Polar Refrigeration CC611 User manual

Model • Modèle • Modell • Modello • Modelo • Malli:
CC611 / CC666
NL Gekoelde toonbankdisplay
Handleiding
8IT Espositore refrigerato da
banco
Manuale di istruzioni
26
FR Présentoir réfrigéré de
comptoir
Mode d'emploi
14 ES Exhibidor refrigerado para
mostrdor
Manual de instrucciones
32
DE Thekenkühlschrank
Bedienungsanleitung
20 PT Montra de balcão
refrigerada
Manual de instruções
38
Counter-top
Refrigerated
Merchandiser
Instruction manual
CC611-CC666_ML_A5_v6_20180125.indb 1 2018/1/25 17:31

2
UK
Safety Tips
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components or service panels on this product.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- BS EN Codes of Practice
- Fire Precautions
- IEE Wiring Regulations
- Building Regulations
• DO NOT use jet/pressure washers to clean the appliance.
• DO NOT use the appliance outside.
• DO NOT use this appliance to store medical supplies.
• DO NOT use electrical appliances inside the appliance
(e.g. heaters, ice cream makers, etc.)
• DO NOT allow oil or fat to come into contact with the plastic
components or door seal. Clean immediately if contact occurs.
• DO NOT store products on top of the appliance.
• Bottles that contain a high percentage of alcohol must be
sealed and placed vertically in the refrigerator.
• Always carry, store and handle the appliance in a vertical
position and move by holding the base of the appliance
• Always switch off and disconnect the power supply to the unit
before cleaning.
• Keep all packaging away from children. Dispose of the
packaging in accordance with the regulations of local
authorities.
• If the power cord is damaged, it must be replaced by a POLAR
agent or a recommended qualified technician in order to avoid
a hazard.
CC611-CC666_ML_A5_v6_20180125.indb 2 2018/1/25 17:31

3
UK
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience or knowledge, unless they have been
given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play
with the appliance.
• Polar recommend that this appliance is PAT tested on an
annual basis to ensure the product remains safe.
Caution Risk of Fire
• Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
Warning: Keep all ventilation openings clear of
obstruction. Unit should not be boxed in without
adequate ventilation.
• Warning: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Warning: Do not damage the refrigerant circuit.
• Warning: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are the
type recommended by the manufacturer.
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of
this machine will provide the best possible performance from your POLAR product.
Pack Contents
• POLAR Counter-Top Refrigerated Merchandiser
• Shelves x 2 • Instruction manual
POLAR prides itself on quality and service, ensuring that at the time of packaging the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your POLAR dealer immediately.
CC611-CC666_ML_A5_v6_20180125.indb 3 2018/1/25 17:31

4
UK
Installation
Note: If the unit has not been
stored or moved in an upright
position, let it stand upright for
approximately 12 hours before
operation. If in doubt allow to
stand.
1. Remove the appliance from the packaging.
Make sure that all protective plastic film and
coatings are thoroughly removed from all
surfaces.
2. Maintain a distance of 20cm (7 inches)
between the unit and walls or other objects for
ventilation. NEVER LOCATE NEXT TO OR
NEAR A HEAT SOURCE.
Note: Before using the appliance
for the first time, clean the
shelves and interior with soapy
water.
Operation
Control Panel
The control panel is located below the doors on the
rear of the appliance.
Turn On
1. Close the doors of the appliance
2. Connect the appliance to a mains power supply
3. Press the button to turn the light On or Off
as required.
Setting the Operating Temperature
1. Press the SET button. The display will flash
2. Press the or buttons to display the
required temperature.
3. Press the SET button to store the temperature
Table of Controller Parameters
The operating parameters of this appliance have been preset for optimum performance and to maximise
the life of the appliance
Display Parameter Preset Value Range
E1 Lower set temperature 2°C -20°C to 2°C
E2 Upper set temperature 6°C 2°C to 45°C
E3 Temperature buffer 4°C 1°C to 10°C
E4 Temperature buffer time delay 3 minutes 0 to 10 minutes
E5 Fixed parameter 0 DO NOT CHANGE
E6 Fixed parameter 00 DO NOT CHANGE
F1 Defrost period 25 minutes 1 to 60 minutes
F2 Defrost interval 6 hours 1 to 24 hours
F3 Defrost temperature 20°C 0°C to 22°C
F4 Centigrade/Fahrenheit 0°C °C/°F
CC611-CC666_ML_A5_v6_20180125.indb 4 2018/1/25 17:31

