Polaris P93 User manual

9400
OWNER’S MANUAL
ENGLISH |FRANÇAIS |
AVERTISSEMENT
POUR VOTRE SÉCURITÉ – Pour toute opération autre que l’entretien de routine et la maintenance décrite dans
ce manuel, ce produit doit être pris en charge par une entreprise qui est autorisée et qualifiée pour la réparation
des équipements de piscine par la juridiction où le dit produit est installé lorsque de telles exigences locales
ou provinciales sont édictées. Si aucune exigence locale ou provinciale n’est disponible, l’agent d’entretien
doit être un professionnel avec suffisamment d’expérience dans l’installation et la maintenance d’équipement
de piscine pour appliquer correctement les consignes du présent manuel. L’installation ou l’utilisation
inappropriée annulera la garantie.
WARNING
FOR YOUR SAFETY - For anything other than the routine cleaning and maintenance described in this
manual, this product must be serviced by a contractor who is licensed and qualified in pool equipment by the
jurisdiction in which the product will be installed where such state or local requirements exist. In the event no
such state or local requirement exists, the maintainer must be a professional with sufficient experience in pool
equipment installation and maintenance so that all of the instructions in this manual can be followed exactly.
Improper installation and/or operation will void the warranty.
P93
P94
H0371400 Rev A

Page 2
THANK YOU FOR PURCHASING THE POLARIS®P93 P94 CLEANER.
YOUR POLARIS ROBOTIC CLEANER HAS BEEN DESIGNED AND MANUFACTURED TO BE EASILY INSTALLED
AND TO PROVIDE LOW MAINTENANCE OPERATION. PRIOR TO INSTALLING YOUR NEW POLARIS CLEANER,
PLEASE DO THE FOLLOWING:
1) Complete and return the warranty card.
2) Record your purchase information on the spaces provided below.
3) Attach your invoice (or a copy) to this page.
Taking these steps will help ensure prompt warranty service, should it be required. If service is required, please
contact your original dealer. If the original dealer does not perform warranty service, please visit
www.polarispool.com to locate an independent service company near you. If you are unable to locate a service
company, please call our Technical Support department at 800-822-7933.
RECORD YOUR POLARIS CLEANER DATA HERE:
Date of Purchase Purchased From Serial Number:
(located on machine head)
City State Zip Code
Table of Contents
Section 1. Important Safety Instructions........ 3
Section 2. Cleaner Specications................... 5
2.1 GeneralSpecications ....................................... 5
Section 3. Assembly and Initial Usage........... 5
3.1 Unpacking .......................................................... 5
3.2 Assembling the Transport Caddy ....................... 5
3.3 Connecting the Control Unit to the Caddy.......... 7
Section 4. Operation......................................... 8
4.1 Submerging the Cleaner .................................... 8
4.2 Operating the Cleaner ........................................ 9
Section 5. Cleaning and Maintenance .......... 10
Section 6. Replacement Parts ....................... 13
Section 7. Troubleshooting ........................... 14
English

Page 3
WARNING
Failure to comply with the following warnings can result in permanent injury, electrocution or drowning.
PREVENT ELECTRICAL SHOCK
To reduce risk of electrical shock:
• Connect unit to receptacle protected by a ground fault circuit interrupter (GFCI). Such a GFCI receptacle should
be provided by a qualified installer and should be tested on a routine basis. To test the GFCI, push the test
button. The GFCI should interrupt power. Push the reset button. Power should be restored. If the GFCI fails to
operate in this manner, the GFCI is defective. If the GFCI interrupts power to the pump without the test button
being pushed, a ground current is flowing, indicating the possibility of an electric shock. Do not use this product.
Disconnect the cleaner and have the problem corrected by a qualified service representative before using.
• Per the United States National Electric Code (NEC®), keep the control unit at least five (5) feet from the edge of
the (pool/spa) water. In Canada, the Canadian Electrical Code (CEC®) requires a minimum distance of 3m (10
ft.) to be maintained between the pool edge and the control unit. Never submerge the control unit.
• Do not enter pool while the Polaris P93 P94 is in water.
• Do not bury cord. Locate cord so as to prevent it from being damaged by lawn mowers, hedge trimmers and
other equipment.
• To reduce the risk of electrical shock, do not use the Polaris P93 P94 robotic cleaner or control unit if the cord is
worn or damaged. Contact Zodiac Pool Systems, Inc. Technical Support immediately for a replacement cord.
• Double insulation—For continued protection against possible electric shock, use only identical replacement parts
when servicing. Do not attempt repair of the Polaris P93 P94 robotic cleaner, control unit, power cord, or floating
cable.
• NEVER OPEN CONTROL UNIT.
• Do not use an extension cord to connect the unit to electric supply; provide a properly located outlet. The control
unit should be placed near the outlet box.
PREVENT CHILD INJURY AND DROWNING
• To reduce the risk of injury, do not permit children to operate this product.
• Do not let anyone, especially small children, sit, step, lean, or climb on any equipment installed as part of your
pool’s operational system.
Section 1. Important Safety Instructions
Congratulations on purchasing the Polaris P93 P94 Robotic Cleaner. Please take a moment to read through the entire
manual before installing your new robotic pool cleaner. Your cleaner must be installed and operated as specified.
READ AND FOLLOW ALL INSTRUCTIONS
English

