SURROUNDBAR®SERIES LOUDSPEAKERS SURROUND SOUND FROM A SINGLE SPEAKER
SERIES CATALOG

polk
technology
2SURROUNDBAR SERIES LOUDSPEAKERS
SURROUNDBAR360° DVD THEATER
POWERPORT®
Polk Audio loudspeakers shatter the boundaries of bass response with patented PowerPort bass venting
technology. Conventional ports have limitations: air turbulence at the mouth of the port can cause “port noise”
and bass output losses of up to 3dB. (A loss of 3dB means that half of your amplifier power is being wasted on
turbulence instead of bass!) The distinctive design of the Polk Audio PowerPort gradually slows air exiting the
port, vastly reducingturbulence, port noise and energy loss. The result is bass that you will feel as well as hear;
bass that reaches out, grabs you by the lapels and shakes you up—for a completely visceral and emotional
movie and music experience. See more about PowerPort at www.polkaudio.com/catalog/technology/.
SURROUNDBAR®360°
SENSATIONAL SURROUND SOUND,
STUNNING SIMPLICITY
The SurroundBar®360° DVD Theater is a complete
home entertainment system. It incorporates the
enveloping sonic benefits of our Polk®SurroundBar
Technology and our patented PowerPort®bass
venting technology with the convenience of a
control console that is a DVD/CD player, amplifier,
and an AM/FM radio. The SurroundBar360°’s sleek,
contemporary design and simple, single-cable speaker
hookup makes it ideal for anyone who wants big, rich
surround sound home entertainment without any of
the hookup hassles of multiple speakers and wires.
Surround sound from a single speaker, which
means no rear speakers, no rear wires.
Built-in subwoofer bass performance and patented
PowerPort®eliminates the need for a separate subwoofer.
No boundary requirements. Works in any room.
No complicated set-up. Out of the box the SurroundBar360°
DVD Theater is playing music and movies in minutes.
Polk Digital Logic guarantees highest level of performance,
easy setup and no calibration.
Fully featured console with AM/FM tuner and inputs
for cable and satellite TV, games and MP3 players.
Built-in high performance DVD player for your DVDs,
CDs and MP3s.
15' cable for the absolute easiest hookup.
No more tangled wires to string around a room.
Easy to install on a wall, thanks to built-in key hole slots.
Two sets of Cradle Mounts, high and low, give you
more on-shelf positioning options.
Gloss black cabinet matches all TVs.
Magnetically shielded, of course, for safe placement
on or near TVs.
Remote control for complete control of all sources
at your fingertips.
SPEAKER DIMENSIONS:
4 1/8" H X 44 1/2" W X 4 7/8" D (10.47CM H X 113.03CM W X 12.38CM D)
CONSOLE DIMENSIONS
3 3/16" H X 16 1/2" W X 11 1/2" D (8.1CM H X 41.91CM W X 29.21CM D)
OVERALL FREQUENCY RESPONSE: Hz - kHz.
SEE SPECIFICATIONS FOR MORE DETAILED PRODUCT INFORMATION.
BLACK
REMOTE CONTROL

polk
technology
WWW.POLKAUDIO.COM 3
FEED FORWARD DISTORTION SUPPRESSION TECHNOLOGY
This technology maximizes acoustic output as it reduces audible distortion. Feed Forward is a
zero latency system that maximizes dynamic output of the subwoofer system, without relying on
slow responding feedback techniques or broad band dynamic compression, which squeeze the
life out of the low end. What you hear is quick, precise bass output with minimal audible distor-
tion, even at ground shaking volume levels.
SURROUNDBAR360° SDA
SURROUND DIGITAL TECHNOLOGY
A tremendous evolution on the original SDA Surround
Technology, Polk SurroundBar Technology brings surround
sound-without the surround speakers into the next century.
Featured only in the exclusive SurroundBar 360° DVD Theater,
Polk Audio’s legendary SDA speaker systems revolutionized
speaker technology in the mid 1980’s and 1990’s and are still
prized today by audio enthusiast for their huge, totally
enveloping sound stage far beyond the capability of
conventional speakers. Original SDA is analog while SDA
Surround Digital uses the tremendous processing capability
of digital microchips to process the audio, a far more powerful
tool then the passive components of original SDA Technology.
A PATENTED TECHNOLOGICAL
BREAKTHROUGH
Polk Audio’s psychoacoustic research and technology have
produced a system capable of delivering a 360°degree surround
sound experience that stands above the rest. Unlike competing
products that attempt to eliminate the need for rear channel
speakers, the SurroundBar 360° DVD Theater is the only multi-
channel single-speaker surround system that works in any room
with easy setup, while eliminating the need for a subwoofer.
The enveloping sound from SDA Surround Digital is so realistic
in some cases it’s better than using 5 or more speakers!
PICTURE/DISPLAY
1080i HDMI1 with high definition video
up-conversion from any video input.
Faroudja DCDi2—480p, 720p, 1080i
Up-converts any input to HD quality
CONNECTIVITY
SIDE CONNECTIONS:
S-Video Input
Composite Video Input
Audio L/R Inputs
USB Port
Headphone Output
REAR CONNECTIONS:
FM Antenna and AM Antenna
Coaxial Digital Input
Optical Digital Inputs
Audio L/R Inputs
Cable/Satellite, AUX1, TV, Record Outputs
AUX 1 Video Inputs (Cable/Satellite: Composite
and S-Video; AUX1: Composite and S-Video)
Video Outputs: Composite, S-Video and
Component, HDMI Output, Subwoofer
Output, Speaker Cable Output
Polk SurroundBar
Technology Front
Polk SurroundBar
Technology Rear
SURROUND DIGITAL TECHNOLOGY

