (item 4) and the washer
(item3),
d) install the other foot in the same way
The main goal of the hurdle collapsible construction is to assure easy and cheap transport Note that once you screw
the feet down, the hurdle is practically non-dismountable Therefore we do not recommend unscrewing the hurdle
feet during idle periods Removing the feet without proper tools can cause serious hurdle damages which Polanik shall
not be liable for
Item 1
Item
2
Item
3
Item
4

Tech specification and instruction manual PP-173 PP-173/6a 6 / 10
VI. Operation an maintenance
The height adjustment is done as follows:
a) while holding the telescope tubes press the spring-
loaded buttons simultaneously,
b) slide the telescopes down or up to adjust the height
until the buttons click,
c) next the hurdle toppling force should be adjusted
accordingly, so press and hold the knob in the hurdle
foot,
d) then slide the counterweight to the corresponding
height according to the label, then release the knob,
do the same with the other hurdle foot

Tech specification and instruction manual PP-173 PP-173/6a 7 / 10
F
oot
plastic plug
Spring
Foot
catch
Hurdle foot
During idle periods the hurdles must be stored in a roofed dry place For optimal performance they should be stored
and transported on Polanik hurdle carts: HC-23 and HC-34
After every athletics season the hurdles must be cleaned from sand (mud, dust and etc) Special attention is required
for the counterweight sliding mechanisms, which should be dismounted, cleaned and greased
Before you begin the maintenance work, your should gather the following items:
 hurdle foot plastic plug for PP-173 (2 pcs for each hurdle) code: S-0008-001-00-00-05,
grease (approx 50g for each foot),
wrench 19,
hex key 5
The counterweight disassembly is done as follows:
a) push down the foot catch and slide it toward the plastic plug,
b) put hex key into the bolt M6 through the technological hole under the foot,
c) hold the foot catch bolt with wrench 19 and unscrew the bolt M6 with the hex key,
d) remove the foot catch bolt and the spring from the counterweight,
e) remove the foot plastic plug from the foot tube (it often happens that the plug is damaged while removing, that is
why the spare plugs should be purchased before the disassembly)
Bolt M6
F
oot
plastic plug
Foot catch bolt
Hurdle foot

Tech specification and instruction manual PP-173 PP-173/6a 8 / 10
Counterweight
Hurdle foot
Foot catch bolt
Spring
F
oot
plastic plug
Bolt M6
f) sli e out the counterweight carefully – pay attention to the stainless steel bearing balls installe in the bottom of
the counterweight – they may fall out , and remove the bolt M6,
g) take out the balls from their sockets,
h) the counterweight, the ball sockets and the inside of the foot tube should be cleaned from dirt and old grease,
i) grease the inside of the ball sockets and install the balls,
j) slide in the counterweight carefully,
j) the assembly process is done in the reverse sequence

Tech specification and instruction manual PP-173 PP-173/6a 9 / 10
VII. IAAF Certificates
PP-173

Tech specification and instruction manual PP-173 PP-173/6a 10 / 10
PP-173/6a