Page 4
SAVE THESE INSTRUCTIONS
English
CAUTION
Failure to comply with the following warnings could cause damage to pool equipment or
personal injury.
• The Polaris P93 P94 must be installed and operated as specified.
• This product is intended for use with permanently-installed pools. Do not use with storable pools. A
permanently-installed pool is constructed in or on the ground or in a building such that it cannot be readily
disassembled for storage. A storable pool is constructed so that it is capable of being readily disassembled for
storage and reassembled to its original integrity.
• Turn the Polaris P93 P94 off before removing it from water, and do not operate out of water.
• Do not remove the cleaner from the pool for 15 minutes after the cleaning cycle has completed.
• Clean the filter canister in the Polaris P93 P94 after each use.
• Donotusetheproductinyourpoolifthewatertemperatureisabove95˚F(35˚C)orbelow55˚F(13˚C).
CAUTION
USE OF THE POLARIS P93 P94 ROBOTIC CLEANER IN A VINYL LINER POOL
Certain vinyl liner patterns are particularly susceptible to rapid surface wear of pattern removal caused by
objects coming into contact with the vinyl surface, including pool brushes, pool toys, floats, fountains, chlorine
dispensers, and automatic pool cleaners. Some vinyl liner patterns can be seriously scratched or abraded
simply by rubbing the surface with a pool brush. Ink from the pattern can also rub off during the installation
process or when it comes into contact with objects in the pool. Zodiac Pool Systems, Inc., is not responsible
for, and the Limited Warranty does not cover, pattern removal, abrasion or markings on vinyl liners.

Page 5
Section 2. Cleaner
Specications
2.1 General Specifications
The general specifications for the cleaner are as follows:
Check that the unit has not been damaged during
transport. If you detect damage, contact Zodiac Pool
Systems, Inc. at 1-800-822-7933 before using your
cleaner.
To unpack the cleaner and its components:
1. Remove the lower portion of the caddy along
with the upper and lower power cable hooks,
control unit hook, power cable hook plate,
locking plate, nuts, bolts and screws.
2 Remove the small box that contains the control
unit.
3. Remove the handles (left and right) of the
caddy, which are located against one side of the
box.
4. Remove the cleaner from the box.
3.2 Assembling the Transport Caddy
1. Insert the upper tubes (handles) into the bottom
tubes on the cart as shown in Figure 2. Make
sure the upper tubes (handles) are in the proper
orientation and align the screw holes.
Figure 1. Components
Figure 2. Install the Handles
X4
X4 X2
X4
X4
X2
X1
X1 X1
X1
X1
X1
1
Control box
supply voltage
100-125 VAC, 60 Hz
Supply voltage 30 V DC
Installed load 150 W max
Cable length 60 ft (18 m)
Cleaner size (WxDxH)
16.9 x 18.9 x 10.6 in.
43 x 48 x 27 cm
Pack size
(WxDxH)
22.8 x 22.8 x 23.2 in.
58 x 58 x 59 cm
Weight of Cleaner 21 lbs. (9.5 kg)
Packed weight 42 lbs. (19 kg)
Filtration less than 100 microns
Cycle lengths 1.30 hrs, 2.30 hrs.
The cleaner is a double-insulated product. A double-
insulated electrical appliance is one which has been
designed in such a way that it does not require a safety
connection to ground. The basic requirement for
double-insulation is that no single failure can result
in dangerous voltage becoming exposed so that it
might cause an electric shock and that this is achieved
without relying on an earthed (grounded) metal casing.
This is achieved by having two (2) layers of insulating
material surrounding live parts or by using reinforced
insulation. Therefore, devices having double-insulated
construction, such as this cleaner, do not utilize a
grounded (three-prong) cord/plug.
Section 3. Assembly and Initial
Usage
3.1 Unpacking
The packaging should contain the following items
(Refer to Figure 1):
• Polariscleaner
• Controlunit
• Transportandstoragecaddy(completewith
assembly components)
English

