Polarlite 1493203 User manual

Outdoor
Operating instructions
Decoration
LED projector “Snowflakes”
Item no. 1493203

Intended use
Use this product to decorate interior and exterior spaces (IP44).
For safety and approval purposes, you must not rebuild and/or
modify this product. If you use the product for purposes other
than those described above, the product may be damaged. In
addition, improper use can cause hazards such as short-circuiting,
fire, electric shock etc. Read the instructions carefully and keep
them. Make this product available to third parties only together
with its operating instructions.
This product complies with the statutory national and European
requirements. All company names and product names are
trademarks of their respective owners. All rights reserved.
Delivery content
• LED projector • L-shaped spanner
• Transformer • Operating instructions
• Ground spike
Safety instructions
Read the operating instructions carefully and especially
observe the safety information. If you do not follow the
safety instructions and information on proper handling
in this manual, we assume no liability for any resulting
personal injury or damage to property. Such cases will
invalidate the warranty/guarantee.

a) Persons / Product
• The device is not a toy. Keep it out of the reach of children and
pets.
• Do not leave packaging material lying around carelessly. These
may become dangerous playing material for children.
• Always check the product for damages before use. Should you
discover any damage, cease use of the product. If you discover
damages while the product is in use (i.e. damaged transformer),
do not touch the product, risk of fatal injury due to electric
shock! First disconnect the mains outlet to which the product
is connected from the power supply (flip o the fuse and/or
automatic circuit breaker and then turn o the residual current
operated circuit breaker to disconnect the power outlet at all
phases). Now unplug the transformer from the power outlet.
Discontinue use of the product immediately, dispose of it in an
environmentally friendly fashion.
• Protect the product from extreme temperatures, strong jolts,
flammable gases, vapours and solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, take it
out of operation and protect it from any accidental use. Safe
operation can no longer be guaranteed if the product:
– is visibly damaged,
– is no longer working properly,
– has been stored for extended periods in poor ambient
conditions or
– has been subjected to any serious transport-related stresses.
• Please handle the product carefully. Jolts, impacts or a fall even
from a low height can damage the product.

• The LEDs get hot during use. Keep the product away from
easily flammable materials when in use.
• The product generates heat during use. Do not cover the
product during use.
• The product is suitable for both indoor and outdoor use.
• Attention, LED light: Do not look directly into the LED light! Do
not look into the beam directly or with optical instruments!
• The mains outlet must be located near to the device and be
easily accessible.
• Only the included transformer may be used as a power supply.
• The transformer may be supplied with power only via a properly
installed power outlet connected to the public supply mains.
Before plugging in the transformer, verify that the transformer's
nominal voltage complies with the voltage of your power supply
company.
• Never plug in or unplug the transformer with wet hands.
• Do not unplug the transformer by tugging on the cord, grasp
and pull the power plug using the provided gripping surface.
• When setting up the product, make sure that the cables are not
pinched, kinked or damaged by sharp edges.
• Always lay the cables so that nobody can trip over or become
entangled in them. This poses a risk of injury.
• Unplug the transformer in case of a thunder storm for safety
reasons.
• Do not over-tighten the screws. Over-tightening the screws may
cause damage to the threading and can impair the strength of
screw connections.

b) Miscellaneous
• Consult an expert when in doubt about operation, safety or
connection of the device.
• Maintenance, modifications and repairs are to be performed
exclusively by an expert or at a qualified shop.
• If you have questions which remain unanswered by these
operating instructions, contact our technical support service or
other technical personnel.
Product overview
310 mm
98 mm
5 m

Operation
Do not install or operate the product under water.
Make sure the cable hangs loosely and is not overly
tensioned. Failure to heed this warning may cause the
cables to tear.
Do not connect the product to the power supply while it
is still in the packaging. Uncoil the power cable fully.
Do not hang any objects from the product and do not
cover the product.
When inserting the ground spike into the soil, do not
use any tools (e.g. hammers), as such would damage the
product.
Check all screw connections from time to time. Screw
connections may loosen over time due to adjusting and
moving the product.
The LEDs are neither dimmable nor replaceable.
1. Uncoil the power cable fully.
2. Loosen the screw by turning it anticlockwise, and remove the
spring washer and flat washer from the ground spike using
the spanner provided (see ).
3. Attach the lamp to the ground spike using the screw, spring
washer and flat washer (see ).
4. Connect the plug of the power cable to the socket on the
transformer. It is only possible to connect in one way. Secure
the connection by turning the plug’s screw cap onto the
transformer’s thread (see ).
5. Choose a suitable location to set up the device with soft
ground. Stony ground will damage the ground spike.
Carefully insert the LED projector including the ground spike
all the way into the soil (see ).

6. Loosen the lateral hexagon screws using the hexagon key
provided. Adjust the angle of the projector as desired and
then retighten the screws.
7. Connect the transformer to a power outlet. The projector is
switched on and starts rotating.
The product has no power switch and is always on as long as
it is connected to the power supply. Disconnect the power
supply in order to switch the LED projector o.
Cleaning and care
• Disconnect the transformer from the mains socket and let the
LED projector cool down suciently before cleaning.
• Do not use any abrasive or chemical cleaners. To clean, use a
clean, dry, lint-free cloth. For stubborn dirt, slightly dampen the
cloth with water.
• Allow the product to dry completely before continued use.
Disposal
Electronic devices are recyclable waste and must not
be disposed of in the household waste. At the end of its
service life, dispose of the product in accordance with
applicable regulatory guidelines.
You thus fulfill your statutory obligations and contribute
to the protection of the environment.

These operating instructions are published by CEI Conrad Electronic International (HK) Limited, 18th Floor, Tower 2,
Nina Tower, No. 8 Yeung Uk Road, Tsuen Wan, New Territories, Hong Kong. All rights including translation reserved.
Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data processing systems
require the prior written approval by the editor. Reprinting, also in part, is prohibited. These operating instructions
represent the technical status at the time of printing.
© Copyright 2016 by CEI Conrad Electronic International (HK) Limited
1493203_v1_0916_02_m_ls_EN(2)distributed by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau
Technical data
a) LED projector
Protection type ......................................IP44
Operating voltage.................................12 V/DC, 0.3 A
Power consumption.............................4.7 W
Number of lights....................................4 x 1 W LED
Light color ................................................Multicolor
Cable length.............................................5 m
Dimensions (Ø x W) ............................98 x 310 mm
Distance to illuminated area ............5 m
Illuminated area......................................5 x 5 m
Projector rotation..................................3 turns / minute
Operating conditions ..........................-20 to +40 °C / 0 – 100 % RH
Storage conditions ...............................-20 to +40 °C / 0 – 100 % RH
Weight ........................................................760 g
b) Transformer RSS1002-036120-W2E-F
Protection type ......................................IP44
Input voltage ...........................................100 – 240 V/AC, 50/60Hz
Output voltage.......................................12 V/DC
Output current .......................................300 mA
Output power .........................................max. 3.6 W
