Polanik MDHJ-3 User manual

Instruction manual
Measuring devices
MDHJ-3
MDPV-8
File: 2016-06-08
PRODUCT SUPPORT
Paweł Ciechanowski
[e-mail]

Instruction manual MDHJ-3 MDPV-8 2/4
I. General description
The devices are designed for measuring the heights at which the crossbar is positioned during the athletics
competition of pole vault (MDPV-8 range up to 8 m) and high jump (MDHJ-3 range up to 3 m).

Instruction manual MDHJ-3 MDPV-8 3/4
II. Assembly
1. Unpack the device (item 1) and the measuring plate (item 2).
2. Unscrew the hand wheel (item 3).
3. Screw the measuring plate (item 2) to the device (item 1) with the hand wheel (item 3)
4. The product is ready for use.
III. Operation
1. Slid out the telescope profiles slowly, DO NOT pull out the segments fast and rapidly.
2. Position the device on the ground in front of the landing area, in the middle of the crossbar.
3. Place the measuring plate tip over the crossbar and adjust the length of the segments , so that the tip
touches the crossbar edge.
4. Use the green line to read out the height.
IV. Maintenance
1. The product is to store in dry place in room temperature.
2. Keep the product away moisture –if the water gets inside the segments, it may damage the product.
2
1
3

Instruction manual MDHJ-3 MDPV-8 4/4
V. Declaration
1)No. 2016-06-08
2)Issuer’s name: POLANIK
Issuer’s address: Zyczliwa 11, 97-300 Piotrkow Tryb.
3)Objects of declaration
4) Technical specification described above is in accordance with the factory’s internal engineering standards.
Additional Information
5) Declaration for:
Buyer/Distributor/User
Signed for and in behalf of:
POLANIK
2016-06-08 Piotrkow Tryb.
(Date and place of issue)
Paweł Ciechanowski
Product Manager
6)……………………………………… ……………………………………………………………………………
(Name, function) (Signature or equivalent authorized by the issuer)
No.
Name
Code
1
High jump’s measuring device 3 m
MDHJ-3
2
Pole vault’s measuring device 8 m
MDPV-8
