Polar Refrigeration CM530 User manual

Model
CM530/ CM531 / CM532 / CM433 / CM434
Chest Freezer
Instruction manual

1
UK
Safety Tips
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out installation and any repairs if required. Do not remove any components or
service panels on this product.
• Consult Local and National Standards to comply with the following:
• Health and Safety at Work Legislation
• BS EN Codes of Practice
• Fire Precautions
• IEE Wiring Regulations
• Building Regulations
• DO NOT use jet/pressure washers to clean the appliance.
• DO NOT use the appliance outside.
• DO NOT use this appliance to store medical supplies.
• DO NOT use electrical appliances inside the appliance
(e.g. heaters, ice-cream makers etc.).
• DO NOT allow oil or fat to come into contact with the plastic components or door seal. Clean immediately if contact occurs.
• Always carry, store and handle the appliance in a vertical position and move by holding the base of the appliance.
• Always switch off and disconnect the power supply to the unit before cleaning.
• Keep all packaging away from children. Dispose of the packaging in accordance with the regulations of local authorities.
• If the power cord is damaged, it must be replaced by a POLAR agent or a recommended qualified technician in order to avoid a
hazard.
• The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction
Caution Risk of Fire
• Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance
• Warning: Keep clear of obstruction all ventilation openings in the appliance enclousure or in the structure for
building-in
• Warning : Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by
the manufacturer
• Warning: Do not damge the refrigerant circuit
• Warning: Do not use electrical applainces inside the food storage comnpartments of the applaince, unless they are the type
recommended by the manufacturer
Product Description
CM530 - POLAR 385 litre Chest Freezer
CM531 - POLAR 516 litre Chest Freezer
CM532 - POLAR 587 litre Chest Freezer
CM433 - POLAR 200 litre Display Chest Freezer
CM434 - POLAR 270 litre Display Chest Freezer

2
Telephone Helpline: 0845 146 2887 (United Kingdom)
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of this machine will provide the
best possible performance from your POLAR product.
Pack Contents
The following is included:
• Polar Chest Freezer
• Instruction Manual
POLAR prides itself on quality and service, ensuring that at the time of packaging the contents are supplied fully functional and free of
damage.
Should you find any damage as a result of transit, please contact your POLAR dealer immediately.
Installation
1. Remove the appliance from the packaging. Make sure that all protective plastic film and coatings are thoroughly removed from all
surfaces.
2. Maintain a distance of 20cm (7 inches) between the unit and walls or other objects for ventilation. Increase this distance if the
obstacle is a heat source.
3. Set the brakes on the castors to keep the appliance in position
OR
Level the appliance by adjusting the screw feet.
Note: If the unit has not been stored or moved in an upright position, let it stand upright for approximately
12 hours before operation. If in doubt allow to stand.
Note: Before using the appliance for the first time, clean the shelves and interior with soapy water.
Control Panel - CM530, CM531, CM532
Temperature Display Thermostat
Run Indicator Run Indicator
Control Panel - CM433, CM434
Thermostat
Temperature Display

3
UK
Operation
Storing Food
To get the best results from your POLAR appliance, follow these instructions:
• Only store foodstuffs in the appliance when it has reached the correct operating temperature.
• Do not place uncovered hot food or liquid inside the appliance.
• Wrap or cover food where possible.
• Avoid opening the doors for prolonged periods of time.
Turn On
1. Close the lid of the appliance.
2. Turn on the appliance.
3. Set the thermostat to the desired temperature.
Defrost
• POLAR recommend defrosting the appliance when any frost buld up inside the freezer reaches 5mm thick. To do this switch the
freezer off at the power supply.
Cleaning, Care & Maintenance
• Switch off and disconnect from the power supply before cleaning.
• Clean the interior of the appliance as often as possible.
• Do not use abrasive cleaning agents. These can leave harmful residues.
• Clean the door seal with water only.
• Always wipe dry after cleaning.
• Do not allow water used in cleaning to run through the drain hole into the evaporation pan.
• Take care when cleaning the rear of the appliance. Sharp edges can cut.
• A POLAR agent or qualified technician must carry out repairs, if required.
Cleaning the Condenser
Periodically cleaning the condenser can extend the life of the appliance.

