Poulan Pro PPB200 LE User manual

ENGLISH ESPAÑOL FRANÇAIS
WARNING:
Read and follow all Safety Rules and Operating Instructions before
using this product. Failure to do so can result in serious injury.
ADVERTENCIA:
Lea el manual de instrucciones y siga todas las advertencias e
instrucciones de seguridad. El no hacerlo puede resultar en le-
siones graves.
AVERTISSEMENT:
Lire lemanueld’instructions etbien respecter tous lesavertisse-
ments et toutes les instructions de sécurité. Tout défaut de le
faire pourrait entraîner des blessures graves.
Instruction Manual
Manual de Instrucciones
Manuel d’Instructions
PPB2000 LE
Electrolux Home Products, Inc.
104 Warren Road
Augusta, GA 30907
Copyright E2004 Electrolux Home Products, Inc. 530164283 2/5/04
R
IMPORTANT MANUAL -- Do not throw away
MANUAL IMPORTANTE -- No lo descarte
MANUEL IMPORTANT -- À Conserver

-- 2 --
SAFETY RULES
WARNING: Failure to follow all
Safety Rules and Precautions can result in
serious injury.
KNOW YOUR UNIT
SRead your instruction manual carefully until
you completely understand and can follow
all warnings and safety rules before operat-
ing the unit.
DRestrict unit to users who understand and
will follow all warnings and safety rules in
this manual.
WARNING: Inspect area before start-
ing unit. Remove all debris and hard objects
such as rocks, glass, wire, etc. that can rico-
chet, be thrown, or otherwise cause injury or
damage during operation.
Use your unit as a blower for:
DSweeping debris or grass clippings from
driveways, sidewalks, patios, etc.
DBlowing grassclippings, straw, orleaves into
piles, around joints, or between bricks.
Use your unit as a vacuum for:
DPicking up dry material such as leaves,
grass, small twigs, and bits of paper.
DFor best results during vacuum use, operate
your unit at high speed.
DMove slowly back and forth over the mate-
rial as you vacuum. Avoid forcing the unit
into apile of debris asthis canclog theunit.
DKeep the vacuum tube about an inch above
the ground for best results.
PLAN AHEAD
DAlways wear eye protection when operat-
ing, servicing, or performing maintenance
on unit. Wearing eye protection will help to
prevent rocks ordebris from being blown or
ricocheting into eyes and face which can
result in blindness and/or serious injury.
Eye protection should be marked Z87.
DAlways wear foot protection. Do not go
barefoot or wear sandals.
DAlways wear respirator or face mask when
working with unit in dusty environments.
DSecure hair above shoulder length. Secure
or remove jewelry, loose clothing, or cloth-
ing with loosely hanging straps, ties, tas-
sels, etc. They can be caught in moving
parts.
DDo not operate unit whenyou aretired, ill,up-
set, or if you are under the influence of alco-
hol, drugs, or medication.
DKeep children, bystanders, and animals
away from work area a minimum of 30 feet
(10 meters) when starting or operating unit.
Do not point the blower nozzle in the direc-
tion of people or pets.
HANDLE FUEL WITH CAUTION, IT IS
HIGHLY FLAMMABLE
DEliminate all sources of sparks or flame (in-
cluding smoking, open flames, or work that
can cause sparks) inthe areas where fuel is
mixed, poured, or stored.
DMix and pour fuel in an outdoor area; store
fuel in a cool, dry, well ventilated place; use
an approved, marked container for all fuel
purposes.
DDo not smoke while handling fuel or while
operating the unit.
DMake sure the unit is properly assembled
and in good operating condition.
DDo not fill fuel tank while engine is hot or
running.
DAvoid spilling fuel or oil. Wipe up fuel spills
before starting engine.
DMove at least 10 feet (3 meters) away from
fuel and fueling site before starting engine.
DAlways store gasoline in a container ap-
proved for flammable liquids.
OPERATE YOUR UNIT SAFELY
WARNING: Stop the engine before
opening the vacuum inlet door. The engine
must be stopped and the impeller blades no
longer turning to avoid serious injury from the
rotating blades.
DInspect unit before each use for worn,
loose, missing, or damaged parts. Do not
use until unit is in proper working order.
DKeep outside surfaces free of oil and fuel.
DNever start or run engine inside a closed
room, building or other unventilated area.
Breathing exhaust fumes can kill.
DTo avoid static electricity shock, do not
wear rubber gloves or any other insulated
gloves while operating unit.
DDo not set unit on any surface except a
clean, hard area while engine is running.