polk
technology
4SURROUNDBAR SERIES LOUDSPEAKERS
DYNAMIC BALANCE®
Advanced laser imaging technology allowed Polk Audio engineers to see the entire vibrating
surface of a driver and tweeter; they could actually see the resonance develop on the speaker
cones––resonance that is the root cause loudspeaker distortion (A). Being able to see the
resonance develop, they determined the “Dynamic Balance” of high-tech materials, geometry
and constrution that effectively tune out the offending resonance (B). Exclusive Dynamic Balance
Composite Material Technology delivers sound that’s effortlessly clean and clear, even at lifelike
volume. See more about Dynamic Balance at www.polkaudio.com/education/technology/php.
SURROUNDBAR®50
The perfect complement to flat and shallow
screen technologies, the Polk Audio SurroundBar50
delivers breathtaking all-enveloping sonic
performance without the need for rear speakers.
The SurroundBar50’s unobtrusive design and color-
coded hookup configuration makes it a welcome
addition for anyone who wants the thrilling
benefits of surround sound and none of the
hassles. More than a cosmetic evolution, the
SurroundBar50 also a sonic evolution, with
greater max SPL, front and rear SDA speakers
and better overall performance from all musical
sources. And while the SurroundBar50’s delivers
enough bass for your listening pleasure, many
people will add a subwoofer to create a sound
system that produces truly compelling
sonic performance.
OVERALL DIMENSIONS:
51" L X 4 1/2" H X 5 1/10" D (129.54CM L X 11.43CM H X 12.95CM D)
OVERALL FREQUENCY RESPONSE 60Hz - 23kHz.
SEE SPECIFICATIONS FOR MORE DETAILED PRODUCT INFORMATION.
BLACK TITANIUM
Polk Audio’s patented SDA Surround Technology,
applied to both front and rear channels for a more
enveloping sound, delivers a vivid sound field from
a single, 51" cabinet; no rear speakers are required.
Dual front ports for superior clean, low distortion bass.
Simplified color-coded hookup with all 5 channels
going directly from your home theater receiver to
the SurroundBar50.
15 feet 10-conductor cable is color-coded and clearly
marked for easy hookup. No more tangled wires
to string around a room.
Easy to install on a wall thanks to a simple
wall-mount bracket.
Dual cradle mounts, high and low, give you more
on-shelf positioning
options, including in front of today’s flat-panel TVs.
Wall bracket (included)
Nine 3 1/2" Dynamic Balance drivers and three 3/4"
Dynamic Balance dome tweeters deliver clear, natural
mid-range, high frequencies and lifelike imaging.
Aluminum extruded enclosure eliminates
cabinet resonance.
Anti-diffraction grille and bezel helps create
open, spacious imaging.
Magnetically shielded, of course, for safe
placement on or near TVs.
A
B
SURROUNDBAR50