5
UK
Should the parameter need adjusting:
1. Press and hold the SET button for six seconds. The “E1” parameter is displayed
2. Press the or buttons until the required value is displayed
3. Press the SET button to store the new value and cycle to the next parameter
NOTE: The controller times out after 10 seconds if no buttons are pressed
Manual Defrost:
Press and hold the button for 6 seconds to begin automatic defrost. The defrost light illuminates
Storing Food
To get the best results from your POLAR appliance, follow these instructions:
• Only store foodstuffs in the appliance when it has reached the correct operating temperature.
• Do not place uncovered hot food or liquid inside the appliance.
• Wrap or cover food where possible.
• Do not obstruct the fans/vents inside the appliance.
• Avoid opening the doors for prolonged periods of time.
Cleaning, Care & Maintenance
• Switch off and disconnect from the power supply before cleaning.
• The doors can be removed for ease of cleaning.
• Clean the interior of the appliance as often as possible.
• Do not use abrasive cleaning agents. These can leave harmful residues.
• Clean the door seal with warm soapy water.
• Always wipe dry after cleaning.
• Do not allow water used in cleaning to run through the drain hole into the evaporation pan.
• A POLAR agent or qualified technician must carry out repairs if required.
Replacing the Interior Lamp
WARNING: Allow the lamp to cool before replacing. The lamp remains hot
immediately after use.
1. Turn Off and disconnect the appliance from the mains power supply.
2. Remove the lamp by twisting it from the lamp sockets.
3. Insert the new lamp and twist into place.
Cleaning the Condenser
Periodically cleaning the condenser can extend the life of the appliance.
POLAR recommend that a POLAR agent or qualified technician clean the condenser.
CC611-CC666_ML_A5_v6_20180125.indb 5 2018/1/25 17:31

6
UK
Troubleshooting
If your POLAR appliance develops a fault, please check the following table before making a call to the
Helpline or your POLAR dealer.
Fault Probable Cause Solution
The appliance is not
working The unit is not switched on Check the unit is plugged in correctly and switched on
Plug and lead are damaged Call POLAR agent or qualified Technician
Fuse in the plug has blown Replace the fuse
Power supply Check power supply
Internal wiring fault Call POLAR agent or qualified Technician
The appliance
turns on, but the
temperature is too
high/ low
Too much ice on the condenser Defrost the appliance
Condenser blocked with dust Call POLAR or qualified technician
Doors are not shut properly Check doors are shut and seals are not
damaged
Appliance is located near a heat
source, in the direct sunlight or
air flow to the condenser is being
interrupted
Move the refrigerator to a more suitable
location
Ambient temperature is too high Increase ventilation or move appliance to a
cooler position
Unsuitable foodstuffs are being
stored in the appliance Remove any excessive hot foodstuffs or blockages to fan
Appliance is overloaded Reduce the amount of food stored in the
appliance
Factory default parameters adjusted Call POLAR or qualified technician
The appliance is
leaking water The appliance is not properly levelled Adjust the screw feet to level the appliance (if applicable)
The appliance is
unusually loud Loose screw/nut Check and tighten all nuts and screws
The appliance has not been installed
in a level or stable position Check installation position and change if necessary
The display lamp
does not illuminate Lamp needs replacing Call POLAR or qualified technician
Light not turned on Ensure Light button has been pressed
properly
Door does not shut Dirt/obstacle in runners Clean runners
CC611-CC666_ML_A5_v6_20180125.indb 6 2018/1/25 17:31