Debris such as gravel, sand, dust, grass,
etc. could be picked up by the air intake and
thrown out through discharge opening,
damaging unit, property,orcausing serious
injury to bystanders or operator.
DAvoid dangerous environments. Do not use
in unventilated areas or where explosive
vapors or carbon monoxide build up could
be present.
DDo not overreach or use from unstable sur-
faces such as ladders, trees, steep slopes,
rooftops, etc.Keep firmfooting and balance
at all times.
DNever place objects inside the blower
tubes; always direct the blowing debris
awayfrompeople, animals, glass, andsolid
objects such as trees, automobiles, walls,
etc. The forceof aircancauserocks, dirt, or
sticks to be thrown or to ricochet which can
hurt people or animals, break glass, or
cause other damage.
DNever run unit without the proper equip-
ment attached. When using your unit as a
blower, always install blower tubes. When
using your unit as a vacuum, always install
vacuum tubes and vacuum bag assembly.
Make sure vacuum bag assembly is com-
pletely zipped.
DCheck air intake opening, blower tubes,
vacuum tubes, and elbow tube frequently,
always with engine stopped and spark plug

-- 3 --
disconnected. Keep vents and discharge
tubes free of debris which can accumulate
and restrict proper air flow.
DNever place any object in the air intake open-
ing as this could restrict proper air flow and
cause damage to the unit.
DNever use for spreading chemicals, fertiliz-
ers, orother substances which maycontain
toxic materials.
DTo avoid spreading fire, do not use near leaf
or brush fires, fireplaces, barbecue pits,
ashtrays, etc.
DUse only for jobs explained in this manual.
MAINTAIN YOUR UNIT PROPERLY
DHave all maintenance other than the rec-
ommended procedures described in the in-
struction manual performed by an autho-
rized service dealer.
DDisconnect spark plug before performing
maintenance except for carburetor adjust-
ments.
DUse only recommended Poulan PRO!re-
placement parts; use of any other parts
may void your warranty and cause damage
to your unit.
DEmpty fuel tank before storing the unit. Use
upfuel leftincarburetorbystartingengineand
letting it run until it stops.
DDo not use any accessory or attachment
other than those recommended by manufac-
turer for use with your unit.
DDo not store the unit orfuel in a closed area
where fuel vapors can reach sparks or an
open flame from hot water heaters, electric
motors or switches, furnaces, etc.
DStore in a dry area out of reach of children.
SPECIAL NOTICE: Exposure to vibra-
tions through prolonged use of gasoline pow-
ered hand tools could cause blood vessel or
nerve damage in the fingers, hands, and
joints of people prone to circulation disorders
or abnormal swelling. Prolonged use in cold
weather hasbeenlinked toblood vessel dam-
age in otherwise healthy people. If symptoms
occur such as numbness, pain, loss of
strength, change in skin color or texture, or
loss of feeling in the fingers, hands, or joints,
discontinue the use of this tool and seek
medical attention. An antivibration system
does not guarantee the avoidance of these
problems. Users who operate power tools on
a continual and regular basis must monitor
closely their physical condition and the condi-
tion of this tool.
SPECIAL NOTICE: This unit is equipped
with a temperature limiting muffler and spark
arresting screen which meets the require-
ments of California Codes 4442 and 4443. All
U.S. forest land and the states of California,
Idaho, Maine, Minnesota, New Jersey, Ore-
gon, and Washington require by law that
many internal combustion engines be
equipped with asparkarresting screen. If you
operate in alocale where such regulations ex-
ist, youarelegally responsible formaintaining
the operating condition of these parts. Failure
to do so is a violation of the law. Refer to the
MAINTENANCE section for information on
maintenance of the muffler and spark arrest-
ing screen.
ASSEMBLY
WARNING: Stop engine and be sure
the impeller blades have stopped turning be-
fore opening the vacuum inlet door or at-
tempting to insert or remove the vacuum or
blower tubes. The rotating blades can cause
serious injury. Always disconnect the spark
plug before performing maintenance or ac-
cessing movable parts.
WARNING: If you receive your unit
assembled, check each step to insure your
unit is properly assembled and all fasteners
are secure. Follow all safety information in
the manual and on the unit.
DA standard screwdriver is required for as-
sembly.
BLOWER TUBE ASSEMBLY
1. Align the rib on the blower tube with the
groove in the blower outlet; slide the tube
into place.
NOTE: Knob must be loose enough toallow
blower tube to be inserted in blower outlet.
Loosen knob by turning counterclockwise.
