Polar Refrigeration CM530-A User manual

Model:
CM530-A / CM531-A / CM532-A
Chest Freezer
Instruction manual
CM530-A_CM531-A_CM532-A_A5_v1_20190626.indb 1 2019/6/26 14:55

2
AU Telephone Helpline: 1300225960
Safety Tips
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components or service panels on this product.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- Fire Precautions
- Wiring Regulations
- Building Regulations
• DO NOT use jet/pressure washers to clean the appliance.
• DO NOT use the appliance outside.
• DO NOT use this appliance to store medical supplies.
• DO NOT use electrical appliances inside the appliance (e.g.
heaters, ice cream makers etc.).
• DO NOT allow oil or fat to come into contact with the plastic
components or door seal. Clean immediately if contact occurs.
• Always carry, store and handle the appliance in a vertical
position and move by holding the base of the appliance.
• Always switch off and disconnect the power supply to the unit
before cleaning.
• Keep all packaging away from children. Dispose of the packaging
in accordance with the regulations of local authorities.
• If the power cord is damaged, it must be replaced by a POLAR
agent or a recommended qualified technician in order to avoid
a hazard.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience or knowledge, unless they have been
given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.
CM530-A_CM531-A_CM532-A_A5_v1_20190626.indb 2 2019/6/26 14:55

3
AUAU
Telephone Helpline: 1300225960
• Polar recommends that this appliance should be periodically
tested (at least annually) by a Competent Person. Testing
should include, but not be limited to: Visual Inspection,
Polarity Test, Earth Continuity (Class I equipment), Insulation
Continuity and Functional Test.
Caution Risk of Fire
• Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
Warning: Keep all ventilation openings clear of
obstruction. Unit should not be boxed in without
adequate ventilation.
• Warning: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Warning: Do not damage the refrigerant circuit.
• Warning: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are the
type recommended by the manufacturer.
Product Description
CM530-A - POLAR 385 litre Chest Freezer CM532-A - POLAR 587 litre Chest Freezer
CM531-A - POLAR 516 litre Chest Freezer
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of
this machine will provide the best possible performance from your POLAR product.
Pack Contents
The following is included:
Polar Chest Freezer Instruction manual
POLAR prides itself on quality and service, ensuring that at the time of packaging the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your POLAR dealer immediately.
Installation
Note: If the unit has not been stored or moved in an upright position, let it stand
upright for approximately 12 hours before operation. If in doubt allow to stand.
CM530-A_CM531-A_CM532-A_A5_v1_20190626.indb 3 2019/6/26 14:55

4
AU Telephone Helpline: 1300225960
1. Remove the appliance from the packaging.
Make sure that all protective plastic film and
coatings are thoroughly removed from all
surfaces.
2. Maintain a distance of 20cm (7 inches)
between the unit and walls or other objects for
ventilation. NEVER LOCATE NEXT TO OR
NEAR A HEAT SOURCE.
Note: Before using the appliance
for the first time, clean the
baskets and interior with soapy
water.
3. Set the brakes on the castors to keep the
appliance in position
OR
Level the appliance by adjusting the screw
feet.
Mounting the castors
Note: The appliance is supplied
with feet by default. However,
castors can be supplied as an
option. Castors can be ordered
using the code of AJ450.
To replace with the castors, follow below steps:
1. Remove the feet support.
2. Attach the castor support.
3. Fix the castor support in place with screws.
4. Mount the castor.
Operation
Control Panel
RUN indicator
Temperature Display Thermostat
Storing Food
To get the best results from your POLAR appliance,
follow these instructions:
• Only store foodstuffs in the appliance when it
has reached the correct operating temperature.
• Do not place uncovered hot food or liquid
inside the appliance.
• Wrap or cover food where possible.
• Do not obstruct the fans inside the appliance.
• Avoid opening the doors for prolonged periods
of time.
CM530-A_CM531-A_CM532-A_A5_v1_20190626.indb 4 2019/6/26 14:55