7
UK
Technical Specifications
Model Voltage Power
(W) Current (A) Temperature Range Capacity (Litres) Refrigerant Dimensions H x W x D mm Weight (kg)
CC611
CC611 230V 50Hz 160 1.3 2-12°C 100 R600a (48g) 675 x 682 x 450 39.1
Electrical Wiring
POLAR appliances are supplied with a 3 pin, moulded, BS1363 plug and lead, with a 13 amp fuse as
standard.
The plug is to be connected to a suitable mains socket.
POLAR appliances are wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Disposal
EU regulations require refrigeration product to be disposed of by specialist companies who remove or
recycle all gasses, metal and plastic components.
Consult your local waste collection authority regarding disposal of your appliance. Local authorities are
not obliged to dispose of commercial refrigeration equipment but may be able to offer advice on how to
dispose of the equipment locally.
Alternatively call the POLAR helpline for details of national disposal companies within the EU.
Compliance
The WEEE logo on this product or its documentation indicates that the product must
not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and
environmentally safe recycling process. For further information on how to dispose of
this product correctly, contact the product supplier, or the local authority responsible for
waste disposal in your area.
POLAR parts have undergone strict product testing in order to comply with regulatory
standards and specifications set by international, independent, and federal authorities.
POLAR products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of POLAR.
Every effort is made to ensure all details are correct at the time of going to press, however, POLAR reserve the right to
change specifications without notice.
CC611-CC666_ML_A5_v6_20180125.indb 7 2018/1/25 17:31

8
NL
Veiligheidstips
• Plaatsen op een vlakke en stabiele ondergrond.
• De installatie en eventuele reparaties zijn door een
servicetechnicus/vaktechnicus uit te voeren. Verwijder geen
componenten of servicepanelen van dit product.
• Raadpleeg en volg de plaatselijke en nationale regelgeving op
m.b.t. tot het volgende:
- Wetgeving van gezondheid en veiligheid op de werkplaats
- Werkregels
- Brandpreventie
- IEE bekabelingsnormen
- Bouwverordeningen
• Dit product NIET reinigen met spuit-/drukreinigers.
• Dit apparaat NIET buitenshuis gebruiken
• Gebruik het product NIET voor het opbergen van medische
producten
• In dit product GEEN elektrische apparaten gebruiken (zoals
bijv. verwarmers, ijsmakers, etc.)
• Laat NIET toe dat olie of vet in contact komt met plastic
componenten of deurafdichtingen. Onmiddellijk reinigen indien
dit wel gebeurt
• GÉÉN producten bovenop het apparaat neerzetten
• Flessen met en hoog alcoholpercentage moet goed worden
gesloten en verticaal in de koelkast worden bewaard
• Dit product altijd in een verticale positie vervoeren, opbergen
en gebruiken. Het product verplaatsen door de basis van het
apparaat vast te houden
• Alvorens dit apparaat te reinigen dient men altijd de
stroomvoorziening uit te schakelen
• Laat verpakkingsmateriaal niet binnen handbereik van kinderen.
Verpakkingsmateriaal in overeenstemming met de regelgeving
van de plaatselijke overheden als afval laten verwerken
• Indien de stroomkabel beschadigd raakt, dient men deze door
een POLAR technicus of aanbevolen vaktechnicus te laten
vervangen om gevaarlijke situaties te voorkomen
CC611-CC666_ML_A5_v6_20180125.indb 8 2018/1/25 17:31