Blower
Tube
Blower
Outlet
Rib
Groove
2. Secure the tube by turning the knob clock-
wise.
3. To remove the tube, turn the knob counter-
clockwise to loosen the tube; remove the
tube.
VACUUM BAG ASSEMBLY
1. Open the zipper on the vacuum bag and
insert the elbow tube.
2. Push the small end of the elbow tube
through the small opening in the bag.
Small
Opening
Zipper
Opening
Elbow
Tube
Rib

-- 4 --
NOTE: Make sure edge ofthe small opening
is flush against the flared area of the elbow
tube, and the rib on the elbow tube is on the
bottom.
3. Close thezipper onthe bag. Make surethe
zipper is closed completely.
4. Remove blower tube from engine.
Rib
Groove
5. Insert the elbow tube into the blower outlet.
Make sure elbow tube rib is aligned with
the blower outlet groove.
6. Turnknob clockwise to secure elbow tube.
VACUUM TUBE ASSEMBLY
WARNING: Stop engine and be sure
the impeller blades have stopped turning be-
fore opening the vacuum inlet door or at-
tempting to insert or remove the vacuum or
blower tubes. The rotating blades can cause
serious injury.
1. Align the lower vacuum tube as shown.
Push lower vacuum tube into upper vacu-
um tube.
Lower Vacuum Tube
Upper Vacuum
Tube
2. Insert the tip of a screwdriver into the latch
area of the vacuum inlet.
Latch Area
Blower
Outlet
Vacuum
Inlet Cover
Latch
Area
3. Gently tilt the handle of the screwdriver to-
ward the back of the unit to release the
latch while pulling up on the vacuum inlet
cover with your other hand.
4. Hold the vacuum inlet cover open until up-
per vacuum tube is installed.
Vacuum Inlet
Vacuum
Inlet
Cover
Retaining Post
5. Place the hooks of the upper vacuum tube
on the retaining posts of the unit.
6. Pivot the tube until it is secured to the
blower unit by the vacuum inlet latch.
Retaining
Post
Hook
Inlet Cover
Latch
PIVOT
HOW TO CONVERT UNIT FROM
VACUUM USE TO BLOWER USE
1. Remove the vacuum tubes by inserting
the tip of a screwdriver into the latch area
of the vacuum inlet.
2. Gently tilt handle of screwdriver toward
the back of the unit to release the latch
while pulling up on the upper vacuum tube
with your other hand.
Latch Area
3. Remove the vacuum bag.
4. Close the vacuum inlet cover and make
sure it is latched closed.
5. Reinstall the blower tube (see BLOWER
TUBE ASSEMBLY).

-- 5 --
SHOULDER STRAP ADJUSTMENT
1. Hold the unit as shown with the muffler side
facing away from your body and clothes.
2. Pass the shoulder strap over your head
and onto your right shoulder.
3. Extend your left arm toward the rear of the
vacuum bag.
4. Adjust shoulder strap until the vacuum
bag/shoulder strap seam lies between
your thumb and index finger.
5. Make sure air flows freely from the elbow
tube into bag. If bag is kinked, the unit will
not operate properly.
OPERATION
KNOW YOUR BLOWER
READ THIS INSTRUCTION MANUAL AND SAFETY RULES BEFOREOPERATING YOURUNIT.
Compare the illustrations with yourunit to familiarize yourself with the location of the various controls
and adjustments. Save this manual for future reference.
Choke Lever
Fuel Mix
Fill Cap
Starter
Rope
Throttle
Lever
Spark Plug
Blower
Tube
Primer Button
Rear
Handle
Lower
Vacuum Tube
Upper
Vacuum Tube
Vacuum Bag
Elbow Tube
THROTTLE LEVER
The THROTTLE LEVER is used to select the
desired engine speed and to stop the engine.
Movethethrottle lever tothe position for
full speed operation. Move the throttle lever
tothe position foridlespeed. To stopthe
engine, move the throttle lever to the STOP
position.
PRIMER BUTTON
The PRIMER BUTTON removes air from the
carburetor and fuel lines and fills them with fuel.
This allows you to start the engine with fewer
pulls on the starter rope. Activate primer button
bypressing it andallowing it to returnto its origi-
nal position.
CHOKE LEVER
The CHOKE helps to supply fuel to the engine
to aid in cold starting. Activate the choke by
moving the choke lever to the FULL CHOKE
position. After engineattempts tostart, movethe
choke lever to the HALF CHOKE position.
Once engine starts, move choke lever to the
RUN position.

