Portway Luxima Mounting instructions

Luxima
Gas Stove
LOG EFFECT HEATING STOVE
Installation, Maintenance & User Instructions
Hand these instructions to the user
Model No. PLGS**RN is for use on Natural Gas (G20) at a supply pressure of
20 mbar in G.B. / I.E.
** denotes cosmetic variance

Information Requirements for Commission Regulation (EU) 2015/1188
Rear Flue Outlet Top Flue Outlet
Model Identifier PLGS**RN PLGS**RN
Indirect Heating Functionality No No
Direct Heat Output 4.6kW 4.2kW
Indirect Heat Output Not Applicable Not Applicable
Fuel - Natural Gas (G20) (G20)
NOx Emissions 130mg/kWh 130mg/kWh
Nominal Heat Output 4.6kW 4.3kW
Minimum Heat Output (Indicative, all models) 1.8kW 1.8kW
Useful Efficiency at Nominal Heat Output 73.3% 67.6%
Useful Efficiency at Minimum Heat Output (Indicative) 50.0% 50%
Auxilliary Power Consumption at Nominal Heat Output 0.0000010kW 0.0000010kW
Auxilliary Power Consumption at Minimum Output 0.0000010kW 0.0000010kW
Auxilliary Power Consumption at Standby Mode 0.0000005kW 0.0000005kW
Permanent Pilot Flame Requirement Not Applicable Not Applicable
Type of Heat Output / Room Temperature Control With electronic room temperature
control.
Contact Details BFM Europe Ltd.
Gordon Banks Drive
Trentham Lakes North
Stoke-on-Trent
ST4 4TJ
Tel : [phone]

CONTENTS
PAGE
Section 1 Information and Requirements
1.0 Appliance Information 3
1.1 Conditions of Installation 4
1.2 Flue and chimney suitability 4
1.3 Ventilation 5
1.4 Clearances to combustible and non-combustible surfaces 5
1.5 Flue and chimney inspection 5-6
1.6 Hearths 6
1.7 Spillage monitoring system 6
1.8 Pre-cast flue systems 7
Section 2 Installation of Fire
2.1 Unpacking the stove 8
2.2 Installing the stove 8
2.3 Installing the stove with top flue outlet to chimney with clay liner 9
2.4 Installing the stove with rear flue outlet to chimney without clay liner 10
2.5 Installing the stove with top flue outlet to chimney without clay liner 11
2.6 Installing the stove with top or rear flue outlet to pre-fabricated flue system 12
2.7 Changing the flue outlet from top to rear 13
2.8 Removing and re-fitting the flue restrictor baffle 14
2.9 Making the gas connection / pressure testing 15-16
2.10 Fitting the batteries 17
Section 3 Assembling Fuel Bed and Commissioning
3.1 Fitting the log fuel bed 18-20
3.2 Lighting the stove manually 21
3.3 Setting the time, date and temperature on the remote handset 22-24
3.4 Lighthing the stove via the remote handset 25-28
3.5 Advanced settings of the remote control 28-32
3.6 Checking for clearance of combustion products 33
Section 4 Maintenance
4.1 Removal of the burner assembly 34-36
4.2 Removal of the gas control valve 36
4.3 Removal of the pilot 36
4.4 Removal / replacement of the thermal cut-out 36-37
4.5 Parts shortlist 37
Section 5 User Instructions
5.1 Installation Information 38
5.2 About the Portway gas stove 39-40
5.3 Operating your stove 41-44
5.4 Manual operation of the stove 45
5.5 Replacing the batteries 46
5.6 Setting the time, date and temperature on the remote handset 47-50
5.7 Advanced settings of the remote control 51-54
5.8 Turning the product off in the event remote handset malfunction 55
5.9 Removal / replacing the log fuel-bed 56-58
5.10 User replaceable parts 59
Product manufactured by:- BFM Europe Ltd, Trentham Lakes, Stoke-on-Trent, Staffordshire, ST4 4TJ.
2

SECTION 1
INFORMATION AND REQUIREMENTS
1.0 APPLIANCE INFORMATION
Main injector : (1 off) Size 400
Pilot Type ERTA OXYP PG-82-330/2
Max. Gross Heat Input : 6.9kW
Min. Gross Heat Input : 3.5kW
Gas Rate : 0.633 m3/hr
Cold Pressure : 20.0+/-1.0 mbar
Ignition : 4.5v battery / electronic ignition
Electrode Spark Gap : 4.0mm
Packed weight : 82kg
Fig 1
3
Important Note : Please secure
rating plate that is supplied in loose
items pack in suitable position and
secure with tie provided.

