CUTTING SAFETY
WARNING: Inspect the area before
each use. Remove objects (rocks, broken
glass, nails, wire, etc.) which can be thrown
by or become entangledin line. Hard objects
can damage thetrimmer headand be thrown
causing serious injury.
SUse only for trimming, scalping, mowing and
sweeping. Do not use for edging, pruning or
hedge trimming.
SKeep firm footing and balance. Do not over-
reach.
SKeep all parts of your body away from muffler
and spinning line. Keep engine below waist
level. A hot muffler can cause serious burns.
SCut from your left to your right. Cutting on
right side of the shield will throw debris away
from the operator.
SUse only in daylight or goodartificial light.
SUse only for jobs explained in this manual.
TRANSPORTINGAND STORAGE
SAllow enginetocool beforestoring ortrans-
porting in vehicle.
SEmpty the fueltank beforestoring or trans-
portingtheunit.Useupfuelleftinthecarbu-
retor by starting the engineandletting itrun
until it stops.
SStoreunitandfuelinareawherefuelvapors
cannot reach sparks or open flames from
water heaters,electric motors or switches,
furnaces, etc.
SStore unit so line limiter blade cannot acci-
dentally cause injury. Theunit can behung
by the shaft.
SStore unit out of reach of children.
SAFETYNOTICE:Exposure to vibrations
through prolonged use of gasoline powered
handtools could cause bloodvessel or nerve
damage in the fingers, hands, and joints of
people prone to circulation disorders or ab-
normal swellings. Prolonged use in cold
weatherhasbeenlinkedtobloodvesseldam-
ageinotherwisehealthypeople. Ifsymptoms
occur such as numbness, pain, loss of
strength, change in skin color or texture, or
loss of feeling in the fingers, hands, or joints,
discontinuetheuseofthis toolandseekmed-
ical attention. An anti--vibrationsystem does
not guarantee the avoidance of these prob-
lems. Users who operate power tools on a
continual and regular basis must monitor
closely their physical conditionand thecondi-
tion of this tool.
SPECIALNOTICE: This unit is equipped
with a temperaturelimiting muffler and spark
arresting screen which meets the require-
mentsofCaliforniaCodes4442and4443. All
U.S. forest land and the states of California,
Idaho, Maine, Minnesota, New Jersey, Ore-
gon, and Washington require by law that
many internal combustion engines be
equippedwithasparkarrestingscreen. Ifyou
operateinalocalewheresuchregulationsex-
ist, youarelegallyresponsibleformaintaining
theoperatingconditionoftheseparts. Failure
to do so is a violation of the law. For normal
homeowneruse,themufflerandsparkarrest-
ing screen will not require any service. After
50 hours of use, we recommend that your
muffler be serviced or replaced by an autho-
rized service dealer.
ASSEMBLY
WARNING: If received assembled,
repeatall steps toensure yourunitis properly
assembled and all fasteners are secure.
Examine parts for damage. Do not use dam-
aged parts.
NOTE:If you need assistance or find parts
missing or damaged, call 1-800-554-6723.
It is normal for the fuel filter to rattle in the
empty fuel tank.
Finding fuel or oil residue onmuffler is normal
due to carburetor adjustments and testing
done by the manufacturer.
ADJUSTINGTHE HANDLE
WARNING: Whenadjustingtheassist
handle,be sure it remains above the safety label
and below the mark or arrow on the shaft.
1. Loosen wing nut on handle.
2. Rotate the handle on the shaftto an upright
position; retighten wing nut.
ATTACHING SHIELD
WARNING: The shield must be prop-
erly installed. The shield provides partial protec-
tion to the operator and others from the risk of
thrown objects, andis equipped witha linelimit-
er blade which cuts excess line to the proper
length. The line limiter blade (on underside of
shield) is sharp and can cut you.
For proper orientation of shield, see KNOW
YOUR TRIMMER illustration in OPERATION
section.
1. Remove wing nut from shield.
2. Insert bracket into slot as shown.
3. Pivot shielduntil boltpasses throughhole
in bracket.
4. Securely tighten wing nut onto bolt.
Wing Nut
Bracket
Slot
Shield
Gearbox
PIVOT
