Polar Refrigeration CG841-A User manual

Model:
CG841-A
Deli Showcase
Instruction manual
CG841-A_A5_v1_20190117.indb 1 2019/1/17 14:42

2
AU Telephone Helpline: 1300225960
Safety Tips
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- Fire Precautions
- Wiring Regulations
- Building Regulations
• DO NOT immerse the appliance in water, or use jet/pressure
washers to clean the appliance.
• Do not store explosive substances such as aerosol cans with a
flammable propellant inside the appliance.
• Do not use the appliance for anything other than its intended
use.
• Always switch off and disconnect the power supply to the
appliance when not in use.
• Not suitable for outdoor use.
• Keep all packaging away from children. Dispose of the
packaging in accordance to the regulations of local authorities.
• If the power cord is damaged, it must be replaced by a POLAR
agent or a recommended qualified technician in order to avoid
a hazard.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play
with the appliance.
• Polar recommend that this appliance is PAT tested on an
annual basis to ensure the product remains safe.
CG841-A_A5_v1_20190117.indb 2 2019/1/17 14:42

3
AU
Telephone Helpline: 1300225960
Caution Risk of Fire
• Do not store explosive substances such as aerosol cans
with a flammable propellant in this appliance.
Warning: Keep all ventilation openings clear of
obstruction. Unit should not be boxed in without
adequate ventilation.
• Warning: Do not use mechanical devices or other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Warning: Do not damage the refrigerant circuit.
• Warning: Do not use electrical appliances inside the food
storage compartments of the appliance, unless they are the
type recommended by the manufacturer.
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of
this machine will provide the best possible performance from your POLAR product.
Pack Contents
The following is included:
• POLAR Deli Showcase
• Instruction Manual
POLAR prides itself on quality and service, ensuring that at the time of packaging the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your POLAR dealer immediately.
Installation
Note: If the appliance has been stored or moved in a non-vertical position, stand
it in an upright position for approximately 12 hours before operation. If in doubt
allow to stand.
1. Remove the appliance from the packaging and remove the protective film from all surfaces.
2. When positioning, maintain a distance of 20cm (7 inches) between the appliance and walls or other
objects for ventilation. NEVER LOCATE NEXT TO OR NEAR A HEAT SOURCE.
Note: Maximum load of shelves is 15kg.
Note: Before using the appliance for the first time, clean the shelves and interior
with soapy water.
CG841-A_A5_v1_20190117.indb 3 2019/1/17 14:42

4
AU Telephone Helpline: 1300225960
Operation
Control Panel
The control panel is located below the doors on the rear of the appliance.
Refrigerant LED is on. Compressor is
running Light button
Defrost LED is on. Unit is defrosting,
compressor is not running SET Set button
Up Button I/O On / Off
Down Button
Turn On
1. Close the door(s) of the appliance.
2. Ensure the power switch is set to [O] and turn on at the socket.
3. Switch on the Power [I].
Adjusting the Temperature
1. Press SET button. The set temperature is displayed.
2. Press up button or down button to change set temperature.
3. Press SET button to exit.
Display Lighting
Press Light button to switch internal display lighting ON / OFF.
Manual Defrost
1. To start manual defrost press the Light button and hold for 6 seconds.
2. To stop manual or automatic defrost press the Light button and hold for 6 seconds.
CG841-A_A5_v1_20190117.indb 4 2019/1/17 14:42

5
AU
Telephone Helpline: 1300225960
Cleaning, Care & Maintenance
Switch off and disconnect from the power supply before cleaning
• The doors can be removed for ease of cleaning
• Clean the interior of the appliance as often as possible
• Do not use abrasive cleaning agents. These can leave harmful residues
• Clean the door seals with warm soapy water
• Always wipe dry after cleaning
Cleaning the Condenser
Periodic cleaning of the Condenser can extend the life of the appliance, POLAR recommend that a POLAR
agent or qualified technician clean the condenser.
Troubleshooting
If the machine malfunctions due to causes other than those listed or the proposed corrective actions do
not solve the problem please call a Polar agent or qualified technician.
Fault Probable Cause Solution
The appliance is not
working
The unit is not switched on Check the unit is plugged in correctly and
switched on
Plug and lead are damaged Call POLAR agent or qualified Technician
Fuse in the plug has blown Replace the fuse
Power supply Check power supply
Internal wiring fault Call POLAR agent or qualified Technician
The appliance is not
cooling
Coolant Leak Call POLAR agent or qualified technician
Fan Motor Failed Call POLAR agent or qualified technician
Airflow to the condenser
obstructed
Increase the gap between appliance and
obstacles/heat source
Condenser is clogged Call POLAR agent or qualified technician
The Light does not
work
Bulb has blown Call POLAR agent or qualified technician
CG841-A_A5_v1_20190117.indb 5 2019/1/17 14:42

6
AU Telephone Helpline: 1300225960
Technical Specifications
Model Voltage Power (W) Current (A) Capacity
(Litres) Refrigerant
CG841-A 220-240V~ 50Hz 480 2.75 295 R290
Dimensions
H x W x D mm
Weight
(kg) Climate Class
1220 x 915 x 675 120 4
Electrical Wiring
The plug is to be connected to a suitable mains socket.
POLAR appliances are wired as follows:
• Live wire (coloured brown) to terminal marked L
• Neutral wire (coloured blue) to terminal marked N
• Earth wire (coloured green/yellow) to terminal marked E
This appliance must be earthed.
If in doubt consult a qualified electrician.
Electrical isolation points must be kept clear of any obstructions. In the event of any emergency
disconnection being required they must be readily accessible.
Compliance
The product must not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and environmentally safe
recycling process. For further information on how to dispose of this product correctly, contact the product
supplier, or the local authority responsible for waste disposal in your area.
POLAR parts have undergone strict product testing in order to comply with regulatory
standards and specifications set by international, independent, and federal authorities.
POLAR products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of POLAR.
Every effort is made to ensure all details are correct at the time of going to press, however, POLAR reserve the right to
change specifications without notice.
CG841-A_A5_v1_20190117.indb 6 2019/1/17 14:42

DECLARATION OF CONFORMITY
Equipment Type
Deli Display - Curved Glass 915mm
Model
CG841-A
Legislation
Electrical Safety
Electromagnetic Compatibility
Standards
EN 60335-1:2012 +A11:2014
EN 60335-2-89: 2010
EN 62233:2008
EN 55014-1:2006 + A1:2009 +A2:2011
EN 55014-2:2015
EN 61000-3-2:2014
EN 61000-3-3:2013
Producer Name
Polar
Producer Address
15 Badgally Road,
Campbelltown,
NSW 2560
I, the undersigned, hereby declare that the equipment specified above conforms to the above Legislation and Standard(s).
Date
4th January 2019
Signature
Full Name
Ashley Hooper
Position
Technical & Quality Manager/ Responsible Supplier
CG841-A_A5_v1_20190117.indb 7 2019/1/17 14:42