INSTALLATION REQUIREMENTS
Efficiency Declaration
The efficiency of this appliance has been measured as specified in
BS EN 613 : 2001 and the result is 73.3% (rear flue) & 67.6% (top flue). The net
calorific value of the fuel has been used for this efficiency calculation.
The test data from which it has been calculated has been certified by BSI Testing
Services.
The efficiency value may be used in the U Government’s Standard Assessment
Procedure (SAP) for energy rating of dwellings.
1.1 CONDITIONS OF INSTALLATION
It is the law that all gas appliances are installed only by a GAS SAFE Registered
Installer, in accordance with these installation instructions and the Gas Safety
(Installation and Use) Regulations 1998 as amended. Failure to install appliances
correctly could lead to prosecution. It is in your own interest and that of safety to
comply with the law.
The installation must also be in accordance with all relevant parts of the Local and
National Building Regulations where appropriate, the Building Regulations
(Scotland Consolidation) issued by the Scottish Development Department, and all
applicable requirements of the following British Standard Code of Practice.
1. B.S. 5871 Part 1 Installation of Gas Fires
2. B.S. 6891 Installation of Gas Pipework
3. B.S. 5440 Parts 1 & 2 Installation of Flues and Ventilation
4. I.S 813 : 1996 Domestic Gas Installation, issued by the National Standards
Authority of Ireland.
1.2 FLUE & CHIMNEY SUITABILITY
This appliance is designed for use with conventional brick built or lined chimneys
and fabricated flues and metal flue boxes conforming to BS 715 / BS EN 1856-2
All flues must conform to the following minimum dimensions.
Minimum diameter of circular flues 125 mm (Without Flue
Restrictor Fitted)
Minimum effective height of all flue types 3 metres
When fitting to conventional chimneys or 175mm flues it may be desirable to
fit the flue restrictor baffle (supplied) to reduce the flue flow and increase the
efficiency of the fire. Safe clearance of products must always be checked by
carrying out a smoke match test as described.
4

1.3 VENTILATION
This Portway stove has a nominal input not exceeding 7kw and therefore does not
normally require additional purpose made ventilation when installed in G.B. If,
however spillage is detected when commisioning the stove there may be
insufficient natural ventilation in the property and additional ventilation may
therefore be required. Any purpose made ventilation must be checked periodically
to ensure that it is free from obstruction.
When Installing in I.E. please consult document I.S. 813 : 1996 Domestic Gas
Installation, which is issued by the National Standards Authority of Ireland. If
installing in Northern Ireland, please consult local building regulations. Any
purpose made ventilation must be checked periodically to ensure that it is free
from obstruction.
1.4 CLEARANCES TO COMBUSTIBLE AND NON-COMBUSTIBLE
SURFACES
The Stove may be fitted below a combustible shelf providing there is a minimum
distance of 290mm above the top of the stove and that it does not extend in front
of the stove. There must be a minimum distance of 450mm to any combustible
side or rear surface. The minimum clearance to non combustible materials at the
sides and the rear is 50mm, but please ensure sufficient access to the draft
diverter on the rear right hand side of the stove can be achieved to complete the
spillage test when commisioning the stove.
1.5 FLUE / CHIMNEY INSPECTION
Before commencing installation, a flue or chimney should be inspected to ensure
that all the following conditions are satisfied.
1. Check that the chimney / flue only serves one fire place and is clear of any
obstruction. Any dampers or register plates must be removed or locked in
the open position.
2. Brick/stone built chimneys or any chimney or flue which has been used for
an appliance burning fuel other than gas must be thoroughly swept. The
base of the chimney / flue must also be thoroughly cleared of debris etc.
3. Any under-floor air supply to the fire place must be completely sealed off.
4. Ensure that the inside of the chimney / flue is in good condition along it’s
length and check that there is no leakage of smoke through the structure
of the chimney during and after the smoke pellet test.
5