5
AUAU
Telephone Helpline: 1300225960
Turn On
1. Close the lid of the appliance.
2. Turn on the appliance.
3. Set the thermostat to the desired temperature.
Defrost
POLAR recommend defrosting the appliance when any frost build up inside the freezer reaches 5mm
thick. To do this switch the freezer off at the power supply.
Cleaning, Care & Maintenance
• Switch off and disconnect from the power supply before cleaning.
• Clean the interior of the appliance as often as possible.
• Do not use abrasive cleaning agents. These can leave harmful residues.
• Clean the door seal with warm water only.
• Always wipe dry after cleaning.
• Do not allow water used in cleaning to run through the drain hole into the evaporation pan.
• Take care when cleaning the rear of the appliance. Sharp edges can cut.
• A POLAR agent or qualified technician must carry out repairs if required.
Cleaning the Condenser
Periodically cleaning the condenser can extend the life of the appliance.
Troubleshooting
If your POLAR appliance develops a fault, please check the following table before making a call to the
Helpline or your POLAR dealer.
Fault Probable Cause Solution
The appliance
is not working
The unit is not switched on Check the unit is plugged in correctly and switched on
Plug and lead are damaged Call POLAR agent or qualified Technician
Fuse in the plug has blown Replace the fuse
Power supply Check power supply
Internal wiring fault Call POLAR agent or qualified Technician
The appliance
turns on,
but the
temperature is
too high/low
Too much ice on the evaporator Defrost the appliance
Condenser blocked with dust Clean the Condenser
Lid not shut properly Check lid is shut and seals are not damaged
Appliance is located near a
heat source or air flow to the
condenser is being interrupted
Move the freezer to a more suitable location
Ambient temperature is too high Increase ventilation or move appliance to a cooler
position
Appliance is overloaded Reduce the amount of food stored in the appliance
The appliance
is leaking water
The appliance is not properly
levelled
Adjust the screw feet to level the appliance (if
applicable)
The appliance
is unusually
loud
Loose nut/screw Check and tighten all nuts and screws
The appliance not installed in a
level or stable position
Check installation position and change if necessary
CM530-A_CM531-A_CM532-A_A5_v1_20190626.indb 5 2019/6/26 14:55

6
AU Telephone Helpline: 1300225960
Technical Specifications
Model Voltage Power Current Temperature
Range
Capacity
(litres) Refrigerant Dimensions H x W x D mm
Weight
(kg)
CM530-A 220-240V~
50Hz
230W 1.4A -24 to -18°C 339 R600a 105g 866 x 1395 x
741.5
67
CM531-A 220-240V~
50Hz
200W 1.3A -24 to -18°C 462 R290 90g 866 x 1795 x
741.5
82
CM532-A 220-240V~
50Hz
280W 1.8A -24 to -18°C 523 R290 95g 866 x 1995 x
741.5
87
Electrical Wiring
The plug is to be connected to a suitable mains socket.
POLAR appliances are wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The product must not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and environmentally safe
recycling process. For further information on how to dispose of this product correctly, contact the product
supplier, or the local authority responsible for waste disposal in your area.
POLAR parts have undergone strict product testing in order to comply with regulatory
standards and specifications set by international, independent, and federal authorities.
POLAR products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of POLAR.
Every effort is made to ensure all details are correct at the time of going to press, however, POLAR reserve the right to
change specifications without notice.
CM530-A_CM531-A_CM532-A_A5_v1_20190626.indb 6 2019/6/26 14:55

DECLARATION OF CONFORMITY
Equipment Type
Model
Legislation
Standards
Producer Name
Producer Address
Chest Freezer - 385Ltr - R600a
Chest Freezer - 516Ltr - R600a
Chest Freezer - 587Ltr - R290a
CM530-A
CM531-A
CM532-A
Electrical Safety
Electromagnetic Compatibility
IEC 60335-1: 2010 +A1:2013 IEC
60335-2-89: 2010 +A1:2012 EN
62233: 2008
BS EN 55014-1:2017
BS EN 55014-2:2015
BS EN 61000-3-2:2014
BS EN 61000-3-3:2013
Polar
15 Badgally Road,
Campbelltown,
NSW 2560
I, the undersigned, hereby declare that the equipment specified above conforms to the above Legislation and Standard(s).
Date 6th March 2019
Signature
Full Name Ashley Hooper
Position Technical & Quality Manager/ Responsible Supplier
CM530-A_CM531-A_CM532-A_A5_v1_20190626.indb 7 2019/6/26 14:55
