PotteryBarn FT-161 User manual

R
evised
December 6, 2017
FT-161Ternary Fountain
-WINTERCARE-
Fountainbowls/topsandotherfountaincomponents,whichcollect water, shouldnotbeleftoutsideinthewinter since anycomponent,
whichfillswithwater andfreezesmaycrack.Likewise, componentssuchaspedestals,whichremaininabasin,filledwithwater,
whichthenfreezes,mayalsocrackor crumble. Ideally, therefore, afountainshouldalwaysbestoredindoorsor inadryprotected
place suchasacoveredporchawayfromtheelements. However, ifafountainmustbeleftoutside:
(1) Removepump, rubber stoppers, drainpipes, finials,andother smallcomponentsfor storageindoors. Note that stoppersor
drainpipesareremovedtoallowdrainageintheeventwater accumulatesinanybasin.
(2) Raisefountainbasefromgroundwithwood stripssothat basewill notfreeze tothegroundsurface.
(3) Cover or wrapthefountainwithburlapor other absorbentmaterial (oldblanket or towel) andthencover securelywith
plastic,making surethat water will notaccumulate inthebasinor other fountaincomponentandfreeze;
(4) Checkfountainperiodicallytoensurethatplastic issecureandwater isnotaccumulating inanyfountaincomponent.
-GENERALFOUNTAINTIPS-
Install fountainsonalevel surface. Youwill needaproperlygrounded110-volt (AConly) GFCI protectedreceptaclenear the
fountainfor your pump. All pumpsaresubmersible andmustbecompletelyunderwater tofunctionproperly. Testall pumpsand
adjusttofull outputprior toassembly. Itisnotrecommendedthat fountainsbeplaced
directlyongrassor dirt. Positionthechannel opening at thebaseofeachfountaintoward
theelectrical outlettobeusedsince thepumpcord will bethreadedthrough thisopening.
CheckoutYouTubefor a“Howto”video.
For moreCampania product informationvisit www.campaniainternational.com
All of ourcaststone is proudly
Pump KitPartsList
PK140 pump (1)
#10 M-Seriesstopper(1)
Approx.6”length of1/2”BlackNon-kinktubing (1)***
1”length of5/8”cleartubing (1)***
1”length of1/2"CPVCpipe(1)***
Adhesive dots(4)*
Hose clamps(1)**
*Preventsthefountainfromscratching the surfaceit rests on.
** Hoseclamps maybeused asflowrestrictors
*** Tubing has been preassembled
FOUNTAININFORMATION:
Thisfountain holdsapproximately21/2gallonsof
water.
Noavailable fountain coversare recommendedforthis
fountain.
Norefill device orsubmersible lightsare suggested for
thisfountain
TOOLSREQUIRED:
Bubble Level
PUMPINFORMATION:
OEMPF140 - 140GPH Pump
6FTcord length

FT
-
161
Ternary
Fountain
R
evised
December 6, 2017
Assembleyourfountainon alevelsurface capableofholdingaminimumof67 pounds with an approximate1/4
square footfootprint.
FT-161D(26 lbs)
15.25”Wx4.75”H
FT-161C(4 lbs)
6.75”Wx3.25”H
FT-161B(13 lbs)
11”Wx3.25”H
FT-161A(3 lbs)
6”Wx2.5”H
1. Place thebasin(FT-161D) intoposition wherethe
fountainwill beinstalled, ensuring that it islevel.
2. Assemble thepumpkit.
a. NOTE: All pumpscomewith 1adapteralready
inserted intothe pumpand 2adapterssecured tothe
power cord.
i. Thisfountainuses thelargestadapter provided.
b. Using ahoseclamp, attachthe1/2”non-kink tubingto
thepumpoutlet.
c. Place thestopper aroundthepumpcordapproximately6
inchesfromthepump.
3. Feedthepumpcordall thewaythrough thehole and
thechannel inthebasin(FT-161D) toensurethe
fountainwill belevel.
a. Lineup thesplit inthestopperwiththedirectionthatthe
channelunder thebasin goes.
b. Forthebest fit, laythepumpon itsside.
4. FIRMLY press thestopper intothehole evenly.
5. Place thepumphouse(FT-161C) over thepumpand
centeredinsideofthebasin(FT-161D).
6. Connect theend of thepreassembledtubing withthe
CPVCpipeintothecoupling protruding fromthe
bottomofthemediumbowl (FT-161B).
7. Center and lowerthemediumbowl(FT-161B) onto
thepumphouse(FT-161C).
8. Fit thesmall bowl (FT-161A) ontothemediumbowl
(FT-161C) by pressing theprotrudingCPVCpipe
fromthesmall bowl intothehole inthetop ofthe
mediumbowl.
9. Fill thefountainwithwater.