5. Using a smoke pellet, check that there is an up-draught in the
chimney / flue and that the smoke can be seen issuing from the
terminal / chimney pot outside.
There must be no leakage of smoke through the structure of
the chimney during or after the smoke pellet test and it is
important to check inside upstairs rooms / loft spaces adjacent to the
chimney / flue. Check the chimney pot / terminal and general condition of
the brickwork or masonry. If the chimney or flue is in poor condition or if
there is no up-draught do not proceed with the installation. If there is a
history of down-draught conditions with the chimney / flue, a tested and
certificated flue terminal or cowl suitable for the relevant flue type should
be considered.
6. A spillage test must always be carried out during commissioning of
the appliance.
1.6 HEARTHS
This stove must only be installed on to a concrete or non-combustible hearth. The
hearth material must be a minimum thickness of 12mm with the top surface at
least 50mm above the floor. The hearth must be fitted symmetrically about the fire
opening and project at least 50mm from the base of the stove in all directions.
1.7 SPILLAGE MONITORING SYSTEM
This appliance is fitted with an spillage sensing thermal switch. This is designed
to shut the fire off in the event of a partial or complete blockage of the flue causing
a build up of combustion products in the room in which the fire is operated. The
following are important warnings relating to this spillage
monitoring system :-
1.7.1 The spillage monitoring system must not be adjusted by the installer.
1.7.2 The spillage monitoring system must not be put out of operation.
1.7.3 When the atmosphere sensing thermal switch is exchanged only a
complete original manufacturers part may be fitted. It is not possible to
replace individual parts on the pilot system on this appliance, only a
complete switch assembly (including the connecting wires) may be
fitted.
6

1.8 FITTING TO PRE-CAST FLUE INSTALLATIONS
When installing this appliance into pre-cast flues, always ensure that the spigot
restrictor baffle has been removed.
To install the stove into a pre-cast flue system, the stove must be set to the rear
flue configuration as detailed in section 2.7
The flue spigot extension supplied should be cut down to give a minmum
engagement of 25mm through the closure plate and a minimum clearance of
50mm to any part of the flue blocks.
It is important to ensure that the pre-cast flue is in good condition and is free from
extruded mortar or sealant from between the flue blocks.
This appliance has been tested for use in a pre-cast flue block system complying
with BS EN 1858. In accordance with BS EN 1858, pre-cast flues built with
directly plastered faces (front or rear) are not correctly installed as to ensure
proper operation with any type of gas stove. In some instances of this flue
construction, temperature cracking of surface plaster may occur through no fault of
the appliance. An air gap or some form of insulation material should be installed
to prevent normal flue temperatures from damaging wall surfaces.
This stove is not suitable for installation into pre-cast flue systems with a cross -
sectional are of less than 16,500mm2or any dimension less than 90mm.
7

SECTION 2
INSTALLATION OF FIRE
2.1 UNPAC ING THE STOVE
Carefully remove the stove from it’s packaging taking care not to damage the gas
controls located beneath the stove. Remove the loose items pack. Remove the
loose item packaging carefully from the the pack. Check the contents as listed :-
DO NOT UNDER ANY CIRCUMSTANCES USE THIS APPLIANCE IF THE GLASS PANEL
IS BRO EN OR NOT SECURELY FIXED TO THE DOOR ASSEMBLY.
Packing Check List
1 off Stove body, burner assembly and controls.
1 off Boxed ceramic 4 piece log fuel-bed set & bag of vermiculite.
1 off Pack of Embaglow
1 off Secondary throat plate (for rear flue applications only)
1 off Closure plate.
1 off Rating plate / securing wire - to be attached to stove
1 off Installation / user manual (combined).
1 off Guarantee card.
1 off Horizontal flue spigot (150mm).
2 off AA batteries (3 off fitted during manufacture to battery holder, 2 off for
handset supplied loose).
1 off RC handset.
2.2 INSTALLING THE STOVE
Due to the weight of the appliance it does not require additional fixing, however if
you wish to mechanically secure the stove, holes are provided in the stoves feet.
There are several methods of installing the Portway gas stove to the flue system.
Please follow the installation criteria stated below dependent upon which type of
flue you are intending to install this gas stove into :-
2.2.1 If you have a stone or brick built chimney with an integral clay flue
liner, and you wish to fit the stove with a top flue outlet, please refer
to section 2.3 for further instuctions.
2.2.2 If you have a stone, brick built chimney without an integral clay flue liner
or a flue block system and wish to fit the stove with a rear flue outlet
and closure plate, please refer to section 2.4 for further instructions.
2.2.3 If you have a stone or brick built chimney without an integral clay flue
liner, and wish to fit the stove with a top flue outlet please refer to
section 2.5 for further instructions.
2.2.4 If you have no chimney and are planning to fit the stove with a
pre-fabricated flue system, please refer to section 2.6 for further
instructions.
8