Page 6
2. Position the bottom power cable hook as shown
in Figure 3. Place the cable hook plate opposite
the power cable hook. Secure using a screw and
tightening with the Torx®wrench.
Refer to Figure 4.
8
Figure 7. Install the Power Cable Hook and
Control Unit Hook
9
Figure 8. Secure the Hooks
3
2
Figure 3. Position the Bottom Power Cable Hook
Figure 6. Position the Bottom Power Cable Hook
4
Figure 4. Secure the Bottom Power Cable Hook
5
Figure 5. Secure the Cable Hook Plate
3. Secure the cable hook plate using two (2) bolts
and two (2) nuts and tighten with Torx wrench.
Refer to Figure 5.
4. Position the power cable hook and control unit
hook on the upper tubes as shown in Figure 6.
Make sure the upper tubes (handles) are in the
proper orientation.
5. Secure the power cable hook and control unit
hook around the tubes using a screw and hand
tighten with the Torx wrench (supplied with
unit). Refer to Figure 7.
6. Secure the control unit hook using two (2) bolts
and two (2) nuts and tighten with Torx wrench.
Refer to Figure 8.
6
7
English

Page 7
3.3 Connecting the Control Unit to the
Caddy
1. Position the control unit over the control unit
hook on the caddy.
2. Slide the locking plate clips into the control
hook and line up the screw holes. Refer to
Figure 13.
3. Secure the locking plate using Phillips head
screws. Do not overtighten. Refer to Figure 14.
1
Figure 13. Position the Locking Plate Clips
Figure 10. Attaching the Support Blocks
(Polaris P93)
Figure 11. Attaching the Support Blocks
(Polaris P94)
2
Figure 14. Secure the Locking Plate
7. Place two (2) caps on the wheels as shown in
Figure 9.
x4
x4
9. The transport caddy is now ready to use as
shown in Figure 12.
Figure 12. Transport and Storage Caddy Assembled
8. Attach the support blocks to the caddy using
four (4) screws as shown in Figures 10 and 11.
For the Polaris P93, see Figure 10 for
orientation and positioning of the blocks, and
for the Polaris P94, see Figure 11
Figure 9. Attaching Wheel Caps
English

Page 8
2. Ensure the unit sinks to the bottom of the pool.
Refer to Figure 17.
2
Figure 17. Cleaner Sinking to the Bottom of the Pool
Figure 18. Spread Floating Cable Over the Pool
1
Figure 16. Submerge the Cleaner Vertically
Section 4. Operation
4.1 Submerging the Cleaner
1. Submerge the cleaner in the pool and remove
any air trapped inside by keeping the unit
vertical. Refer to Figure 16.
3. Spreadouttheoatingcableoverthepool,
ensuring there are no kinks or coils in the cable.
Refer to Figure 18.
English
3.4 Electrical Connection
WARNING
Failure to comply with the following warnings can
result in permanent injury, electrocution or drowning.
PREVENT ELECTRICAL SHOCK
• U.S.: Per NEC® requirements, keep the control
unit at least five (5) ft. (1.5 m) from the edge of the
pool. CANADA: Per CEC® requirements, keep
the control unit at least three (3) m (10 ft.) from the
edge of the pool.
• Only connect the control unit to a receptacle
protected by a ground fault circuit interrupter
(GFCI). Contact a certified electrician if you cannot
verify that the receptacle is protected by a GFCI.
• Do not use an extension cord to connect the control
unit.
• Do not allow anyone to swim while the cleaner is in
the pool.
For your safety and to obtain the best possible
performance from your cleaner, connect the cleaner’s
oatingcabletothecontrolunitandthreadconnector
until it is snug. Do not overtighten. Refer to Figure 15.
The control unit is equipped with an automatic shut
off feature to prevent overheating if operated in direct
sunlight for an extended period of time.
WARNING
The control unit is water-resistant, not waterproof. In
order to prevent electrocution, which could result in
serious injury or death, never submerge the control
unit or leave exposed to inclement weather.
Figure 15. Electrical Connection
2
1
Power Supply
Connector
Floating Cable