-- 6 --
OPERATING POSITION
Blower
Eye
Protection
Vacuum
OPERATING TIPS
SWhile vacuuming or blowing debris, hold
the unit with the muffler side facing away
from your body and clothes (see OPERAT-
ING POSITION illustration above).
STo reduce the risk of hearing loss
associated with sound level(s), hearing
protection is required.
STo reduce the risk of injury associated with
contacting rotating parts, stop the engine be-
fore installing or removing attachments. Do
not operate without guard(s) in place.
SOperate power equipment only at reasonable
hours--not early in the morning or late at night
when people might be disturbed. Complywith
times listed in local ordinances. Usual recom-
mendations are 9:00 a.m. to 5:00 p.m.,
Monday though Saturday.
STo reduce noise levels, limit the number of
pieces of equipment used at any one time.
STo reduce noise levels, operate power
blowers at the lowest possible throttle
speed to do the job.
SUse rakes and brooms to loosen debris be-
fore blowing.
SIn dusty conditions, slightly dampen sur-
faces or use a mister attachment when wa-
ter is available.
SConserve water by using power blowers
instead of hoses for many lawn and garden
applications, including areas such as gutters,
screens, patios, grills, porches, and gardens.
SWatchoutfor children, pets, open windows,
or freshly washed cars. Blow debris away
safely.
SUse the full blower nozzle extension so the
air stream can work close to the ground.
SAfter using blowers and other equipment,
CLEAN UP! Dispose of debris in trash re-
ceptacles.
BEFORE STARTING ENGINE
WARNING: Be sure to read the fuel
information in the safety rules before you be-
gin. If you do not understand the safety rules,
do not attempt to fuel your unit. Call
1-800-554-6723.
FUELING ENGINE
WARNING: Remove fuel cap slowly
when refueling.
This engine is certified to operate on
unleaded gasoline. Before operation,
gasoline must be mixed with a good quality
synthetic 2-cycle air-cooled engine oil
designed to be mixed at a ratio of 40:1.
Poulan/Weed Eater!brand synthetic oil is
recommended. Mix gasoline and oil at a ratio
of 40:1. A 40:1 ratio is obtained by mixing 3.2
ounces (95 ml) of oil with 1 gallon (4 liters) of
unleaded gasoline. DONOT USEautomotive
oil or marine oil. These oils will cause engine
damage. When mixing fuel, follow
instructions printed on container. Once oil is
added to gasoline, shake container
momentarily to assure that the fuel is
thoroughly mixed. Always read and follow the
safety rules relating to fuel before fueling your
unit.
IMPORTANT
Experience indicates that alcohol blended
fuels (called gasohol or using ethanol or
methanol) can attract moisture which leads to
separation and formation of acids during
storage. Acidic gas can damage the fuel
systemofanengine while instorage. Toavoid
engine problems, empty the fuel system
before storage for 30days orlonger. Drain the
gas tank, start the engine and let it rununtil the
fuel lines and carburetor are empty. Usefresh
fuel next season. Never use engine or
carburetor cleaner products in the fuel tank or
permanent damage may occur.
NOTE: Unit must be placed on its side when
adding fuel (see illustration below).
TO STOP THE ENGINE
DTo stop the engine, move the throttle lever
to the STOP position.
BEFORE STARTING THE ENGINE
WARNING: You MUST make sure
the tubes are secure before using the unit.
DFuel engine. Move at least 10 feet (3 me-
ters) away from the fueling site.
DHold the unit in the starting position as
shown. Make sure the blower end is di-
rected away from people, animals, glass,
and solid objects.

-- 7 --
Blower
Vacuum
STARTING POSITION
WARNING: When starting engine,
hold theunit asillustrated. Donot setunit onany
surfaceexcept aclean, hardarea whenstarting
engine or while engine is running. Debris such
as gravel, sand, dust, grass, etc. could be
picked up by the air intake and thrown out
through the discharge opening, damaging the
unit or property, or causing serious injury to by-
standers or the operator.
STARTING A COLD ENGINE
1. Move throttle lever to the position.
2. Move choke lever to the FULL CHOKE
position.
3. Slowly press the primer button 8 times.
Throttle Lever
Choke Lever
Primer Button
4. Pull starter rope sharply until engine at-
tempts to run, but nomore than 5pulls (be-
low 30_F, 8 pulls).
NOTE: If engine attempts to start before the
5th pull, go to next step immediately.
5. Move the choke lever to the HALF
CHOKE position.
6. Pull the starter rope sharply until the en-
gine runs, but no more than 5 pulls (below
30_F, 10 pulls).
