Poulan Pro BVM200VS User manual

545103471
3/27/09
Replaces
545103471 - 1/07/09 Page:
PARTS LIST BVM200VS
1
Parts List No.
Date
MODEL
NOTE : Illustration may differ from actual model due to design changes.
1. 530015814 Screw
2. 545135806 Assy - Engine Cover
3. 530015880 Screw
4. 545134001 Shield - Baffle
5. 545099101 Baffle
6. 530016391 Screw
7. 545081852 Kit - Starter Pulley
8. 530042086 Spring - Starter
9. 545107101 Tube - Starter Rope
10. 530054834 Handle - starter
11. 545081833 Kit - Rope
12. 545081830 Kit - Switch (momentary) (Incl. 13)
13. 545128201 Protector - Switch
14. 545099001 Bearing
15. 530626605 Nut
16. 545113803 Trigger - Throttle
17. 545134103 Assy - Scroll LH (Incl. 19,20)
18. 530015814 Screw
19. 545100801 Door- Vac
20. 545115601 Spring - Vac Door
21. 545144501 Knob - Blower
22. 530016406 Screw - Handle Vac
23. 530092322 Washer - Lock
24. 545109901 Washer - Impeller
25. 545113601 Assy-Impeller
26. 545113701 Spacer - Flywheel
27. 530015197 Nut
28. 530016386 Screw
29. 545161604 Assy-Scroll Assy. RH (Incl. 14)
30. 545101201 Handle - Vac
31. 545100401 Assy - Fuel Tank (Incl. 32,33,34,35)
32. 530095646 Assy - Fuel Pickup
33. 530069247 Kit - Fuel Line (carb/purge)
34. 530069216 Kit - Fuel Line (tank/purge)
35. 530057973 Assy - Fuel Cap w/retainer
36. 530016445 Screw - Fuel Tank Retainer
545146927 Manual
545001245 Decal - Warning
545001285 Decal - Start Instructions
522928602 Decal - Spark Arrestor Warning
WARNING
All repairs, adjustments and
maintenance not described in
the Operator’s Manual must be
performed by Qualified Service
Personnel.
Ref. Part No. Description Ref. Part No. Description
Not Shown
= New Part Number For This IPL
= Refer to the Service Reference Indicated for more information.(Located at the END of the IPL)
31 30
1
228
26
23
24
25
22
18
27 20 19
21
15
29
34
35 32
12 13
17
9
8
5
4
7
6
36
3
16
33
11
10
14

545103471
3/27/09
Replaces
545103471 - 1/07/09 Page:
PARTS LIST BVM200VS
2
Parts List No.
Date
MODEL
NOTE : Illustration may differ from actual model due to design changes.
1. 545090001 Assy - Muffler (Incl. 2,3,4,5)
2. 530015241 Screw
3. 545081845 Kit - Spark Screen
4. 530058982 Bolt
5. 545081832 Gasket-Muffler (gasket kit)
6. 545115301 Cylinder
7. 530015953 Bolt
8. 952030249 Spark Plug (RCJ-6Y)
9. 545084901 Adapter - Carb.
10. 530016441 Screw
11. 545115501 Linkage - Throttle
12. 545081831 Kit - Carb. Assy (WT847) (Incl. 13,18)
13. 545157102 Lever- Choke (Gold)
14. 545112603 Base - Airbox
15. 530016429 Screw
16. 545116801 Filter
17. 545112702 Cover - Air Box Filter
18. 530035497 Bulb - Purge (walbro 188-16)
19. 545081832 Gasket (Carb / Adapter) (gasket kit)
20. 545081832 O-Ring (Adapter / Cylinder) (gasket kit)
21. 545081864 Kit - Piston / Connecting Rod (Incl. 22,23,24)
22. 530012472 Ring - Piston
23. 530015162 Retainer - Wrist Pin
24. 545081865 Kit - Assy. Connecting Rod
25. 545158001 Module - Ignition
26. 530016357 Screw
27. 545127601 Assy - Wire Harness
28. 545081832 O-Ring (Cyl/Crankcase) (gasket kit)
29. 530015828 Washer
30. 530054115 Assy - Flywheel
31. 530015941 Retainer - Crankshaft
32. 530055728 Bearing - Outer
33. 530019264 Seal
34. 530032125 Bearing - Inner
35. 530012582 Assy - Crankcase (Incl. 32,33,34)
36. 545102102 Assy - Crankcase & Crankshaft (Incl. 31,35)
37. 545081832 O-Ring (Rear Plug) (gasket kit)
38. 530057954 Assy - Rear Plug (Incl. 37)
39. 530016386 Screw
40. 545081832 Kit - Gasket (Incl. 5,19,20,28,37)
Ref. Part No. Description Ref. Part No. Description
= New Part Number For This IPL
= Refer to the Service Reference Indicated for more information.(Located at the END of the IPL)
25
31
24
30
20
18 19
11
17 16 15
12
13
14
23
8
6
10 9
7
4
532
29
26 27
21 23
22
1
36
35
34 33 32
39
40
38 37
GASKET
KIT
28
WARNING
All repairs, adjustments and
maintenance not described in
the Operator’s Manual must be
performed by Qualified Service
Personnel.

545103471
3/27/09
Replaces
545103471 - 1/07/09 Page:
PARTS LIST BVM200VS
3
Parts List No.
Date
MODEL
NOTE : Illustration may differ from actual model due to design changes.
= New Part Number For This IPL
1. 545099401 Tube - Upper Vac
2. 530095589 Tube - Lower Vac
3. 545116601 Tube - J
4. 530095564 Assy - Vac Bag
5. 545100501 Tube - Upper Blower
6. 545100601 Tube - Lower Blower
7. 545151201 Nozzle - High Speed
= Refer to the Service Reference Indicated for more information.(Located at the END of the IPL)
Ref. Part No. Description
6
7
1
234
5
WARNING
All repairs, adjustments and
maintenance not described in
the Operator’s Manual must be
performed by Qualified Service
Personnel.