Page 9
Figure 19. Start the Cleaner
2. When the cycle program button is selected the
indicator light will illuminate. The cleaner will
start in a few seconds.
3. To change the selected cleaning cycle, press the
new cycle button and the new cycle will start in
a few seconds.
4. If you wish to stop the cleaner during a cleaning
cycle, press the OFF button. Refer to Figure 20.
5. At the end of the cycle, the cleaner will stop and
after15minutesthelightwillashslowlyto
indicate the cycle is completed.
Figure 20. Turn Cleaner Off
6. The cleaner includes a safety feature that
automatically stops the cleaner after about 20
seconds if it is powered on but not submerged
in water. For pools equipped with a beach area,
this safety feature allows the cleaner to reverse,
and back into the pool when the impeller is out
of the water.
7. Disconnect the control unit cable from the
electrical outlet.
8. Disconnect the cable from the control unit.
NOTE The cleaner cable must always be disconnected
before removing the cleaner from the pool.
4.2 Operating the Cleaner
CAUTION
To prevent damage to the cleaner, be sure to adhere
to the following guidelines:
• Do NOT remove the cleaner from the pool for 15
minutes after the cleaning cycle ends.
• Approximately 15 minutes after the cycle is
completed, the light located on the control unit
will flash slowly to indicate that the cleaner may
be removed from the pool. The 15 minute period
allows the motor to cool and will prevent damage to
the cleaner.
• Remove the cleaner from the pool after the
cleaning cycle is completed and store on the caddy
out of direct sunlight or inclement weather.
• Never lift the cleaner out of the pool by the floating
cable. Always use the handle to remove it from the
pool (refer to Figures 21 and 22).
• Take additional care when lifting the cleaner out of
the pool. It becomes heavier when filled with water.
• Remove the cleaner from pool when super
chlorinating or adding acid.
• Do not handle cleaner while it is in operation.
NOTE Always make sure the cleaner head is fully
submerged in the water before you begin the
operation cycle.
When the cleaner is powered ON it will remain in
standby until one of the cycle program selection buttons
is pressed. Select either the Cycle I or Cycle II cleaning
program on the control unit:
Cycle I Program Cycle II Program
Completed in 1.5hours Completed in 2.5 hours
Maximum coverage in
minimal time
Intensive and complete
cleaning
Thorough pool floor
cleaning
Thorough pool floor and
wall cleaning
1. To start your cleaner, press the desired cycle
button (Figure 19). "Cycle I" is the most
commonly selected cleaning program for
inground pools.
English

Page 10
Section 5. Cleaning and
Maintenance
WARNING
To avoid electric shock and other hazards which
could result in permanent injury or death, disconnect
(unplug) the cleaner from the power source before
performing any cleaning and maintenance.
5.1 Cleaning the Filter Canister
Theltercanistershouldbecleanedattheendofeach
cycle.
1. Ensure that the control unit cable has been
disconnected from the electrical outlet or that
theoatingcablehasbeendisconnectedfrom
the control unit.
2. Remove the cleaner from the water and let
the remaining water drain by maintaining the
cleaner in the vertical position.
3. Set the unit on its wheels.
4. Toremovethelterfromthecleaner,followthe
steps 5 through 8 (Figures 23 through 26).
5. Push the cover lock (1) and lift the cover (2)
until it is secured in the vertical position. Refer
to Figure 23.
2
1
Figure 23. Lift Cleaner Cover
9. Remove the cleaner from the pool using the
handle (refer to Figures 21 and 22). Never lift
thecleaneroutofthepoolbytheoatingcable.
10. Loosely coil the cable starting at the cleaner and
go toward the connection point at control unit.
Remove any twists along the way. Store the
cable by wrapping it around the hooks located
at the rear of the caddy.
1
2
Figure 21. Remove Cleaner From Pool
3
Figure 22. Keep Cleaner Vertical to Drain Water
English
IMPORTANT
• Use your cleaner as often as needed to keep your
pool clean.
• Clean the filter canister after each cleaning cycle.
• Do not leave your cleaner in the pool on a
permanent basis.
• At the end of each cycle, remove the cleaner from
the pool. Start at the cleaner head and untangle
any coils in the cable before storing the cleaner.