7. After a 5 second warm--up, move the
choke lever to the RUN position.
8. Allow the unit to run for 30 more seconds
at the RUN position before moving the
throttle lever to the position.
If engine has not started after 5 pulls (at HALF
CHOKE), repeat STARTING A COLDENGINE
procedure. If engine still does not start,proceed
to STARTING A FLOODED ENGINE.
9. To stop the engine, move thethrottle leverto
the STOP position.
STARTING A WARM ENGINE
NOTE: If fuel tank is empty, add fuel; then,
follow STARTING A COLD ENGINE proce-
dure. Do not fill fuel tank while engine is hot.
1. Move throttle lever to the position.
2. Pull starter rope sharply until engine runs,
but no more than 5 pulls.
NOTE:If engine has not started, pull starter
rope 5 more pulls. If engine still does not run,
it is probably flooded.
3. To stop the engine, move thethrottle leverto
the STOP position.
STARTING A FLOODED ENGINE
Flooded engines can be started by placing the
choke lever in the RUN position. Move throttle
lever to the fast position ; then, pull rope
until engine starts. After engine starts, move the
throttle lever to the slow position to allow
engine to idle.
Starting could require pulling the starter rope
many times depending on how badly the unit is
flooded.
If unit still doesn’t start refer to the TROUBLE-
SHOOTING TABLE or call 1-800-554-6723.
MAINTENANCE
WARNING: Avoid touching muffler
unless engine and muffler are cold. A hot
muffler can cause serious burns.
WARNING: Stop engine and be sure
the impeller blades have stopped turning be-
fore opening the vacuum inlet door or at-
tempting to insert or remove the vacuum or
blower tubes. The rotating blades can cause
serious injury. Always disconnect the spark
plug before performing maintenance or ac-
cessing movable parts.
GENERAL RECOMMENDATIONS
The warranty onthis unit does not coveritems
that have been subjected to operator abuse
or negligence. To receive full value from the
warranty, the operator must maintain unit as
instructed in this manual. Various adjust-
ments will need to be made periodically to
properly maintain your unit.
CHECK FOR LOOSE
FASTENERS AND PARTS
SSpark Plug Boot
SAir Filter
SHousing Screws
SMuffler
CHECK FOR DAMAGED OR WORN
PARTS
Contact an authorized service dealer for re-
placement of damaged or worn parts.
SFuel Tank -- Do not useunit if fuel tankshows
signs of damage or leaks.
SVacuum Bag -- Do not use vacuum bag if it
is torn or damaged.

-- 8 --
INSPECT AND CLEAN UNIT AND
DECALS
SAfter each use, inspect complete unit for
loose or damaged parts. Clean the unit and
decals using a damp cloth with amild deter-
gent.
SWipe off unit with a clean dry cloth.
CLEAN AIR FILTER
Air Filter
Cover
Air Filter Screws
Cleaning the air filter:
A dirty air filter decreases engine perform-
ance and increases fuel consumption and
harmful emissions. Always clean or replace
air filter after every 5 hours of operation or
yearly, whichever comes first.
1. Clean the cover and the area around it to
keep debris from falling into the carburetor
chamber when the cover is removed.
2. Remove parts as illustrated.
NOTE: Donotcleanfilter ingasoline orother
flammable solvent. Doing so can create a fire
hazard or produce harmful evaporative emis-
sions.
3. Wash the filter in soap and water.
4. Allow filter to dry.
5. Apply a few drops of oil to the filter;
squeeze filter to distribute oil.
6. Replace parts.
REPLACE SPARK PLUG
Replace spark plug each year to ensure the
engine starts easier and runs better. Set
spark plug gap at 0.025 inch (0.6 mm). Igni-
tion timing is fixed, nonadjustable.
1. Twist, then pull off spark plug boot.
2. Remove spark plug from cylinder and dis-
card.
3. Replace with Champion RCJ-6Y spark
plug and tighten securely with a 3/4 inch
(19 mm) socket wrench.
4. Reinstall the spark plug boot.
REPLACE FUEL FILTER
To replace fuel filter, drain unit byrunning itdry
of fuel, then remove fuel cap/retainer assem-
bly from tank. Pull filter from tank and remove
it from the fuel line. Install new fuel filter on fuel
line; reinstall parts.
Fuel Line
Fuel Filter
CHECK MUFFLER MOUNTING
SCREWS
Once each year, ensure muffler mounting
screws are secure and tightened properly to
prevent damage. Mounting
Screw
Holes
Muffler Cover
Screws
1. Loosen and remove the 2screws fromthe
muffler cover.