polk
technology
WWW.POLKAUDIO.COM 5
SDA®SURROUND
Polk’s patented SDA®Surround technology puts you in the center of the action. Our
revolutionary system literally uses the space between your ears to create your own
5-channel surround sound environment from a single front speaker. See more about
SDA Surround at www.polkaudio.com/education/technology.php.
SURROUNDBAR®
Polk’s patented SDA®Surround Technology means
you won’t need to install rear speakers. What you
hear is a completely immersive sound experience,
as if there are multiple speakers all around you.
The sleek, unobtrusive design is a welcome
addition for anyone who wants all the thrills of
surround sound…but none of the hassles. The
Polk Audio SurroundBar will complete your high
definition TV experience. It’s the perfect match
for flat-panel and shallow screen TVs. And it
works with any surround sound receiver.
The technology behind the SurroundBar is based
on Polk’s legendary SDA SRT Systems, which
one reviewer called “The Ultimate Loudspeaker.”
SDA Surround Technology makes the speakers
disappear by cancelling the acoustic position
location information. That information is then
replaced by the correct surround sound information
of the original recording just as if sounds were
actually coming from all around you. Whether
it’s music or movies you’re assured of a great
surround sound experience.
OVERALL DIMENSIONS:
42 5/8" L X 4 1/2" H X 5 1/8" D (108.2CM L X 11.18CM H 12.95CM D)
OVERALL FREQUENCY RESPONSE: 80Hz - 23kHz
SEE SPECIFICATIONS FOR MORE DETAILED PRODUCT INFORMATION.
BLACK TITANIUM
Polk Audio’s patented SDA Surround Technology
delivers an immersive surround sound field
from a single, 43" enclosure. No rear speakers
are required.
SDA Surround works equally well with all surround
sound formats including multi-channel music.
The SurroundBar works in any room—SDA
Surround is not dependent on your room’s
walls to produce the surround effect.
Works with any surround sound receiver. All five
channels connect directly to the SurroundBar.
Included 25 feet 10-conductor cable is color-
coded and clearly marked for easy hookup.
No more tangled wires to string around a room.
Easy installation thanks to a simple-to-install
wall-mount bracket (included).
A separate cradle mount for placement
on top of a TV or on a shelf (included).
Seven 3 1/2" Dynamic Balance®drivers and
three 3/4" Dynamic Balance dome tweeters
deliver outstanding performance for music
listening and movies.
Aluminum extruded enclosure reduces
cabinet resonance for distortion-free sound.
Magnetically shielded, of course,
for safe placement on or near TVs.
SURROUNDBAR

We’re fanatics when it comes to providing you useful, accurate information that can help you evaluate our products. But as we all know, we live in an imperfect world. At least some of us do.
That’s why performance specifications and product dimensions are subject to change without notice. For the most current specifications see our website, www.polkaudio.com/home.
Polk Audio is a Directed Electronics company which trades on NASDAQ under the symbol DEIX. Investor information can be found at http://investor.directed.com.
Polk Audio, Polk, PowerPort, Dynamic Balance, F/X, Atrium, Big Speaker Sound Without The Big Speaker, High Velocity Compression Drive, Acoustic Resonance Control, ARC Port, Casket Basket,
I-Sonic, SurroundBar & SDA are registered trademarks of Britannia Investment Corporation used under license by Polk Audio, Incorporated. Polk Audio Designs & miDock are trademarks of
Britannia Investment Corporation used under license by Polk Audio, Incorporated.
SURROUNDBAR
LOUDSPEAKERS AND SYSTEMS SURROUNDBAR360° SURROUNDBAR50 SURROUNDBAR
Driver Complement 8 - 2 1/2" full range drivers 9 - 3 1/2" mid-bass drivers, 7 - 3 1/2" mid-bass drivers,
3 - 3/4" Silk Dome Tweeters 3 - 3/4" silk dome tweeters
Overall Frequency Response 80 Hz - 23 kHz 100Hz - 23kHz
Sensitivity (1w/1m) 90dB 89dB
Nominal Impedence 8 Ohms 8 Ohms
Recommended Amplification 20 - 150 Watts / channel 20 - 125 Watts / channel
Bass Technology PowerPort with Feed Forward dual front ports acoustic suspension
Finish black satin black with gloss trim or titanium black or titanium
Product Weight / Shipping Weight 12 lbs / 27 lbs 15 lbs / 21 lbs 25 lbs / 27 lbs
5.44 kgs / 12.25 kgs 6.8 kgs / 9.5 kgs 11.34 kgs / 12.25 kgs
Console Weight 15 lbs (6.8 kgs)
Speaker Dimensions 4 1/4" H x 45 1/2" W x 4 3/4" D 4 1/2" H x 51" W x 5 1/10" D 4 7/16" H x 42 5/8" W x 5 1/8" D
10.8cm H x 115.57cm W x 12.06 cm D 11.43cm H x 129.54cm W x 12.95 cm D 11.27cm H x 108.27cm W x 13 cm D
Console Dimensions 3 1/4" H x 16 1/2" W x 11 1/2" H n/a n/a
8.25cm H x 41.91cm W x 29.21cm D
SURROUNDBAR SERIES LOUDSPEAKERS PRODUCT SPECIFICATIONS
POLK AUDIO
5601 METRO DRIVE
BALTIMORE, MD 21215
WWW.POLKAUDIO.COM
CUSTOMER SERVICE:
800-377-7655 (USA & CANADA)
410-358-3600 (WORLDWIDE)
COPYRIGHT© APRIL 2008
ALL RIGHTS RESERVED.
