MARVEL insect exterminator
type: steel , white 14-03-01-3 & 4
Installation and service manual
Please read carefully, before using your unit!
The information in this service manual is based on the latest information, and is provided subject
to alterations. We reserve the right to change the construction and/or configuration of the product
at any time without obligation to modify earlier versions of the product.
For further data: www.fly-killers.pl
A) Read this manual carefully before taking any action with regard to the MARVEL insect
exterminator.
Congratulations with the purchase of this high quality electric insect exterminator. Before using this model
we would like to ask you to read this manual carefully. If you have questions afterwards feel free to
contact your local supplier.
The information in this manual is based upon the latest information, and is provided subject to alterations.
We reserve the right to change the construction and/or configuration of the product at any time without
obligation to modify earlier versions of the product.
Store this manual carefully for future use.
B) Safety
When using electric tools, basic precautions to reduce risk of fire, electric shock and personal injury, must
always be followed including the following:

Service manual POMEL Sp. z o.o. / April 2015 / version 1.0 page: 2 / 4
All right reserved. No part of this document may be reproduced, stored in a database or any other retrieval system, or published, in
any form or in any way, electronically, mechanically, digitally per photo print or microfilm or any other way without written permission
from the writer.
Consider work area environment. Keep work area clean and well lit.
The Marvel unit should be connected to the mains (230 or, respectively, 240V AC, 50Hz, unless
otherwise specified)
Do not use power tools in the presence of flammable materials.
Do not abuse cable. Keep it away from heat, oil and sharp edges.
Maintain fly control system with care. Keep the fly control system clean for better and safer
performance. Follow instructions for lubricating and changing accessories.
Disconnect mains, when not in use, before servicing, and when changing accessories or
components.
Make a habit of checking to see that wrenches and adjusting service tools are removed from the fly
control system before turning it on.
The use of any accessory or attachment other than recommended in these operating instructions or
the catalogue may present a risk of personal injury.
The fly control system complies with the relevant safety rules. Repairs should only be carried out by
qualified persons using original spare-parts, otherwise this may result in considerable danger to the
user.
Use a safe mains connector with proper ground.
Wiring in the fly control system meets safety standard EN 60335-2-59
Always leave repairs (other than cleaning, glue board replacement or replacing the lamp) to your
dealer/distributor.
The light from the ultraviolet lamps is harmless to people and animals even after prolonged
exposure.
Note: In case of replacement of the lamps and/or the starters use components of the
same specifications. Only use genuine spare-parts for service and maintenance
C) Receipt of equipment
While unpacking, check for any signs of shipment damage and, if found, notify both transporter and
supplier in writing within 7 days after receipt with full details of the damage that has occurred and retain
the equipment and packing materials for inspection. Check that all parts have been received as ordered.
Make sure that all packaging is removed from the machine before use.
D) Installation
To achieve maximum effectiveness, the following installation notes must be considered:
Choose a place where the unit can be reached and cleaned easily.
Avoid obstacles, which limit the possibility for the insects to reach the apparatus.
Avoid draught by fans or air shafts and avoid direct sunlight.
Use good quality mounting material.
Use a safe mains connector with ground.
Note: fly control systems may never be hung directly above uncovered food!!
E) Maintenance
The fly control system requires no maintenance other than cleaning, changing of the glue board and lamp
replacement.
1) Cleaning
a) Disconnect the device from the mains.
b) Wipe the front grid and casing clean with a damp cloth or one moistened with methylated
spirits.

Service manual POMEL Sp. z o.o. / April 2015 / version 1.0 page: 3 / 4
All right reserved. No part of this document may be reproduced, stored in a database or any other retrieval system, or published, in
any form or in any way, electronically, mechanically, digitally per photo print or microfilm or any other way without written permission
from the writer.
2) Changing the glue board
a) Glueboard is located behind front of the unit
b) Take the old glue board away and place new glueboard inside the of the unit
c) Protective sheet from new glueboard must be removed before the insert into unit.
3) Lamp replacement
We recommend to replace the UV-A lamp once every year before the main insect season starts:
The lamps should in any case be replaced after 9,000 burning hours.
a) Disconnect the device from mains.
b) Pull up used lamp from lamp holder .
c) Place new lamps in the lamp holder, mind to the pin connectors
F) Specifications
Specifications of the unit are outlined below:
Technical name : MARVEL insect light trap
Area coverage (m²) : 30 square meter per unit
Light source (W) (UV-A) : 1 x 11 watt shatterproof UV-A lamp
Type of UV lamps : UV Lamp RoHS certified
Electrical supply (V) : 220-240,
Catch specifications (V) : by means of long life glue board
Power consumption (W) : 14
Weight (kg) : 1,4
Material : stainless steel AISI 430 with steel or plastic front
Glass protection : shatterproof tubes included with 95% UV-A transparency
Degree of protection (IP) : IP 20 (drip proof)
Guarantee : 2 years return to base
Int. building norm : acc. EN 60335-2-59 int. standard for insect exterminators
Lamp life time (h) : 9000
Dimensions (L*D*H) : 250 * 248 * 95mm
CE-approval : yes
Mounting position : wall mounted, free standing
Cable : included EU or UK as option
Packaging : neutral cardboard box included
Manual : enclosed with the unit in English
Service : unit can be serviced without special tools
G) Construction parts
Table 1: Descriptions parts
Description
Pc / set
Steel casing
1
Front grid
1
UVA Lamp
1
Lamp holder
1
glue board
1
ballast
1
mains plug
1

Service manual POMEL Sp. z o.o. / April 2015 / version 1.0 page: 4 / 4
All right reserved. No part of this document may be reproduced, stored in a database or any other retrieval system, or published, in
any form or in any way, electronically, mechanically, digitally per photo print or microfilm or any other way without written permission
from the writer.
H) Spare parts list
Table 2: Recommended spare parts
Description
Amount
11W PLS UV-A lamp shatterproof
1
glue board
1
I) Certification and declaration
All MARVEL units comply with the EU-directive on machine safety
The unit and spare part components are in full compliance with the CE directive and the WEEE / RoHS
directives. The EC declaration of conformity is listed below:
CE declaration of conformity
We, POMEL Sp. z o.o.
Serocka 11
07-200 Wyszków, Poland
Tel: [phone]
Fax: [phone]
www.pomel.com.pl
Declare, under our responsibility, that the imported products:
Type: MARVEL steel, white insect control unit