2. Remove the muffler cover.
3. Tighten the 2 muffler mounting screws se-
curely.
4. Reinstall muffler cover and 2 screws.
Tighten securely.
INSPECT MUFFLER AND SPARK
ARRESTING SCREEN
WARNING: The muffler on this prod-
uct contains chemicals known to the State of
California to cause cancer.
As the unit is used, carbon deposits build up
on the muffler and spark arresting screen,
and must be removed to avoid creating a fire
hazard or affecting engine performance.
VIEW OF MUFFLER
Exhaust
Diverter
Screws
Spark arresting
screen
Replace the spark arresting screen every 50
hours of operation or if any damage or breaks
in the screen are noted.

-- 9 --
NOTE: Do not attempt to clean the spark ar-
resting screen.
1. Loosen and remove the 2screws fromthe
muffler cover. Remove the muffler cover.
2. Loosen and remove both screws from the
exhaust diverter.
3. Remove the exhaust diverter and spark
arresting screen.
4 Install new spark arresting screen.
5. Reinstall exhaust diverter and both
screws. Tighten screws securely.
6. Reinstall muffler cover and 2 screws.
Tighten securely.
NOTE: If any part of the muffler is cracked,
broken or damaged, we recommend that the
muffler be replaced.
CARBURETOR ADJUSTMENTS
There is no screw for idle adjustment on your
blower. The throttle lever is used to control
engine speed. The throttle lever can be
placed in one of four positions: STOP, IDLE
or , FULL THROTTLE or , and one
intermittent position. If yourengine will notrun
properly or you require further assistance,
contact an authorized service dealer or call
1--800--554--6723.
STORAGE
WARNING: Perform the following
steps after each use:
SAllow engine to cool, and secure the unit
before storing or transporting.
SStore unit and fuel in a well ventilated area
where fuel vapors cannot reach sparks or
open flames from water heaters, electric
motors or switches, furnaces, etc.
SStore unit with all guards in place. Position
unit so that any sharp object cannot acci-
dentally cause injury.
SStore unit and fuel well out of the reach of
children.
SEASONAL STORAGE
Prepare unit for storage at end of season orif
it will not be used for 30 days or more.
If your unit is to be stored for a period of time:
SClean the entire unit before lengthy stor-
age.
SStore in a clean dry area.
SLightly oil external metal surfaces.
FUEL SYSTEM
Under FUELING ENGINE in the OPERA-
TION section of this manual, see message la-
beled IMPORTANT regarding the use of ga-
sohol in your engine.
Fuel stabilizer is an acceptable alternative in
minimizing the formation of fuel gum deposits
during storage. Add stabilizer to gasoline in fuel
tank or fuel storage container. Follow the mix
instructions found on stabilizer container. Run
engine at least 5 minutes after adding stabilizer.
ENGINE
SRemove spark plug and pour1teaspoon of
40:1, 2-cycle engine oil (air cooled) through
the spark plug opening. Slowly pull the
starter rope 8 to 10 times to distribute oil.
SReplace spark plug with new one ofrecom-
mended type and heat range.
SClean air filter.
SCheck entire unit for loose screws, nuts,
and bolts. Replace any damaged, broken,
or worn parts.
SAt the beginning of the next season, use
only fresh fuel having theproper gasoline to
oil ratio.
OTHER
SDo not store gasoline from one season to
another.
SReplace your gasoline can if it starts to rust.

-- 10 --
TROUBLE CAUSE REMEDY
Engine will not
start. 1. Engine flooded.
2. Fuel tank empty.
3. Spark plug not firing.
4. Fuel not reaching
carburetor.
5. Compression low.
1. See “Starting a Flooded Engine”
in Operation section.
2. Fill tank with correct fuel mixture.
3. Install new spark plug.
4. Check for dirty fuel filter; replace.
Check for kinked or split fuel line;
repair or replace.
5. Contact an authorized service dealer.
Engine will not
idle properly. 1. Fuel not reaching
carburetor.
2. Carburetor requires
adjustment.
3. Crankshaft seals worn.
4. Compression low.
1. Check for dirty fuel filter; replace.
Check for kinked or split fuel line;
repair or replace.
2. Contact an authorized service dealer.
3. Contact an authorized service dealer
4. Contact an authorized service dealer.
1. Air filter dirty.
2. Fuel not reaching
carburetor.
3. Spark plug fouled.
4. Carburetor requires
adjustment.
5. Carbon build up.
6. Compression low.
Engine will not
accelerate,
lacks power, or
dies under a
load.