Page 11
Figure 27. Wash Filter Canister
7
5.2 Cleaning and Storing the Cleaner
The cleaner must be cleaned regularly using slightly
soapy clean water, do not use solvents such a
trichloroethylene or its equivalent. Rinse the cleaner
generously using clean water. Do not let your cleaner
dry in direct sunlight near the pool. The cleaner must be
stored on its own caddy, so that it dries quickly.
1. Place the rear wheels on the caddy side wedges
as shown in Figure 28.
1
Figure 28. Position Cleaner on Caddy
2. Roll the unit into place onto the caddy. Refer to
Figure 29.
6. Removethelterassemblyfromthebody(3),
as shown in Figure 24.
3
Figure 24. Remove Filter Assembly
7. Push the quick release button on the canister
assembly(4)andpullopenthelterassembly
(5). Refer to Figure 25.
4
5
Figure 25. Open Filter Assembly
8. Separatetheltercanisterfromthelter
support (6), as shown in Figure 26.
6
Figure 26. Remove Filter Canister
9. Emptyalldebrisfromtheltercanister,then
rinsethecanister,theltersupport,andthe
cleaner under water or using a hose.
Refer to Figure 27.
English

Page 12
English
Figure 29. Roll Cleaner onto Place on the Caddy
2
5.3 Replacing the Brushes
ThecleaneristtedwithPVCbrushes.Thereare
''wear'' indicators on the brushes. To maintain cleaner
performance at its best you need to replace the brushes
as soon as one of the wear indicators has been reached
(even if the blade wear is not even). It is recommended
that you replace the brushes every two (2) years.
1. Lift the cleaner to a vertical position so that the
handle is up. Refer to Figure 30.
1
Figure 30. Cleaner in Upright Position
2. Separate the edges of the brush and undo the
tabs as shown in Figure 31. Remove the worn
brushes.
2
Figure 31. Undo the Tabs of the Brush
3. To install a new brush, position the new brush
on the roller with the spikes facing downwards.
Refer to Figure 32.
3
Figure 32. Install the New Brush
4. Thread each tab into the slot provided and
gently feed it through until the heel comes out
at the other side of the slot. Refer to Figure 33.
4
Figure 33. Pull Tabs Through Each Slot
5. Use a pair of scissors to cut the tabs 3/4 inch
from the heel so that they are no higher than the
spikes as shown in Figure 34.
Figure 34. Cut Tabs
6. Repeat this procedure to install the second
brush.

Page 13
English
5.4 Replacing the Tires on the Cleaner
1. Pull on the inside of the old tire to remove the
tire lip from the wheel. See Figure 35.
1
Figure 35. Pull the Old Tire Over the Wheel
2. Remove the old tire as shown in Figure 36.
2
Figure 36. Remove the Old Tire
3. To replace the tire, position the tire on the wheel
making sure to orient the tire so that the word
INSIDE is toward the body of the cleaner. See
Figure 37.
Figure 37. Tire Replacement Orientation
1
I
N
S
I
D
E
Towards
Body
I
N
S
I
D
E
I
N
S
I
D
E
4. Pushonesideofthetireontothewheelandt
the rib of the tire in the groove of the wheel as
shown in Figure 38.
2
Figure 38. Start on One Side of the Tire
5. Work the tire onto the wheel and verify the
rib of the tire is positioned properly within the
groove of the wheel. Refer to Figure 39
3
Figure 39. Work the Tire On Around the Wheel
6. Push and position the rib of the inner side of
the tire in the groove of the wheel. Refer to
Figure 40.
If needed, turn the wheel gently to
help with installation.
4
Figure 40. Push the Tire into Place on the Wheel
Section 6. Replacement Parts
The complete replacement parts list and exploded
view is available on the Polaris website at
www.polarispool.com.