4
Telephone Helpline: 0845 146 2887 (United Kingdom)
Troubleshooting
If your POLAR appliance develops a fault, please check the following table before making a call to the Helpline or your POLAR retailer.
Technical Specifications
Electrical Wiring
The plug is to be connected to a suitable mains socket.
POLAR appliances are wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
All POLAR appliances must be earthed, using a dedicated earthing circuit.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency disconnection being required they must
be readily accessible.
Fault Probable Cause Action
The appliance is not
working
The unit is not switched on Check the unit is plugged in correctly and switched on
Plug and lead are damaged Call POLAR agent or qualified Technician
Fuse in the plug has blown Replace the fuse
Power supply Check power supply
Internal wiring fault Call POLAR agent or qualified Technician
The appliance turns on,
but the temperature is
too high/low
Too much ice on the evaporator Defrost the appliance
Condenser blocked with dust Clean Condenser
Lid not shut properly Check lid is shut and seals are not damaged
Appliance is located near a heat source or air
flow to the condenser is being interrupted
Move the freezer to a more suitable location
Ambient temperature is too high Increase ventilation or move appliance to a cooler position
Appliance is overloaded Reduce the amount of food stored in the appliance
The appliance is leaking
water
The appliance is not properly levelled Adjust the screw feet to level the appliance
The appliance is
unusually loud
Loose nut/screw Check and tighten all nuts and screws
The appliance has not been installed in a
level or stable position
Check installation position and change if necessary
Model Voltage Power Current Temp
Range
Capacity
(litres) Refrigerant Dimensions H x W x D (mm)
Weight
(Kg)
CM530 230V 50Hz 230W 2.5A -24 to -18C 385 R600a 105g 845 x 1395 x 688 67
CM531 230V 50Hz 270W 2.1A -24 to -18C 516 R290 100g 845 x 1795 x 688 82
CM532 230V 50Hz 270W 2.4A -24 to -18C 587 R290 100g 845 x 1995 x 688 87
CM433 230V 50Hz 200W 1.2A -24 to -18C 200 R600a 90g 920 x 953 x 553 42
CM434 230V 50Hz 250W 1.2A -24 to -18C 270 R600a 100g 928 x 1195 x 654 60

5
UK
Compliance
The WEEE logo on this product or its documentation indicates that the product must not be disposed of as household
waste. To help prevent possible harm to human health and/or the environment, the product must be disposed of
in an approved and environmentally safe recycling process. For further information on how to dispose of this product
correctly, contact the product supplier, or the local authority responsible for waste disposal in your area.
POLAR parts have undergone strict product testing in order to comply with regulatory standards and specifications
set by international, independent, and federal authorities.
POLAR products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic, mechanical, photocopying, recording or
otherwise, without the prior written permission of POLAR.
Every effort is made to ensure all details are correct at the time of going to press, however, POLAR reserve the right to change specifications without notice.

DECLARATION OF CONFORMITY
• Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •
• Declaración de conformidad • Declaração de conformidade
I, the undersigned, hereby declare that the equipment specified above conforms to the above Directive(s) and Standard(s).
Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de bovenstaande
Richtlijn(en) en Standaard(en).
Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus
Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n) und
Norm(en) entspricht.
Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.
El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y estándar(es)
arriba mencionadas.
Eu, o abaixo-assinado, declaro que o equipamento anteriormente especificado está em conformidade com a(s) anterior(es)
Directiva(s) e Norma(s)
Equipment Type • Uitrustingstype • Type d'équipement • Gerätetyp •
Tipo di apparecchiatura • Tipo de equipo • Tipo de equipamento
Chest Freezer
Model • Modèle • Modell • Modello • Modelo • Malli CM433 CM434 CM530
CM531 CM532
Application of Council Directives(s)
Toepassing van Europese Richtlijn(en) • Application de la/des directive(s) du
Conseil • Anwendbare EU-Richtlinie(n) • Applicazione delle Direttive • Aplicación
de la(s) directiva(s) del consejo • Aplicação de directiva(s) do Conselho
EMC Directive 2004/108 EC
LVD Directive 2006/95 EC
RoHS Directive 2011/65/EU
Producer Name • Naam fabrikant • Nom du producteur • Name des Herstellers •
Nome del produttore • Nombre del fabricante • Nome do fabricante
Polar
Producer Address • Adres fabrikant • Adresse du producteur • Anschrift des
Herstellers • Indirizzo del produttore • Dirección del fabricante • Endereço do
fabricante
Fourth Way,
Avonmouth,
Bristol,
BS11 8TB
United Kingdom
Date • Data • Date • Datum • Data • Fecha • Data 09/03/16
Signature • Handtekening • Signature • Unterschrift
Firma • Firma • Assinatura
Full Name • Volledige naam • Nom et prénom • Vollständiger Name •
Nome completo • Nombre completo • Nome por extenso
Richard Cromwell
Position • Functie • Fonction • Position • Qualifica • Posición • Função Commercial Director

CM530_CM532_UK_v2