1. Clean or replace air filter.
2. Check for dirty fuel filter; replace.
Check for kinked or split fuel line;
repair or replace.
3. Clean or replace spark plug
and re-gap.
4. Contact an authorized service dealer.
5. Contact an authorized service dealer.
6. Contact an authorized service dealer.
Engine smokes
excessively. 1. Choke partially on.
2. Fuel mixture incorrect.
3. Air filter dirty.
4. Carburetor requires
adjustment.
1. Adjust choke.
2. Empty fuel tank and refill with
correct fuel mixture.
3. Clean or replace air filter.
4. Contact an authorized service dealer.
Engine runs hot. 1. Fuel mixture incorrect.
2. Spark plug incorrect.
3. Carburetor requires
adjustment.
4. Carbon build up.
1. See “Fueling Engine” in Operation
section.
2. Replace with correct spark plug.
3. Contact an authorized service dealer.
4. Contact an authorized service dealer.
TROUBLESHOOTING TABLE
WARNING: Always stop unit and disconnect spark plug before performing any of the
recommended remedies below other than remedies that require operation of the unit.

-- 11 --
LIMITED WARRANTY
ELECTROLUX HOME PRODUCTS, INC.,
warrants to the original purchaser that each
new Poulan PROrbrand gasoline tool or at-
tachment is free from defects in material and
workmanship and agrees to repair or replace
under this warranty any defective gasoline
product or attachment as follows from the
original date of purchase:
2 YEARS -- Parts and Labor, when used for
household purposes.
90 DAYS -- Parts and Labor, when used for
commercial, professional, or income producing
purposes.
30 DAYS -- Parts and Labor, if used for rental
purposes.
This warranty is not transferable and does not
cover damage or liability caused by improper
handling, improper maintenance, or the use of
accessories and/or attachments not specifically
recommended by ELECTROLUX HOME
PRODUCTS, INC., for this tool. Additionally,
this warranty does not cover tune-ups, spark
plugs, filters, starter ropes, starter springs, cut-
ting line, or rotating head parts that will wearand
requirereplacement with reasonable use during
the warranty period. This warranty does not
cover predelivery setup or normal adjustments
explained in the instruction manual.
THIS WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS, AND YOU MAY HAVE
OTHER RIGHTS WHICH VARY FROM
STATE TO STATE.
NO CLAIMS FOR CONSEQUENTIAL OR
OTHER DAMAGES WILL BE ALLOWED,
AND THERE ARE NO OTHER EXPRESS
WARRANTIES EXCEPT THOSE EX-
PRESSLY STIPULATED HEREIN.
SOME STATES DO NOT ALLOW LIMITA-
TIONS ON HOW LONG AN IMPLIED WAR-
RANTY LASTS OR THE EXCLUSION OR
LIMITATIONS OF INCIDENTAL OR CONSE-
QUENTIAL DAMAGES, SO THE ABOVE
LIMITATIONS OR EXCLUSION MAY NOT
APPLY TO YOU.
The policy of ELECTROLUX HOME PROD-
UCTS, INC., is to continuously improve its
products. Therefore, ELECTROLUX HOME
PRODUCTS, INC., reserves the right to
change, modify, or discontinue models, de-
signs, specifications, and accessories of all
products at any time without notice or obliga-
tion to any purchaser.
U.S. EPA/CALIFORNIA
EMISSION CONTROL WARRANTY STATEMENT
YOUR WARRANTY RIGHTS AND OBLIGA-
TIONS: The U.S. Environmental Protection
Agency/California Air Resources Board and
ELECTROLUX HOME PRODUCTS, INC., are
pleased to explain theemissionscontrolsystem
warranty on your year 2002--2004 small off--
road engine. In California, all small off--road en-
gines must be designed, built, and equipped to
meet the State’s stringent anti--smog standards.
ELECTROLUX HOME PRODUCTS, INC.,
must warrant the emission control system on
your small off--road engine for the periods of
time listed below provided there has been no
abuse, neglect, or improper maintenance of
your small off--road engine. Your emission con-
trol system includes parts such as the carbure-
tor and the ignition system. Where a warrant-
able condition exists, ELECTROLUX HOME
PRODUCTS, INC., will repair your small off--
road engine engineat no cost to you. Expenses
covered under warranty include diagnosis,
parts and labor. MANUFACTURER’S WAR-
RANTY COVERAGE: If any emissions related
part on your engine (as listed under Emissions
Control Warranty Parts List)is defectiveor ade-
fect in the materials or workmanship of the en-
gine causes the failure of such an emission re-
lated part, the part will be repaired or replaced
by ELECTROLUX HOME PRODUCTS, INC.