Page 14
Symptom Cause Solution
Theashingindicator
lights appear just after
start (pressing the Power
or Cycle button to start the
cleaner) (< 20 seconds).
Ensuretheoatingcableisproperly
plugged into the control unit.
Unplugtheoatingcablefromthecontrolunitand
plug it in again.
Ensure the cleaner is well submerged
and free of trapped air.
Submerge the cleaner following the procedure in
Section 4.1, "Submerging the Cleaner".
Cleaner needs to be reset and start
new cycle.
Press the power button OFF and then Cycle I or II
Program buttons to start new cycle.
Propellerdoesnotturn.Thelter
canister needs to be emptied.
Please contact your local service representative.
Wheels do not turn. Please contact your local service representative.
Theashinglightsappear
during the cycle.
Lightashesifthecleanersucks
air for 60 seconds or more. May be
caused at beach entry if cleaner does
not reverse correctly.
Resubmerge the cleaner following the procedure in
Section 4.1, "Submerging the Cleaner".
The cleaner does not stay
rmlyonthepoolbottom.
There is air in the appliance casing. Submerge the cleaner following the procedure in
Section 4.1, "Submerging the Cleaner".
The cleaner does not or no
longer climbs the pool sides.
Theltercanisterisfullordirty. Cleantheltercanisterfollowingtheprocedure
Section 5.1, "Cleaning the Filter Canister".
Sides of pool are slippery or slimy.
Although the water seems clear,
microscopic algae, invisible to the
human eye, are present in the pool.
As a result the pool sides become
slippery and prevent the cleaner from
climbing. Check tires for wear and
replace as necessary.
Do a shock chlorination treatment and slightly
reduce the pH. DO NOT leave the cleaner in the
pool during this treatment.
On startup the cleaner does
not move.
Not supplied with electricity. The outlet, the control unit is connected to, is not
supplying electrical power. Check that the outlet
to which the control unit is connected is receiving
electricity.
Unit is turned ON. Check that you have started one (1) of the two
(2) programs and check that the indicator for the
selected program is lit. If the problem persists,
contact your local service representative.
The Cycle I and II program
indicatorsashalternately.
Your cleaner has encountered
a problem or an issue during its
operation.
Disconnect the control unit and wait 20 seconds
before reconnecting the control unit. Check that the
oatingcableiscorrectlyconnectedtothecontrol
unit. Check that no debris impedes the rotation of
thebrushesand/orthepropeller.Emptythelter
canisterandcleanthelter.Startanewcleaning
program. If the problem continues contact your
local service representative.
Section 7. Troubleshooting
The following table lists some of the more common symptoms, causes and solutions encountered when using the cleaner.
TheunitemploysashinglightsduringCycleIandIItoindicatedifferentissuesonthecontrolunitandonthecleaner.
Theseindicationsarenotnecessarilymajorissues.Toturnofftheashinglight,pressthepowerbutton.Thenstartanew
cycle:Iftheashinglightspersistaftercompletingtroubleshooting,pleasecontactyourretailer.DONOTopenthe
control unit.
English

Page 15
The cleaner seems to be
performinglessefciently.
The brushes have become smooth or
the "wear" indicator shows.
Replace the brushes following the procedure in
Section 5.3, "Replacing the Brushes".
Filter canister is full or dirty. Cleantheltercanisterfollowingtheprocedurein
Section 5.1, "Cleaning the Filter Canister".
Floating cable is excessively coiled or
kinked.
Makesuretheoatingcableisspreadoutoverthe
pool. Ensure the cable is not too tightly wrapped
or coiled when storing. If the problem persists, lay
the cable straight in the sun to relax it and remove
kinks.
English

Page 16
English
NOTES

9400
GUIDE DU PROPRIÉTAIRE
AVERTISSEMENT
POUR VOTRE SÉCURITÉ – Pour toute opération autre que l’entretien de routine et la maintenance décrite
dans ce manuel, ce produit doit être pris en charge par une entreprise qui est autorisée et qualifiée pour
la réparation des équipements de piscine par la juridiction où le dit produit est installé lorsque de telles
exigences locales ou provinciales sont édictées. Si aucune exigence locale ou provinciale n’est disponible,
l’agent d’entretien doit être un professionnel avec suffisamment d’expérience dans l’installation et la
maintenance d’équipement de piscine pour appliquer correctement les consignes du présent manuel.
L’installation ou l’utilisation inappropriée annulera la garantie.
P93
P94
H0371400 Rev -