2.3 INSTALLING THE STOVE USING TOP FLUE OUTLET WHEN
CHIMNEY HAS INTEGRAL CLAY FLUE LINER.
Fig. 2
9
Minimum effective
flue height
3.0 metres
Flue termination
to comply with
BS 5440-1
Flue pipe to project not
less than 150mm
above register plate
Register plate
Integral clay chimney
liner
Minimum 50mm side and rear
clearance to non combustible or
450mm to combustible
surfaces to be strictly adhered to.
IMPORTANT NOTE : If the stove is fitted with a top flue outlet and the chimney does
not have an integral clay chimney liner then the flue must be lined with a flexible flue
liner as shown in section 2.4. Alternatively, a liner-less flue kit (part number B-
1028579) can also be utilised on chimneys without an integral clay liner providing the
chimney is in good, sound condition and does not exceed 10m in height on an
external chimney or 12m in height on an internal chimney.
The stove can also be fitted with the closure plate and a rear flue outlet as shown in
section 2.4 overpage.
In the event of clearance
issues to a structural lintel
a cranked pipe kit is
available, please quote
part number
1188-1028590.
Usage of other cranked
pipe designs is not
permitted, only the
kit specified can be utilsed
for this installation
method. It may also be
necesssary to remove the
flue restrictor plate,
subject to spillage tests.

2.4 INSTALLING THE STOVE USING REAR FLUE OUTLET WHEN
CHIMNEY HAS NO INTEGRAL CLAY FLUE LINER.
Fig. 3
10
Minimum effective
flue height
3.0 metres
Flue termination
to comply with
BS 5440-1
Use flue spigot
supplied to obtain
150mm projection
into chimney.
Closure plate
to be sealed
with adhesive
tape that
complies to
British Gas
PRS10
specification
Void volume to be a
minimum of 12dm3
Minimum 250mm from
bottom of flue duct to
base of fireplace opening
Minimum 50mm side and rear
clearance to non combustible or
450mm to combustible
surfaces to be strictly adhered to.
A trim kit is available to fit
around the perimeter of
the closure plate if
required, please quote
part number
1188-1028591

2.5 INSTALLING THE STOVE USING TOP FLUE OUTLET WHEN
CHIMNEY HAS NO INTEGRAL CLAY FLUE LINER.
Fig. 4
11
Minimum effective
flue height
3.0 metres
Flue termination
to comply with
BS 5440-1
Register plate
5” / 125mm
Flexible flue
liner
5” / 125mm
flue liner
IMPORTANT NOTE : If the stove is fitted with a top flue outlet and the chimney does
not have an integral clay chimney liner then the flue should be lined with a flexible flue
liner as shown above.
A liner-less flue kit (part number 1188-1028579) can also be utilised on chimneys
without an integral clay liner providing the chimney is in good, sound condition and
does not exceed 10m in height on an external chimney or 12m in height on an internal
chimney. Alternatively, the stove can be fitted with the closure plate and a rear flue
outlet to unlined chimneys as shown in section 2.4 on the previous page.
Minimum 50mm side and
rear clearance to non
combustible or 450mm to
combustible
surfaces to be strictly
adhered to.
In the event of clearance
issues to a structural lintel
a cranked pipe kit is
available, please quote
part number
1188-1028590.
Usage of other cranked
pipe designs is not
permitted, only the
kit specified can be utilsed
for this installation
method. It may also be
necesssary to remove the
flue restrictor plate,
subject to spillage tests.

2.6 INSTALLING THE STOVE USING A PRE-FABRICATED FLUE
SYSTEM
Fig. 5
12
Minimum effective
flue height
3.0 metres
Flue termination
to comply with
BS 5440-1
5” / 125mm
Flue liner to
BS 715
Ensure that clearances
to combustible materials
comply with building
regulations
Product shown fitted in top flue
outlet position, product can also be
fitted to pre-fabricated flue system
via rear outlet on the stove.

2.7 CHANGING THE FLUE OUTLET FROM TOP TO REAR
2.7.1 There is a choice of either top of rear flue outlet options for the Portway
gas stove. The stove is supplied from the factory with the flue outlet in
the top position, if you wish to use the rear flue outlet then follow figure
6 below to change the outlet from top to rear.
Fig. 6
IMPORTANT NOTE : WHEN SETTING UP THE STOVE TO USE A REAR FLUE
CONFIGURATION THE SECONDARY THROAT PLATE WHICH IS IDENTIFIED
ABOVE IN FIGURE 6 AND SUPPLIED IN THE LOOSE ITEMS PAC MUST BE
FITTED. THE STOVE MUST NOT BE INSTALLED ON A REAR FLUE
CONFIGURATION WITHOUT THIS COMPONENT FITTED.
13
Blanking plate
Flue spigot
Closure plate
Flue spigot extension
Flue restrictor baffle
Flue outlet plate
Secondary throat plate