OWNER’S WARRANTY RESPONSIBILI-
TIES:As the small off--road engine engine own-
er, you are responsible for the performance of
the required maintenance listed in your instruc-
tion manual. ELECTROLUX HOME PROD-
UCTS, INC., recommendsthat youretain all re-
ceipts covering maintenance on your small off--
road engine, but ELECTROLUX HOME
PRODUCTS, INC., cannot deny warranty sole-
ly for the lack of receipts or foryour failure to en-
sure the performance of all scheduled mainte-
nance. As the small off--road engine engine
owner, you should be aware that ELECTRO-
LUX HOME PRODUCTS, INC., may deny you
warranty coverage if yoursmall off--roadengine
engine or apart of it has failed due to abuse, ne-
glect, improper maintenance, unapproved mod-
ifications, or the use of parts not made or ap-
proved by the original equipment manufacturer.
You are responsible for presenting your small
off--road engine to an ELECTROLUX HOME
PRODUCTS, INC., authorized repair center as
soon as a problem exists. Warranty repairs
should be completed in a reasonable amountof
time, not to exceed 30 days. If you have any
questionsregardingyourwarrantyrightsandre-
sponsibilities, you should contact your nearest
authorized service center or call ELECTRO-
LUX HOME PRODUCTS, INC., at
1--800--554--6723. WARRANTY COM-
MENCEMENT DATE: The warranty period be-
gins on the date the small off--road engine is
purchased. LENGTH OF COVERAGE: This
warranty shall be for a period of two years from
the initial date of purchase. WHAT IS COV-
ERED: REPAIR OR REPLACEMENT OF
PARTS. Repair or replacement of any war-
ranted part will be performedat no charge to the
owner at an approved ELECTROLUX HOME
PRODUCTS, INC., servicing center. If you
have any questions regarding your warranty
rights and responsibilities, you should contact
your nearest authorized service center or call

-- 12 --
ELECTROLUX HOME PRODUCTS, INC., at
1--800--554--6723 WARRANTY PERIOD: Any
warranted part which is not scheduled for re-
placement as required maintenance, orwhich is
scheduled only for regular inspection to the ef-
fect of “repair or replace as necessary” shall be
warrantedfor2 years. Anywarranted partwhich
is scheduled for replacement as required main-
tenance shall be warrantedfor the period oftime
up to the first scheduled replacement point for
that part. DIAGNOSIS: The owner shall not be
charged for diagnostic labor which leads to the
determination that a warranted part is defective
if the diagnostic work is performed at an ap-
proved ELECTROLUX HOME PRODUCTS,
INC., servicing center. CONSEQUENTIAL
DAMAGES: ELECTROLUX HOME PROD-
UCTS, INC., may be liable fordamages toother
engine components caused by the failure of a
warranted part still under warranty. WHAT IS
NOT COVERED: All failures caused by abuse,
neglect, or improper maintenance are not cov-
ered. ADD--ON OR MODIFIED PARTS: The
use of add--on or modified parts canbe grounds
for disallowing a warranty claim. ELECTRO-
LUX HOME PRODUCTS, INC., is not liable to
cover failures of warranted parts caused by the
use of add--on or modified parts. HOW TOFILE
ACLAIM:If you have any questions regarding
your warranty rights and responsibilities, you
should contact your nearest authorized service
center or call ELECTROLUX HOME PROD-
UCTS, INC., at 1--800--554--6723. WHERE TO
GET WARRANTY SERVICE: Warranty ser-
vices or repairs shall be provided at all ELEC-
TROLUX HOME PRODUCTS, INC., service
centers. Call: 1--800--554--6723 MAINTE-
NANCE, REPLACEMENT AND REPAIR OF
EMISSION RELATED PARTS: Any ELEC-
TROLUX HOME PRODUCTS, INC., approved
replacement part used in the performance of
any warranty maintenance or repair on emis-
sion related parts will be provided without
chargetotheownerifthe partis underwarranty.
EMISSION CONTROL WARRANTY PARTS
LIST: Carburetor, Ignition System: Spark Plug
(covered up to maintenance schedule), Ignition
Module, Muffler including catalyst. MAINTE-
NANCE STATEMENT: The owner is responsi-
ble for the performance of all required mainte-
nance as defined in the instruction manual.
This engine is certified to be emissions compliant for the following use:
Moderate (50 hours)
Intermediate (125 hours)
Extended (300 hours)