Page 18
NOUS VOUS REMERCIONS D'AVOIR ACHETÉ LE ROBOT NETTOYEUR POLARIS®P93 P94.
VOTRE ROBOT NETTOYEUR POLARIS A ÉTÉ CONÇU ET FABRIQUÉ EN VUE D'UNE INSTALLATION
FACILE ET D'UN MINIMUM DE MAINTENANCE ET D’ENTRETIEN. AVANT D'INSTALLER VOTRE NOUVEAU
NETTOYEUR POLARIS P93 P94, VEUILLEZ SUIVRE LES ÉTAPES SUIVANTES :
1) Remplir et renvoyer le bon de garantie.
2) Enregistrer votre information d'achat dans les espaces prévus ci-dessous.
3) Joindre votre facture (ou une copie) à cette page.
Le respect de ces étapes assure un service rapide de garantie, le cas échéant. Si une réparation est requise, veuillez
communiquer avec votre détaillant d’origine. Si le détaillant d’origine ne remplit pas convenablement le service de
garantie, veuillez visiter www.polarispool.com pour localiser un service de réparation indépendant près de chez vous.
Si vous ne parvenez pas à localiser un service de réparation, veuillez communiquer avec notre service du soutien
technique au 800-822-7933.
ENREGISTRER LES RÉFÉRENCES DE VOTRE NETTOYEUR POLARIS P93 P94 ICI :
Date d'achat Acheté chez Numéro de série :
(situé sur la tête de l’appareil)
Ville État/Province Code postal
Table des matières
Section 1. Consignes de Sécurité
Importantes .................................. 19
Section 2. Spécications du
Nettoyeur....................................... 21
2.1 Spécicationsgénérales .................................. 21
Section 3. Assemblage et utilisation initiale 21
3.1 Déballage ........................................................ 21
3.2 Assemblage du chariot de déplacement ......... 22
3.3 Raccordement du module de commande au
chariot .............................................................. 23
3.4 Raccordement électrique ................................ 24
Section 4. Fonctionnement ........................... 24
4.1 Immersion du nettoyeur ................................... 24
4.2 Fonctionnement du nettoyeur........................... 25
Français
Section 5. Entretien et nettoyage.................. 27
5.1 Nettoyagedupanierltrant ............................. 27
5.2 Nettoyage et entreposage du nettoyeur .......... 28
Section 6. Pièces de Rechange..................... 30
Section 7. Dépannage ................................... 31