2.8 REMOVAL & RE-FITTING THE FLUE RESTRICTOR BAFFLE
2.8.1 The flue restrictor baffle can be removed and re-fitted as shown below
in figure 7.
Fig. 7
2.8.2 It is recommended that the removal or re-fitting of the flue
restrictor baffle is completed with the flue pipe disconnected from
the spigot.
14
Flue restrictor baffle
Flue outlet plate
Flue spigot
Flue restrictor baffle
securing screws
Flue spigot
retaining bolts

2.9 MA ING THE GAS CONNECTION / PRESSURE TESTING
2.9.1 The gas connection should be made to the appliance inlet elbow to
using 8mm rigid tubing. To access the appliance inlet elbow you will
need to remove the burner unit as follows :-
2.9.2 Firstly the ceramic support panel must be removed to allow access to
the burner fixings. Remove the 4 off ceramic support retaining screws
as shown below in figure 8, the rear panel should also be removed and
stored in a safe location.
Fig. 8
2.9.3 Remove the 4 off screws that hold the burner in position, see figure 9
below.
Fig. 9
15
Four off ceramic
support retaining
screws
Four off burner retaining
screws
Injector retaining screw

2.9.4 Loosen the screw holding the main burner injector, the burner can then
be slid forward and lifted clear.
2.9.5 This will allow the gas supply cover plate to be removed via 4 screws
and provide access to the inlet elbow as shown below in figure 10.
Fig. 10
2.9.6 The gas supply can be routed into the stove from the rear left, right or
centrally.
2.9.7 Store the removed burner components in a safe position.
2.9.8 The gas connection to the appliance should be made to the isolating /
inlet elbow using 8mm rigid tubing. There must be no soldered joints
below the stove.
2.9.9 Remove the pressure test point screw from the inlet elbow and fit a
manometer.
2.9.10 Turn on the main gas supply and carry out a gas tightness test.
2.9.11 Fit the batteries as per section 2.10. Please then consult section 3.2 to
3.5 for full lighting instructions.
2.9.12 Refit the burner. to check that the gas pressure is 20.0 mbar (+/-
1.0mbar) 8.0 in w.g.(+/- 0.4 in w.g.).
2.9.13 Turn off the stove, remove the manometer and refit the pressure test
point screw. Check the pressure test point screw for gas tightness with
the appliance turned on using a suitable leak detection fluid or detector.
Gas Inlet elbow accessed by
removal of gas supply cover plate
16

2.10 FITTING THE BATTERIES
2.10.1 To prevent un-necessary battery drain, the battery pack that is
used to provide the remote and electronic control function for this
product is disconnected at the factory. Prior to attempting to light the
product, can the installer please ensure that the battery pack is
re-connected as shown in section 2.10.2 & 2.10.3 below.
2.10.2 Locate the battery pack in the support cradle at the bottom L/H side of
the stove (batteries are fitted to this from the factory).
2.10.3 The wire and connecting plug from the battery pack should then be
re-connected into the supply wire running from the control unit / valve.
See figure 11 below.
Fig. 11
2.10.4 Fit 2 off AA batteries to the handset by unclipping the rear cover, fitting
the batteries then replacing the rear cover. Switch the white power
isolation switch to the “on” position on the valve after connecting the
battery pack.
17
Battery pack
Power isolation switch
location - slide to “on”
position after
connecting battery pack
Connecting point in wire - battery pack to control valve

SECTION 3
ASSEMBLING FUEL BED AND COMMISSIONING
3.1 ASSEMBLING THE LOG FUEL BED
3.1.1 Place a thin, even layer of vermiculite over the fuel tray as shown below
in figure 12, ensuring that the air slots and pilot aperture are not
obstructed as indicated. Fit the optional Embaglow material if required
in the central section as shown by the dotted area.
Fig. 12
3.1.2 Position Log “A” onto the locating pins on the rear of the fuel tray as
shown below in figure 13, using the holes to position securely.
Fig. 13
18

3.1.3 Position Log “B” onto Log “A” as shown below in figure 14, using the
locating lug on Log ”A” and the locating point on Log “B” as a guide for
placement as shown below in figure 14.
Fig. 14
3.1.4 Position Log “C” onto Log “A” as shown below in figure 15, using the
locating lug on Log ”A” and the locating point on Log “C” as a guide for
placement as shown below in figure 15.
Fig. 15
19
Log “B” correctly located on Log “A”
Log “C” correctly located on Log “A”