9
NL
• Dit apparaat is niet bedoeld voor gebruik door personen met
lichamelijke, zintuigijike of mentale beperkingen (inclusief
kinderen) of met gebrek aan ervaring of kennis tenzij zij
hierin worden begeleid of zijn opgeleid in het gebruik van het
apparaat door een persoon, die verantwoodelijk is voor hun
veiligheid.
• Men dient er toezicht op te houden dat kinderen niet met het
apparaat spelen.
• Polar beveelt aan dat dit apparaat jaarlijks PAT getest wordt
om ervoor te zorgen het product veilig blijft.
Voorzichtig Risico van Fire
• Laat explosieve stoffen niet opslaan: zoals spuitbussen
met een ontvlambare drijfgas in dit apparaat.
Waarschuwing: Hou alle ventilatieopeningen vrij
van obstakels. De eenheid mag niet ingesloten
worden zonder geschikte ventilatie.
• Waarschuwing: Gebruik geen mechanische apparaten of
andere middelen te gebruiken om het ontdooien , andere dan
de door de fabrikant aanbevolen versnellen
• Waarschuwing: niet damge het koelcircuit
• Waarschuwing: Gebruik geen elektrische apparaten binnen
het voedsel opslag comnpartments van het apparaat, tenzij ze
het type aanbevolen door de fabrikant
Inleiding
Neem de tijd en lees deze handleiding aandachtig door. Een correct gebruik en onderhoud van deze
machine waarborgt de beste prestatie van uw POLAR product.
Verpakkingsinhoud
• Gekoelde toonbankdisplay POLAR
• Lades x 2 • Handleiding
POLAR is trots op de haar productkwaliteit en dienstverlening en controleer de inhoud van de
verpakkingen, tijdens de verpakkingsfase, op functionaliteit en schade.
Mocht u product door transport zijn beschadigd, neem dan onmiddellijk contact op met uw POLAR dealer.
CC611-CC666_ML_A5_v6_20180125.indb 9 2018/1/25 17:31

10
NL
Installatie
Opmerking: indien het apparaat
niet in een rechtopstaande
positie is opgeslagen of
vervoerd, dient men het
product 12 uur vóór gebruik
in de rechtopstaande positie
te plaatsen. Bij twijfel dient
men het product in een
rechtopstaande positie te
plaatsen.
1. Haal het product uit de verpakking. Zorg ervoor
dat u de beschermingsfolie en -lagen van alle
oppervlakken heeft verwijderd.
2. Voor een adequate ventilatie dient men een
afstand van 20cm aan te houden tussen dit
product of muren en andere objecten. NOOIT
PLAATSEN NAAST OF DICHTBIJ EEN
HITTEBRON.
OPMERKING: Voor het eerste
gebruik, dient men de planken
en de binnenkant van het
apparaat met warm zeepwater
te reinigen, en vervolgens goed
te spoelen.
Bediening
Bedieningspaneel
Het bedieningspaneel bevindt zich onder de deuren
aan de achterzijde van het apparaat.
Inschakelen
1. Sluit de deuren van het apparaat
2. Sluit het apparaat aan op de stroomvoorziening
3. Druk op de knop om de verlichting naar
wens aan of uit te schakelen
Werktemperatuur instellen
1. Druk op de SET knop. Het display knippert
2. Druk op de of knoppen om de vereiste
temperatuur weer te geven
3. Druk op de SET knop om de
temperatuurwaarde op te slaan
Tabel van bedieningsparameters
De werkparameters van dit apparaat zijn reeds ingesteld voor optimale prestatie en om de levensduur
van het apparaat te maximaliseren.
Display Parameter Preset waarde Bereik
E1 Laagste temperatuur 2°C -20°C tot 2°C
E2 Hoogste temperatuur 6°C 2°C tot 45°C
E3 Temperatuurbuffer 4°C 1°C tot 10°C
E4 Tijdsvertraging temperatuurbuffer 3 minuten 0 tot 10 minuten
E5 Vaste parameter - NIET WIJZIGEN
E6 Vaste parameter - NIET WIJZIGEN
F1 Ontdooiperiode 25 minuten 1 tot 60 minuten
F2 Ontdooi-interval 6 uur 1 tot 24 uur
F3 Ontdooitemperatuur 20°C 0°C tot 22°C
F4 Celsius/Fahrenheit 0°C °C/°F
CC611-CC666_ML_A5_v6_20180125.indb 10 2018/1/25 17:31