Page 19
Français
AVERTISSEMENT
Si les précautions suivantes ne sont pas observées, il y a risque de blessures graves, de choc
électrique ou de noyade.
ÉVITER LES CHOCS ÉLECTRIQUES
Pour réduire le risque d'un choc électrique :
•Brancher l’appareil à la prise protégée par un disjoncteur de fuite à la terre (DDFT). Un tel DDFT doit être fourni
par un installateur qualifié et doit faire l'objet de tests sur une base régulière. Pour faire l'essai du DDFT, appuyer
sur le bouton TEST. Le disjoncteur de fuite à la terre doit couper l’alimentation électrique. Appuyer sur le bouton
de réinitialisation. L’alimentation électrique devrait être restaurée. Si le disjoncteur de fuite à la terre fait défaut
de fonctionner de cette manière, le disjoncteur de fuite à la terre est défectueux. Si le disjoncteur de fuite à la
terre coupe l'alimentation de la pompe sans que le bouton TEST ne soit enfoncé, un courant de terre circule,
indiquant la possibilité d'un choc électrique. Ne pas utiliser ce produit. Débrancher l’aspirateur, puis faire corriger
le problème par un technicien qualifié avant son utilisation.
•Conformément au Code national électrique des États-Unis (NEC), garder l'unité d'alimentation à au moins
1,5 m (5 pi) du bord de l’eau de (piscine/spa) et ne pas la retirer de son chariot. Au Canada, le Code canadien
de l’électricité (CCE) requiert qu'une distance minimale de 3 m (10 pi) doit être maintenue entre le bord de la
piscine et l'unité d'alimentation. Ne jamais immerger le module de commande.
•Ne pas entrer dans la piscine lorsque le nettoyeur Polaris est dans l'eau.
•Ne pas enterrer le cordon. Placer le cordon de manière à éviter qu'il ne soit endommagé par les tondeuses à
gazon, les taille-haies et tout autre équipement.
•Pour réduire le risque de choc électrique, ne pas utiliser l’aspirateur nettoyeur Polaris ou le module de commande
si le cordon est usé ou endommagé. Veuillez immédiatement communiquer avec Zodiac Pool Systems, Inc. pour
obtenir un fil de rechange.
•Insolation double—Pour une protection continue contre les chocs électriques, n'utiliser que des pièces identiques
au moment de l'entretien. Ne pas essayer de réparerle nettoyeur Polaris, le module de commande, le cordon
d'alimentation ou le câble flottant.
•NE JAMAIS OUVRIR LE MODULE DE COMMANDE.
•Ne pas utiliser une rallonge afin de brancher l’appareil à l’alimentation ; fournir une sortie adéquatement
localisée. Le module de commande doit être placée près de la boîte de sortie.
ÉVITER QUE LES ENFANTS NE SE BLESSENT OU SE NOIENT
• Pourréduirelerisquedeblessure,nepaspermettreauxenfantsd’utiliseroudefairefonctionnerceproduit.
• Nelaisserpersonne,surtoutdesjeunesenfants,s’asseoir,mettrelepied,s'appuyeroumontersurdes
appareils faisant partie de notre système opérationnel de piscine.
Section 1. Consignes de Sécurité Importantes
Félicitationspourl'achatduRobotNettoyeurPolarisP93P94.Veuillezlireceguideaucompletavantd’installervotre
nouveau nettoyeur de piscine. Le nettoyeur doit être installé et utilisé selon ces directives.
LIRE ET SUIVRE TOUTES LES CONSIGNES

Page 20
CONSERVER CES DIRECTIVES
ATTENTION
Le défaut de se conformer aux avertissements suivants pourrait entraîner des dommages
à l'équipement de la piscine ou causer des blessures.
• Ce produit est destiné pour une utilisation avec des piscines permanentes. Ne pas utiliser avec des piscines
remisables. Une piscine installée en permanence est enfouie dans le sol ou en surface ou dans un bâtiment de telle
sorte qu'elle ne peut pas être facilement démontée pour le rangement. Une piscine démontable est construite de
sorte qu'elle est susceptible d'être facilement démontée pour le rangement et remontée dans son intégrité originale.
• Le nettoyeur Polaris doit être installé et utilisé tel que est spécifié.
• Mettrele nettoyeur Polaris hors tension avant de le retirer de l'eau et ne pas le faire fonctionner hors de l'eau.
• Nepasretirerle nettoyeur Polaris de la piscine avant 15 minutes une fois le cycle de nettoyage terminé.
• Nettoyerlefiltre cartouche du nettoyeur Polaris après chaque utilisation.
• Nepasutiliserle nettoyeur dans la piscinesilatempératuredel’eauestsupérieureà35˚C(95˚F)ouinférieure
à13˚C(55˚F).
ATTENTION
UTILISATION DU NETTOYEUR POLARIS DANS UNE PISCINE À SURFACE DE VINYLE
Certains motifs de toile de vinyle sont particulièrement sensibles à l'usure rapide de leur surface par des objets
qui entrent en contact avec la surface de vinyle, y compris les brosses de nettoyage, les jouets de piscine, les
flotteurs, les fontaines, les distributeurs de chlore et les nettoyeurs automatiques de piscine. Certains modèles
de recouvrement en vinyle peuvent être sérieusement rayés ou éraflés lorsque leur surface est frottée avec une
brosse de piscine. L'encre du modèle peut également s'effacer pendant le procédé d'installation ou quand elle
entre en contact avec des objets dans la piscine.
Zodiac Pool Systems, inc. n'est pas responsable de l’élimination du dessin, des coupures, des éraflures ou des
inscriptions sur les recouvrements en vinyle et cette garantie ne couvre pas ces situations.
Français
