POSIFLEX HS-2510W User manual

1
Package Contents
9HS-251xW desktop POS x 1
9Power adaptor x 1
9Power cord x 1
9Desktop mounting kit pack x 1
(including 4 fixing screws, 4
plastic anchors, and 1 desktop
mounting bracket)
9Desktop POS user manual x 1
9Recovery or information CD x 1
9Optional item(s)
Product Features
Standard Features
System
zIntel Bay Trail-D J1900 2.0G CPU up to 2.42G, 2M Cache,
quad-core Celeron CPU
zDDR3L 1333 FSB, SO-DIMM socket *1, Max 8G
Mechanical Structure
zFan free structure for harsh environment
zMonitor tilt adjustment angle from 17° to 45°
Display
z9.7"/12" LCD touch panel, 1024x768 resolution
zP-CAP touch panel
HS-2510W/HS-2512W
JIVA Desktop POS
User Manual
15590901010 Ver. Original
http://www.posiflex.com

2
Optional Items
System
zSSD storage device
zDDR3L 1333 FSB, SO-DIMM socket *1, Max 8G
zWindows XP, POSReady 7, Windows 7,
Windows
Embedded 8.1 Industry, Android per request
WIFI
zWireless LAN
Views of the HS-251xW
Front View of HS-251xW
Rear View of HS-251 xW
Top I/O Interface Cover
Bottom I/O Interface Cover
Cable Exit
Power LED
LCD Touch Panel
3-track
Magnetic Stripe Reader
Smart Card Reader
(Optional)

3
Left Side View of HS-251xW
Bottom View of HS-251xW
View of I/O Interface of HS-251wX
Top I/O Interface
1 COM (DB9) Port 2 DB25 parallel port
3 USB3.0 Port 4 VGA Port
Power Button
Bottom IO Interface
1
2
3
4

4
Bottom I/O Interface
1 12VDC-IN Power Jack 2 RJ11 Cash Drawer Port
3 USB2.0 Port 4 RJ45 LAN Port
5 COM Port 6 PS2 Port for Keyboard
7 Line-Out Jack
Connecting Power Adapter and I/O Cables
Follow the steps listed below to open the bottom I/O-port
protective cover and connect cables.
1. Make the desktop POS lie on
the surface of a desk and the
LCD touch panel face down.
2. Press the portion A with
thumb and then lever the
cover with forefinger in the
direction B.
3. Remover the cover.
1
2
3
4
5
6
7
A
B

5
4. Connect power adapter and
I/O cables to the bottom I/O
interface of the desktop POS.
5. Make the cover join to the
wedge portions of the rear
plate of the POS.
6. Determine that the cover is
well wedged to the wedge
portions of the rear plate of
the POS.
7. Gather the I/O cables together
for cable arrangement and
lever down the 2 hooks of the
cover to cover the I/O
interface.

6
8. Determine that the I/O
interface is covered and the
cable passes through the cable
exit.
Connect I/O cables to the top I/O interface
If you want to connect I/O cable to the top I/O interface, follow
the steps listed below to open the top I/O-port protective cover
and connect I/O cables to the top I/O interface.
1. Press the cable-exit cover with
thumb.
2. Pull the top I/O-port
protective cover in the
direction A.
3. Remove the cover.
Cable out
Direction A

7
4. Connect I/O cables to the top
I/O interface of the desktop
POS and then gather the
cables together in the cable
exit.
5. Break the cable-exit cover.
6. Make the cover join to the
wedge portions of the rear
plate of the POS.
7. Determine that the cover is
well wedged to the wedge
portions of the rear plate of
the POS.
8. Push the cover to make the 2
hooks of the cover to wedge
the 2 wedge portions of the
rear plate of the POS.
Cable
Exi
t

8
9. Determine that the I/O
interface is covered and the
cable passes through the cable
exit.
Mounting the POS onto a Table
To avoid the POS from backward tilting and wagging when a
user touches the LCD panel, use the desktop mounting kit
shipped with the POS to hold and secure the POS firmly on a
table. Please follow the steps below to mount the POS.
1. Determine a position of a table onto which the POS is
mounted. Then, take the desktop mounting bracket out of the
desktop mounting kit pack. Through the 2 holes formed on
the bracket, drill 2 holes on the table and plug 2 plastic
anchors into the 2 holes. Then, hold the bracket and then
apply the 2 self-tapping screws into the 2 holes to secure the
bracket.
2. Align the 2 screw bolts on the
bottom of the POS with the 2
tracks of the bracket.
Cable out

9
3. Push hard the POS backward along the 2 tracks of the
bracket on the table to firmly secure the POS.
To completely mount the desktop POS onto the table, you can
apply two more self-taping screws into the 2 holes formed on the
base stand of the POS, as illustrated below.
Powering ON the HS-251xW
Then press the power button to power
on the POS. To power it off, press the
button again.
Once powering off the system, if you
want to power it on again, please wait
for at least 3 seconds.
If the system hangs due to a reason, such as software resource
conflict, please press and hold the power button for over 10
seconds around to forcedly shut down the system.

10
Status LED Indicator
After powering ON the HS-251xW, you can read the system
operation status from the power LED indicator. The LED status is
described below.
LED Status Description
Solid blue System power ON
POWER Solid orange System standby
ERROR Solid red
Brief lit indicates printer busy
PAPER OUT Solid red
Paper Out
Installing an Operating System
This product is highly professional equipment. Therefore, we do
NOT encourage you to install any operating system into this
machine without professional assistance. Posiflex Technology,
Inc. shall not be responsible for any technical support to
questions on this aspect. We suggest that you contact your dealer
for OS installation.
Operating System Recovery
For the HS-251xW main system preloaded with an operating
system on HDD, Posiflex provides a recovery CD shipped with
the main system for the preloaded operating system. The system
integrator shall take care of software restoration after the OS is
recovered.
If you plan to recover your operating system, we do NOT
encourage you to recover any operating system. Please contact
your service center for operating system recovery.
Operating the Built-in Printer
HS-251xW is provided with a built-in
printer. This built-in printer works to
get printer-ready. For the detailed
information, refer to the installation as
follows:

11
LOADING PAPER
Desk Top Application
1. Press down the hood release button to release the paper cover as in Pix 1.
2. Pull down the released paper cover wide open manually as in Pix. 2.
3. Drop the thermal paper roll inside the printer in orientation as in Pix 3.
4. Close the paper cover back leaving the tail of the paper roll coming out
of the opening between the hood and the top cover as in Pix. 4.
5. Excessive paper will cut when changing the paper at power on status.
Adjustment of LCD Monitor for a Better Viewing Angle
For an optimal viewing angle, you can adjust the LCD monitor up
and down around the directions A and B at the angle from 17° to
45°.
Optional Upgrade Kits
Posiflex HS-251xW can work with multiple optional upgrade kits,
such as MSR, Smart Card Reader and the like. For the detailed
instruction, refer to the technical manual of HS-251xW or each of
the user manuals of the optional upgrade kits.
A
B
Pix. 1 Pix. 2 Pix. 3
Release Button
Paper Roll
Pix. 4
Paper Roller Orientation

12
Specifications
HS-2510W HS-2512W
CPU Intel Bay Trail-D J1900 2.0G CPU up to 2.42G, 2M Cache, quad-
core Celeron CPU
Memory DDR3L 1333 FSB, SO-DIMM socket *1, Max 8G
OS POSReady 7, Windows 7,
Windows Embedded 8.1 Industry,
Android per request
Display 9.7" 1024 x 768 LCD P-CAP
touch panel
12" 1024 x 768 LCD P-CAP
touch panel
VGA
Interface D-SUB 15 Pin, with 12V power for Posiflex LCD Monitor
Storage Two SATA ports for 2.5'' or 1'' SATA device; EMMC adaptor
Board 8G/16G/32G on M/B
Ethernet 10/100/1000 Mb, 1 port
Wireless
LAN Optional, with a reserved external antenna
Power
Supply 12VDC power adaptor, 120W
Serial Port
3 ports – DB9 x 2 on bottom side (I/O plate), RJ-45 x 1 on top side
(I/O plate); +5V software switch control & jumper for COM1/2/3,
+12V jumper control for COM1/2/3
Parallel Port Co-design for I/O plate DB25 connector or internal connector for
printer
CR Port 1 port, controlling 2 cash drawers
USB Port 4 ports, 1 USB3.0 port on the top I/O interface and 3 USB2.0 ports
on the bottom I/O interface
PS/2 KB Port 1 port on the bottom I/O plate
Audio 1 line-out jack
Extension
Slot mini PCI-E slot, half-card size
Power
Switch
On M/B at right side wall of system, instant power ON when the
power switch is pushed.
Printer Built-in Printer
Power-Off
Control
By hardware switch or by software, continuous push for 2 ~ 3 sec to
enable the power OFF function
Power-ON
Wake-Up Through alarm/LAN

13
HS-2510W HS-2512W
Mechanical
Installation Desktop
LED
Indicator Power on (blue) / standby (orange), bi-color LED indicators
Touch
Controller USB interface
Touch
Sensor P-CAP touch
Brightness
Control By software
Operating
Condition
0°C - 40°C, 20%RH - 90%RH (Equipped with HDD);
0°C - 50°C, 20%RH - 90%RH (Equipped with SSD)
Storage
Condition -20°C - 70°C, 10%RH - 90%RH
To get the detailed information on ϡ
ϡϡ
ϡ HS-251xW, please download the
technical manual of this model from Posiflex Global Website
(http://www.posiflex.com/en-global/Download/download).

14
